DEAR CLIENT
THANKS FOR YOUR CHOICE AND WE ARE AT YOUR DISPOSAL FOR ANY HELP
AND SUGGESTION.
THE ELECTRO STIMULATOR GL1 ARE PRODUCED BY:
DOMINO s.r.l.
Tel. (+39) 0438.793052
Fax. (+39) 0438.796463
E-MMail: info@domino.tv.it
THE ELECTRO STIMULATOR GLOBUS ELITE is distribuited by:
GLOBUS ITALIA S.r.l.
Tel. 0438.7933
www.globusitalia.com
info@globusitalia.com
This product has been manufactured according to the technical regulations in force
and it has been subjected to certifications according to 93/42/CEE directive for medical devices, by the CERMET Body n°. 0476, in order to assure the product's security.
The user must follow all prescriptions and restrictions shown in the operating manual
in order to keep the maximum security level of the product.
The DOMINO s.r.l. declines all responsibility for every different use from what indicated in this operating manual.
All complete or partial reproductions of texts and/or pictures of this operating
manuals made by any electronic or mechanic equipments are strictly forbidden
without written permission of the DOMINO s.r.l..
ELITE MULTIRev. 2.1
1
ENGLISH
Program list
User manual
DEUTSCH
Behandlungsprogramme
Gebrauchsanweisung
FRANÇAIS
Liste programmes
Manuel d’utilisation
ESPAÑOL
Lista de programas
Manual de utilizacion
Electrode Placement
4-9
10-28
30-35
36-54
56-61
62-80
82-87
88-106
107-112
ELITE MULTIRev. 2.1
2
ELITE MULTIRev. 2.1
3
SUMMARY......................................................................................................................................................3
PROGRAM LIST.............................................................................................................................................4
ACCESSORIES..................................................................................................................................................10
CONTRAINDICATIONS..................................................................................................................................11
CARE INSTRUCTIONS...................................................................................................................................12
- Taking care and cleaning the stimulator
- Maintenance and use of electrodes and cables
WARNINGS.....................................................................................................................................................13
- Precautionary measures
- Use destination
TECHNICAL FEATURES................................................................................................................................14
BATTERY RECHARGEMENT........................................................................................................................15
- How to charge the battery
STIMULATOR AND DISPLAY DESCRIPTION............................................................................................16
KEYBOARD DESCRIPTION...........................................................................................................................17
USING THE STIMULATOR..........................................................................................................................18
STIMULATION INTENSITY..........................................................................................................................21
- Open Circuit
- Stimulation intensity
TREATMENT DESCRIPTIONI SPORT, FITNESS AND BEAUTY, HEALTH AND REHAB............................22
COMMON QUESTIONS...............................................................................................................................26
WARRANTY TERMS.....................................................................................................................................28
SUMMARY
PROGRAM LIST
SPORT MAN
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
ELITE MULTIRev. 2.1
4
Muscle Program number Program name Electrode placement Phase time (min.)
Intensity
Sport M. 1
Czpillarisation
Sport M. 2
Warm Up
Sport M. 3
Recovery
post-comp./training
Sport M. 4
Maximum force
lower limbs
Sport M. 5
Resistent force
lower limbs
Sport M. 6
Explosive force
lower limbs
Sport M. 7
Reactivity
lower loimbs
Sport M. 8
Relaxation
lower limbs
Sport M. 9
Maximum force
abdominal/dorsal
Sport M. 10
Resistent force
abdominals/dorsals
Sport M. 11
Relaxation
abdominals/dorsals
Sport M. 12
Maximum force
upper limb/pectorals
Sport M. 13
Resistent force
upper limbs/pectorals
Sport M. 14
Explosive force
upper limbs/pectorals
Sport M. 15
Relaxation
upper limbs pectorals
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
Mod
20’
Mod
10’
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
15’5’5’
Int
Max
Int
20’
Int
ELITE MULTIRev. 2.1
PROGRAM LIST
SPORT WOMAN
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
Muscle Program number Program name Electrode placement Tempo fasi (min.)
Intensità
Sport W. 16
Capillarisation
Sport W. 17
Warm up
Sport W. 18
Recovery
post-comp./training
Sport W. 19
Maximum force
lower limbs
Sport W. 20
Resistent force
lower limbs
Sport W. 21
Explosive force
lower limbs
Sport W. 22
Reactivity
lower limbs
Sport W. 23
Relaxation
lower limbs
Sport W. 24
Maximum force
abdominals / dorsals
Sport W. 25
Resistent force
abdominals / dorsals
Sport W. 26
Relaxation
abdominals / dorsals
Sport W. 27
Maximum force
lower limbs/pectorals
Sport W. 28
Resistent force
lower limbs/pectorals
Sport W. 29
Explosive force
lower limbs/pectorals
Sport W. 30
Relaxation
lower limbs/pectorals
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
Mod
20’
Mod
10’
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
Mod
20’
15’5’5’
Int
Max
Int
20’5’5’
Int
Max
Int
15’5’5’
Int
Max
Int
20’
Int
5
ELITE MULTIRev. 2.1
6
PROGRAM LIST HEALTH AND REHAB
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
Muscle Program number Program name Electrode placement Phase time (min.)
Intensity
Rehab 31
DEMO
Rehab 32
Research motor
points
Rehab 33
Antalgic Tens
Rehab 34
Endorphinic
Tens
Rehab 35
Contractures
Rehab 36
Haematomas
Rehab 37
Sciatica
Rehab 38
Atrophy recovery
lower limbs
Rehab 39
Lumbago
Rehab 40
Atrophy recovery
upper limbs
Rehab 41
Cervicals
Rehab 42
Peryarthritis
Rehab 43
Epicondylitis
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
2’2’2’ 2’
Mod
Mod
Mod
Mod
5’
Mod
30’
Mod
Mod
20’
20’
Mod
Mod
30’
Mod
20’
30’
Mod
15’
5’
Int
Ele
20’
20’
Mod
Mod
Int
5’
30’
Mod
10’
15’
Mod
Mod
10’
15’
Mod
Mod
R7
I1-I2-I4
T3
S1-S2-S3-S4-S5-S6-S7
R1
R2
R3-R4
15’
Int
ELITE MULTIRev. 2.1
PROGRAM LIST
FITNESS MAN
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
Muscle Program number Program name Electrode placement Phase time (min.)
Intensity
Fitness M. 44
Fitness M. 45
Fitness M. 46
Fitness M. 47
Fitness M. 48
Fitness M. 49
Fitness M. 50
Fitness M. 51
Fitness M. 52
Fitness M. 53
Fitness M. 54
Fitness M. 55
Fitness M. 56
Fitness M. 57
Fitness M. 58
Fitness M. 59
Fitness M. 60
Fitness M. 61
Fitness M. 62
Fitness M. 63
Relaxant massage
Bio Pulse
25’
Mod
Toning
Massage
As indicated in the figures at the
end of the manual
As indicated in the figures at the
end of the manual
Mod
20’
vascolarisation
lower limbsi
Int
25’
Dtainage
lower limbs
Lypolisis
lower limbs
Firming
lower limbs
Toning
lower limbs
Sculpting / Firming
lower limbs
Mass
lower limbs
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
I1-I2-I3-I4-I5-I6
Drainage
abdominal / dorsals
Lypolisis
abdominals / dorsals
Firming
abdominals / dorsals
Toning
abdominals / dorsals
Sculpting
abdominals / dorsals
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
T1-T2-T3-T4-T5-T6
Drainage
Upp. limbs pectorals
Lypolisis
Upp. limbs pectorals
Firming
Upp. limbs pectorals
Toning
Upp. limbs pectorals
Sculpting
Upp. limbs pectorals
Mass
Upp. limbs pectorals
Int
20’
20’
30’
Int
Int
20’
Ele
15’
Ele
20’
Max
15’
Max
20’
Int
20’
30’
Int
Int
20’
Int
15’
Int
Int
20’
20’
Int
Int
30’ 20’
Int
Ele
20’
15’
Ele
20’
Max
15’
Max
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
S1-S2-S3-S4-S5-S6-S7-S8
7
ELITE MULTIRev. 2.1
8
PROGRAM LIST
FITNESS WOMAN
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
Muscle Program number Program name Electrode placement Phase time (min.)
Intensity
Fitness W. 64
Relaxant Massage
Bio Pulse
Fitness W. 65
Toning
massage
Fitness W. 66
vascularisation
Fitness W. 67
Drainage
thighs and hips 1
Fitness W. 68
Drenaggio
thighs and hips
Bio Pulse
Fitness W. 69
Lypolisis
thighs and hips 1
Fitness W. 70
Lipolisi
thighs and waist 2
Bio Pulse
Fitness W. 71
Firming
cthighs and hips 1
Fitness W. 72
Firming
cthighs and hips 1
Bio Pulse
Fitness W. 73
Toning
thighs and hips
Fitness W. 74
Sculpting
thighs and hips
Fitness W. 75
Drainage
gluteus 1
Fitness W. 76
Drainage gluteus 2
Bio Pulse
Fitness W. 77
Lypolisis
gluteus 1
Fitness W. 78
Lypolisis gluteus 2
Bio Pulse
Fitness W. 79
Firming
gluteus 1
Fitness W. 80
Firming gluteus 2
Bio Pulse
As indicated in the figures at
the end of the manual
As indicated in the figures at
the end of the manual
25’
Mod
Mod
20’
Int
25’
Int
20’
20’
Max
20’
30’
Int
Int
Int
20’
Int
20’
Ele
20’
20’
Ele
15’
Ele
20’
Ele
20’
Int
20’
Int
20’
30’
Int
Int
20’
20’
Int
Int
20’
Ele
Ele
20’
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I1-I2-I3-I4-I5
I6
I6
I6
I6
I6
I6
ELITE MULTIRev. 2.1
PROGRAM LIST
FITNESS WOMAN
Key words: Mod = Moderated - Elev = Elevated - Int =Intermediate - Max = Maximum
Muscle Program number Program name Electrode placement Phase time (min.)
Intensity
Fitness W. 81
Fitness W. 82
Fitness W. 83
Fitness W. 84
Fitness W. 85
Fitness W. 86
Drainage abdominals
2
Bio Pulse
Fitness W. 87
Fitness W. 88
Lypolisis
abdominals 2
Bio Pulse
Fitness W. 89
Firming
abdominals 1
Fitness W. 90
Firming
abdominals 2
Bio Pulse
Fitness W. 91
Toning
abdominals
Fitness W. 92
Sculpting
abdominals
Fitness W. 93
Firming
brast
Fitness W. 94
Sculpting
breast
Fitness W. 95
Drainage
upper limbs
Fitness W. 96
Lypolisis
upper limbs
Fitness W. 97
Capillarisation
face
Fitness W. 98
Face lifting effect
Toning gluteus
1
Toning gluteus
2
Ele
15’
Ele
15’
Sculpting gluteus
1
20’
Ele
Sculpting gluteus
2
20’
Ele
Drainage abdomi-
nals 1
20’
Int
Lypolisis
abdominals 1
20’
Int
20’
30’
Int
Int
Int
20’
Int
20’
Ele
20’
20’
Ele
15’
Ele
20’
Ele
15’
Mod
10’
Mod
Int
20’
Int
30’
15’
Mod
Mod
15’
T5-T6
I6
I6
I6
I6
T5-T6
T5-T6
T5-T6
T5-T6
T5-T6
T5-T6
T5-T6
S9
S9
S1-S2-S3-S4-S5-S6-S7
T5-T6
V1
V1
9
ELITE MULTIRev. 2.1
10
ACCESSORIES
Accessories:
a. 4 electrode connection cables
(coloured cables for EMS, TENS treatments)
b. 2 grey cables for Microcurrent treatment (only for 300 models)
c. Case of 4 reusable adhesive electrodes (5 x 5 cm)
d. Case of 4 reusable adhesive electrodes (5 x 9 cm)
e. Bag for transport
f. Battery charger (see technical features)
g. Operating manual complete of electrode placement guide
h. Unit
i. Personal Trainer
l. Guarantee
This stimulator is supplied complete of cables and electrodes. When you open the
packing, verify the simulator equipment is complete. If some of the above- mentioned accessories are missing, you should immediately contact the shopkeeper. Also
check the stimulator and electrodes integrity.
Electrodes
: The electrodes are for single use they are self-adhesive and don’t require gel. The electrode cable is female. They are branded CE complied with MDD
93/42/EEC requirements.
All the information can be subjected to changes without notice.
STANDARD SYMBOLS
The symbols mean that the apparatus is in accordance with medical CE require-
ments class II and type BF.
The external charger is class II
Attention: read the instruction with attention
Complies with requirements of medical device 93/42 CEE number 0476.
Patient part type BF (Body Floating)Parti applicate BF
Isolation class II°
Switching ON/Switching OFF
0476
ELITE MULTIRev. 2.1
CONTRAINDICATIONS
Contraindications
- Do not stimulate the neck region (carotid sinus).
- Patients who have a demand type cardiac pacemaker.
- Stimulation should be not used on cancer patients (previous permission
received by the oncologist).
- Do not stimulate the cerebral zone.
- Do not use on undiagnosed pains until aetiology is established.
- Do not use on sores and dermatological diseases.
- Do not use on acute traumas.
- Do not stimulate recent cicatrix.
- Do not use during pregnancy.
- Do not use during driving car.
- It is absolutely forbidden to stimulate the ocular and genital zone
- It is also forbidden the use of the stimulator in the water (it is not protected
against the water). Do not use the stimulator in environment where combustible
gas, inflammables, or oxigen are present.
- It is also properly to use with caution in case of capillary fragility because an
excessive stimulation could cause the break of more quantity of capillaries. Anyway,
it is always preferable to contact your doctor before using.
Adverse possible effects
Skin irritation can occur in rare case. In case of allergic reactions by the use of
gel, stop the treatment and contact the specialist doctor.
If during the stimulation treatment tachycardia or extrasistolia should appear, it
is better to stop the treatment The sensation will pass immediately
11
ELITE MULTIRev. 2.1
CARE INSTRUCTION
Taking care and cleaning the stimulator
- In case of damage of the covering apparatus, this has to be replaced.
- In case of real or presumed spoilt, do not make any repairs by yourself. Only
authorized centres can carry out repairs.
- Do not give a shock to the product by clashing, overturning or shaking. It may
cause trouble or accident in a long run although no immediate trouble occurs.
- Store the electro stimulator at a place free from a wet areas and water. Avoid
installing in places subject to humidity, high temperature, dust or places exposed
to direct sunbeam or near to sources of high electromagnetic emission: The stimulator must be used free and not wrapped or covered.
- Do not use thinner, gasoline, kerosene, cleaning powder or chemicals; for cleaning the machine and the cables, it is sufficient a soft duster lightly humid.
- After a long period of no use, it is advisable to check the correct working of the
stimulator and of the battery. (Contact authorized centres).
- Do not use the apparatus during the battery rechargement.
- The stimulator is connected to the electricity by means of the apposite feeder.
Before the connection check that electric system is complied with the requirements
in force in your country.
- It is advisable not to use the apparatus together with other electronic equipment
above all those used for support of vital functions.
Maintenance and use of electrodes and cables
Before placing the electrodes on your body, be sure to always wash and dry the skin
in order to ensure good conductivity.
After the use of the reusable mono-user electrodes, store them in the apposite seat
and insert in a plastic bag cleaned and closed.
Check that there is no contact or overlapping among the electrodes.
The electrodes can be used for 25/30 applications.
If the electrodes loose their conductivity and adhesion, they could be old and need
replacement
In case of use of electrodes not adhesive, it is advisable to clean the surface with
water.
Use only the electrodes recommended by the supplier.
Be sure that the cables and electrodes are cleaned before any application.
In case of cable deterioration, replace them with original spare parts.
12
ELITE MULTIRev. 2.1
WARNINGS
Precautionary measures
- Only person with mental competence must use the device.
- The electro stimulator must be used only for transcutaneous neuro-stimulation.
- The neurostimulation apparatus should only be used under the continued super-
vision of a physician.
- The stimulator should only be used with skin electrodes intended for nerve and
muscle stimulation.
- The user must keep the device out of reach of children.
- Electronic monitoring equipment (such as ECG monitors and ECG alarms) may
not operate properly when stimulation is in use
- Stimulus delivered by this device may be sufficient to cause electrocution:
Electrical current of this magnitude must not flow through the thorax because it
may cause a cardiac arrhythmia. (Do not stimulate pectoral and dorsal muscles
simultaneously)
- Do not use the apparatus in case of any health problem without consulting your
doctor.
- Do not use the stimulator near short wave devices.
Use destination
Read the operating manual carefully in order to avoid carrying out installation, use
and maintenance non-adequate that could damage the apparatus, the operator and
the user.
The stimulators are used in the following operating environments and fields:
- home;
- surgeries hospital;
- physiotherapic surgery;
- rehabilitation centres;
- treatments of pain in general
- in any type of sequential electro stimulation,
- aesthetic and sports use,
The use of the stimulator is allowed to patients (rightly informed about the
methods), doctors and paramedic.
13
ELITE MULTIRev. 2.1
TECHNICAL FEATURES
14
TECHNICAL
FEATURES
Number of channels: 4
Constant current: Yes
Intensity: 0-100 mA with load 1000
Wave form: rectangular, biphasic, symmetric, compensated
Work frequency: 0,3-150 Hz
Recovery frequency: 0,3-150 Hz
Amplitude: 40-450 µs.
Working time: from 1 to 30 sec.
Recovery time: from 0 to 1 min.
Frequency Range: continuous variation from 1 to 150 Hz
modulation minimum time 3 sec.
Amplitude Range: continuous variation from 40 to 450 µs.
minimum frequency 1 Hz
maximum frequency 150 Hz.
modulation minimum time 5 sec.
Ramp-up time: from 0 to 15 sec.
Ramp-down time: from 0 to 15 sec.
Power supply: accumulator Ni-MH rechargeable 7,2 V 1,5 Ah
Globus Model
Adaptor: AC-DC Adaptor
PRI: 230V~50 Hz 2.9 W
SEC: 7,5 V - 150 mA 1.13 VA
MODEL: MA075D015CE
Devices case: ABS
Protection: IP 20
Dimension: 160x99x35,4
Weight: 404 gr.
Device removal
Don't throw the device out but recycle or get rid of them appropriately following
the removal rules in force in your country.
ELITE MULTIRev. 2.1
BATTERY RECHARGEMENT
15
How to charge the battery
The stimulator is supplied together with a rechargeable battery. The batteries are
Nickel Metal hydrate type with peak efficiency without memory effect. When the
battery indicator lights up on the display it
is advisable to recharge the batteries.
Shut off the stimulator and the electrodes;
connect it to the supplied charger (Globus
MA 075D015CE), inserting the plug in the
special outlet (see the side figure). The LED
on the charger is lit when the connection is correctly executed. The first recharge
must be absolutely complete and it has not to be stopped for any reason. A complete recharge takes about 10 hours; should the stimulator accidentally stay connected for longer than (72 hours) the battery will not be damaged.
Only use the charger supplied with the stimulator. Battery should only be replaced
by an authorized centre.
Attention
Do not use a charger different from that supplied with the stimulator.
During the charger the stimulator MUST NOT be connected to the electrodes.
If the charger is connected with the stimulator switched on, it will automatically
switch off.
Should the cable or connector show signs of wear and tear you should replace it
immediately.
ELITE MULTIRev. 2.1
STIMULATOR AND DISPLAY DESCRIPTION
INDICATOR OF NUMBER
OF PHASES AND OF
PHASE IN PROGRESS
NUMBER OF
PROGRAM
CHANNEL
INTENSITY
BATTERY
INDICATORS
TIME
INDICATORS
Warnings and information for first use
Before using the stimulator read the following information:
- Read this operating manual with attention;
- Examine with care the stimulator and its parts for individuating eventual external damages;
- if at the switching on all the segments should appear on the display, shut off
the stimulator and start again. In case the segments would be present again, contact the assistance centre without using the machine.
- The stimulator is ready to use when on the display the software version (left
low number).
- if the battery is not sufficiently charged, the machine will switch off immediately. It is therefore advisable to recharge the battery following the instruction mentioned in paragraph “Battery Rechargement”.
CH 1
CH 2
CH 3
CH 4
16
ELITE MULTIRev. 2.1
KEYBOARD DESCRIPTION
INCREASING AND
DECREASING
INTENSITY
SWITCH FUNCTION
NOTE
:
3 “
= By pressing the switch for three seconds you activate the funcion.
SWITCH LEFT
SWITCH UP
SWITCH TIME
SWITCH RIGHT
SWITCH DOWN
SWITCH
ON/OFF/OK
ON/OFF/OK
LEFT
UP
DOWN
RIGHT
TIME
fn
Intensity
Confirms the selection of a program in progress and activates the
pause
3”
= Switching on/switching off.
3”
= during the program returns to the previous phase.
During the program it increases the four channels intensity simultaneously.
During the program it decreases the four channels intensity simultaneously.
3” During the program it allows to skip to the subsequent phase.
During the program displays the remaining total time or the
remaining time of the ongoing phase.
Pressed alone it allows the change of the duration phase.
Increases/decreases the intensity of corresponding channels.
17
ELITE MULTIRev. 2.1
USING STIMULATION
PRACTICAL USE
For a correct use, proceed as follow:
- check that the stimulator is not connected to the electric system for the battery
rechargement;
- connect the cables to the special output;
- attach the electrodes to the cables already connected to the stimulator;
- place the electrodes on the skin;
The stimulator and its accessories must be put back in the special bag respecting
the following conditions:
Temperature: 5-45 °C
Humidity: 20-85 %
Start up and navigation
To turn on press the button On/Off (OK) for three seconds until a bip is heard
Low left of the display, The software version and the model will be displayed for
three seconds
18
How to select the program.
By buttons Up e Down select the number of the program. Press OK to confirm.
During the choice the following parameters are displayed:
number of phases the program name (up) and the program duration (left up).
Starting program.
After the program selection, use switches to increase the intensity of each channel or switch to increase the intensity on all channels simultaneously.
Display during the treatment.
During the treatment execution the display will show you the following parameters: the number of program (top left), how many phases the program consists of,
in which phase you are (the current square is filled), the remaining time of the
ongoing phase (top right) and left and the type of used wave EMS, TENS etc.
ELITE MULTIRev. 2.1
19
ELITE MULTIRev. 2.1
20
How top ut the program in pause.
You can put the program in Pause mode by pressing switch OK of Joypad. The
intensity turns to 0. Start stimulation again by pressing OK.
The program continues where stimulation was shut off.
During the pause the lightening PAUSE description will appear.
How to stop the program
To stop the program hold down the bottom OK for 3 seconds.
How to display the remaining time of a program.
During the program, the remaining time of the ongoing phase is displayed. If you
want to see the remaining total time press switch TIME.
It will be displayed for two seconds and all the phase indicators are filled.
How to change the phase time.
To change the phase time, press switch Function fn; the time indicator of the phase
in progress, starts blinking; press switches Up and Down of Joypad to change it.
The new entered time will be automatically confirmed after two seconds of visualisation.
Jumping phase.
While stimulating, you have the option to jump to the next or previous sequence.
Hold down the push button right or left for 3 seconds.
Increasing and decreasing the intensity
To increase or decrease the intensity on each channel, press the corresponding switches Up or down.
If you want to increase or decrease all the channels simultaneously., press switches
Up or Down of Joypad.
ELITE MULTIRev. 2.1
21
STIMULATION INTENSITY
Open circuit
Should the current circuit be open (due to a cable breakage or electrodes not correctly placed) and the user increases the intensity more than 10 mA, the intensity
automatically shuts off to 0 mA.
It is therefore necessary before starting any treatments, to be sure that the cables
are connected to the device and the electrodes have a good contact with your skin.
Also check if the electrodes are too old and need replacement.
Stimulation intensity
The needed intensity value to obtain a special contraction, is completely subjective. It can depend on a series of factors such as the position of electrode, the adipose stratum, the perspiration etc. For these reasons the same current intensity
value can give different sensations from a person to another, from a day to another or furthermore you could feel more contraction on the left limb rather than
on the right one.
During the same working session, it will be necessary to set the intensity as to
obtain the same contraction level. This is due to the so-called accomodation phenomenons
- Moderate: the muscle is not tired; the contraction is tolerable and com
fortable. First level in the intensity graph.
- Intermediate: the muscle visibly contracts but it does not cause any arti-
cular movement. Second level in the intensity graph
- Elevated: the muscle sensibly contracts. The contraction would cause a
articular movement for this reason the limb must be blocked. Third level
in the intensity graph
- Maximum: the muscle is subjected to a maximum contraction. It is a chal-
lenging work that should be carried out after several applications.
P.S. In the program guide also the advisable intensity values are indicated. We
propose you an intensity value just as indication; you have to regulate it on the
bases of your sensations.
Moderate
Intermedi
ate
Elevated
Maximum
from 10 mA to 20 mA
from 20 mA to 30 mA
over 30 mA
at a limit of endurance but not painful muscle contraction.
ELITE MULTIRev. 2.1
22
TREATMENTS
Here below you can find a brief description of the program included in the electro stimulator
SPORT
Warm Up:
Increases the muscle’s temperature to make it more prepared for training. It also
increases the blood supply and the metabolism in the muscle. Recommended before physical training or competition.
Intensity: moderate or intermediate.
Maximum Force:
Improves the maximum force capacity and increases muscle mass. It allows to train
with maximum loads with fewer risks of injuries compared to classic heavy
strength training. Recommended for all sports where you need maximum strength.
Intensity: Maximum muscle contraction without pain. Active rest should give com-
fortable muscle vibrations.
Resistance Force:
Improves the capacity to develop a high level of force over a prolonged period
of time and increases the ability to withstand toxin accumulation and therefore
delays the fatigue of the muscle. To achieve a very high intensity of work the
objective is to induce a large number of long strong contractions alternating with
short active rests. This is recommended for sports needing intense muscle work
over a prolonged period of time.
Intensity: intermediate or maximum. The Active Rest should give muscle vibrations.
Explosive Force:
This program increases the capacity to rapidly achieve a maximum force expression. The objective is to use the largest amount of muscles in the shortest possible time. It is advisable to start with a maximum force program in order to prepare the muscle for the Explosive Force. Recommended for all sports characterized by maximum force expressions with natural load e.g. sprint, ball sports, alpine skiing. Intensity: maximum, muscle contraction without pain. The Active Rest
should give muscle vibrations.
Reactivity:
To improve the reactivity it is necessary to increase the quick contraction of the
fast fibres and the receptive activity of the myo-tactical nervous fibres. It is advisable to combine this treatment with pliometric and proprioceptive activities in
order to complete the reactivity training. The muscle contractions are brief, very
strong and at a very high speed. For all sports needing quick acceleration and
reaction capacity e.g. ball sports, combat sports, sprint.
Intensity: maximum, muscle contraction without pain. The Active Rest should give
muscle vibrations.
Muscle Relaxation:
Enables a very effective muscle relaxation thanks to the comfortable vibrations
that increase the circulation. These programs can be used at any occasion when
muscle relaxation is needed.
Intensity: from moderate to intermediate.
ELITE MULTIRev. 2.1
23
Capillarisation:
Increases the blood supply to the muscle and improves the resistance quality and
recovery. This circulation increasing, allows to maintain active the primary and
secondary capillary system that improves the tissue oxygenation. This gives a delayed fatigue during very intense work. The capillarisation programs are especially
recommended for sports where resistance strength and endurance are important.
Intensity: intermediate.
Recovery post competition/training:
It increases the ability to regain muscular capacity after training or competition.
The stimulation varies from muscular vibrations to light contractions that allows a
circulation improvement and a minor muscle hardening. This program also relieves
the pain due to the endorphin production. This program is recommended for all
sports because it helps to recover rapidly the maximum capacity of the muscle. It
is advisable to be used after 8–24 hours of training or competition.
Intensity: from moderate to intermediate
FITNESS AND BEAUTY
Drainage:
The combined stimulation achieved by the four channels of the stimulator produces a muscular pumping effect, starting at the extremity of the limb and spreading
all the way to its root. The pumping action, mainly activates the venous but also
the lymphatic systems by mechanical effect. Its objective is to improve the circulation and to promote the elimination of toxins.
Intensity: from moderate to intermediate.
Lypolysis:
The low frequency of this program has a positive effect on the metabolism; it
increases the capacity to eliminate toxins and unwanted fluids. This method enables to model the undesirable areas modifying the metabolism of lipocytes. It improves circulation and increases the capacity to eliminate the orange skin appearance.
Intensity: from moderate to intermediate.
Vascolarisation:
It enables a very effective decontraction of the muscle due to the comfortable vibrations that increase the circulation and help the muscle to relax. These programs
can be used at any occasion when muscle relaxation is needed.
Intensity: intermediate.
Firming:
The program is suitable for sedentary people who have weak muscles that have
lost some of their bulk. It prepares the muscle to more intense stimulations. It can
be used every day on large muscle groups such as the thighs, abdominal and dorsal muscles.
Intensity: from intermediate to elevated.
Toning:
The toning program offers genuine maintenance work for muscular tone. This type
of training session is of moderate intensity, making it suitable for everyone without
causing muscle soreness. The program is specially aimed at those who, attentive to
their physical condition, are looking for a complement to their regular training. It
can be undertaken three times a week.
Intensity: from intermediate to elevated
ELITE MULTIRev. 2.1
24
Sculpting:
The sculpting program is the last phase in a complete aesthetic program. The program is aimed at those who desire to obtain muscular sculpting in place where
traditional muscle-building exercises are insufficient. The sculpting program produces intense work and for this reason it is normal for some muscle soreness to be
felt during the hours following sessions of this nature. You can prevent the soreness by executing some stretching exercises before and after the session or you
can associate a relaxation program.
Intensity: from intermediate to elevated
Muscular mass increasing:
Special program to increase the volume and the muscular mass.
Intensity: maximum muscle contraction without pain.
It is advisable to carry out a warm up program before starting any Firming,
Toning, Sculpting, Body Sculpting and Mass program.
HEALTH
Tens utilizes the nervous system’s own pain relief mechanism to ease both acute and
chronic pain. When stimulating, impulses are sent through the nerves to block the
pain impulses. The analgesic effect occurs during the program execution but it can
also last for hours. The duration of this effect varies. Tens also increases the circulation. Place the electrode on the painful area and start the program. You can carry
out this program on any occasion when pain relief is needed.
Attention! TENS relieves the pain but it does not treat the cause. If the pain persists, seek medical advice.
TENS (Antalgic-EEndorphinic)
It offers effective relaxation of the muscle, as well as pain relief. The TENS utilises
the nervous system’s own pain relief mechanism to ease both acute and chronic pain.
When stimulating, impulses are sent through the nerves to block the pain impulses.
You can carry out this program on any occasion when pain relief and muscle relaxation are needed.
Attention! TENS relieves the pain but it does not treat the cause. If the pain persists, seek medical advice.
Intensity: ANTALGIC TENS Pins and needle sensation without pain. Should not cause
muscle contraction. ENDORPHINIC TENS: visible muscle vibrations.
TENS:
(Cervical, Lumbago, Periarthritis, Epicondylite, Tunnel Carpal, Sciatica, Knee pain,
Achilles’ Tendon):
The TENS utilizes the nervous system’s own pain relief mechanism to ease both acute
and chronic pain. When stimulating, impulses are sent through the nerves to block
the pain impulses. In this program we use the stimulation alternative with light contractions that stimulate the release of endorphins.
Attention! TENS relieves the pain but it does not treat the cause. If the pain persists ,seek medical advice.
Intensity: pins and needle sensations without pain.
ELITE MULTIRev. 2.1
25
REHAB
Atrophy Recovery
Resuming physical activity after a period of interruption. After injuries or other interruption in physical activity, the muscles often lose strength and muscle mass. It is
important to restore normal muscle capacity as soon as possible. The Atrophy Recovery
program, gives the possibility to train specific muscle that are affected. Can be used
on any occasions when resuming activity is needed.
Intensity: from moderate to intermediate.
Muscle Relaxation
This program enables a very effective relaxation of the muscle due to comfortable
muscle vibrations that increase the circulation and help the muscle to relax. Tensed
muscles are a common problem e.g. after an injury or after overworking of muscle.
This kind of program can be used in any occasion when muscle relaxation is needed.
Intensity: moderate.
Haematoma:
This program increases the absorption of the muscle haematoma caused by, for example, a contusion. It also improves the circulation in the involved arm. This program
should not be used within 72 hours of the muscle injuries. Always seek medical advice for further information.
Intensity: from intermediate to moderate.
This is a medical device for the presence of clinic stimulation program. It is therefore
certified by the Notified Body Cermet n° 0476 complied with 93/42/CEE requirements.
The certification covers clinic applications
ELITE MULTIRev. 2.1
26
COMMON QUESTIONS
Why does the intensity return immediately to 0r when increasing its value?
The unit has a control of current supply. In case the circuit is open the intensity is
automatically shut off.
It is therefore necessary, before starting any treatment, lo be sure that the cables are
well connected and the electrodes completely placed on the skin.
What kind of electrodes must be used for electro stimulation?
We suggest you to use adhesive electrodes that are more practical and improve the
stimulation quality. If used with care, they will last for about 25 - 30 applications.
The electrodes need to be replaced when a bad connection with your skin occurs.
Where to place the electrodes?
On the back of this manual you will find a comprehensive electrode placement guide.
If you want to verify the correct placement of electrodes you can also use the special motor point pen or follow this method: place the electrode as indicated by the
picture, start the stimulation and with your hand move the electrode without removing it and let the skin sliding above the muscle. You will notice a change in contraction according to the different positions. Place the electrode where the contraction
is greater. Always remember to decrease the intensity to zero before moving the electrodes.
How to use the Y cables.
With the help of a so-called Y-cable, the number of electrodes is doubled. This enables you to stimulate simultaneously two muscular groups with only one channel.
Does the power decrease using the Y cables?
The supplied intensity for each channel does not vary. If you use the Y cables on only
one channel the current is logically distributed on a greater muscular area consequently
the contraction will be less pronounced. Increase the intensity until the correct contraction is reached.
ELITE MULTIRev. 2.1
27
What to do when the discharged battery indicator appears?
You can continue your stimulation until it starts diminishing; then turn off the unit,
disconnect the electrode cables and connect the charger to the special plug. Connect
the charger to an external socket 220 V.
The electro stimulation can hurt me?
It is very difficult that electro stimulation can cause muscular problem. A very important principle to follow during stimulation is to increase the intensity gradually and to
avoid pain.
Is it possible to use the electric stimulator during the menstrual cycle?
Possible interferences, like anticipations, delays, accentuations or reductions of the cycle
can be subjective and variable. It is however advisable to avoid treatments in the
abdominal zone during the cycle.
Is it possible to use the electric stimulator during lactation?
Until now, it has not found collateral effects in relation to the electric stimulator use
during lactation. It is however advisable not to treat the thoracic zone.
Does the presence of dermatological diseases like psoriasis, urticaria, etc. prevent the
electric stimulator use?
Yes, it is advisable not to treat epidermic zones, which present important dermatological diseases.
When is it possible to see the first results?
The aesthetic results obtained are always subjective. It is however possible to state
that you can achieve good results about tonicity after 15 days with 3 or 4 sessions a
week; for lypolysis and drainage treatment at least 40 days are necessary. Better and
speeder results are obtained if treatments are combined with a good physical activity
and a correct life style
How many sessions I can weekly perform?
As regards the physical training we suggest you to follow the weekly program indications reported on the Globus Personal Trainer. The weekly frequency of Fitness and
aesthetic program can be varied according to the kind of treatment. Toning treatments
for example should be performed 3 - 4 times a week Lypolysis and drainage instead
can be used every day.
ELITE MULTIRev. 2.1
28
Warranty terms
Warranty terms
This product is guaranteed to the first user for a 24-month period from the purcha-
se date against material defects or manufacturing, provided that it is used properly
and maintained in the normal efficiency conditions.
To enjoy the guarantee service, the user must observe the following guarantee articles:
1) The products must be delivered for repairing by the User in their original packaging, the expenses are charged to the User.
2) The product guarantee depends on the presentation of fiscal document (cash voucher, fiscal receipt or selling invoice) and certifying the purchase date of the product.
3) The repairing will not have effect on the original date of guarantee expiration and
will not mean the renewing or extension of the guarantee .
4) When during the repairing will not be found any defect, will be in any case charged the expenses related to the checking time.
5) The guarantee doesn't have effect in case of damages by bits, falls, improper or
incorrect use, not original external supply, accidents, alterations, changes / removal of
guarantee seals and / or product infringement. The guarantee doesn't cover the damages caused during the transportation due to the use of inadequate boxing (see art.
1).
6) The guarantee doesn't cover the impossibility of using the product, other occasional or consequential expenses or other purchaser expenses.
ATTENTION: Before returning the machine to be repaired, it is recommended to carefully read the user manual instructions. In case of device breakdowns, contact the
shopkeeper before. The fabricant can make at any moment all the necessary modifications to improve the product aesthetic and quality.
Produced by:
DOMINO S.R.L
Phone +390438793052
Fax +390438796463
E-mail: info@domino.tv.it
Loading...
