Discover the
professional’s choice.
Commercial Faucets
™
Commercial Faucets Crafted
In The Elkay Tradition
Table of Contents
Food Service 3-8
Since 1920 Elkay’s mission has remained
constant … provide better customer service, higher
quality and more innovation than our competitors.
Our faucets are no exception. Every Elkay faucet
is crafted from the best grade materials and is
precision engineered for maximum
performance. Best of all, there
is an Elkay commercial faucet for
virtually any ap
plication, all
with the style, functionality
and quality associated with
the Elkay name.
Our extensive faucet offering and ability to
meet a wide range of commercial
requirements is enhanced with
interchangeable components,
including spouts, handles and
aerators. This versatility makes
it easy to configure an Elkay
faucet to your specific needs, as
well as replace components if these
needs ever change.
Lavatory 9-11
Scrub and Hand Wash 12-18
Service and Utility 19-21
Classroom 22-24
General Use 25-28
Accessories 29-31
the core of most Elkay commercial faucets is our
At
new ceramic disk cartridge which is designed to be
interchangeable with other faucet brands. Compared
to conventional faucet cartridges, our ceramic disks
provide smoother and easier operation, a longer
expected life and are well suited for both high or lowpressure water areas.
From healthcare facilities and schools… to restaurants
and office buildings, El
kay has the ideal faucet for every
application. To find the Elkay faucet that’s right for you,
simply go to the section of this catalog that best
describes your type of installation. Our most popular
models are identified in large, green type.
NSF/ANSI 61 Certified
2
The Elkay Difference
Interchangeable spouts are available in a wide
array of styles and sizes to help create just the right
faucet for essentially any application
Interchangeable handle options meet ADA
requirements and are offered in wristblade and
lever styles
2.2 GPM vandal-resistant aerator standard with
1.5 and .5 GPM insert and key included for low-flow
specified applications.
Ceramic disk cartridge technology provides
g-lasting, superior performance and ease-of-operation
lon
Durable polished chrome finish stands up well
to heavy-use environments and looks attractive in
any setting
Solid brass construction throughout helps ensure
years of service and NSF/ANSI 61 compliance
Discover the professional’s choice™.
Visit us at elkayusa.com for most current
warranty information.
Elkay reserves the right to change materials, design and specifications without notice.
FOOD SERVICE
Elkay Food Service Faucets provide functionality with style and are available for a
variety of functions throughout the commercial kitchen. Choose from pot-fillers and
pre-rinses, as well as wall-mounted and deck-mounted faucets with an assortment of
handle and spout styles. Count on Elkay to make finding the right faucet for any food
service application an easy task!
Food Service
Spout Options:
Arc Tube
8", 10" and 12"
Tube Spout
8"
Food Service
Handle Options:
Gooseneck
4", 5" and 8"
High Arc
8" and 10"
Double Swing
20"
4" Wristblade Handle2" Lever Handle
6" Wristblade Handle
3
8" Centerset Wall Mount
■
Choice of 3 handle options
■
Choice of 2 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
1/2" NPT female inlets
FOOD SERVICE
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
ARC TUBE
LK940AT08L2H 8" 2" Lever Standard 6.25
LK940AT08L2S 8" 2" Lever Shut Off Valve 6.5
LK940AT08T4H 8" 4" Wristblade Standard 6.5
LK940AT08T4S 8" 4" Wristblade Shut Off Valve 6.75
LK940AT08T6H 8" 6" Wristblade Standard 6.5
LK940AT08T6S 8" 6" Wristblade Shut Off Valve 7
LK940AT10L2H 10" 2" Lever Standard 6.25
LK940AT10L2S 10" 2" Lever Shut Off Valve 6.5
LK940AT10T4H 10" 4" Wristblade Standard 6.5
LK940AT10T4S 10" 4" Wristblade Shut Off Valve 6.75
LK940AT10T6H 10" 6" Wristblade Standard 6.5
LK940AT10T6S 10" 6" Wristblade Shut Off Valve 7
LK940AT12L2H 12" 2" Lever Standard 5.5
LK940AT12L2S 12" 2" Lever Shut Off Valve 5.75
LK940AT12T4H 12" 4" Wristblade Standard 5.5
LK940AT12T4S 12" 4" Wristblade Shut Off Valve 6
LK940AT12T6H 12" 6" Wristblade Standard 5.75
LK940AT12T6S 12" 6" Wristblade Shut Off Valve 6
DOUBLE SWING
LK940DS20L2H 20" 2" Lever Standard 7.75
LK940DS20L2S 20" 2" Lever Shut Off Valve 8
LK940DS20T4H 20" 4" Wristblade Standard 8
LK940DS20T4S 20" 4" Wristblade Shut Off Valve 8.25
LK940DS20T6H 20" 6" Wristblade Standard 8
LK940DS20T6S 20" 6" Wristblade Shut Off Valve 8.25
LK940AT08L2H
LK940AT10T4S
LK940AT12T6H
LK940DS20T4S
4
LK940HA08L2H
LK940TS08T4H
8" Centerset Wall Mount
■
Choice of 3 handle option
■
Choice of 2 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
LK940TS08L2H
Model Number Reach Handle Inlet WT. LBS.
LK940HA08L2H 8" 2" Lever Standard 6.25
LK940HA08L2S 8" 2" Lever Shut Off Valve 6
LK940HA08T4H 8" 4" Wristblade Standard 6.5
LK940HA08T4S 8" 4" Wristblade Shut Off Valve 6.75
LK940HA08T6H 8" 6" Wristblade Standard 6.5
LK940HA08T6S 8" 6" Wristblade Shut Off Valve 7
LK940HA10L2H 10" 2" Lever Standard 6.5
LK940HA10L2S 10" 2" Lever Shut Off Valve 6.75
LK940HA10T4H 10" 4" Wristblade Standard 6.5
LK940HA10T4S 10" 4" Wristblade Shut Off Valve 6.75
LK940HA10T6H 10" 6" Wristblade Standard 6.75
LK940HA10T6S 10" 6" Wristblade Shut Off Valve 7
LK940TS08L2H 8" 2" Lever Standard 6.25
LK940TS08L2S 8" 2" Lever Shut Off Valve 6.5
LK940TS08T4H 8" 4" Wristblade Standard 6.5
LK940TS08T4S 8" 4" Wristblade Shut Off Valve 6.75
LK940TS08T6H 8" 6" Wristblade Standard 6.5
LK940TS08T6S 8" 6" Wristblade Shut Off Valve 7
■
1/2" NPT female inlets
Spout Shipping
HIGH ARC
TUBE SPOUT
FOOD SERVICE
LK943C
Model LK943C
8" Centerset
Wall Mounted Pre-Rinse
■
2" lever handles
■
Self closing spray valve
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
44" flexible stainless steel hose
■
Insulated handle
■
Chrome finish
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
Shipping WT: 13 lbs.
5
3"-8" Adjustable Centers
■
Choice of 3 handle options
■
Choice of 5 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
1/2" NPT female inlets with 2" offset
FOOD SERVICE
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
ARC TUBE
LK945AT08L2T 8" 2" Lever 2" Offset 5.75
LK945AT08T4T 8" 4" Wristblade 2" Offset 6
LK945AT08T6T 8" 6" Wristblade 2" Offset 6.25
LK945AT10L2T 10" 2" Lever 2" Offset 6
LK945AT10T4T 10" 4" Wristblade 2" Offset 6
LK945AT10T6T 10" 6" Wristblade 2" Offset 6
LK945AT12L2T 12" 2" Lever 2" Offset 5
LK945AT12T4T 12" 4" Wristblade 2" Offset 5
LK945AT12T6T 12" 6" Wristblade 2" Offset 5.25
DOUBLE SWING
LK945DS20L2T 20" 2" Lever 2" Offset 7
LK945DS20T4T 20" 4" Wristblade 2" Offset 7.25
LK945DS20T6T 20" 6" Wristblade 2" Offset 7.5
GOOSENECK
LK945GN04L2T 4" 2" Lever 2" Offset 6
LK945GN04T4T 4" 4" Wristblade 2" Offset 6
LK945GN04T6T 4" 6" Wristblade 2" Offset 6.25
LK945GN05L2T 5" 2" Lever 2" Offset 6
LK945GN05T4T 5" 4" Wristblade 2" Offset 6
LK945GN05T6T 5" 6" Wristblade 2" Offset 6.25
LK945GN08L2T 8" 2" Lever 2" Offset 5
LK945GN08T4T 8" 4" Wristblade 2" Offset 5.5
LK945GN08T6T 8" 6" Wristblade 2" Offset 5.5
HIGH ARC
LK945HA08L2T 8" 2" Lever 2" Offset 5.75
LK945HA08T4T 8" 4" Wristblade 2" Offset 6
LK945HA08T6T 8" 6" Wristblade 2" Offset 6
LK945HA10L2T 10" 2" Lever 2" Offset 6
LK945HA10T4T 10" 4" Wristblade 2" Offset 6
LK945HA10T6T 10" 6" Wristblade 2" Offset 6.25
TUBE SPOUT
LK945TS08L2T 8" 2" Lever 2" Offset 6
LK945TS08T4T 8" 4" Wristblade 2" Offset 6
LK945TS08T6T 8" 6" Wristblade 2" Offset 6.25
LK945AT08L2T
LK945AT10T6T
LK945DS20T4T
LK945GN08L2T
LK945HA08T4T
LK945TS08L2T
6
LK810GN04T6
LK811AT08L2
LK810HA08T4
8" Centerset
with Exposed Deck
■
Choice of 3 handle options
■
Choice of 4 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
LK810AT08L2
Model Number Reach Handle Spray WT. LBS.
LK810AT08L2 8" 2" Lever 6
LK810AT08T4 8" 4" Wristblade 6.25
LK810AT08T6 8" 6" Wristblade 6.5
LK811AT08L2 8" 2" Lever ■ 6.75
LK810AT10L2 10" 2" Lever 6.25
LK810AT10T4 10" 4" Wristblade 6.5
LK810AT10T6 10" 6" Wristblade 6.5
LK810AT12L2 12" 2" Lever 5.25
LK810AT12T4 12" 4" Wristblade 5.5
LK810AT12T6 12" 6" Wristblade 5.75
LK810GN04L2 4" 2" Lever 6
LK810GN04T4 4" 4" Wristblade 6.25
LK810GN04T6 4" 6" Wristblade 6.5
LK810GN05L2 5" 2" Lever 6.25
LK810GN05T4 5" 4" Wristblade 6.25
LK810GN05T6 5" 6" Wristblade 6.5
LK810GN08L2 8" 2" Lever 5.5
LK810GN08T4 8" 4" Wristblade 5.75
LK810GN08T6 8" 6" Wristblade 6
LK810HA08L2 8" 2" Lever 6
LK810HA08T4 8" 4" Wristblade 6.25
LK810HA08T6 8" 6" Wristblade 6.5
LK810HA10L2 10" 2" Lever 6.25
LK810HA10T4 10" 4" Wristblade 6.5
LK810HA10T6 10" 6" Wristblade 6.75
LK810TS08L2 8" 2" Lever 6
LK810TS08T4 8" 4" Wristblade 6.25
LK810TS08T6 8" 6" Wristblade 6.5
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
Spout Side Shipping
ARC TUBE
GOOSENECK
HIGH ARC
TUBE SPOUT
FOOD SERVICE
LK810TS08L2
7
Single Hole
with Concealed Deck
■
Dual control
■
2" lever handles
■
Choice of 3 spout options
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
FOOD SERVICE
■
Replacement cartridge 45924C for hot
Spout Shipping
Model Number Reach Handle WT. LBS.
ARC TUBE
LK500AT08L2 8" 2" Lever 5.5
LK500AT10L2 10" 2" Lever 5.5
LK500AT12L2 12" 2" Lever 4.75
GOOSENECK
LK500GN08L2 8" 2" Lever 4.75
HIGH ARC
LK500HA08L2 8" 2" Lever 5.5
LK500HA10L2 10" 2" Lever 5.5
LK500AT08L2
8" Centerset
with Concealed Deck
■
Choice of 2 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator
with optional 1.5 and .5 GPM insert
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
Adjustable mounting up to 8" spread
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
ARC TUBE
LK801AT08L2 8" 2" Lever ■ 6.25
GOOSENECK
LK801GN08L2 8" 2" Lever ■ 5.5
LK500HA08L2LK500GN08L2
LK801AT08L2
LK801GN08L2
8
LAVATORY FAUCETS
Elkay Lavatory Faucets are designed to withstand the frequent and often times harsh
use of commercial restroom applications. Select from twin handle and single control
4" centerset models with and without pop up… or choose an elegant 8" centerset
designer faucet, depending on your requirements and preference. For lav faucets that
look as good as they perform, look to Elkay!
Lavatory Faucet
Handle Options:
4" Wristblade Handle2" Lever Handle
Single Control models available with 4" or 7" Wristblade Handle
6" Wristblade Handle
9
LAVATORY FAUCETS
4" Centerset with Exposed
Deck and Integral Spout
■
Choice of 4 handle options
■
Quarter turn ceramic disc cartridge
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Solid brass construction
■
Chrome finish
■
Replacement cartridge P29121NL for cold
■
Replacement cartridge P29122NL for hot
Pop Shipping
Model Number Handle Up WT. LBS.
TWIN HANDLE
LK402L2 2" Lever 3.75
LK402T4 4" Wristblade 3.75
LK402T6 6" Wristblade 4
LK403L2 2" Lever ■ 4.75
LK403T4 4" Wristblade ■ 4.75
LK403T6 6" Wristblade ■ 5
SINGLE CONTROL
LK422L4 4" Lever 5
LK422L7 7" Lever 5
LK423L4 4" Lever ■ 6
LK423L7 7" Lever ■ 6
LK402L2
LK403T4
LK422L7
10
8" Centerset
with Concealed Deck
■
Choice of 3 handle options
■
Cast fixed spout
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator
standard with 1.5 and .5 GPM insert
■
Chrome finish
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
Adjustable mounting up to 8" spread
Spout Shipping
Model Number Reach Handle WT. LBS.
CAST FIXED
LK804CF06L2 6" 2" Lever 7.25
LK804CF06T4 6" 4" Wristblade 7.25
LK804CF06T6 6" 6" Wristblade 7.5
LK804F 8" Fancy Lever 6
LK804CF06L2
LK804F
LK652
LK656
LK651
LK654
Metered Deck Mount
■
Self-closing metering ceramic cartridge
■
Polished chrome finish
■
Solid brass construction
■
Vandal-resistant aerator with key
■
2.2 GPM / 8.3L / min at 60 P.S.I.G
■
0.25 Gal / cycle max.
Spout Shipping
Model Number Reach Hole Mounting WT. LBS.
CAST FIXED
LK651 5" 3 Hole 8" cc 6.2
LK652 4-1/8" 3 Hole Centerset 3.8
LK654 4-1/8" 1 Hole 2.4
LK656 4" 2 Hole 4" cc 4.2
Electronic Deck Mount
■
Adjustable hot and cold operation
■
Modular one-piece construction with all
concealed components above deck
■
Double infrared sensors with automatic
setup and indicator light
■
Automatic self-adapting sensor technology
■
Low battery indicator
■
.5 GPM / 1.9 LPM vandal-resistant spray head
LAVATORY FAUCETS
LK736B
LK737B
Spout Shipping
Model Number Reach Power WT. LBS.
CAST FIXED
LK736AC 5-9/16" AC 5.6
LK736B 5-9/16" Battery 5.6
Electronic Deck Mount
■
For pre-tempered operation
■
Splash-proof circuit control module
■
Sensor range adjustment screw
■
Low battery LED indicator light
■
Variable time out settings
■
Bak-chek tee for hot/cold supply
■
Below deck control box
■
.5 GPM / 1.9 LPM vandal-resistant spray head
■
4" centerset mounting
Spout Shipping
Model Number Reach Power WT. LBS.
CAST FIXED
LK737AC 4-9/16" AC 5.6
LK737B 4-9/16" Battery 5.6
11
SCRUB AND HAND WASH
Elkay’s extensive line of Scrub and Handwash Faucets is specially designed to
service the healthcare industry. Our offering includes sensor operated electronic models
and pedal valves, as well as conventional manual faucets, ideal for hospitals, doctors’
offices and other healthcare related facilities. Elkay Scrub and Handwash Faucets…
just what the doctor ordered!
Scrub and Hand Wash
Spout Options:
12
Arc Tube
8", 10" and 12"
nd Hand Wash
Scrub a
Handle Options:
Gooseneck
4", 5" and 6"
High Arc
8" and 10"
4" Wristblade Handle2" Lever Handle
6" Wristblade Handle
Tube Spout
8"
LKB721C
Electronic Deck Mount
■
Dual power AC and battery
■
Adjustable sensor range
■
Gooseneck spout
■
2.0 gpm laminar flow aerator
■
Chrome plated finish
■
Solid brass construction
■
Vandal-resistant and water-resistant
sensor control module
■
Adjustable shut-off delay
■
Adjustable time-out feature
Spout Shipping
Model Number Reach Power WT. LBS.
LKB721C 5-3/8" AC/Battery 7
SCRUB AND HAND WASH
LKB722C
Electronic Wall Mount
■
Dual power AC and battery
■
Adjustable sensor range
■
Gooseneck spout
■
2.0 gpm laminar flow aerator
■
Chrome plated finish
■
Solid brass construction
■
Vandal-resistant and water-resistant
sensor control module
■
Adjustable shut-off delay
■
Adjustable time-out feature
Spout Shipping
Model Number Reach Power WT. LBS.
LK B722C 5-3/8" AC/Battery 8
13
4" Centerset
with Exposed Deck
■
Choice of 3 handle options
■
Choice of 4 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
LK406GN04L2
SCRUB AND HAND WASH
Model Number Reach Handle WT. LBS.
Spout Shipping
ARC TUBE
LK406AT08L2 8" 2" Lever 4.75
LK406AT08T4 8" 4" Wristblade 5
LK406AT08T6 8" 6" Wristblade 5.25
LK406AT10L2 10" 2" Lever 4.75
LK406AT10T4 10" 4" Wristblade 5
LK406AT10T6 10" 6" Wristblade 5.25
LK406AT12L2 12" 2" Lever 4
LK406AT12T4 12" 4" Wristblade 4
LK406AT12T6 12" 6" Wristblade 4.25
GOOSENECK
LK406GN04L2 4" 2" Lever 4.75
LK406GN04T4 4" 4" Wristblade 5
LK406GN04T6 4" 6" Wristblade 5
LK406GN05L2 5" 2" Lever 4.75
LK406GN05T4 5" 4" Wristblade 5
LK406GN05T6 5" 6" Wristblade 5.25
LK406GN08L2 8" 2" Lever 4
LK406GN08T4 8" 4" Wristblade 4.25
LK406GN08T6 8" 6" Wristblade 4.5
HIGH ARC
LK406HA08L2 8" 2" Lever 4.75
LK406HA08T4 8" 4" Wristblade 4.75
LK406HA08T6 8" 6" Wristblade 5
LK406HA10L2 10" 2" Lever 5
LK406HA10T4 10" 4" Wristblade 5
LK406HA10T6 10" 6" Wristblade 5.25
TUBE SPOUT
LK406TS08L2 8" 2" Lever 4.75
LK406TS08T4 8" 4" Wristblade 5
LK406TS08T6 8" 6" Wristblade 5
LK406AT08T4
LK406GN08L2
LK406HA08T6
LK406TS08L2
14
LK500AT08T4
LK500GN05T6
Single Hole
with Concealed Deck
■
Dual Control
■
Choice of 3 handle options
■
Choice of 3 spout options
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
LK500GN05L2
Spout Shipping
Model Number Reach Handle WT. LBS.
ARC TUBE
LK500AT08L2 8" 2" Lever 5.5
LK500AT08T4 8" 4" Wristblade 5.5
LK500AT08T6 8" 6" Wristblade 5.75
LK500AT10L2 10" 2" Lever 5.5
LK500AT10T4 10" 4" Wristblade 5.5
LK500AT10T6 10" 6" Wristblade 5.75
LK500AT12L2 12" 2" Lever 4.75
LK500AT12T4 12" 4" Wristblade 5.5
LK500AT12T6 12" 6" Wristblade 5.75
GOOSENECK
LK500GN04L2 4" 2" Lever 5.5
LK500GN04T4 4" 4" Wristblade 5.5
LK500GN04T6 4" 6" Wristblade 5.75
LK500GN05L2 5" 2" Lever 5.5
LK500GN05T4 5" 4" Wristblade 5.75
LK500GN05T6 5" 6" Wristblade 6
LK500GN08L2 8" 2" Lever 4.75
LK500GN08T4 8" 4" Wristblade 5
LK500GN08T6 8" 6" Wristblade 5
HIGH ARC
LK500HA08L2 8" 2" Lever 5.5
LK500HA08T4 8" 4" Wristblade 5.75
LK500HA08T6 8" 6" Wristblade 6
LK500HA10L2 10" 2" Lever 5.5
LK500HA10T4 10" 4" Wristblade 5.75
LK500HA10T6 10" 6" Wristblade 6
SCRUB AND HAND WASH
LK500HA08L2
15
8" Centerset Wall Mount
■
Choice of 3 handle options
■
Gooseneck spout
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
1/2" NPT female inlets
■
Optional external shut-off valve available
SCRUB AND HAND WASH
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
GOOSENECK
LK940GN04L2H 4" 2" Lever Standard 6.25
LK940GN04L2S 4" 2" Lever Shut Off Valve 6.5
LK940GN04T4H 4" 4" Wristblade Standard 6.5
LK940GN04T4S 4" 4" Wristblade Shut Off Valve 6.75
LK940GN04T6H 4" 6" Wristblade Standard 6.5
LK940GN04T6S 4" 6" Wristblade Shut Off Valve 7
LK940GN05L2H 5" 2" Lever Standard 6.5
LK940GN05L2S 5" 2" Lever Shut Off Valve 6.75
LK940GN05T4H 5" 4" Wristblade Standard 6.5
LK940GN05T4S 5" 4" Wristblade Shut Off Valve 6.5
LK940GN05T6H 5" 6" Wristblade Standard 6.75
LK940GN05T6S 5" 6" Wristblade Shut Off Valve 7
LK940GN08L2H 8" 2" Lever Standard 5.5
LK940GN08L2S 8" 2" Lever Shut Off Valve 6
LK940GN08T4H 8" 4" Wristblade Standard 6
LK940GN08T4S 8" 4" Wristblade Shut Off Valve 6.25
LK940GN08T6H 8" 6" Wristblade Standard 6
LK940GN08T6S 8" 6" Wristblade Shut Off Valve 6.25
LK940GN04L2H
LK940GN05T6S
16
LK940GN08T4H
LK800AT12T6
LK800GN04T6
LK801GN08L2
LK800HA08L2
LK800AT08L2
8" Centerset
with Concealed Deck
■
Choice of 3 handle options
■
Choice of 4 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator standard
with 1.5 and .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
Adjustable mounting up to 8" spread
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
ARC TUBE
LK800AT08L2 8" 2" Lever 6.25
LK800AT08T4 8" 4" Wristblade 6.5
LK800AT08T6 8" 6" Wristblade 6.5
LK800AT10L2 10" 2" Lever 6.25
LK800AT10T4 10" 4" Wristblade 6.5
LK800AT10T6 10" 6" Wristblade 6.75
LK800AT12L2 12" 2" Lever 5.5
LK800AT12T4 12" 4" Wristblade 5.5
LK800AT12T6 12" 6" Wristblade 5.75
GOOSENECK
LK800GN04L2 4" 2" Lever 6.25
LK800GN04T4 4" 4" Wristblade 6.25
LK800GN04T6 4" 6" Wristblade 6.5
LK800GN05L2 5" 2" Lever 6.25
LK800GN05T4 5" 4" Wristblade 6.5
LK800GN05T6 5" 6" Wristblade 6.75
LK800GN08L2 8" 2" Lever 5.5
LK800GN08T4 8" 4" Wristblade 5.75
LK800GN08T6 8" 6" Wristblade 6
LK801GN08L2 8" 2" Lever ■ 5.5
HIGH ARC
LK800HA08L2 8" 2" Lever 6.25
LK800HA08T4 8" 4" Wristblade 6.25
LK800HA08T6 8" 6" Wristblade 6.5
LK800HA10L2 10" 2" Lever 6.25
LK800HA10T4 10" 4" Wristblade 6.5
LK800HA10T6 10" 6" Wristblade 6.75
TUBE SPOUT
LK800TS08L2 8" 2" Lever 6.25
LK800TS08T4 8" 4" Wristblade 6.25
LK800TS08T6 8" 6" Wristblade 6.5
SCRUB AND HAND WASH
LK800TS08T4
17
Spouts
■
For use with Elkay knee and
foot pedal valves (see below)
■
Solid brass construction
■
Chrome plated finish
■
Vandal-resistant anti-hose aerator
Shipping
Model Number Spout Reach WT. LBS.
SCRUB AND HAND WASH
BACK MOUNT
LK395A 8-1/4" Swing 3
DECK MOUNT
LK396A 10-3/4" Rigid 3
Knee and Foot Pedal Valves
■
Chrome plated finish
■
Hands-free operation for
enhanced sanitation
■
LK397C and LK398C includes
mounting package (stops, valves
and wall flanges)
LK395A
LK396A
Shipping
Model Number Mounting Activation WT. LBS.
LK397C Wall Knee 14
LK398C Wall Foot 9
LK399A Floor Foot 3
18
LK397C
LK398C
LK399A
SERVICE AND UTILITY
Elkay Service and Utility Faucets are available for a wide range of institutional
applications. A choice of inlets, as well as spout options that include bucket hooks and
vacuum breakers, make this versatile group of faucets the answer to a large array of
installation requirements. When it comes to facility maintenance, it’s Elkay at your service!
Service and Utility
Spout Options:
3" Bucket Hook
7" Bucket Hook
8" Arc Tube
7" Vented
19
8" Centerset Wall Mount
■
Choice of 3 handle options
■
Choice of 3 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
Rough Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
1/2" NPT female inlets
■
Optional external shut-off valve available
on selected models
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
SERVICE AND UTILITY
LK940BR03L2H 3" 2" Lever Standard 7.5
LK940BR07L2H 7" 2" Lever Standard 8.75
LK940BP03L2H 3" 2" Lever Standard 7
LK940BP03L2S 3" 2" Lever Shut Off Valve 7.5
LK940BP03T4H 3" 4" Wristblade Standard 7.25
LK940BP03T4S 3" 4" Wristblade Shut Off Valve 7.5
LK940BP03T6H 3" 6" Wristblade Standard 7.5
LK940BP03T6S 3" 6" Wristblade Shut Off Valve 7.75
LK940BP07L2H 7" 2" Lever Standard 8
LK940BP07L2S 7" 2" Lever Shut Off Valve 8.25
LK940BP07T4H 7" 4" Wristblade Standard 8.25
LK940BP07T4S 7" 4" Wristblade Shut Off Valve 8.25
LK940BP07T6H 7" 6" Wristblade Standard 8.5
LK940BP07T6S 7" 6" Wristblade Shut Off Valve 8.75
LK940AT08L2H 8" 2" Lever Standard 6.25
LK940VS07L2H 7" 2" Lever Standard 7
LK940VS07L2S 7" 2" Lever Shut Off Valve 7.5
LK940VS07T4H 7" 4" Wristblade Standard 7.25
LK940VS07T4S 7" 4" Wristblade Shut Off Valve 7.5
LK940VS07T6H 7" 6" Wristblade Standard 7.5
LK940VS07T6S 7" 6" Wristblade Shut Off Valve 7.75
BUCKET HOOK
ARC TUBE
VENTED SPOUT
LK940BR03L2H
LK940BR07L2H
LK940AT08L2H
LK940VS07L2H
Single Hole Wall Mount
■
Cross arm handle
■
Chrome plated brass
■
1/2" IPS female inlets
■
Sold as a pair or individually
Model Number Description WT. LBS.
LK69C Pair includes (1) LK69CH and (1) LK69CP 2
LK69CH 3/4" threaded hose outlet 1
LK69CP Plain outlet 1
20
Shipping
LK69CP
LK69CH
LK945VS07L2T
3"-8" Adjustable Centers
Wall Mount
■
Bucket hook spout
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
■
Replacement cartridge 45924C for hot
■
1/2" NPT female inlets
LK945BP03L2T
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
BUCKET HOOK
LK945BP03L2T 3" 2" Lever 2" Offset 6.5
LK945BP07L2T 7" 2" Lever 2" Offset 7.5
VENTED SPOUT
LK945VS07L2T 7" 2" Lever 2" Offset 6.75
LK945VS07T4T 7" 4" Wristblade 2" Offset 6.75
LK945VS07T6T 7" 6" Wristblade 2" Offset 7
SERVICE AND UTILITY
LK945BP07L2T
LK400
4"- 83/8" Adjustable Centers
Wall Mount
■
2" lever handles
■
Bucket hook spout
■
Solid brass construction
■
Rough chrome finish
■
1/2" NPT female inlets
Shipping
Model Number Description Inlet WT. LBS.
LK400 3/4" threaded hose outlet Standard 4
8" Centerset Wall Mount
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
Rough chrome finish
LKB940C
Spout Shipping
Model Number Reach Handle Inlet WT. LBS.
BUCKET HOOK
LKB940C 7" 2" Lever 1/2" Offset 5.6
21
Elkay Classroom Faucets are available in a complete
range of models designed especially for use on standard
drinking fountain and sink applications. Rigid or swing
spout, deck or concealed undermount, two-wing hot and
cold or single-wing hot and cold, we have a model to meet
every arrangement. For faucets that belong at the head of
the class, rely on Elkay!
CLASSROOM
Single Hole Deck Mount
with Dual Handles
■
High spout design
■
Die-cast metal wing handles
■
Heavy chrome plate tubular brass spout
■
Removable cartridge
■
Cast brass body
■
3/8" O.D. copper tubing
LKDC2088
Shipping
Model Number Spout Reach Handles WT. LBS.
LKDC2088 5-1/8" rigid Dual Mixing 5
LKDC2223 6-5/8" swing Dual Mixing 5
Single Hole Concealed Deck Mount
with Single Handle
■
High spout design
■
Die-cast metal wing handle
■
Heavy chrome plate tubular brass spout
■
Removable cartridge
■
Cast brass body
■
1/2" I.P. connections
Spout Shipping
Model Number Reach Handle WT. LBS.
LKDC2085 5-1/8" rigid Right Side 4
LKDC2085L 5-1/8" rigid Left Side 4
LKDCVR2085* 5-1/8" rigid Right Side 4
LKDCVR2085L* 5-1/8" rigid Left Side 4
* VR models feature vandal resistant aerator, handle screw and
factory installed anti-rotation pins
LKDC2085
LKDC2223
LKDC2085L
22
LK535AT08T4
LK535GN08T6
LK535HA08L2
LK535GN04L2
Single Hole with
Single Control
■
Choice of 3 handle options
■
Choice of 3 spout styles
■
Quarter turn ceramic disc cartridge
■
Solid brass construction
■
2.2 GPM vandal-resistant aerator
standard with .5 GPM insert included
■
Chrome finish
■
Includes spout swing restriction pin
■
Replacement cartridge 45923C for cold
Spout Shipping
Model Number Reach Handle WT. LBS.
ARC TUBE
LK535AT08L2 8" 2" Lever 4.5
LK535AT08T4 8" 4" Wristblade 4.5
LK535AT08T6 8" 6" Wristblade 4.75
LK535AT10L2 10" 2" Lever 4.5
LK535AT10T4 10" 4" Wristblade 4.5
LK535AT10T6 10" 6" Wristblade 4.75
LK535AT12L2 12" 2" Lever 3.75
LK535AT12T4 12" 4" Wristblade 3.75
LK535AT12T6 12" 6" Wristblade 4
GOOSENECK
LK535GN04L2 4" 2" Lever 4.5
LK535GN04T4 4" 4" Wristblade 4.5
LK535GN04T6 4" 6" Wristblade 4.75
LK535GN05L2 5" 2" Lever 4.5
LK535GN05T4 5" 4" Wristblade 4.75
LK535GN05T6 5" 6" Wristblade 5
LK535GN08L2 8" 2" Lever 3.75
LK535GN08T4 8" 4" Wristblade 4
LK535GN08T6 8" 6" Wristblade 4
HIGH ARC
LK535HA08L2 8" 2" Lever 4.5
LK535HA08T4 8" 4" Wristblade 4.75
LK535HA08T6 8" 6" Wristblade 5
LK535HA10L2 10" 2" Lever 4.5
LK535HA10T4 10" 4" Wristblade 4.75
LK535HA10T6 10" 6" Wristblade 5
CLASSROOM
23
8" Centers
with Concealed Deck
■
Tubular brass Hi-Arc®swing spout with
restricted flow aerator
■
Choice of 2 handle styles
■
Cast brass body
■
1/2" I.P. connections
CLASSROOM
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
HI-ARC
LKDC2432 7-1/4" swing Wing 5
LKDC2432BH 7-1/4" swing 4" Blade 5
LKDC2433 7-1/4" swing Wing ■ 6
Classroom Bubblers
®
LKDC2432
■
No-lead Flexi-Guard®bubbler with
anti-microbial additive, flexes on impact
to prevent accidental injury.
■
Built-in adjustable water volume control and
pressure regulator.
■
1/2" straight pipe thread connection.
Shipping
Model Number Body Mouthguard Handle WT. LBS.
LK1141A Chrome Plated Flexi-Guard Pushbutton 3
LKBH1141A Chrome Plated Flexi-Guard Bat 5
LKVR1141A* Chrome Plated Metal Pushbutton 4
LKVRBH1141A* Chrome Plated Metal Bat 5
LKSS1141A Stainless Steel Flexi-Guard Pushbutton 4
LKSSVR1141A* Stainless Steel Metal Pushbutton 4
LKR1141A Chrome Plated Flexi-Guard
* VR models feature anti-rotation pin
Remote 4
Pushbutton
LK1141A
LKVRBH1141A
24
LKR1141A
LKE4121
Elkay General Use Faucets are an ideal choice for
light-duty applications, such as a teacher’s lounge or an
office’s kitchenette area. Choose from a wide selection of
kitchen and hospitality faucets, in a variety of configurations,
for those areas that do not require a commercial grade
product, but still require the peace-of-mind that Elkay
quality provides.
Single Handle Concealed Deck
■
Choice of two spout styles
■
Circular brass base
■
Removable cartridges
■
Chrome plated finish
■
Swing spout with aerator
■
Water saving flow restrictor
GENERAL USE
LKE4124F
LKE4161
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
HI-ARC
LKE4121 8" Lever 5
LKE4121RS 8" Lever 5
LKE4123 8" Lever ■ 5
LKE413945RS 6-1/2" Lever 5
LKE4124F 10" Lever ■ 5
®
TUBE SPOUT
LKE4160 8" Lever 3
LKE4161 8" Lever ■ 3
25
8" Centerset Concealed Deck
with Twin Handles
■
Choice of 3 spouts styles
■
Removable cartridges
■
Chrome plated finish
■
Swing spout with aerator
■
Water saving flow restrictor
GENERAL USE
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
HI-ARC
LKD2432 8" Wing 5
LKD2432BH 8" 4" Blade 5
LKD2433 8" Wing ■ 6
LKD2439 6-1/2" Wing 5
LKD2439BH 6-1/2" 4" Blade 5
LKD2452 10" Wing 5
LKD2452BH 10" 4" Blade 5
LKD2453 10" Wing ■ 6
CAST SPOUT
LKD230 9-1/2" Wing 7
LKD230BH5 9-1/2" 5" Blade 8
LKD231 9-1/2" Wing ■ 8
LKD231BH5 9-1/2" 5" Blade ■ 8
GOOSENECK
LKD232S 5-5/8" Wing 7
LKD232SBH5 5-5/8" 5" Blade 7
®
LKD2433
LKD2439BH
LKD231
26
LKD232SBH5
LKD2443
LKD2445BH
8" Centerset Exposed Deck Mount
with Twin Handles
■
Choice of 2 spout styles
■
Removable cartridges
■
Chrome plated finish
■
Swing spout with aerator
■
Water saving flow restrictor
†
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
HI-ARC
LKD2442 8" Wing 5
LKD2442BH 8" 4" Blade 5
LKD2443 8" Wing ■ 5
LKD2445BH 7-1/4" 4" Blade 5
GOOSENECK
LKD2423 7" Wing 6
LKD2423BH 7" 4" Blade 6
®
GENERAL USE
LKD2423
LKE4101
LKE4103
Single Handled Deck Mount
■
Integrated tube spout
■
Removable cartridges
■
Chrome plated finish
■
Swing spout with aerator
■
Water saving flow restrictor
Spout Side Shipping
Model Number Reach Handle Spray WT. LBS.
TUBE SPOUT
LKE4100 8" Lever 4
LKE4100F 8" Lever 4
LKE4101 8" Lever ■ 4
LKE4102 8" Lever 4
LKE4103 8" Lever ■ 4
†
Clear crystalac handles are non-ADA compliant
27
Twin Handle Bar/Hospitality
■
Choice of 3 spout styles
■
Removable cartridges
■
Chrome plated finish
■
Water saving flow restrictor
†
Spout Shipping
Model Number Reach Handle WT. LBS.
HI-ARC
®
LKDA2437 6" swing Clear Crystalac 5
GENERAL USE
LKD2437BH 6" swing 4" Blade 6
LKDA2438 6-1/2" swing Clear Crystalac 5
LKD2438BH 6-1/2" swing 4" Blade 5
LKD2448BH 6-1/2" swing 4" Blade 4
LKDA2447 6" swing Clear Crystalac 4
LKD2447BH 6" swing 4" Blade 4
CAST SPOUT
LKD2230 9-1/2" swing Wing 6
GOOSENECK
LKD20888 4-3/4" rigid Wing 5
LKD208813 4-3/4" rigid Wing 5
LKDVR208813* 4-3/4" rigid Wing 5
LKD2223 5-5/8" swing 4" Blade 6
LKA2475 3-1/2" swing Clear Crystalac 2
LKD24898 4" swing Wing 3
LKD24898BH 4" swing 4" Blade 4
Single Handle Bar/Hospitality
LKD2438BH
LKA2475
LKD2230
■
Choice of two spout styles
■
Circular brass base
■
Removable cartridges
■
Chrome plated finish
■
Water saving flow restrictor
Spout Shipping
Model Number Reach Handle WT. LBS.
HI-ARC
®
LKE4122 6" swing Lever 5
GOOSENECK
LKD20858 4-3/4" rigid Wing, Right Side 4
LKD20858L 4-3/4" rigid Wing, Left Side 4
LKD208513 4-3/4" rigid Wing, Right Side 4
LKD208513L 4-3/4" rigid Wing, Left Side 4
LKDVR208513* 4-3/4" rigid Wing, Right Side 4
LKDVR208513L* 4-3/4" rigid Wing, LeftSide 4
* VR models feature vandal-resistant aerator, handle screw and
factory installed anti-rotation pins
†
Clear crystalac handles are non-ADA compliant
28
LKD20888
LKD20858
LKE4122
LKD208513
Arc Tube
Double Swing
3" Bucket Hook
Cast Fixed
Gooseneck
7" Bucket Hook
Spouts
For use with Commercial Grade Faucets, pages 3-8, 14-21
■
Large nut used on 4" and 8" centerset models
■
Small nut used on all single hole models
Spout Shipping
Model Number Reach Description WT. LBS.
ARC TUBE
A55393 8" Small Nut .50
A55395 10" Small Nut .50
A55399 12" Small Nut .55
BUCKET HOOK
A55404 3" Polished 1.5
A55405 3" Rough 1.75
A55406 7" Polished 2.5
A55407 7" Rough 2.75
CAST FIXED
A55409 6" 2.5
DOUBLE SWING
A55411 20" 2.0
GOOSENECK
A55397 4" Small Nut .50
A55401 5" Small Nut .50
A55403 8" Small Nut .75
HIGH ARC
A55446 8" Small Nut .50
A55445 10" Small Nut .75
TUBE SPOUT
A55408 8" .75
VENTED SPOUT
A55468 7" 1.5
ACCESSORIES
High Arc
Tube Spout
Vented
29
Handles
For use with Commercial Grade Faucets, pages 3-21
Shipping
Model Number Size Description WT. LBS.
45918C 2" Lever .25
45919C 4" Wrist Blade .50
45920C 6" Wrist Blade .75
Aerators
ACCESSORIES
For use with Commercial Grade Faucets, pages 3-22
LK734 2.2 GPM Vandal-Resistant Aerator Kit
LK733 .5 GPM Vandal-Resistant Aerator Kit
LK735 1.5 GPM Vandal-Resistant Laminar Flow Aerator Kit
A55536 Aerator Key included with all Vandal-Resistant Aerator Kits,
LK736 2.2 GPM Aerator
For use with General Use Grade Faucets, pages 24-27
LK370 2.2 GPM Swi
LK3712 2.2 GPM Swivel Spray Aerator
(Standard on all commercial faucets)
(can be ordered separately)
vel A
erator
Cartridges
For use with Commercial Grade Faucets, pages 3-22
4" Wristblade Handle2" Lever Handle 6" Wristblade Handle
A55536
LK370
Vandal-Resistant
Aerator
LK736
LK3712
45922C Left hand (hot) ceramic 1/4 turn cartridge long stem
45921C Right hand (cold) ceramic 1/4 turn cartridge long stem
45924C Left hand (hot) ceramic 1/4 turn cartridge short stem
45923C Right hand (cold) ceramic 1/4 turn cartridge short stem
For use with General Use Grade Faucets, pages 24-27
P29121NL R
P29122NL Left hand (hot) ceramic 1/4 turn cartridge
ight hand (cold) ceramic 1/4 turn cartridge
Backsplash Mounting Kit
LKMK462 For installation of wall-mount faucets onto
30
stainless steel backsplash. Includes 2 ea.
of 1/2" nipples, 1/2" NPT by 1/2" sweat
ells, washers and lock nuts. 1 lb.
45922C 45924C
LKMK462
Sensor Operated
Faucet Accessories
For use with Sensor Operated Faucets, page 13
MIXING VALVES
ACCESSORIES
LK725
LK723
LK726
LK731
LK724
LK723 Anti-scald thermostatic mixing valve with
nickel plated brass body, 1/2" SWT inlets
and outlet connections, check valves on
inlets and mixed temperature range of
80°-120°F. Certified under ASSE 1016.
Ship Wt. 2 lbs.
LK724 Mechanical mixing valve with C.P. brass
body, 3/8" compression on inlets and outlet
connections, and check valves on inlets.
Ship Wt. 1 lb.
AERATORS
LK725 1.6 gpm, female thread. Ship Wt. 1/4 lb.
LK726 Laminar flow control, 2.0 gpm, female thread.
Ship Wt. 1/4 lb.
LK731 Rose spray head to convert laminar flow
control spout end to rose spray,
2.5 gpm. Ship Wt. 1 lb.
31
Coast-To-Coast Elkay Sales Network
Our national sales presence and extensive distributor base provide
excellent service and convenience. For the name of your nearest
Elkay Sales Rep or Wholesaler:
• Visit the “Where to Buy” area on elkayusa.com
• Call our customer service department at 630.572.3192
Elkay Technical Support
• Help is always just “One Call” away.
• Trained factory technicians available during business hours,
5 days a week
• 98% of technical service inquiries handled on the first call
Throughout the birth and growth
of the Elkay plumbing products
group, the leadership and vision
of Elkay's founders has always
been maintained: provide better
customer service, higher quality
and more innovation than our
competitors. Our faucets are no
exception. We invite you to
learn more about our products
and services.
Visit elkayusa .com
• Up-to-date product specification sheets
• Current catalog and pricing
• Local sales rep locator
• Warranty information
• Where to buy our products
• Service information
• How to contact Elkay
© 2010 Elkay Printed in U.S.A. (9/10) F-4192 10M
Contact Information
Web Site: elkayusa.com
Corporate Headquarters:
630.574.8484
Customer Service: 630.572.3192
Fax: 630.574.5012
2222 Camden Court
Oak Brook, Illinois 60523
Loading...
