Page 1

E:fact® Technical Service Data

INDEX

Parts List

Coils & Transformers Miscellaneous Controls & Resistors Capacitors & electrolytics Cabinet Parts Semiconductors

Schematics

Television, part 1 Television, part 2 Power Supply System Control Placement Chart

To purchase a complete paper version of this service manual, order PHOTOFACT

set #4135

EMERSON

MODEL

Model TC1973D (Version A)

SCHEMATIC NOTES

For SAFETY use only equivalent replacement part,

see parts list.

Circuitry not used in some versions. Circuitry used in some versions.

To place the order, contact your local Sams Distributor or call our Customer Service operation at 1-800-428-7267.

For E:fact ordering or information, use the following web site link.

http://www.hwsams.com/efact.html

Product #084135

Ground Chassis ground Common tie point Taken from common tie point

Schematic voltage source tie point.

Cabling: Heavy lines reduce use of multiple lines.

Waveforms and voltages are taken from ground, unless

noted otherwise.

Waveforms taken with triggered scope and keyed rainbow

generator. Waveform voltage is peak to peak. Timebase

is per division. Waveforms shown at 10 divisions. Supply voltages maintained as seen at input. Voltages measured with digital meter and a 1000µV RF

signal, with colorbar pattern, applied to antenna terminal. Controls adjusted for normal operation. Capacitors are 50 volts or less, 5% or greater unless noted. Electrolytic capacitors are 50 volts or less,

20% or greater unless noted. Resistors are 1/2W or less, 5% or greater unless noted. Value in ( ) used in some versions. Measurements with switching as shown, unless noted. Rated voltage shown on zener diodes.

Page 2

PARTS LIST

COILS & TRANSFORMERS

Item No. Function/Rating Mfr. Part No.

# DY801 Yoke Horiz 2.7mH 027Z092002 # FB401 (1) Horizontal Output 043220040F

L001 47µH 021673470K L101 33µH 021LA6330K L202 .47µH 021LA6R47M L203 .91µH 021S05R91K L204 .18µH 021S65R18J L205 .43µH 021S05R43J L206 15µH 021LA6150K L301 22µH 021LA6220K L302 10µH 021LA6100K L406 18µH 02186G180M

L410 4.7µH 021679472K

# L501 Line Filter 0292000070 # L502 Degaussing 028H200016

L602 22µH 021LA6220K L604 33µH 021LA6330K L606 100µH 021LA6101K L607 33µH 021LA6330K L801 100µH 021673101K T401 Horizontal Drive 03305Y002W

# For SAFETY use only equivalent replacement part.

(1) Focus and screen controls are part of FB401.

Vert 19.9mH

18µH 021U6A180M

Degaussing 028S200008 Degaussing 028A200021

1248L3PL.SAM

Page 3

PARTS LIST continued

MISCELLANEOUS

Item No. Description Mfr. Part No. Notes

# ATC001 Antenna 0632400005 Unit # BL001 Plug 0634200015 FJ # CD501 Line Cord 1206614311 AC, Polarized

CF201 Filter 1027045R72 SAW CF202 Trap 1011T4R517 4.5MHz CF301 Filter 1012T4R514 4.5MHz CF302 Filter 1011T4R504 4.5MHz CF401 Filter 1002R50304 503kHz

# F501 Fuse 081PC04003 4Amp, 125V, Slow Blowing

FH501, 02 Fuse Holder 06710T0006 For F501

# J801 Socket 066C130012 CRT

OS101 Receiver 077Q000006 Remote, PIC-12043SP

# RY101 Relay 0560S20113 Power

SP351 Speaker 070J132011 3" Round, 8 Ohms, 2W SW102 Switch 0504101T32 Power SW103 Switch 0504101T32 Volume Down SW104 Switch 0504101T32 Volume Up SW105 Switch 0504101T32 Channel Down SW106 Switch 0504101T32 Channel Up

# TU001 (1) Tuner 0145100040 UHF/VHF, ENV-568N8G3 # V801 CRT 092Z200411 G-A48ACB32X

X101 Crystal 1002T01201 12MHz X601 Crystal 100W357903 3.58MHz

Filter 1003R50303 503kHz

PC Board A3F401A11A CRT PC Board A3F401A01A Main Transmitter 076R074040 Remote, R25-7345 Wedges 129A000010 Yoke Positioning (3 Used)

# For SAFETY use only equivalent replacement part.

(1) Contact TNI Electronics for replacement; order by part number on tuner.

1248L3PL.SAM

Page 4

PARTS LIST continued

CONTROLS & RESISTORS

Item No. Function/Rating Mfr. Part No. NTE Part No.

# R002 100 5% 1W R3U181101J 1W110

R124 R4X5T6392F R135 10K 1% 1/4W R4X5T4103F R156 56K 1% 1/6W R4X5T6563F R157 22K 1% 1/6W R4X5T6223F -

# R177 1200 5% 10W Wirewound - 10W212

R411 200K 1% 1/6W R4X5T6204F -

# R413 47 5% 1/4W Fusible R635U4470J - # R423 10K 5% 2W R3U18A103J 2W310

R425 15K 1% 1/4W R4X5T4153F R427 390K 1% 1/4W R4X5X4394F -

# R435 100K 1% 1/4W R4X5T4104F - # R436 27K 1% 1/6W R4X5T6273F - # R437 1500 5% 1/8W R902N8152J EW215 # R439, 40 15K 1% 1/6W R4X5T6153F - # R441 1800 5% 1/8W R902N8182J EW218 # R442 .68 5% 1W Fusible R63581R68J -

R445 150K 1% 1/4W R4X5T4154F -

# R447, 48 3300 5% 2W R3U18A332J 2W233 # R452 1.2 5% 1W Fusible R635811R2J F1W1D2

# R490 68 5% 1/2W Fusible R615U2680J - # R501 820K 5% 1/2W R002T2824J HW482 # R502 4.7 5% 10W Wirewound R5Y2CF4R7J 10W4D7 # R506 180 5% 10W R5Y2CF561J 10W118

# R507 47 5% 1/4W Fusible R635U4470J - # R509 17K 1% 1/4W R4X5T4173F - # R523 4.7 5% 3W R3X28B4R7J 3W4D7 # R802 10K 5% 2W R3U18A103J 2W310

R804 20K 2% 1/6W R001T6203G -

# R805 10K 5% 2W R3U18A103J 2W310

R807 24K 2% 1/4W R001T4243G QW324 R808 24K 2% 1/6W R001T6243G -

# R810 10K 5% 2W R3U18A103J 2W310 # TH501 5.1 Cold PTC, 200 D8R0C5R0M0 -

1500 5% 10W Wirewound R5Y2CF152J 10W215

3900 5% 2W - 2W239

180 15W - -

# For SAFETY use only equivalent replacement part.

1248L3PL.SAM

Page 5

PARTS LIST continued

CAPACITORS & ELECTROLYTICS

Item No. Rating Mfr. Part No.

C120 1µF 20% 50V NP E02ET5010M C133 .0022 10% 2kV C13VB07H3K C228 18pF 5% 50V NPO C0JTCH4G1J C229 27pF 5% 50V N075 C0NTLH4K1J C231 68pF 5% 50V N075 C0NTLH4U1J C232 15pF 5% 50V NPO C0JTCH4E1J

# C412 470µF 20% 10V E02LT1471M # C414 100µF 20% 35V E02LT4101M

C420 2.2µF 20% 50V NP E02ET52R2M

# C433 1000µF 20% 35V E02LT4102M # C434 22µF 20% 63V E0RIT6220M # C436 470µF 20% 16V E02LT2471M # C442 270pF 10% 2kV C01TBP7K2K # C443 .0062 +50% -10% 1.6kV P4N2F9622H # C446 1µF 20% 160V E0E7TB010M # C448 10µF 20% 100V E0RIT8100M

C453 .001 10% 1kV C0JTB0613K

# C478 470µF 20% 16V E02LT2471M # C499 47µF 20% 25V E001T3470M # C502 .1 10% 250VAC P2222B104K

C503, 04 .001 10% 2kV C13VB0713K

# C506 560µF 20% 200V E5MCFC561M # C507 100µF 20% 160V E0E7FB101M

C813 .001 10% 2kV C13VB0713K

# For SAFETY use only equivalent replacement part.

1248L3PL.SAM

Page 6

PARTS LIST continued

CABINET PARTS

Item Mfr. Part No.

Cabinet Front 701APJ0044 Cabinet Front Assembly A3C809A720 Cabinet Rear 702APA0070 Plate Front 7232020626

1248L3PL.SAM

Page 7

SEMICONDUCTORS

(Select the replacement that gives the best results.)

Item No. Type No. Mfr. Part No. ECG Part No. NTE Part No. TCE Part No.

D001 MTZJ5.1AT-77 D97U05R11A - - D101 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 D104, 05 MTZJ5.6BT-77 D97U05R61B ECG5011T1 NTE5011T1 SK9968 D106 MTZJ5.1BT-77 D97U05R11B - - -

D124 RD15EB1TA11R D92T0150B1 ECG5023A NTE5023A SK14A D125 1S2472T-77 D1VT024720 ECG177 NTE177 SK9091

# D126 10E10 D28T10E100 ECG125 NTE125 SK3081

D127 11E1TA1B2 D28T011E10 ECG116 NTE116 SK3313 D139 RD30EB4TA11R D92T0300B4 ECG5035A NTE5035A SK30A D145 MTZJ6.2BT-77 D97U06R21B ECG5013T1 NTE5013T1 SK9969 D153 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 D155, 56 MTZJ5.6BT-77 D97U05R61B ECG5011T1 NTE5011T1 SK9968 D201, 02 ITT410 D5WTTT4100 ECG614 NTE614 SK3327 D401, 02 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 D403 11E1TA1B2 D28T011E10 ECG116 NTE116 SK3313

# D405 RD27EB3TA11R D92T0270B3 ECG5033A NTE5033A SK27A # D406 RD11EB1TA11R D92T0110B1 ECG5019A NTE5019A SK10A # D407 10ELS6TA2B5 D28X10ELS6 - - - # D408 10ELS6TA1B2 D28T10ELS6 ECG552 NTE552 SK9000

D409 11E1TA1B2 D28T011E10 ECG116 NTE116 SK3313

# D410, 11 10ELS6TA1B2 D28T10ELS6 ECG552 NTE552 SK9000

D412 MTZJ36BT-77 D97U03601B - - D416 1S2472T-72 D17X024720 ECG177 NTE177 SK9091 D417 11E1TA1B2 D28T011E10 ECG116 NTE116 SK3313 D418 1S2472T-72 D17X024720 ECG177 NTE177 SK9091 D419 MTZJ9.1BT-77 D97U09R11B - - -

# D422 10ELS6TA1B2 D28T10ELS6 ECG552 NTE552 SK9000 # D501 Thru # D504 RM11C D2BTRM11C0 ECG125 NTE125 SK3081

D601, 02 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 D651, 52 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 D801, 02, 03 1SS132T-77 D1VT001320 ECG519 NTE519 SK3100 IC101 OEC8059A I51D08059A - - IC102 ST93C46CB1 IC3D06CB1J - - -

# IC104 UPC78L05J-T I02J98L050 ECG977 NTE977 SK3462

IC105 PST600C I9UJ0T600C - - -

# IC201 LA7676 103DE76760 - - - # IC351 UPC1213C(MS) I0XDP12130 ECG1516 NTE1516 - # IC401 LA7837 I03SD78370 ECG7104 NTE7104 - # IC402, 03 UPC78M09H I0X398M090 ECG1910 NTE1910 - # IC501 STR30110 I2B4901100 ECG7077 NTE7077 - # IC901 TA8782N I05DE87820 - - -

Q103 2SC945A(C)-TP TCLT00945P ECG85 NTE85 SK3124A Q104 2SC2001(C)-TL TCLT02001L ECG85 NTE85 SK3849

Q105, 06, 08 2SC945A(C)-T TCLT009450 ECG85 NTE85 SK3124A Q110, 25, 26 2SC945A(C)-T TCLT009450 ECG85 NTE85 SK3124A Q202, 03, 05 2SC945A(C)-T TCLT009450 ECG85 NTE85 SK3124A

# Q401 2SD2333-(RQ) TDKF023330 ECG2331 NTE2331 - # Q402 2SC2621(D,E)-RAC TC3Q026210 ECG157 NTE157 SK3747

Q601, 04 2SA733(C)-T TALT007330 ECG290A NTE290A SK3114A Q605 2SC945A(C)-T TCLT009450 ECG85 NTE85 SK3124A

# Q801, 02, 03 2SA1624-AA TA3T016240 ECG288 NTE288 SK3434 # Q804, 05, 06 2SC4217(D,E)-RAC TC3F042170 ECG157 NTE157 SK3747

Q903 2SA952(C)-T TALT00952L ECG290A NTE290A SK3114A

HZS5R1EB2-T D94TA5R1B2 ECG5010A NTE5010A SK5A1

EM1CV1 D2BT0EM1C0 - - -

10E10 - ECG125 NTE125 SK3081

2SC945P,Q - ECG85 NTE85 SK3124A

2SC945P,Q - ECG85 NTE85 SK3124A 2SC945P,Q - ECG85 NTE85 SK3124A 2SC945P,Q - ECG85 NTE85 SK3124A

2SC945P,Q - ECG85 NTE85 SK3124A

# For SAFETY use only equivalent replacement part.

1248L3SE.SAM
