Electrolux ENB 3440 User Manual

A/E/28. (05.)200370388
FRIDGE - FREEZER
INSTRUCTION BOOK
ENB 3440
2
This instruction book contains safety precautions, information on use and helpful hints and tips.
To ensure you use this appliance effectively and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference.
The symbols below help you to find things more easily:
Safety precautions
Warnings and Safety information
Hints, useful information
Environmental information
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
3
Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance.
During Use
This appliance is designed for domestic use only, specifically for the storage of edible foodstuffs. It is not intended for commercial or industrial use. Containers with flammable gases or liquids can leak at low temperatures. Do not store any containers with flammable materials, such as spray cans, fire extinguisher refill cartridges etc. in the appliance. Frozen food should not be refrozen once it has thawed out. Do not place carbonated or fizzy drinks in the freezer compartment. Ice lollies can cause 'frost/freezer burns' if consumed straight from the freezer. Do not remove items from the freezer compartment if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns. Bottles and cans must not be placed in the freezer compartment they can burst when the contents freeze. Manufacturers' recommended storage times should be adhered to. Refer to relevant instructions.
Maintenance and Cleaning
Before cleaning, always switch off the appliance and disconnect from the electrical supply. When unplugging always pull the plug from the mains socket, do not pull on the cable.
Servicing
This product should be serviced by an authorised engineer and only genuine spare parts should be used. Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre.
At the end of the Appliance Life
When disposing of your appliance use an authorised disposal site. Remove the plug and ensure that any locks or catches are removed, to prevent young children being trapped inside.
The Appliance and the Environment
This appliance does not contain gases which could damage the ozone layer. Avoid damaging the cooling unit. The packaging used on this appliance marked with the symbol is recyclable.
Keep this instruction book for future reference and ensure it is passed on to any new owner.
IMPOR
IMPORTT
ANT S
ANT S
AFET
AFET
Y INS
Y INS
TR
TR
UCTIONS
UCTIONS
These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department.
Prior to installation
Check the appliance for transport damage. Under no circumstances should a damaged appliance be installed. In the event of damage please contact your retailer.
Installation
This appliance is heavy. Care should be taken when moving it. It is dangerous to alter the specifications or attempt to modify this product in any way. Ensure that the appliance does not stand on the electrical supply cable. If the supply cable is damaged, it must be replaced by a cable available from your local Service Force Centre.
Make sure that the power plug has not been squashed or damaged during transit.
- A damaged power plug may overheat and cause a fire.
As you unpack the appliance, check carefully for any signs of transit damage. Do not place heavy articles or the fridge/freezer itself on the power cord.
- There is a risk of a short circuit and fire.
Do not remove the power cord by pulling on its lead, particularly when the fridge/freezer is being pulled out of its niche.
- Damage to the cord may cause a short-circuit, fire and/or electric shock.
- If the power cord is damaged, it must be replaced by a certified service agent or qualified service personnel.
If the power plug socket is loose, do not insert the power plug.
- There is a risk of electric shock or fire.
Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Parts which heat up should not be exposed. Whenever possible, the back of the appliance should be close to a wall, but leaving the required distance for ventilation, as stated in the installation instructions. The appliance should be left for 2 hours after installation before it is turned on, in order to allow the refrigerant to settle.
Child Safety
Do not allow children to tamper with the controls or play with the product. Keep packaging materials away from children, to prevent the risk of suffocation!
Safety precautions for isobutane Warning
The refrigerant isobutane (R 600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
4
CCONTENT
ONTENTSS
Instructions for the User
Important Safety Instructions 3
General Information 5 Description of the Appliance 5
Using the Appliance 6
Before Use 6 Putting it into use 6 To Start the Appliance 6 The Refrigerator 7 Storage Shelves 7 Storage Times 7 The Freezer 8 Freezing Fresh Food 8 Frozen Food Storage 8 Thawing 8 To Make Ice Cubes 8
Hints and Tips 9
Normal Operating Sounds 9 Food Storage 9 Energy Saving Advice 9 In the Event of a Power Failure 9
Maintenance and Cleaning 10
Internal Cleaning 10 External Cleaning 10 When the Appliance is Not in Use 10
Defrosting 10
To Change the Light Bulb 11
Something Not Working 12
Service and Spare Parts 13
Customer Care Department 13
Guarantee Conditions 14
Instructions for the Installer
Technical Data 15
Installing the Appliance 15
Transportation, Unpacking 15 Cleaning 15 Location 15 Levelling the Appliance 16 Ventilation Requirements 16 Door Reversal 16
Electrical Connections 18
Storage Chart 19
5
INS
INS
TR
TR
UCTIONS F
UCTIONS F
OR THE USER
OR THE USER
General information
This appliance is designed for the storage of refrigerated and frozen food in a domestic environment.
To ensure correct operation, the appliance should be located where the ambient temperature is between 10-32 °C.
A - Refrigerator B - Freezer
1. Top
2. Lighting box
3. Glass shelves
4. Bottle rack
5. Cooling surface
6. Defrost water drain
7. Glass shelf
8. Salad drawers
9. Rating plate
10. Air grid
11. Freezing compartment
12. Storage compartment(s)
13. Adjustable feet
14. Dairy compartement
15. Egg tray
16. Door shelf
17. Door gasket
18. Bottle shelf
19. Handles
20. Ice tray
21. Condenser
22. Defrost water outlet tube
23. Spacer
24. Evaporator tray
25. Compressor
26. Rollers
Description of the appliance
6
Using the Appliance
This appliance is designed for domestic use only, specifically for the storage of edible foodstuffs.
The appliance is designed to operate in ambient temperatures (surrounding air temperature) between 10 °C and 32 °C.
If these temperatures are exceeded i.e. colder or warmer, the appliance will not operate correctly. Should the ambient temperatures be exceeded for long periods, the temperature in the freezer section will rise above -18 °C and food spoilage may occur.
Before Use
Remove all packaging and securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0,5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly.
Do not use detergents, abrasive powders, highly perfumed cleaning products, wax polishes or products containing alcohol.
Putting it into use
Place the accessories into the appliance then plug to the mains socket.
The thermostat knob is on the light box in the refrigerator. You can switch the appliance on and set the temperature with it by turning the knob clockwise.
The next paragraph will give instructions for setting.
))
To Start the Appliance
1. Allow the appliance to stand for 2 hrs after installation.
2. Plug in the appliance and switch on at the mains supply.
3. The thermostat interrupts the cooling automatically for more or less time depending on the setting then restarts it assuring the required temperature.
The closer it is set to maximum position the more intensive the refrigerating will be. When the thermostat knob is set to a medium position (between minimum and maximum), in the freezer a temperature colder than -18°C, in the refrigerator around +5°C can be reached. Setting it to a medium position is adequate for everyday use.
The temperature coming about in the refrigerator is effected by not only the position of the thermostat but the ambient temperature, frequency of door openings and the quantity of food put into it newly, etc.
In the maximum position - in case of
increased demand e.g. during heatwaves ­the compressor may operate continually. This does not cause damages to the appliance.
