SERVICE MANUAL
for
Eltax Atomic A15.2
Type: 10068
Eltax A/S.
Drejervej 2
DK 7490 Aulum
Denmark
Tel.: +45 9641 1500
Fax sales.: +45 9641 1501
www.eltax.com @: info@eltax.com
Sparepart:
World Wide United Kingdom Deutschland France
Eltax Service DK Eltax UK Eltax Deutschland Eltax France
Tel.: +45 9641 1599 Tel.:+44(0)1327860789 Tel.:+49(0)461 28080 Tel.:+33(0)466 680626
Fax.: +45 9641 1598 Fax.:+44(0)1327861058 Fax.: +49(0)461 29966 Fax.:+33(0)466 680636
@: Service@eltax.com @: uk@eltax.com @: deutschland@eltax.com @: france@eltax.com
Netherlands Belgium Luxembourg
Eltax Benelux Eltax Benelux Eltax Benelux Eltax Italy
Tel.:+32(0)2 354 53 63 Tel.:+32(0)2 354 53 63 Tel.:+32(0)2 354 53 63 Tel.: +39 011 6603780
Fax.:+32(0)2 351 03 96 Fax.:+32(0)2 351 03 96 Fax.:+32(0)2 351 03 96 Fax.: +39 011 6603780
@: benelux@eltax.com @: benelux@eltax.com @: benelux@eltax.com @: italy@eltax.com
Italy
A
A
Increase of On/St. by circuit sensitivity. Serial 01, 02
Attention!!
This update may only be performed by skilled service personnel.
Add parallel over resistor R27 , a resistor 560Ω/½W. Total value 470Ω
Add parallel over capasitor C14 , a capasitor 3,3uF/16V Total value 4,7uF/16V
C14
R27
d a resistor
560Ω ½W
positiv
negative
d a capasitor
3,3uF/16V
Sparepart List.
Item no. Type
03937 Amplifier A-15.2R, black
13602 Subwoofer 380mm Black/Black 4ohm
03939 Remote Frontpanel Atomic X.2, black
03941 Remote Control Atomic.2, black
06626 Mainscord UK-ClassII - IEC 320
06633 Mainscord EU-ClassII - IEC 320
When ordering spareparts please indicate the serial number of the equipment.
