Emerson CK5051 User Manual

SPACE SAVING
AM / FM CLOCK RADIO
WITH DUAL ALARMS

OWNER'S MANUAL

CK5051

Visit our web site at www.emersonradio.com

CK5051_ib_Rev.p65 17/12/2001, 10:5114

WARNING

!

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PRESENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNIN G

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrow­head symbol, within an equi­lateral triangle is intented to
alert the user to the presence
of uninsulated ‘dangerous voltage’
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.

CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER
(OR BAC K) , NO USE R
SERVICEABLE PARTS INSIDE
REFER SERV ICING TO
Q U A L I F I ED S E R V I C E
PERSONNEL.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10. Protect the power c ord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments / accessories specified by the manufacturer.

12. Unplug this apparatus during lightning storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, suc h as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

14. This appliance shall not be exposed to dripping or splashing water and that no object
filled with liquids such as vases shall be placed on the apparatus.

The exclamation point within
an equilateral triangle is in­tended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompany­ing the appliance.

1

CK5051_ib_Rev.p65 17/12/2001, 10:511

Thank you for purchasing this Emerson Space Saving AM/FM Clock Radio
with Dual Alarms.

The bright green LED display is designed to be highly visible and easily readable
from anywhere in your room. At the same time we have managed to minimize the
cabinet size so that the radio won’t take up too much space on your night table.

The dual alarms can be set and used independently. And since there are two separate
Radio/Buzzer selector switches, you can set one alarm to wake you to buzzer and
the other to wake you to radio if your wish. All of the controls are easy to see and
easy to use. The radio has a slide rule dial for easy tuning. The cloc k has fast
forward and slow reverse setting controls for quick and easy adjustments.

The Sure-Alarm battery back up system will remember the time and alarm settings
of cours e, but it can do more than that. As long as there is a fresh 9-volt battery
installed, the Sure-Alarm system will operate the radio or buzzer alarm to wake you
up even if the power is off at your normal wake up time.

We have taken great care to make sure that your radio was in perfect worki ng order
when it left our factory. It has been designed to give you many years of enjoyment
and trouble free operation. Should you experience any problems with the operation
or performance of this product please refer to the service and warranty information
at the end of this instruction manual.

Once again, from all of us at Emerson Radio Corp., thanks for your purchase.

For future reference, record the serial number in the space provided.
Model: CK5051
Serial Number:

2

CK5051_ib_Rev.p65 17/12/2001, 10:512

IMPORTANT NOTES

Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or close heat radiating appliances such as

electric heaters.

• Dusty places.

• Places subject to constant vibration.

• Humid or moist places.

FCC INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference

that may cause undesired operation.

CK5051_ib_Rev.p65 17/12/2001, 10:513

3

PREPARATION FOR USE

UNPACKING AND SET UP

• Remove the radio from the carton and remove all packing material from the

radio. We suggest that you save the packing material, if possible, in the unlikely
event that your radio ever needs to be returned for service. The original carton
and packing material is the only safe way to pack your radio to protect it from
damage in transit.

• Remove any descriptive labels or stickers on the front or top of the cabinet. Do

not remove any labels or stickers from the back or bottom of the cabinet.

• Note the serial number on the bottom of your radio and write this number in the

space provided on Page 2 of this manual.

• Place your radio on a level surface such as a table, desk or shelf, convenient to

an AC outlet, out of direct sunlight, and away from sources of excess heat, dirt,
dust, moisture, humidity, or vibration.

• Unwind the AC power cord and extend it to its full length. The FM antenna is

built in to this cord. It must be fully extended to provide the best FM reception.

SURE-ALARM BATTERY BACK UP SYSTEM

The Sure-Alarm battery back up system in this radio will maintain the time and
alarm settings in the event of a temporary power interruption. When the power is
restored the time and alarm settings will be correct. If the power is off at your wake
up time, the Sure-Alarm system will use the battery power to turn on the radio or
buzzer alarm as usual, as long as the back up battery is installed and has sufficient
power remaining.

The Sure-Alarm battery back up system requires one 9-volt battery, not included.
We recommend that you install an alkaline battery for longest life and best
performance.

4

CK5051_ib_Rev.p65 17/12/2001, 10:514

To install the battery:

T

• Open the battery compartment cover on the bottom

of the radio by pressing the tab in the direction of
the arrow.

Press

• Connect the 9-volt battery to the battery terminal. It

can only be connected one way.

• Push the battery into the battery compartment and

replace the cover.

9

V

O

L

POWER FAILURE INDICATOR

If no battery is installed in the radio, or if the battery in the compartment is weak or
dead, the time and alarm settings will be lost if the power is interrupted. When the
power is restored the clock display will begin flashing. This is your indication that
the time display is incorrect and needs to be reset.

Important: After you reset the time, be sure to reset your alarm settings as well.

POWER SOURCE

This radio is designed to operate on normal 120V 60Hz AC power only. Do not
attempt to operate the radio on any other power source. You could cause damage
to the radio that is not covered by your warranty.

This radio should be connected to an AC outlet that is always ‘live’. Do not connect
it to an outlet that is controlled by a wall switch. When the power to the radio is
interrupted, the Sure Alarm battery back up system takes over to maintain the ti me
and alarm s ettings. To maximize the life of the back up battery, keep the radio
connected to a ‘live’ AC outlet at all times.

This radio uses a polarized AC plug which has
one blade wider than the other. This plug will
only fit into a polarized AC outlet. This is a safety
feature. If the plug will not fit, you may have an
older non-polarized AC outlet. Do not defeat the
safety feature by trying to file the wider blade,
or replacing the plug. Contact an electrician to
replace your outdated outlet.

5

CK5051_ib_Rev.p65 17/12/2001, 10:515

LOCATION OF CONTROLS AND INDICATORS

121202345

678

1516171213

141918

22

9

10

11

Top Panel

1. ALARM 1 setting button.
(ALARM RESET)

2. CLOCK setting button.

3. F. FWD (Fast Forward) button.

4. SLOW REV. (Slow Reverse) button.

5. ALARM 2 setting button.

6. RADIO ON button.

7. SLEEP button (Sleep to music timer).

8. SNOOZE /RADIO OFF(Sleep ‘Off’) button.

Left Side

9. ALARM 1 selector switch.
(RADIO/BUZZER/OFF)

10. ALARM 2 selector switch.
(RADIO/BUZZER/OFF)

11. Display DIMMER switch (HIGH/LOW).

6

Right Side

12. VOLUME control.

13. BAND switch (AM/FM).

14. TUNING control.

Front Panel

15. ALARM 1 ‘On’ indicator.

16. AM indicator.

17. Time display.

18. ALARM 2 ‘On’ indicator.

19. Tuning Dial.

Back/Bottom Panel

20. AC power cord.

21. Speaker.

22. Back up battery
compartment.

CK5051_ib_Rev.p65 17/12/2001, 10:516

OPERATING INSTRUCTIONS

SETTING THE CLOCK

When you connect the radio to your AC outlet for the first time the clock display will
begin flashing “12:00” (AM). The flashing will stop when you set the time.

1. Depress the Clock button and the Fast Forward button and advance the
display to a few minutes ahead of the correct time.

AM indicator

ALARM 1 indicator

ALARM 2 indicator

2. Release the Fast Forward button and depress Slow Rev erse button
until the correct time appears, then release all buttons.

Note: Be sure to observe the AM indicator to make sure that the time is set correctl y

for AM or PM. If the AM indicator is ‘on’, the time displayed is “AM”. If the AM
indicator is ‘off’, the time displayed is “PM”.

SETTING THE WAKE UP TIMES

This clock radio has two separate alarms that can be set and used independently.
You may use the alarms to wake two people at different times, or you may use one
alarm for weekdays and the other for weekend wake up times. The procedure for
adjusting the wake up time is the same for both Alarm 1 and Alarm 2.

1. Depress and hold either the Alarm 1 or Alarm 2 setting button. The display will
change from the correct time to the Alarm 1 or Alarm 2 wake up time.

2. While holding the Alarm 1 or Alarm 2 setting button, depress the Fast Forward

button to advance the display to a few minutes ahead of the desired wake up

time.

3. Release the Fast Forward button and depress the Slow Reverse button
until the desired wake up time appears, then release all buttons.

Note: Be sure that you have set the wake up time correctly by observing the AM

indic ator. If the AM indicator is ‘on’ the wake up time is “AM”. If the AM
indicator is ‘off’, the wake up time is “PM”.

7

CK5051_ib_Rev.p65 17/12/2001, 10:517

CHECKING THE WAKE UP TIMES

Whenever you want to check the wake up times, simply press either the Alarm 1 or
Alarm 2 setting buttons. The display will change from correct time to wake up time.
Release the Alarm 1 or Alarm 2 setting buttons to return to correct time.

LISTENING TO THE RADIO

1. Set the Band selector to the desired band, AM or FM.

2. Set the Volume control to a low setting.

3. Press the Radio On button to turn the radio ‘On’.

4. Select your desired station with the Tuning control.

5. Adjust the Volume control to the desired setting.

6. When you are finished listening, press the Snooze/Radio Off button to turn the
radio ‘Off’.

ANTENNA INFORMATION

AM – The AM bar antenna is inside the cabinet. If AM reception is weak, change

the position of cabinet until the internal antenna picks up the strongest signal.

FM – The FM antenna is built in to the AC power cord. If FM reception is weak try

varying the position and direction of the power cord until you find the strongest
signal.

WAKE TO RADIO

1. Turn the radio ‘On’ and select the band, station, and volume level that you wish
to hear when the alarm comes on, then turn the radio ‘Off’ again.

2. Reconfirm the wake up time settings for the alarm you are using, Alarm 1,
Alarm 2, or both alarms.

3. Set the Alarm selector switch for one or both alarms to the ‘Radio’ position. The
appropriate Alarm 1 and/or Alarm 2 indicators will light up to confirm that the
alarms are set.

4. At the selected wake up time the radio will turn ‘On’. It will play for one hour and
then shut off automatically.

8

CK5051_ib_Rev.p65 17/12/2001, 10:518

5. To stop the radio sooner, press the Alarm 1 (Alarm Reset) button. The radio wi ll
stop but the alarm remains set and will turn the radio on again at the same time
on the following day.

6. If you do not want the alarm to turn the radio on the following day, set the
appropriate Alarm selector to the ‘Off’ position.

WAKE TO BUZZER

1. Reconfirm the wake up time settings for the alarm you are using, Alarm 1,
Alarm 2, or both alarms.

2. Set the Alarm selector switch for one or both alarms to the Buzzer position. The
appropriate Alarm 1 and/or Alarm 2 indicators will light up to confirm that the
alarms are set.

3. At the selected wake up time the buzzer will sound. It will continue for one hour
and then shut off automatically.

4. To stop the buzzer sooner, press the Alarm 1 (Alarm Reset) button. The buzzer
will stop but the alarm remains set and will turn the buzzer on again at the same
time on the following day.

5. If you do not want the alarm to turn the buzzer on the following day, set the
appropriate Alarm selector to the ‘Off’ position.

RADIO AND BUZZER OPERATION

You may also set one alarm for wake to radio and the other for wake to buzzer. Just
set the Alarm 1 and Alarm 2 selector switches to the desired positions.

SNOOZE ALARM

After the radio or buzzer alarm sounds in the morning you may press the Snooze
Bar for a few more minutes sleep. The alarm will stop for approximately 9 minutes
and then turn on again. You may repeat the Snooze operation up to seven times if
desired, but after the seventh time the alarm will not turn on again.

Note: Whenever the Snooze Bar is depressed the display changes from normal

time to a “minutes and s econds” display. The minute will be the last digit
that appeared in the time display, and the seconds will continue to advance.
When the Snooze bar is released the display returns to the correct time.

9

CK5051_ib_Rev.p65 17/12/2001, 10:519

SLEEP TO MUSIC TIMER

You can program the sleep timer to play the radio for up to 59 minutes and then shut
off automatically.

1. Press the Sleep button. The display will briefly show “0:59” and the radio will
begin to play. After 59 minutes the radio will shut off automatically.

2. To adjust the amount of time that the radio will play before shutting off, hold the
Sleep button. The radio will begin counting down from “0:59”. When the desired
amount of sleep time appears on the display, release the Sleep button.

3. To cancel the sleep timer before it counts down to “00” and shut the radio ‘Off’
immediately, press the Snooze bar.

IMPORTANT:

Remember that the station and volume settings you choose for the Sleep To Music
operation are the same settings you will hear if you set the alarm for wake to radio
the following morning.

DIMMER CONTROL

The Dimmer control was set to the ‘High’ position at our factory. If you find the clock
display is too bright in a darkened room, set the Dimmer control to the ‘Low’ position.

CK5051_ib_Rev.p65 17/12/2001, 10:5110

10

CARE AND MAINTENANCE

There are no user serviceable parts inside this radio. Please refer all service probl ems
to a qualified service facility. See the warranty page of this manual for further
details.

If the cabinet becomes dusty, wipe the exterior with a soft dust cloth only. Never
use dusting sprays or polishes on the cabinet.

If the cabinet becomes dirty or smudged with fingerprints it may be wiped with a
soft cloth that has been slightly dampened with a mild soap and water solution.
Always disconnect the power cord from the AC outlet before cleaning, and never
allow any liquid to get inside the cabinet.

Note: If there is no battery in the back-up battery compartment, the Time and Alarm

settings will be lost when the power cord is disconnected for cleaning. Reset
the clock and wake up times after reconnecting the power cord.

TO FIND THE LOCATION AND PHONE NUMBER

SERVICE

FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE

OF YOUR NEAREST SERVICE CENTER
PERMITTED TO PERFORM WARRANTY...

CALL TOLL FREE: 1-800-695-0098

PLEASE CALL:

1-800-898-9020

FOR CUSTOMER SERVICE, PLEASE WRITE TO:

Emerson Radio Corp.

Consumer Affairs Dept.

1901 Diplomat Drive,

Farmers Branch, TX 75234.

11

CK5051_ib_Rev.p65 17/12/2001, 10:5111

LIMITED WARRANTY

Emerson Radio Corp. warrants manufacturing defects in original material, including
original parts and workmanship, under normal use and conditions, for a period of
ninety (90) days from the date of original purchase in the U.S. With your dated
proof of purchase, we will provide repair service at no charge for labor and parts
at an authorized Depot Repair Facility, or replace the product in our discretion.
For repair or replacement, pack your unit in a padded box, enclose your check or
money order payable to Emerson Radio Corp. in the amount of $5.00 (not required
by California residents) to cover shipping and handling costs, and enclose a copy
of your proof of purchase. Send your unit to:

Emerson Radio Corp.
1901 Diplomat Drive,

Farmers Branch, TX 75234.

This warranty does not cover damage from negligence, misuse, abuse, accident,
failure to follow operating instructions, commercial use, rental, repairs by an
unauthorized facility, or products purchased, used, serviced or damaged outside
of the United States.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

AU898H

(

12

CK5051_ib_Rev.p65 17/12/2001, 10:5112

EMERSON
Part No. : 16-2840

112-01

800.898.9020

EMERSON RADIO CORP.

Printed in China

CK5051_ib_Rev.p65 17/12/2001, 10:5113
