Edition: 1.12.2009 · BA 880-EN
Original Operating Instructions
C-VLR
C-VLR 60 | 100 | 120 | 150 | 251
C-VLR 250 | 300 | 400 | 500
C-Serie
C-Series
Klaue
Claw
Table of contents
Table of contents
1 Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Supplier documentation and accompanying documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Directives, standards, laws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 Symbols and meaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 Technical terms and meaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.8 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Warning instruction markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Unacceptable operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Personal qualifi cations and training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.6 Safety-conscious work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.7 Safety notes for the operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.8 Safety instructions for installing, commissioning and maintenance . . . . . . . . . . . . . . . . . . . . . . 9
2.9 Guarantee conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Transport, storage and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.1 Unpack and check the delivery condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.2 Lifting and transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.1 Ambient conditions for storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Set up and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Data plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Areas of application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1 Preparing for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.3 Connecting pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.4 Regulating and relief valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.5 Filling with lubricating oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.6 Connecting the motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6 Commissioning and decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1.1 Checking the rotation direction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2 Decommissioning/ storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3 Re-commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
2
Table of contents
7 Maintenance and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.1 Ensuring operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.2 Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.2.1 Changing the oil and lubricating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.2.2 Air fi ltering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.2.3 Coupling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3 Repair/ Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.4 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8 Malfunctions: Causes and elimination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
9 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
3
Foreword
1 Foreword
1.1 Principles
These operating instructions:
• are a part of the following contact free running claw vacuum pumps, models C-VLR 60,
C-VLR 100, C-VLR 120, C-VLR 150, C-VLR 250,
C-VLR 251, C-VLR 300, C-VLR 400 and
C-VLR 500.
• describe how to use them safely and properly in
all life phases.
• must be available where the equipment is used.
1.2 Target group
The target group for these instructions is technically
trained specialists.
1.3 Supplier documentation and accompanying documents
Document Contents No.
Operating Instructions BA 880-EN
Supplier documentation
Declaration of Conformity C 0080-EN
Declaration of harmlessness 7.7025.003.17
Spare parts‘ list Spare parts document E 880
Data sheet Technical data and graphs D 880
Info sheet Storage guidelines for machines I 150
Manufacturer’s declaration
EU Directive 2002/95/EG (RoHS)
—
1.4 Abbreviations
Fig. Figure
C-VLR vacuum pump
3
/h pumping capacity
m
mbar (abs.) Final vacuum, operating vacuum
1.5 Directives, standards, laws
See Conformity Declaration
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
4
1.6 Symbols and meaning
Symbol Explanation
Condition, pre-requisite
#### Instructions, action
a), b),... Instructions in several steps
Results
Foreword
[-> 14]
Cross reference with page number
Information, note
Safety symbol
Warns of potential risk of injury
Obey all the safety instructions with this symbol in order to avoid injury
and death.
1.7 Technical terms and meaning
Term Explanation
Machine Pump and motor combination ready to be connected
Motor Pump drive motor
Vacuum pump Machine to create a vacuum
Claw Machine‘s design or active principle
Pumping capacity
Vacuum pump volume fl ow related to the condition in the suction connection
Final pressure (abs.) The maximum vacuum that a pump reaches when the suction opening is
closed. Given as absolute pressure.
Permanent vacuum The vacuum or the suction range at which the pump operates perma-
nently.
The permanent vacuum or intake pressure is ≥ than the fi nal vacuum
and < than the atmospheric pressure.
Noise emission
The noise emitted at a specifi c loading given as a fi gure, sound pressure
level dB(A) as per EN ISO 3744.
1.8 Copyright
Passing on or copying this document, using and
providing information on its contents are prohibited
unless expressly permitted. Contraventions will lead
to claims for damages.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
5
Safety
2 Safety
The manufacturer is not responsible for damage if
you do not follow all of this documentation.
2.1 Warning instruction markings
Warning Danger level Consequences if not obeyed
DANGER
WARNING
CAUTION
NOTICE
2.2 General
immediately imminent danger Death, severe bodily injury
possible imminent danger Death, severe bodily injury
possible hazardous situation Slight bodily injury
possible hazardous situation Material damage
These operating instructions contain basic instructions for installation, commissioning, maintenance
and inspection work which must be obeyed to ensure the safe operation of the machine and prevent
physical and material damage.
The safety instructions in all sections must be taken
into consideration.
The operating instructions must be read by the
responsible technical personnel/ operator before
installing and commissioning and must be fully understood. The contents of the operating instructions
must always be available on site for the technical
personnel / operator. Instructions fi xed directly onto
the machine must be obeyed and must always remain legible. This applies for example to:
• Symbols for connections
• Data and motor data plate
• Instruction and warning plates
The operator is responsible for observing local regulations.
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
6
Safety
2.3 Designated use
The machine must only be operated in such areas
as are described in the operating instructions:
• only operate the machine in a technically perfect
condition
• do not operate the machine when it is only partially assembled
• the machine must only be operated at an ambient temperature and suction temperature of
between 5 and 40°C. Please contact us for
temperatures outside this range.
• the machine may convey, compress or extract
the following media:
• all non-explosive, non-infl ammable, non-ag-
gressive and non-poisonous dry gases and
gas air mixtures
2.4 Unacceptable operating modes
• extracting, conveying and compressing explosive, infl ammable, aggressive or poisonous media, e.g. dust as per ATEX zone 20-22, solvents
as well as gaseous oxygen and other oxidants,
water vapour, liquids or solid materials
• using the machine in non-commercial plants if
the necessary precautions and protective measures have not been taken in the plant
• installing in environments that are at risk of explosions
• using the machine in areas with ionising radiation
• modifi cations to the machine and accessories
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
7
Safety
2.5 Personal qualifi cations and training
• Ensure that people entrusted with working on
the machine have read and understood these
operating instructions before starting work,
particularly the safety instructions for installation,
commissioning, maintenance and inspection
work.
• Manage the responsibilities, competence and
monitoring of staff
• all work must only be carried out be technical
specialists:
• Installation, commissioning, maintenance
and inspection work
• Working with electricity
• personnel being trained to work on the ma-
chine must be supervised by technical specialists only
2.6 Safety-conscious work
The following safety regulations apply in addition
to the safety instructions and intended use listed in
these instructions:
• Accident prevention regulations, safety and operating regulations
• the standards and laws in force
2.7 Safety notes for the operator
• hot parts of the machine must not be accessible
during operation or must be fi tted with a guard
• People must not be endangered by the free
extraction or discharge of pumped media
• Risks arising from electrical energy must be
eliminated.
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
8
Safety
2.8 Safety instructions for installing, commissioning and maintenance
• The operator will ensure that any installation,
commissioning and maintenance work is carried out by authorised, qualifi ed specialists who
have gained suffi cient information by an in-depth
study of the operating instructions.
• Only work on the machine when it is idle and
cannot be switched on again
• Ensure that you follow the procedure for decommissioning the machine described in the operating instructions.
• Fit or start up safety and protective devices
again immediately after fi nishing work.
• Conversion work or modifi cations to the machine are only permissible with the manufacturer’s consent.
• Only use original parts or parts approved by the
manufacturer. The use of other parts may invalidate liability for any consequences arising.
• Keep unauthorised people away from the machine
2.9 Guarantee conditions
The manufacturer’s guarantee or warranty will no
longer apply in the following cases:
• Improper use
• Not complying with these instructions
• Operation by insuffi ciently qualifi ed staff
• Using spare parts that have not been approved
by Gardner Denver Schopfheim GmbH
• Unauthorised modifi cations to the machine or
the accessories supplied by Gardner Denver
Schopfheim GmbH
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
9
Transport, storage and disposal
3 Transport, storage and disposal
3.1 Transportation
3.1.1 Unpack and check the delivery condition
a) Unpack the machine on receipt and check for
transport damage.
b) Notify the manufacturer of transport damage im-
mediately
c) Dispose of the packaging in accordance with the
local regulations in force.
3.1.2 Lifting and transporting
a) Select the lifting device suitable for the total
b) Ensure that the machine cannot tip and fall.
c) Do not stop under a suspended load.
d) Put the goods to be conveyed on a horizontal
Lifting device/ Transporting with a crane
1
a) Tighten the eyebolts (Fig. 1/1) fi rmly.
b) The machine must be suspended on the eyebolt
WARNING
Death or limbs crushed as a result of the items
being transported falling or tipping over.
When transporting with the lifting device remem-
ber:
weight to be transported.
base.
WARNING
Bodily injury resulting from improper operation
a) Loads crosswise to the ring level are not per-
mitted.
b) Avoid impact stress.
using the lifting device for lifting and transporting.
Fig. 1 Lifting and transporting
1 Eyebolt
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
10
3.2 Storage
Transport, storage and disposal
NOTICE
Material damage caused by improper storage.
Ensure that the storage area meets the following
conditions:
a) dust free
b) vibration free
3.2.1 Ambient conditions for storage
Ambient conditions Value
Relative humidity 0% to 80%
Lagertemperatur -10°C to +60°C
The machine must be stored in a dry environment
with normal air humidity. It should not be stored for
more than 6 months.
see Info “Machine storage guidelines”, Page 4
3.3 Disposal
WARNING
Danger from infl ammable, corrosive or poisonous substances.
Machines that come into contact with hazardous substances must be decontaminated before
disposal.
When disposing ensure the following:
a) Collect oils and grease separately and dispose
of in accordance with the local regulations in
force.
b) Do not mix solvents, limescale removers and
paint residues
c) Remove components and dispose of them in
accordance with the local regulations in force.
d) Dispose of the machine in accordance with the
national and local regulations in force.
e) Parts subject to wear and tear (marked as such
in the spare parts list) are special waste and
must be disposed of in accordance with the
national and local waste laws.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
11
Set up and operation
4 Set up and operation
4.1 Setup
Q MN
E
P
H
A
C
F
E
F
F
F
E
IK
S
O
B
P
1
Fig. 2 Vacuum pump C-VLR 60
A Vacuum connection
B Exhaust air outlet
C Vacuum regulating valve
E Cooling air inlet
Cooling air outlet
F
Oil fi lling point
H
Oil sight glass
I
Oil discharge point
K
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
12
M Oil recommendation plate
N Data plate
O Rotation direction plate
P
P
1
Q
S Suction fi lter
Z
Drive motor
Motor data plate
hot surfaces > 70S°C
Outlet silencer
Z
Set up and operation
1
Q
A
CS
F
O
E
E
F
F
E
I K
NMO
H
P
P
1
Fig. 3 Vacuum pump C-VLR 150
A Vacuum connection
B Exhaust air outlet
C Vacuum regulating valve
E Cooling air inlet
Cooling air outlet
F
Oil fi lling point
H
Oil sight glass
I
Oil discharge point
K
Z
M Oil recommendation plate
N Data plate
O Rotation direction plate
P
Drive motor
P
Motor data plate
1
hot surfaces > 70°C
Q
Anschlusskasten
S
1
Outlet silencer
Z
B
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
13
Set up and operation
B
Z
Q
Fig. 4 Vacuum pump C-VLR 300
A Vacuum connection
B Exhaust air outlet
C Vacuum regulating valve
E Cooling air inlet
Cooling air outlet
F
Oil fi lling point
H
H
S
1
A
C
O
P
F
E
E
F
F
E
IK
I
Oil sight glass
Oil discharge point
K
P
Drive motor
hot surfaces > 70°C
Q
Anschlusskasten
S
1
Outlet silencer
Z
4.1.1 Data plate
1 Type/ Size (mechanical version)
1
3
4 52
2 Year of construction
3 Motor design
4 Serial number
5 Item no.
6 Final pressure (abs.)
Typ VTR 100 (01)
Bauj./Nr. 09
2849751
1027610116
150 mbar (abs.)
100 / 120 m³/h
3~ Mot.
7 Pumping capacity 50 Hz/ 60 Hz
EN 60034
S1 3,00/ 3,60 kW
1410 / 1700 min
-1
8 Speed 50 Hz/60 Hz
9 Motor output 50 Hz/ 60 Hz
6
78910
10 Operating mode
Fig. 5 Data plate (example)
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
14
Set up and operation
4.2 Description
The C-VLR model range has a connecting thread on the suction side and an exhaust silencer on the pressure side. With the C-VLR 60 the incoming air is cleaned by a fi lter cartridge. The C-VLR 100-500 have a
micro fi lter on the suction side.
The ZEPHYR C-VLR is a double shaft rotary piston vacuum pump in which the claws roll off against each
other contact free and dry. The counter-rotating claw rotors are synchronised by a gear pair in the gearbox.
The synchronous gearbox gear wheels and the bearing on the motor side are lubricated with oil. These
components are in a gearbox that also contains the oil supply. Oil conveying devices always ensure that the
bearings and the gear wheels are suffi ciently supplied with oil at all permissible speeds. The feed chamber
has no sealants or lubricants. The C-VLR 400 and 500 sizes have grease lubricated bearings on the B side.
The gearbox and the compression chamber are separated from each other by special seals. The gearbox is
sealed from the outside with shaft seals and O rings, the compressor chamber with piston rings. Between
the two there is also another atmospherically ventilated area that can be loaded with sealing gas (special
version).
The C-VLR 100-500 is enclosed in an insulation hood.
In order to dissipate compression heat, the cooling air is sucked through between the machine and the hood
using drum fan that sucks in the fresh cooling air (Fig. 3/E) and discharges the heated air out of the cooling
air outlet (Fig. 3/F). The ZEPHYR VLR is driven by standard fl anged three phase motors via a coupling (with
an elastomer component).
A vacuum regulating valve (Fig. 2/C) is used to set the vacuum to the required values.
4.3 Areas of application
These contact free running claw vacuum pumps C-VLR can be operated constantly at any pressure between
atmospheric and an inlet pressure of:
100 mbar (abs.) ➝ C-VLR 60 / 150
150 mbar (abs.) ➝ C-VLR 100 / 120
200 mbar (abs.) ➝ C-VLR 250 / 251 / 300
250 mbar (abs.) ➝ C-VLR 400 / 500
The pumping capacity with unrestricted suction is 60, 100, 120, 150, 211, 235, 300, 385 and 500 m
3
/h at
50 Hz. Data sheet D 880 shows the dependency of the pumping capacity on the intake pressure.
If the unit is switched on more frequently (at regular
intervals of about 12 times an hour (C-VLR 60 - 150)
or 10 times an hour (C-VLR 250 - 500)) at higher
ambient temperatures and intake temperatures, the
excess temperature limit of the motor winding and
the bearings may be exceeded.Please contact the
manufacturer should the unit be used under such
conditions.
If it is installed in the open air the unit must be protected from environmental infl uences, (e.g. by a protective roof).
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
15
Installation
5 Installation
5.1 Preparing for installation
Check the following points:
• Machine freely accessible from all sides
• Do not close ventilation grids and holes
• Suffi cient room for installing and removing pipes
and for maintenance work, particularly for installing and dismantling the machine
• No external vibration effects
• Do not suck any hot exhaust air from other machines into the cooling system.
The oil fi lling point (Fig. 2/H... 4/H), oil sight glasses (Fig. 2/I... 4/I) and oil outlets (Fig. 2/K... 4/K)
must be easily accessible.
The cooling air inlets (Fig. 2/E... 4/E) and cooling air outlets (Fig. 2/F... 4/F) must be at least 30 cm
from adjacent walls. Cooling air coming out must not be sucked in again.
For maintenance work there must be a minimum of 40 cm in front of the inlet fi lter (Fig. 2/S) and
the inlet silencer (Fig. 3/S
, 4/S1)
1
5.2 Installation
NOTICE
The machine may only be operated when it is
set up horizontally.
Material damage resulting from the machine
tipping over and falling.
When installed at more than 1000 m above sea
level a reduction in power is noticeable. In this
case we would ask you to contact us.
Contamination in the intake air
To protect the machine the operator should install
appropriate fi lters on the suction side.
Ensure that the foundation complies with
the following conditions:
• Level and straight
• The bearing surface must be designed to be
able to take the weight of the machine.
It is possible to install the machine on a fi rm base without anchoring. When installing on a substructure we recommend fi xing with fl exible buffers.
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
16
Installation
5.3 Connecting pipes
a) Vacuum connection at (Fig. 2/A... 4/A).
NOTICE
Material damage resulting from the forces and
torques of the pipes on the unit being too high.
Only screw pipes in by hand.
The pumping capacity of the vacuum pump
is reduced if the suction pipe is too narrow
and/or too long..
b) The discharged air can be blown out through
the exhaust silencer (ZSZ) at (Fig. 2/B... 4/B) or
conducted away using a hose or a pipe.
NOTICE
Length of the connection pipes
With connection pipes that have the same pipe
cross section as the machine connection and are
more than 3m long, a non-return valve especially
for the purpose must be installed in order to avoid
reverse operation when the machine has stopped.
Exhaust air must not be restricted
No blocking systems must be built into the
exhaust air pipe (max. pressure difference 30
mbars). When the exhaust air pipe is connected it
must be checked regularly for impurities.
5.4 Regulating and relief valve
The vacuum can be set by turning the control knob
(Fig. 2/C... 4/C) as shown on the symbol fi tted to the
button.
NOTICE
Do not operate without the standard regulating
and relief valve.
If the permissible vacuum is exceeded (see data
plate) the machine may be damaged.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
17
Installation
5.5 Filling with lubricating oil
a) Fill the lubricating oil (for suitable types see
“Maintenance”) for the gear wheels and oil fi lling point (Fig. 3/H) up to the middle of the sight
glasses (Fig. 3/I).
b) Close the oil fi lling point.
5.6 Connecting the motor
DANGER
Danger of death if the electrical installation has
not been done professionally.
The electrical installation must only be done by a
qualifi ed electrician observing EN 60204. The
operating company has to provide the main
switch.
a) The motor‘s electrical data is given on the data
plate (Fig. 3/N) or on the motor data plate (Fig. 3/
). The motors comply with DIN EN 60034
P
1
and are in protection class IP 55 and insulation
class F. The appropriate connection diagram is
located in the motor‘s terminal box (not for the
plug connection version). The motor data must
be compared with the data of the existing mains
network (current type, voltage, network frequency, permitted current value).
b) Connect the motor via the plug connection or
the motor protection switch (for safety reasons,
a motor protection switch is required and the
connecting cable must be installed via a cable
fi tting to provide strain relief).
We recommend using motor protection switches
with delayed switch off, depending on possible
excess current. Temporary excess current may
occur when the machine is started cold.
NOTICE
Power supply
The conditions at the installation location must match
the information on the motor data plate.
Without derating the following is permissible:
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
18
• ± 5% Voltage deviation
• ± 2% Frequency deviation
6 Commissioning and decommissioning
6.1 Commissioning
Commissioning and decommissioning
WARNING
Improper use
May lead to severe or fatal injuries. Therefore be
sure to obey the safety instructions.
CAUTION
Hot surfaces
When the machine is at operating temperature the
surface temperatures on the components (Fig. 2/
Q... 4/Q) may go above 70°C.
You must avoid touching the hot surfaces
(marked with warning plates).
CAUTION
Noise emission
The highest noise pressure levels measured as
per EN ISO 3744 are given in Section 9.
When spending a long time in the vicinity of the
running machine use ear protectors to avoid
permanent damage to your hearing.
NOTICE
Wait until the machine stops.
The machine must only be switched on again
after it stops.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
19
Commissioning and decommissioning
6.1.1 Checking the rotation direction
The intended direction of rotation of the drive
shaft is shown by the rotary direction arrow
(Fig. 2/O... 4/O) on the motor fl ange.
a) Start the motor briefl y (max. two seconds) to
check the direction of rotation. When looking at
the motor fan, it must rotate anti-clockwise.
NOTICE
Incorrect direction of rotation
Operating in the wrong direction of rotation leads
to damage to the machine.
Use a phase sequence indicator to check the direction of rotation (clockwise rotating fi eld).
6.2 Decommissioning/ storing
Stop the machine
a) Switch the machine off.
b) If available close the cut off device in the suction
and pressure pipe.
c) Disconnect the machine from the electricity
source.
d) Depressurise the machine:
Open the pipes slowly.
The pressure reduces slowly.
e) Remove the pipes and hoses.
f) Seal the connections for suction and discharge
nozzles with adhesive foil.
see also Section 3.2.1, Page 11
6.3 Re-commissioning
a) Check the condition of the machine (cleanliness,
cabling etc.).
For installation see Section 5 Page 16
For commissioning see Section 6.1 Page 19
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
20
7 Maintenance and repair
Maintenance and repair
DANGER
Danger of death from touching live parts.
Before maintenance work disconnect the machine
by pressing the main switch or unplugging it and
ensure that it cannot be turned on again.
WARNING
Hot surfaces and equipment
During maintenance work there is the danger of
getting burnt on hot components (Fig. 2/Q) and
by the machine lubricating oil.
Wait for the machine to cool down.
7.1 Ensuring operational safety
Regular maintenance work must be carried out in order to ensure operational safety.
Maintenance intervals also depend on the operational demands on the machine.
With any work observe the safety instructions described in Section 2.8 “Safety notes for installation, com-
missioning and maintenance”.
The whole unit should always be kept in a clean condition.
7.2 Maintenance work
Interval Maintenance to be carried out Section
monthly Check the pipes and screws for leaks and to ensure they are
—
seated properly and if necessary seal again or tighten up.
monthly Check the terminal box and cable inlet holes for leaks and if
—
necessary re-seal.
monthly Clean the regulating valve, the ventilation slots on the ma-
—
chine and the motor cooling ribs.
monthly Check the oil level 7.2.1
5.000 h Changing the oil
5.000 h C-VLR 400 / 500: Lubricate the bearing on the side facing
away from the motor
monthly/ every 6 months C-VLR 60: Clean or replace fi lter cartridge 7.2.2
depending on how dirty the
C-VLR 100 - 500: Clean the micro fi lter
discharged medium is
at least once a year Check for coupling wear 7.2.3
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
21
Maintenance and repair
7.2.1 Changing the oil and lubricating
MH
I K
Fig. 6 Changing the oil
Oil fi lling point
H
Oil sight glass
I
Oil discharge point
K
M Oil recommendation plate
Changing the oil:
NOTICE
Always change the oil when the machine is at
operating temperature and in an atmospherically
ventilated area.
If it is not completely emptied the amount that can
be refi lled is reduced.
The waste oil must be disposed of in compliance with
the local environmental protection regulations.
If you are going to use another oil type, empty the
oil removing device housing and oil cooler
completely.
The oil level in the sight glasses (Fig. 6/I) must be
checked every month.
The machine must be switched off and vented to atmospheric pressure to top up the oil.With clean operations the oil must be changed after every 5,000
operating hours..
The oil viscosity must comply with ISO VG 150 as
per DIN 51519.
Designation as per DIN 51502: CLP HC 150.
We recommend the following oil brand: GEARLUBE 150 or equivalent oils by other manufacturers
(also see oil recommendation plate (Fig. 6/M)).
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
22
LL KIHM
Maintenance and repair
1
Fig. 7 Lubrication
H
Oil fi lling point
Oil sight glass
I
Oil discharge point
K
L
Grease nipple
Lubrication plate
M
1
Lubrication:
The bearings on the C-VLR 400 / 500 must be lubricated with 30 g of grease every 5,000 operating
hours or after no more than 2 years (see the two
grease nipples (Fig. 7/L)).
We recommend Klüber PETAMO GY 193 or other
similar greases (see lubrication plate (Fig. 7/M
)).
1
NOTICE
This lubrication interval applies when operating the
machine at an ambient temperature of 20° C. At
40°C this interval is halved.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
23
Maintenance and repair
7.2.2 Air fi ltering
f
2
m
2
Fig. 8 Vacuum tight suction fi lter
f
Filter cartridge
2
m2 Tension clamps
NOTICE
Insuffi cient maintenance on the air fi lter
The power of the machine lessens and damage may
occur to the machine.
Vacuum tight suction fi lter (C-VLR 60)
The fi lter cartridge (Fig. 8/f
) for the suction fi lter
2
(Fig. 2/S) must be cleaned monthly or more often
depending on the level of contamination by purging
from the inside outwards. In spite of cleaning the
fi lter its separation effi ciency will continue to deteriorate. Therefore the fi lter should be replaced every six
months.
Filter cartridge (Fig. 8/f2) can be removed after undoing the tension clamps (Fig. 8/m2).
NOTICE
Do not damage the fi lter cartridges when cleaning them.
1
Fig. 9 Purging fi lter cartridge
1 Filter cartridge
2
Compressed air
Micro fi lters (C-VLR 100 - 500)
The micro fi lter inbuilt in the intake silencer (Fig. 3/
S
, 4/S1) must be cleaned or replaced more or less
1
often depending on how dirty the medium in it is by
washing or blowing through.
WARNING
Danger of injury when dealing with compressed air
When blowing through with compressed air, solid
particles may be carried along or powder dust swirling around may cause injury to the eyes.
Therefore, when cleaning with compressed air always
wear goggles and a dust mask.
2
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
24
7.2.3 Coupling
q
m
Fig. 10 Coupling C-VLR 60
Coupling sprocket
k
Motor
m
n
Housing
1
Coupling half on the motor side
q
Screws
s
4
s
5
Maintenance and repair
The coupling sprocket (Fig. 10/k, 11/k)) is subject to
wear and must be checked regularly (at least once a
k
s
4
n
1
year).
CAUTION
Defective coupling sprocket
Defective sprockets may lead to the rotor shaft
breaking.
To check the coupling switch the motor
(Fig. 10/m, 11/m) off and ensure that it cannot be
switched on again.
C-VLR 60
Undo the screws (Fig. 10/s
) on the housing fl ange
4
(Fig. 10/n1) . Remove the motor axially with the
half of the coupling on the motor side (Fig. 10/q)
and suspend with the lifting device. If the sprocket
(Fig. 10/k) is damaged or worn, then replace it.
C-VLR 100 - 5 00
Undo the screws (Fig. 11/s5) on the motor fl ange.
Remove the motor with the coupling half on the
motor side (Fig. 11/q) from the fanhousing (Fig. 11/
n2) axially and suspend using a lifting tool. If the
sprocket (Fig. 11/k) is damaged or worn, then replace it. The fan (Fig. 11/v) should also be checked
for damage from time to time and replaced if necessary.
n
2
NOTICE
m
Fig. 11 Coupling C-VLR 100- 500
k
Coupling sprocket
m Motor
Fan housing
n
2
Coupling half on the motor side
q
Screws
s
5
v Fan
Frequent starting up and high ambient temperature
The service life of the sprocket (Fig. 10/k, 11/k) is
v
reduced.
q
k
Re-assemble in reverse order.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
25
Maintenance and repair
7.3 Repair/ Service
a) For on site repair work the motor must be
disconnected from the mains by a qualifi ed
electrician so that it cannot be started up again
accidentally. For repairs use the manufacturer,
its branch offi ces or authorised dealers. Please
contact the manufacturer for the address of the
service centre responsible for you (see Manufacturer‘s address).
NOTICE
For each machine that is sent to an Elmo Rietschle
Service centre for inspection, maintenance or repair, a
fully completed, signed declaration of harmlessness
must be enclosed.
The declaration of harmlessness is part of the
supplier‘s documentation.
Fig. 12 Clearance certifi cate 7.7025.003.17
b) After a repair or re-commissioning, the actions
listed under „Installation“ and „Commissioning“
must be carried out as for initial commissioning.
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
26
7.4 Spare parts
Maintenance and repair
Order spare parts in accordance with the:
• Spare parts list:
E 880/1 ➝ C-VLR 100 / 250 300
E 880/2 ➝ C-VLR 400 / 500
E 880/3 ➝ C-VLR 60
E 880/4 ➝ C-VLR 150
E 880/5 ➝ C-VLR 251 (01)
• Download the PDF fi le:
http://www.gd-elmorietschle.com
➝ Downloads
➝ Product Documents
➝ C-Series ➝ Spare Parts
• Parts subject to wear and gaskets are indi-
cated separately on the list.
• Web site:
http://www.service-er.de
• Select the type, size and design.
Fig. 13 Spare parts list (example)
NOTICE
Only use original spare parts or parts approved by
the manufacturer. The use of other parts may lead to
malfunctions and invalidate liability or the guarantee
for any consequences arising.
Fig. 14 Web site
http://www.service-er.de
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
27
Malfunctions: Causes and elimination
8 Malfunctions: Causes and elimination
Fault Cause Troubleshooting Important
Machine is switched
off by the motor protection switch
Pumping capacity is
insuffi cient
Mains voltage/ Frequency
does not correspond with the
motor data
Connection to motor terminal
board is not correct
Motor protection switch is not
set correctly
Motor protection switch is
triggered too quickly
The regulating valve is dirty so
that the permissible vacuum
value is exceeded
The suction fi lter is dirty Clean or replace the suction
The suction pipe is too long or
too narrow
Check by qualifi ed electrician Section 5.5
Use a motor protection switch
with an overload-dependent
delayed switch off that takes
into consideration the short
term excess current at start
up (version with short circuit
and overload trigger as per
VDE 0660 Part 2 orIEC 947-4)
Clean or replace the regulating valve
fi lter
Check the hose or the pipe Section 5.3
Section
7.2Section 7.4
Section 7.2.2
Section 7.4
Machine or system leaking Check the pipework and
screw connections for leaks
and to ensure that they are
fi rmly seated.
Section 7.2
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
28
Malfunctions: Causes and elimination
Fault Cause Troubleshooting Important
Final pressure (max.
vacuum) is not
reached
Machine or system leaking Check the pipework and
screw connections for leaks
and to ensure that they are
Section 7.2
fi rmly seated.
Machine gets too hot Ambient or intake temperature
is too high
Cooling air supply is obstructed
Ensure it is being used properly
Check environmental conditions
Section 2.3
Section 5.1
Clean ventilation slots Section 7.2
The regulating valve is dirty so
that the permissible vacuum
Clean or replace the regulating valve
Section 7.2
Section 7.4
value is exceeded
The machine makes
a abnormal noise
Deposits on the rotary piston Clean the working space and
the rotary piston
The regulating valve is vibrat-
Replace the valve Section 7.4
Elmo Rietschle
Service
ing
Please contact Elmo Rietschle Service for other malfunctions or those that cannot be eliminated.
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
29
Technical Data
9 Technical Data
C-VLR 60 100 120 150 251
Sound pressure level (max.)
EN ISO 3744
Tolerance± 3 dB(A)
dB(A)
50 Hz 78 82 81 79 81
60 Hz 80 85 83 82 84
50 Hz 95 94 93 97 92
Sound power level dB(A)
60 Hz 95 97 96 99 97
Weight * kg 51 105 119 125 140
Length * mm 625 661 717 826 1060
Width mm 431 540 540 533 635
Height mm 295 360 360 375 375
Vacuum connection G 1 G 1
Exhaust air outlet G 1 G 1
/
2
1
/
2
G 11/
G 11/
2
2
G 11/
G 11/
2
2
G 2
G 2
1
Correct amount of oil l 0,4 0,55 0,55 0,6 0,6
C-VLR 250 300 400 500
Sound pressure level (max.)
EN ISO 3744
Tolerance± 3 dB(A)
dB(A)
50 Hz 80 80 86 88
60 Hz 81 81 89 89
50 Hz 92 92 96 100
Sound power level dB(A)
60 Hz 94 94 100 101
Weight * kg 213 263 330 381
Length * mm 1060 1060 1059 1201
Width mm 716 716 744 764
Height mm 525 525 525 525
Vacuum connection G 2 G 2 G 3 G 3
Exhaust air outlet G 2 G 2 G 3 G 3
Correct amount of oil l 0,75 0,75 0,75 0,75
* The length and the weight may differ from the information listed here depending on the motor manufac-
turer.
| www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH
30
Technical Data
You will fi nd more technical data on the data sheet
D 880
• Download the PDF fi le:
D 880 ➝ C-VLR 60 - C-VLR 500
• Download the pdf fi le:
http://www.gd-elmorietschle.com
➝ Downloads
➝ Product Documents
➝ C-Series ➝ Data Sheets
NOTICE
Subject to technical changes.
Fig. 15 Data sheet (example)
www.gd-elmorietschle.com © Gardner Denver Schopfheim GmbH, Gardner Denver Deutschland GmbH |
31
Elmo Rietschle is a brand of
Gardner Denver‘s Industrial Products
Division and part of Blower Operations.
www.gd-elmorietschle.com
er.de@gardnerdenver.com
Gardner Denver
Schopfheim GmbH
Roggenbachstraße 58
79650 Schopfheim · Deutschland
Tel. +49 7622 392-0
Fax +49 7622 392-300
Hereby the manufacturer
confirms:
EC - declaration of conformity 2006/42/EC
Gardner Denver Schopfheim GmbH
Postfach 1260
D-79642 Schopfheim
that the machine:
of the:
Claw vacuum pump
Series: C-VLR
Type: C-VLR 60, C-VLR 100, C-VLR 120,
C-VLR 150, C-VLR 250, C-VLR 251,
C-VLR 300, C-VLR 400, C-VLR 500,
C-VLR 1000
is conform to the regulations of the guideline indicated above.
The following harmonized and national standards and specifications are applied:
EN 1012-1:2010
EN 1012-2:1996+A1:2009 Compressors and vacuum pumps — Safety requirements — Part 2:
Compressors and vacuum pumps — Safety requirements — Part 1:
Compressors
Vacuum pumps
These declarations of conformity are invalid when the machine has been modified without prior approval by us and the approval has been documented in writing.
Name and address of the EC person in
charge for documentation
Gardner Denver Schopfheim GmbH
Postfach 1260
D-79642 Schopfheim
Gardner Denver Schopfheim GmbH
Schopfheim, 1.8.2011
Dr. Friedrich Justen, Director Engineering
C_0080_EN
Safety declaration form
s
.
s
/
A
.
3
S
for vacuum pumps and component
7.7025.003.17
Page 1 of 1
Gardner Denver Schopfheim GmbH
Roggenbachstr. 58, 79650 Schopfheim Phone: +49/(0)7622/392-0 Fax: +49/(0)7622/392-300
Repairs and/or maintenance of vacuum pumps and components will only be carried out if a declaration has been
filled in correctly and completely
.
If not, the repair work cannot be started and delays will result.
This declaration must only be filled in and signed by authorised qualified staff
2. Reason for the submission1. Type of vacuum pumps/ components
Type description:
Machine number
Order number:
Delivery date:
3. Condition of vacuum pumps/ component
4. Contamination of the vacuum pumps
Was this being operated? YES NO components when in use
Which lubrication was used? Toxic YES NO
Corrosive YES NO
Was the pump/ component emptied? Microbiological*) YES NO
(Product/Consumables) YES NO Explosive*) YES NO
Has the pump/ component been cleaned and decontaminaRadioactive*) YES NO
other YES NO
YES
Cleaning agent:
Cleaning method:
*) Microbiological, explosive or radioactively contaminated vacuum pumps/ components will only be accepted
with proof that they have been cleaned properly.
Type of toxic substance or process-related, dangerous reaction products with which the vacuum pumps/
components came into contact:
Trade name, manufacturer's Chemical Hazard
product name name class substances are released accidents
1
2
3
4
Personal protection measures:
ction to be taken if toxic First aid in the event of
Hazardous decomposition products when subjected to thermal load
YES NO
Which?
5. Legally binding declaration
We swear that the information in this declaration is accurate and complete and that I, the undersigned, am in a
position to judge this. We are aware that we are liable to the contractor for damage caused by incomplete and
inaccurate information. We undertake to release the contractor from any damage claims from third parties arising
from incomplete or incorrect information. We are aware that, regardless of this declaration, we are directly liable
to third parties including in particular the contractor's staff entrusted with handling or repairing the product
Company:
Street: Post code/ Town:
Phone: Fax:
Name (in capitals) Position:
Date:
Legally binding signature:
TOS no. / Index: 7.7025.003.17 / 0
Office responsible: G
Company stamp:
File management: ..\7702500317.xl
Gardner Denver Schopfheim GmbH Postfach 1260 D-79642 Schopfheim
