Emerson SB250A User Manual

SB250A

Copyright 2005 Viacom International Inc. All Rights Reserved. Nickelodeon,
Nicktronics, SpongeBob SquarePants and all related titles, logos and
characters are trademarks of Viacom International Inc. Created by
Stephen Hillenburg.

!

CAUTION

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrow­head symbol, within an equi­lateral triangle is intented to
alert the user to the presence
of uninsulated ‘dangerous voltage’
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.

WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER
(O R BACK ), NO USE R
SERVICEABLE PARTS INSIDE
REFER SERVI CIN G TO
Q U A L I F I E D S E R V I C E
PERSONNEL.

The exclamation point within
an equilateral triangle is in­tended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompany­ing the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1.) Read these instructions.

2.) Keep these instructions.

3.) Heed all warnings.

4.) Follow all instructions.

5.) Do not use this apparatus near water.

6.) Clean only with dry cloth.

7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.

8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10.) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11.) Only use attachments / accessories specified by the manufacturer.

12.) Unplug this apparatus during lightning storms or when unused for long periods of time.

13.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.

14.) This appliance shall not be exposed to dripping or splashing water and no object filled with
liquids such as vases shall be placed on the apparatus.

15.) Do not overload wall outlet. Use only power source as indicated.

16.) Use replacement parts as specified by the manufacturer.

17.) The product may be mounted to a wall only if recommended by the manufacturer.

18.) Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.

1

SB250A_011205.p65 12/1/2005, 17:251

Emerson Radio Corp . has produced this audio prod uct under licence from
Nickelodeon. We have taken great care to make sure your unit was in
perfect working order when it left our factory.

It has been designed to give you many years of enjoyment and trouble free
operation. Read this manual before operating this unit to become familiar
with i ts features. In the event you require technical assistance, please contact
the Emerson Radio Customer Service hotline at 1-800-898-9020. Retain
this manual for future reference.

NOTES:

• Please avoid using this unit in places of high temperature or humidity
over prolonged periods of time as damage may occur.

• Exposure to direct sunlight in places such as car interiors may cause
the unit to become warped and/or lead to malfunctioning.

• Avoid using or storing this unit in dusty or sandy locations.

The serial number of your unit is located on a label on the bottom cabinet.
Please take a moment now to record the serial number in the space
provided below. You may need this number in case your unit is damaged
or lost. You may also be asked to provide this number when calling to
request warranty service.

Model No: SB250A
Serial No:

SB250A_011205.p65 12/1/2005, 17:252

2

IMPORTANT NOTES

• Av oid installing this unit in places

exposed to direct sunlight or close to
heat radiating applianc es such as
electric heaters, on top of other stereo
equipment that r adiates too much heat,
places lacking ventilation or dusty areas,
places subject to constant vibration and/
or humid or moist areas.

• Do not attempt to clean this unit with

chemical solvents as this might damage

• Operate controls and switches as
described in the manual.

• Before turning ‘On’ the power, make
certain that power cord is properly
installed.

• Store your CDs in a cool area to avoid
damage from heat.

• When moving the set, be sure to first
disconnect the power cord.

the finish. Use a clean dry cloth.

CLASS 1 LASER PRODUCT

CLASS 1 LASER PRODUCT

APPAREIL Á LASER DE CLASSE 1

PRODUCTO LASER DE CLASE 1

This product contains a low power Laser Device.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interferenc e to radio
communications. Howev er, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, whic h can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that

may cause undesired operation.

CAUTION

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS

DEFEATED.

AVOID EXPOSURE TO BEAM

SB250A_011205.p65 12/1/2005, 17:253

3

PREPARATION FOR USE

UNPACKING AND SET UP

• Carefully remove the main unit and the AC power cord from the display

carton. Remove all the packing material from the unit. Remove any
decorative or descriptive labels from the front or top of the cabinet. Do
not remove any labels from the back or bottom of the cabinet.

• Carefully remove any small strips of tape that may have been used to

prevent the CD door from opening in transit.

• Unwind the AC power cord and extend it to its full length.

• This unit was shipped with a dummy CD transit card in the CD player.

This dummy CD prevents the laser pick up from moving during
shipment. This card must be removed before you can insert your own
CDs. Press on the indented area of the CD door to open it. Carefully
remove the dummy CD from the player and discard it. Close the CD
door.

• Place the unit on a flat, level surface such as a table, desk, counter,

shelf, etc, convenient to a 120V 60 Hz AC outlet, out of direct sunlight,
and away from sources of excess heat, dust, moisture, or strong
magnetic fields.

4

SB250A_011205.p65 12/1/2005, 17:254

POWER SOURCES

AC Outlet

This model is designed to operate on 120V 60Hz AC or 12V DC (8 “C” batteries,
not included). Attempting to operate this model from any other power source could
cause damage to the unit and such damage is not covered by your warranty.

AC Operation

Connect the small end of the AC power cord to the AC socket on the back cabinet,
then plug the AC power cord into a 120V AC outlet.

PHONES

NOTE: This unit has a polarized AC plug with one wide blade and one narrow

blade. This plug will only fit into a matching polarized AC outlet. This is a safety
feature to reduce the possibility of electric
shock. If this plug will not fit in your AC outlet,
you probably have an outdated non-polarized
outlet. You should have your outdated outlet
changed by a qualified, licensed electrician. Do
not file the wide blade on the plug, or use an
adapter to make the plug fit into your outlet.
This defeats the safety feature and could
expose you to electric shock.

Note: In order to operate the unit on batteries the AC power cord must be
completely disconnected from the AC socket on the back cabinet.

5

SB250A_011205.p65 12/1/2005, 17:255

AC Plug

Battery Operation

1.) Turn the unit upside down. The battery compartment is located on the bottom

cabinet.

2.) Press downward on the battery door locking tabs and remove the battery door.

Locking Tabs

3.) Insert 8 fresh “C” batteries, not included, in the battery compartment. We

recommend alkaline batteries for longest life and best performance. Be sure
to observe the battery polarity markings engraved in the battery compartment.
If the batteries are inserted incorrectly the unit will not work.

4.) Replace the battery door.

When the sound becomes weak or distorted it is time to change the batteries.
Always change all 8 batteries at the same time. Do not mix old and new batteries
together. Do not mix different types of batteries, such as alkaline batteries and
normal batteries, in the battery compartment.

If the unit will not be used for an extended period of time - such as two weeks or
more – or if the unit will be used mainly on AC power, remove the batteries from
the battery compartment. If weak or dead batteries are left in the battery
compartment they may eventually leak, causing possible corrosion damage to the
unit, and such damage is not covered by your warranty.

6

SB250A_011205.p65 12/1/2005, 17:256
