AM / FM CLOCK RADIO
with SURE-ALARM
™
BATTERY BACK-UP
IMPORTANT
Call toll-free 1-800-210-2281 for exciting information
and special discounts on Extended Service Plans.
OWNER'S MANUAL
CK5028
Visit our web site at www.emersonradio.com
Thank you............................
For purchasing this Emerson AM/FM Clock Radio with Sure-Alarm™ Battery Back
Up System. It has been designed and engineered to provide you with many years
of reliable operation with a minimum of care. Listen to your favorite AM/FM radio
stations; wake up to the radio or an electronic buzzer alarm; sleep to music with the
auto shutoff timer; and use the Snooze Alarm when you need a few more minutes
sleep before you can get up and face a new day.
The Sure-Alarm™ Battery Back Up System not only maintains the time and alarm
settings in case of a power failure, but it will also wake you up even if the power is
'off' at the selected alarm time, as long as the back up battery has sufficient power .
Please read this instruction manual completely to make sure that you understand
all the features of your new clock radio, and please save this manual for future
reference. If you experience any problems with the set up or operation of this radio,
please call the Emerson Radio Corporation Customer Service Hotline, toll free at:
1-800-898-9020.
The serial number of your radio is located on a label on the bottom of the cabinet.
We suggest that you record the serial number in the space below for future reference.
MODEL NO: CK5028
SERIAL NUMBER:
1
IMPORTANT NOTES
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or close heat radiating appliances such as electric
heaters.
• Dusty places.
• Places subject to constant vibration.
• Humid or moist places.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
DANGEROUS VOL TAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product's enclosure.
ATTENTION
The Owner's Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
This device complies with part 15 of the FCC rules. Operation is subject to the
condition that this device does not cause harmful interference.
2
PREPARATION FOR USE
UNPACKING AND SET UP
• Remove all packing materials from the unit. Also remove any descriptive labels
from the front or top of the radio. Do not remove any labels from the back or
bottom of the radio.
• Place the radio on a stable shelf, desk, nightstand, table, etc, convenient to a
1 10V 60Hz AC outlet, and away from direct sunlight or sources of heat, humidity ,
moisture, dust, or vibration.
• Unwind the AC power cord. The FM antenna is built into the power cord so be
sure to extend it to its full length for best FM reception.
BACK UP BATTERY INSTALLATION
The Back Up battery compartment is located on the bottom of the radio. Open the
battery door, as shown in the illustration, and connect a 9V battery (not included)
to the battery terminals. The battery can only be connected one way. Push the
battery back into the battery compartment and replace the battery door.
Press
9
V
O
L
T
Note: Use only a well known brand of Alkaline battery for longest life and best
performance.
In the event of a temporary power interruption the clock display will go off, but the
back up battery will maintain the time and alarm settings. When power is restored
the clock display will come on again and the time and alarm settings will be correct.
POWER FAILURE INDICATION
If you do not install a battery, or if the battery is exhausted and the power is
interrupted, the time and alarm settings will be lost. When power is restored the
display will begin flashing. This flashing display is your indication that the clock is
incorrect and you must reset both the time and alarm settings.
3
