Electrolux COMP48 User Manual

ITEM #

MODEL #

EMPower

Two (2) Drawer Refrigerated-

Freezer Base - 48"

EMPower

Two (2) Drawer Refrigerated-Freezer Base ­48"

727093 (COMP48)EMPower Restaurant Range

Short Form Specification

Item No.

EMPower unit to be Electrolux Dual Temp Two (2) Drawer Refrigerated/
Freezer Base with built-in compressor EMPower unit. EMPower unit able
to oprate both as refrigerator or as freezer, with tEMPowerper ature range
from -7.6°F to +46.4 °F (-22°C to +8°C). Digital thermostat and display are
protected by the Stainless Steel front panel. Stainless Steel front panel with
incorporated Stainless Steel wire netting is easy to rEMP owerove for access
to the thermostat and to allow for easy cleaning. May be installed below
any top EMPower unit. Perforated top surface provides the necessary
ventilation to allow f or a flush connection between base and Electrolux
top EMPower units, eliminating the need for the top EMPo wer unit legs.
Each drawer to accommodate two (2) 12” x 20” x 6” deep pans with use
of included, removable division bar or two (2) 325 mm x 530 mm (1/1 GN)
pans. Drawer guides with safety stop can support up to 264 lbs. (120 kg)
and are removable for cleaning. Magnetic snap-in drawer gaskets are
removable for cleaning. Perforated bottom plate in each drawer
guarantees correct air-flow , allows for small pans to stand upright and is
removable for cleaning. Perforated bottom plate can support up to 88 lbs.

APPROV AL:

Dual Temp refrigerated/
freezer Base 7,2 Amps, 48
" wide, (2) drawers
accommodates (1) 18"x26
" pan or (2) 12"x20" pans
per drawer, (2) digital
thermostats, perforated top
surface, self-contained,
stainless steel construction,
6" adjustable,

NAME #

SIS #

AIA #

(40 kg). Forced air circulation for rapid cooling and an even tEMPowerper ature
distribution. Access to all components from the front and bottom. CFC free
(ecological refrigerant type: R404a, - gas in foam: cyclopenthane). Suitable for
use in ambient tEMPowerperatures of up to 104 °F (40 °C). Rounded corners inside
well for safe and easy cleaning. Constructed entirely in AISI 304 Stainless Steel
with Scotch Brite finish. Right-angled side edges to allow flush fitting joints
between EMPower units, minimizing gaps and possible dirt traps. Heavy duty
Stainless Steel tubular drawer handles. Supplied with 6" (150 mm) height
adjustable, removable legs. EMPower unit may be installed on castors.

Main Features

•Two (2) Drawer Refrigerated/Freezer Base with

built-in compressor unit.

•Unit able to oprate both as refrigerator or as freezer,

with temperature range from -7.6 °F to +46.4 °F (-22°
C to +8°C).

•Digital thermostat and display are protected by the

Stainless Steel front panel.

•Stainless Steel front panel with incorporated

Stainless Steel wire netting is easy to remove for
access to the thermostat and to allow for easy
cleaning.

•May be installed below any top unit.

•Perforated top surface provides the necessary

ventilation to allow for a flush connection between
base and Electrolux top units, eliminating the need
for the top unit legs.

•Each drawer to accommodate two 12” x 20” x 6”

deep pans with use of included, removable division
bar or two 325 mm x 530 mm (1/1 GN) pans.

•Drawer guides with safety stop mechanism can

support up to 264 lbs. (120 kg) and are removable
for cleaning.

•Magnetic snap-in drawer gaskets are removable

for cleaning.

•Perforated bottom plate in each drawer guarantees

correct air-flow, allows for small pans to stand
upright and is removable for cleaning.

•Perforated bottom plate can support up to 88lbs.

(40 kg).

•Forced air circulation for rapid cooling and an even

temperature distribution.

•Access to all components from the front and bottom.

•Suitable for use in ambient temperatures of up to

104 °F (40 °C).

•Rounded corners inside well for safe and easy

cleaning.

•Right-angled side edges to allow flush fitting joints

between units, eliminating gaps and possible dirt
traps.

•Heavy duty Stainless Steel tubular drawer handles.

•Supplied with 6" (150 mm) height adjustable,

removable legs.

Two (2) Drawer Refrigerated-Freezer Base - 48"

EMPower

Electrolux Professional, Inc.

10200 David T aylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401

www.electroluxusa.com/professional

•Unit may be installed on castors.

Construction

•CFC free (ecological refrigerant type: R404a, - gas in

foam: cyclopenthane).

•Constructed entirely in AISI 304 Stainless Steel with

Scotch Brite finish.

•4 pins to install the top are supplied with the unit.

Optional Accessories

•Kit of 4 wheels (2 with brake) for

refrigerated/freezer base 36" and 48"

•EMPower support for containers in

refrigerated bases

•EMPower 48" stainless steel top (with rear

splash & sides) for refrigerated/freezer
base

PNC 880123 ❑
PNC 880249 ❑
PNC 880315 ❑

EMPower

Two (2) Drawer Refrigerated-

Freezer Base - 48"
