Emerson SB351 User Manual
13" COLOR TV WITH
DVD PLAYER
OWNER'S MANUAL
13" COLOR TV WITH
DVD PLAYER
OWNER'S MANUAL
13" COLOR TV WITH
DVD PLAYER
OWNER'S MANUAL
13" COLOR TV WITH
DVD PLAYER
6
CONTENTS
Contents .......................................................1
Warning...........................................................3
Important Safety Instructions.................. 4
Precautions .................................................9
Power Source..............................................9
Location of Controls.................................10
• Front............................................................10
• Rear ............................................................10
Remote Control..........................................11
• Battery Installation.......................................12
• Effective Distance of the Remote Control
Transmitter....................................................12
Connections ..............................................13
• Connecting the Unit to an External TV ........13
• Connecting an External Component to
this Unit..........................................................13
• Connecting an External Unit to the
Side A/V IN Jacks...........................................14
• Connecting the Unit to a Home
Theatre System.............................................15
Cable (CATV)/Satellite Connections......16
Outdoor Antenna Connections ..............17
TV Operation ..............................................18
• Setting the Language..................................18
• Setting the AIR/CATV Menu Option.............18
• Setting the Channels into Memory...............19
• Adding and Deleting Channels ....................20
• Basic TV Operation..................................... 21
• Mute ............................................................22
• Sleep...........................................................22
• TV/AV Button..............................................22
• DVD/TV Button............................................22
Closed Captions .......................................23
On-Screen Control Adjustments
(Picture) .........................................................24
• Personal Preference ......................................24
• Blue Background.............................................24
Setting Parental Control..............................25
• Movie Rating Set Up........................................26
• TV Parental Rating Set Up ..............................27
• Changing the No Rating Option........................28
• Changing the External Source Option ............28
• Changing the Password..................................29
DVD Operation ...............................................30
• Setup Mode.....................................................30
• Pause/Step......................................................30
• OSD Language ...............................................31
• Menu ..............................................................31
• Audio...............................................................31
• Slow Play .......................................................32
• Search............................................................32
• Repeat Playback.............................................32
• A-B Repeat Playback......................................32
• Subtitle ..........................................................32
• Angle...............................................................32
• Display (Remain Time) ..............................33
• Resume play ...............................................33
• Zoom .............................................................33
• Programmed Playback.....................................34
Picture CD Operation ...................................35
Troubleshooting Guide ...............................36
Reception Disturbances...............................38
Specifications ...............................................39
Limited Warranty...........................................40
1
Thank you for purchasing the SpongeBob SquarePants 13" Color TV with DVD Player from Emerson
Radio Corp. Please read this manual before operating this unit to become familiar with its features and
obtain the performance that will bring you continued enjoyment for many years. In the event you
require technical assistance, please call the Emerson Service Department at: 1-800-898-9020.
For future reference, rec ord the serial number in the space provided.
Serial Number
2
WARNING
• TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
• THIS APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER AND THAT NO
OBJECT FILLED WITH LIQUIDS SUCH AS VASES SHALL BE PLACED ON APPRATUS.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presenc e of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of elec tric shock to persons .
Warning: To reduce the risk of
electric s hock, do not remove
cover (or back ) no use rserviceable par ts inside. Refer
servicing to qualified service
personnel.
The exclamation point within an
equilateral triangle is intended
to aler t the user to presence of
important operating and maintenance (s ervicing) instructions
in the literatur e accompanying
the appliance.
3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with manufacturer’s
instructions.
8. Do not install near any heat source suc h as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replace
ment of the obs olete outlet.
10. Protect the power cord from being walked on or pinched partic ularly at plugs, conve nienc e receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories s pecified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table s pecified by the manufacturer, or sold
with the apparatus . When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning s torms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as if the power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
4
IMPORTANT SAFETY INSTRUCTIONS
15. Retain Instructions
The safety and operating instruc tions should be retained for future reference.
16.Water and Moisture
Do not us e this product near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry
tub, in a wet basement, or near a s wimming pool and the like.
17. Power Sources
The product s hould be operated only from the type of power source indicated on the marking label. If
you are not sure of the type of power s upply to your home, consult your product dealer or local
power c ompany. For products intended to operate from battery power, or other sources, refer to the
operating ins tructions.
18. Grounding or Polarization
This produc t may be equipped with a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If
you are unable to ins ert the plug fully into the outlet, try reversing the plug. If the plug should still fail to
fit, contact your electric ian to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug. Alternative Warnings -This product is equipped with a three-wire grounding-type plug,
a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a
safety feature. If you are unable to ins ert the plug into the outlet, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
19. Outdoor Antenna Grounding
If an outside antenna or cable s ystem is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against voltage s urges and built-up static
charges. Article 810 of the National Electric al Code, ANSI/ NFPA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to antenna
disc harge unit, size of grounding conductors, location of antennadischarge unit, connection to
grounding electrodes, and requirements for the grounding electrode. See fig. A on page 7.
20. Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time,unplug it from the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the product due to lightning and powerline surges.
21. Power Lines
An outs ide antenna system should be located in the vicinity of overhead power lines or other electric
light or power c ircuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
22. Overloading
Do not overload wall outlets , extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
5
IMPORTANT SAFETY INSTRUCTIONS
23. Object and Liquid Entry
Never insert objects of any kind into this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid
of any kind on the produc t.
Do not attempt to s ervice the product yourself as opening or removing covers may expose you
24. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified s ervice personnel under
the following conditions :
a. When the power-s upply cord or the plug is damaged,
b. If liquid has been s pilled, or objects have fallen into the product,
c. If the product has been exposed to rain or water,
d. If the product does not operate normally by following the operating instructions. Adjus t only
those controls that are covered by the operating instructions as an improper adjustment of
other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation,
e. If the product has been dropped, or damaged in any way,
f. When the produc t exhibits a distinct change in performance, this indicates a need for service.
25. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the s ame characteristics as the original part. Unauthorized
subs titutions may result in fire, electric shock, or other hazards.
26. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
27. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
28. Heat
The product should be s ituated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produc e heat.
29. Nonuse Period
If the unit is to be left unus ed for a long period of time, unplug the power cord.
30. Note To CATV System Installer
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable
ground s hall be connected to the grounding system of the building, as close to the point of cable
entry as practical.
6
IMPORTANT SAFETY INSTRUCTIONS
FIGURE A
EXAMPLE OF ANTENNA
GROUNDING ACCORDING TO
NATIONAL ELECTRICAL CODE
INSTRUCTIONS
a. Use No.10AWG(5.3mm2)copper, No.8 AWG(8.4mm2)aluminum, No.17AWG(1.0mm2) copper-clad
steel or bronze wire, or larger, a s a ground wire.
b. Secure antenna lead-in and ground wires to house with stand-off insulators spaced from 4-6 feet
(1.22-1.83m) apart.
c. Mount antenna dis charge unit as close as possible to where lead-in enters house.
d. Use jumper wire not s maller than No.6AWG(13.3mm2) copper, or the equivalent, when a separate
antenna grounding elec trode is used.
7
IMPORTANT SAFETY INSTRUCTIONS
ON PLACEMENT
* Do not us e the unit in places which are extremely hot, cold, dusty or humid.
* Place the unit on a flat and even s urface.
* Do not restric t the air-flow of the unit by placing it in a place with poor ventilation, by
covering it with a cloth or by placing it on a carpet.
ON CONDENSATION
* When left in a heated room where it is warm and damp, water droplets or condensation
may form inside the unit.
* When there is condens ation inside the unit, the unit may not function normally.
* Let it stand for 1 to 2 hours before turning the power on, or gradually heat the room up and
dry the unit before us e.
CAUTION:
Remove AC plug from wall outlet and batteries from battery compartment of the remote control
when the unit will not be used for a prolonged period.
HIGH VOLTAGE:
Live parts are acces sible when the rear cover is removed.
Please read IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
This product inc orporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
8
PRECAUTIONS
NOTES ON HANDLING:
• When shipping the TV/DVD player, always use the
original shipping carton and packing materials. For
maximum protection, repack the unit as it was
originally packed at the factory.
• Do not use volatile liquids, such as insect spray near
the TV/DVD player.
• The top and rear panels of the TV/DVD player may
become warm after a long period of use. This is
normal and not a malfunction.
• When the TV/DVD player is not in use, be sure to
remove the disc and turn off the power.
• If you do not use the TV/DVD player for a long
period, the unit may not function properly in the future.
Turn on and use the TV/DVD player occasionally.
NOTES ON CLEANING:
Use a soft, dry cloth for cleaning.
• For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe
it dry. Do not use any type of solvent, such as
thinner and benzene, as they may damage the
surface of the TV/DVD player.
• If you use a chemical-saturated cloth to clean the
unit, follow that product’s instructions.
Warning: Cleaning and adjustment of lenses and/or
other components of playback mechanism should be
performed by a qualified service technician.
TO OBTAIN A CLEAR PICTURE:
The TV/DVD player is a high technology, precision
device. If the optical pic k-up lens and disc drive parts are
dirty or worn down, the picture quality becomes poor. To
obtain a clear picture, we recommend regular inspection
and maintenanc e (cleaning or parts replacement) every
1,000 hours of use depending on the operating
environment. For details , contact your nearest dealer.
NOTES ON MOISTURE CONDENSATION:
Moisture condensation damages the TV/DVD player.
Please read the following carefully.
• Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. In the same way,
moisture may condense on the optical pick-up lens inside
this unit, one of the most crucial internal parts of the TV/
DVD player.
Moisture condensation occurs during the following
cases:
• When you bring the TV/DVD player directly from a cold
place to a warm place.
• When you use the TV/DVD player in a room where you
just turned on the heater, or a place where the cold wind
from the air conditioner directly hits the unit.
• In summer, when you use the TV/DVD player in a hot
and humid place just after you moved the unit from an
air conditioned room.
• When you use the TV/DVD player in a humid place.
Do not use the TV/DVD player when moisture
condensation may occur.
• If you use the TV/DVD player in such a situation, it may
damage discs and internal parts. Remove the disc,
connect the power cord of the TV/DVD player to the wall
outlet, turn on the TV/DVD player and leave it “ON” for
two or three hours. After two or three hours, the TV/DVD
player will have warmed up and evaporated any moisture.
Keep the TV/DVD player connected to the wall outlet and
moisture condensation will seldom occur.
POWER SOURCE
Insert the AC plug (with the 2 blades) into a conveniently located AC outlet
having 120V, 60Hz.
NOTE: The AC plug supplied with the unit is polarized to help minimize the
possibility of electric shock. If the AC plug does not fit into a nonpolarized
AC outlet, do not file or cut the wide blade. It is the user’s responsibility to
have an electrician replace the obsolete outlet.
9
AC Outlet
AC Plug
LOCATION OF CONT ROLS
1. Speaker
2. Power Button
3. Channel Buttons
4. DVD Door
5. TV/AV/DVD Button
6. MENU Button
7. Volume Buttons
8. DVD Stop Button
9. DVD Play Button
10. DVD Open/Close Button
11. Remote Sensor
12. Front Audio ( R) Input (AV 2)
13. Front Audio (L) Input (AV 2)
14. Front Video Input (AV 2)
15. Earphone Jack
16. 75 ohm Antenna Socket
17. Video/Audio Input (AV 1)
18. Video/Audio Output
19. Digital Audio Out Socket
(For DVD only)
10
REMOTE CONTROL
1. TV/AV Button
2. POWER Button
3. Number Buttons/- -- Button
4. TV Navigation ( ) Button
5. TV MENU Button
6. TV Navigation ( ) Button
7. TV Navigation ( ) Button
8. CHANNEL Up/Down Button
9. DVD Navigation ( ) Button
10. ENTER Button
11. DVD Navigation ( ) Button
12. DVD Navigation ( ) Button
13. DVD MENU Button
14. PAUSE/STEP Button
15. PLAY ( ) Button
16. ZOOM Button
17. STOP ( ) Button
18. SUBTITLE Button
19. REPEAT Button
20. SETUP Button
21. SEARCH Button
22. PROGRAM Button
23. CLEAR Button
24. DVD/TV Button
25. OPEN/CLOSE Button
26. SLEEP Button
27. DISPLAY Button
28. MUTE Button
29. PP (Personal Preference) Button
30. TV Navigation ( ) Button
31. VOLUME Up/Down Button
32. DVD Navigation ( ) Button
33. +10 Button
34. SEARCH Button
35. SEARCH Button
36. SKIP ( ) Button
37. SKIP ( ) Button
38. Repeat A-B Button
39. ANGLE Button
40. AUDIO Button
41. SLOW PLAY Button
42. DISPLAY Button
11
REMOTE CONTROL (CONTINUED)
BATTERY INSTALLATION
1. Loosen the screw to open the battery compartment cover.
2. Install two (2) “AAA” batteries (not included), paying
attention to the polarity diagram in the battery compartment.
3. Screw the battery compartment cover on the battery
compartment.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated next to the
battery compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and Carbon-zinc)
or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer’s directions.)
EFFECTIVE DISTANCE OF THE REMOTE CONTROL TRANSMITTER
12
NOTES:
• When there is an obstacle
between the DVD and the
transmitter, the transmitter may
not operate.
• When direct sunlight, an
incandescent lamp, fluorescent
lamp or any other strong light
shines on the REMOTE
SENSOR of the DVD, the
remote operation may be
unstable.
Loading...
