ELAC S10.2 POWERED SUBWOOFER
S10.2 Powered Subwoofer
OPERATING INSTRUCTIONS
Safety Instructions
1. General information
• Please read and follow these safety instructions.
• Keep them safe for future reference.
• Observe all warnings on the speaker and in the manual. Please check the speaker for damage before
use. The speaker must be in perfect working condition. Damaged parts may lead to personal injury.
• CAUTION! Subwoofers and active speakers may be heavy. Be careful when lifting them to prevent
personal injury.
2. Use only as directed
• Connect the speaker(s) according to the instructions in the manual.
• Many ELAC speakers are equipped with spikes and/or anti-slip feet. They are explicitly provided for
levelling the speaker. For levelling on an uneven floor, unscrew the spikes or anti-slip feet by 2-3 turns of
thread. The speaker should always be in perfect vertical alignment: the stability of the speaker must not
be compromised by using spikes or anti-slip feet as the speaker may tip-over.
3. Location
• Install the speakers on a level surface only
• When choosing the location of these speakers do not place them in locations that are:
• In direct sunlight
• Very humid
• Prone to vibrations
• Exceptionally hot or cold
• Near CRT Televisions (the speakers are not magnetically shielded and may cause color issues
with a CRT based TV)
• Close to magnetic cards (Since the speakers are not magnetically shielded placing magnetic
cards such as credit cards or commuter cards may cause them to fail).
WARNING! Please ensure the product is perfectly stable to avoid injury from tip-over. Please note, that stability
can be increased by using spikes on carpeted surfaces. However, the mounting of spikes must be carried out
carefully due to their very sharp ends which may cause injuries. The stability on slippery floors can be increased
by using Velcro fastening tape or double-sided adhesive tape. Do not install the speaker near any heat
sources such as radiators, heating valves, stoves, or other apparatus (including amplifiers) that produce heat, or
in areas where there is a risk of explosion.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install the speaker in a closed rack or in a closed cupboard.
• Do not put burning candles on or near the speaker.
• Do not install the speaker near transformers because electromagnetic stray fields can cause hum noise
on woofers.
• In combination with certain materials / lacquers / material surfaces, anti-slip feet or spike washers may
cause colored imprints on the surfaces.
ELAC S10.2 Subwoofer | www.elac.com | Page 1
4. Overload
• Extreme overload of the device due to very high volume may cause damage to individual components.
Because of the possible danger, you should never leave loudspeakers under extreme overload
conditions unattended.
5. Service
• DANGER! Do not open the cabinet because of potentially hazardous voltages exist inside! Servicing to
be carried out by qualified service personnel only.
• Servicing is required when the loudspeaker has been damaged in any way, such as damage to
the power supply cord or the plug, or when liquid has been spilled or objects have fallen into the
loudspeaker, the speaker has been exposed to rain or moisture, does not operate normally, or has been
dropped. To reduce the risk of electric shock, do not open the loudspeaker. Servicing to be carried out
by qualified service personnel only.
6. Fuse links
• Various faults in subwoofers or active speakers may cause the fuse to blow. If the fuse blows, only
replace it with the correct fuse type and rating as shown on the rear of the loudspeaker on the fuse
holder.
7. Cleaning
• NOTE: Clean only with soft, smooth cloth or with dust brush. Do not use scouring agents, alcohol,
benzene, furniture polish or other agents for cleaning! Modern furniture is often coated with multiple
varnishes and plastics which can be treated with chemical agents. Some of these agents contain
substances which degrade or soften the rubber feet. Therefore we advise you to place an anti-slip mat
underneath the loudspeaker.
8. Volume
• CAUTION! Continuous high volume may cause severe damage to your hearing. Please listen responsibly.
9. Disposal
• The packaging is made from recyclable materials. Dispose of this in an environmentally friendly manner.
At end of life do not dispose the speaker with the standard household waste. The speaker must be
recycled in accordance with local legislation. Ask your local government for further information on
recycling as the device contains valuable raw materials. Disable the speaker before disposal.
10. Power
• This subwoofer is only intended to be connected to voltages that are listed on the rear panel of the
cabinet. Connection to any other voltage may cause irreversible damage to the subwoofer and will void
the warranty. Use of plug adapters is not recommended because they may allow connection to voltages
other than those printed on the back of this subwoofer.
ELAC S10.2 Subwoofer | www.elac.com | Page 2
Philosophy
Thank you for purchasing this ELAC product.
Since the time we started (1926), ELAC has always striven to achieve the very best.
Your new ELAC speakers are built to the highest standards using high-quality components that are carefully
constructed to deliver the best-in-class sound quality. They are developed by a passionate group of individuals
whose soul purpose is to bring a new dimension of sound quality into your home. Enjoy!
Before Use
• Avoid damage to the speakers and other components:
• Unbox the subwoofer carefully to avoid physical damage
• Keep your equipment turned o before connecting RCA cable
• Check to ensure power cable is pushed in and secured to avoid electrical shock and injury.
BASH Technology
The BASH® technology implemented in the amplifier module of the ELAC subwoofer features power reserves
with typically much lower levels of distortion. This is achieved by using an audiophile class A/B power amplifier
whose supply voltage is regulated by a class D amplifier circuit to prevent any unnecessary power losses and to
approach the eciency of a class D amplifier.
Since the audio signal is amplified in the analog domain, the high-frequency interference typical of class D
amplifiers is minimized along with their problem where the switching speed of the transistors is limited leading
to an increase of total harmonic distortion.
ELAC S10.2 Subwoofer | www.elac.com | Page 3
Controls and Indicators
1. Level — This control allows you to adjust the output of the subwoofer. The level should be adjusted so that it
properly blends with the rest of your audio system.
2. Low pass (Hz) — This control adjust the crossover frequency or low-pass filter of the subwoofer. The filter can
be set between 50 Hz and 150 Hz.
3. Phase — The phase switch allows you to invert the polarity (180 degrees) of the subwoofer to match the polarity of your main speakers and help blend the subwoofer signal.
4. Power — The power switch allows you to change the power mode of the subwoofer between “On” (Always
on), “O” (Always O), or “Auto” which will automatically sense if an audio signal is present to turn the subwoofer on. After several minutes of inactivity the subwoofer will switch to standby mode to conserve power.
5. Line In — These line level inputs are used to connect the subwoofer to your pre-amp/AV receiver. When
connecting to an AV Receiver with a single Subwoofer/LFE output, connect the RCA cable (not supplied) to the
Left input. If you are connecting your subwoofer to a pre-amp or stereo system without a dedicated subwoofer
output connect both the Left/Right inputs using stereo RCA cables (not included) to the stereo pre-outs on your
pre-amp.
6. Power Indicator — This indicator will illuminate in Blue signifying the subwoofer is powered on. There will be
no illumination when the subwoofer is o or in standby mode.
7. AC Inlet — Use the supplied power cord to connect the subwoofer to an available AC outlet.
1
2
6
3
4
5
7
ELAC S10.2 Subwoofer | www.elac.com | Page 4
Connecting your Subwoofer
If you are connecting the subwoofer to an AV Receiver or Pre-Amp with a dedicated subwoofer or LFE output,
connect an RCA cable (not supplied) from the LFE/Subwoofer output on the AV Receiver/Pre-Amp to the Left
RCA input on the subwoofer (Fig 1).
If you are connecting the subwoofer to a stereo pre-amp or AV Receiver without a dedicated LFE/Subwoofer
output, connect a set of stereo RCA connectors to the left and right RCA inputs on the subwoofer. If you are
using a pre-amp with only one set of pre-outs, use a splitter for each output on the pre-amp and connect two
sets of stereo RCA cables to both the amplifier and to the subwoofer (Fig 2).
ELAC S10.2 Subwoofer | www.elac.com | Page 5
Subwoofer Placement
Finding the proper placement for your subwoofer can take some trial and error, however here are a few basic
tips to get you started. In most cases the best position for the subwoofer is in the front corner (1) of the room.
Placing a subwoofer in a corner excites most room modes and oers the best chance of avoiding a null area (a
part of the room that experiences an acoustic reduction in bass).
If placing the subwoofer in the corners creates an abnormal amount of bass, you can try moving the subwoofer
to one of the side walls (2) near the front of the room.
If possible the best option is to move the subwoofer around the room and find the location that sounds the best
from your normal listening position. There are many test discs you can purchase that provide the correct test
signals for helping find this optimum location.
ELAC S10.2 Subwoofer | www.elac.com | Page 6
SPECIFICATIONS
S10.2
Enclosure Type Bass Reflex
Amplifier Type BASH Tracking
Maximum Amplifier Power 200 Watts Peak/100 Watts RMS
Frequency Response 35Hz - 150Hz
Crossover Frequency 50Hz - 150Hz
Driver 10" High Excursion Doped Paper
Cabinet CARB2 Rated MDF
Port Dual Flared
Passive Radiator N/A
Cabinet Finish Black Ash Vinyl
Dimension (WxHxD) 13.5" x 13.5" x13.5”
ELAC S10.2 Subwoofer | www.elac.com | Page 7
ELAC Americas Inc.
North America Limited Liability Warranty
Powered Subwoofers
ELAC Americas Inc. warrants to the original purchaser that this product be free from defects and or workmanship
for a period of 3 (Three) years on the cabinet and speaker driver and 1 (One) year on the amplifier from the
original date of purchase. During this time period, repair or replacement of parts will be free of charge to the
original owner (See below limitations). Shipping to and return from the repair center will be the responsibility of
the original purchaser.
Limitations
Warranty begins on the date of original purchase from an authorized ELAC Americas Inc. dealer.
Product is warranted only if used in home applications. Commercial use of this product is not warranted.
Product that has been modified or altered in anyway will not be warranted.
Product that has been abused or subjected to faulty equipment will not be warranted.
Products with defaced or removed serial numbers will not be warranted.
If service is required
In the event that service is required, please contact ELAC America at 714-252-8843 or at service@elac.com to
arrange for service or replacement. You will be responsible to provide proof of purchase (Copy or original sales
receipt). Shipping to and from our repair center will be the responsibility of the original purchaser.
Warranty Outside of North America
This warranty applies to products purchased in the United States and Canada. For warranty claims outside of
North America please contact the local dealer/distributor in the country of purchase.
ELAC S10.2 Subwoofer | www.elac.com | Page 8
