PLATINUM BEAM 5R EXTREME™ user manual 1.0
0.1 manual user | ™EXTREME 5R BEAM PLATINUM | NOITALE
w w w . e l a t i o n l i g h t i n g . c o m
©2014 ELATION PROFESSIONAL all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ELATION PROFESSIONAL logo and identifying product names and numbers herein are trademarks of ELATION PROFESSIONAL. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted. Product names used in this document may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. All non-ELATION brands and product names are trademarks or registered trademarks of their respective companies.
ELATION PROFESSIONAL and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic loss associated with the use or reliance of any information contained within this document, and/or as a result of the improper, unsafe, insufficient and negligent assembly, installation, rigging, and operation of this product.
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
2 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
C O N T E N T S
General Information |
4 |
Warranty |
6 |
Safety Instructions |
7 |
General Guidelines |
8 |
Discharge Lamp Warning |
9 |
Fixture Overview |
10 |
Lamp Installation Instructions |
11 |
Fixture Installation |
19 |
Understanding DMX |
22 |
Fixture Menu |
26 |
EWDMX Wireless DMX Receiver Set Up |
36 |
DMX Channel Functions And Values |
38 |
Error Codes |
41 |
Cleaning and Maintenance |
43 |
Technical Specifications |
44 |
Optional Accessories |
47 |
cETLus Approval Mark |
47 |
3 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
G E N E R A L I N F O R M A T I O N
INTRODUCTION
Congratulations, you have just purchased one of the most innovative and reliable lighting fixtures on the market today! The PLATINUM BEAM 5R EXTREME™ has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit. These instructions contain important information regarding safety during use and maintenance.
UNPACKING
Thank you for purchasing the PLATINUM BEAM 5R EXTREME™ by Elation Professional®. Every PLATINUM BEAM 5R EXTREME™ has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your unit for damage and be sure all accessories necessary to operate the unit have arrived intact. In the event damage has been found or parts are missing, please contact our customer support team for further instructions. Please do not return this unit to your dealer without first contacting customer support at the number listed below. Please do not discard the shipping carton in the trash. Please recycle whenever possible.
BOX CONTENTS
•(2) Omega Brackets
•(1) 3pin DMX Cable
•(1) powerCON Cable
•(1) Safety Cable
•Manual & Warranty Card
M A N U A L U P D A T E S
Please check www.elationlighting.com for the latest updated version of this manual.
4 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
CUSTOMER SUPPORT
Elation Professional® provides a customer support line, to provide set up help and to answer any question should you encounter problems during your set up or initial operation. You may also visit us on the web at www.elationlighting.com for any comments or suggestions. For service related issue please contact Elation Professional®.
ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST
Voice: 323-582-3322 Fax: 323-832-9142
E-mail: support@elationlighting.com
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: +31 45 546 85 30 Fax: +31 45 546 85 96
E-mail: support@elationlighting.eu
WARRANTY REGISTRATION
The PLATINUM BEAM 5R EXTREME™ carries a two-year (730 days) limited warranty. Please fill out the enclosed warranty card to validate your purchase. All returned service items whether under warranty or not, must be freight pre-paid and accompany a return authorization (R.A.) number. The R.A. number must be clearly written on the outside of the return package. A brief description of the problem as well as the R.A. number must also be written down on a piece of paper and included in the shipping container. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. Items returned without a R.A. number clearly marked on the outside of the package will be refused and returned at customer’s expense. You may obtain a R.A. number by contacting customer support.
I M P O R T A N T N O T I C E !
There are no user serviceable parts inside this unit. Do not attempt any repairs
yourself; doing so will void your manufactures warranty. Damages resulting from
modifications to this fixture and/or the disregard of safety and general user
instructions found in this user manual void the manufactures warranty and are
not subject to any warranty claims and/or repairs.
5 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
2 - Y E A R L I M I T E D W A R R A N T Y
A.Elation Professional® hereby warrants, to the original purchaser, Elation Professional® products to be free of manufacturing defects in material and workmanship for a period of two years, (730 days) from the date of purchase. This warranty shall be valid only if the product is purchased within the United States of America, including possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable evidence, at the time service is sought.
B.For warranty service, send the product only to the Elation Professional® factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Elation Professional® will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss of or damage to any such accessories, nor for the safe return thereof.
C.This warranty is void if the serial number has been altered or removed; if the product is modified in any manner which Elation Professional® concludes, after inspection, affects the reliability of the product; if the product has been repaired or serviced by anyone other than the Elation Professional® factory unless prior written authorization was issued to purchaser by Elation Professional®; if the product is damaged because not properly maintained as set forth in the instruction manual.
D.This is not a service contract, and this warranty does not include maintenance, cleaning or periodic check-up. During the period specified above, Elation Professional® will replace defective parts at its expense, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship. The sole responsibility of Elation Professional® under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of Elation Professional®. All products covered by this warranty were manufactured after January 1, 1990, and bare identifying marks to that effect.
E.Elation Professional® reserves the right to make changes in design and/or improvements upon its products without any obligation to include these changes in any products theretofore manufactured.
F.No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products described above. Except to the extent prohibited by applicable law, all implied warranties made by Elation Professional® in connection with this product, including warranties of merchantability or fitness, are limited in duration to the warranty period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or fitness, shall apply to this product after said period has expired. The consumer’s and or Dealer’s sole remedy shall be such repair or replacement as is expressly provided above; and under no circumstances shall Elation Professional® be liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
G.This warranty is the only written warranty applicable to Elation Professional® Products and supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore published.
6 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
S A F E T Y I N S T R U C T I O N S
The PLATINUM BEAM 5R EXTREME™ is an extremely sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow the guidelines in this manual. The manufacturer of this device will not accept responsibility for damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual.
This device falls under PROTECTION CLASS 1. It’s essential this device be grounded properly. Only qualified personnel should perform all electrical connections.
•For proper operation, follow the Installation guidelines described in this manual. Only qualified and certified personnel should perform installation of this fixture and only the original rigging parts (brackets) included with this fixture should be used for installation. Any modifications will void the original manufactures warranty and increase the risk of damage and/or personal injury.
•Never look directly into the light source of this fixture to prevent risk of injury to your retina, which may induce blindness. Those suffering from EPILEPSY should avoid looking directly into the light source of this unit at all times.
•The fan and air inlets must remain clean and never blocked. Allow approx. 6” (15cm) between this fixture and other devices or a wall for proper cooling.
•Always disconnect from main power source before performing any type of service and/or cleaning procedure. Only handle the power cord by the plug end, never pull out the plug by tugging the wire portion of the cord.
•Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If the power cord is damaged, replace it immediately with a new one of similar power rating.
7 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
G E N E R A L G U I D E L I N E S
• N E V E R O P E N T H I S F I X T U R E W H I L E I N U S E !
•During the initial operation of this fixture, a light smoke or smell may emit from the interior of the fixture. This is a normal process and is caused by excess paint in the interior of the casing burning off from the heat associated with the lamp and will decrease gradually over time.
•This fixture is a professional lighting effect designed for INDOOR / DRY LOCATIONS ONLY on stage, in nightclubs, theatres, etc.
•Please make sure there are NO FLAMMABLE MATERIALS close to the fixture while operating, to prevent any fire hazard.
•The fixture must be installed in a location with adequate ventilation, at least 1.5 feet (.5m) from adjacent surfaces. Be sure no air ventilation slots are blocked.
•DO NOT attempt installation and/or operation without knowledge how to do so.
•DO NOT permit operation by persons who are not qualified to operate this type of fixture. Most damages are the result of operations by nonprofessionals.
•Consistent operational breaks may ensure the fixture will function properly for many years to come.
•DO NOT shake fixture, avoid brute force when installing and/or operating fixture.
•Always install the fixture with an appropriate safety cable. When installing the fixture in a suspended environment, always use mounting hardware that is no less than M10 x 25 mm, also be sure the hardware is insert in the pre-arranged screw holes in the bracket of the fixture.
•Use the original packaging and materials to transport the fixture in for service.
•DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before replacing or serving.
8 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
D I S C H A R G E L A M P W A R N I N G
This fixture is fitted with a DISCHARGE LAMP, which is highly susceptible to damage if improperly handled. NEVER touch the lamp with your bare hands, as the oil from your hands will shorten the life of the lamp. Also, NEVER move the fixture until the lamp has had ample time to cool. Lamps are NOT covered under warranty conditions.
Avoid switching the fixture ON and OFF repeatedly in short intervals, as this will reduce lamp life and intensity. To achieve the intensity associated with discharge lamps, these lamps use gas sealed in a high-pressure environment to emit a brilliant output.
Due to the high pressure involved with the construction of the lamp, the lamp MAY EXPLODE DURING PROLONGED EXTENSIVE USE. This risk is increased with age; added care is encouraged when dealing with older lamps. Thus, the lamp must always be replaced at the end of their recommended duty cycle. Extreme caution should be used when operating this or any fixture fitted with a gas discharge lamp.
U V R A D I A T I O N N O T I C E
This fixture emits intense UV radiation, which is harmful to the eyes and skin. The intense luminance of the lamp can cause severe damage to the retina. NEVER operate this fixture with ANY of the protective covers removed. These covers have been specially designed to shield against UV radiation.
L A M P R E P L A C E M E N T
Please note that due to the nature of the Phillips™ Platinum 5R
Lamp and the optical path of the Elation PLATINUM BEAM 5R
EXTREME fixture, the lamp MUST BE replaced at 2,000 hours.
Use only Genuine Original Phillips™ platinum lamps. Other brand lamps may cause damage and void warranty!
9 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
F I X T U R E O V E R V I E W
1. LED Assembly
2. LCD Menu Function Display
3. Wireless DMX Indicator
4. DC Switch
5. Microphone
6. LEFT Button
7. DOWN Button
8. RIGHT Button
9. MODE/ESC Button
10. UP Button
11. ENTER Button
12. Wireless DMX Antenna
13. Carrying Handle(s)
14. Lamp Access/Cover Panel
15. 3pin DMX Input
16. 3pin DMX Output
17. 5pin DMX Output
18. 5pin DMX Input
19. powerCON Input
20. Fuse
10 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
L A M P I N S T A L L A T I O N I N S T R U C T I O N S
L A M P R E P L A C E M E N T
Please note that due to the nature of the Phillips™ Platinum 5R Lamp and the optical path of the Elation PLATINUM BEAM 5R EXTREME fixture, the lamp MUST BE replaced at 2,000 hours.
Use only Genuine Original Phillips™ Platinum 5R Lamps. Other brand lamps may cause damage and void warranty!
INSTALLING OR REPLACING THE LAMP
To ensure a proper/safe lamp change, carefully read all the following instructions.
LAMP PROTECTION CIRCUITRY
Because of the nature of the extreme heat associated with the Phillips™ Platinum 5R lamp and the tight nature of the internal optical system, it is IMPERATIVE that the lamp be replaced every 2,000 Hours. This is done to protect the internal optical system as well as prevent accidental lamp explosion, which could lead to hot glass particles falling from the fixture.
FAILURE TO CHANGE THE LAMP WITHIN 300 HOUR of the 2,000 HOUR RATED LIFE, WILL CAUSE THE FIXTURE TO AUTOMATICALLY SHUT DOWN!
At 2,000 Hours the LCD control display will begin to flash, “Replace The Lamp” and the lamp will flicker for the first five minutes of operation. At this point the lamp has reached the maximum rated life and should be replaced immediately. After the lamp has flickered for about five minutes it should strike normally allowing the fixture to be used temporarily until a replacement lamp can be installed. The fixture will continue to operate for an additional 300 hours, however the “Replace the Lamp” warning will continue to flash in the display. Keep in mind that the flicker protection circuitry will only work for about 300 Hours (lamp clock life of 2,000-2,300 Hours).
After 2,300 Hours the fixture will no longer respond to DMX commands and immediately enter a hibernation mode that will electronically discontinue all fixture functionality with the exception of a few menu commands. The fixture will continue to enter hibernation mode until the lamp is replaced and the lamp clock has been reset. To replace the lamp follow the safety guidelines and procedures listed on the next page.
11 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
LAMP SAFETY INSTRUCTIONS
•ALWAYS replace lamp every 2,000 Hours.
•Use only Genuine Original Phillips™ Platinum 5R lamps. Other brand lamps may cause damage and void the warranty!
•NEVER touch the lamp with your bare hands, as the oil from your hands will shorten the life of the lamp.
•Always disconnect the fixture’s main power supply before replacing lamp.
•Allow fixture to cool for at least 15 minutes before attempting any type of service.
•Make sure ALL covers/panels are replaced/secured before operating the fixture to prevent any risk and/or damage to eye retina from UV Radiation exposure!
LAMP INSTALLATION PROCEDURE
1.Place fixture on a flat surface and remove (4) screws marked “A”, “B”, “C”, and “D” and then remove rear cover plate (see image below) to access the lamp.
LAMP COVER PLATE
12 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
2. Gently remove (2) Red Wires connected to spade terminals on base of lamp.
3.Using two fingers on your RIGHT hand, pull the retention handle OUT and towards the RIGHT as far as possible.
13 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
4.While pulling the retention handle with your RIGHT hand, use your LEFT hand to gently twist the lamp COUNTERCLOCKWISE to remove it from under the retention brackets.
14 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
w w w . e l a t i o n l i g h t i n g . c o m
5.Using two fingers on your RIGHT hand, pull the retention handle OUT and towards the RIGHT as far as possible.
6.While pulling the retention handle with your RIGHT hand, use your LEFT had to gently install the lamp under the retention brackets by holding the lamp at a slight angle and positioning it until it is flush with the base.
15 PLATINUM BEAM 5R EXTREME™ User Manual 1.0
