Eizo DURAVISION FDV1001T, DURAVISION FDX1201T, DURAVISION FDX1002T, DURAVISION FDX1001T User Manual
Important
Please read this User’s Manual carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
重要
请仔细阅读用户手册，熟练掌握其安全和有效的操作程序。
请妥善保存此手册，供日后参考。
For U.S.A. , Canada, etc. (rated 100-120 Vac) Only
FCC Declaration of Conformity
We, the Responsible Party EIZO NANAO TECHNOLOGIES INC.
5710 Warland Drive, Cypress, CA 90630
Phone: (562) 431-5011
declare that the product Trade name: EIZO
Model: DuraVision FDX1001T/FDV1001T/FDX1201T
is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures.
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and receiver
* Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
* Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
.
Canadian Notice
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de le classe B est comforme à la norme NMB-003 du Canada.
SAFETY SYMBOLS
This manual and this product use the safety symbols below. They denote critical information. Please read them carefully.
WARNING
Failure to abide by the information in a WARNING may result in serious injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate injury and/or property or product damage.
Indicates an attention to be required. For example, the symbol
risk of electric shock”.
Indicates a prohibited action. For example, the symbol
such as “Do not disassemble”.
Indicates a mandatory action that must be followed. For example, the symbol illustrates the
notication of general prohibition such as “Grounding the unit”.
illustrates the hazard type such as “the
illustrates a particular prohibited action
Using the special functions, such as screen size change (ex. changing the horizontal and vertical ratio of images input)
for commercial purposes or for the purpose of showing in public may violate copyright laws.
Product specication may vary with sales areas.
Conrm the specication in the manual written in language of the region of purchase.
Copyright© 2010 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
Apple and Macintosh are registered trademarks of Apple Inc.
Windows and Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries.
VESA is a registered trademark or a trademark of Video Electronics Standards Association in the United States and other countries.
PC-9801 and PC-9821 are trademarks of NEC Corporation.
EIZO, EIZO Logo and DuraVision are registered trademarks of EIZO NANAO CORPORATION in Japan and other countries.
All other trademarks are the properties of their respective owners.
2
PRECAUTIONS
IMPORTANT
To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit
•
(refer to the gure below).
Location of Caution Statement
【
WARNING
】
If the unit begins to emit smoke, smells like something is burning, or makes strange
noises,disconnect all power connections immediately and contact your dealer for
advice.
Attempting to use a malfunctioning unit may result in re, electric shock, or equipment damage.
Do not open the cabinet or modify the unit.
Opening the cabinet or modifying the unit may result in re, electric shock, or burn.
Refer all servicing to qualied service personnel.
Do not attempt to service this product yourself as opening or removing covers may result in re, electric
shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet
may result in re, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet,
unplug the unit immediately. Have the unit checked by a qualied service engineer before using it again.
Place the unit at the strong and stable place.
A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit
falls, disconnect the power immediately and ask your dealer for advice. Do not continue using a damaged
unit. Using a damaged unit may result in re or electric shock.
3
WARNING
Use the unit in an appropriate location.
Not doing so may result in re, electric shock, or equipment damage.
Do not place outdoors.
•
Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected
•
by strong vibration or shock.
Do not place in a dusty or humid environment.
•
Do not place in a location where water is splashed on the screen (bathroom, kitchen, etc.).
•
Do not place in a location where the steam comes directly on the screen.
•
Do not place near heat generating devices or a humidier
•
Do not place in an inammable gas environment.
•
To avoid danger of suffocation, keep the plastic packing bags away from babies and
children.
Use the enclose AC adapter.
The enclosed AC adapter is for use with this product only. Do not use the AC adapter with other
equipment. Connecting to power sources that do not match the power ratings of the AC adapter may
result in re or electric shock.
Make sure the power cord meets the following requirements.
This product does not include a power cord. Please provide separately a power cord which meets the
requirements. (For more information, please contact your dealer.)
The power cord is compatible with the standards of the country and region in which
•
this product is to be used.
The power cord has a rated value of at least 2.5A.
•
Power supply: 100-240Vac 50/60Hz
To disconnect the power cord, grasp the plug rmly and pull.
Tugging on the cord may damage and result in re or electric shock.
Use the correct voltage.
The unit is designed for use with a specic voltage only. Connection to another voltage than specied
•
in this User’s Manual may cause re, electric shock, or equipment damage.
Power supply: 100-240Vac 50/60Hz
Do not overload your power circuit, as this may result in re or electric shock.
•
Handle the power cord and AC adapter with care.
Do not place heavy objects on, pull or tie the power cord or the AC adapter. Use of a damaged cord or
AC adapter may result in re or electric shock.
Never touch the plug, AC adapter or power cord during a thunderstorm.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user’s manual of the arm stand and
install the unit securely.
Not doing so may cause the unit to become unattached, which may result in injury or equipment damage.
When the unit is dropped, please ask your dealer for advice. Do not continue using a damaged unit.
Using a damaged unit may result in re or electric shock. When reattaching the tilt stand, please use the
same screws and tighten them securely.
4
WARNING
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part
of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical
symptoms result, please consult your doctor.
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached
is dangerous. It may result in injury.
When handling the unit, grip the bottom of the unit rmly withboth hands
ensuring the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.
Do not install the unit in a closed space.
If the inerior becomes hot, it may result in re, electric shock or damage.
Do not touch the power plug or AC adapter with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a problem.
Mind that the AC adapter becomes hot during use.
Do not cover or place anything on top of the AC adapter. Do not place the AC adapter on top of
•
things that trap heat such as carpets, blankets, etc. Keep the AC adapter away from direct sunlight
and heat sources such as heaters.
Not doing so may result in re.
Do not touch with bare hands. Doing so may result in burns.
•
Do not suspend the AC adapter in midair.
Using it while suspended in midair may result in re or electric shock.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in re.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric shock.
If you plan to leave the unit unused for an extended period, disconnect the power cord
from the wall socket after turning off the power for safety and power conservation.
5
Notice for this monitor
Aside from displaying microscope images, this product is also suited to the dedicated usages such as operation of
terminal equipment.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is used
outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications specied in this manual are only applicable to signal cables specied by US.
Use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in
lower brightness is recommended.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Set up the screen saver and/or make use of the power saving function to avoid displaying the same image for
extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime.
(Refer to “Cleaning” on the next page.)
The LCD panel is manufactured using high-precision technology. However, missing pixels or lit pixels may appear on
the LCD panel, this is not malfunction. Percentage of effective pixels : 99.99% or higher.
The backlight of the LCD panel has a xed life span. When the screen becomes dark or begins to icker, please contact
your dealer.
Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in damage to the
panel. Do not attempt to brush with tissues as this may scratch the LCD panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation
may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation
disappears, otherwise it may cause some damages to the monitor.
6
Cleaning
ATTENTION
•
Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may
damage the cabinet or panel.
Do not soak liquid into the clearance between the panel and the panel frame.
•
NOTE
Optional ScreenCleaner is recommended for cleaning the panel surface.•
● Panel
Clean the panel with a soft cloth such as cotton cloth or lens cleaning paper.
•
Remove persistent stains gently with a cloth dampened with little water, and then clean the panel again
•
with a dry cloth for better nishing.
● Cabinet
Clean the cabinet with a soft cloth dampened with a little mild detergent.
•
To use the monitor comfortably
An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
•
according to the environmental conditions.
Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
•
7
CONTENTS
Cover ............................................................ 1
PRECAUTIONS ................................................ 3
Notice for this monitor .............................................. 6
CONTENTS ............................................................ 8
Chapter 1 Introduction .......................................9
1-1. Features .............................................................. 9
1-2. Package Contents .............................................. 9
Controls and Functions ................................... 10
1-3.
Chapter 2 Connecting Cables.......................... 11
2-1. Connection Procedures ....................................11
● When used as a PC monitor .............................11
● When using video equipment ........................... 12
Adjusting
2-2.
2-3.Installing
2-4.Calibrating
the Screen Angle ............................. 13
the Touch Panel Driver ..................... 14
the Monitor ..................................... 14
Chapter 3 Settings and Adjustments .............. 15
3-1. Basic Operation and Functions ...................... 15
3-2. Color Adjustment ............................................. 17
3-3. Congure other settings .................................. 18
Chapter 4 Troubleshooting .............................. 19
Chapter 5 Reference ......................................... 21
5-1. Attaching an Arm .............................................. 21
5-2. Specications ................................................... 22
Glossary ............................................................ 28
5-3.
Preset Timing .................................................... 29
5-4.
LIMITED WARRANTY .......................................... 30
8
CONTENTS
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
FDX1001T/FDV1001T: 10.4-inch screen, FDX1201T: 12.1-inch screen
•
Resolution
•
- FDX1001T/FDX1201T: XGA (1024 × 768) display compliant
- FDV1001T: VGA (640 × 480) display compliant
Maximum brightness
•
FDX1001T: 460 cd/m2, FDV1001T: 350 cd/m2, FDX1201T: 780 cd/m
LED backlight LCD panel
•
The LED backlight provides better power efficiency and reduced power consumption compared to existing
uorescent backlight LCD panels.
No mercury, a hazardous substance, is used.
Analog signal support
•
PC signal: D-Sub mini 15 pin connector × 1
- FDX1001T/FDX1201T: Horizontal scanning frequency 24 kHz - 50 kHz
Vertical scanning frequency 55 Hz - 75 Hz
- FDV1001T: Horizontal scanning frequency 24 kHz - 32 kHz
Vertical scanning frequency 56 Hz - 70.5 Hz
Video signal: S-Video/ Video input connector × 1
- Applicable Format NTSC, PAL, SECAM
Resistive technology touch panel function
•
Enables touch operation of the PC screen.
Crosshair display function
•
Displays lines (Fine, Circle or Broken Line) as a reference for the position of the image displayed on the monitor.
3-3. Congure other settings (page 18)
Video aspect function
•
Alters the display range of the input image (overscan). 3-3. Congure other settings (page 18)
2
1-2. Package Contents
Check that all the following items are included in the packaging box. If any items are missing or damaged,
contact your local dealer.
NOTE
Please retain the packing materials for future transport of the monitor.
•
Please refer to the touch panel driver installation guide on the CD-ROM when installing the touch panel driver.
•
LCD Monitor
•
AC Adapter
•
Cable Tie
•
User’s Manual (Limited Warranty included)
•
EIZO Touch Panel Disk (CD-ROM)
•
-Touch Panel Driver
-User’s Manual for Touch Panel Driver (PDF le)
RS-232C Cable
•
ATTENTION
This product does not include a power cord. Please provide separately a power cord which meets the usage
•
requirements.
Chapter 1 Introduction
9
Loading...
