DVD Receiver
DR-110
Instruction manual
INDEX
WARNINGS & IMPORTANT ......................................... i~ii
INDEX ................................................................................1
FEATURES ........................................................................2
PACKAGE CONTENTS ....................................................3
PRECAUTIONS.................................................................4
DISC CARE .......................................................................5
DISC COMPATIBILITY CHART ........................................6
REMOTE CONTROL UNIT ...............................................7
FRONT PANEL/DISPLAY WINDOW.................................9
REAR PANEL AND CONNECTIONS..............................11
VIDEO OUTPUT TERMINALS AND CONNECTIONS ...................11
SPEAKER SYSTEM TERMINALS AND CONNECTIONS .......12
AUX IN Terminals and Connections ………………………...12
INITIAL SETTING............................................................13
TV SETUP........................................................................13
TV DISPLAY..................................................................................13
TV TYPE (TV System)...................................................................13
TV OUTPUT ..................................................................................13
AUDIO OUT (SPEAKER SETUP) .........................................14
AUDIO OUT................................................................................... 14
DOWN MIX ....................................................................................14
SOUND EFFECTS AND TEST TONE .............................15
DOLBY DIGITAL SETUP .................................................16
DOLBY P
ORLOGIC II SETUP ............................................17
LPCM SETUP ..................................................................19
GENERAL SETUP...........................................................19
ANGLE MARK ............................................................................... 19
OSD LANGUAGE ..........................................................................19
CAPTIONS ....................................................................................20
SCREEN SAVER...........................................................................20
PREFERENCES ..............................................................20
AUDIO…........................................................................................ 20
SUBTITLE......................................................................................20
DISC MENU...................................................................................21
PARENTAL ....................................................................................21
PASSWORD.................................................................................. 21
DEFAULTS ....................................................................................21
ON-SCREEN DISPLAY (OSD) ....................................... 22
DVD OSD MODES ............................................................ 22
AUDIO CD/VCD OSD MODES ........................................... 22
BASIC OPERATION OF PLAYBACK ............................23
START PLAYBACK............................................................. 23
SKIP PLAYBACK ................................................................23
FAST FORWARD/REVERSE SCAN............................... 24
SLOW-MOTION PLAYBACK .............................................. 24
PAUSE/STOP PLAYBACK .................................................25
ADVANCED OPERATION OF PLAYBACK ...................25
REPEATED PLAYBACK ..................................................... 25
DVD MENU (DVD ONLY) .................................................25
VCD PLAYBACK CONTROL (PBC)................................25
MULTI-ANGLE PLAYBACK ................................................27
CHANGING SUBTITLE DURING PLAYBACK .........................27
CHANGING AUDIO LANGUAGE DURING PLAYBACK ..........27
GOTO FUNCTION.............................................................. 28
DVD Search Functions .................................................................. 28
VCD/Audio CD DIRECT Functions................................................ 28
DIGIT BUTTONS ................................................. …………..28
I
NPUT SWITCH FUNCTION ................................................... 28
DIGITAL TUNER WITH RDS PS FUNCTION/AMPLIFIER
SYSTEM................................................................... 29
TUNING OPERATION ..................................................... 29
RDS PS FUNCTION ........................................................... 30
AMP VOLUME UP/DOWN ADJUSTMENT ................................31
WORKING WITH JPEG FILES AND MP3 PLAYBACK. 32
WORKING WITH JPEG FILES.........................................32
MP3 COMPATIBLE FORMAT
ADDITIONAL INFORMATION ........................................34
GLOSSARY..................................................................... 34
REGION MANAGEMENT INFORMATION...................... 34
LICENSE .........................................................................34
WARNING .......................................................................34
TROUBLE SHOOTING ...................................................35
SPECIFICATION .............................................................36
..........................................33
1
WARNING & IMPORTANT
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
WARNING: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
CAUTION:
REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
FULLY INSERT.
This symbol warns the user of
un-insulated voltage within the
unit that can cause dangerous
electric shocks.
This symbol alerts the user that
there are important operating
and maintenance instruction in
the literature accompanying this
unit.
CAUTION:
THIS DVD VIDEO PLAYER IS A CLASS 1 LASER PRODUCT. USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOUSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
Including interference that may cause undesired operation.
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment dose cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
─ Reorient or relocate the receiving antenna.
─ Increase the separation between the equipment and receiver.
─ Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.
─ Consult the dealer or an experienced radio/TV technician for help.
Note:
This product incorporates copyright protection technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
i
IMPORTANT SAFEGUARDS AND PRECAUTIONS
READ THE SAFETY AND OPERATING INSTRUCTION before operating your DVD player.
FOLLOW INSTRUCTIONS AND HEED ALL WARNINGS on your DVD player in this manual.
1. Save these instructions for later use.
2. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
3. Do not use this DVD player near water.
4. Do not place this DVD player on an unstable cart, stand or table. The DVD player may fall, causing serious
damage to the DVD player.
5. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To ensure reliable
operation of the DVD player and to protect it from overheating, those openings must not be blocked or
covered. Placing the DVD player on a bed, sofa, rug, or other similar surface should never block the
openings. This DVD player should never be placed near or over a radiator or heat register. This DVD
player should not be placed in a built-in installation unless proper ventilation is provided.
6. This DVD player should be operated from the type of power source indicated on the marketing label. If you
are not sure of the type of power available, consult your dealer or local service.
7. As a safety feature, your DVD video player is equipped with either a 2-wire polarized plug (one plug blade
bigger than the other) or a 3-wire grounded plug (a third pin for grounding). The 2-wire polarized plug will fit
only one way in to power outlet. The 3-wire grounded plug will fit only into a grounding-type power outlet.
8. Do not allow anything to rest on the power cord. Do not locate this DVD player where persons will walk on
the cord.
9. If an extension cord is used with this DVD player, make sure that the total of the ampere ratings on the
products plugged into the extension cord do not exceed the extension cord ampere rating.
10. Never push objects of any kind into this DVD player through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any
kind on the DVD player.
11. Do not attempt to service this DVD player yourself, as opening or removing covers may expose you to
dangerous voltage points or other risks. Refer all servicing to service personnel.
12. An appliance and cart combination should be moved with care. Quick stop, excessive force, and uneven
surfaces may cause the appliance and cart combination to overturn.
13. Unplug this DVD player during lightning storms or unused for long periods of time.
14. Unplug this DVD player from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the DVD player.
C. If the DVD player has been exposed to rain or water.
D. If the product has been dropped or the cabinet has been damaged.
E. If the product exhibits a distinct change in performance, indicating a need for service.
This digital versatile disc (DVD) video player uses PAL and NTSC video
signals and 100-240V AC, 50/60Hz (standard household current).
For future reference, record the model and serial number (located on
the rear of the DVD video player) in the space provided.
Model No: ______________
Serial No: _______________
ii
FEATURES
Compatible With DVD, Super VCD,
VCD, Audio CD, CVD, and MP3
Media Format.
This DVD player can play a variety of disc media including
DVD Video, Video CD, Audio CD, Super VCD, CVD, and
MP3 media format.
Input Switches/RDS PS Function
The input switches function can switch the status between
DVD, AUX-input, TV, VCR, and TUNER. This DVD player
also provides RDS PS (Radio Data System Program
Service station name) function under FM mode.
Analog Audio Output
This DVD player can output either down mixed audio with
LT/RT and Stereo modes or 5.1ch audio output with the
inner Amplifier.
Digital Audio Outputs
The DVD player features one optical audio output. User
selectable SPDIF/RAW and SPDIF/PCM digital audio
maximizes convenience when switching between DVD and
Audio CD playback.
Dolby® Digital & DTS® Digital Audio
Output Support
This DVD player can send Dolby® Digital or DTS® Digital
audio data via its built-in digital audio output to an external
®
Dolby
Digital or DTS® Digital decoder.
High Quality 96kHz/24bit Audio D/A
Converter
This DVD player features a 96kHz/24Bit D/A converter for
superior audio reproduction of encoded discs.
10-Bit/27MHz D/A Video Converter
This DVD player’s 10-bit/27MHz D/A converter is four
times more accurate than conventional 8-bit converters.
The result is artifact-free and crystal clear video image.
Video Zoom Support
The user selectable digital video zoom-out, zoom-in on a
specific portion of a video image is.
Multi-Speed Slow Motion Forward /
Reverse Scan
This DVD player offers perfect slow motion scans.
Volume Control of Analog 5.1ch
audio output all or individual
control
This DVD player can control the volume of analog audio
output from remote control.
Auto Power Shut Down Function
This DVD player offers auto power shut down function.
When the player is not in use for 20 minutes, the player will
shut down automatically to save the power consumption
and prolong the life of DVD player.
Invalid with the inner Tuner turned on.
SPEAKER SETUP refer to P.17
SPEAKER TO BE USED
This unit is designed to provide the best sound-field quality
with a 5.1ch speaker configuration. The most effective
speakers to use with this unit are main speakers, rear
speakers, a center speaker and a subwoofer.
The main speakers are used for the main source sound
plus the effect sounds. They will probably be the speakers
from this DVD/ AV Amplifier player. The rear speakers are
used for the effect and surround sounds, and the center
speaker is for the center sounds (dialog etc.) within
programs encoded with Dolby Surround sounds. The
Subwoofer is for the effect of a super low bass to the music
broadcasting. The center speaker needs to be equal in
power to the main speakers, although the rear speakers
should not to be equal. However, all the speakers should
have high enough power handling to accept the maximum
output.
Multi-Speed Fast Forward/Reverse
Scan
The digital fast forward/reverse scan function is capable of
scanning with different speeds.
2
PACKAGE CONTENTS
Please verify that the following items are included within the DVD carton. If items are missing, please promptly return this unit to
the retailer for an exchange.
DVD Player x1
Remote Control Unit x1
AA Batteries x2
3
SCART Cable x1
AM/FM ANTENNA One Each
Operation Manual x1
3
PRECAUTIONS
Please read the following carefully to get the best and safest performance from this DVD player
Power Supply
Make sure to use the correct power outlet as rated on the
back of the DVD unit. (AC 100-240V)
Power Cord
Do not put any heavy objects on top of the power cord to
avoid fires or electrical shocks caused by cord damage.
Unplug the power cord if the unit will not be used for a
long time.
Unit Placement
Do not place this unit in locations with:
Vibrations
High humidity
Poor ventilation
Direct sunlight
Extremely high or low temperatures
This unit should be placed on a horizontal surface only.
Keep this unit away from television sets, radios,
computers and loudspeakers to avoid magnetic field
interference.
Usage and Storage
Do not remove the top cover to avoid possible electric
shock from touching the inside of this unit.
Do not place any heavy objects on top of this unit.
Condensation
Condensation may result from moving the unit from a
cold place to a hot place. Please turn the power on for
1 to 2 hours before using this unit if condensation
occurs.
Unit Cleaning
Clean the front panel and the body of the unit with a dry
soft cloth. Other areas can be cleaned using a soft
cloth moistened with a mild detergent. Do not clean
with evaporative solutions to avoid possible damage to
the unit.
4
DISC CARE
Disc Usage
Please hold all discs by their edges or the center
opening as shown below. Do not touch the shiny
surface of the discs.
Do not stick labels or tape on the discs, and do not
scratch or damage the discs.
The disc spins at a high speed during playback. Do
not use damaged, cracked, or warped discs because
they could damage the unit.
Disc Cleaning
Fingerprints or dirt on disc surfaces can weaken the
light reflected from the disc and directly influence the
signal quality. The poorer the signal quality, the
poorer the playback performance. Keep the disc
clean by wiping it straight out from the center with a
dry soft cloth.
If the disc is very dirty, wipe with a moist soft cloth,
then follow with a dry soft cloth.
Do not use record cleaning sprays, benzene,
thinner, anti-static electricity liquids, or any other
solvent. These may damage the disc surface.
Disc Storage
Please keep the discs in their original cases to avoid
bending the discs. Do not keep discs in locations
with high temperature, high humidity, or direct
sunshine. These conditions may also cause
damage to the discs.
Carefully read all instructions on the disc label.
5
DISC COMPATIBILITY CHART
This DVD player can play the following types of discs:
Disc Type Dimension/Side/Layer Max. Playback Time (Storage Capacity)
DVD Video
Video CD
Audio CD
DVD MPEG2 TYPE
12 cm (5’’) /single sided/single layer
12 cm (5’’) /single sided/double layer
12 cm (5’’) /double sided/single layer
12 cm (5’’) /double sided/double layer
8 cm (3’’) /single sided/single layer
8 cm (3’’) /single sided/double layer
8 cm (3’’) /double sided/single layer
8 cm (3’’) /double sided/double layer
VCD MPEG1 TYPE
12 cm (5’’)/single sided/single layer 74 min.
8 cm (3’’)/single sided/single layer 20 min.
CD CD
12 cm (5’’)/single sided/single layer 74 min.
133 min. (4.7 GB)
242 min. (8.5 GB)
266 min. (9.4 GB)
484 min. (17 GB)
41 min.
75 min.
82 min.
150 min.
8 cm (3’’)/single sided/single layer 20 min.
DVD and VCD Discs contain both video and audio and can support multiple audio tracks.
Audio CD: Discs have audio only.
Do not insert DVD-ROMs, CD-ROMs intended for computers in this DVD player.
This unit complies with VCD ver. 1.1, ver. 2.0.
This unit is compatible with CD-R & CD-RW.
The playback time of SVCD is among 37 minutes.
6
REMOTE CONTROL UNIT
To use the remote control unit to operate the DVD player, insert two batteries (size AA) making sure that the + and –
ends of the batteries are matched to the +/– marks printed inside the battery compartment. To use the remote controller,
please point the remote control unit at the remote sensor on the DVD player.
Notes:
Do not use different types of batteries together, or mix old and new batteries.
When the remote control unit does not function correctly or its operation range reduces, please replace both batteries at the same time.
If the remote control unit will be not used for a long time, please remove the batteries to avoid possible damage from battery leakage or corrosion.
Keep the remote controller away from extremely hot or humid locations.
Do not open the remote controller unit.
Insert two AA Batteries.
7
Remote Control Unit
1. POWER
Switches power ON/OFF. Refer to P.23.
2. DIGITS – 0,1,2,3,4,5,6,7,8,9, +10
Used for direct selection of menu choices, audio tracks,
and other input such as time etc. Under Tuner mode,
stores FM station FREQ, up to 20 stations can be
stored. Refer to P.28 & P.29.
3. ANGLE
If the DVD disc contains multiple view angles, this
button will change the viewing angle displayed by the
DVD player. Refer to P.27.
4. A-B
Display A-B repeat playback. Refer to P.26.
5. REPEAT
Shows repeat playback for one title, or all titles on the
disc. Refer to P.26.
6. VOLUME – & +
Reduce / Increase the volume of analog audio output.
Refer to P.31.
7. SET UP
Customizes settings. Refer to P.13.
8. AMP VOL
Switches volume adjustment between all and each
channel Left, Center, Right, Rear Left, Rear right.
Refer to P.31
9.
Fast reverse scans during playback. Toggles between
X2, X4, X6, and X8 or for back search of Tuner stations.
Refer to P.24 & P.29.
10.
Goes back to the previous chapter during play. Under
tuner mode, turns in previous lower FREQ station.
Refer to P.23 & P.30.
11. S
Used for navigation within a selection menu. Refer to
P.26
12. W
Used for navigation within a selection menu and for
lower FREQ fine-tuning when the Tuner is on. Refer to
P.26 & P.30.
13. DISPLAY
On-Screen display of the DVD player’s operational
status. Refer to P.22.
14. /
Pause or stops the playback. Push this button once for
pause and twice for pre-stop and thrice for full stop
(DVD MODE). Push this button once for pause and
twice for stop (VCD MODE) Refer to P.25.
15. SLOW
Engages slow-motion forward/reverse playback. Refer
to P.24.
16. ZOOM
Enters the zoom mode (X1.5, X2, X3) during playback.
17. T
Used for navigation within a selection menu. Refer to
P.26
18. X
Used for navigation within a selection menu and for
lower FREQ fine-tuning when the Tuner is on. Refer to
P.26 & P.30.
19. ENTER/PLAY
Confirms selection of an item in the menu or starts
playing the disc. Refer to P.23 & P.26.
20.
Skips to the next chapter during play. Under tuner
mode, turns in next higher FREQ station. Refer to P.23
& P.30.
21.
Fast-forward scans during playback. Toggles between
X2, X4, X6, and X8 or for forward search of Tuner
stations. Refer to P.24 & P.29.
22. MUTE
Use to mute the sound of playback.
23. AUDIO
During playback of a DVD disc with two or more audio
languages, this button changes between the audio
languages played. Refer to P.27.
24. GOTO
Enables search mode by title/chapter and time. Refer
to P.28.
25. DVD MENU
Some DVDs have complex submenus. This button
allows access to these submenus. The button turns
on/off the Playback Control function during SVCD or
VCD playback. Refer to P.26.
26. SUBTITLE
During playback of DVD discs with two or more
subtitle languages, this button toggles between
available subtitle languages. Refer to P.27.
27. INPUT
Switches between DVD, AUX-INPUT, TV, VCR and
TUNER mode. Refer to P.28.
28. OPEN/CLOSE
Opens or close disc tray. Refer to P.23.
8
FRONT PANEL/DISPLAY WINDOW
Front Panel
Front Panel Controls Reference Guide
1. STANDBY （Remote Sensor）
2. Disc Tray
3. Multi-Function Display Window
4. Volume Knob
5. Power On/Off button
Rear Panel
6. Open/Close (Eject) Button
7. Previous Button
8. Next Button
9. Stop Button
10. Play Button
To Po w e r
AM
FM
ANTENNA
VIDEO
S-VIDEO
1. Audio In Jack: Left Channel
2. SCART Terminal AV1 (TV)
3. Speak System Terminals:
FR/SR/CENTER/SL/FL
4. AM/FM/RDS Antenna
5. Optical Audio Out
L
R
V1 (TV)
V2 (VCR)
AV - SCARTS
FR SR CEN SL F L
6. Speak System Terminal: SUBWOOFER
7. Composite Video Output Jack
8. S-Video Output Jack
9. Video In Jack
10. Audio In Jack: Right Channel
11. SCART Terminal AV2 (VCR)
9
Display Window
10
REAR PANEL AND CONNECTIONS
A
A
Video Output Terminals and
Connections
Composite Video Output Terminal
Composite video output is the most commonly used
video connection in use today and is supported by
most televisions and A/V receivers. Composite video
is set to display without user setup.
S-Video Output Terminal
You will want to use S-Video output with televisions
or monitors equipped with an S-Video input.
NOTE:
S-Video cable is not included with this player.
SCART Terminal
1. The SCART terminal AV1 (TV) can be connected to the TV set equipped with SCART connectors.
NOTE:
Figures and silkscreen in this book for reference only.
For selected TVs, when the TV set is at standby mode, power on the DVD player will automatically power on the TV and switch to the SCART
video input channel.
V1 (TV)
V2 (EXT)
11
Speaker System Terminals
A
A
Use Speaker System for connection with the external
Speakers of FR, FL, R Surround, L Surround, Center and
Sub woofer.
* External Speakers Load (of FR, FL, R Surround, L
Surround, Center): 4 ohms; Subwoofer with RCA JACK.
Optical Digital Audio Output Terminals
Use digital audio outputs for connection with an external
®
Dolby
output, you will need to purchase an Optical cable for
connection with the Optical Input Terminal of an AV
amplifier. (Digital cable is not included with this player.)
Note when connecting the Optical digital cable:
Digital or DTS® decoder. To use the Optical
Remove the dust protection cap from the connector
and connect the cable firmly so that the
configurations of both cable and connector match.
Keep the dust protection cap and always re-attach
the cap when not using the connector to protect
against dust.
AUX IN Terminals and Connections
Video In and Audio IN Terminals and
Connections
Use AUX IN terminals (Video in & Audio in) for
connection with the external players.
* External players: such as DVD, VCR and so on.
SCART Terminal
The SCART terminal AV1 (TV) can be connected
to the TV set equipped with SCART connectors.
The SCART terminal AV2 (EXT) can be
connected to another external player.
NOTE: Figures and silkscreen in this book for reference only.
SCART OUT
V1 (TV)
V2 (EXT)
External Player
12
INITIAL SETTING
Press the SETUP button on the remote controller to set up
the initial setting. The On-Screen Display (OSD) will display
below:
SETUP MENU - - MAIN PAGE
TV SETUP
AUDIO SETUP
DOLBY DIGITAL SETUP
Pro Logic II SETUP
LPCM SETUP
GENERAL SETUP
PREFERENCES
EXIT SETUP
GOTO TV SETUP PAGE
TV SETUP
There are three available items: They are TV DISPLAY, TV
TYPE, and TV OUTPUT.
- - TV SETUP PAGE - -
TV DISPLAY NORMAL/PS
TV TYPE NORMAL/LB
TV OUTPUT WIDE
MAIN PAGE
SET TV DISPLAY MODE
TV DISPLAY
NORMAL/PS
4:3 Pan & Scan video output for a normal TV set
NORMAL/LB
4:3 Letterbox video output for a normal TV set
WIDE
16:9 Wide Screen video output for a wide screen TV
set
NOTES:
Aspect ratios available for playback will be printed on the DVD disc
rear packaging.
Some DVDs are recorded in the Cinema Wide format (16:9 aspect
ratio), and some are recorded in the standard format (4:3 aspect
ratio). Some DVD discs are recorded in both formats and may have
the Pan Scan feature available. The Pan Scan feature if available
will fill the entire screen in 4:3 TV screen. However, it will cut some
of the picture off at the two sides.
TV TYPE (TV System)
There are three available items to switch TV System:
They are MULTI, NTSC and PAL.
MULTI
The DVD player will choose the correct system to
display the playback of inserted disc.
NTSC
The DVD player will output in NTSC format regardless
of what format the disc was designed for.
PAL
The DVD player will output in PAL format regardless of
what format the disc was designed for.
- - TV SETUP PAGE - -
TV DISPLAY
TV TYPE MULTI
TV OUTPUT NTSC
PAL
MAIN PAGE
SET TV DISPLAY MODE
TV OUTPUT
The TV OUTPUT has S-VIDEO option only.
NOTE:
S-Video output and SCART video output can be used
simultaneously, but the SCART terminal provides composite video
only.
- - TV SETUP PAGE - -
TV DISPLAY
TV TYPE
TV OUTPUT S-VIDEO
MAIN PAGE
SET TV OUTPUT
13
AUDIO OUT (Speaker setup)
There are two available items: They are AUDIO OUT and
DOWN MIX.
AUDIO OUT
You can choose to send the player’s audio signals to
an external receiver using the following outputs:
ANALOG:
Audio signals are sent using inner amplifier. Selecting
this choice will disable the digital audio outputs.
SPDIF/RAW:
Set to this selection will output the raw bit stream
signal of Dolby Digital or DTS from the optical jack. In
order to enjoy Dolby
®
Digital DTS discs, this unit’s
digital output jack must be connected to the
digital-input jack of a Dolby
®
Digital or DTS compatible
receiver or processor.
SPDIF/PCM:
PCM stands for Pulse Code Modulation and is digital
audio. Connecting this unit to an amplifier with a
built-in D/A converter can play the same digital audio
format as on CDs.
NOTES:
Do not play the Dolby Digital or DTS sound tracks on an audio
component without having a built-in Dolby Digital or DTS decoder.
Otherwise, when you play the Dolby Digital or DTS sound track, a
loud noise will come out from the speakers, affecting your ears or
causing the speakers to be damaged.
This player has a conversion function for converting Dolby
into the LPCM format. This allows playback of CDs with the regular
playback system without the need for a special converter.
- - AUDIO SETUP PAGE - -
AUDIO OUT ANALOG
DOWNMIX SPDIF/RAW
FRONT SPDIF/PCM
CENTER
REAR
SUBWOOFER
CNTR DIST.
REAR DIST.
TEST TONE
SELECT AUDIO OUTPUT
®
Digital
DOWN MIX
LT/RT
A kind of Dolby Pro-Logic coding formats.
STEREO
Down mixed Stereo L/R audio output.
5.1 CH
Set to “5.1CH” setting items to enable the 5.1
channels.
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX LT/ RT
FRONT STEREO
CENTER 5.1CH
REAR
SUBWOOFER
CNTR DIST.
REAR DIST.
TEST TONE
SET DOWNMIX MODE
14
SOUND EFFECTS AND TEST TONE
There are seven available sound-effect items: They are
FRONT, CENTER, REAR, SUBWOOFER, CNTR DIST.,
REAR DIST.,
and TEST TONE:
FRONT
Set Front Speakers size large/small
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT LARGE
CENTER SAMLL
REAR
SUBWOOFER
CNTR DIST.
REAR DIST.
TEST TONE
SETUP FRONT SPEAKER SIZE
CENTER
Set Center Speaker size large/small/off.
REAR
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT
CENTER LARGE
REAR SMALL
SUBWOOFER OFF
CNTR DIST.
REAR DIST.
TEST TONE
SETUP CENTER SPEAKER SIZE
Set Rear Speakers size large/small/off.
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT
CENTER
REAR LARGE
SUBWOOFER SMALL
CNTR DIST. OFF
REAR DIST.
TEST TONE
SETUP REAR SPEAKERS SIZE
SUBWOOFER
Set Subwoofer Speaker on/off.
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT
CENTE
REAR
SUBWOOFER ON
CNTR DIST. OFF
REAR DIST.
TEST TONE
DO YOU HAVE A SUBWOOFER?
CNTR DIST
Adjust the delay distance of CENTER speaker.
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT
CENTER
REAR
SUBWOOFER
CNTR DIST.
REAR DIST.
TEST TONE
SET CENTER DELAY
1.5MTR
-
-
-
-
-
-
1MTR
-
-
-
-
0.5MTR
-
-
OFF
NOTE:
Please set the “CENTER” item to “LARGE” or “SMALL” first.
REAR DIST:
Adjust the delay distance of REAR speaker.
NOTE:
Please set the “REAR” item to “LARGE” or “SMALL” first.
- - AUDIO SETUP PAGE - -
Audio Out
DOWNMIX
FRONT
CENTER
REAR
SUBWOOFER
CNTR DIST.
REAR DIST.
TEST TONE
SET SURROUND DELAY
-
-
-
-
-
-
5MTR
-
-
-
3MTR
-
-
1MTR
-
OFF
15
SOUND EFFECTS AND TEST TONE
DYNAMIC
TEST TONE
Test the output ability of left, center, right, right
surround, and left surround speakers in sequence.
NOTE:
Please set the “DOWNMIX” item to “5.1CH” first.
- - AUDIO SETUP PAGE - -
AUDIO OUT
DOWNMIX
FRONT
CENTER
REAR
SUBWOOFER
CNTR DIST.
REAR DIST. ON
TEST TONE OFF
TEST TONE
DOLBY DIGITAL SETUP
There are two available items: They are DUAL MONO and
DYNAMIC.
DUAL MONO
There are four available modes: STEREO, L-MONO,
R-MONO, and MIX-MONO.
- - DOLBY DIGITAL SETUP - -
DUAL MONO STEREO
DYNAMIC L-MONO
MAIN PAGE
DUAL MONO (1 + 1) SETUP
R-MONO
MIX-MONO
Audio output description
MODE LEFT SPEAKER RIGHT SPEAKER
STERO STEREO -L STEREO -R
L-MONO L-MONO L-MONO
R-MONO R-MONO R-MONO
MIX-MONO L-MONO+R-MONO L-MONO+R-MONO
“Dynamic Range” is the difference between the
maximum level and the minimum level of sounds.
Sounds on a movie originally designed for movie
theaters feature a very wide dynamic range, so
sometimes it is not suitable for home use. Depending
on the condition of your listening environment,
Dynamic Range function can reduce the instant sound
effect alteration of the movie while playing back.
When seeing movies in the night, turn this function on
to avoid the suddenly loud sound to influence your
neighbors. (Default value is FULL, no compression to
be done.)
NOTES:
This function works only during playback of Dolby Digital recorded
discs.
The level of Dynamic Range Reduction may differ depending on the
DVD discs.
16
- - DOLBY DIGITAL SETUP - -
DUAL MONO
DYNAMIC
MAIN PAGE
DYNAMIC RANGE COMPRESSION
FULL
6/8
4/8
2/8
OFF
Pro Logic II SETUP
There are three available items: They are Pro Logic
OFF, ON and AUTO.
- - Pro Logic II SETUP- -
SETUP Pro Logic mode
Pro Logic OFF
Pro Logic II Mode ON
DIMENSION AUTO
PANORAMA
CENTER WIDTH
SURROUND FILTER
SURROUND COHERENCE
MAIN PAGE
Set to ON to enable Pro Logic II Mode. There are six
available items: They are Pro Logic, VIRTUAL,
MUSIC, MOVIE, MATRIX, and CUSTOM.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode Pro Logic
DIMENSION VIRTUAL
PANORAMA MUSIC
CENTER WIDTH MOVIE
SURROUND FILTER MATRIX
SURROUND COHERENCE
CUSTOM
Movie
MAIN PAGE
Set to MUSIC mode to enable three available items:
They are DIMENSION, PANORAMA, and CENTER
WIDTH.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode Pro Logic
DIMENSION VIRTUAL
PANORAMA MUSIC
CENTER WIDTH MOVIE
SURROUND FILTER MATRIX
SURROUND COHERENCE
CUSTOM
Music
MAIN PAGE
DIMENSION
Dimension: -3, -2, -1, 0, 1, 2, 3:
Dimension control. Allows the user to gradually adjust
the soundfield either towards the front or towards the
rear. This can be useful to help achieve a more
suitable balance from all the speakers with certain
recording.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode -3
DIMENSION -2
PANORAMA -1
CENTER WIDTH 0
SURROUND FILTER 1
SURROUND COHERENCE
3
Dimension
MAIN PAGE
2
PANORAMA
Panorama: ON/OFF:
Panorama mode. Extends the front stereo image to
include the surround speakers for an exciting
“wraparound” effect with sidewall imaging.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode
DIMENSION
PANORAMA ON
CENTER WIDTH OFF
SURROUND FILTER
SURROUND COHERENCE
Panorama
MAIN PAGE
17
Pro Logic II SETUP
CENTER WIDTH
Center Width: 0, 1, 2, 3, 4, 5, 6, 7:
Center Width control. Allows variable adjustment of
the center image so it may be heard only from the
center speaker, only from the left/right speakers as a
“phantom” center image, or various combinations of
all three front speakers. With this control it is possible
it create a balanced left-center-right stage
presentation for both the driver and the front
passenger. For home users, it allows improved
blending of the center and main speakers, or to
control the sense of image width, or “weight”.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode 1
DIMENSION 2
PANORAMA 3
CENTER WIDTH 4
SURROUND FILTER 5
SURROUND COHERENCE
7
Center Width
0
6
Set to CUSTOM mode to enable five available items:
They are DIMENSION, PANORAMA, CENTER
WIDTH, SURROUND FILTER and SURROUND
COHERENCE.
The functions of the three (Dimension, Panorama, Center
Width) are same in Music mode.
Surround Filter
SURROUND COHERENCE
Surround Coherence: ON/OFF.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode
DIMENSION
PANORAMA
CENTER WIDTH
SURROUND FILTER
SURROUND COHERENCE
OFF
ON
Surround Coherence
NOTE:
Press or button following the direction of the cursor on the
screen to do setting in one more menu page.
Surround Filter: ON/OFF.
- - Pro Logic II SETUP- -
Pro Logic
Pro Logic II Mode
DIMENSION
PANORAMA
CENTER WIDTH
SURROUND FILTER ON
SURROUND COHERENCE
Surround Filter
OFF
18
LPCM SETUP
This option sets the audio output format sent using the
unit’s optical digital audio output.
Linear PCM OUT
LPCM 48K
In the Linear PCM setting, “48K” means “the digital
audio output maximum sampling rate is 48kHz”;
therefore, when the title’s encoding sampling rate* is
96kHz, the output will be forced converted to 48kHz.
LPCM 96K
If “96K” is selected, then the maximum
output-sampling rate is 96kHz and no conversion will
take place.
NOTES:
Sampling rate:
When a sound wave is converted to a digital signal, the sound is
sampled and converted to data at a specific frequency rate. For
example, a signal with a 96 kHz sampling rate indicates that in one
second, the analog signal was sampled 96000 times to produce
the digital signal.
In LPCM set-up menu, there will be a case that even when “LPCM
96K” is selected, output signal is converted to 48kHz if the disc has
the copy guard management system in it.
DISC CODING AND OUTPUT FORMAT
Disc Audio encoding format Digital output format
DVD
- - LPCM SETUP PAGE - -
LPCM OUTPUT LPCM 48K
LPCM 96K
MAIN PAGE
SET LPCM OUTPUT TO 48 OR 96K
Dolby Digital Bit stream
Dolby Digital®
DTS® Bit stream (1~5.1 ch) or OFF
Linear PCM
(48/96kHz, 24bits)
(1~5.1 ch) or 48kHz/16bits
2ch Linear PCM
Linear PCM
(48kHz/16 bits up to 96kHz/24bits)
GENERAL SETUP
There are four available selections: ANGLE MARK, OSD
LANG, CAPTIONS, and SCR SAVER.
ANGLE MARK
During playback of a title with multiple angle sections,
the message "
the screen.
" will appear on the upper corner of
When ANGLE MARK is set to "ON", the angle mark
OSD will stay on the screen until the end of the
playback title or chapter.
When ANGLE MARK is set to "OFF", the angle mark
OSD will stay on the screen for 3 sec and then
disappear.
OSD LANGUAGE
You can select the language for the setup menu or the
operation message display. There are five available
OSD languages: ENGLISH, FRENCH, GERMAN,
DUTCH and DANISH for display.
- - GENERAL PAGE - -
ANGLE MARK ON
OSD LANG OFF
CAPTIONS
SCR SAVER
MAIN PAGE
ANGLE MARK ON/OFF
- - GENERAL PAGE - -
ANGLE MARK
OSD LANG ENGLISH
CAPTIONS FRENCH
SCR SAVER GERMAN
DUTCH
MAIN PAGE DANISH
SET OSD LANGUAGE
Video CD
Audio CD
MPEG 1 Linear PCM (44.1kHz sampling)
Linear PCM Linear PCM (44.1kHz/16bit)
19
CAPTIONS
Closed Caption (CC) is a standardized method of
encoding text into an NTSC television signal. A TV can
display the text with a built-in decoder. Closed Caption
can be carried on DVD. If a DVD title contains a CC
mark on the rear of the DVD disc’s box, then you can set
“CAPTIONS” to “ON” and read written captions on the
TV screen. Default is set to “OFF”.
- - GENERAL PAGE - -
ANGLE MARK
OSD LANG
CAPTIONS ON
SCR SAVER OFF
MAIN PAGE
CLOSED CAPTION
SCREEN SAVER
When this DVD player is idle (after about 5 minutes of
inactivity), the screen saver can be activated to prolong
the TV monitor’s life.
NOTE:
Caution: The DVD player can hold a still video image or OSD image
on your television screen indefinitely. If you leave the still video
image or OSD image displayed on your TV for a very long time. It
may cause the permanent damage to your TV screen.
- - GENERAL PAGE - -
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER ON
OFF
MAIN PAGE
SCREEN SAVER
PREFERENCES
Preferences allow you to set the default AUDIO,
SUBTITLE, DISC MENU, PARENTAL, PASSWORD, and
factory DEFAULTS of this player. This setting is only
available when the DVD player is in the STOP mode by
pressing the / button thrice.
NOTE:
Pressing the / button once only pause the playback, to
pre-stop it after pressing / button twice and to stop the
playback completely by pressing / thrice.
AUDIO
This unit supports six audio selections, as shown below,
for your preferred audio setting.
SUBTITLE
This unit supports six subtitle selections, as shown
below, for your preferred default subtitle setting. When
“OFF” is selected, there will be no subtitle is displayed
during playback.
- - PREFERENCES PAGE - -
AUDIO ENGLISH
SUBTITLE FRENCH
DISC MENU GERMAN
PARENTAL
PASSWORD DUTCH
DEFAULTS DANISH
MAIN PAGE
PREFERRED AUDIO LANGUAGE
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU FRENCH
PARENTAL GERMAN
PASSWORD
DEFAULTS DUTCH
DANISH
MAIN PAGE OFF
PREFERRED SUBTITLE LANGUAGE
SPANISH
ENGLISH
SPANISH
20
DISC MENU
PASSWORD
This unit supports six DISC MENU languages.
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU ENGLISH
PARENTAL FRENCH
PASSWORD GERMAN
DEFAULTS SPANISH
DUTCH
MAIN PAGE DANISH
PREFERRED MENU LANGUAGE
PARENTAL
Functions to limit the playback of some discs that
contain mature scenes. The limitation varies from disc
to disc; when it is activated, playback is completely
prohibited. There are eight levels of parental setting of
this unit.
When you want to change the parental rating level, you
will be asked to enter a password.
NOTE:
Use “3308” to override the forgotten password and re-enter a new
password.
- - PREFERENCES PAGE - -
AUDIO 1 G
SUBTITLE 2
DISC MENU 3 PG
PARENTAL 4 PG-13
PASSWORD 5
DEFAULTS 6 PG-R
7 NC-17
MAIN PAGE 8 ADULT
SET PARENTRAL CONTROL
PASSWORD VERIFY PAGE
INPUT PASSWORD:
PLEASE ENTER PASSWORD
The password is a 4-digit number. When you want to
change the password, select “CHANGE” as shown below.
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD CHANGE
DEFAULTS
MAIN PAGE
CHANGE PASSWORD
You will be asked to enter the old password, then enter
the new password, and confirm it.
PASSWORD CHANGE PAGE
OLD PASSWORD:
NEW PASSWORD:
CONFIRM PWD:
PLEASE ENTER OLD PASSWORD
NOTES:
The default password number is”3308”.
DEFAULTS
When you select “RESET”, all the initial settings will be
restored to the default setting.
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULTS RESET
MAIN PAGE
LOAD FACTORY SETTING
21
ON-SCREEN DISPLAY (OSD)
DVD OSD Modes
There are two OSD display modes available when playing
a DVD disc.
Mode 1
Shows the status of the pressed button and some special
messages are displayed on the screen. For example,
when the
OPEN/CLOSE button is pressed, the OSD shows:
OPEN
CLOSE
Mode 2
Shows the playback information of a movie or title.
When pressing the DISPLAY button on R/C, the
information OSD will display on the screen in the
sequence as shown below:
1st time 2nd time
ROOT MANU
00:00:00
TITLE REMAIN
01:35:13
3rd time 4th time
CHAPTER ELAPSED
00:05:13
CHAPTER REMAIN
00:25:13
When pressing the DISPLAY button on the remote
control again, it will turn off the OSD.
Audio CD/VCD OSD Modes
There are two OSD display modes available when playing
a SVCD, VCD, and Audio CD disc.
Mode 1
Shows the status of the pressed button and some special
messages are displayed on the screen as previous
description.
Mode 2
Shows the playback time information of a disc.
PBC ON (VCD 2.0 above only):
When pressing the DISPLAY button on R/C, the
information OSD will display on the screen in the
sequence as shown below:
1. SINGLE ELAPSED 2. SINGLE REMAIN
SINGLE ELAPSED
00:05:13
SINGLE REMAIN
00:05:13
PBC OFF or Audio CD playback:
1. SINGLE ELAPSED 2. SINGLE REMAIN
SINGLE ELAPSED
00:05:13
SINGLE REMAIN
00:05:13
3. TOTAL ELAPSED 4. TOTAL REMAIN
TOTAL ELAPSED
00:05:13
TOTAL REMAIN
00:05:13
When pressing the DISPLAY button on the remote
control again, it will turn off the OSD.
22
BASIC OPERATION OF PLAYBACK
Preparation:
If a television set is used, turn on its power and set the TV/Video switch to the right channel.
If a sound system is used, turn on the amplifier first and make sure its outputs are set properly.
START Playback
1. Press the POWER button to turn on the DVD player.
2. Press the OPEN/CLOSE button to open the disc tray.
3. Place a disc onto the tray and make sure that it is
placed squarely on the tray.
4. Press the OPEN/CLOSE or ENTER/PLAY button to play
the disc.
NOTES:
When using a DVD disc, some menu selections and some DVD
playback functions are available during playback.
When using a VCD disc with PBC, the PBC menu will be displayed
on the screen. You can use the PBC menu, or press the PBC button
to set PBC off and the disc will play immediately.
For a VCD disc without PBC or an Audio CD, the disc will be played
immediately.
SKIP Playback
DVD Playback
Press the
chapter.
Before pressing button After pressing button
TITLE 002/04 CHAPTER 01/09
Press the
the current chapter or previous chapter.
Before pressing button After pressing button
TITLE 002/04 CHAPTER 02/09
(NEXT) button to skip to the next
(PREV) button to skip to the beginning of
TITLE 002/04 CHAPTER 02/09
TITLE 002/04 CHAPTER 01/09
VCD/Audio CD Playback
PBC ON (VCD 2.0 above only):
Press the (NEXT) or (PREV) button will go
back to the PBC menu or the beginning of the song
playing.
PLAYING VCD PBC MENU
PBC OFF or Audio CD
Press the (NEXT) or (PREV) button will skip to
the next or previous track of VCD or Audio CD.
PREVIOUS
NEXT
Song 1
Song 2
Song 3
Song 4
Song 5
Song 6
23
FAST FORWARD/REVERSE SCAN
SLOW-MOTION Playback
Using the
(FF) and (FR) buttons to fast forward and
reverse scan.
DVD Playback
When the
playback changes in cycles of 2468 Play 2
FF 2 FF 8
FF X2
FR 2 FR 8
FR X2
or button is pressed, the speed of
Fast Forward
Fast Reverse
FF X8
FR X8
When the ENTER/PLAY button is pressed during fast
forward/reverse scan, normal playback will be
resumed.
VCD/Audio CD Playback
When the
playback changes in cycles of 2468 Play 2.
(Similar as DVD Playback)
or button is pressed, the speed of
When the ENTER/PLAY button is pressed during fast
forward/reverse scan, normal playback will be
resumed.
NOTES:
It is normal that video image may seem discontinuous during fast
forward/reverse scan.
When the fast forward scan reaches the end of a track (Audio
CD/VCD) or a title (DVD), normal playback of the next track/title will
be resumed.
When the fast reverse scan reaches the beginning of a track (Audio
CD/VCD) or a title (DVD), the normal playback of the track/title will
be resumed.
DVD Playback
When the SLOW button is pressed, the speed of
playback changes in cycles of slow forward
248slow reverse248PLAY slow
forward 2.
SF 2 SF 8
SF X2
Slow Forward
SF X8
SR 2 SR 8
SR X2
Slow Reverse
SR X8
When the ENTER/PLAY button is pressed during slow
forward/reverse scan, normal playback will be
resumed.
VCD Playback
When the SLOW button is pressed, the speed of
playback changes in cycles of slow forward 246
PLAY slow forward 2.
SF
2 SF 6
SF X2
Slow Forward
SF X6
When the ENTER/PLAY button is pressed during slow
forward scan, normal playback will be resumed.
NOTE:
During slow-motion play, you will not be able to hear the audio
portion of the track.
24
PAUSE/STOP Playback
/
/
DVD Playback
Pause/Play
Pressing the
Press the ENTER/PLAY button to return to normal play.
PAUSE
Pressing the
You must press the / button thrice to full stop the
playback.
PLAYING
STOP
RESUME
PLAY
PLAY
STOP
Press the ENTER/PLAY
button will resume
playback.
NOTE:
When the unit is not in use, please remove the disc and press the
POWER button to turn off DVD player.
/ button to freeze the image.
PLAY
/ button twice only pre-stop the playback.
Press the
TWICE will Pre-stop
playback.
STOP
Press the
THRICE will totally stop
playback.
button
PRE-STOP
PRESS PLAY TO CONTINUE
STOP
button
VCD/Audio CD Playback
PBC ON (VCD 2.0 above only):
Pressing the / button once to freeze the image.
Press the ENTER/PLAY button to return to normal play.
PAUSE
PLAY
PBC OFF or Audio CD
Pressing the / button once to freeze the image.
Press the ENTER/PLAY button to return to normal play.
PAUSE
Pressing
/ button twice will stop playback during
PBC off or Audio CD playback.
PLAYING (VCD) STOP
PLAYING (Audio CD) STOP
PLAY
STOP
STOP
25
ADVANCED OPERATION OF PLAYBACK
REPEATED Playback
TITLE/CHAPTER Repeat
When the REPEAT button is pressed, the repeated
playback is triggered and the OSD message is changed
in cycles of “CHAPTER REPEAT ON”, “TITLE REPEAT
ON”, and “REPEAT OFF.”
CHAPTER REPEAT
Enables the repeated playback of a chapter for a DVD
disc or track for an Audio CD disc or a VCD disc.
TITLE REPEAT
Enables the repeated playback of a title for a DVD disc
or a disc for an Audio CD disc or a VCD disc.
REPEAT OFF
Resumes normal play.
CHAPTER REPEAT ON
A-B Repeat
You are able to perform a repeated playback between
any two points of a track or a chapter.
1. Press the
beginning point (A). The OSD message “A TO B SET
A “ will be shown on the right lower screen corner.
2. Press the
The OSD message “A TO B SET B ” will be shown. In
the meantime, the repeated playback begins between
the two points, A and B.
3. Pressing the
The OSD message “A TO B CANCELLED” will be
shown.
SET A SET B
A TO B SET A
A-B button during playback to set the
A-B button again to set the end point (B).
A-B button again resumes normal play.
TITLE REPEAT ON
A TO B SET B
DVD MENU (DVD ONLY)
DVD Playback
Some DVDs have complex contents such as
multi-subtitle, multi-audio, or multi-angle. In these
cases, you may use the DVD menu to select audio
language, subtitle language, and angle.
1. Press the
the DVD menu, if it is available on the disc.
2. Use the
press the ENTER/PLAY button to select the preferred
item. Or you can directly press the numeric buttons to
select the item.
3. Pressing the ENTER/PLAY button resumes the playback
of the scene when the DVD MENU button was first
pressed.
DVD MENU button during playback to display
buttons to control the direction and
DVD MENU
DISC MENU
PLAY MOVIE
SPECIAL
CHPATERS
SUBTITLES
AUDIO
CHARACTERS
VCD PLAYBACK CONTROL (PBC)
VCD Playback
This function is only available for Video-CD version
2.0 or higher. The PBC operation may differ by disc,
therefore, refer to the instructions for each disc.
Press the DVD MENU button to switch on/off the PBC
function. The OSD message “PBC ON” or “PBC OFF”
will be displayed.
On the PBC menu, the
buttons are dedicated for “GO BACK TO PREVIOUS
PAGE” and “GO TO NEXT PAGE” of the PBC menu, if
available.
VCD PBC MENU Page 1 VCD PBC MENU Page 2
Song 1
Song 2
Song 3
Song 4
Song 5
Song 6
(PREV) and (NEXT)
Song 7
Song 8
Song 9
Song 10
Song 11
Song 12
26
MULTI-ANGLE Playback
A
Some DVD discs may contain scenes with a number of
different angle views. Whenever a scene with multiple
angle views is played, you can use the
ANGLE button to
view this scene from different angles.
The OSD icon " " will appear on the screen during
the playback of a scene with multi-angle views.
When the ANGLE button is pressed, the angle for
playback will change in cycles among the available
angle numbers.
Angle 1/3 Angle 2/3
1/3
2/3
Angle 3/3 Angle 1/3
3/3
1/3
NOTE:
The "ANGLE MARK" in the initial setting must be set to "ON."
Changing SUBTITLE During Playback
During playback of a DVD disc with more than two subtitle
languages, you can change the subtitle or disable the
subtitle by pressing the
SUBTITLE button.
When the SUBTITLE button is pressed, the subtitle for
playback will change in cycles among the available
subtitle numbers and “OFF” status. “ OFF” will disable
the subtitle display.
The OSD message will show the current subtitle number.
If no selection is made, this OSD message will disappear
after 3 seconds.
English Subtitle Chinese Subtitle
SUBTITLE 01 / 02: ENGLISH
How are you?
SUBTITLE 02 / 02:Chinese
你好嗎?
Subtitle Off English Subtitle
SUBTITLE OFF
SUBTITLE 01 / 02: ENGLISH
NOTES:
Sometimes the subtitle language can only be changed in DVD
menu instead of during playback.
The number of available subtitle language is depending on the disc.
How are you?
Changing AUDIO LANGUAGE During
Playback
During playback of a DVD disc with more than two audio
languages, you can change the audio/language by
pressing the
AUDIO button.
When the AUDIO button is pressed, the audio /
language for playback will change in cycles among
the available audio/language numbers.
The OSD message will show the current subtitle
number. If no selection is made, this OSD message
will disappear after 3 seconds.
English Language Chinese Language
UDIO 01 / 02: ENGLISH
NOTES:
Sometimes the audio language can only be changed in DVD menu
instead of during playback.
The number of available audio language is depending on the disc.
AUDIO 02 / 02: Chinese
27
GOTO Function
P
Under the search mode, specific title, chapter, or time
can be located for immediate playback.
DVD Search Functions
During a DVD playback, pressing the GOTO button can
enable the search function. The OSD will show three
search methods after pressing
two times.
TITLE and CHAPTER search TIME search
TITLE 01/35 CHAPTER 06/38
The “TITLE 01/35” indicates that the player is currently
playing title no. 1 of 35 titles. The “CHAPTER 06/38”
indicates that the player is currently playing chapter 6 of
38 chapters. The “TIME 00:20:12” indicates that the
current playback time is 20 minutes and 12 seconds into
the playback.
GOTO button one time and
TIME--:--:--
- - AUDIO SETU
To search by title, use the buttons to
highlight the first two digits of the “TITLE nn/nn” section.
Once highlighted, use the number keys on the remote to
enter the title you want to play. Presses
ENTER/PLAY to
complete your search selection.
To search by chapter, use the buttons to
highlight the first two digits of the “CHAPTER nn/nn”
section. Once highlighted, use the number keys on the
remote to enter the chapter you want to play. Presses
ENTER/PLAY to complete your search selection.
To search by time, use the buttons to
highlight the “TIME nn:nn:nn” section. Once highlighted,
use the number keys on the remote to enter the time
frame from which you want to play. Presses
to complete your search selection.
ENTER/PLAY
VCD/Audio CD DIRECT Functions
During a VCD or Audio CD playback, this unit only
supports the time search function.
1. Pressing the GOTO button during play will display the
OSD for VCD/Audio CD search.
2.
When the time is set, play from this position will start
immediately.
VCD Search Audio CD Search
GO TO _ _: _ _
NOTE:
Audio CD playback’s background is start up logo.
GO TO _ _: _ _
Digit Buttons
On the PBC menu, all items must be selected and
executed by using the number buttons only.
Input Switch Function
1. Press the / button thrice for full stop.
2. Press the INPUT button to switch between AUX-INPUT,
TV, VCR, TUNER and DVD mode. (Also shown on the
VFD.)
AUXTVVCRTUNERDVD AUX
NOTES:
AUX mode refers to P.12 Video In and Audio IN Terminals and
Connections.
TV mode refers to P.11 SCART Terminal. The sound of TV
program will appear from the amplifier.
VCR mode refers to P.12 SCART Terminal mode.
TUNER mode refers to P.29 TUNING OPERATION.
28
Digital Tuner with RDS PS Function/Amplifier System
TUNING OPERATION
After power-on, the machine will be at the DVD mode
with the AMP default setting. If you want to enjoy the
Tuner you can, when a DVD disc loaded on the disc
tray, press the
to stop the DVD Player, and then you press the
INPUT button on remote control four times to switch
Tuner mode.
NOTES:
When a VCD 2.0ver. disc loaded on the disc tray, you must press
DVD MENU button once to switch off the PBC function, then press
/ button twice to stop the DVD Player.
When a VCD1.0ver. CDDA or MP3 disc loaded on the disc tray,
you can otherwise press / twice to stop the DVD Player.
/ button on the remote control thrice
FM tuning and saving
Press INPUT button on the remote control to convert
the DVD player mode into Tuner Mode and the OSD
appears:
Under AUTO mode, press
search up to higher frequencies or downward to lower
frequencies, up to 20 frequencies broadcasting can
be tuned in and kept in correspondence with the
digitals 1 to 20.
When the
frequency is spotted, OSD appears e.g.:
/ pressed, the searching stops. Once one
(FF) or
(FR) to
--- TUNER MENU ---
-- FM MODE --
STATION: 1
FREQ: 101.70 MHz
MODE: AUTO
--- TUNER MENU ---
-- FM MODE --
STATION: 1
FREQ: 87.50 MHz
MODE: AUTO
Press SUBTITLE button on remote to convert
between auto and manual mode. The OSD appears:
--- TUNER MENU ---
-- FM MODE --
STATION: 1
SAVE TO 1
It also appears on the VFD:
FM 1 101.7 M
Each time one frequency is spotted there will be 3
seconds program broadcasting from it, and then the
searching goes on to the next frequency searching
until the digits 1 to 20 used up.
Under MANUAL mode, press
tune in up to a higher frequency or downward to a
lower frequency, up to 20 frequencies broadcasting
can be tuned in and kept in correspondence with the
digitals 1 to 20. Each time one frequency is going to
be spotted, the OSD appears e.g.:
(FF) or
(FR) to
FREQ: 87.50 MHz
--- TUNER MENU ---
MODE: MANUAL (or AUTO)
29
-- FM MODE --
And VFD appears:
STATION: 1
FREQ: 101.70 MHz
MODE: MANUAL
INPUT STATION
It also appears on the VFD:
INPUT
When the digit 1 pressed, OSD appears:
--- TUNER MENU ---
-- FM MODE --
STATION: 1
FREQ: 101.70 MHz
MODE: MANUAL
SAVE TO 1
Also the VFD appears:
SAVE TO 1
After a while, OSD appears:
-- FM MODE --
STATION: 1
FREQ: 101.70 MHz
MODE: MANUAL
FM 1 101.7 M
Press
again the FREQ goes up higher frequency.
The program of the frequency spotted goes to
broadcast. With the same way above go on to do the
next frequency searching. To get an optimum of
receiving broadcast you can press or for a fine
frequency adjustment of the program broadcasting,
and the result of which can be kept by pressing
ENTER/PLAY on the remote control.
After saving you can run any digit of 1~20, in each of which
one FREQ frequency broadcasting has been saved, to
listen to the broadcast of the FM frequencies
corresponding with what you have ever saved.
Press (NEXT) or (PREVIOUS) turns in next
higher or previous lower FREQ station.
NOTES:
You can save up to 20 frequencies.
Machine will save the frequencies for later use.
VFD of the machine will display the saved message being
played when the TUNER is on.
The FM frequency range: 87.5 – 108MHz
Frequency-step = 50KHz
For a good reception the FM antenna is required and that
have to be put in an optimum location.
RDS PS FUNCTION (Radio Data
System Program Service station name)
The name of the RDS station now being received
instead of the frequency will display on the VFD.
e.g.: BBC R3
NOTE:
This function can be used under Tuner mode only.
30
AMP Volume up/down Adjustment
Press the AMP VOL button on the remote control,
TV OSD appears:
ALL IIIIIIIIIIIIIIIIIIII 05
Press AMP VOL twice, OSD Appears:
LF IIIIIIIIIIIIIIIIIIII 05
Press AMP VOL thrice to seven times the OSD converts in
turn of RF, LS, RS, CN and SW;
RF IIIIIIIIIIIIIIIIIIII 05
LS IIIIIIIIIIIIIIIIIIII 05
RS IIIIIIIIIIIIIIIIIIII 05
CN IIIIIIIIIIIIIIIIIIII 05
SW IIIIIIIIIIIIIIIIIIII 05
Press AMP VOL continually it goes in cycle.
Press the VOL+ or VOL- button on the remote
control to change the Volume value of ALL, LF, RF,
LS, RS, CN or SW separately.
NOTES:
You can adjust the Volume, either, by turning the Volume knob in
the front panel of the machine.
The volume will automatically step up/down when the remote
button is pushed down for longer time.
After powering off the player and to turn on again, the player will
keep the volume of last setting.
31
Working With JPEG Files and MP3 Playback
Working with JPEG Files
What is a JPEG?
JPEG is short for the 'Joint Photographic Experts
Group', a group of experts nominated to produce
standards for continuous tone image coding.
The best known standard from JPEG is 10918-1
(ITU-T T.81), which is the first of a multi-part set
of standards for still image compression. This
allows you to create files (such as photographs,
drawings, and most clip-art) that can be archived
on a CD-R for viewing on the AD-1600/1700M,
computer, or the web.
WHAT IS PICTURE CD? HAT IS PICTURE CD?
This DVD player provides with the ability to playback
most JPEG files, that are commonly used for digital
cameras, and KODAK Picture CDs to view your photos
on a television in the comfort of your home from a CD-R!
PLAYING YOUR JPEG FILES
Normal Slide Show Presentation
When a JPEG disc is loaded into the player, a menu will
appear on screen. From the Play Mode shown on the
menu, select the “FOLDER” option using your direction
keys. Each picture in the current directory will be displayed
consecutively in a slideshow presentation and will be
seated to the most of your TV screen. Nine slideshow
“transition” modes are provided. Use
select.
PLAY MODE: FOLDER
SMART NAVI
ROOT
ROOT
JPG
MP3
ROOT
JPG
MP3
PLAY MODE: FOLDER
SMART NAVI
0
ATT00011 1
ATT 00014 2
ATTOOO17 3
ATT00020 4
BIGCAT 5
DVD MENU button to
Use numeric keys to designate the number of the picture,
from which the photos showing go on in the PLAY MODE
accordingly.
CHANGE THE PLAY MODE PLAYING
Press ► to enter the PLAY MODE selection and press
▼ or ▲ for selection of the play modes of REP-ONE,
SINGLE, FOLDER, FOLDER REP, DISC SCAN, DISC,
DISC REP, in sequence. And press ◄ back to Photo
selection.
ROOT
JPG
MP3
PLAY MODE: DISC REP
SMART NAVI
0
ATT00011 1
ATT00014 2
ATTOOO17 3
ATT00020 4
DIGITAL PHO 5
ROOT
DIGITAL PHO
SONY
PLAY MODE: SINGLE
SMART NAVI
0
SONY 53
ATT00011 17
ATT00014 36
ATTOOO17 37
ATT00020 52
Note: From the play-mode shown on the menu you may
also select the “SINGLE” option to view a picture
indefinitely until
(NEXT), (PREV), or ENTER/PLAY
buttons is selected.
IMAGE ROTATION
There are four modes to rotate a picture: Invert, Mirror,
Left, and Right. These operations are allowed only when a
picture is being displayed normally, and will be cancelled
automatically when a new picture is displayed. The arrow
key are used to select the different rotation modes:
Up ▲ -Invert/Normal Down ▼-Mirror/Normal
Left ◄ -Turn left Right ► -Turn right
32
ZOOM
This feature allows you to view a picture at the increments
of 25% to 200%. Press the
message (“Zoom On”) will verify your selection. Use
(FF) and (FR) buttons to control the amount of zoom in
and out. Press the direction keys to move the picture in any
direction. With “Zoom Off”, the picture is scaled to fit most
of your TV screen.
Note: When in the ZOOM mode, the slideshow transition
and image transformation features are disabled.
ZOOM button. An on screen
MENU
The DVD MENU key is used to display nine pieces of
thumbnail picture. From the stop position, press the
DVD MENU button. After it is enabled, up to nine
scaled-down thumbnails pictures will be displayed on the
screen. The
to display the next and previous nine pictures in the current
directory. Each of the nine pictures is numbered from 1-9.
By pressing a number key, the corresponding picture will
be enlarged to fill most of your TV screen and the digest
mode will be cancelled.
(NEXT) and (PREV) buttons can be used
MP3 Compatible Format
Start Playback
1. Place MP3 files recorded disc into the DVD player,
then it will enter the menu of the disc automatically.
Note:
There will be no second menu if all the contents of the songs are
recorded in the Root menu.
2. Please use arrow buttons for movement to
select a track (song) and press ENTER/PLAY button to
play.
Song Selection
Direct select with numeral keys
Press the numeral button directly from
to select the song what you want.
EX: If you want to select #25 song, you have to press
button twice and then press 5 button.
0 to 9 and +10
+10
Direct select with navigation keys
Under stop status, you can use
buttons for movement to select a title/song, then
ENTER/ PLAY button to confirm.
press
Fast Forward/Reverse Scan
Under the status of playback, you can use the
and (FR) buttons to fast forward and reverse scan.
When the
speed of playback changes in cycles of 2468
33
(FF) or (FR) button is pressed, the
arrow
(FF)
PLAY 2…
When the ENTER/PLAY button is pressed during fast
forward/reverse scan, normal playback will be resumed.
Skip Playback
Under the status of playback, you can use the (NEXT)
and (PREV) buttons to skip forward and reverse
playback.
Pause Playback
Pressing the / button once during playback will
pause the playback.
To resume normal play, please press the ENTER/PLAY
button.
Stop Playback
Press the / twice button to stop playback.
NOTES:
Sometimes it will not have menu if all MP3 files are burned in the
root directory (no sub-directory existence)
It sometimes takes a long time to load an MP3 disc; during this time
no other function (Stop or Eject) can be accessed.
Even if the disc contains several sub directories, only the directory
name of the folder where the MP3 files are stored is displayed.
NOTE:
When the unit is not in use, remove the disc and power off the
player.
ADDITIONAL INFORMATION
GLOSSARY
DTS®
DTS® stands for Digital Theater System. DTS® Digital
Surround is an encoded/decoded system, which
delivers 5.1 channels of “master quality” 48KHz/20-bit
audio sound.
AC-3 (Dolby® Digital)
A sound system developed by Dolby Laboratories, Inc.
that gives movie theatre ambience to audio output when
player is connected to a Dolby Digital 5.1 channel
processor or amplifier.
Pro Logic II
Pro Logic II is a matrix decoder. It creates a 5.1- channel
experience from a stereo input system. Pro Logic II
provides a stable open soundfield – good for music;
full-bandwidth stereo surround, 20-20kHz; minimum
alteration of the sound.
MPEG
The word “MPEG” is short for Moving Picture Experts
Group. This is an international standard for
compression of audio. MPEG1 used on VCDs conforms
to up to 2-channel stereo. MPEG 2 used on DVDs
conforms to up to 7.1-channel surround. By connecting
to an MPEG decoder or an AV amplifier with a built-in
MPEG decoder, the MPEG audio of DVD discs
recorded in this format can be played.
Dynamic Range
“Dynamic range” is the difference between the
maximum level and the minimum level of sounds.
Sounds on a movie originally designed for movie
theaters feature a very wide dynamic range, so
sometimes it is not suitable for home use. Depending on
the condition of your listening environment, Dynamic
Range function can reduce the instant sound effect
alteration of the movie while playing back. When
viewing movies at night, turn this function on to avoid
sudden loud sounds from disturbing your neighbors.
Subtitles
Subtitles are captions of language superimposed on
movies, etc. Up to 32 different subtitle languages can be
recorded on one DVD disc. The subtitle function can be
used to select the language of your choice.
Closed Captions
Closed Captions (CC) is a standardized method of
encoding text into an NTSC television signal. A TV can
display the text with a built-in decoder or by a separate
decoder. All TVs larger than 13 inches sold in the US
since 1993 have Closed Caption decoders. Closed
Captions can be carried on DVD, videotape, broadcast
TV, cable TV, and so on.
REGION MANAGEMENT INFORMATION
This DVD player is designed and manufactured to
respond to the Region Management Information recorded
on a DVD disc. If the region number described on the DVD
disc does not correspond to the region number of this DVD
player (The region number can be found on the rear panel
of the DVD player), this DVD player will not play the disc.
The OSD message “WRONG REGION” will show on the
TV screen. This player will play DVD discs made for “ALL”
regions. The illustration below shows the regions and
corresponding region numbers.
X REGION 1 USA & Canada
Y REGION 2 Europe, Japan, South Africa, Middle East
Z REGION 3 Southeast Asia
[ REGION 4 Central & South America, Australia, New Zealand
\ REGION 5 Former Soviet Union, India, Pakistan, Africa
] REGION 6 China
How to change the regional coding!
On the remote control press OPEN/CLOSE when the tray is
open key in 62818 + region (see above) 0 = Multi region. In
rare cases the DVD is blocked so it is unable to be played in
multi region DVD-Players. In these cases the regional coding
must be set to the region indicated on the software.
LICENSE
“Dolby” License
Manufactured under license from Dolby Laboratories.
“Dolby”, Pro Logic and the double-D symbol are
trademarks of Dolby Laboratories.
DTS License
"DTS" and "DTS Digital Out" are trademarks of Digital
Theater Systems, Inc.
Warning
The specifications and design of this product are
subject to change without notice, due to
improvement.
34
TROUBLE SHOOTING
Before requesting service for this unit, please check the following chart for possible causes and remedies. If the remedies
indicated in the chart below do not solve the problem, please consult your dealer for instructions.
Common Symptom Possible Cause Remedy
No power
Power turn off Auto power off function
Disc tray can't close Disc is not properly placed Replace the disc properly.
No playback
Unwanted mosaic-like garbage
display during playback
No audio
No Video
Remote control unit does not
work
Power cord is not properly connected to the
power outlet
Power is OFF
No disc is inserted (“no disc” will be shown on
screen).
Disc is upside down. ("No disc” is shown on
screen).
Dirty disk
Deformed disk
Condensation in unit
Poor disc
Video CD (MPEG1)
Slow or fast playback
Audio terminals are not connected.
TV volume is too low
Wrong AUDIO OUTPUT setting
Disconnection of video equipment
Wrong output setting of VIDEO OUTPUT
No batteries in remote control
Dead batteries
Remote control not being pointed at the
remote sensor
Make sure there is a connection between the power cord
and the outlet.
The power is automatically turned off after 20 minutes
have elapsed in the stop mode (auto power off function).
Turn the power back on.
Turn the power ON.
Insert a disc.
Reload disk. The label side should face upward.
Clean disc surface.
Replace disc.
Turn power on for 1-2 hours before using the unit.
Replace disc
Playback with DVD format
Press [PLAY] to resume normal playback
Check audio connections
Adjust TV volume
Check AUDIO OUTPUT setting
Check video connections
Check video output setting of VIDEO OUTPUT in
GENERAL SETUP
Put in new batteries
Replace batteries
Point the remote control at the remote sensor
DVD Symptom Possible Cause Remedy
Does not play, even when a title
is selected
Audio or subtitle language is
not the one selected during the
initial setting.
Setting language is not what
you want
Audio or Subtitle can not be
changed
The password for parental
rating has been forgotten
The video image brightness
fluctuates during playback
Can not fast scan during
playback of DVD movie.
Prohibited by the parental rating Confirm the PARENTAL setting.
The selected language does not exist in the
disc
Wrong OSD language setting Check the OSD language setting
The disc contains only one language
Some disc should be changed in DVD MENU.
The DVD player is connected to the television
via a video tape recorder
Some discs may have sections, which prohibit
skip or scan operations by users.
Select another language using [AUDIO] or [SUBTITLE]
Check the disc contents.
Use “3308” to override the forgotten password and
re-enter a new password.
Connect the DVD player directly to the TV, bypassing the
VCR.
No operation can be done during this problem.
35
SPECIFICATION
Power requirement AC100 V to 240V, 50/60 Hz
Power consumption (With Amplifier on) <180 W (approx. 9W at standby mode)
Power Amplifier Rated output (maximum) 5 x 60W music power
Output terminals (Speakers Load) 4ohms (of FR, FL, RS, LS, CENT);
Weight 4.2Kg / 9.25 pound.
Dimensions (W x D x H) 430x310x80 (mm) / 16.9 x 12.2 x 3.1 (Inch)
Operating temperature range +5 °C to +40 °C / 41
Operating relative humidity range 45 % to 75%
Video system PAL 625/50 Hz
S-video terminal
Composite video terminal 1 Vp-p±0.2 (75 Ω)
Horizontal resolution More than 500 Lines
Audio parameters (Amplifier)
1. First class laser product. Rating labels on the back of the machine
2. Danger: when the internal functions are out of order or
damaged, opening the cover may cause unseen radiation.
3. It should be kept away from direct sunlight.
4. Caution: Do not open the top cover. No internal part should
be maintained or serviced by the user. Qualified person
should carry out all such work.
Features and specifications are subject to change without notice.
Weight and dimensions are approximate.
Y output level 1 Vp-p±0.2 (75 Ω)
C output level 0.88 Vp-p±0.176 (75 Ω)
Frequency Response 20Hz ~ 20kHz ±1dB
Dynamic Range ≧70dB
S/N Ratio ≧80dB
CLASS 1
LASER PRODUCT
o
F ~ 104oF
36
Eltax DVD Receiver
DR-110
www.eltax.com
