KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
A heavy duty industrial resilient seated butterfly valve
GENERAL APPLICATION
Water, air, dry bulk conveying etc. These valves
are for any service where a drop-tight shut-off
with maximum flow area is required.
TECHNICAL DATA
Sizes: DN 20 - 900
Pressure: 16 bar DN 20 - 300
10 bar DN 350 - 900
Reinforced seat:
16 bar DN 350 - 600
End of line: 10 bar DN 20 - 300
6 bar DN 350 - 900
Reinforced seat:
10 bar DN 350 - 600
Vacuum service: 0.4 bar
Temperature: -28°C to +160°C
Flange accommodation: PN 6/10/16
ASME 125/150
JIS 10K
JIS 16K
BS Table E
AS4087 PN 16
AS2129 Table E
FEATURES
• Wafer and lugged body design with
face-to-face dimension, according to
EN 558 Series 20 and API 609.
• Designed according to EN 593 and API 609.
• The seat is field replaceable and fully isolates
the body and shaft from the flow.
• Primary shaft sealing exceeds the pressure
rating of the valve and prevents leakage
through shaft area to atmosphere.
• A secondary shaft sealing provides back-up
safety.
• A molded-in O-ring in the seat for flange
sealing eliminates the need for gaskets.
• Shaft seals prevent moisture penetrating into
the shaft area.
• The two piece shaft allows for a thin disc
and provides minimal obstruction to flow
(up to DN 300).
• Rounded polished disc edge gives full
concentric sealing, lower torques, longer seat
life and drop-tight shut-off.
• Body locating holes allow ease of installation
and centering between the flanges.
• Extended body neck allows for pipe insulation.
• Actuator flange according to ISO 5211.
• Top and bottom shaft bearings for optimized
support and minimum friction and decreased
torque.
• Top bushing absorbs actuator side thrust
loads.
• All valves comply to Pressure Equipment
Directive (2014/68/EU) Module B + D,
CE Marking.
• Available approvals: NSF/ANSI 61, ACS,
KIWA, WRAS, DVGW-G, ABS, CU-TR.
• Sizes DN 20 up to DN 40 might deviate from
the above mentioned features. Please contact
factory.
Emerson.com/FinalControl VCTDS-06268-EN 21/03
© 2021 Emerson. All Rights Reserved.
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
SERIES GRW/GRL
DN 50-300
(GRW SHOWN)
2
3
10
10
11
8
6
9
4
7
1
PARTS LIST
Item Qty Description
1 1 Body
2 1 Seat
3 1 Disc
4 1 Upper shaft
5 1 Lower shaft
6 1 Upper bushing
7 1 Packing
8 1 Body circlip
9 1 Shaft circlip
10 2 Upper and lower bearing
11 1 Plug
5
DN 350-900
(GRL SHOWN)
11
10
7
9
8
5
6
4
12
PARTS LIST
Item Qty Description
1 1 Body
2 1 Seat
3 1 Disc
4 1 Shaft
5 1 Bushing
6 1 Shaft circlip
7 1 Body circlip
8 1 Body O-ring
9 1 Shaft O-ring
10 1 Disc screw
11 1 Disc screw O-ring
12 4 Upper and lower bearing
13 1 Plug
14 1 Plug O-ring
15 1 Plug circlip
12
1
12
12
14
3
2
13
15
2
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
MATERIAL SPECIFICATION (DN 20-300)
Part name Material Designation EN/DIN mat.no Remark
DN 20-40
Body Ductile iron GJS-400-15 EN JS-1030
Disc Stainless steel GX5CrNiMo19-11-2 EN 1.4408 Comparable with CF8M
Shaft Stainless steel X17CrNi16-2 EN 1.4057 Similar to ASTM A276/Gr. 431
Seat EPDM
NBR
EPDM-A
EPDM-WA3
DN 50-300
Body Ductile iron GJS-400-15 EN JS-1030 Dual certified to ASTM A536-65-45-12
Ductile iron GJS-400-18LT EN 5.3103 Dual certified to ASTM A395-60-40-18
Carbon steel GP240GH EN 1.0619
Stainless steel GX5CrNiMo19-11-2 EN 1.4408
Disc Super duplex GX2CrNiMoN26-7-4 EN 1.4469
316 stainless steel GX5CrNiMo19-11-2 EN 1.4408 Comparable with CF8M
304 stainless steel GX5CrNiMo19-10 EN 1.4308 Comparable with CF8
Aluminium bronze CuAl10Fe2-C EN CC331G
Nickel aluminium bronze CuAl10Fe5Ni5 EN CC333G
Ductile iron NYL GJS-400-15 EN JS-1030 NYL = Nylon coating, max. temp. 60°C
Ductile iron CTD GJS-400-15 EN JS-1030 CTD = Nickel plating
Shaft 316 stainless steel X5CrNiMo17-12-2 EN 1.4401
431 stainless steel X17CrNi16-2 EN 1.4057
Super duplex GX2CrNiMoN25-7-4 EN 1.4410
®
Monel
K500 DIN 17752 EN 2.4375
Seat EPDM Food grade, NSF/ANSI 61, ACS
EPDM E5 KIWA, WRAS, ACS
NBR Food grade
NBR N7 DVGW-G
HNBR
White NBR
FKM
Neoprene
Bushing Polyester
Packing NBR
Bearing PTFE/steel
Circlip Stainless steel
Plug Carbon steel
NOTES
Valves with super duplex disc will have super duplex disc screw. All other discs will have a duplex disc screw.
®
Monel
is a registered trademark of Special Metals Corporation.
3
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
MATERIAL SPECIFICATION
Part name Material Designation EN/DIN mat.no Remark
DN 350-900
Body Ductile iron GJS-400-15 EN JS-1030 Dual certified to ASTM A536-65-45-12
Disc Super duplex GX2CrNiMoN26-7-4 EN 1.4469
Shaft 431 stainless steel X17CrNi16-2 EN 1.4057 Similar to ASTM A276/Gr. 431
Seat EPDM Food grade, NSF/ANSI 61, ACS
Disc screw Super duplex GX2CrNiMoN25-7-4 EN 1.4410
Disc screw O-ring EPDM
Plug Carbon steel
Plug O-ring NBR
Plug circlip Stainless steel
Bushing Polyester
Shaft/Body O-ring NBR
Bearing PTFE/steel
Shaft/Body circlip Stainless steel
* Carbon steel and stainless steel body material options are available up to and including DN 600
Ductile iron GJS-400-18LT EN 5.3103 Dual certified to ASTM A395-60-40-18
Carbon steel* GP240GH EN 1.0619
Stainless steel* GX5CrNiMo19-11-2 EN 1.4408
Super duplex GX2CrNiMoN26-7-4 EN 1.4469
Duplex GX2CrNiMoN22-5-3 EN 1.4470
Duplex GX2CrNiMoN22-5-3 EN 1.4470
316 stainless steel GX5CrNiMo19-11-2 EN 1.4408 Comparable with CF8M
304 stainless steel GX5CrNiMo19-10 EN 1.4308 Comparable with CF8
Aluminium bronze CuAl10Fe2-C EN CC331G
Nickel aluminium bronze CuAl10Fe5Ni5 EN CC333G Comparable with BS 1400 AB2
Ductile iron NYL GJS-400-15 EN JS-1030 NYL = Nylon coating, max. temp. 60°C
Ductile iron CTD GJS-400-15 EN JS-1030 CTD = Epoxy coated, max. temp. 120°C
Duplex X2CrNiMoN22-5-3 EN 1.4462
Super duplex X2CrNiMoN25-7-4 EN 1.4410
®
K500 DIN 17752 EN 2.4375
Monel
EPDM E5 KIWA, WRAS, ACS
NBR Food grade
NBR N7 DVGW-G
HNBR
FKM
Duplex X2CrNiMoN22-5-3 EN 1.4462
NBR
FKM
MATERIAL SPECIFICATION - REINFORCED SEAT
Part name Material Designation EN/DIN mat.no Remark
DN 350-600
Body Ductile iron GJS-400-15 EN JS-1030 Dual certified to ASTM A536-65-45-12
Disc Stainless steel GX5CrNiMo19-11-2 EN 1.4408 Comparable with CF8M
Shaft 431 Stainless steel X17CrNi16-2 EN 1.4057 Similar to ASTM A276/Gr. 431
Seat EPDM E6
Disc screw Duplex X2CrNiMoN22-5-3 EN 1.4462
Disc screw O-ring NBR
Plug Carbon steel
Plug O-ring NBR
Plug circlip Stainless steel
Brushing Polyester
Shaft/body O-ring NBR
Bearing PTFE/steel
Shaft/body circlip Stainless steel
NOTES
Valves with super duplex disc will have super duplex disc screw. All other discs will have a duplex disc screw.
®
is a registered trademark of Special Metals Corporation.
Monel
Ductile iron GJS-400-18LT EN 5.3103 Dual certified to ASTM A395-60-40-18
Carbon steel GP240GH EN 1.0619
Stainless steel GX5CrNiMo19-11-2 EN 1.4408
Super duplex GX2CrNiMoN26-7-4 EN 1.4469
Duplex GX2CrNiMoN22-5-3 EN 1.4470
Nickel aluminium bronze CuA10Fe5Ni5 EN CC333G Comparable with BS 1400 AB2
Ductile iron CTD GJS-400-15 EN JS-1030 CTD = Epoxy coated, max. temp. 120°C
Super duplex X2CrNiMoN25-7-4 EN 1.4410
NBR N8
4
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
SERIES GRW (WAFER)
DN 50-300 DN 350-900
H
45˚
øN
α
øN
øE
A
F
øG
øE
L
A
F
øG
L
C
øB
C
øB
Q øA øM øYY
J
A
D
A
J
D
Q øA øM øYY
VALVE DIMENSIONS (mm)
(1)
Size
(DN)
(2)
YY G H
20 30 61 115 25 65 25 49 4 38 35 18 50 12 8 - 50 4 45° 6.6 F05 1.0
25 30 61 115 25 65 25 49 4 38 35 18 50 12 8 - 50 4 45° 6.6 F05 1.0
32 40 78 130 33 65 25 61 4 49 35 25 64 12 8 - 50 4 45° 6.6 F05 1.5
40 40 78 130 33 65 25 61 4 49 35 25 64 12 8 - 50 4 45° 6.6 F05 1.5
50 50 91 135 43 65 25 60 4 66 35 28 80 12 8 - 50 4 45° 7.0 F05 1.8
65 62 105 150 46 100 30 76 4 78 55 43 93 16 11 - 70 4 45° 9.0 F07 2.7
80 77 123 160 46 100 30 82 4 97 55 65 112 16 11 - 70 4 45° 9.0 F07 3.2
100 99 154 180 52 100 30 104 4 129 55 87 144 16 11 - 70 4 45° 9.0 F07 4.5
125 124 187 195 56 100 30 120 4 160 55 113 175 20 14 - 70 4 45° 9.0 F07 6.1
150 150 208 210 56 90 30 131 4 181 55 142 196 20 14 - 70 4 45° 9.0 F07 6.8
200 195 265 240 60 90 30 162 4 233 55 188 248 20 14 - 70 4 45° 9.0 F07 11.3
250 245 320 275 68 150 30 198 4 290 85 237 305 25 18 - 125 4 45° 13.5 F12 19.1
300 291 372 310 78 150 50 230 4 340 85 283 355 30 22 - 125 4 45° 13.5 F12 26.8
350 325 416 325 78 150 70 260 4 378 85 318 398 35 - 10 x 8 125 4 45° 13.5 F12 40.0
400 380 474 360 102 200 70 298 6 435 130 368 455 40 - 12 x 8 165 4 45° 22.0 F16 63.0
450 434 534 395 114 200 70 334 6 495 130 421 515 40 - 12 x 8 165 4 45° 22.0 F16 86.0
500 486 589 430 127 200 70 385 6 549 130 471 569 50 - 14 x 9 165 4 45° 22.0 F16 106.0
600 585 691 500 154 200 70 456 6 650 130 568 670 60 - 18 x 11 165 4 45° 22.0 F16 158.0
700 685 800 570 165 200 80 518 6 755 130 668 775 70 - 20 x 12 165 4 45° 22.0 F16 231.0
750 735 862 605 190 200 90 551 6 816 130 713 835 70 - 20 x 12 165 4 45° 22.0 F16 290.0
800 785 907 640 190 300 90 583 6 860 200 765 880 70 - 20 x 12 254 8 22.5° 17.5 F25 326.0
900 885 1007 715 203 300 100 659 6 960 200 864 980 80 - 22 x 14 254 8 22.5° 17.5 F25 419.0
Shaft Top plate drilling
(3)
Key Bolt circle
No.
holes α
Holes
dia.
Adapt.
code
Weight
(kg)A B C D E F J L M N Q
(4)
NOTES
1. Sizes 20-40 differ from above images.
2. ‘Q’ dimension is the minimum allowable pipe or flange inside diameter at
the centered body face to protect the disc sealing edge against damage
when opening the valve.
3. ‘H’ dimension refers to flat on shaft.
4. Weight may vary depending on trim materials used.
5. øYY dimension is to the outside of the seat
6. øM dimension is to the O-ring seal
5
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
SERIES GRL (LUG)
DN 50-300
45˚
H
øN
DN 350-900
α
øN
øE
A
øG
F
L
øE
A
øG
F
L
C
C
Q øA øM øYY øB
J
A
D
A
J
D
Q øA øM øYY øB
VALVE DIMENSIONS (mm)
(1)
Size
(DN)
(2)
YY G H
20 30 61 115 25 65 25 43 4 38 35 18 50 12 8 - 50 4 45° 6.6 F05 1.4
25 30 61 115 25 65 25 43 4 38 35 18 50 12 8 - 50 4 45° 6.6 F05 1.4
32 40 78 130 33 65 25 55 4 58 35 25 66 12 8 - 50 4 45° 6.6 F05 2.1
40 40 78 130 33 65 25 55 4 58 35 25 66 12 8 - 50 4 45° 6.6 F05 2.1
50 50 92 135 43 65 25 60 4 66 35 28 80 12 8 - 50 4 45° 7.0 F05 2.7
65 62 105 150 46 100 30 76 4 78 55 43 93 16 11 - 70 4 45° 9.0 F07 4.0
80 77 126 160 46 100 30 82 4 97 55 65 112 16 11 - 70 4 45° 9.0 F07 4.3
100 99 156 180 52 100 30 104 4 129 55 87 144 16 11 - 70 4 45° 9.0 F07 7.0
125 124 190 195 56 100 30 120 4 160 55 113 175 20 14 - 70 4 45° 9.0 F07 10.0
150 150 214 210 56 100 30 131 4 181 55 142 196 20 14 - 70 4 45° 9.0 F07 11.0
200 195 268 240 60 90 30 162 4 233 55 188 248 20 14 - 70 4 45° 9.0 F07 17.0
250 245 321 275 68 150 30 198 4 290 85 237 305 25 18 - 125 4 45° 13.5 F12 29.5
300 291 375 310 78 150 50 230 4 340 85 283 355 30 22 - 125 4 45° 13.5 F12 41.0
350 325 416 325 78 150 70 260 4 378 85 318 398 35 - 10 x 8 125 4 45° 13.5 F12 52.0
400 380 474 360 102 200 70 298 6 435 130 368 455 40 - 12 x 8 165 4 45° 22.0 F16 88.0
450 434 534 395 114 200 70 334 6 495 130 421 515 40 - 12 x 8 165 4 45° 22.0 F16 107.0
500 486 589 430 127 200 70 385 6 549 130 471 569 50 - 14 x 9 165 4 45° 22.0 F16 161.0
600 585 691 500 154 200 70 456 6 650 130 568 670 60 - 18 x 11 165 4 45° 22.0 F16 235.0
700 685 800 570 165 200 80 518 6 755 130 668 775 70 - 20 x 12 165 4 45° 22.0 F16 315.0
750 735 862 605 190 200 90 551 6 816 130 713 835 70 - 20 x 12 165 4 45° 22.0 F16 378.0
800 785 907 640 190 300 90 583 6 860 200 765 880 70 - 20 x 12 254 8 22.5° 17.5 F25 438.0
(5)
900
885 1007 715 203 300 100 659 6 960 200 864 980 80 - 22 x 14 254 8 22.5° 17.5 F25 559.0
Shaft Top plate drilling
(3)
Key Bolt circle
No.
holes α
Holes
dia.
Adapt.
code
Weight
(kg)A B C D E F J L M N Q
(4)
NOTES
1. Sizes 20-40 differ from above images.
2. ‘Q’ dimension is the minimum allowable pipe or flange inside diameter at
the centered body face to protect the disc sealing edge against damage
when opening the valve.
3. ‘H’ dimension refers to flat on shaft.
4. Weight may vary depending on trim materials used.
5. Valve size DN 900 is tapped flange design and has no separate lugs.
6. ØYY dimension is to the outside of the seat
7. ØM dimension is to the O-ring seal
6
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
SERIES GRW AND GRL
U
V
Note: all holes in lugged version
are through threaded, except the
holes closest to top and bottom
shaft.
TORQUE APPLICATION FACTOR CATEGORIES
Application I
Clean liquid lubricating media (water, clean
oils, lube oil, mineral oil, etc.); and with no
deposit or chemical attack, valve operated at
least once a week.
Temperature range from 0°C to maximum
temperature rating of the elastomer seat.
Application II
Other liquid media and lubricating gases
(aqueous liquids, such as food and beverage,
water, etc.); and with minor deposit or chemical
attack, valve operated at least once a month.
Temperature range from 0°C to maximum
temperature rating of the elastomer seat.
DIMENSIONS OF TAPPED FLANGE LOCATING HOLES (mm)
Size Series GRW Series GRL
(DN) U V U V
700 45.5 5.5 45.5 5.5
750 65.0 25.0 45.5 5.5
800 60.0 20.0 45.5 5.5
900 54.5 6.5 54.5 6.5
Application III
a. Dry non-abrasive media or gases
(non-abrasive powders and dry gas); or
b. Fluids with moderate deposit or chemical
c. Valves not frequently operated (once a year).
All above with temperature range from
-10°C to maximum temperature rating of the
elastomer seat.
attack; or
c. Valves operated less than once a month.
Temperature range from 0°C to maximum
temperature rating of the elastomer seat.
Application IV
a. Dry abrasive media and degreasing
NOTES
1. For applications with temperatures above or below
the guidelines above, please consult factory.
2. For dry service valves it is suggested to use U/C
discs (reduced diameter) when service conditions
are less than 3.5 bar.
applications (sand, cement, silicone free,
oxygen cleaned); or
b. Liquids with severe deposit; or
VALVE SEATING AND UNSEATING TORQUES (Nm)
Differential
pressure (bar)
I*
3.5 7 7 10 10 13 19 26 37 58 81 148 241 345 467 639 845 1089 1700 2494 2967 3495 4422
7 7 7 10 10 13 20 27 40 63 88 164 271 387 520 719 960 1248 1979 2943 3521 4169 5275
10 7 7 11 11 14 21 30 44 70 99 188 315 451 595 832 1123 1473 2373 3575
14 7 7 11 11 15 23 33 49 80 113 219 374 536 - - - - - - - - 16 8 8 12 12 15 25 36 51 85 120 235 403 578 - - - - - - - - -
3.5 (U/C) - - - - 8 11 16 22 35 49 89 145 207 280 383 507 653 1020 1497 1780 2097 2653
II*
3.5 7 7 10 10 14 21 29 42 66 93 169 274 392 528 718 945 1212 1877 2736 3245 3811 4822
7 7 7 11 11 14 22 31 45 71 100 185 303 434 580 796 1058 1369 2153 3180 3793 4479 5667
10 7 7 11 11 15 23 33 49 78 111 208 347 498 652 906 1217 1590 2542 3804
14 8 8 12 12 16 26 36 54 88 125 240 406 583 - - - - - - - - 16 8 8 12 12 17 27 38 56 93 132 255 436 626 - - - - - - - - -
3.5 (U/C) - - - - 8 13 17 25 40 56 101 164 235 317 431 567 727 1126 1642 1947 2287 2893
III*
3.5 7 7 11 11 15 23 32 48 74 105 190 306 439 588 797 1045 1336 2055 2978 3523 4127 5222
7 7 7 11 11 16 24 34 50 79 112 206 336 481 639 874 1156 1490 2328 3417
10 8 8 12 12 16 26 36 54 86 122 229 380 545 709 981 1312 1707 2710
14 8 8 13 13 17 28 40 59 96 136 261 439 629 - - - - - - - - 16 8 8 13 13 18 29 41 61 101 143 276 468 672 - - -
3.5 (U/C) - - - - 9 14 19 29 44 63 114 184 263 353 478 627 801 1233 1787 2114 2476 3133
IV*
3.5 7 7 12 12 17 26 37 55 86 122 221 355 509 679 915 1195 1521 2322 3341 3940 4601 5822
7 8 8 13 13 18 27 39 58 91 129 237 384 551 728 990 1303 1671 2589 3772
10 8 8 13 13 18 29 41 62 99 140 260 428 615 795 1094 1454 1883 2963
14 8 8 13 13 19 31 45 67 108 154 292 487 700 - - - - - - - - 16 8 8 13 13 20 32 46 69 113 161 307 517 742 - - - - - - - - -
3.5 (U/C) - - - - 10 16 22 33 52 73 133 213 305 408 549 717 913 1393 2005 2364 2761 3493
20 25 32 40 50 65 80 100 125 150 200 250 300 350 400 450 500 600 700 750 800 900
Valve size (DN)
(1)
4302 5120 6479
(1)
4565 5419 6858
(1)
4034
4378
(1,2)
(1)
(1,2)
4065 4788 6059
(2)
4828
5719 7237
4473 5252 6646
(2)
5223
6168 7805
(1)
- - - - - -
(1)
NOTES
* Application I, II, III, IV
3.5 U/C refers to reduced diameter disc option.
1. Use a minimum of Class 8.8 steel bolts to connect actuator to valve.
2. Duplex shaft not suitable for these conditions, use only 431 stainless steel or super duplex.
7
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
VALVE SEATING AND UNSEATING TORQUES (Nm) - REINFORCED SEAT
Differential pressure
(bar)
I*
10 851 1173 1563 2026 3198
14 986 1374 1849 2419 3876
16 1053 1474 1992 2615 4216
II*
10 947 1298 1721 2221 3879
14 1081 1499 2007 2614 4157
16 1149 1599 2150 2810 4496
III*
10 1297 1755 2300 2936 4509
14 1432 1956 2586 3329 5187
16 1499 2057 2729 3525 5526
350 400 450 500 600
Valve size (DN)
TORQUE APPLICATION FACTOR CATEGORIES
Application I
Clean liquid lubricating media (water, clean oils, lube oil, mineral oil, etc.); and with no deposit or
chemical attack, valve operated at least once a week.
Temperature range from 0°C to maximum temperature rating of the elastomer seat.
Application II
Other liquid media and lubricating gases (aqueous liquids, such as food and beverage, water, etc.);
and with minor deposit or chemical attack, valve operated at least once a month.
Temperature range from 0°C to maximum temperature rating of the elastomer seat.
NOTES
As the reinforced seat is intended for high pressure
applications the base torque commences at
1000kPa/10 bar.
Reinforced seat are suitable for:
Severe vacuum application (use 10 bar torque values).
•
• High line velocities up to 12 m/s for liquids.
• Pressure testing during erection and
commissioning.
Application III
a. Dry non-abrasive media or gases (non-abrasive powders and dry gas); or
b. Fluids with moderate deposit or chemical attack; or
c. Valves operated less than once a month.
Temperature range from 0°C to maximum temperature rating of the elastomer seat.
NOTE
1. For applications with temperatures above or below the guidelines above, please consult factory.
8
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
MAXIMUM ALLOWABLE SHAFT TORQUES (Nm)
Valve size (DN)
Shaft material
316SS (SS 1.4401) - - - - 65 160 160 160 320 320 320 545 970 - - - - - - - - 431SS (SS 1.4057) 20 20 90 90 90 230 230 230 460 460 460 935 1660 1470 1824 2448 3308 5346 6300 6300 7560 11424
Duplex (SS 1.4462) - - - - - - - - - - - - - 1103 1368 1836 2481 3341 4725 4725 5670 8568
Super duplex (SS 1.4410) - - - - 85 210 210 210 420 420 420 855 1520 1348 1727 2390 3032 4589 5408 5408 6489 9806
®
Monel
K500 (2.4375 ) - - - - 76 190 190 190 381 381 381 777 1381 1225 1520 2040 2756 3713 5250 5250 6300 9520
FLOWRATE CO-EFFICIENTS - Kv VALUES
Valve size
(DN)
20 - 0.2 0.5 1.3 2.8 4.5 8.3 12.8 19.0
25 - 0.2 0.5 1.3 4.5 10.3 17.7 26.5 31.0
32 - 0.6 2.0 6.0 14.8 23.5 36.0 49.8 54.0
40 - 0.6 2.0 6.0 16.0 28.0 43.0 55.0 56.0
50 0 0.9 4.8 14 30 47 72 99 108
65 0 2.4 11 27 50 78 123 172 217
80 0 6 28 55 91 141 215 304 409
100 0 14 57 109 177 265 407 600 807
125 0 28 85 158 250 389 630 964 1251
150 7 52 130 226 367 578 987 1551 1946
200 22 115 231 405 646 1029 1773 2910 3516
250 34 173 339 641 980 1546 2677 4449 5806
300 49 253 495 935 1430 2255 3905 6710 8910
350 119 304 637 1142 1936 3110 5010 8969 10407
400 155 397 832 1492 2529 4062 6544 11714 13592
450 196 503 1053 1888 3200 5141 8288 14826 17203
500 242 621 1300 2331 3951 6347 10224 18303 21238
600 349 894 1871 3357 5689 9140 14723 26357 30583
700 475 1216 2547 4569 7744 12440 20040 35875 41626
750 545 1396 2924 5245 8890 14281 23005 41183 47785
800 620 1589 3327 5968 10114 16248 26174 46857 54369
900 785 2011 4211 7553 12801 20564 33127 59303 68811
20 25 32 40 50 65 80 100 125 150 200 250 300 350 400 450 500 600 700 750 800 900
Disc opening (degrees)
10° 20° 30° 40° 50° 60° 70° 80° 90°
NOTE
K
= The volume of water in m3/hr that will pass through a valve with a pressure drop of 1 bar at 20°C
v
PRESSURE-TEMPERATURE DIAGRAM
Disc
Seat material*
material** Body material
EPDM all DI GJS-400-15
CS GP240GH
EPDM all SS Gx5CrMo19-11-2
DI GJS-400-18LT
Super Duplex, Duplex
NBR and white NBR all all 50-300 Std / EOL
HNBR all all 50-300 Std / EOL
FKM all all 50-300 Std / EOL
EPDM E5 all all 50-300 Std / EOL
Neoprene all all 50-300 Std / EOL
EPDM all DI GJS-400-15
CS GP240GH
EPDM all SS Gx5CrMo19-11-2
DI GJS-400-18LT
Super Duplex, Duplex
NBR all all 350-900 Std / EOL
HNBR all all 350-900 Std / EOL
FKM all all 350-900 Std / EOL
EPDM E6 all all 350-600 Std / EOL
NBR N8 all all 350-600 Std / EOL
* All seat materials drop tight
** Per material listed in the material specification tables
Minimum temperature size range DN 20-40: -10°C
Size range
(DN)
Valve function
Standard / End of Line
50-300 Std / EOL
50-300 Std / EOL
350-900 Std / EOL
350-600 Std / EOL
Temperature (°C)
-40 -28 -20 -15 0 50 80 100 120 130 150 160
16 bar / 10 bar
16 bar / 10 bar
16 bar / 10 bar
16 bar / 10 bar
16 bar / 10 bar 10 bar / 6 bar
16 bar / 10 bar
16 bar / 10 bar
10 bar / 6 bar
10 bar / 6 bar
10 bar / 6 bar
10 bar / 6 bar
10 bar / 6 bar 6 bar / 4 bar
16 bar / 10 bar
16 bar / 10 bar
9
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
SELECTION GUIDE
Example: GRL 0100 - D0 A1 S2 E0 A1 I - 00 000 00
Series
GR
Body style
GRL Lug
GRW Wafer
Size
0020 DN 20 0250 DN 250
0025 DN 25 0300 DN 300
0032 DN 38 0350 DN 350
0040 DN 40 0400 DN 400
0050 DN 50 0450 DN 450
0065 DN 65 0500 DN 500
0080 DN 80 0600 DN 600
0100 DN 100 0700 DN 700
0125 DN 125 0750 DN 750
0150 DN 150 0800 DN 800
0200 DN 200 0900 DN 900
Body
D0 Ductile iron GJS 400-15
D2 Ductile iron GJS 400-18-LT
C0 Carbon steel
S0 316 stainless steel
Disc
D0 Ductile iron - ENP S1 304 stainless steel
D1 Ductile iron - epoxy A1 Aluminum bronze
D2 Ductile iron - nylon N0 Nickel aluminum bronze
D3 Ductile iron - FBE
S0 316 stainless steel V0 Super duplex
Shaft
S0 316 stainless steel
S2 431 stainless steel M1 Monel
U0 Duplex
Seat
E0 EPDM FG (NSF ANSI/61 and ACS) N7 NBR (DVGW-G)
E5 EPDM (WRAS, KWIA, ACS) N8 NBR reinforced (DN 350-600, NPS 14-24)
E6 EPDM reinforced (DN 350-600, NPS 14-24) N9 White NBR
H1 HNBR F1 FKM
N0 NBR FG
Flange drilling
Single drilled lug and wafer Multi drilled wafer
A1 ASME 125/150 M1 PN 10/16, ASME 125/150, BS EJIS10
J1 JIS B2210 - 10K M2 PN10/16, ASME 125/150, BS E
P1 PN 6 MB PN 6/10/16, ASME 125/150
P2 PN 10 MC PN 10/16
P3 PN 16
PA PN 6/10/16
Actuator mounting
I ISO 5211 mount
Actuation
00 None G1 Gear - blue
H1 10 pos handle - blue G5 Chainwheel - blue
Special
000 None C22 NSF/ANSI std 61
P04 Reduced disc for 3.5 bar 009 Silicone free
Coating
00 Standard blue 03 C5M blue ctd body
02 C3 blue ctd body 04 FBE blue ctd body
[4]
[4]
(3)
ctd U0 Duplex
(1)
V0 Super duplex
®
K500
(2)
NOTES
1. The standard shaft material is 431 stainless steel. 316 SS is only available as an option on DN 50-300.
2. All disc screws will be of duplex except for super duplex disc which will have a super duplex disc screw.
3. FBE = Fusion bond epoxy
4. Carbon Steel and Stainless Steel body material options are available DN 50 - 600
Other options are available on request.
Please consult your local sales representative.
®
is a registered trademark of the
Monel
Special Metals Corporation.
10
KEYSTONE SERIES GR RESILIENT SEATED BUTTERFLY VALVES
GRW/GRL (ISO)
FLANGE ACCOMMODATION CHART FOR WAFER VALVES
Sizes (DN)
Ord.
Drillings
PN 6 NA - STD MB NA - STD MB Mod. P1 Mod. P1 Mod. P1
PN 10 STD MC STD MB STD MC STD MB STD M1 STD M 2 A-o P2
PN 16 STD MC STD MB STD MC STD MB STD M1 STD M 2 A-o P3
ASME 125/150 NA - STD MB NA - STD MB STD M1 STD M 2 A-o A1
BS Table E NA - NA - NA - STD MB STD M1 STD M 2 A-o B1
JIS 10K NA - NA - NA - STD MB STD M1 NA - A-o J1
20
code 25
FLANGE ACCOMMODATION CHART FOR LUG VALVES
Ord.
Drillings
PN 6 NA - NA - NA - STD PA A-o P1 A-o P1 A-o P1
PN 10 STD PB STD PB STD PB STD PA A-o P2 A-o P2 A-o P2
PN 16 STD PB STD PB STD PB STD PA A-o P3 A-o P3 A-o P3
ASME 125/150 NA - STD A1 NA - STD A1 A-o A1 A-o A1 A-o A1
BS Table E NA - NA - NA - NA - A-o B1 A-o B1 A-o B1
JIS 10K NA - NA - NA - NA - A-o J1 NA - A-o J1
20
code 25
Ord.
code 32
Ord.
code 32
Ord.
code 40
Ord.
code 40
Ord.
code 50-500
Sizes (DN)
Ord.
code 50-500
Ord.
code 600
Ord.
code 600
Ord.
code 700-900
Ord.
code 700-900
Ord.
code
Ord.
code
Mod. = Modifications required - Is possible but will require some modifications and will be a special
STD = Standard valve locating plate is multi drilled and covers this flange standard
A-o = As ordered - All valves have to be ordered as this drilling using the code above
NA = Not possible on this valve size
11
VCTDS-06268-EN © 2021 Emerson Electric Co. All rights reserved 03/21. Keystone is a mark owned by one of the companies in the Emerson Automation Solutions
business unit of Emerson Electric Co. The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective
owners.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be
construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are governed by
our terms and conditions, which are available upon request. We reserve the right to modify or improve the designs or specifications of such products at any time without
notice.
Emerson Electric Co. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any
Emerson Electric Co. product remains solely with the purchaser.
Emerson.com/FinalControl
12
Loading...
