Surge Protection
For Business-Critical Continuity

Communications/Data/Signal Line Surge Protection

Product Catalog

TM

Mission-Critical Voice and Data
Signal Protection

Unmatched Protection for
Peace of Mind …

company has made in sophisticated communications

systems. Now think how costly it would be to your

company if this mission-critical equipment went down.

The fact is — in a nanosecond — power surges, spikes

and transients can compromise or totally disrupt voice

and data communications, costing thousands in repairs

and lost productivity.

The stakes are far too high to place your trust in

anything but the best — Emerson Network Power Surge

Protection products.

Our Transient Voltage Surge Suppression (TVSS)

and data/signal line protection products provide

the protection you need to help eliminate damage,

disruption and costly downtime. Plus, all of the

Think of the investment your

power quality solutions in this catalog are backed by

a team of power quality specialists who understand

communications systems as thoroughly as the products

they sell.

Let Emerson Network Power Surge Protection provide

unmatched protection and peace of mind.

Table of Contents

Products

Page #

TRANSIENT VOLTAGE SURGE SUPPRESSION

™

PowerSure

DMK Series 2

PowerSure™ — IH Series 3

PowerSure

PowerSure

™

™

seireS MI/MPL — 4

seireS LI/LPL — 5

PowerSure™ — Ordering Information 6

Islatrol™ — SP-6TVN 7

PowerSure™ EMC Series 8

PowerSure™ TCS-HW Series 9

Islatrol™ — RM Series

10

DATA/SIGNAL LINE PROTECTION

Edco RM-CAT6 Series 11

Edco RM-CXO6 11

Edco PLP-S Series 12

Edco FAS-1 and FAS-2 Series 13

Edco PHC Series 14

The IEEE Emerald Book

recommends that a listed

surge protection device (SPD)

be installed at the service

entrance of all facilities

to divert large transients

associated with lightning or

major power system events

outside the facility.

Edco RJA-RJD Series 15

Edco H Series (

and TTA-2 Test Point Adaptor) 16

Edco COHP Series 17

Edco MEGA-TEK 25 Series 18

Edco MGB Ground Rail 19

Edco PC642 Series 20

Edco PC642PTU 21

Edco CAT6-5 POE 21

Edco LCDP Series 22

Edco TCS-T1 Series 23

Edco TCS-Multi T1 Series 24

Edco DCB Series 25

Edco CCTV-1 26

Edco CX Series 26

Edco CATV-DF 27

Edco NET Series

Edco FAS-TEL and FAS-31XT

28

29

Transients generated within

the premises can best be

diverted by SPDs located

close to the internal source of

the transients or close to the

electronic load equipment,

using a listed and properly

rated SPD applied to each

individual or set of electronic

conductors (e.g. power, voice

and data).

Best results are obtained if

both locations are protected.

Transient Voltage Surge Suppression

Featuring

NTI V3 SHIELD

Technology

Emerson Network Power designs superior

Transient Voltage Surge Suppression (TVSS)

devices for a variety of field applications.

The PowerSure® DMK Series is available

with various configurations and energy-

handling ratings to ensure the proper level

of protection for your application. As part of

the total power protection solution, Emerson

Network Power provides engineering

assistance to configure the appropriate

equipment for your individual needs.

™

PowerSure® DMK Series

Surge Suppression for AC Applications

The PowerSure® DMK Series of Transient Voltage Surge Suppressors (TVSS)
provides fast, reliable protection for AC circuits. A small footprint allows easy
installation in almost any environment. Install at your critical distribution panel to
protect all down-line equipment.

The PowerSure® DMK Series features independent primary Silicon Avalanche
Diode (SAD) and secondary Metal Oxide Varistor (MOV) suppression technology
to ensure continued protection. The latest technological advancement of the
DMK Series is the addition of V3 SHIELD™ Technology, which provides the lowest­possible clamp voltage to peak pulse current handling far in excess of traditional
fused designs. Combined with a solid grounding system, the DMK Series is the
ultimate in protecting sensitive electronic equipment from damaging transient
voltage surges.

Features

■ Nondegrading Bipolar SAD technology

provides reliable performance with the
lowest-possible clamping voltage and
fastest response time in comparison to
other TVSS technologies

■ V3 SHIELD

thermal protection against prolonged
over-voltage conditions

■ V3 SHIELD

peak pulse current to be handled by the
suppression module, well in excess to
traditional fused modules

™

Tec hnol ogy provides

™

Tec hnol ogy allows act ual

■ Status indication on each module to show

normal compromised suppression status

■ Field re placeab le m odul es fo r easy repa ir

and upgrade

■ Independent primary SAD suppression and

secondary MOV suppression technology
ensures continued protection

■ Remote failure indication for long

distance monitoring

■ Interior and exterior enclosures available

■ 3 year warranty

General Technical Specifications

Part Number PowerSure® DMK-B

Operating Voltage 120/240 VAC Split Phase

Clamping Voltage 211 VAC

Operating Current NA, Parallel

Total Peak Surge Current 156kA

Operating Frequency 50/60 Hz

EMI Attenuation NA

SPD Technology SAD / MOV

Modes of Protection L-L & L-N (Standard), N-G
(Enhanced Mode option)

Status Indication

Connection Type Wire Leads

Operating Temperature -40°C to +50°C

Dimensions (Inches) 14H x 12W x 6D

Weight 22 lbs

Certifications UL 1449

Notes: NEMA 1 (interior) or NEMA 4 (exterior) enclosures available. All units are UL 1449 Listed. Enhanced
mode (N-G) protection option available. All units come standard with Remote Failure Indication. Counter
option is available with a transient counter (interior enclosure only).

Power On & MOVs functional

Part Number PowerSure® DMK-C

Operating Voltage 120/208 VAC 3 Phase Wye

Clamping Voltage 211 VAC

Operating Current NA, Parallel

Total Peak Surge Current 156kA

Operating Frequency 50/60 Hz

EMI Attenuation NA

SPD Technology SAD / MOV

Modes of Protection L-L & L-N (Standard), N-G
(Enhanced Mode option)

Status Indication

Connection Type Wire Leads

Operating Temperature -40°C to +50°C

Dimensions (Inches) 20H x 12W x 6D

Weight 30 lbs

Certifications UL 1449

Power On & MOVs functional

2

Transient Voltage Surge Suppression

PowerSure® — IH Series

Modular Surge Protective Device (SPD) capable of handling the high-impulse,
potentially damaging transients commonly found at the service entrance or
distribution panels. Its robust design allows for placement and protection in the
most severe exposure locations.

Features

■ Surge current capacity — 100,000 to

400,000 Amps per phase

■ Replaceable modules ensure protected

mode flexibility

■ All voltage and phase configurations

■ Unique MOV /sil ver l ink fuse arr ay enab les

the IH Series to deliver the industry’s most
robust design; Coordination between fuse
gauge and MOV ensures repeatable strike
performance

■ Status indication includes: audible alarm,

for m C cont act, and int ernal/e xter nal
status indi cation

■ Optional equipment includes rotary

disco nnec t, surge counte r, NEMA 3R, 4 o r
4X enclosures

■ 5 year warranty

Performance Technical

Clamping

UL 1449 Classification*

120/208

Line to Neutral 400 Volts

Line to Line 800 Volts

Line to Ground 400 Volts

Neutral to Ground 400 Volts

277/480

Line to Neutral 800 Volts

Line to Line 1,500 Volts

Line to Ground 800 Volts

Neutral to Ground 800 Volts

480

Line to Line 1,500 Volts

Line to Ground 1,500 Volts

* UL classifications for other voltages available

upon request.

Specifications

Peak Surge Current Capability (8 x 20 µs)

Model: IHxxxx400

Phase: 400,000 Amps

L-N: 200,000 Amps

L-L: 200,000 Amps

L-G: 200,000 Amps

N-G: 200,000 Amps

Model: IHxxxx200

Phase: 200,000 Amps

L-N: 100,000 Amps

L-L: 100,000 Amps

L-G: 100,000 Amps

N-G: 100,000 Amps

Model: IHxxxx200-2

Phase: 200,000 Amps

L-N: 200,000 Amps

L-L: 200,000 Amps

L-G: N/A

N-G: 200,000 Amps

Model: IHxxxx100-2

Phase: 100,000 Amps

L-N: 100,000 Amps

L-L: 100,000 Amps

L-G: N/A

N-G: 100,000 Amp

General Technical Specifications

Operating Voltage Range +/- 15%

Fault Current Rating (AIC) 200 kAIC

Operating Frequency Range 47–63 Hz

Capacity Continuous

50 V EMI/RFI Attenuation 50 dB

Response Time < 0.5 ns

Operating Temperature -40°C to +50°C

Operating Humidity 0% to 95%

Certifications UL 1449, 1283, CUL, CE

Warranty 5 Year

Dimensional Diagram

Model A B C D E F

IHxxxY400 16 14 8 16.75 12 .31

IHxxxD400 16 14 8 16.75 12 .31

IHxxxY200-2 16 14 8 16.75 12 .31

IHxxxD200-2 16 14 8 16.75 12 .31

IHxxxY200 16 14 8 16.75 12 .31

IHxxxD200 16 14 8 16.75 12 .31

IHxxxY100-2 16 14 8 16.75 12 .31

IHxxxD100-2 16 14 8 16.75 12 .31

3

Transient Voltage Surge Suppression

PowerSure® — LPM/IM Series

A compact Surge Protective Device (SPD) designed to protect electronic

equipment and microprocessor-based systems from transients on distribution

and sub-distribution panels, or any medium exposure locations.

Features

 Surge cu rrent capaci ty — 100,000 to

160,000 Amps per p hase

 All mode and 2 mode prot ecti on opti on

 Small footprint s

 All voltage and p hase co nfigur ations

 For m C contact for rem ote indicati on,

LED status in dication, and au dible ala rm
standar d

 Nem a 12 metal enclosu re

 Sand enca psulation

 Therm al protec tion

 Silve r li nk fusing

 5 year warrant y

Performance Technical Specifications

Clamping

UL 1449 Classification*

120/208

Line to Neutral 400 Volts

Line to Line 800 Volts

Line to Ground 400 Volts

Neutral to Ground 400 Volts

277/480

Line to Neutral 800 Volts

Line to Line 1,500 Volts

Line to Ground 800 Volts

Neutral to Ground 800 Volts

480

Line to Line 1,500 Volts

Line to Ground 1,500 Volts

* UL classifications for other voltages available

upon request.

Peak Surge Current Capability (8 x 20 µs)

Model: IMxxxx160

Phase: 160,000 Amps

L-N: 80,000 Amps

L-L: 80,000 Amps

L-G: 80,000 Amps

N-G: 80,000 Amps

Model: IMxxxx100-2

Phase: 100,000 Amps

L-N: 100,000 Amps

L-L: 100,000 Amps

L-G: N/A

N-G: 100,000 Amps

Dimensional Diagram

General Technical Specifications

Operating Voltage Range +/- 15%

Fault Current Rating (AIC) 65 kAIC

Operating Frequency Range 47–63 Hz

Capacity Continuous

50 V EMI/RFI Attenuation 40 dB

Dry Contact Rating 125 VAC, 8A, 1.0 pf

Response Time < 0.5 ns

Operating Temperature -45°C to +50°C

Operating Humidity 0% to 95%

Certifications UL 1449, CUL

Warranty 5 Year

Model A B C D E F

IMxxxY160 8 6 4 8.75 4 .31

IMxxxD160 8 6 4 8.75 4 .31

IMxxxY100-2 6 4 3 6.75 2 .31

IMxxxD100-2 6 4 3 6.75 2 .31

4

Transient Voltage Surge Suppression

PowerSure® — LPL/IL Series

Electronic grade Surge Protective Device (SPD) designed to protect

electronic equipment and microprocessor-based systems from transients on

sub-distribution panels, branch panels, or equipment located in

low exposure locations.

Features

 Surge cu rrent capaci ty — 25,000 to

100,000 Amps per phase

 All mode and 2 mode protec tion o ption

 Small footprint

 All voltage and p hase co nfigur ations

 LED status indic ation and fo rm C contact

for r emote indicat ion

 Sand enca psulation

 Therm al protect ion

 Silve r link fusing

 5 year warr anty

Performance Technical Specifications General Technical Specifications

Clamping

UL 1449 Classification*

120/208

Line to Neutral 400 Volts

Line to Line 800 Volts

Line to Ground 400 Volts

Neutral to Ground 400 Volts

120/240

Line to Neutral 400 Volts

Line to Line 800 Volts

Line to Ground 400 Volts

Neutral to Ground 400 Volts

277/480

Line to Neutral 800 Volts

Line to Line 1,500 Volts

Line to Ground 800 Volts

Neutral to Ground 800 Volts

480

Line to Line 1,500 Volts

Line to Ground 1,500 Volts

* UL classifications for other voltages available

upon request.

Peak Surge Current Capability (8 x 20 µs)

Model: ILxxxx100

Phase: 100,000 Amps

L-N: 50,000 Amps

L-L: 50,000 Amps

L-G: 50,000 Amps

N-G: 50,000 Amps

Model: ILxxxx50

Phase: 50,000 Amps

L-N: 25,000 Amps

L-L: 25,000 Amps

L-G: 25,000 Amps

N-G: 25,000 Amps

Model: ILxxxx25-2

Phase: 25,000 Amps

L-N: 25,000 Amps

L-L: 25,000 Amps

L-G: N/A

N-G: 25,000 Amps

Operating Voltage Range +/- 15%

Fault Current Rating (AIC) 14 kAIC

Operating Frequency Range 47–63 Hz

Capacity Continuous

50 V EMI/RFI Attenuation 40 dB

Dry Contact Rating 125 VAC, 8 A, 1.0 pf

Response Time < 0.5 ns

Operating Temperature -40°C to +50°C

Operating Humidity 0% to 95%

Certifications UL 1449, CUL, CE

Warranty 5 Year

Dimensional Diagram

5

Transient Voltage Surge Suppression

PowerSure® — Ordering Information

PowerSure® High Exposure Model Number : I H

®

PowerSure

PowerSure

Medium Exposure Model Number : I M

®

Low Exposure Model Number : I L

1 2

Voltage Code

Nominal Voltage Level Model
Identification

L–N L–L L–G

120 N/A 120 120

120 208 120

120 240 120

N/A 240 240 240

277 480 277 277

N/A 480 480 480

Other voltages available, please consult factory.

1 2 3 6

1 2 4

1 2 5

Phase Configuration

Phase Configuration Model
Identification

Single Phase 2 Wires + Gnd N
(Line & Neutral)

Single Phase 2 Wires + Gnd L
(Line & Line)

Single (Split) Phase S
3 Wires + Gnd

Three Phase Wye Y
4 Wires + Gnd

Three Phase Delta D
3 Wires + Gnd

Three Phase Delta Hi-Leg H
4 Wires + Gnd

Three Phase Wye w/no Neutral X
3 Wires + Gnd

How To Specify the Appropriate Model

All model numbers begin with a prefix (IH, IM, IL).
Moving from left to right, choose correct
configuration from each column for your
application. Your completed model number
should look similar to the example below:

Example Part Number: IH 120 L 200 4X

3

Surge Capacity (High Exposure)

Surge Capacity Per Phase Model
(L-N + L-G) Identification

400 kA

L–N L–G N–G 400

200 200 200

200 kA

L–N L–G N–G 200-2

200 N/A 200

200 kA

L–N L–G N–G 200

100 100 100

100 kA

L–N L–G N–G 100-2

100 N/A 100

4 5

Surge Capacity (Medium Exposure)

Surge Capacity Per Phase Model
(L-N + L-G) Identification

160 kA

L–N L–G N–G 160

80 80 80

100 kA

L–N L–G N–G 100-2

100 N/A 100

Recommended Connections

Surge Capacity (Low Exposure)

Surge Capacity Per Phase Model
(L-N + L-G) Identification

100 kA

L–N L–G N–G 100

50 50 50

50 kA

L–N L–G N–G 50

25 25 25

25 kA

L–N L–G N–G 25-2

25 N/A 25

6

Options

Option Model
Identification

Rotary Disconnect R

Surge Counter C

NEMA 3R Enclosure 3R

NEMA 4 Enclosure 4

NEMA 4X Enclosure 4X

6

Transient Voltage Surge Suppression

®

Islatrol

— SP-6TVN

Industrial Strength Surge Suppression (Series)

The Islatrol® SP-6TVN is an industrial-strength surge suppression/filtering device
that plugs into a standard duplex receptacle. It features uniquely designed
repositionable outlets for easy installation behind desks and other furniture.
It protects your sensitive home or office equipment, including TVs, home theaters,
satellite dishes, computers, printers, copiers, and fax machines, from damaging

power disturbances traveling through your wiring into your electrical outlets.

Features

■ Plugs into standard 120 V, 15 Amp

REPOSITIONABLE OUTLETS

General Technical S

AC Power Protection

Nominal Operating Voltage 120 VAC, Single Phase

Operating Voltage Range 120 VAC +/- 10%

Operating Frequency Range 47 – 63 Hz

Rated Output (Amps) 15 Amperes

ANSI/IEEE C62.41 Category Categor y A & B

Connection Type (6) 5-15R Receptacles and
5-15P Plug

Phase Configuration 2 Wire + Gnd

Size 7.5 x 4.75 x 1.75 (Inches)

Enclosure High Impact Plastic

Weight 2.0 lbs (0.9 kgs)

Modes Of Protection L – N, L – G, N – G

Indication of Suppression Status Status Indicator

Response Time < .5 ns Normal Mode

Certifications UL 1449 Listed

Warranty 5 Year

Maximum Continuous Operating Voltage (MCOV)

Line to Neutral 130 VAC

Peak Surge Current (8 x 20 µs)

Line to Neutral 13,000 Amps

Line to Ground 13,000 Amps

Neutral to Ground 13,000 Amps

Total 39,000 Amps

pecifications

electrical outlet

■ Total peak surge current capacity of

39,000 Amps

■ Cables for telephone, video, and

data connectors

■ Repositionable outlets rotate to

accommodate available space

■ Perfect for tight spaces, behind furniture

and appliances

■ Intelligent monitoring against improper

wiring/grounding

■ 60 dB maximum high frequency

■ Operational indicator lamp

■ 5 year limited warranty

ANSI/IEEE C62.41 Cat A Ringwave (6 kV, 200 A, 100 kHz)

Normal Mode 265 V

Common Mode 290 V

ANSI/IEEE C62.41 Cat B Ringwave (6 kV, 500 A, 100 kHz)

Normal Mode 275 V

Common Mode 290 V

Frequency Response

Normal Mode 60 dB Maximum, forward/reverse, 100 kHz to 50 MHz

Common Mode 40 dB Maximum, forward/reverse, 5 MHz to 50 MHz

Low Voltage Protection

Video 1 & 2 Phone Network

Connection Type Type “F” Type RJ-11 Type RJ-45

Cables Provided 6' (2x) Type “F” 6' RJ-11 Male 6' RJ-45 Male
Ends Ends Ends

Peak Surge Current 5 kA 2 kA 3 kA
(8 x 20 µs) (10 x 1000 µs) (8 x 20 µs)

Capacitance <12 pf <50 pf <70 pf

Protection Level L-G T-R, T-G, R-G L-G (8 Lines)

Clamping Voltage (DC) 145 V 270-350 V 30 V

Attenuation 1 dB @ 2 Ghz N/A N/A

7

Transient Voltage Surge Suppression

PowerSure® EMC Series

120/240 VAC Heavy Duty (Parallel)

The PowerSure® EMC Series surge suppressor is designed to protect AC
distribution panel circuits or 120 V power supplies feeding sensitive electronic
equipment. Electrically, the unit incorporates MOV and thermal fusing
technology. The PowerSure® EMC Series is designed to be installed in parallel on
standard single or split phase 120/240 VAC circuits.

Features

■ Fast response time

■

40,000 Amps per phase capacity

 Failsafe and fused

Operational status indicators



■

UL 1449 listed and OWHX listed

 5 year warranty

General Technical Specifications

Part Number PowerSure® EMC-240B

Operating Voltage 120/240 VAC

Clamping Voltage 395 VAC

Operating Current NA, Parallel

Total Peak Surge Current 80 kA (8 x 20 µs)

Operating Frequency 47–63 Hz

EMI Attenuation (100 kHz to 100 MHz) > 40 dB

SPD Technology Metal Oxide Varistors (MOVs)

Modes of Protection Line-to- Line,
Line-to-Neutral

Status Indication Power On & MOVs functional

Connection Type Wire Leads

Fault Current Rating 42 kAIC

Operating Temperature -40°C to +85°C

Dimensions (Inches) 4.6H x 2.2W x 2.8L

Weight 13.5 oz

Certifications UL 1449, Suppressor/
OWHX Arrester

8

Transient Voltage Surge Suppression

PowerSure® TCS-HW Series

Point-of-Application Protection

Utilizing bipolar Silicon Avalanche Diode (SAD) technology, the PowerSure®
TCS-HW Series features a two-stage design that provides superior protection
for sensitive equipment and for ANSI/IEEE C62.41 Location Category
A applications. The PowerSure® TCS-HW Series can be incorporated
into larger power protection or used as point-of-application protection.
Hardwired into a single 15 or 20 amp AC circuit, the PowerSure® TCS-HW
Series places protection at, or near, the critical load. The field-tested design
ensures continuous protection in the most demanding environments, with
configurations available for 120 and 240 VAC, single-phase applications.

Features

■ Provides superior, nondegrading protection

using bipolar SAD technology

■ Provides independent secondary stage for

maximum continued protection

■ Includes remote status indication via RJ-11 jack

■ Protects individual circuits

■ Withstands demanding environments with its

rugged metal enclosure

■ Installs easily

■ CE listed

■ 1 year warranty

General Technical Specifications

Part Number PowerSure® TCS-HWD
Operating Voltage 240 VAC Single Phase
Clamping Voltage 424 VAC
Operating Current 20A
Total Peak Surge Current 48kA
Operating Frequency 50/60 Hz
EMI Attenuation -13dB max
SPD Technology SAD / MOV / Filter
Modes of Protection L-N, L-G, N-G
Status Indication Power On & MOVs functional, Remote Status
Connection Type Wire Leads

Operating Temperature -40
Dimensions (Inches) 4H x 4W x 2.5D
Weight 1.25 lb
Certifications CUL, CE

°C to + 50°C

Part Number PowerSure® TCS-HWR
Operating Voltage 120 VAC Single Phase
Clamping Voltage 216 VAC
Operating Current 20A
Total Peak Surge Current 48kA
Operating Frequency 50/60 Hz
EMI Attenuation -13dB max
SPD Technology SAD / MOV / Filter
Modes of Protection L-N, L-G, N-G
Status Indication Power On & MOVs functional, Remote Status
Connection Type Wire Leads

Operating Temperature -40
Dimensions (Inches) 4H x 4W x 2.5D
Weight 1.25 lb
Certifications CUL, CE

°C to + 50°C

9

Transient Voltage Surge Suppression

Islatrol® — RM Series

120 VAC Rackmount

This line of AC surge protectors is ideal for protecting the power feeding
valuable rack equipment. All models provide ten protected outlets on
the back and two protected convenience outlets on the front. This series
provides 40,000 Amps of surge protection and up to 60 dB of high-

Model shown: RM-115-10 RM

frequency noise filtering. Status LEDs indicate the correct power is coming
to the unit, whether the unit is properly grounded and whether the surge
components are still in tact. Units are available with an optional digital
meter, mounted on the front of the unit, that will monitor the voltage,
current and power of the protected equipment.

Features

■ 40 kA surge protection

■ 60 dB max noise filtering

■ 15 A & 20 A models available

■ Power, ground and surge status indicators

■ Optional digital meter

■ Optional twist lock plug

■ 1 year warranty

General Technical Specifications

Part Number Voltage Amperage Plug (NEMA) Receptacles (NEMA) Digital Meter Locking Plug

RM-115-10RM 120 V 15 A 5-15P 5-15R Yes No

RM-120-10RM 120 V 20 A 5-20P 5-20R Yes No

RM-120-10RML 120 V 20 A L5-20P 5-20R Yes Yes

Rackmount AC Power Protection

Rated Voltage 120 V

Rated Current 15 A & 20 A

Peak Surge Current 20 kA/mode, 40 kA/phase

Response Time <5 ns

EMI/RFI Filtering 60 dB Max

LED Indicators Green-Power On
Green-Ground OK
Green-Surge Circuit OK

Digital Meter Voltage Amps, Watts, VA, Hz, PF,
(Optional) Kwh, and Clock

Input Power
15 A Models SJT 14/3C Power Cord (15 ft)
with NEMA 5-15P Plug

20A Models SJT 12/3C Power Cord (15 ft)
with NEMA 5-20P Plug
NEMA L5-20P Plug- Optional

Output Receptacles
15 A Models Front- (2) NEMA 5-15R
Back- (10) NEMA 5-15R

20 A Models Front- (2) NEMA 5-20R
Back- (10) NEMA 5-20R

Thermal Protection Thermal Protected MOVs

Over-current Protection Circuit

Dimensions 1.75"H x 19"W x 2.0"D (1U)

Warranty 1 Year

10

General Technical Specifications

Part Number RM-CAT6-16R

Operating Voltage 5 V

Clamping Voltage 8.2 V

Frequency Range 0–250 MHz

Operating Current 0.15 A

SPD Technology GDT, SAD, W/Series PTC

Modes of Protection Signal High-Low,
Signal High-Ground,
Signal Low-Ground

Data/Signal Line Protection

Edco RM-CAT6 Series

CAT6 Channel Rackmount

The Edco RM-CAT6 is a 16-channel high-speed data line protector that utilizes

a three-stage hybrid design technology. This unit addresses high-energy

voltage transients that can damage expensive computer equipment. Ideal

for network switches and hubs, the Edco RM-CAT6 is easily mounted in close

proximity to the protected equipment.

Features

 Three stage h ybri d

Exc eeds category 6 transmiss ion values

■

 Compa ct 1U rack size

 Low ins ertion l oss

Peak Surge Current 10 kA (8 x 20 µs)

Insertion Loss <0.1 dB

VSWR <1.2

Operating Humidity 0-95% Non-Condensing

Operating Temperature -40°C to +85°C

Input Connection Type RJ-45

Output Connection Type RJ-45

Mounting Rackmount

Enclosure Type Painted Steel

 1 year warr anty

Dimensions 1.75Hx19Wx6.3D

Weight 5.5 lbs

Warranty

1 Year

General Technical Specifications

Part Number RM-CX06-16R

Operating Voltage 5 VDC

Clamping Voltage 6 VDC

Operating Current 0.15 A

Peak Surge Current 20 kA (8 x 20 µs)

Edco RM-CX06

CCTV Channel Rackmount

The Edco RM-CX06 Surge Protective Device (SPD) is a 16 channel coax
SPD implementing three-stage hybrid technology. The SPD addresses over­voltage transients with a primary Gas Discharge Tube (GDT), and secondary
Silicon Avalanche Diode (SAD) components. Over-current protection, e.g.,
sneak and fault currents, are mitigated with solid-state resettable fuses — PTCs.
The Edco RM-CX06 SPD is designed in accordance with NFPA 780 (2004 edition)
requirements, with up to 20 kA of surge current capability.

Features

 Sneak/fault current protection

 Low insertion loss

 Shielded case

Frequency Range 0–100 MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology GDT, SAD, w/Series PTC

Connection Type BNC, 50/75 Ohm

 16 channel

 1 year warranty

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.75H x 19W x 2.0D (1U)

Weight 3.2 lbs

Certifications UL 497B

11

Data/Signal Line Protection

PLP-S

Edco PLP-S Series

Isolated Power Loop Circuit Protection

Using the highest quality Silicon Avalanche Diode (SAD) technology, the Edco
PLP-S Series is designed to protect your equipment from harmful power surges
and transients. Nondegrading SADs will last the lifetime of your equipment,
ensuring system uptime.

The Edco PLP-S Series of products provides isolated power loop circuit protection
in applications where higher current is required, such as fire alarm and
security systems.

Whether incorporated into a larger power protection strategy or used as primary
protection, the Edco PLP-S Series family provides unparalleled protection.
The Edco PLP-S Series keeps your critical equipment online in the most
demanding environmental conditions.

Features

■ Silicon Avalanche Diode (SAD) design for

nondegrading performance and protection

■ Provides protection for both single and

multiple circuits

■ Designed for easy hardwire installation

General Technical Specifications

Operating Voltage 5, 14, 30, 60, 140, 200 VDC

Clamping Voltage 6, 16, 33, 67, 150, 211 VDC

Operating Current 7A

Peak Surge Current 400 A

Frequency Range 0 to 30MHz

Insertion Loss < 0.1 dB at 30 MHz

SPD Technology SAD

Connection Type Terminal Screw

Operating Temperature -40°C to +60°C

Dimensions (Inches)

Weight 2.5 oz

Certifications

2H x 3W x 1.5D

UL 497B

■ Rugged enclosure for harsh environments

■ Provides unparalleled clamping performance

for maximum equipment protection

■ UL 497B listed

■ 1 year warranty

Ordering Information

12

Data/Signal Line Protection

< 3

10 – 1 4 AWG

GR OUND L UG

PROT EC TED E QU IP.

EQ UI P.

LI NE .

UNPR OT EC TE D OR F IE LD S ID E

Edco FAS-1 and FAS-2 Series

One and Two Pair Signal Line Protector (Commercial)

The Edco FAS-1 and Edco FAS-2 Series are multi-stage single pair or two pair
surge suppressors designed for high exposure applications. These products were
specifically designed to meet multiple low voltage protection applications in the

fire and security industries.

General Technical Specifications

Operating Voltage 15, 24, 36, 52 VDC

Clamping Voltage 18, 33, 43, 60 VDC

Operating Current 2.5 A

Peak Surge Current 10 kA (8 x 20 µs)

Frequency Range 0–10 MHz

Insertion Loss < 0.1 dB at 10 MHz

SPD Technology GDT, SAD, w/Series Inductor

Connection Type Terminal block
w/compression lugs
Terminals accept up to 12 AWG

Operating Temperature -40

Dimensions (Inches) FAS-1 = 1.5H x 1.5W x 2.8L
FAS-2 = 2H x 2W x 2.8L

Weight FAS-1 = 3.5 oz FAS-2 = 7 oz

Certifications UL 497B

°C to +85°C

Features

 Lightning protection for low voltage

 Data/signal lines

 Multi-stage protection

 Common mode and differential protection mode

 Automatic recovery



5 year warranty

Ordering InformationInstallation

12VDC use: FAS-1-018 HC (single pair)
FAS-2-018 HC (two pair)

24VDC use: FAS-1-033 HC (single pair)
FAS-2-033 HC (two pair)

24VAC use: FAS-1-043 HC (single pair)
FAS-2-043 HC (two pair)

48V Systems use: *FAS-1-060 HC (single pair)
*FAS-2-060 HC (two pair)

*Not UL Listed

Caution: The hybrid design of this product includes series
resistance. Do not place this product in service on any
signal line capable of continuously supplying more than

2.5 amperes.

DO NOT daisy chain grounds. NOT intended for
shield termination. Install ground in accordance
with all applicable codes.

13

PCB1B:

Unprotected Pair 2

Unprotected Pair 1

Protected Pair 2

Protected Pair 1

Keying Pin

Even TerminalsOdd Terminals

Field Side

Electronics Side

9

7

5

3

1

10

8

6

4

2

1.0

{

}

}

{

2.125"

2.4"

Groun d Termin al 1 or 10 to Bui ld ing A ppr oved G ro und

015

020
030

043

060

S P 7 0

130 R M S

15 Volts

20 Volts

30 Volts

43 Volts

60 Volts

*100 Volts

*150 Volts

*Not UL Listed

(For Horn, Bell, Strobes)

(For 120V Signal Lines)

VOLTAGE CLAMP

P H C

Data/Signal Line Protection

EDCO PCB1B BASE SOLD SEPARATELY

Edco PHC Series

Two-Pair Signaling Circuit Protector (Modular)

The Edco PHC Series is designed to protect two pairs of wires specifically
for alarm and security systems where operating currents can be as high
as 5 Amps. Electrically, the Edco PHC Series is a rugged series hybrid
implementing a staged complement of MOVs, copper wound inductors and
Silicon Avalanche Diodes. This design reduces series resistance to 0.2 Ohms
per pair. These products are intended to mate with an Edco PCB1B
gold-plated female terminal connector.

The Edco PHC modules plug into a base assembly (Edco PCB1B). The base
assembly can be mounted to any flat surface and should be located as close
as practical to the protected equipment. Terminal 1 and/or terminal 10
should be connected to Building-Approved Ground with 12 or 10 gauge

solid wire.

General Technical Specifications

Operating Voltage 12, 18, 24, 36, 52, 60, 120 VDC

Clamping Voltage 15, 20, 30, 43, 60, 70, 150 VDC

Operating Current 5 A

Peak Surge Current 10 kA (8 x 20 µs)

Frequency Range 0–10 MHz

Insertion Loss < 0.1 dB at 10 MHz

SPD Technology MOV, SAD, w/Series Inductor

Connection Type Terminal block
w/compression lugs
Terminals accept up to 10 AWG

Operating Temperature -40°C to +85°C

Dimensions (Inches) 3.7H x 1.75W x 2.375L
(PHC + PCB1B Base)

Weight 8 oz

Certifications UL 497B

Features

 Three-stage prote ctio n

 Differen tial prot ection

 Common mode p rote ctio n

 Plug-in module

 Autom atic recover y

 Fast r esponse time

Terminal Assignments

DO NOT daisy chain grounds. NOT intended for shield
termination. Install ground in accordance with all
applicable codes.

Dimensions

 Continu ous cur rent up to 5 Amps

 UL 497B liste d

 Req uire s Edco PCB1B base

 PC642PTU (Pass Thr u Unit)

ava ilab le for troubles hootin g

 5 year warrant y

Ordering Information

How to Specify the Appropriate Model

14

Applications Part Number

24V Horn, Strobe, Bell: PHC-043 & PCB1B

70V Speaker Lines: PHC-SP70 & PCB1B

Data/Signal Line Protection

Edco RJA-RJD Series

RJ-45 Telephone/Data

The Edco RJA and Edco RJD Series are four pair telephone/data line
protectors that implement advanced two stage hybrid design. These units
address over voltage transients with silicon breakover devices, while sneak
and fault currents are mitigated with PTC technology, which consists of solid
state resettable fuses.

The Edco RJA and Edco RJD Series incorporate Edco RJ-45 female jacks in and
out. The Edco RJA voltage clamp is set for C.O. Trunks and Analog Telephone
Extensions (with ring in voltage), and the Edco RJD voltage clamp is set for
Digital Extensions (no ring in voltage).

General Technical Specifications

Operating Voltage 48, 220 VDC

Clamping Voltage 55, 280 VDC

Operating Current 0.15 A

Peak Surge Current 200 A (10 x 1000 µs)

Frequency Range 0–50 MHz

Insertion Loss < 0.1 dB at 50 MHz

SPD Technology Silicon Breakover
Devices w/Series PTC

Connection Type RJ-45 Jacks

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.0H x 2.5W x 4.25L

Weight 3 oz

Certifications UL 497A, CUL,

Features

 <1 nanosecon d response time

 S olid -state r esettable f

 S ilicon brea kover technolo gy

 L ow capaci tance

 Lin e-to -line prot ection

 A ccommodates RJ-11 jac k

use s — PTCs

 T ip & r ing to gr ound protec tion

 C AN/CSA C22.2, No. 226-92 compliant

 UL 497A list ed

 4 pair pr otec tion

 5 year wa rranty

Ordering InformationInstallation

Analog Phone RJA-45

Digital Phone RJD-45

The Edco RJA and Edco RJD Series are intended for indoor use only and shall be
employed on the equipment side of a listed primary telephone protector.

15

Data/Signal Line Protection

Edco H Series

Telecom/Punch Block Protection
Advanced Ultra High Speed Technology

The Edco H-Series modules are ultra high speed fused solid state secondary
protectors for KEY/PABX systems. The units are available in three different
clamping voltages. The Edco H-Series is constructed with solid state silicon
foldback technology, polyswitch resettable fuses — PTCs — and failure fuses.
These protection modules are intended to be used in conjunction with proper
primary protectors (UL 497). The protective elements switch from the normal
high-impedance state to a low-impedance state upon a detection of a surge,
then switch back to high impedance after the surge has passed. The Edco
H-Series single pair modules fit onto a standard Edco MI-50 split block and
replace bridging clips. In addition, these modules require the Edco MGB Ground
Rail for each Edco MI-50 block used.

TTA-2 Test Point Adaptor

Plugs into test points on HCO, HDE, and HAE, as well as other Edco 66 Block
Protectors. Adaptor is equipped with test clips for connection to telephone test

TTA-2 TEST POINT ADAPTOR

(SOLD SEPARATELY)

(butt) set or meter. Order part # TTA-2

General Technical Specifications Installation

Operating Voltage 50, 180, 230 VDC

Clamping Voltage 65, 200, 270 VDC

Operating Current 0.15 A

Peak Surge Current 160 A
(10 x 1000 µs T & R to Ground)

Frequency Range 0– to 20 MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology Silicon Breakover Device
w/ Series PTC

Connection Type Clip

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.25H x 0.4W x 2.8L

Weight 1 oz

Certifications UL 497A, CUL

Ordering Information

Central Office/Trunks HCO

Analog Extensions HAE

Digital Extensions HDE

DO NOT daisy chain grounds. NOT intended for shield termination.
Install ground in accordance with all applicable codes.

16

Data/Signal Line Protection

Edco COHP Series

Data/Signal Line/Punch Block Protection
High Exposure Applications

The Edco COHP modules are three-stage hybrid protectors for low voltage data and
telecommunications applications. The modules address over-voltage transients with
gas tubes and silicon avalanche components. In addition, sneak and fault currents
are mitigated with resettable fuses (PTCs). Intended to be used on pairs without
the presence of ring ing voltage. The Edco COHP modules are designed for data and
control applications as an isolated loop circuit protector.

General Technical Specifications

Operating Voltage 6, 12, 24, 43, 52 VDC

Clamping Voltage 8, 15, 30, 50, 60 VDC

Operating Current 0.15 A

Peak Surge Current 10 kA (8 x 20 µs)

Frequency Range 0 to 20 MHz

Insertion Loss < 0.1 dB at 20 MHz

Features

 Replaces bridging clips on MI -50 Block
 <1 nanosecond response time
 Line-to-line protection
 Line-to-ground protection
 Utilizes MGB grounding rail

SPD Technology GDT, SAD, w/ Series PTC

Connection Type Clip

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.25H x 0.4W x 2.8L

Weight 1 oz

Certifications UL 497B

 Rugged three electrode gas tube first stage
 Silicon avalanche hybrid technology
 Polyswitch resettable fusing — PTCs
 5 year warranty

Ordering Information

COHP-008 8 Volts

COHP-015 15 Volts

COHP-030 30 Volts

COHP-050 50 Volts

COHP-060 60 Volts

17

Data/Signal Line Protection

KSU Tip/Ring Protection

CO Lines

Male AMP-TYPE
UNPROTECTED

Female AMP-TYPE
PROTECTED

Building

Approved Ground

MEG-25-CO

KSU

MEG-25-DE

Digital

Digital

Digital

Digital

Digital

Digital

Edco MEGA-TEK 25 Series

Telephone Circuit Protection AMP-Type 25-Pair

The Edco MEGA-TEK 25 Series surge suppressor installs directly inline with
existing AMP-TYPE 25 pair connectors. The close proximity to the KSU/PBX
preserves the Edco MEGA-TEK’s response time, clamping level and ground
reference by reducing lead lengths.

The Edco MEGA-TEK’s unique design maximizes surge suppression performance
while reducing hardware and labor costs to install. The Edco MEGA-TEK is a
UL 497A telephone secondary protector. The product is available in
3

application specific models.

Features

 AMP-TYPE connectors

 Automatic recovery — resettable fusing

 25 pair protection

 High energy silicon technology

 UL 497A listed

 <1 nanosecond response time

General Technical Specifications

Part Number MEG-25-CO

Break Down Voltage 270

Application Central Office Lines

Max. Continuous Current 145ma

Part Number MEG-25-AE

Break Down Voltage 200

Application Analog Extension Lines

Max. Continuous Current 145ma

Part Number MEG-25-DE

Break Down Voltage 65

Application Digital Extension Lines

Max. Continuous Current 160ma

Installation

The hybrid design of this product includes series
resistance. Do not place this product in service on any
signal lines capable of more than 150 milliamperes
continuously.

Installation Procedures

1. Never install telephone wiring during a
lightning storm.

2. Disconnect telephone line at the network interface
before installing the secondary protection.

3. The MEGA-TEK Series is intended for indoor use
only. Plug the female AMP-TYPE connector from the
unprotected Telco cable into the male AMP-TYPE
connector on the ME
LINE side.

4. Plug the male AMP-TYPE connector from the local
equipment cable to be protected into the female
AMP-TYPE connector on the MEGA-TEK Series.
This is the EQUIP side.

5. Bond the green #12 AWG stranded ground wire
from the MEGA-TEK Series to AC Power Ground
or Building Approved Ground. For recommended
grounding techniques, refer to Edco Technical
Bulletin #1090.

GA-TEK Series. This is the

18

US PATENT NO. 4,703,983

Data/Signal Line Protection

Edco MGB Ground Rail

Fits Standard 66M1-50 Punch Down Blocks
Split Block Variations

Edco MGB Ground Rail — Designed to fit standard 66M1-50 Punch Down Blocks.

Allows Edco’s H-Series, COHP, PB Series and other similar Surge Suppressors to
access ground when snapped onto the 66M1-50 Punch Down Block.

The Standard 66MI-50 block is capable of accommodating up to 25 Edco
surge suppressors.

PROTECTED SIDE

Application Diagram

UNPROTECTED SIDE

Emerson Network Power
recommends a 10AWG
wire to building approved
ground — keep short.

19

PCB1B:

Unprotected Pair 2

Unprotected Pair 1

Protected Pair 2

Protected Pair 1

Keying Pin

Even TerminalsOdd Terminals

Field Side

Electronics Side

9

7

5

3

1

10

8

6

4

2

1.0

{

}

}

{

2.125"

2.4"

Groun d Ter minal 1 or 10 t o Buil din g App rov ed Grou nd

PC642

PCB1B

-

VOLTAGE CLAMP

60 Volts

50 Volts

43 Volts

36 Volts

30 Volts

15 Volts

8 Volts

2 0 0

PC642C

20 Volts

*200 Volts

0 6 0

0 5 0

0 4 3

0 3 0

0 2 0

0 3 6

0 1 5

0 0 8

no suffix
stage 2 clamp
each line-to-ground

stage 2 clamp
line-to-line only

stage 2 clamp line-to-line
and each line to ground

D

X

low capacitance option stage
2 clamp line-to-line and each
line to ground

•Not UL Listed

LC

Data/Signal Line Protection

Edco PC642 Series

Zone/Loop/Data

The Edco PC642 Series surge suppressor is a two-pair (four-wire) module
implementing three-stage hybrid technology. This module addresses
over-voltage transients with gas tubes and silicon avalanche components.
In addition, sneak and fault currents are mitigated with resettable fuses (PTCs).
The PTCs increase resistance several orders of magnitude when over-currents
exceed safe levels. A normal state resumes when over-currents are removed.
The ability to self-restore in this manner significantly increases suppressor
performance and survivability.

20

EDCO PCB1B BASE SOLD SEPARATELY

General Technical Specifications

Operating Voltage 5, 12, 18, 24, 30, 36,
43, 52, 180 VDC

Clamping Voltage 8, 15, 20, 30, 36, 43,
50, 60, 200 VDC

Operating Current 0.15 A

Peak Surge Current 10 kA (8 x 20 µs)

Frequency Range 0 to 20 MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology GDT, SAD, w/Series PTC

Connection Type Terminal block
w/compression lugs
Terminals accept up to 10 AWG

Operating Temperature -40°C to +85°C

Dimensions (Inches) 2H x 1W x 2.5L
(PC642 + PCB1B Base)

Weight 1 oz

Certifications UL 497B

Caution: The hybrid design of this product includes
series resistance. Do not place this product in service
on any signal line capable of supplying more than
150 milliamperes continuously.

The Edco PC642 card edge module is gold-plated, double-sided, and is designed
to mate with the Edco PCB1B gold-plated female terminal connector. When
snapped together, the data circuits “pass thru” the protector in a serial fashion
from the four “Field Side” terminals to the four “Electronics Side” terminals.
Terminals 1 or 10 of the Edco PCB1B must be attached to Building-Approved
Ground per Edco Technical Bulletin # 2015.

Features

 Three-stage hy brid p rotect ion

 Sneak/fa ult current p rotect ion

 Res ettable fusing — PTCs

 Low capacit ance opti on

 Plug-in module

Terminal Assignments

DO NOT daisy chain grounds. NOT intended for shield
termination. Install ground in accordance with all
applicable codes.

 Fast r esponse time

 Req uire s Edco PC B1B base

 PC642PTU (Pass Thru Unit)

ava ilab le for troublesh ooting

 5 year warr anty

Ordering Information

APPLICATION:

RS485, RS422: PC642C-008LC & PCB1B

RS423, Token Ring: PC642C-008LC & PCB1B

RS232: PC642C-020 & PCB1B

E-NET, 10 BASE T: PC642C-030LC & PCB1B

4–20ma: PC642C-036 & PCB1B

How to Specify the Appropriate Model

Installation Diagram

PCB1B:

Unprotected Pair 2

Unprotected Pair 1

Protected Pair 2

Protected Pair 1

Keying Pin

Even TerminalsOdd Terminals

Field Side

Electronics Side

9

7

5

3

1

10

8

6

4

2

1.0

{

}

}

{

2.125"

2.4"

Data/Signal Line Protection

Edco PC642PTU

Pass Thru Unit

The Edco PC642PTU is an invaluable tool for troubleshooting Edco card-edge-

style protectors (PC642, PC2TEL, PHC, SLCP Series).

Simply unplug the existing Edco card-edge-style protector and plug the Edco

PC642PTU (Pass Thru Unit) into the Edco PCB1B base of the circuit to be tested.

The Edco PC642PTU will provide continuity to your circuit, thus eliminating the

need for a two-man crew or to rewire your circuit for troubleshooting purposes.

NOTE – The Edco PC642PTU is NOT a surge protector. Proper
surge protection must be reinstalled on the circuit.

DO NOT daisy chain grounds. NOT intended for shield/drain
wire termination.

Install ground in accordance with all applicable codes.
The Edco PCB1B base sold separately.

General Technical Specifications

Operating Voltage 60 VDC

Clamping Voltage 65 VDC

Operating Current

Peak Surge Current 60 A (10 x 1000 µs)

Frequency Range 0–250MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology Silicon Avalanche Diode (SAD

300 mA

Edco CAT6-5 POE

CAT6/CAT5 Power Over Ethernet

The Edco CAT6-5 POE Series is designed to work on Category 5 Power­Over-Ethernet transmission lines as well as Category 6 applications. Ideal

to protect expensive equipment against surges and transients entering a
building on exposed transmission lines. Available in both female to female
and male to female RJ-45 connectors.

Features

■ Exceeds CAT5 & 6 transmission values

■ CAT5 POE compatible

■ CAT6 compatible

Connection Type RJ-45 Jacks

Operating Temperature

Dimensions (Inches) 0.8H x 1.0W x 2.3L (FF)

0.8H x 1.0W x 3.0L (MF)

Weight 1 oz

-40

°C to +85°C

■ Applications up to 60 VDC @ 300 mA

■ 1 year warranty

Ordering Information

RJ-45 (FF) CAT6-5POE-FF

RJ-45 (MF) CAT6-5POE-MF

21

Data/Signal Line Protection

Edco LCDP Series

Data Circuit Protection

The Edco LCDP Series is designed to conveniently protect 8 wire, low voltage data
circuits and employs two RJ-45 jacks for easy installation. The Edco LCDP utilizes
silicon avalanche (solid-state) suppression technology, and exhibits very low
capacitance to accommodate high data rates. This unit supports high-speed data
rates of over 100 Mbps.

Features

 <1 nan osecond r esponse time

 Line-to-line prot ection

 Low ca pacitance

 RJ-45/4 pair prote ction (8 w ire)

 Sil icon avalan che design

 Line to gro und pr otec tion

 5 y ear warrant y

General Technical Specifications

Operating Voltage 5, 12, 24, 48, 65 VDC

Clamping Voltage 8, 15, 30, 60, 75 VDC

Operating Current 1.5 A

Peak Surge Current (10 x 1000 µs) 008 = 125 A, 015 = 72 A,
030 = 22 A, 060 = 18 A, POE*=15 A

Frequency Range 0—100 MHz

Insertion Loss < 0.1 dB at 50 MHz

SPD Technology Silicon Avalanche Diode (SAD)

Connection Type RJ-45 Jacks

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.0H x 2.5W x 4.25L

Weight 3 oz

Certifications UL 497B (*except LCDP-POE)

Installation

The user equipment plugs into the LCDP’s equipment (protected) side,
and the LCDP’s line (unprotected) side is connected to the incoming line.
All 8 conductors are protected. The green ground wire must be bonded
to the protected equipment power ground (third wire, green wire safety
ground). Do not add length to the ground wire, for it must be kept as
short as possible.

Ordering Information

LCDP-008 8 Volts

LCDP-015 15 Volts

LCDP-030 30 Volts

LCDP-060 60 Volts

LCDP-POE 75 Volts

22

Data/Signal Line Protection

Edco TCS-T1 Series

T1 Line Protection Against Damaging Transients

Protection of your vital T1 lines should be part of the overall power protection plan
for your facility. The Edco TCS-T1 Series provides you state-of-the-art protection in
a small package.

T1 lines need protection from direct and indirect lightning, as well as power
disturbances from nearby AC lines. The Edco TCS-T1 Series prevents T1 line
disturbances by providing a level of protection typically not provided by the
telephone company.

The Edco TCS-T1 Series devices combine highly reliable, nondegrading Silicon
Avalanche Diode (SAD) technology, along with high energy gas tube protection.
This technology combination leverages the best aspects of each protection
method in a single, reliable design to ensure optimal performance.

The Edco TCS-T1 Series features two models with different clamping voltages.
Both the Edco TCS-T1S and the Edco TCS-T1DS support in-line connections via
hardwire lugs or standard RJ-45 ports.

Features

 Use s bipolar Silicon Avalanche D iode to

provi de nondegra ding protec tion

 Provi des un paralleled perfor mance in a

com pact, modul ar design

 Offer s RJ or hardwire connec tion

capabilitie s to p rovide installat ion fle xibility

General Technical Specifications

Part Number Edco TCS-T1S

Operating Voltage 170 VDC

Clamping Voltage 211 VDC

Operating Current 1A

Total Peak Surge Current* 40,000 A

Frequency Range 0 to 55MHz

Insertion Loss < 0.1 dB at 55 MHz

SPD Technology SAD / GDT

Connection Type Hardwire Lugs or RJ-45

Operating Temperature -40°C to +85°C

Dimensions (Inches) 2H x 3W x 1.5D

Weight 5 oz

Certifications UL 497B

 Comes complete w ith ring t erminals

and a mal e/male RJ -45 cable to make
installation easy

 1 y ear warrant y

Part Number Edco TCS-T1DS

Operating Voltage 8 VDC

Clamping Voltage 13 VDC

Operating Current 1A

Total Peak Surge Current* 40,000 A

Frequency Range 0 to 55MHz

Insertion Loss < 0.1 dB at 55 MHz

SPD Technology SAD / GDT

Connection Type Hardwire Lugs or RJ-45

Operating Temperature -40°C to +85°C

Dimensions (Inches) 2H x 3W x 1.5D

Weight 5 oz

Certifications UL 497B

*Based on component specifications for all T1 lines.

23

Data/Signal Line Protection

Edco TCS-Multi T1 Series

T1/E1 Line Protection

The Edco TCS-Multi T1 Series provides you state-of-the-art surge protection in a
scalable backplane connected solution.

The Edco TCS-Multi T1 Series features two models with different clamping
voltages, the Edco TCS-T1S-MX and the Edco TCS-T1DS-MX support in-line
connections via 4 pin headers, standard RJ-45 ports or both.

Features

■ Uses bipolar Silicon Avalanche Diode to

provide nondegrading protection

■ Protects against lightning surges and

internal transient activity

■ Provides unparalleled performance in a

compact, modular design

■ Offers RJ and hardwire capabilities to

provide installation flexibility

■ Enclosure can be mounted as a telco mount

(vertical or horizontal) and 19" rack mount
single or double enclosure

General Technical Specifications

Enclosure Dimensions:
Telco Board Mount

(Inches) 1.75H x 8.5W x 5.5D
(Centimeters) 4.4H x 21.6W x 14D
19" Rackmount
(Inches) 1.75H x 19W x 5.5D
(Centimeters) 4.4H x 48.3W x 14D

Primary Technology Silicon Avalanche Diode

Secondary Technology Gas Discharge Tube

Interface RJ-45 and hardwire

Enclosure Options

Telco Board Mount
Enclosure Part Number 2000048-00 — Enclosure with backplane
and brackets, holds up to 6 cards
Comes with 4 cards installed

2000052-00 — Enclosure without cards

19" Rackmounting
Single Enclosure 2000049-00 — Mounting bracket,
holds up to 6 cards
Dual Enclosure 2000050-00 — holds up to 12 cards
Other configurations available

Card Performance Technical Specifications

Part Number Edco TCS-T1DS-M2

Operating Frequency Up to 55 MHz

Signal Line Voltage Up to 8 Vpk

Clamping Voltage 13 Vpk

Response Time 5 ns or less

Peak Pulse Current 10kA*

Nominal Current 4,000 Amp

Leak Capacitance 38 Picofarad

Protection Modes:
Hardwire L1-G – L3-G
L2-G – L4-G
L1-L2 – L3-L4
RJ-48C Standard (RJ-45) Pin 1-G – Pin 4-G
Pin 2-G – Pin 5-G
Pin 1-Pin 2 – Pin 4-Pin 5

* Based on component specifications (8 x 20 µs)

24

TCS-T1S/T1DS-M2

HARD CONNECT

AND RJ

Data/Signal Line Protection

Edco DCB Series

DC Power Protection for Critical Equipment

DC powered equipment is susceptible to transient events that may pass from
the AC, Telco, or Coax services to the equipment directly or through other
equipment. Harmful transients found in all power services can cause costly
damage and downtime of vital DC powered equipment.

In response to this problem, the Edco DCB Series for state-of-the-art surge
protection was created to fit various application needs. The Edco DCB Series is
available in 24 or 48 VDC configurations, and mounts to an equipment chassis.
Its compact size makes the Edco DCB easy to install, even in the tightest spaces.

Alone, or as part of your overall power protection strategy, the Edco DCB
Series protects and provides unparalleled performance in power protection for
critical equipment.

Features

■ Bipolar Silicon Avalanche Diode technology

provides fast, nondegrading protection

■ Metal Oxide Varistors provide a “second

stage” of power protection

■ Ideal protection for radios, channel banks,

rect ifiers, inv erters , convert ers and vari ous
other DC powered equipment

■ Compact module designed to fit tight

spa ces where DC power prote ctio n
is needed

■ 1 year warranty

General Technical Specifications

Part Number Edco DCB-24S & DCB -24SM

Operating Voltage 24 VDC

Clamping Voltage 31 VDC

Operating Current 150A

Total Peak Surge Current 17,000A

Frequency Range 0 to 55 MHz

Insertion Loss < 0.1 dB at 55 MHz

SPD Technology SAD / MOV

Connection Type Standard Lug (S) Mini Lug (M)

Operating Temperature -40°C to +60°C

Dimensions (Inches) 2.8H x 5.2W x 2D

Weight 12 oz

Part Number Edco DCB-48

Operating Voltage 48 VDC

Clamping Voltage 83 VDC

Operating Current 150 A

Total Peak Surge Current 52,000A

Frequency Range 0 to 55 MHz

Insertion Loss < 0.1 dB at 55 MHz

SPD Technology SAD / MOV

Connection Type Standard Lug (S) Mini Lug (M)

Operating Temperature -40°C to +60°C

Dimensions (Inches) 3.1H x 5.25W x 2.4D

Weight 12 oz

25

Data/Signal Line Protection

Edco CCTV-1

Closed Circuit TV Protection

The Edco CCTV-1 application is specifically designed for lightning protection on
closed circuit TV systems. The protector is easily installed with standard type BNC
coax connectors. The Edco CCTV-1 offers low loss even at frequencies approaching
500 Mhz. This is important for error-free data communication applications.

General Technical Specifications

Operating Voltage 5 VDC

Clamping Voltage 90 VDC (Spark Over Voltage)

Operating Current 1A

Peak Surge Current 10 kA (8 x 20 µs)

Frequency Range 0 to 1 GHz

Features

 Automatic recovery

 Low insertion loss

 Easily installed

Insertion Loss < 0.5 dB at 500 MHz
<1.0 dB at 900 MHz

SPD Technology Gas Discharge Tube (GDT)

Connection Type BNC, 75 Ohm

Operating Temperature -40°C to +85°C

 Shielded case

 Miniature size

 5 year warranty

Dimensions (Inches) 0.6H x 0.6W x 2.0L

Weight 1 oz

Edco CX Series

CCTV High Exposure

The Edco CX06-M & Edco CX06-MI Surge Protective Devices (SPDs)
implement three-stage hybrid technology. The SPDs address over-voltage
transients with a primary Gas Discharge Tube (GDT), and secondary Silicon
Avalanche Diode (SAD) components. Over-current protection, e.g. sneak
and fault currents, are mitigated with solid-state resettable fuses — PTCs.
The Edco CX06-M & Edco CX06-MI SPDs are designed in accordance with
NFPA 780 (2004 edition) requirements, with up to 20 kA of surge current
capability. The Edco CX06-MI model has an isolated ground and is
recommended for use at the camera end.

General Technical Specifications

Operating Voltage 5 VDC

Clamping Voltage 6 VDC

Operating Current 0.15 A

Peak Surge Current 20 kA (8 x 20 µs)

Frequency Range 0– 20 MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology GDT, SAD, w/Series PTC

26

Features

 Sneak/fault current protection

 Low insertion loss

 Shielded case

Connection Type BNC, 50/75 Ohm

Operating Temperature -40°C to +85°C

Dimensions (Inches) M = 1.5H x 1W x 3.25L
MI = 1.5H x 1W x 4L

Weight M = 2.3 oz MI = 3 oz

Certifications UL 497B

 CX06-MI has an isolated ground

 5 year warranty

Ordering Information

Head End CX06-M

Camera End CX06-MI

General Technical Specifications

Operating Voltage 25 VDC

Clamping Voltage 150 VDC
(Spark Over Voltage)

Operating Current 1 A

Peak Surge Current 10 kA (8 x 20 µs)

Data/Signal Line Protection

Edco CATV-DF

High Frequency Coax Protector — F-Type

The Edco CATV–DF surge protectors are designed to protect sensitive
electronic equipment from damage due to excessive voltage or currents
generated by lightning or static build-up.

Applications include direct broadcast satellite systems, HDTV, and cable modems.

The Edco CATV-DF offers low signal loss at frequencies up to 2 gigahertz.
Incorporates GDT (Gas Discharge Tube) technology.

Features

 Automatic recovery
 Low insertion loss
 Shielded case

Frequency Range 0 to 2 GHz

Insertion Loss < 1.0 dB at 1 GHz
< 2.0 dB at 2 GHz

SPD Technology Gas Discharge Tube (GDT)

Connection Type Type F Female

 Easily installed
 5 year warranty

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1.25H x 2.5W x 4L

Weight 3 oz

27

Data/Signal Line Protection

Edco NET Series

SIECOR Network Interface Device

The Edco NET Series is a SIECOR Network Interface Line Module with built-in
secondary surge protection. In addition to silicon breakover clamping
technology (over-voltage), the Edco NET Series incorporates state-of-the-art
resettable over-current protection devices — PTCs.

The over-current circuitry allows normal telephone currents to pass, but quickly
switches to a high impedance state when subjected to extended over-currents
that can damage telephone system line cards.

Features

 Tip to ring protection
 Tip, ring to ground protection
 Solid state over-current protection

 Resettable fusing — PTCs
 UL 497A listed
 5 year warranty

General Technical Specifications

Part Number Edco NET-015T

Max. Peak Signal Voltage 12

Nominal Breakdown Voltage 15

Max Peak Pulse Current
Ip 10 X 1000 µs 124

Typ Cap (pf) 2100

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Part Number Edco NET-030T

Max. Peak Signal Voltage 24

Nominal Breakdown Voltage 30

Max Peak Pulse Current
Ip 10 X 1000 µs 71

Typ Cap (pf) 1180

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Part Number Edco NET-050T

Max. Peak Signal Voltage 43

Nominal Breakdown Voltage 50

Max Peak Pulse Current
Ip 10 X 1000 µs 45

Typ Cap (pf) 900

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Part Number Edco NET-060T

Max. Peak Signal Voltage 52

Nominal Breakdown Voltage 60

Max Peak Pulse Current
Ip 10 X 1000 µs 36

Typ Cap (pf) 750

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Part Number Edco NET-200T

Max. Peak Signal Voltage 180

Nominal Breakdown Voltage 230

Max Peak Pulse Current
Ip 10 X 1000 µs 200A (T-G)+ (R-G)

Typ Cap (pf) 150

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Part Number Edco NET-TEL

Max. Peak Signal Voltage 220

Nominal Breakdown Voltage 270

Max Peak Pulse Current
Ip 10 X 1000 µs 200A (T-G)+ (R-G)

Typ Cap (pf) 150

Max Continuous Current 150ma

Nominal Series Resistance 8 Ohms

Installation

Notes:

A. Never install telephone wiring during a

lightning storm.

B. Protectors are intended for indoor or outdoor

use within a network interface device
(Siecor CAC 7600).

C. If any visible damage has occurred to module,

turn off power before attempting to remove or
insert another module.

D. Install in accordance with the NEC, Article 800.

30

Data/Signal Line Protection

Edco FAS-TEL and FAS-31XT

RJ11/RJ31X Telephone Protection

The Edco FAS-TEL and Edco FAS-31XT are single pair telephone or data line
protectors that implement advanced two-stage hybrid design. These units
address over-voltage transients with silicon breakover devices, while sneak
and fault currents are mitigated with PTC technology which consists of solid
state resettable fuses.

The Edco FAS-31XT replaces the RJ31X jack with a protected version. Four
screw terminals are provided to wire the protector in the same manner as a
standard RJ31X jack.

The Edco FAS-TEL is nearly identical to the Edco FAS-31XT except with out
the shorting bars. Two screw terminals are provided to connect Telco Line to
protector. Protected equipment such as modems are plu
modular jack on the Edco FAS-TEL.

gged into female

General Technical Specifications

Operating Voltage 43, 52, 220, & 220 VDC

Clamping Voltage 50, 60, 270, & 270 VDC

Operating Current 0.15 A

Peak Surge Current 160 A
(10 x 1000 µs T & R to Ground)

Frequency Range 0 to 20 MHz

Insertion Loss < 0.1 dB at 20 MHz

SPD Technology Silicon Avalanche Diode
w/ Series PTC

Connection Type Terminal block
with compression lugs IN /
RJ connector OUT

Operating Temperature -40°C to +85°C

Dimensions (Inches) 1H x 2W x 2L

Weight 2 oz

Certifications UL 497A, CUL

Features

 <1 nanosecond response time
 Solid-state silicon breakover technology
 Low capacitance
 Over-current protection
 UL 497A listed

Installation

 Line-to-line protection
 Line-to-ground protection
 Polyswitch resettable fuses — PTCs
 5 year warranty

Ordering Information

Digital Phone FAS-TEL-060T

Analog Phone/Fax/Modem/

Alarm System Phone FAS-31XT

DSL FAS-TEL-200T

31

Headquarters

Surge Protection
30 Charles Street
Binghamton, NY 13905
T: 607-721-88404
T: 800-288-6169
F: 607-722-8713
W: www.emersonnetworkpower.com/surge
E: [e-mail]

Emerson Network Power.
The global leader in enabling Business-Critical Continuity

AC Power
Connectivity

DC Power

Business-Critical Continuity, Emerson Network Power and the Emerson Network Power logo are trademarks and service marks of Emerson Electric Co.
©2007 Emerson Electric Co.

While every precaution has been taken to ensure accuracy and completeness in this literature, Emerson Network Power assumes no responsibility, and disclaims all liability for damages
resulting from use of this information or for any errors or omissions.

SL-30104 Rev.0 10/07 Printed in USA

Embedded Computing
Embedded Power

Monitoring

TM

.

Outside Plant
Power Switching & Controls

Precision Cooling

Emer sonNetworkPower.com

Racks and Integrated Cabinets

Services

Surge Protection
