Emerson PD5812 User Manual

Portable CD-R/RW Player

with Digital Tuning AM/FM Radio

OWNER'S MANUAL

PD5812

Visit our web site at www.emersonradio.com

WARNING

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE
O

R OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO

PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with
arrowhead symbol within an
equilateral triangle is intended
to alert the user to the
presence of uninsulated
‘dangerous voltage’ within the
product’s enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.

CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR
BACK), NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.

The exclamation point within
an equilateral triangle is
intended to alert the user to the
presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus
(including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles
and the point where they exit from the apparatus.

Only use attachments/accessories specified by the manufacturer.

11.

12. Unplug this apparatus during lightning storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way such as the following: the power-supply cord or plug has been damaged; liquid has
been spilled or objects have fallen into the apparatus; the apparatus has been exposed to rain or
moisture; the apparatus does not operate normally, has changed its performance or has been dropped.

14. This appliance should not be exposed to dripping or splashing water and no object filled with liquids
such as vases should be placed on the apparatus.

15. Do not overload wall outlet. Use only power source as indicated.

16. Use replacement parts as specified by the manufacturer.

17. The product may be mounted to a wall only if recommended by the manufacturer.

18. Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks.

1

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY: This unit employs a laser. Only qualified service personnel should attempt to service
this device due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

WARNING: DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

DANGER:

Invisible and hazardous laser radiation when open and interlock failed or defeated. Avoid
direct exposure to beam.

FCC WARNING:

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment
may cause harmful interference unless the modifications are expressly approved in the instruction manual.
The user could lose the authority to operate this equipment if an unauthorized change or modification is
made.

Thank you
For purchasing the Portable CD audio system from Emerson. This uniquely designed product has a built-in
CD player with a 20 track programmable memory, random and repeat playback. It also features a great
sounding digital tuning AM/FM stereo radio with 20 preset station memories.

We are sure that this unit will provide you with many years of exceptional performance with a minimum of
care and maintenance. Please review the contents of this instruction manual completely and carefully before
operating your unit, to make sure that you understand all functions and operations and get the maximum
benefit out of all the great features included in this product.

2

PREPARATION FOR USE

AC Plug

AC Outlet

+

+

+

+

+

+

+

+

Unpacking and Setup

• Carefully remove the unit from the display carton and remove all packing material from the unit itself.

• The detachable AC power cord is packed in the carton separately from the unit. Make sure that the AC

power cord is not accidentally discarded with the carton or packing material.

• Press the OPEN/CLOSE area to open the CD compartment door. There is a white card in the CD

compartment which is intended to prevent the CD pickup from moving during shipment of the product.
Remove this card from the CD compartment before use.

Power Sources

This portable audio system is designed to operate on either 120V AC 60Hz house current or by using eight
(8) ‘C’ batteries, not included. Attempting to operate this unit from any other power source may cause
damage to the unit, which is not covered by your warranty.

AC Operation

Unwind the AC cord and extend it to its full length. Insert the small end of
the AC cord into the AC socket on the rear of the unit. Insert the other end
of the AC cord into any convenient 120V 60Hz household outlet.

Please note that this unit is equipped with a polarized AC plug which has
one blade wider than the other. This is a safety feature to reduce the
likelihood of electric shock. This polarized AC plug will only fit in a
polarized AC outlet. If you find that you cannot insert this plug into your
outlet, you may have an obsolete non-polarized outlet. Please do not try to
defeat this safety feature by using a non-polarized adapter or by filing the
wider blade to make it fit into your outlet. If this plug does not fit into your outlet, you should contact a
qualified licensed electrician to replace your obsolete outlet.
NOTE: The radio memories will be kept for 10 seconds if the AC cord is unplugged and no batteries are
inserted.

Battery Installation

To use this unit with battery power, remove the battery compartment on the bottom of the unit by sliding it in
towards the rear of the unit. Insert eight (8) ‘C’ size batteries following the diagram in the compartment.

NOTE: The AC power cord must be disconnected from the AC socket on the rear of the unit in order for the
unit to operate on battery power.

FRONT

3

PREPARATION FOR USE (CONTINUED)

Headphones

For private listening, plug headphones (not included) into the Headphone jack on the side
of the unit. The speakers will be disconnected when headphones are used

PROTECT YOUR FURNITURE

This model is equipped with non-skid rubber 'feet' to prevent the product from moving
when you operate the controls. These 'feet' are made from non-migrating rubber material
specially formulated to avoid leaving any marks or stains on your furniture. However
certain types of oil based furniture polishes, wood preservatives, or cleaning sprays may
cause the rubber 'feet' to soften, and leave marks or a rubber residue on the furniture. To
prevent any damage to your furniture we strongly recommend that you purchase small
self-adhesive felt pads, available at hardware stores and home improvement centers
everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the
product on fine wooden furniture.
