EMPower
Smooth Gas Griddle Top - 36"
EMPower
Smooth Gas Griddle Top - 36"
169113 (ARG36FL)EMPower Restaurant Range
Short Form Specification
EMPower unit to be Electrolux Smooth Gas Griddle Top with three high efficiency 26,000 BTU (7 ,6 kW) burners. Suitable for natural gas or propane gas. Thick 1" (25 mm) mild steel griddle plate maintains selected tEMPowerperatures and assures quick recovery . 3,2" (81,5 mm) wide drainage channel running on full length of cooking surface. Large grease drainage hole diameter 2,4" (60mm). Two half gal. (2 l) grease collector drawers with hole to indicate when full, capture all excess grease and oil and can be extracted for easy dumping and cleaning. Worktop in AISI 304 Stainless Steel. 3mm stainless steel splashback. Front and side panels in Stainless Steel with Scotch Brite finish. All major components can be accessed from fr ont of the appliance for ease of maintenance. Special heavy duty chrome plated knobs for durability and easy cleaning. The configuration of bezels and knobs provides high level of protection against water infiltr ations. Right-angled side edges to allow flush fitting joints between EMPower units. Supplied with 4" (102mm) height adjustable, removable legs. EMPower unit may be installed on refrigerated base or open cupboard.
APPROV AL:
griddle, 36" wide, gas, 78,000 BTU , smooth top, 4" adjustable, removable legs
NAME #
SIS #
AIA #
Main Features
Three high efficiency 26,000 BTU (7,6 kW) burners.
Thick 1" (25 mm) mild steel griddle plate maintains
selected temperatures and assures quick recovery .
Suitable for natural gas or propane gas.
Flame failure device to protect against accidental
extinguishing of the flame.
3" (81,5 mm) wide drainage channel running on full length
of cooking surface.
Two large grease drainage holes diameter 2 ½" (60mm).
Three full length, half gal. (2 l) grease collector drawers
with hole to indicate when full, captures all excess grease and oil and can be extracted for easy dumping and cleaning.
3mm stainless steel splashback.
Front and side panels in Stainless Steel with Scotch Brite
finish.
All major compartments located in front of unit for ease
of maintenance.
Special heavy duty chrome plated knobs for durability
and easy cleaning.
The configuration of bezels and knobs provides high
level of protection against water infiltrations.
Right-angled side edges to allow flush fitting joints
between units, eliminating gaps and possible dirt traps.
Provided with kit for side-by-side connection between
units for minimizing gaps and possible dirt traps.
Supplied with 4" (102mm) height adjustable, removable
legs.
Unit may be installed on refrigerated base by removing
the legs and inserting the special pins (optional accessory).
Unit may be installed on open cupboard by removing
the legs and inserting the srews provided as standard with the open cupboards.
Included Accessories: propane converter kit, pressure
regulator and main shut off valve.
In compliance with ETL Certification (UL & NSF).
Configured for Natural Gas, LP Conversion Kit Included.
Construction
Worktop in 304 AISI stainless steel.
4 screws to install on the cupboard base are supplied
with the unit.
Gas pressure regulator is supplied with the unit.
Optional Accessories
Scraper for smooth griddlePNC 164255
EMPower 4 pins kit for mounting unit
to refrigerated/freezer. 1 kit is supplied with each EMPower refrigerated base
EMPower back mounted rear shelf-
spacer, 36"unit
PNC 169048
PNC 169099
Smooth Gas Griddle Top - 36"
EMPower
Electrolux Professional, Inc.
10200 David T aylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
www.electroluxusa.com/professional
EMPower
Smooth Gas Griddle Top - 36"
Portioning Shelf 12" PNC 169173
Portioning Shelf 16" PNC 16917 4
Portioning Shelf 24" PNC 169175
Portioning Shelf 36" PNC 169176
❑ ❑ ❑ ❑
