Emerson LC195EM82 Owner's Manual

EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.

19” Digital / Analog

LCD TV

Owner’s Manual

LC195EM87

LC195EM82

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

HIGH-DEFINITION TELEVISION

TO RECEIVE DIGITAL/ANALOG SIGNAL, YOU MUST CONNECT ANTENNA.

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

IF YOU NEED ADDITIONAL ASSISTANCE WITH SETUP OR OPERATING AFTER READING OWNER’S MANUAL, PLEASE CALL TOLL FREE 1-800-256-2487, OR VISIT OUR WEB SITE AT http://www.EmersonAudioVideo.com

NTRODUCTION

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

Important Safeguards

1. READ INSTRUCTIONS - All the safety and operating instructions

should be read before the appliance is operated.

2. RETAIN INSTRUCTIONS - The safety and operating instructions

should be retained for future reference.

3. HEED WARNINGS - All warnings on the appliance and in the

operating instructions should be adhered to.

4. FOLLOW INSTRUCTIONS - All operating and use instructions

should be followed.

5. CLEANING - Unplug TV from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

EXCEPTION: A product that is meant for uninterrupted service and,

that for some speci c reason, such as the possibility of the loss of an authorization code for a CAT V converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6. ATTACHMENTS - Do not use attachments not recommended by

the TV manufacturer as they may cause hazards.

7. WATER AND MOISTURE - Do not use this TV near water, for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8. ACCESSORIES - Do not place this TV on

an unstable cart, stand, tripod, bracket, or table. The TV may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV.

Any mounting of the appliance should follow

the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

AMEUBLES - Cet appareil ne doit être placé

que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’ installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. VENTILATION - Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the TV on a bed, sofa, rug, or other similar surface. This TV should never be placed near or over a radiator or heat register. This TV should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10. POWER SOURCES - This TV should be operated only from the type

of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TVs intended to operate from battery power, or other sources, refer to the operating instructions.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

11. GROUNDING OR POLARIZATION - This TV is equipped with a

polarized alternating-current line plug (a plug having one blade wider than the other). This plug will  t into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to  t, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12. POWER-CORD PROTECTION - Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. OUTDOOR ANTENNA GROUNDING - If an outside antenna or

cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

EXAMPLE OF ANTENNA GROUNDING AS PER

14. LIGHTNING - For added protection for this TV receiver during a

15. POWER LINES - An outside antenna system should not be located

16. OVERLOADING - Do not overload wall outlets and extension

17. OBJECT AND LIQUID ENTRY - Never push objects of any kind into

FIGURE A

NATIONAL ELECTRICAL CODE

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING

lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV due to lightning and power-line surges.

in the vicinity of overhead power lines or other electric light of power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

cords as this can result in a risk of  re or electric shock.

this TV through openings as they may touch dangerous voltage points or short out parts that could result in a  re or electric shock. Never spill liquid of any kind on the TV.

GROUND CLAMPS

ELECTRODE SYSTEM (NEC ART 250, PART H)

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

INTRODUCTION

18. SERVICING - Do not attempt to service this TV yourself as opening

or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to quali ed service personnel.

19. DAMAGE REQUIRING SERVICE - Unplug this TV from the wall

outlet and refer servicing to quali ed service personnel under the following conditions: a. When the power supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the TV. c. If the TV has been exposed to rain or water. d. If the TV does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a quali ed technician to restore the TV to its normal operation.

Precautions

e. If the TV has been dropped or damaged in any way. f. When the TV exhibits a distinct change in performance, this

indicates a need for service.

20. REPLACEMENT PARTS - When replacement parts are required, be

sure the service technician uses replacement parts speci ed by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in  re, electric shock, injury to persons or other hazards.

21. SAFETY CHECK - Upon completion of any service or repairs to this

TV, ask the service technician to perform routine safety checks to determine that the TV is in proper operating condition.

22. HEAT - This TV product should be situated away from heat sources

such as radiators, heat registers, stoves, or other products (including ampli ers) that produce heat.

LAMP IN LCD CONTAINS MERCURY, DISPOSE ACCORDING TO LOCAL, STATE OR FEDERAL LAW.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA

BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

FCC WARNING

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground should be connected to the grounding system of the building as close to the point of cable entry as practical.

LOCATION

For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation:

• Shield it from direct sunlight and keep it away from sources of intense heat.

• Avoid dusty or humid places.

• Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

• Install the unit in a horizontal position.

• Avoid locations subject to strong vibration.

• Do not place the unit near strong magnetic fields.

• Avoid moving the unit to locations where temperature differences are extreme.

• Be sure to unplug the AC power cord from the outlet before carrying the unit.

TO AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

• Do not handle the power cord with wet hands.

• Do not pull on the power cord when disconnecting it from an AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the power cord immediately and take the unit to our authorized service center for servicing.

• Do not place anything directly on top of the unit.

This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

Product that have earned ENERGY STAR® are designed to protect the environment through superior energy efficiency.

NTRODUCTION

The serial number of this product may be found on the back of the unit. No others have the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft.

date of purchase

dealer purchase from

Note about recycling:

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

dealer phone No.

model No.

serial No.

dealer address

Supplied Accessories5

owner’s manual (1EMN22282)

• If you need to replace these accessories, please refer to the part No. with the illustrations and call our toll free customer support line found on the cover of this manual.

• Depending on your antenna system, you may need different types of combiners (mixers) or separators (splitters). Contact your local electronics store for these items.

remote control (NF604UD)

batteries (AA x 2)

Phillips pan screw for attaching the stand x 2 (FPH34140)

Attaching the Stand

You must attach the stand to the unit to display upright. Be sure the front and rear of the stand match the proper direction.

Turn the main unit over and place

it onto a table which has a soft cloth draped over it. Make sure not to damage the screen.

Note:

• When attaching the stand, ensure that all screws are tightly fastened. If the stand is not properly attached, it could cause the unit to fall, resulting in injuries as well as damage to the unit.

• Make sure to use a table which can support the weight of this unit and is larger than this unit.

• Make sure the table is in a stable location.

Symbols Used in this Manual

The following is the description for the symbols used in this manual. Description refers to:

Insert the stand all the way to the

main unit slowly.

Drive Phillips pan screws in the 2

threaded holes with a screwdriver tightly.

: Digital TV operation

DTV

: Analog TV operation

• If neither symbol appears under the function heading, operation is applicable to both.

INTRODUCTION

Features5

• DTV/TV/CATV

- You can use your remote control to select channels which are broadcast in digital format and conventional analog format. Also, cable subscribers can access their cable TV channels.

• Information Display (DTV only)

- You can display the title, contents and other information of the current DTV program on the TV screen.

• Auto Channel Scan

- This unit automatically scans and memorizes channels available in your area, eliminating difficult setup procedures.

• V-chip

- This feature allows you to block children’s access to inappropriate programs.

• Closed Caption Decoder

- Built-in closed caption decoder displays text for closed caption supported programming.

• MTS/SAP Tuner

- Audio can be selected from the remote control.

• Auto Shut Off Function

- If there is no signal input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.

• Sleep Timer

- This feature will automatically turned off the power of the unit at a specific time.

• Choices for On-screen Language

- Select your on-screen language: English, Spanish or French.

• Stereo Sound Function

• PLL Frequency Synthesized Tuning

- Provides free and easy channel selection and lets you tune directly to any channel using the channel number buttons on the remote control.

• Component Video Input

• S-video Input

• AV Input

• Digital Audio Coaxial Output

Contents5

INTRODUCTION

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Attaching the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Symbols Used in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Remote Control Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

CONNECTION

Basic Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

External Device Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

INITIAL SETTING

Initial Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Auto Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Language Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

WATCHING TV

Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Switching Each Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Switching Audio Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

TV Screen Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

OPTIONAL SETTING

Channel Add/Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Picture Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Closed Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

DTV Closed Caption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

DTVCC Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Back Light Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Color Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

V-chip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TROUBLESHOOTING

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

INFORMATION

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Cable Channel Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

General Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Electrical Speci cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Other Speci cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

OPTIONAL SETTING TROUBLESHOOTING

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover

All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed, downloaded or stored in any storage medium, in any form or for any purpose without the express prior written consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.

Information in this document is subject to change without notice. Funai reserves the right to change the content herein without the obligation to notify any person or organization of such changes.

with the design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way without the express written consent of Funai. All other trademarks used herein remain the exclusive property of their respective owners. Nothing contained in this manual should be construed as granting, by implication or otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights to the fullest extent of the law.

NTRODUCTION

Remote Control Function5

1. POWER button (p11)

Press to turn the unit on and off.

1 2

5 6

2. MUTE

Press to turn the sound on and off.

3. SLEEP button (p14)

12 13

Press to activate the sleep timer.

4. Number buttons (p13)

• Press to select channels.

-/ENT. button

• Press to shift the minor channel

+100 button

• Press to select 100 or higher

• Press to search if there are minor

5. CH. K / L buttons (p13) Press to select channels and the

external input mode.

6. VOL. X / Y buttons (p13) Press to adjust the volume.

7. ENTER button (p11) Press to decide the command of

setting when the main menu is displayed.

8. SETUP button (p11) Press to display the main menu.

9. s / B / K / L buttons (p11) Press to move left/ right/ up/

down through the items.

button (p13)

from the major channel.

channels. (CATV)

channels on the currently selected major channel. (DTV)

10. RETURN

Press to return to previous menu

operation.

11. INPUT button (p13)

• Press to access connected an external device like a DVD player or VCR.

• Press to switch between the digital mode (DTV) and analog mode.

12. DISPLAY

Digital Mode (DTV)

• Press to display the channel

information, signal type and TV setting.

Analog Mode (TV)

• Press to display the channel number, signal type and TV setting.

External Input Mode

• Press to display the external input mode, signal type and TV setting.

13. AUDIO button (p14)

Digital Mode (DTV)

• Press to select the audio language.

Analog Mode (TV)

• Press to select the audio mode.

14. SCREEN MODE button (p16) Press to select aspect ratio

available for the TV screen.

15. CH. RECALL

Press to return to previous channel.

button

button (p15)

button (p13)

Installing the Batteries

Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control.

21 3

Battery Precautions:

• Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.

• Do not mix different types of batteries together (e.g., Alkaline and Carbon-Zinc) or old batteries with fresh ones.

• If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.

• Do not try to recharge batteries; they can overheat and rupture.

INTRODUCTION

Control Panel5

1. POWER button (p11)

POWER

INPUT SELECT

CHANNEL

VOLUME

SETUP

Press to turn the unit on and off.

2. INPUT SELECT button (p13)

Press to access connected an external device like a

• DVD player or VCR. Press to decide the command of setting when the

• menu is displayed.

3. CHANNEL K / L buttons (p13)

Press to select channels or move up/down through the

main menu items.

4. VOLUME X / Y buttons (p13)

Press to adjust the volume or move right (X) / left (Y) through the main menu items.

5. SETUP button (p11)

Press to display the main menu.

6. Infrared Sensor Window

Receives infrared rays transmitted from the remote control.

CONNECTION

INITIAL SETTING

WATCHING TV INFORMATION

Rear Panel5

rear of this unit

OPTIONAL SETTING TROUBLESHOOTING

1. ANT jack (p8) RF coaxial cable connection for your antenna or

cable /satellite box.

2. HEADPHONE jack

Headphone connection for personal listening.

3. COMPONENT and AUDIO input jacks (p9) Component video cable connection for an external

device.

Use component video and audio output jacks of an

external device.

4. AUDIO input jacks (p9) RCA audio cable connection for an external device.

5. VIDEO input jack (p10)

RCA video cable connection for an external device.

6. S-VIDEO input jack (p9) S-video cable connection for an external device.

7. COAXIAL (digital audio) output jack (p10)

side of the unit

VIDEO 2

AUDIOCOMPONENT

PrPbY

VIDEO 1

AUDIO

VIDEOS-VIDEO

COAXIAL

6 7 8

Digital audio coaxial cable connection for a decoder or

an audio receiver.

Use digital audio input jack of an external device.

8. AC power cord

Connect to a standard AC outlet to supply power to

this unit.

ONNECTION

Cables not included.

Please purchase the necessary cables at your local store.

Basic Connection

This section describes how to connect the unit to an antenna, cable/satellite box, etc.

Note:

• Be sure your antenna or other device is connected properly before plugging in the power cord.

[Antenna Cable Connection]

When connecting the unit to an antenna or cable TV company (without cable/satellite box) Connect the RF coaxial cable on your home outlet to the antenna input jack of this unit.

e.g.)

VHF / UHF

antenna

RF coaxial cable

cable TV

company

* Once connections are completed, turn on the unit and begin initial setup.

Channel scanning is necessary for the unit to memorize all available channels in your area. (Refer to “Initial Setup” on page 11.)

rear of this unit

Note:

• For your safety and to avoid damage to device, please unplug the RF coaxial cable from the antenna input jack before moving the unit.

• If you use an antenna to receive analog TV, it should also work for DTV reception. Outdoor or attic antennas will be more effective than settop versions.

• To easily switch your reception source between antenna and cable, install an antenna selector.

• If you connect to the cable system directly, contact the CATV installer.

[Connection to Cable Box or Satellite Box]

Connect the RF coaxial cable on your home outlet to the input jack of the cable/satellite box. Use another RF coaxial cable to connect the antenna input jack of the unit to the output jack of the cable/satellite box.

e.g.)

satellite

dish

cable/satellite box

rear of this unit

cable TV

company

* Required cables and connecting methods differ depending on the cable/satellite box.

For more information, please contact your cable/satellite provider.

RF coaxial cable RF coaxial cable

RF OUTANT. IN

(red)

(blue)

(green)

Cables not included.

Please purchase the necessary cables at your local store.

External Device Connection

[Component Video Cable Connection]

Component video connection offers better picture quality for video devices connected to the unit. Use a component video cable to connect the unit to external video devices equipped with component video output jacks. If you connect to the unit’s component video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO2.

component video cable

(red)(blue)(green)

e.g.)

DVD player with the component video output jacks

COMPONENT VIDEO OUT

AUDIO OUT

PrPbY

rear of this unit

(blue)

(green)

COAXIAL

(red)

(red)(blue)(green)

VIDEOS-VIDEO

VIDEO 2

PrPbY

VIDEO 1

AUDIOCOMPONENT

AUDIO

CONNECTION

INITIAL SETTING

WATCHING TVINTRODUCTION

RCA audio cable

Note:

• This unit accepts 480i / 480p / simplified 1080i video signals.

• Simplified 1080i video signal differs to the original 1080i video signal because it is displayed after converted into 480p signal.

[S-video Cable Connection]

S-video connection offers good picture quality for video devices connected to the unit. Use an S-video cable to connect the unit to external video devices equipped with S-video output jack. If you connect to the unit’s S-video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO1.

e.g.)

DVD player with the S-video output jack

AUDIO OUT

S-VIDEO

OUT

rear of this unit

COAXIAL

VIDEO 2

PrPbY

VIDEO 1

VIDEOS-VIDEO

AUDIOCOMPONENT

AUDIO

S-video cable

RCA audio cable

OPTIONAL SETTING

TROUBLESHOOTING

INFORMATION

Note:

• If you connect to the S-video jack and the video jack at the same time, the S-video connection will have priority.

ONNECTION

Cables not included.

Please purchase the necessary cables at your local store.

[Video Connection]

Video connection offers standard picture quality for video devices connected to the unit. If you connect to the unit’s video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO1. When the audio jack of the video device is monaural, connect the RCA audio cable to the audio L input jack.

rear of this unit

e.g.)

AUDIO OUT

camcorder video game

VIDEO

OUT

VIDEO 2

AUDIOCOMPONENT

PrPbY

VIDEO 1

AUDIO

COAXIAL

VIDEOS-VIDEO

RCA video cable

VCR

RCA audio cable

Note:

• If you connect to the S-video jack and the video jack at the same time, the S-video connection will have priority.

[Digital Audio Output Connection (for digital broadcasting only)]

If you connect this unit to an external digital audio device, you can enjoy multi-channel audio like 5.1ch digital broadcasting sound.

e.g.)

Dolby Digital decoder

DIGITAL AUDIO

COAXIAL IN

rear of this unit

COAXIAL

VIDEO 2

PrPbY

VIDEO 1

VIDEOS-VIDEO

AUDIOCOMPONENT

AUDIO

digital audio coaxial cable

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

NITIAL SETTING

These operations are accessible by remote control. Some may also be accessible by controls on the main unit.

Initial Setup

This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and “AUTO PRESET CH”, which automatically scans and memorizes viewable channels.

Before you begin:

Make sure if the unit is connected to antenna or cable.

After making all the necessary connections, press

[POWER] to turn on the unit.

• This operation may take a few moments.

Use [Cursor K / L] to select the on-screen language

from the choices on the right side of the TV screen. (ENGLISH / ESPAÑOL / FRANÇAIS)

SELECT LANGUAGE SELECCIONE EL IDIOMA CHOISIR LA LANGUE

SELECT : K,

SELECCIONE : K,

CHOIX : K,

• “INITIAL SETUP“ menu on step 3 will be displayed in

the selected language after you press [ENTER].

, L , L , L

SET

AJUSTE

VALIDER

ENGLISH ESPAÑOL FRANÇAIS

ENTER

Note:

• If you connect the cable system directly, contact the CATV installer.

• If you press [POWER] or [SETUP] during “AUTO PRESET CH”, this setting will be canceled.

• The initial auto channel scan function can be executed for either TV/DTV or CATV only once. If you want to scan both TV/DTV and CATV, you need to select “CHANNEL SETUP” in the main menu to scan and memorize other channels after initial presetting is completed. (Refer to page 12.)

• You can cancel or exit the initial “AUTO PRESET CH” menu by pressing [SETUP].

• When no channel can be received by “AUTO PRESET CH”, “NO TV SIGNALS” is displayed on the TV screen.

• If there is no signal input from the antenna terminal and no operation for several seconds after you turn on the unit, “HELPFUL HINTS” appears. Follow the instructions listed on the TV screen.

- HELPFUL HINTS -

1. PLEASE CHECK TO SEE IF THE ANTENNA / CABLE / SATELLITE IS PROPERLY CONNECTED.

2. DID YOU PERFORM “AUTO PRESET CH”?

3. PLEASE REFER TO FRONT PAGE OF THE OWNER’S MANUAL OR REAR PANEL FOR SUPPORT LINE INFORMATION.

Main Menu

This section describes the overview of the main menu displayed when you press [SETUP]. For more details, see the reference page for each item. The main menu consists of the function setting items below.

INITIAL SETTING

WATCHING TVINTRODUCTION CONNECTION

OPTIONAL SETTING

Use [Cursor K / L] to select “AUTO PRESET CH(TV/DTV)”

for TV channels or “AUTO PRESET CH(CATV)“ for CATV channels, then press [ENTER].

- INITIAL SETUP -

PLEASE CONNECT ANTENNA OR CABLE OR SATELLITE TO THIS UNIT.

AUTO PRESET CH (TV/DTV) AUTO PRESET CH (CATV)

• Scanning and memorizing the channels automatically start.

AUTO PRESET CH(TV/DTV)

• When the scanning and memorizing are completed,

the lowest memorized channel in the broadcasting will be displayed.

Press [SETUP]. e.g.) digital TV mode

- TV SETUP PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] BACK LIGHT [BRIGHT] COLOR TEMP. [NORMAL] DTVCC

• PICTURE

You can adjust the picture quality.

(Refer to “Picture Adjustment” on page 18.)

• CHANNEL SETUP

You can automatically scan the viewable channels and

remove those that are undesired. (Refer to “Auto Channel Scan” on page 12.)

• V-CHIP SETUP

You can set the viewing limitations. (Refer to “V-chip” on page 22.)

• LANGUAGE

You can change the language (English, Spanish,

French) displayed on the main menu.

(Refer to “Language Selection” on page 12.)

• CAPTION

You can change the display format for closed caption,

which displays the dialogue of a TV program or other information across the TV screen.

(Refer to “Closed Caption” on page 18.)

TROUBLESHOOTING

INFORMATION

NITIAL SETTING

• BACK LIGHT

You can set the desired brightness mode. (Refer to “Back Light Setting” on page 21.)

• COLOR TEMP.

You can adjust color temperature (“NORMAL”, “WARM”,

“COOL”).

(Refer to “Color Temperature” on page 21.)

• DTVCC

In addition to the basic closed caption described

on page 18, DTV has its own closed caption called DTVCC.

(Refer to “DTV Closed Caption” on page 19.)

Auto Channel Scan

If you switch wires (e.g., between antenna and CATV) or if you move the unit to a di erent area after the initial setting, or if you restore the DTV channel you deleted, you will need to perform auto channel scan.

Before you begin:

Make sure if the unit is connected to antenna or cable.

Press [SETUP] to display the main menu.

Use [Cursor K / L] to select “CHANNEL SETUP”, then

press [ENTER].

e.g.) digital TV mode

- TV SETUP -

Use [Cursor K / L] to select your desired preset type,

then press [ENTER].

e.g.) digital TV mode

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] BACK LIGHT [BRIGHT] COLOR TEMP. [NORMAL] DTVCC

- CHANNEL SETUP -

ADD/DELETE(DTV) AUTO PRESET CH(DTV) AUTO PRESET CH(TV/DTV) AUTO PRESET CH(CATV) ! CATV takes approx. 50min.

• When the scanning and memorizing are completed, the lowest memorized channel will be displayed.

• When you selected “AUTO PRESET CH(TV/DTV)”, the lowest memorized analog channel will be displayed when the scanning and memorizing are completed. If there is no analog channel, the lowest memorized digital channel will be displayed.

Note:

• If you connect the cable system directly, contact the CAT V

installer.

•

If you press [POWER] or [SETUP] during auto channel scan,

the setting will be canceled.

•

When no channel can be received by auto channel scan,

“NO TV SIGNALS” will be displayed on the TV screen.

Channel settings will be saved even if the power fails.

•

If you have Spanish or French menus and need English,

press [SETUP]. Use [Cursor K / L] to select “IDIOMA” or “LANGAGE”. Press [ENTER] to select “ENGLISH”. Press [SETUP] to remove the main menu.

•

With regard only to the digital channel, even after the

scanning is complete if you unplug the AC power cord before turning off the unit by pressing [POWER], the channel setting may be lost.

Language Selection

You can choose English, Spanish, or French as your on-screen language.

Press [SETUP] to display the main menu.

Use [Cursor K / L] to select “LANGUAGE”, then press

[ENTER] repeatedly to change the setting. e.g.) digital TV mode

- TV SETUP PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF]

BACK LIGHT [BRIGHT] COLOR TEMP. [NORMAL] DTVCC

ENGLISH

• When aerial antenna is connected, select “AUTO PRESET CH(TV)”, “AUTO PRESET CH(DTV)” or “AUTO PRESET CH(TV/DTV)”.

• When connected to CATV, select “AUTO PRESET CH (CATV)”.

• Scanning and memorizing the channels automatically

start.

e.g.) digital TV mode

AUTO PRESET CH(DTV)

D25

Press [SETUP] to exit.

ESPAÑOL

FRANÇAIS

ATCHING TV

INTRODUCTION

Channel Selection

5 Volume Adjustment

Select channels by using [CH. K / L] or [the Number buttons].

• To select the memorized channels, use [CH. K / L] or [the Number buttons].

• To select the non-memorized channels, use [the Number buttons].

To Use [the Number buttons]

- When selecting analog channel 12

DTV

- When selecting digital channel 12-1

Be sure to press [–/ENT.] before entering the minor channel number.

• Press [CH. RECALL ] to return to the previously

viewed channel.

• When you select a channel larger than 100, press [+100] first. Then use [the Number buttons] to press the lower 2-digit numbers.

About digital TV broadcasting:

With its high definition broadcast, digital broadcasting far surpasses analog broadcasting in both its picture and sound quality.

What is the minor channel?

By using high compression technology, digital broadcasting offers a service that enables multiple signals to send simultaneously. Therefore, you can select more than one program per major channel since digital broadcasting technology distinguishes between multiple channels broadcast by a single network.

NTSC (analog mode)

CH4

: change automatically : change manually by using [CH. K/L]

[Air Time]

18:00

18:30

19:00

19:30

20:00

20:30

major channel

ATSC (digital mode)

CH4

No signal No signal

CH4

(high denition TV)

CH4

CH4-1

No signal

CH4

No signal

CH4-1CH4 CH4-2

minor channel

CH4-2

Note:

• “NO SIGNAL” will appear on the TV screen after the minor channel broadcast is over.

This section describes how to adjust the volume. The mute function, which turns the sound off and on, is also described.

Use

[VOL. X / Y] to adjust the audio volume

VOLUME 20

• The volume bar will be displayed at the bottom of the TV screen when adjusting the volume.

• The volume bar display will automatically disappear in a few seconds.

Press [MUTE ] to turn off and on the sound.

MUTE 20

• “MUTE” is displayed on the TV screen for a few seconds.

Press [MUTE ] again or use [VOL. X / Y] to recover the original volume.

Switching Each Mode

You can easily switch with the remote control to the DTV (ATSC) and T V (NTSC) or to access an external device when they are connected to the unit.

Press [INPUT] repeatedly to cycle through the input modes.

ANALOG MODE

DIGITAL MODE

• To use the video or S-video input jack on the unit, select “VIDEO1”.

• To use the component video input jack on the unit, select “VIDEO2”.

Note:

• When you switch the analog mode to the digital mode, it may take a while until the digital channel selection is completed. “NOW SCANNING“ is displayed while switching the mode.

VIDEO1

VIDEO2

CONNECTION INITIAL SETTING OPTIONAL SETTING

WATCHING TV

TROUBLESHOOTING

INFORMATION

ATCHING TV

Switching Audio Mode

5 Sleep Timer

This section describes how to switch the audio in the analog mode and how to switch the audio language in the digital mode.

The sleep timer can be set to automatically turn o the unit after an incremental period of time.

While receiving an MTS broadcast, press [AUDIO ] repeatedly to cycle through the available audio channel.

MAIN

SAP

MAIN : Outputs main-audio SAP : Outputs second audio program MONO : Outputs mono-audio

• The information display will automatically disappear in a few seconds.

DTV

Press [AUDIO ] to display the currently selected

language and the number of available languages.

Press [AUDIO ] repeatedly to cycle through the

available audio languages.

MONO

A Day of Memories

75 TV-PG ENGLISH 1/2

25-03

KABC

Press [SLEEP ] to set the sleep timer.

• Sleep timer display appears on the TV screen.

Press [SLEEP ] repeatedly to change the amount of

time until shut off.

• You can set your unit to turn off after a set period of time (from 30 to 120 minutes).

• Each press of [SLEEP ] will increase the time by 30

minutes.

• After set up, the sleep timer display can be called up

for checking by pressing [SLEEP ].

To Cancel the Sleep Timer

Press [SLEEP displayed on the TV screen.

] repeatedly until “SLEEP OFF“ is

SLEEP OFF

SLEEP 120MIN.

• Available languages differ depending on the broadcast. “OTHER” is displayed when the audio language cannot be acquired, or the acquired languages are other than English, Spanish or French.

• The information display will automatically disappear

in a few seconds.

Note:

• Pressing [AUDIO ] does not control external audio device.

Note:

• The sleep timer setting display will automatically disappear in a few seconds.

• When you disconnect the unit from the AC outlet or when a power failure occurs, the sleep timer setting will be canceled.

Screen Information

You can display the currently selected channel or other information such as the audio mode on the TV screen.

In the analog mode, the current channel number is displayed.

DTV

In the digital mode, the detailed broadcasting information for the current channel such as program title, program guides are displayed.

INTRODUCTION

CONNECTION INITIAL SETTING OPTIONAL SETTING

Press [DISPLAY ].

• The current channel number is displayed at the topright corner of the TV screen.

• To clear the display, press [DISPLAY ] again.

CH 25

Press [DISPLAY ] repeatedly to cycle through the available display modes.

OFF

[Broadcasting Information]

• The following information is displayed.

1 program title 2 signal quality indicator 3 program rating 4 channel number 5 broadcast station 6 audio language

(Refer to “Switching Audio Mode” on page 14.)

[Program Guide]

• The program guide added to broadcasting information is displayed.

BROADCASTING INFORMATION

PROGRAM GUIDE

A Day of Memories

75 TV-PG ENGLISH 1/2

25-03

KABC

WATCHING TV

4 5 6

TROUBLESHOOTING

program guide

A Day of Memories

75 TV-PG ENGLISH 1/2

A quarter-century ago, which may now qualify as the good old days of newspapering, run-of-paper sales accounted for 80 percent of the industry’s advertising revenues.

25-03

KABC

Note:

• When the program guide consists of more than 6 lines, use [Cursor K / L] to scroll.

• “No description provided” is displayed when the program guide is not provided.

• While the program guide is displayed, the closed caption function is interrupted.

• In external input mode, the following screen is displayed; e.g.) When an external device is connected to VIDEO1 input

jack.

VIDEO 1

• The information display will automatically disappear in a few seconds when the closed caption is on.

INFORMATION

ATCHING TV

TV Screen Display Mode

3-5 types of display modes can be selected when the broadcasting station is sending 4:3 or 16:9 video signal or an external device is connected to the unit.

Press [SCREEN MODE ] repeatedly to switch the TV aspect ratio.

For 4:3 video signal

SIDEBAR

(

analog / external input mode

FULL

WIDE

(digital mode)

: digital mode : analog / external input mode

[SIDEBAR]

Select to display a 4:3 picture at its original size. The black bars appear on the left and right sides of the screen.

[FULL]

Select to display a 4:3 picture to fill the screen.

[MOVIE]

Select to reduce the black bars on top and bottom.

[WIDE]

Digital mode:

Select to display a 4:3 picture to fill the screen and shrink “FULL” picture horizontally.

Analog / external input mode:

Select to display a 4:3 picture to fill the screen and stretch “FULL” picture horizontally.

¾available in the analog / external input mode only

WIDE

MOVIE

For 16:9 video signal

)

FULL

SIDE CUT

ZOOM

: digital mode : analo

/ external input mode

[FULL]

Select to display a 16:9 picture to fill the screen.

[SIDE CUT]

Select to display a 16:9 picture to fill the screen and stretch “FULL” picture horizontally. The left and right sides of the picture will be cropped out.

[ZOOM]

Select to enlarge a 16:9 picture without distorting the aspect ratio.

[MOVIE]

Select to reduce the black bars on top and bottom.

[EXPAND]

Select to reduce the black bars on the left and right sides.

¾available in the analog / external input mode only

Note:

• You may not switch the display mode depending on the program.

EXPAND

MOVIE

PTIONAL SETTING

Channel Add/Delete

The channel add/delete function lets you add the channel that was not added by the auto channel scan due to the reception status at the initial setting. You can also delete the unnecessary channels.

Press [SETUP] to display the main menu.

Use [Cursor K / L] to select “CHANNEL SETUP”, then

press [ENTER]. e.g.) digital TV mode

- TV SETUP -

Use [Cursor K / L] to select “ADD/DELETE(DTV)” or

“ADD/DELETE”, then press [ENTER].

e.g.) digital TV mode

PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE [ENGLISH] CAPTION [OFF] BACK LIGHT [BRIGHT] COLOR TEMP. [NORMAL] DTVCC

- CHANNEL SETUP -

ADD/DELETE(DTV) AUTO PRESET CH(DTV) AUTO PRESET CH(TV/DTV) AUTO PRESET CH(CATV) ! CATV takes approx. 50min.

Press [SETUP] to exit.

Note:

• ”ADD/DELETE(DTV)” or “ADD/DELETE” menu will disappear automatically in a few seconds.

• In the digital mode (DTV), you can add or delete channels only for major channel.

• Once you delete a DTV channel, you cannot recover the channel without performing auto channel scan again. (Refer to “Auto Channel Scan” on page 12.)

WATCHING TVINTRODUCTION CONNECTION INITIAL SETTING

OPTIONAL SETTING

TROUBLESHOOTING

Select the channel you want to add or delete.

(Refer to “Channel Selection“ on page 13.)

e.g.) digital TV mode

D25

ADD/DELETE : DTV

Use [Cursor s / B] to select “ADD” or “DELETE”.

• To add or delete another channels, repeat steps 4-5.

• Color of channel number displayed at the right top of the TV screen indicates;

- Blue: The selected channel will be added.

- Red: The selected channel will be deleted.

INFORMATION

+ 39 hidden pages
