Electrolux EHT8IROW6 User Manual

Warewashing

Green&Clean Hood Type

Dishwasher, Manual with Filtering

System

Warewashing
Green&Clean Hood Type Dishwasher,

Manual with Filtering System

504261 (EHT8IROW6)Hood type dishwasher, with

double skin insulated manual
hood, Wash Safe Control,
CLEAR BLUE Filtering
System and drain pump, 80r/h

- S.E. Asia, China, India, Latin
America

Short Form Specification

Item No.

Unit to be Electrolux Green & Clean upright hood type hot water rinsing dishwasher
with WASH SAFE CONTROL. Electrical characteristics to be ___230 volts, three
phase 60Hz operation, convertible to single phase on-site. Uses 2 liters of clean
water per final rinse cycle. 84°C rinse temperature and pressure guaranteed by
built in atmospheric boiler and built in rinse booster pump. Washing performance
is guaranteed by a powerful 0.8 kW wash pump and upper and lower stainless
steel revolving washing spray arms. Unit to feature "WASH SAFE CONTROL" led
light. Green light will indicate that all items washed have been properly rinsed.
CLEAR BLUE filtering system removes majority of soil from the wash water. 304
Stainless steel construction to include double skin insulated hood, external, front
and side panels, wash tank, tank filter plus wash and rinse arms. Unit shall be field
convertible from straight to corner operation. The unit shall include drain pump
and is equipped with flexible fill hoses. Delivered on height-adjustable feet.

ITEM #
MODEL #
NAME #
SIS #
AIA #

Main Features

•CLEAR BLUE advanced filtering system provides cleaner
wash water and higher active detergent thus ensuring better
washing performances and lower running costs.

•ETL-Sanitation approved (ANSI/NSF 3 sanitation standard)
and DIN 10512 compliant.

•Requires only 2 liters of water per washing cycle thus
ensuring low energy, water, detergent and rinse aid
consumption.

•Built-in atmospheric boiler sized to raise incoming cold
water to a minimum of 84 °C for sanitizing rinse. No external
boiler is required. Constant temperature of 84 °C throughout
the rinsing cycle regardless of the network's water pressure.

•Green light of "WASH SAFE CONTROL" confirms that items
have been rinsed properly.

•Unique temperature interlock guarantees required
temperatures in both the wash and final rinse.

•Maximum capacity per hour of 80 racks or 1.440 dishes
(High productivity mode) easy to switch to 63 racks or 1.134
dishes (ETL-Sanitation mode) by pressing a button.

•45/84/150 seconds cycles (High productivity mode);
57/84/150 seconds cycles (ETL-Sanitation mode).

•Incorporated Soft Start feature to offer additional protection
to more delicate items.

•Slanted wash arms and sloped ceiling to avoid detergent­filled wash water dropping on clean dishes after the rinsing
phase, thus guaranteeing ideal washing results.

•Cycle may be interrupted at any time by lifting the hood.

•Automatic self-cleaning cycle and self-draining vertical wash

pump and boiler to avoid bacteria proliferation.

•

State-of-the-art electronic controls with built-in programming,
self-diagnostics for serviceability and automatic interior
self-cleaning cycle.

•Three phase electrical connection, convertible to single
phase on-site.

•IP25 protection against water jet, solid objects and small
animals (larger than 6 mm).

Construction

•Heavy duty Stainless steel construction. Internal cavity as
well as exterior panels are in 304 series Stainless steel.

•Pressed tank in front position to facilitate cleaning.

•Double skin insulated hood.

•Specially designed Stainless steel wash/rinse arms and

nozzles provide superior cleaning action.

•Revolving interchangeable Stainless steel wash/rinse arms
above and below the rack, screw out for simple clean up.

•Pre-arranged for on-site HACCP implementation and Energy
Management device.

•Element protection from dry fire and low water.

•Incorporated drain pump to control water level in wash tank

draining.

Green&Clean Hood Type Dishwasher, Manual with Filtering

Warewashing

APPROVAL:

System

Electrolux Professional

www.electrolux.com/foodservice

[e-mail]

Included Accessories

•2 of Yellow cutlery containerPNC 864242

•1 of Basket for 18 dinner plates - yellowPNC 867002

•1 of Basket for 48 small cups or 24 cups - bluePNC 867007

Optional Accessories

•Kit 8 plastic boxes for cutlery - yellowPNC 780068 ❑

•12lt external manual water softenerPNC 860412 ❑

•8lt external automatic water softenerPNC 860413 ❑

•20lt external manual water softenerPNC 860430 ❑

•HACCP connection cable for double skin hood

type

•Stainless steel inlet hose kitPNC 864016 ❑

•Filter for partial demineralizationPNC 864017 ❑

•External reverse osmosis filter for undercounter

and hood type dishwashers with atmosphere
boiler

•Kit to measure total and partial water hardnessPNC 864050 ❑

•Yellow cutlery containerPNC 864242 ❑

•Back panel for double skin manual hood type -

AISI 304

•Filter for total demineralizationPNC 864367 ❑

•ZERO LIME device kit with pump and air gap for

hood type

•Kit 4 plastic boxes for cutlery - yellowPNC 865574 ❑

•Basket for 6 trays 530x370 mm - redPNC 866743 ❑

•Basket for 12 soup bowls - greenPNC 867000 ❑

•Basket for 18 dinner plates - yellowPNC 867002 ❑

•Basket for 48 small cups or 24 cups - bluePNC 867007 ❑

•Basket for bulk cutlery-capacity: 100 pieces -

brown

•Cover rack for small and light items (500x500
baskets)

•Baskets for 25 tilted glasses (h 120 mm - diam 80
mm) - blue

•Basket for 16 vertical glasses (h 70 mm - diam
100 mm) - blue

•Basket semi-professional 500x500x190mmPNC 867024 ❑

•Baskets for 16 tilted glasses (h 220 mm - diam

100 mm) - blue

PNC 864007 ❑

PNC 864026 ❑

PNC 864342 ❑

PNC 864526 ❑

PNC 867009 ❑
PNC 867016 ❑
PNC 867021 ❑
PNC 867023 ❑

PNC 867040 ❑

Warewashing

Green&Clean Hood Type Dishwasher,

Manual with Filtering System
