Electrolux EOB 51001 User Manual
electrolux 1
user information
IE
GB
Built-in oven
EOB 51001
electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that make
your life more comfortable.
You find some examples on the cover in this manual.
Please take a few minutes to study this manual so that you can take advantage
of the benefits of your new machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind.
Good luck!
4 electrolux
Contents
Warnings and Important Safety Information ........................................................ 5
Description of the appliance............................................................................... 7
Controls............................................................................................................. 8
Before using the oven for the first time ............................................................... 9
Using the Oven ............................................................................................... 10
Baking and Roasting Tables ............................................................................ 14
Cleaning and Maintenance .............................................................................. 16
If something is wrong ....................................................................................... 21
Technical Data ................................................................................................ 22
Electrical Connection ...................................................................................... 23
Instructions fo Building In ................................................................................. 24
Guarantee/Customer Service ........................................................................... 25
European Guarantee ....................................................................................... 26
Guide to using the user instructions
Safety instructions
Step by step instructions
)
Hints and Tips
This appliance conforms with the following ECC Directives:
- 2006/95 (Low Voltage Directive);
- 89/336 (EMC Directive);
- 93/68 (General Directive);
and subsequent modifications.
electrolux 5
Warnings and Important Safety Information
These warnings are provided for the safety of the users and those living
with them. So read them carefully before installing and using the appliance.
This will allow you to obtain best performance, avoid improper actions,
use the appliance in complete safety and also respect the environment.
If you need assistance, contact our Customer Care Department on 08705
950 950.
Installation
• The installation must be performed
by a qualified person in accordance
with the rules and regulations in
force. The individual operations for
installing the appliance are
described under the instructions for
the installer.
• Have the appliance installed and
connected by a qualified person
with specialist knowledge, who will
carry it out in accordance with the
directives.
• If any modifications to the power
supply are required because of the
installation, these should also be
carried out by a qualified electrician.
Operation
• This oven is designed for cooking
foodstuffs; never use it for other
purposes.
• When opening the oven door during
or at the end of cooking be careful
of the stream of hot air, which
comes out of the oven.
Be very careful when using the
•
cooker. The extreme heat of the
heating elements makes the
shelves and other parts very hot.
• If you should for whatever reason use
aluminium foil to cook food in the
oven, never allow it to come into
direct contact with the floor of the
oven.
• When cleaning the oven, proceed
with care: never spray anything onto
the grease filter (if fitted), the heating
elements and the thermostat sensor.
• If is dangerous to make
modifications of any kind to this
appliance or to its specifications.
• During the baking, roasting and
grilling process, the oven window
and the other parts of the appliance
get hot, so children should be kept
away from the appliance. Take care,
if connecting electrical appliances
to sockets near the oven, that
cables do not come into contact with
hot rings or get caught in the oven
door.
• Always use oven gloves to take hot
ovenproof dishes or pots out of the
oven.
• Regular cleaning prevents the
surface material from deteriorating.
• Before cleaning the oven, either turn
the power off or pull the mains plug
out.
6 electrolux
• Make sure that the oven is in the
“OFF” position, when the oven is no
longer being used.
• This oven was made as a single ap-
pliance or as a combination
appliance with electrical hotplate,
depending on the model, for singlephase connection to 230 V.
• The appliance must not be cleaned
with a superheated steam cleaner
or a steam jet cleaner.
• Do not use abrasive cleaners or sharp
metal scrapers. These can scratch the
glass in the oven door, which may
result in the shattering of the glass.
People Safety
• This appliance is intended for use by
adults. It is dangerous to allow children
to use it or play with it.
• Children should be kept away while
the oven is working. Also, after you
have switched the oven off, it remains
hot for a long time.
• This appliance is not intended for use
by children or other persons whose
physical, sensory or mental capabilities or lack of experience and knowledge prevents them from using the
appliance safely without supervision
or instruction by a responsible person to ensure that they can use the
appliance safely.
Customer Service
• Have checks and/or repairs carried
out by the manufacturer’s service
department or by a service
department authorised by the manufacturer and use only original spare
parts.
• Do not attempt to repair the
appliance yourself in the event of
malfunctions or damage. Repairs
carried out by untrained persons may
cause damage or injury.
The symbol on the product or its
packaging indicates that this product is
not to be treated as normal household
waste. Instead it must be handed over to
a collection point for the recycling of
electrical and electronic equipment. The
correct disposal of this product will help
to protect the environment and human
health. Environment and health are
endangered by incorrect disposal. For
more detailed information about recycling
of this product, please contact your local
town hall, your household waste disposal
service or the shop where you purchased
the product.
Description of the appliance
electrolux 7
1
10
11
1. Control Panel
2. Oven Function Control Knob
3. Minute minder
4. Thermostat Control Knob
5. Mains On Indicator
6. Thermostat Control Indicator
6
524
3
7
8
9
7. Air Vents for Cooling Fan
8. Grill
9. Oven light
10.Oven Fan
11. Rating plate
Oven accessories
Removable
handle
Grill / Roasting pan
Grill Pan Grid
Anti-tip shelf
8 electrolux
Controls
Oven Function Control Knob
The oven is off
0
Oven light - The oven light will be
on without any cooking function.
Defrost Setting - This setting is
intended to assist in thawing of
frozen food.
Fan cooking - This allows you to
roast or roast and bake
simoultaneously using any shelf,
without flavour transference.
Grill - The heat comes from the
top element only.
Mains on Indicator
The mains on light will come on when the
oven function control knob is set.
Thermostat Control Knob
Turn the thermostat control knob anticlockwise to select temperatures
between 50°C and 250°.
Minute minder
The minute minder will mark the end of
a timed period with an acoustic alarm.
The maximum timing is 60 minutes.
Turn the minute minder knob to the
maximum time position, then turn it
back to the required time.
The minute minder will not affect in any
way the oven operation, if it is in use.
electrolux 9
Thermostat Control Indicator
The thermostat control indicator will come
on when the thermostat control knob is
turned. The indicator will remain on until
the correct temperature is reached. It will
then cycle on and off to show the temperature is being maintained.
Safety Thermostat
To prevent dangerous overheating
(through incorrect use of the appliance or
defective components), the oven is fitted
with a safety thermostat, which interrupts
the power supply. The oven switches
back on again automatically, when the
temperature drops.
Should the safety thermostat trigger due
to incorrect use of the appliance, it is
enough to remedy the error after the oven
has cooled down; if on the other hand, the
thermostat triggers because of a defective
component, please contact Customer
Service.
The cooling fan
The oven is provided with a cooling fan,
meant to keep the front panel, the knobs
and the oven door handle cool.The fan
switches on automatically when the oven
is activated. Warm air is blown out
through the aperture near the oven door
handle. The fan switches off when, after
cooking, the oven function control knob
is set to OFF position 0.
Before using the oven for the first time
Remove all packaging, both
inside and outside the oven, before
using the oven.
Before using for the first time, the oven
should be heated up without food.
During this time, an unpleasant odour
may be emitted. This is absolutely
normal. It is caused by manufacturing
residues.
Ensure the room is well ventilated.
1. Switch the oven function
)
control knob to fan cooking
.
Then let the oven cool down. Then
dampen a soft cloth with warm
water and a little mild washingup liquid and use this to clean the
oven cavity.
Before using for the first time,
carefully wash the oven
accessories as well.
2. Set the thermostat control
knob to 250°.
3. Open a window for ventilation.
4. Allow the oven to run empty
for approximately 45 minutes.
This procedure should be repeated with
the full grill function for approximately
5-10 minutes.
To open the oven door, always
hold the handle in the centre.
10 electrolux
Using the oven
The oven is supplied with an exclusive
system which produces a natural
circulation of air and the constant
recycling of steam.
This system makes it possible to cook in
a steamy environment and keep the
dishes soft inside and crusty outside.
Moreover, the cooking time and energy
consumption are reduced to a minimum.
During cooking steam may be produced
which can be released when opening the
oven door. This is absolutely normal.
However, always stand back from
the oven when opening the oven
door during cooking or at the end
of it to allow any build up of steam
or heat to release.
Attention! - Do not place objects
on the oven base and do not cover
any part of the oven with aluminium
foil while cooking, as this could
cause a heat build-up which
would affect the baking results and
damage the oven enamel. Always
place pans, heat-resisting pans
and aluminium trays on the shelf
which has been inserted in the
shelf runners.When food is heated,
steam is created, like in a kettle.
When the steam comes into
contact with the glass in the oven
door, it condenses and creates
water droplets.
To reduce condensation, always
preheat the empty oven for 10
minutes.
We recommend you wipe the water
droplets away after every cooking
process.
4
3
2
1
Always cook with the oven
door closed. Stand clear when
opening the drop down oven door.
Do not allow it to fall open support the door using the door
handle, until it is fully open.
The oven has four shelf levels. The
shelf positions are counted from
the bottom of the oven as shown
in the diagram.
It is important that these shelves
are correctly positioned as shown
in the diagram.
Do not place cookware directly on
the oven base.
Fan Cooking
The air inside the oven is heated by the
element around the fan situated behind
the back panel. The fan circulates hot
air to maintain an even temperature inside
the oven.
The advantage of cooking with this
function is energy saving through:
z Faster Preheating
As the fan oven quickly reaches
temperature, it is not usually
necessary to preheat the oven
Loading...
