Electrolux EFI 60011, EFI 60012, EFI 60013 User Manual

EFI 60011-60012-60013

User manual

electrolux 3electrolux 3

electrolux 3

GB

WW

W

elcome to the world of Electrelcome to the world of Electr

elcome to the world of Electr

oluxolux

olux

Thank you for choosing a first class product from Electr olux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual. Please take a few minutes to study this manual so that you can take advantage of the benefits of your new machine. We promise that it will provide a superior User Experience delivering Ease-of-Mind. Good luck!

44

4

electr electr

electr

oluxolux

olux contents

GB

Contents

Safety warnings ................................ 5

Description of the Appliance ............. 7

Control Panel.................................... 8

Maintenance and Care ..................... 9

Special accessories ........................ 14

Something Not Working.................. 14

Installation ...................................... 15

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how to avoid damaging the appliance.

General information and tips. Environmental information.

electroluxelectrolux

electrolux

safety warnings

55

5

GB

Safety warnings

• When used as an extractor unit, the hood must be fitted with a hose having preferably the same diameter as the outlet hole. Attention: Attention:

Attention: Attention:

Attention: The hose is not supplied and must be purchased separately.

• The minimum distance between the supporting surface for the cooking vessels on the hob and the lowest part of the range hood must be not less than

60cm60cm

60cm from electric cookers

and

70cm70cm

70cm from gas or mixed cookers. If the instructions for installation for the gas hob specify a greater distance, this must be adhered to.

• Before any cleaning or maintenance operation, disconnect the hood from the mains by removing the plug or disconnecting the home mains switch.

• The appliance is not intended for use by children or persons with impaired physical, sensorial or mental faculties, or if lacking in experience or knowhow, unless they are under supervision or have been trained in the use of the appliance by a person responsible for their safety.

• Children should be monitor ed to ensure that they do not play with the appliance.

• Never use the hood without effectively mounted grating.!

• The hood must NEVER be used as a support surface unless specifically indicated.

• The premises must be sufficiently ventilated, when the kitchen hood is used together with other gas combustion devices or other fuels.

• The suctioned air must not be conveyed into a conduit used for the disposal of the fumes generated by appliances that combust gases or other fuels.

• The flaming of foods beneath the hood itself is severely prohibited.

• The use of exposed flames is detrimental to the filters and may cause a fire risk, and must therefor e be avoided in all circumstances.

• Any frying must be done with care in order to make sure that the oil does not overheat and burst into flames.

• As regards the technical and safety measures to be adopted for fume discharging it is important to closely follow the relations provided by the competent authorities.

• The hood must be regularly cleaned on both the inside and outside (AT LEAST ONCE A MONTH, it is in any event necessary to proceed in accordance with the maintenance instructions provided in this manual)..

• Failure to follow the instructions as concerns hood and filter cleaning will lead to the risk of fires.

• Do not use or leave the hood without the lamp correctly mounted because of the possible risk of electric shocks.

66

6

electr electr

electr

oluxolux

olux safety warnings

GB

• We decline any responsibility for any problems, damage or fires caused to the appliance as the result of the non-observance of the instructions included in this manual.

This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electr onic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

electrolux electrolux

electrolux description of the appliance

77

7

GB

Description of the Appliance

••

•

The cooker hood is designed toThe cooker hood is designed to

The cooker hood is designed to extract unpleasant odours frextract unpleasant odours fr

extract unpleasant odours frextract unpleasant odours fr

extract unpleasant odours fr

om theom the

om the

kitchen, it will not extract steam.kitchen, it will not extract steam.

kitchen, it will not extract steam.

• The hood is supplied as an extractor unit and can also be used with a recirculation mode by fitting a charcoal filter .

Attention!Attention!

Attention!

EFI 60011 - EFI 60012: one charcoal filter EFI 60013: two charcoal filters

Extraction modeExtraction mode

Extraction mode

• In this mode fumes are extracted to the outside via a

hosehose

hose connected to

the

coupling ringcoupling ring

coupling ring.

Note:Note:

Note: The coupling ring may be placed on the top or on the rear exhaust according to the needs.

• In order to obtain the best performance the hose should have a diameter equal to the outlet hole.

Rear

Top

TT

T

opop

op

RearRear

Rear

HoseHose

Hose

Coupling ring

Rear view

To the outside

88

8

electr electr

electr

oluxolux

olux description of the appliance

GB

RecirRecir

Recir

culation modeculation mode

culation mode

• The air is filtered thr ough a

charchar

char

coalcoal

coal

filterfilter

filter and returned to the kitchen.

Attention!Attention!

Attention!

EFI 60011 - EFI 60012: one charcoal filter EFI 60013: two charcoal filters

ContrContr

Contr

ol Panelol Panel

ol Panel

• Best results ar e obtained by using a low speed for normal conditions and a high speed when odours are more concentrated. Turn the hood on a few minutes before you start cooking. The hood should be left on after cooking for about 15 minutes or until all the odours have disappeared. The control switches are located on the unit’s front panel:

• the

light switchlight switch

light switch switches the hood

lamp on and off

• the

motor switchmotor switch

motor switch switches the motor on and off, enabling you to select one of the three different speeds.

The EFI 60012 and EFI 60013 hoods are also equipped with a micro-switch which can be found under the lower runner of the visor on the right hand side. With this micro-switch, the appliance may be automatically switched on and off by opening and closing the pull-out panel, but only if the fan speed has already been set and the light switch is turned to “

II

I”.

Light switch

Motor switch

- control panel

electrolux electrolux

electrolux maintenance and care

99

9

GB

Maintenance and Care

Attention! Attention!

Attention! Before performing any maintenance operation, isolate the hood fr om the electrical supply by switching off at the connector and removing the connector fuse. Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket.

Metal grMetal gr

Metal gr

ease filterease filter

ease filter

• The purpose of the grease filters is to absorb grease particles which form during cooking and it

mustmust

must always be used, either in the external extraction or internal re-circulation function.

•

EFI 60011 only:EFI 60011 only:

EFI 60011 only: The synthetic filter is very thin (approx. 1 mm) and positioned on the inside of its related support grill. The filter should be changed once a month. The grill should be cleaned with luke warm water and non-abrasive detergent when you change the filter. The grease filter can be order ed from your local Service Force Centre.

•

EFI 60012 - EFI 60013 only:EFI 60012 - EFI 60013 only:

EFI 60012 - EFI 60013 only: The metal grease filters must be removed and washed, either by hand or in the dishwasher, every four weeks. Hand washingHand washing

Hand washingHand washing

Hand washing Soak grease filters for about one hour in hot water with a grease-loosening cleaner, then rinse off thoroughly with hot water. Repeat the process if necessary. Refit the grease filters when they are dry.

EFI 60011EFI 60011

EFI 60011

EFI 60012EFI 60012

EFI 60012

EFI 60013EFI 60013

EFI 60013

EFI 60011 onlyEFI 60011 only

EFI 60011 only
