Elenco Projects 1-101 User Manual

Copyright © 2012, 2010 by Elenco®Electronics, Inc. All rights reserved. No part of this book shall be reproduced by 753102 any means; electronic, photocopying, or otherwise without written permission from the publisher.

REV-H Revised 2012

Patent # 7144255

Project 58

-1-

1. Most circuit problems are due to incorrect assembly, always double-check that your circuit exactly matches the drawing for it.

2. Be sure that parts with positive/negative markings are positioned as per the drawing.

3. Be sure that all connections are securely snapped.

4. Try replacing the batteries.

5. If the motor spins but does not balance the fan, check the black plastic piece with three prongs on the motor shaft. Be sure that it is at the top of the shaft.

Elenco

is not responsible for parts damaged due to

incorrect wiring.

Basic T roub leshooting

Note: If you suspect you have damaged parts, you can follow

the Advanced Troubleshooting procedure on page 6 to determine which ones need replacing.

Basic T roubleshooting 1 Parts List 2 How to Use It 3 About Your Snap Circuits

Parts 4

DO’s and DON’Ts of Building Circuits 5

Advanced T r oubleshooting 6 Project Listings 7 Projects 1 - 101 8 - 44 Other Snap Circuits

Projects 45

Snap Circuits

Project Shapes 46

WARNING: SHOCK HAZARD - Never connect Snap

Circuits®to the electrical outlets in your home in any wa y!

Table of Contents

WARNING: Always check your wiring

before turning on a circuit. Never leave a circuit unattended while the batteries are installed. Never connect additional batteries or any other power sources to your circuits. Discard an y cracked or broken parts.

Adult Supervision: Because children’s

abilities var

y so much, even with age groups, adults should exercise discretion as to which experiments are suitable and safe (the instructions should enable supervising adults to

establish the experiment’s suitability for the child). Make sure your child reads and follows all of the relevant instructions and safety procedures, and keeps them at hand for reference.

This product is intended for use by adults and children who have attained sufficient maturity to read and follow directions and warnings.

Never modify your parts, as doing so may disable important safety features in them, and could put your child at risk of injury.

W ARNING FOR ALL PROJECTS WITH A SYMBOL - Moving parts. Do not touch the motor or f an during operation.

Do not lean over the motor. Do not launch the fan at people, animals, or objects. Eye protection is recommended.

WARNING: CHOKING HAZARD -

Small parts. Not for children under 3 years.

Conforms to

ASTM

F963-96A

• Use only 1.5V AA type, alkaline

batteries (not included).

• Insert batteries with correct polarity.

• Non-rechargeable batteries should not

be recharged. Rechargeable batteries should only be charged under adult supervision, and should not be recharged while in the product.

• Do not mix old and new batteries.

• Do not connect batteries or battery holders in parallel.

• Do not mix alkaline, standard (carbonzinc), or rechargeable (nic kel-cadmium) batteries.

•

Remove batteries when they are used up.

• Do not short circuit the battery terminals.

• Never throw batteries in a fire or attempt to open its outer casing.

• Batteries are harmful if swallowed, so keep away from small children.

Batteries:

Note: If you have the more advanced Models SC-300, SC-500, or SC-750, there are additional part lists in the other project manuals.

Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:

help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.

Qty. ID Name Symbol Par t # Qty. ID Name Symbol Par t #

 1

Base Grid (11.0” x 7.7”)

6SCBG

 1

Red Light Emitting Diode (LED)

6SCD1

 3

1-Snap Wire 6SC01

 1

2.5V Lamp 6SCL1

 6

2-Snap Wire 6SC02

 1

Battery Holder -

uses

2 1.5V type AA (not included)

6SCB1

 3

3-Snap Wire 6SC03

 1

Speaker 6SCSP

 1

4-Snap Wire 6SC04

 1

Music Integrated Circuit

6SCU1

 1

5-Snap Wire 6SC05

 1

Alarm Integrated Circuit

6SCU2

 1

6-Snap Wire 6SC06

 1

Space War Integrated Circuit

6SCU3

 1

Whistle Chip 6SCWC

 1  1

Motor Fan

6SCM1

6SCM1F

 1

Slide Switch 6SCS1

 1

100Ω Resistor 6SCR1

 1

Press Switch 6SCS2

 1  1

Jumper Wire (Black) Jumper Wire (Red)

6SCJ1 6SCJ2

 1

Photoresistor 6SCRP

You may order additional / replacement parts at our website: www.snapcircuits.net

-2-

Parts List (Colors and styles may vary) Symbols and Numbers

-3-

The Electronic Snap Circuits®kit has 101 projects. They are simple to build and understand.

The Snap Circuits

kit uses building bloc ks with snaps to build the different electrical and electronic circuits in the projects. Each block has a function: there are switch blocks, lamp blocks, battery bloc ks, diff erent length wire b loc ks, etc. These blocks are in different colors and have numbers on them so that you can easily identify them. The circuit you will build is shown in color and with numbers, identifying the blocks that you will use and snap together to form a circuit.

For Example:

This is the switch block which is green and has the marking on it as shown in the drawings. Please note that the drawing doesn’t reflect the real switch bloc k e xactly (it is missing the ON and OFF markings), but gives you the general idea of which part is being used in the circuit.

This is a wire block which is blue and comes in different wire lengths. This one has the number , , , , or on it depending on the length of the wire connection required.

There is also a 1-snap wire that is used as a spacer or for interconnection between different layers.

To build each circuit, you have a power source block number that needs two (2) “AA” batteries (not included with the Snap Circuits

kit).

A large clear plastic base grid is included with this kit to help keep the circuit blocks properly spaced. You will see evenly spaced posts that the different blocks snap into. You do not need this base to build your circuits, but it does help in keeping your circuit together neatly. The base has rows labeled A-G and columns labeled 1-10.

Next to each part in every circuit drawing is a small number in black. This tells you which level the component is placed at. Place all parts on lev el 1 first, then all of the parts on level 2, then all of the parts on level 3, etc.

Usually when the motor is used, the fan will usually be placed on it. On top of the motor shaft is a black plastic piece (the motor top) with three little tabs. Lay the fan on the black piece so the slots in its bottom “fall into place” around the three tabs in the motor top. If not placed properly, the fan will fall off when the motor starts to spin.

Some circuits use the jumper wires to make unusual connections. Just clip them to the metal snaps or as indicated.

Note: While building the projects, be careful not to accidentally make a direct connection across the battery holder (a “short circuit”), as this may damage and/or quickly drain the batteries.

How To Use It

2 3 4 5 6

(Part designs are subject to change without notice).

Note: If you have the more advanced Models SC-300, SC-500, or SC-750, there is additional inf

ormation in your other project manual(s).

The base grid functions like the printed circuit boards found in most electronic products.

It is a platform for mounting parts and wires (though the

wires are usually “printed” on the board. The blue snap wires are just wires used to connect other components, they

are used to transpor

t electricity and do not affect circuit performance. They come in different lengths to allow orderly arrangement of connections on the base grid.

The red and black jumper wires make flexible connections for times when using the snap wires would be difficult.

They also are used to make

connections off the base grid (like the projects using water). The batteries (B1) produce an electrical voltage using a chemical reaction.

This “v

oltage” can be thought of as electrical pressure, pushing electrical “current” through a circuit. This voltage is much lower and much safer than that used in your house wiring. Using more batteries increases the “pressure” and so more electricity flows.

The slide switch (S1) connects (ON) or disconnects (OFF) the wires in a circuit.

When ON it has no effect on circuit performance.

The press switch (S2) connects (pressed) or disconnects (not pressed) the wires in a circuit, just like the slide s

witch does.

Resistors, such as the 100Ω resistor (R1), “resist” the flow of electricity and are used to control or limit the electricity in a circuit.

Increasing circuit

resistance reduces the flow of electricity. The photoresistor (RP) is a light-sensitive resistor, its value changes from

nearly infinite in total darkness to about 1000Ω when a bright light shines on it. A light bulb, such as in the 2.5V lamp (L1), contains a special wire that glows

bright when a large electric current passes through it. Voltages above the bulb’s rating can burn out the wire.

The motor (M1) converts elecricity into mechanical motion. Electricity is closely related to magnetism, and an electric current flo

wing in a wire has a magnetic field similar to that of a very, very tiny magnet. Inside the motor is three coils of wire with many loops. If a large electric current flows through the loops, the magnetic effects become concentrated enough to move the coils. The motor has a magnet inside so, as the electricity moves the coils to align them with the permanent magnet, the shaft spins.

The speaker (SP) converts electricity into sound. It does this by using the energy of a changing electrical signal to create mechanical vibr

ations (using

a coil and magnet similar to that in the motor), these vibrations create variations in air pressure which travel across the room. You “hear” sound when your ears feel these air pressure variations.

The whistle chip (WC) contains two thin plates. When an electrical signal is applied across them the

y will stretch slightly in an eff

ort to separate (like two magnets opposing each other), when the signal is removed they come back together. If the electrical signal applied across them is changing quickly, then the plates will vibrate. These vibrations create variations in air pressure that your ears feel just like sound from a speaker.

The LED (D1) is a light emitting diode, and may be thought of as a special one-wa

y light bulb. In the “forward” direction (indicated by the “arrow” in the

symbol) electricity flows if the voltage exceeds a turn-on threshold (about

1.5V); brightness then increases. A high current will burn out the LED, so the current must be limited by other components in the circuit. LEDs block electricity in the “reverse” direction.

Some types of electronic components can be super-miniaturized, allowing many thousands of parts to fit into an area smaller that your fingernail. These “integrated circuits” (ICs) are used in everything from simple electronic toys to the most advanced computers. The music, alarm, and space war ICs (U1, U2, and U3) in Snap Circuits

are actually modules containing specialized sound-generation ICs and other supporting components (resistors, capacitors, and transistors) that are always needed with them. This was done to simplify the connections you need to make to use them. The descriptions for these modules are given here for those interested, see the projects for connection examples:

(+)

HLD

OUT

(–)

TRG

IN1

(–)

IN2

IN3

OUT

IN1

(+)

OUT

IN2

(–)

Music IC:

(+) - power from batteries (–) - power return to batteries OUT - output connection HLD - hold control input TRG - trigger control input

Music for a few seconds on power-up, then hold HLD to (+) power or touch TRG to (+) power to resume music.

Alarm IC:

IN1, IN2, IN3 - control inputs (–) - power return to batteries OUT - output connection

Connect control inputs to (+) power to make five alarm sounds, see project 22 for configurations.

Space War IC:

(+) - power from batteries (–) - power return to batteries OUT - output connection IN1, IN2 - control inputs

Connect each control input to (–) power to sequence through 8 sounds.

-4-

About Your Snap Circuits®Parts

Our Student Guides give much more information about your parts along with a complete lesson in basic electronics. See www.snapcircuits.net/learn.htm or page 45 for more information.

-5-

DO’s and DON’Ts of Building Circuits

After building the circuits given in this booklet, you ma y wish to e xperiment on your own. Use the projects in this booklet as a guide, as many important design concepts are introduced throughout them. Every circuit will include a power source (the batteries), a resistance (which might be a resistor, lamp, motor, integrated circuit, etc.), and wiring paths between them and back. You must be careful not to create “shor t circuits” (very

low-resistance paths across the batter

ies, see examples below) as this

will damage components

and/or quickly drain your batteries. Only

connect the ICs using configurations given in the projects, incorrectly doing so may damage them. Elenco®is not responsible for parts

damaged due to incorrect wiring.

Here are some important guidelines:

ALWAYS

USE EYE PROTECTION WHEN EXPERIMENTING ON YOUR O WN.

ALWAYS

include at least one component that will limit the current through a circuit, such as the speaker, lamp, whistle chip, ICs (which must be connected properly), motor, photoresistor, or resistor.

ALWAYS

use the LED and switches in conjunction with other components that will limit the current through them. Failure to do so will create a short circuit and/or damage those par ts.

ALWAYS

disconnect your batteries immediately and check your wiring if something appears to be getting hot.

ALWAYS

check your wiring before turning on a circuit.

ALWAYS

connect ICs using configurations given in the projects or as per the connection descriptions for the parts.

NEVER

connect to an electrical outlet in your home in any way.

NEVER

leave a circuit unattended when it is turned on.

NEVER

touch the motor when it is spinning at high speed.

Note: If you have the more advanced Models SC-300, SC-500, or SC-750, there are additional guidelines in your other project manual(s).

For all of the projects given in this book, the parts may be arranged in different ways without changing the circuit. For example, the order of parts connected in series or in parallel does not matter — what matters is how combinations of these sub-circuits are arranged together.

Examples of SHORT CIRCUITS - NEVER DO THESE!!!

You are encouraged to tell us about new circuits you create. If they are unique, we will post them with your name and state on our website at www.snapcircuits.net/kidkreations.htm. Send your suggestions to Elenco

Elenco®provides a circuit designer so that you can make your own Snap Circuits®drawings. This Microsoft®Word document can be downloaded from www.snapcircuits.net/SnapDesigner.doc or through the

www.snapcircuits.net website.

WARNING: SHOCK HAZARD - Nev

er connect Snap Circuits®to

the electrical outlets in your home in any way!

Placing a 3-snap wire directly across the batteries is a SHORT CIRCUIT.

This is also a

SHORT CIRCUIT.

When the slide switch (S1) is turned on, this large circuit has a SHORT CIRCUIT path (as shown by the arrows). The short circuit prevents any other portions of the circuit from ever working.

NEVER

DO!

NEVER

DO!

NEVER

DO!

NEVER

DO!

Warning to Snap Rover owners: Do not connect your parts to the

Rover body except when using our approved circuits, the Rover body has a higher voltage which could damage your parts.

NEVER

DO!

-6-

Advanced Troubleshooting (Adult supervision recommended)

Elenco

is not responsible for parts damaged due to incorrect

wiring.

If you suspect you have damaged parts, you can follow this procedure to systematically determine which ones need replacing:

1.2.5V lamp (L1), motor (M1), speaker (SP), and battery holder

(B1): Place batteries in holder. Place the 2.5V lamp directly

across the battery holder

, it should light. Do the same with the motor (motor + to battery +), it should spin to the right at high speed. “Tap” the speaker across the battery holder contacts, you should hear static as it touches. If none work, then replace your batteries and repeat, if still bad then the battery holder is damaged.

2.Jumper wires: Use this minicircuit to test each jumper wire, the lamp should light.

3.Snap wires: Use this minicircuit to test each of the snap wires, one at a time

. The lamp

should light.

4.Slide switch (S1) and Press switch (S2): Build project #1, if the lamp (L1) doesn’t light then the slide switch is bad.

Replace

the slide switch with the press switch to test it.

5.100Ω resistor (R1) and LED (D1): Build project #7 except initially use the speaker (SP) in place of the resistor

, the LED should light. Then replace the speaker with the resistor; the LED should still light.

6.Alarm IC (U2): Build project #17, you should hear a siren. Then place a 3-snap wire between g

rid locations A1 and C1, the sound is different. Then move the 3-snap from A1-C1 to A3-C3 to hear a 3rd sound.

7.Music IC (U1): Build project #74 but use the press switch (S2) in place of the photoresistor (RP).

Turn it on and the LED (D1) flickers for a while and stops, it resumes if you press and hold down the press switch. Then touch a 3-snap wire across base grid points A1 and C1 and the flickering resumes for a while.

8.Space war IC (U3) and photoresistor (RP): Build project #19, both switches (S1 and S2) should change the sound.

Then replace the slide switch with the photoresistor, waving your hand over it should change the sound.

9.Whistle chip (WC): Build project #61 and if there is light on the photoresistor (RP) then you will hear sound from the whistle chip

Note: If you have the more advanced models SC-300, SC-500, or SC-750, there are additional tests in your other project manual(s).

ELENCO

150 Carpenter Avenue

Wheeling, IL 60090 U.S.A.

Phone: (847) 541-3800

Fax: (847) 520-0085

e-mail: help@elenco.com

Website: www.elenco.com

You may order additional / replacement parts at:

www.snapcir

cuits.net

-7-

Project # Description Page #

1 Electric Light & Switch 8 2 DC Motor & Switch 8 3 Sound Activated Switch 9 4 Adjusting Sound Level 9 5 Lamp & Fan in Series 10 6 Lamp & Fan in Parallel 10 7 Light Emitting Diode 11 8 One Direction for LED 11

9 Conduction Detector 12 10 Space War Alarm Combo 12 11 Flying Saucer 13 12 Decreasing Saucer Lift 13 13 Two-Speed Fan 14 14 The Fuse 14 15 Musical Doorbell 15 16 Momentary Alarm 15 17 Alarm Circuit 16 18 Laser Gun 16 19 Space War 17 20 Light Switch 17 21 Paper Space War 17 22 Light Police Siren 18 23 More Loud Sounds 18 24 More Loud Sounds (II) 18 25 More Loud Sounds (III) 18 26 More Loud Sounds (IV) 18 27 Clap Sounds 19 28 More Clap Sounds 19 29 More Clap Sounds (II) 19 30 More Clap Sounds (III) 19 31 More Clap Sounds (IV) 19 32 Voice Light Diode 20 33 Voice Control 20 34 Motor Space Sounds 20

Project # Description Page #

35 Motor Space Light 20 36 Space Battle (II) 21 37 Silent Space Battle 21 38 Periodic Sounds 21 39 Blinking Double Flashlight 21 40 Motor-Controlled Sounds 22 41 More Motor Sounds 22 42 More Motor Sounds (II) 22 43 More Motor Sounds (III) 22 44 More Motor Sounds (IV) 22 45 Light-Controlled Flicker 23 46 More Sound Effects 23 47 This OR That 24 48 This AND That 24 49 Neither This NOR That 25 50 NOT This AND That 25 51 Reflection Detector 26 52 Quieter Reflection Detector 26 53 Flashing Laser Light with Sound 27 54 Space War Flicker 27 55 Spinning Rings 28 56 Strobe the House Lights 28 57 Race Game 29 58 Using Parts as Conductors 29 59 Spin Draw 30 60 Space War Flicker Motor 30 61 Light-Controlled Sounds 31 62 Light-Controlled Sounds (II) 31 63 Light-Controlled Sounds (III) 31 64 Light-Controlled Sounds (IV) 31 65 Light-Controlled Sounds (V) 31 66 Electronic Bombing Game 32 67 Quiet Zone Game 33 68 Space War Music Combo 33

Project # Description Page #

69 Space War Siren 34 70 Quiet Water Alarm 34 71 Light-Controlled Lamp 35 72 Voice-Controlled Lamp 35 73 Motor-Controlled Lamp 35 74 Light-Controlled LED 36 75

Sound-Controlled Time Delay LED

Motor-Controlled Time Delay LED

36 77 Space War Flicker LED 37 78 Music AND Gate 37 79 Flash and Tone 37 80

Lamp, Speaker & Fan in Parallel

38 81 Pencil Alarm 38 82 Pencil Alarm Variants 38 83 Fun with the Alarm IC 39 84 Motor Sounds Combo 39 85 Motor Sounds Combo (II) 39 86 Music Alarm Combo 40 87 Bomb Sound 40 88 Bomb Sound (II) 40 89 Light-Controlled LED (II) 41 90 Touch Light 41 91 Touch Sound 41 92 Wacky Sounds 41 93 Wackier Sounds 42 94 Really Wacky Sounds 42 95 Noisier Water Space War 43 96 Light/Water Space War 43 97 OR/AND Space War Light 43 98 Simple Water Alarm 44 99 Simple Salt Water Alarm 44

100 Ambulance Water Alarm 44 101 Ambulance Contact Alarm 44

Project Listings

-8-

Project #1

OBJECTIVE: To show ho w electricity is turned “ON” or “OFF” with a switch.

Electric Light & Switch

Project #2

OBJECTIVE: To show how electricity is used to run a Direct Current (DC) Motor.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2.

When you close the slide switch (S1), current flows from the batteries (B1) through the motor (M1) making it rotate. Place the fan blade on the motor shaft and close the slide switch. The motor will rotate f orcing the fan blade to move air past the motor.

In this project, you changed electrical power into mechanical power. DC motors are used in all the battery powered equipment requiring rotary motion, such as a cordless drill, electric toothbrush, and toy trains that run on batteries just to name a few. An electric motor is much easier to control than gas or diesel engines.

DC Motor & Switch

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2. Install two (2) “AA” batteries (not included) into the batter y holder (B1).

When you close the slide switch (S1), current flows from the batteries through the lamp and back to the battery through the switch. The closed switch completes the circuit. In electronics this is called a closed circuit. When the slide switch is opened, the current can no longer flow back to the battery, so the lamp goes out. In electronics this is called an open circuit.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean o ver the motor.

-9-

Project #3

OBJECTIVE: To show how sound can turn “ON” an electronic device.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2. Finally, lay the speaker (SP) on the table and connect it to the circuit using the jumper wires as shown.

When you close the slide switch (S1), the music may play for a short time, and then stop. After the music has stopped, clap your hands close to the whistle chip (WC) or tap the base with your finger. The music should play again f or a short time, then stop. Blow on the whistle chip and the music should play.

You could connect the speaker using snap wires instead of the jumper wires, but then the speaker may create enough sound vibrations to reactivate the whistle chip.

Sound Activated Switch

Project #4

OBJECTIVE: To show how resistance can lower the sound from the speaker.

Build the circuit shown on the left.

When you close the slide switch (S1), the music may play for a short time and then stop. After the music has stopped, clap your hands close to the whistle chip (WC) or tap the base with your finger. The music should play again for a short time, then stop.

In this project, you changed the amount of current that goes through the speaker (SP) and reduced the sound output of the speaker. Resistors are used throughout electronics to limit the amount of current that flows.

Adjusting Sound Level

Visit www.snapcircuits.net or page 45 to learn about Snap Circuits®upgrade kits, which have more parts and circuits.

-10-

Project #5

OBJECTIVE: To show how a lamp can indicate when a fan is running.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2. Finally, place the fan blade on the motor (M1).

When you close the slide switch (S1), the fan will spin and the lamp (L1) should turn on. The fan will take a while to start turning due to inertia. Inertia is the property that tr ies to keep a body at rest from moving and tries to keep a moving object from stopping.

The light helps protect the motor from getting the full voltage when the slide switch is closed. Part of the voltage goes across the lamp and the rest goes across the motor. Remove the fan and notice how the lamp gets dimmer when the motor does not have to spin the fan blade.

Lamp & Fan in Series

Project #6

OBJECTIVE: To show how an indicator light can be connected without affecting the current in the motor.

Build the circuit shown on the left. When you close the slide switch (S1), both the fan and the lamp (L1)

should turn on. The fan will take a while to start turning due to inertia. In this connection, the lamp does not change the current to the motor (M1). The motor should start a little faster than in Project #5.

Remove the fan and notice how the lamp does not change in brightness as the motor picks up speed. It has its own path to the battery (B1).

Lamp & Fan in Parallel

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean o ver the motor.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean o ver the motor.

-11-

Project #7

OBJECTIVE: To show ho w a resistor and LED are wired to emit light.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2.

When you close the slide switch (S1), current flows from the batteries (B1) through the slide switch, through the resistor (R1), through the LED (light emitting diode, D1) and back to the battery. The closed slide switch completes the circuit. The resistor limits the current and prevents damage to the LED. NEVER PLACE AN LED DIRECTLY ACROSS THE BATTERY! If no resistor is in the circuit, the battery may push enough current through the LED to damage the semiconductor that is used to produce the light. LEDs are used in all types of electronic equipment to indicate conditions and pass information to the user of that equipment.

Can you think of something you use everyday that has an LED in it?

Light Emitting Diode

Project #8

OBJECTIVE: To show how electricity can only pass in one direction through an LED.

Rebuild the circuit used in Project #7 but put the LED (D1) in as shown on the left.

When you close the slide switch (S1), current should flow from the batteries (B1) through the resistor and then through the LED. When current flows through an LED, it lights up. Since the LED is in backwards, current cannot flow. The LED is like a check valve that lets current flow in only one direction.

In this project, you changed the direction of current through the LED. An electronic component that needs to be connected in one direction is said to have polarity. Other parts like this will be discussed in future projects. Placing the LED in backwards does not harm it because the voltage is not large enough to break down this electronic component.

One Direction for LED

-12-

Project #9

OBJECTIVE: To make a circuit that detects the conduction of electricity in different materials.

Rebuild the circuit from Project #7 but leave the slide switch (S1) out as shown on the left.

When you place a metal paper clip across the terminals as shown in the picture on the left, current flows from the batteries (B1) through the resistor (R1), through the LED (D1), and back to the battery. The paper clip completes the circuit and current flows through the LED. Place your fingers across the terminals and the LED does not light. Your body has too high of a resistance to allow enough current to flow to light the LED . If the v oltage, which is electrical pressure, w as higher , current could be pushed through your fingers and the LED would light. This detector can be used to see if a material like plastic is a good conductor or a poor conductor.

Conduction Detector

Project #10

OBJECTIVE: To combine the sounds from the space war and

alarm integrated circuits.

Build the circuit shown and add the jumpers to complete it. Turn it on, press the press switch (S2) several times, and wave your hand over the photoresistor (RP) to hear all the sound combinations. If the sound is too loud you may replace the speaker (SP) with the whistle chip (WC).

Space War Alarm Combo

To learn more about how circuits work, visit www.snapcircuits.net or page 45 to find out about our Student Guides.

-13-

Project #11

OBJECTIVE: To make a circuit that launches the fan blade to simulate a flying saucer.

Rebuild the circuit from Project #2, but reverse the polarity on the motor (M1) so the negative (–) on the motor goes to the positive (+) on the battery (B1). New alkaline batteries are recommended for this project.

When you close the slide switch (S1), the motor will slowly increase in speed. When the motor has reached maximum rotation, turn the slide switch off. The fan blade should rise and float through the air like a flying saucer. Be careful not to look directly down on fan b lade when it is spinning.

The air is being blown down through the blade and the motor rotation locks the fan on the shaft. When the motor is turned off, the blade unlocks from the shaft and is free to act as a propeller and fly through the air. If speed of rotation is too slow, the fan will remain on motor shaft because it does not have enough lift to propel it. The motor will spin faster when both batteries are new.

If the fan doesn’t fly off, then turn the switch on and off several times rapidly when it is at full speed.

Flying Saucer

Project #12

OBJECTIVE: To show how voltage affects speed of a DC motor and can decrease the lift of the saucer.

Change the circuit in Project #11 by adding the lamp (L1) in series with the motor as shown in the diagram on the left.

When you place the lamp in series with any electronic device, it will draw less current because it adds resistance. In this case, the lamp in series reduces the current through the motor, and that reduces the top speed of the motor. Close the slide switch (S1), and wait until the fan reaches maximum speed. Open the s witch and observe the difference in the height due to the lamp. In most cases, it may not even launch.

Decreasing Saucer Lift

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean over the motor.

WARNING: Fan may not

rise until switch is released.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean over the motor.

WARNING: Fan may not

rise until switch is released.

-14-

Project #13

OBJECTIVE: To show how switches can increase or decrease the speed of an electric fan.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the board first. Then, assemble parts marked with a 2. Finally, add the 2-snap wires that are marked for level three.

When you close the slide switch (S1), current flows from the batteries through the slide switch (S1), motor (M1), the lamp (L1), and back to the battery (B1). When the press switch (S2) is closed, the lamp is shorted and motor speed increases.

The principle of removing resistance to increase motor speeds is only one way of changing the speed of the motor. Commercial fans do not use this method because it would produce heat in the resistor and fans are used to cool circuits by moving air over them. Commercial fans change the amount of voltage that is applied to the motor using a transformer or other electronic device.

Two-Speed Fan

OBJECTIVE: To show how a fuse is used to break all current paths back to the voltage source.

Use the circuit built in Project #13. When you close the slide switch (S1), current flows from the batteries

through the slide switch (S1), the lamp (L1), motor (M1), and back to the battery (B1). Pretend the 2-snap wire marked fuse in the drawing on the left is a device that will open the circuit if too much current is taken from the battery. When press switch (S2) is closed, the light is shorted and motor speed increases due to an increase in current to the motor. While still holding press switch (S2) down, remove the 2-snap wire marked fuse and notice how everything stops. Until the fuse is replaced, the open circuit path protects the electronic parts. If fuses did not exist, many parts could get hot and even start fires. Replace the 2-snap wire and the circuit should return to normal.

Many electronic products in your home hav e a fuse that will open when too much current is drawn. Can you name some?

The FuseProject #14

WARNING: Moving

parts. Do not touch the fan or motor during operation. Do not lean over the motor.

WARNING: Moving

parts. Do not touch the fan or motor during operation. Do not lean over the motor.

-15-

Project #15

OBJECTIVE: To show how an integrated circuit can be used as a musical doorbell.

Build the circuit shown on the left. When you close the slide switch (S1), the music integrated circuit (U1) may start playing one song then stop. Each time you press the press switch “doorbell button” (S2) the song will play again and stop. Even if you let go of the press switch (S2), the integrated circuit keeps the song playing until it has reached the end of the song.

Musical integrated circuits are used to entertain young children in many of the toys and chairs made to hold infants. If the music is replaced with words, the child can also learn while they are entertained. Because of great advances in miniaturization, many songs are stored in a circuit no bigger than a pinhead.

Musical Doorbell

Project #16

OBJECTIVE: To show how integrated circuits can also create loud alarm sounds in case of emergencies.

Modify the circuit used in Project #15 to look like the one shown on the left.

When you close the slide switch (S1), the music integ r ated circuit (U1) may start playing one song then stop. The song will be much louder than in the previous project because it is now being used as an alarm. Each time you press the press switch “alarm button” (S2) after the song stops playing, the song will play again, but only while you hold the button down.

Momentary Alarm

Visit www.snapcircuits.net or page 45 to learn about more Snap Circuits®products to add to your collection.

-16-

Project #17

OBJECTIVE: To show how an integrated circuit can be used to make real alarm sounds.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the board first. Then, assemble parts marked with a 2.

When you close the slide switch (S1), the integr ated circuit (U2) should start sounding a very loud alarm sound. This integrated circuit is designed to sweep through all the frequencies so even hard of hearing people can be warned by the alarm.

If the alarm sound was passed through an amplifier and installed into a police car, it would also serve as a good police siren.

Alarm Circuit

Project #18

OBJECTIVE: To show how integrated circuits sound can easily be changed to exciting space war sounds.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2.

When you close the slide switch (S1), the integr ated circuit (U2) should start sounding a laser gun sound. This integrated circuit is designed to produce different sounds that can easily be changed. You can even switch the sound on and off quickly to add sound eff ects to your games or recordings.

Laser Gun

-17-

Project #19

OBJECTIVE: To introduce you to the space war integrated circuit and the sounds it can make.

Build the circuit shown on the left, which uses the space war integrated circuit (U3). Activate it by flipping the slide switch (S1) or pressing the press switch (S2); do both several times and in combination. You will hear an exciting range of sounds, as if a space war is raging!

Like the other integrated circuits, the space war IC is a superminiaturized electronic circuit that can play a variety of cool sounds stored in it by using just a few extra components.

In movie studios, technicians are paid to insert these sounds at the precise instant a gun is fired. Try making your sound occur at the same time an object hits the floor. It is not as easy as it sounds.

Space War

Project #20 Light Switch

OBJECTIVE: To show how light can control a circuit using a photoresistor.

Use the circuit from Project #19 above, but replace the slide switch (S1) with the photoresistor (RP). The circuit immediately makes noise. Try turning it off. If you experiment, then you can see that the only ways to turn it off are to cover the photoresistor, or to turn off the lights in the room (if the room is dark). Since light is used to turn on the circuit, you might say it is a "light switch".

The photoresistor contains material that changes its resistance when it is exposed to light. As it gets more light, the resistance of the photoresistor decreases. Parts like this are used in a number of ways that affect our lives. For example, you may have streetlights in your neighborhood that turn on when it starts getting dar k and turn off in the morning.

Project #21 Paper Space War

OBJECTIVE: To give a more dramatic demonstration of using the photoresistor.

Use the same circuit as for Project #20. Find a piece of white paper that has a lot of large black or dark areas on it, and slowly slide it over the photosensitive resistor. You should hear the sound patter n constantly changing, as the white and dark areas of the paper control the light to the photosensitive resistance. You can also try the pattern below or something similar to it:

-18-

Project #22

OBJECTIVE: To build a police siren that is controlled by light.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2. Finally, inser t the parts with a 3 last on level 3.

Cover the photoresistor (RP) and turn on the slide switch (S1). A police siren with music is heard for a while and stops, then you can control it by covering or uncovering the photoresistor.

Light Police Siren

Project #23

More Loud

Sounds

OBJECTIVE: To show variations of the circuit in Project #22.

Project #24

More Loud

Sounds (II)

OBJECTIVE: To show variations of the circuit in Project #22.

Project #26

More Loud

Sounds (IV)

OBJECTIVE: To show variations of the circuit in Project #22.

Project #25

More Loud

Sounds (III)

Modify the Project #22 by connecting points X & Y. The circuit works the same way but now it sounds like a machine gun with music.

Now remove the connection between X & Y and then make a connection between T & U. The circuit works the same way but now it sounds like a fire engine with music.

Now remove the connection between T & U and then make a connection between U & Z. The circuit works the same way but now it sounds like an ambulance with music.

Now remove the connections between U & Z and between V & W, then make a connection between T & U. The circuit works the same way but now it sounds like a familiar song but with static.

Visit www.snapcircuits.net or page 45 to learn about Snap Circuits®upgrade kits, which have more parts and circuits.

-19-

Project #27

OBJECTIVE: To build a police siren and other sounds that are controlled by clapping your hands.

Build the circuit shown on the left by placing all the parts with a black 1 next to them on the base grid first. Then, assemble parts marked with a 2.

Turn on the slide switch (S1) and a police siren is heard and then stops, clap your hands and it will play again. Note however that music can be heard faintly in the background of the siren. If clapping does not trigger the sound, tap the whistle chip (WC) with your finger.

Clap Sounds

Project #28

More Clap

Sounds

OBJECTIVE: To show how ICs can do many jobs.

Project #29

More Clap

Sounds (II)

OBJECTIVE: To show how ICs can do many jobs.

OBJECTIVE: To show how

ICs can do many jobs.

Project #30

More Clap

Sounds (III)

Project #31

More Clap

Sounds (IV)

Modify the last circuit by connecting points X & Y using the black jumper wire. The circuit works the same way but now it sounds like a machine gun.

Now remove the connection between X & Y and then make a connection between T & U. The circuit works the same way but now it sounds like a fire engine.

Now remove the connection between T & U and then make a connection between U & Z. The circuit works the same way but now it sounds like an ambulance.

Now remove the connections between U & Z and between V & W, then make a connection between T & U. The circuit works the same way but now it sounds like a familiar song but with static.

-20-

Project #32 Voice Light Diode

OBJECTIVE: To build a circuit that uses your voice to control a light emitting diode.

Build the circuit shown on the left and turn on the slide switch (S1). The LED (D1) may be on for a while and then turn off. Clap or talk loud and the LED will light again and keep flickering for a little while.

OBJECTIVE: To use your voice to control sounds.

Project #34

Motor Space Sounds

OBJECTIVE: To build a circuit that uses a motor to activate space war sounds.

OBJECTIVE: To build a circuit that uses a motor to activate a light diode.

This circuit is loud and may bother other people around you so replace the speaker with the LED (D1), (position it like in Project #32); the circuit operates in the same manner.

Project #35

Motor

Space Light

Turn it on and wait for any sounds to stop then spin the motor (M1) and the sounds play again.

Do you know why turning the motor makes the sound play? Actually, the DC motor is also a DC generator and when you turn it, the motor generates a voltage that triggers the sound circuits.

Project #33

Voice Control

The preceding circuit probably did not seem too exciting; so replace the LED (D1) with the speaker (SP). You hear a range of exciting sounds. Clap or talk loud and the sounds will resume. If you find that the sound does not turn off, then vibrations created by the speaker may be activating the whistle chip (WC). Set the speaker on the table near the circuit and connect it to the same locations using the jumper wires to prevent this.

-21-

OBJECTIVE: To build a circuit with light and sound that change and repeat.

Project #39

Blinking

Double

Flashlight

Build the circuit shown on the left and turn it on. The lamp (L1) alternates between being on and off while the speaker (SP) alternates between two musical tones . . . like someone is flipping a switch, but at a very consistent rate. Periodic signals like this are very important in electronics.

Project #38 Periodic Sounds

Project #36 Space Battle (II)

OBJECTIVE: To show another way of using the space war integrated circuit.

Build the circuit shown on the left, which is based on the circuit in the Space War Project #19. Turn on the switch and you will hear exciting sounds, as if a space battle is raging!

The motor is used here as a 3-snap wire, and will not spin.

Project #37

Silent Space

Battle

OBJECTIVE: To show another way of using the space war part.

The preceding circuit is loud and may bother people around you, so replace the speaker (SP) with the LED (D1), position it as in Project #32. Now you have a silent space battle.

In the circuit at left, replace the speaker (SP) with an LED (D1); position it as in Project #32. The lamp alternates between being on and off while the LED alternates between being dimmer and brighter.

OBJECTIVE: To build a circuit with two lights that alternate.

To learn more about how circuits work, visit www.snapcircuits.net or page 45 to find out about our Student Guides.

-22-

Project #40

OBJECTIVE: To show how motion can trigger electronic circuits.

This circuit is controlled by spinning the motor (M1) with your hands. Turn on the slide switch (S1). A police siren is heard and then stops. Spin the motor and it will play again. Note howev er, that music can be heard faintly in the background of the siren.

Motor-Controlled Sounds

Project #41

More Motor

Sounds

OBJECTIVE: To show how motion can trigger electronic circuits.

Project #42

More Motor

Sounds (II)

OBJECTIVE: To show how motion can trigger electronic circuits.

Project #43

More Motor Sounds (III)

Project #44

More Motor

Sounds (IV)

Modify the last circuit by connecting points X & Y with the lamp (L1). The circuit works the same way but now it sounds like a machine gun.

Now remove the connection between X & Y and then make a connection between T & U with the lamp (L1). The circuit works the same way but now it sounds like a fire engine.

Now remove the connection between T & U and then make a connection between U & Z. The circuit works the same way but now it sounds like an ambulance.

Now remove the connections between U & Z and between V & W, then make a connection between T & U. The circuit works the same way but now it sounds like a familiar song but with static.

-23-

Project #45

OBJECTIVE: To make a circuit that uses light to control the blinking of another light.

This circuit does not use the noisy speaker (SP) it uses a nice quiet LED (D1). Turn on the slide switch (S1), the LED flickers. Wait a few seconds, then cover the photoresistor (RP) and the flicker stops. The flicker is controlled by the photoresistor, uncover it and the flicker resumes.

People who are deaf need lights to tell them when a doorbell is ringing. They also use circuits like this to tell them if an alarm has been triggered or an oven is ready.

Can you think of other uses?

Light-Controlled Flicker

Project #46

OBJECTIVE: To investigate the different sound effects available from the alarm integrated circuit.

Build the circuit shown on the left.

When you close the slide switch (S1), the integrated circuit (U2) should start sounding an up-down siren. This is just one more sound effect that this integrated circuit is designed to produce. Different sounds that can easily be changed are very important when designing games and toys. Switch the sound on and off quickly and see if you can create even different effects. This mode will create many robotic sounds if switched quickly.

More Sound Effects

-24-

Project #47

OBJECTIVE: To introduce you to the OR concept of electronic wiring.

Build the circuit shown. Notice that if you turn on the slide switch (S1) OR press the press switch (S2) the LED (D1) lights up. There is no partially lit state here, the diode is either totally on or totally off. While this may seem very simple and boring, it represents an important concept in electronics. Two switches like this may be used to turn on a light in your house, or they might be two sensors at a railroad crossing used to start the ding-ding sound and lower the gate. You could also have more than two switches and the circuit would function the same way.

This OR That

Project #48

OBJECTIVE: To introduce you to digital circuits.

Build the circuit shown. Notice that if you turn on the slide switch (S1) AND press the press switch (S2) the LED (D1) lights up. Once again, there is no partially lit state here, the LED is either totally on or totally off. Two switches like this may be used to turn on the same light in your house, the room switch and the master s witch in the electrical box. You could also have more than two switches and the circuit would function the same way.

Combinations of AND and OR circuits are used to add and multiply numbers together in modern computers. These circuits are made of tiny transistors in massive integrated circuits.

This AND That

Visit www.snapcircuits.net or page 45 to learn about more Snap Circuits®products to add to your collection.

-25-

Project #49

OBJECTIVE: To demonstrate the concept of a NOR circuit.

Build the circuit at left and test the combinations of the slide switch (S1) and press switch (S2). If you compare it to the OR circuit in Project #47, you can see the LED lights in the opposite combinations of that circuit. Hence, we refer to it as a NOR

circuit (short for “NOT this OR that”). Like the OR and AND, it is an important building block in computers.

Neither This NOR That

Project #50

OBJECTIVE: To demonstrate the concept of a NAND circuit.

Build the circuit at left and test the combinations of the slide switch (S1) and press switch (S2). If you compare it to the AND circuit in Project #48, you can see the LED (D1) lights in the opposite combinations of that circuit. Hence, we refer to it as a NAND circuit (short for “NOT this AND that”). This circuit can also hav e more or less than two inputs, though when it only has one input it is referred to as a NOT

circuit. Like the OR, AND, and NOR, NAND and NOT are

important building blocks in computers.

NOT This AND That

-26-

Project #51

OBJECTIVE: To detect if a mirror is present.

Build the circuit at left. Place it where there won’t be any room light hitting the photoresistor (RP) (such as in a dark room or under a table), and then turn it on. The 2.5V lamp (L1) will be bright, but there should be no sound.

Take a small mirror and hold it over the lamp and photoresistor. You should hear sound now. You have a reflection detector! You can also use a white piece of paper instead of a mirror, since white surfaces reflect light.

Reflection Detector

Project #52

OBJECTIVE: To detect a mirror.

Quieter Reflection Detector

-27-

Project #53

OBJECTIVE: To build the circuit used in a toy laser gun with flashing laser light and trigger.

When you press the press switch (S2), the integrated circuit (U2) should start sounding a very loud laser gun sound. The red LED will flash simulating a burst of laser light. You can shoot long repeating laser burst, or short zaps by tapping the press switch.

Flashing Laser Light

with Sound

Project #54

OBJECTIVE: To build a circuit using the space war IC to make exciting sounds.

Build the circuit shown on the left, which uses the Space War integrated circuit (U3).

Set the slide switch (S1) on and the speaker (SP) makes exciting sounds. The output of the IC can control lights, speakers, and other low power devices.

You may replace the speaker with the 2.5V lamp (L1), and the bulb will flicker. You can also use the LED (D1) in place of the lamp (position it with the “+” side towards the 6-snap).

Space War Flicker

Visit www.snapcircuits.net or page 45 to learn about Snap Circuits®upgrade kits, which have more parts and circuits.

-28-

Project #55

OBJECTIVE: To build an electronic spinner.

Setup: Cut out the disc on page 46 that looks like the one shown here. Using Scotch tape, attach the disc with the printed side up on the top of the fan blade. Place the blade on the motor (M1) as shown to the left and below.

When the press switch (S2) is pressed, the arcs will turn into colored rings with a black background. Notice how the color drops in brightness when it is stretched to make a complete circle.

Spinning Rings

Project #56

OBJECTIVE: To use the spinner to see strobe effect due to 60 cycles.

Use the circuit from Project #55. Setup: Place the spinning rings under a fluorescent light that runs on

normal house current. Start the disc spinning and release the press switch (S2). As the speed changes you will notice the white lines first seem to move in one direction then they start moving in another direction. This effect is because the lights are blinking 60 times a second and the changing speed of the motor is acting like a strobe light to catch the motion at certain speeds. To prove this, try the same test with a flashlight. The light from a flashlight is constant and if all other lights are out, you will not see the effect that looks like a helicopter blade in a movie. Some fluorescent lights use an electronic ballast and they also produce a constant light.

Strobe the House Lights

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean o ver the motor.

-29-

Project #58

OBJECTIVE: To show that motors and lamps may sometimes be used as ordinary conductors.

Turn on the slide switch (S1) and tap the whistle chip (WC), it makes a machine gun sound (with music in the background). Thoroughly cover the photoresistor (RP) with your hand and the sound becomes a siren. After a while the sound will stop, tap the whistle chip and it resumes.

Press the press switch (S2) and the LED (D1) lights, but the lamp (L1) does not light and the motor (M1) does not spin. Electricity is flowing through the lamp and motor, b ut not enough to turn them on. So in this circuit they are acting like 3-snap wires.

Using Parts as

Conductors

Project #57

OBJECTIVE: Build an electronic game for racing.

Modify Project #56 by adding the pointer as shown on the left. The paper should be cut from page 46 and taped high enough on the speaker (SP) so the pointer will stick over the fan (M1) with paper. Bend the pointer at a right angle as shown on the left. Setup: Cut out the grid with four (4) colors from page 46 and place it under the base as shown on the left. Each play er picks a color (or tw o colors if only 2 people are playing) and places a single snap on row G. The purple player in column 1, the blue player in column 2, the green player in column 3, and the yellow player in column 4. Spin the wheel by closing the press switch (S2). The first single color wedge that the pointer points to is the first player to start. In some models, you only have three 1-snaps, so use a 2-snap if you have four players. The Play: Each player gets a turn to press the press switch. They release the press switch and when the pointer points to a wedge the players that match the colors on the wedge get to move up one space. If a liner comes up like the one shown on the left then the players on each side of the line get to move up two (2) spaces. The first player to reach the top row (A) wins. If two players reach the top row at the same time they must both drop down to ro w “D” and play continues.

Race Game

WARNING: Moving parts.

Do not touch the fan or motor during operation. Do not lean over the motor.

-30-

Project #59

OBJECTIVE: To produce circular artistic drawings.

Rebuild the simple motor connection as shown on the left. This is the same setup as Project #57. Setup: Cut out a circular piece of thin cardboard from the back of an old spiral notebook or note pad.

Use the fan blade as a guide. Place the fan on the cardboard and trace around it with a pencil or pen. Cut the cardboard out with scissors and tape it to the fan blade. Do the same thing with a piece of white paper, but tape the paper on top of the cardboard so it can be removed easily later.

Drawing: To make a ring drawing obtain some thin and thick marking pens as drawing tools. Spin the paper by pressing and holding press switch (S2) down. Press the marker on the paper to form rings. To make spiral drawings, release press switch and as the motor (M1) approaches a slow speed move the marker from the inside outward quickly.

Change the colors often and avoid using too much black to get hypnotic effects. Another method is to make colorful shapes on the disc then spin the disc and watch them blend into each other. When certain speeds are reached under fluorescent lights without electronic ballasts, the strobe principle shown in another project will produce strange effects and backward movement. Make a wheel with different colored spokes to see this strange effect. Adding more spokes and removing spokes will give different effects at different motor speeds.

Spin Draw

Project #60

OBJECTIVE: To run the motor using the space war IC.

Space War Flicker Motor

Thin Cardboard White Paper

Turn on the slide switch (S1) and the motor (M1) spins (you may need to give it a push with your finger to get it started). The sounds from the space war IC (U3) are used to drive the motor. Because the motor uses magnets and a coil of wire similar to a speaker, you may even hear the space war sounds coming faintly from the motor.

To learn more about how circuits work, visit www.snapcircuits.net or page 45 to find out about our Student Guides.

-31-

Project #61

OBJECTIVE: To give a more dramatic demonstration of using the photosensitive resistance.

Build the circuit shown on the left. Turn on the slide switch (S1), a police siren is heard. The loudness of

the sound depends on how much light reaches the photoresistor (RP), try partially shielding it or placing near a very bright light, and compare the sound.

Light-Controlled Sounds

Project #62

Light-

Controlled

Sounds (II)

OBJECTIVE: To show a variation of the circuit in Project #61.

Project #63

Light-

Controlled

Sounds (III)

OBJECTIVE: To show a variation of the circuit in Project #61.

Project #64

Light-

Controlled

Sounds (IV)

Project #65

Light-

Controlled

Sounds (V)

Modify the last circuit by connecting points X & Y. The circuit works the same way but now it sounds like a machine gun.

Now remove the connection between X & Y and then make a connection between T & U. The circuit works the same way but now it sounds like a fire engine.

Now remove the connection between T & U and then make a connection between U & Z. The circuit works the same way but now it sounds like an ambulance.

Now remove the connection between U & Z, add a 1-snap at Z (on level 3), add a second 3-snap between V & W (on level 3), and finally place the music IC (U1) directly over the alarm IC (U2) on level 4. Listen to the sounds.

-32-

Project #66 Electronic Bombing Game

OBJECTIVE: To make an electronic bombing game.

Build the circuit at left. It uses both jumper wires as permanent connections. It also uses two 2-snap wires as “shorting bars”.

Setup: Player 1 sets the target by placing one shorting bar under the paper on row B, C, or D. Player 2 must NOT know where the shorting bar is located under the paper.

The object is for Player 2 to guess the location by placing his shorting bar at positions X, Y, or Z. In the drawing on the left Player 1 set up this hole at position “D”. If Player 2 places his shorting bar across “Z” on the first try then he gets a hit. He keeps guessing until he hits. After each hit, remove the shorting bars and slide the switch off and on to reset the sound. Player 2 then sets the B, C, D side and player 1 tries his luck.

Play multiple rounds and see who gets the best overall score. The winner will be the player who is best at reading his opponent’s mind.

Shorting Bar for B, C, or D.

Paper Sheet to hide position of shorting bar.

Shorting Bar for X, Y, or Z.

-33-

Project #67

OBJECTIVE: Make and play the electronic game of “Quiet Zone”.

Use the circuit from Project #66, but place two 2-snap wires (“shorting bars”) under the paper sheet as shown on left.

Setup: Player 1 sets the “Quiet Zone” by placing 2 shorting bars under the paper on row A, B, C, or D, leaving only one open. Player 2 must NOT know where the shorting bars are located under the paper.

Both Player 1 and Player 2 are given 10 points. The object is for Player 2 to guess the location of the “Quiet Zone” by placing his shorting bar at positions X, Y, or Z. In the drawing on the left Player 1 set up the “Quiet Zone” at position “C”. If Player 2 places his shorting bar across “Z” on the first try, the sounds played mean he has not found the “Quiet Zone” and he loses 1 point. He has three (3) tries to find the zone on each turn. Each time sounds are made he loses a point. Player 2 then sets the B, C, D side and player 1 starts searching. Play continues until one player is at zero points and makes sound during that players turn.

Quiet Zone Game

Project #68

OBJECTIVE: To combine the sounds from the space war and

music integrated circuits.

Space War Music Combo

Shorting Bar for B , C, o r D.

Paper Sheet to hide position of shorting bar.

Shorting Bar for X, Y, or Z.

Visit www.snapcircuits.net or page 45 to learn about more Snap Circuits®products to add to your collection.

-34-

Project #69

OBJECTIVE: To combine effects from the space war and alarm integrated circuits.

Build the circuit shown on the left and turn on the slide switch (S1). Press and hold the press switch (S2) to make the lamp (L1) brighter.

Space War Siren

Quiet Water Alarm

OBJECTIVE: To sound an alarm when water is detected.

Sometimes you want a water alarm that can be heard but is not loud enough to be annoying or distracting, so let's make one. We'll also put a light on it that could be seen in a noisy room, in a real application you could use a powerful light that would be easily seen.

Build the circuit shown but initially leave the jumper wires outside the cup. Tur n on the slide switch (S1); nothing happens. Place the jumper wires into a cup of water and an alarm sounds and the light comes on.

Project #70

-35-

Project #71

OBJECTIVE: To turn a lamp on and off using light.

Cover the unit, turn the slide switch (S1) on, and notice that the lamp (L1) is off after a few seconds. Place the unit near a light and the lamp turns on. Cover the photoresistor (RP) and place it in the light again. The lamp will not turn on. The resistance of the photoresistor decreases as the light increases. The low resistance acts like a wire connecting point C to the positive (+) side of the battery (B1).

Light-Controlled Lamp

OBJECTIVE: To turn a lamp on and off using the voltage generated from a photoresistor.

Project #73

Use the circuit from Project #71. Remove the photoresistor (RP) and connect the whistle chip (WC) across points A & B. Turn the slide switch (S1) on and clap your hands or talk loud near the whistle chip (WC), the lamp will light. The whistle chip has a piezocrystal between the two metal plates. The sound causes the plates to vibrate and produce a small voltage. The voltage then activates the music IC (U1) and turns the lamp on.

Project #72

Voice-Controlled Lamp

OBJECTIVE: To turn a lamp on and off using the voltage generated when a motor rotates.

Use the circuit from Project #72. Remove the whistle chip (WC) and connect the motor (M1) across points A & B. Turn the slide switch (S1) on and turn the shaft of the motor and the lamp (L1) will light. As the motor turns, it produces a voltage. This is because there is a magnet and a coil inside the motor. When the axis turns the magnetic field will change and generate a small current in the coil and a voltage across its terminals. The voltage then activates the music IC (U1).

Motor-Controlled Lamp

-36-

Project #74

OBJECTIVE: To control an LED using light.

Cover the unit, turn the slide switch (S1) on, and notice that the LED (D1) is on for a few seconds and then goes off. Place the unit near a light and the LED will light. Cover the photoresistor (RP) and place it near the light again. The LED will not turn on. The resistance of the photoresistor decreases as the light increases.

Light-Controlled LED

OBJECTIVE: To control an LED using sound.

Project #76

Use the circuit from Project #74. Connect the whistle chip (WC) to points A1 and C1 on the base grid, then remove the photoresistor (RP). Tur n the slide switch (S1) on and clap your hands or talk loud near the whistle chip, the LED (D1) will light. The whistle chip has a piezocrystal between the two metal plates. The sound causes the plates to vibrate and produce a small voltage. The voltage then activates the music IC (U1).

Project #75

Sound-Controlled Time

Delay LED

OBJECTIVE: To control an LED using a motor.

Use the circuit from Project #75. Remove the whistle chip (WC) and connect the motor (M1) across points A1 and C1 on the base grid. Turn the slide switch (S1) on and turn the shaft of the motor and the LED (D1) will light. As the motor turns, it produces a voltage. There is a magnet and a coil inside the motor. When the axis turns, the magnetic field will change and generate a small current across its terminals. The voltage then activates the music IC (U1).

Motor-Controlled Time

Delay LED

Visit www.snapcircuits.net or page 45 to learn about Snap Circuits®upgrade kits, which have more parts and circuits.

-37-

Project #79

OBJECTIVE: Build a circuit that flashes light and plays sounds.

Turn the slide switch (S1) on and the lamp (L1) and LED (D1) start flashing. You hear two different tones driving the LED and lamp. IC’s can be connected to control many different devices at the same time.

Flash and Tone

Project #77

Space War Flicker LED

OBJECTIVE: Flash an LED using the space war IC.

Project #78

Music AND Gate

Build the circuit shown on the left. The circuit uses the alarm (U2) and space war (U3) IC’s to flash the LED (D1). Turn the slide switch (S1) on and the LED starts flashing.

OBJECTIVE: To build an AND gate.

You will only hear music if you turn on the slide switch (S1) AND

press the press switch (S2). This is referred to as an AND gate in electronics. This concept is important in computer logic. Example: If condition X AND

condition Y are true,

then execute instruction Z.

-38-

Project #80

OBJECTIVE: To show the power drop of components connected in parallel.

Leave the fan off the motor (M1). Turn on the slide switch (S1), the motor spins and the lamp (L1) turns on. Place the fan on the motor and press the press switch. The lamp is not as bright now, because it takes more power from the batteries (B1) to spin the motor with the fan on it, which leaves less battery power av ailab le to light the lamp. If y ou have weak batteries, the difference in lamp brightness will be more obvious because weaker batteries don’t have as much power to supply.

The speaker (SP) is being used as a low-value resistance here to make the above effects more apparent.

Lamp, Speaker & Fan in Parallel

Project #81

OBJECTIVE: To draw an alarm activator.

Pencil Alarm

Pencil Alarm Variants

Project #82

Remove the jumper connected to point Y (as shown in the drawing) and connect it to point X instead. Touch the loose ends to the pencil drawing again, the sound is different now.

Next connect a 2-snap wire between points X & Y connect the jumper to either point. Touch the loose ends to the pencil drawing again, you hear a different sound.

Now remove the 2-snap wire between X & Y and connect it between X & Z, connect the jumpers to W & Y. Touch the loose ends to the pencil drawing again, you hear yet another sound.

Now you can draw your own shapes and see what kinds of sounds you can make.

OBJECTIVE: To draw an alarm activator.

Build the circuit shown and connect the two jumpers to it, leave the loose ends of the jumpers unconnected for now. There is one more part you need and you are going to draw it. Take a pencil (No. 2 lead is best but other types will also work). SHARPEN IT, and fill in the shape below. You will get better results if you place a hard, flat surface directly beneath this page while you are drawing. Press hard (but don’t rip the paper), and fill in the shape several times to be sure you have a thick, even layer of pencil lead.

Turn on the slide switch (S1) and take the loose ends of the jumpers, press them to the shape and move them around over the dra wing. If you don’t hear any sound then move the ends closer together and move over the drawing, add another layer of pencil lead, or put a drop of water on the jumper ends to get better contact.

WARNING:

Moving parts. Do not touch the fan or motor during operation. Do not lean over the motor.

-39-

Project #83

OBJECTIVE: To show some new ways of using the alarm IC.

Build the circuit shown and place the fan on the motor (M1), but leave the jumpers off for the time being. Turn on the slide switch (S1) and tap the whistle chip (WC), it makes a machine gun sound (with music in the background). Thoroughly cover the photoresistor (RP) with your hand and the sound becomes a siren. With the photoresistor covered, press the press switch (S2) and the sound becomes that of an ambulance. Uncover the photoresistor and the sound remains that of a machine gun whether the press switch is pressed or not. After a while the sound will stop, tap the whistle chip and it resumes.

Connect the two jumpers as shown and tap the whistle chip to resume the sound. The lamp (L1) and LED (D1) light and the motor spins. The sound continues, but it may become distor ted as the motor speeds up. The motor draws a lot of power from the batteries (B1), and this may reduce the voltage to the music (U1) and alarm (U2) ICs, distorting the sound. The sound may even stop if your batteries are weak.

Fun with the Alarm IC

Project #84

OBJECTIVE: To connect multiple devices

together.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean o ver the motor.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean over the motor.

Project #85

Motor

Sounds

Combo (II)

OBJECTIVE: To connect multiple devices

together.

In the circuit, the outputs from the alarm and music ICs are connected together. Build the circuit shown and then place the alarm IC (U2) directly over the music IC (U1), resting on three 1snaps. Turn on the slide switch (S1) and you will hear a siren and music together. Push the press switch (S2) and the fan spins, while the sound may not be as loud. The fan may rise into the air when you release the switch.

This circuit is similar to project #84, but the fan will fly a little higher since the sound circuit no longer drives the lamp (L1) and therefore uses less battery power.

WARNING: Moving parts. Do not touch the fan or

motor during operation. Do not lean over the motor.

To learn more about how circuits work, visit www.snapcircuits.net or page 45 to find out about our Student Guides.

Motor

Sounds

Combo

In the circuit, the outputs from the alarm and music ICs are connected together. Build the circuit shown and then place the alarm IC (U2) directly over the music IC (U1), resting on two 1-snaps and a 2-snap. Turn on the slide switch (S1) and you will hear a siren and music together while the lamp (L1) varies in brightness. Push the press switch (S2) and the fan spins, while the sound may not be as loud. The fan may rise into the air when you release the press switch.

-40-

Project #86

OBJECTIVE: To combine the sounds from the music and alarm integrated circuits.

Build the circuit shown and add the jumper to complete it. Tur n it on and you will hear a siren and music together. Press the press switch (S2) and the siren changes to a fire engine sound. After a f e w seconds, covering the photoresistor (RP) will stop the music (but the siren continues). The motor (M1) is used here as a 3-snap wire and will not spin.

Music Alarm Combo

Project #87 Bomb Sound

OBJECTIVE: Build a circuit that sounds like a bomb dropping.

OBJECTIVE: Build a circuit that sounds like bombs dropping.

Use the circuit from Project #87. Replace the slide switch (S1) with the motor (M1). Turn the shaft on the motor and now it sounds like a bunch of bombs dropping.

Turn the slide switch (S1) on and you hear the sound of a bomb dropping and then exploding. The LED (D1) lights and then flashes as the bomb explodes. This is one sound generated from the space war IC (U3).

Project #88

Bomb

Sound (II)

-41-

Project #89

OBJECTIVE: Build a circuit that turns an LED on and off if there is light present.

When there is light on the photoresistor (RP), the LED (D1) will flicker. Shield the photoresistor from the light, the LED should turn off.

Light-Controlled LED (II)

OBJECTIVE: Build a circuit that turns on and off an LED using the whistle chip.

Project #91

Use the circuit from Project 89. Replace the photoresistor (RP) with the whistle chip (WC). Tap on the whistle chip and the LED (D1) flickers. Tap again and the LED may flicker for a longer time. See how long the LED will stay on.

Project #90

Touch Light

OBJECTIVE: Build a circuit plays sound if you tap on the whistle chip.

Use the circuit from Project #90. Replace the LED (D1) with the speaker (SP). Now you can hear the different sound as you tap on the whistle chip (WC).

Touch Sound

-42-

In the circuit, the outputs from the alarm and music ICs are connected together. Build the circuit shown and then place the alarm IC (U2) directly over the music IC (U1), resting on two 1snaps and a 2-snap. There is also a 2-snap on top of the alarm IC. Turn on the switch (S1) and you will hear a siren and music together while the lamp (L1) varies in brightness.

OBJECTIVE: To combine different sounds.

Project #94

Wacky Sounds

OBJECTIVE: To combine different sounds.

Build the circuit shown. Turn it on, press the press switch (S2) several times, and wave your hand o ver the photoresistor to hear all the sound combinations. Y ou can mak e the sound from the m usic IC louder by replacing the 100Ω resistor (R1) with the 2.5V lamp (L1).

Really Wacky Sounds

Visit www.snapcircuits.net or page 45 to learn about more Snap Circuits®products to add to your collection.

OBJECTIVE: To combine different sounds.

Now remove the 2-snap connection between X & Y and then make a 2-snap connection between X & Z (on level 5). The circuit works the same way but has different sounds.

Wackier Sounds

Project #93

Project #92

-43-

Project #95

OBJECTIVE: To use water to control the space war integrated circuit.

Add the press switch (S2) to the preceding circuit to make it look lik e the one at left. There will be sound if the press switch is pressed or the jumper wires are in the water. Pressing the press switch or pulling the wires out of the water changes the sound played.

If you prefer you can just touch the jumper wire metal with your fingers instead of putting the jumpers in the water. Wet your fingers to get better electrical contact.

Noisier Water Space War

OBJECTIVE: To use water to control the space war integrated circuit.

Project #97

Use the circuit from Project #95. Replace the speak er (SP) with the LED (D1), positioning it as in Project #89. Putting the jumper wires in the water OR pressing the press switch (S2) will cause the LED to be bright.

Project #96

Light/Water Space War

OBJECTIVE: To control the space war integrated circuit.

Use the circuit from Project #96. Replace the LED (D1) with the 2.5V lamp (L1). Putting the jumper wires in the water OR pressing the press switch (S2) will cause the lamp to be dimly lit. Putting the jumper wires in the water AND pressing the press switch at the same time will cause the lamp to be much brighter.

OR/AND Space War Light

-44-

OBJECTIVE: To sound an alarm when water is detected.

Build the circuit shown but initially leav e the jumper wires outside the cup. Turn on the slide switch (S1); nothing happens. Place the jumper wires into a cup of water and an alarm sounds!

You could use longer wires and lay them on your basement floor, if your basement floods during a storm, then this circuit will sound an alarm.

Project #99

Simple Salt

Water Alarm

OBJECTIVE: To detect salt water.

Add salt to the water and the tone of the alarm is louder and faster, telling you that salt is in the water you detected. Also, try holding the jumper wires with your fingers to see if your body can set off the alarm.

Project #100

Ambulance

ter Alarm

OBJECTIVE: To show a variation of the circuit in Project #98.

Modify the circuit in Project 98 by making a connection between A & B. The water alarm works the same way but no w it sounds lik e an ambulance.

Project #101

Ambulance

Contact Alarm

OBJECTIVE: To show a variation of the circuit in Project #98.

The same circuit also detects if the jumper wires get touched together, so connect them to each other. The tone of the sound is now much different. Therefore, this circuit will tell you if there is water between the jumper wires or if the wires are touching each other.

Project #98 Simple Water Alarm

-45-

OTHER SNAP CIRCUITS®PROJECTS!

For a listing of local toy retailers who carry Snap Circuits visit www.elenco.com or call us toll-free at 800-533-2441. For Snap Circuits upgrade kits, accessories, additional parts, and more information about your parts visit www.snapcircuits.net.

Build 200 Additional Projects

Including:

• AM Radio

• Water Detector

• Motion Detector

• Electronic Kazoo

• Burglar Alarm

• Tone Generator

• Make Y our Own Battery

• Music Radio

• Lie Detector

Contains 29 New Parts

Including:

• Antenna Coil

• Microphone

• Power Amplifier IC

• Variable Capacitor

• Five Fixed-value Capacitors

• High Frequency IC

• Tw o Transistors

• Adjustable Resistor

• Four Fixed-value Resistors

Build 400 Additional Projects

Including:

• Electronic Cat

• Music Meter

• Adjustable Light Control

• Digitally Tuned FM Radio

• Digital Voice Recorder

• Light Controlled Music

• AC Generator

• Flashing Numbers

Contains 41 New Parts

Including:

• FM Radio Module

• Analog Meter

• Recording IC Module

• Diode

• 7-Segment LED Display

• Relay

•SCR

• Transformer

Upgrade Kit

Model UC-30

Upgrade Kit

Model UC-40

Build Over 650 Additional Projects

Including:

• Strobe Light

• Electromagnetism

• Electronic Kazoo

• Transistor AM Radio

• Rechargeable Battery

• Solar Batteries

• Mega Pulser and Flasher

• Paperclip Compass

Contains 52 New Parts

Including:

• Solar Cell

• Electromagnet

• Vibration Switch

• Two-spring Socket

• Bag of Paperclips

• Includes the CI-73

Computer Interface

Upgrade Kit

Model UC-60

Deluxe Snap Rover

Model SCROV-50

Introducing the next generation of the RC Snap Rover

! This version includes a disc launcher, digital voice recorder, and music sounds. Over 50 parts allow you to complete over 40 additional projects.

• Includes 30 parts

• Build over 20 projects

• Full-color assembly manual

• Sound effects

Snap Circuits

Green

Alternative Energy Kit

Model SCG-125

If you want to enhance your Snap Cir cuits

experience and get even smarter, then try

Part # 753294

For use with SC-100

Educational Series - teaches Basic Electricity & Electronics in the everyday world using our Learn By Doing

concept! 48 full-color pages, and written with the help of educators.

Snap Circuits

Student Guide Jr.

Put your circuits in motion!

Learn about energy sources and how to “think green”. Build over 125 projects and have loads of fun learning about environmentally-friendly energy and how the electricity in your home works. Includes fullcolor manual with over 100 pages and separate educational manual. This educational manual will explain all the forms of environmentally-friendly energy including: geothermal, hydrogen fuel cells, wind, solar, tidal, hydro, and others. Contains over 40 parts.

Snap Circuits®LIGHT

Model SCL-175

Features:

• Infrared detector

• Strobe light

• Color changing LED

• Glow-in-the-dark fan

• Strobe integrated circuit (IC)

• Fiber optic communication

• Color organ controlled by iPod

or other MP3 player,

voice, and fingers.

iPod®shown not included.

Build over 175

projects!

Contains over

60 parts

-46-

Page 28 for Project #55

Page 29 for Project #57

ELENCO

150 Carpenter Avenue

Wheeling, IL 60090

(847) 541-3800

Website: www.elenco.com

e-mail: elenco@elenco.com

Elenco Projects 1-101 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
