Eizo CS270 User Manual
Color Management LCD Monitor
Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC or external device to using the
monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizoglobal.com
Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications..
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
2
Notice for this monitor
Aside from general purposes like creating documents, viewing multimedia content, this product is also suited
to applications such as graphics creation and digital photo processing, where accurate color reproduction is
a priority.
This product has been adjusted specically for use in the region to which it was originally shipped. If the
product is used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to
the composition of the rubber. Check the desk surface before use.
It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more
after the monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and
maintain a stable display.
When the screen image is changed after displaying the same image for extended periods of time, an
afterimage may appear. Use the screen saver or power save function to avoid displaying the same image for
extended periods of time.
If the monitor displays continuously over a long period of time, dark smudges or burn-in may appear. To
maximize the life of the monitor, we recommend the monitor be turned off periodically
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer
to “Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may
appear on the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker,
please contact your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such
as interference patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage
your panel. (If the pressure marks remain on the panel, leave the monitor with a black or white screen. The
symptom may disappear.)
.
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do
not attempt to brush with tissues as this may scratch the panel.
Notice for this monitor
3
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet
or panel, and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
The stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
Notice for this monitor
4
CONTENTS
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 6
1-1. Features ......................................................... 6
1-2. Controls and Functions ............................... 7
Front ................................................................ 7
●
Rear ................................................................. 8
●
1-3. EIZO LCD Utility Disk.................................... 9
Disk contents and software overview ............. 9
●
To use ColorNavigator 6 ................................. 9
●
1-4. Basic Operations and Functions ...............10
Basic Adjustment menu operations ...............10
●
Showing Button Guide ...................................11
●
Functions ........................................................12
●
Chapter 2 Adjusting Screens .......................... 13
2-1. Setting Resolution .......................................13
Compatible Resolutions/Formats ...................13
●
To switch signal formats .................................14
●
To set the display resolution for the OS .........14
●
To select screen size ......................................15
●
2-2. To select the display mode (color mode) ..17
2-3. Adjusting Color ............................................18
To adjust brightness .......................................18
●
To adjust the temperature ..............................19
●
To adjust gamma ............................................19
●
To set color gamut ......................................... 20
●
To perform advanced adjustments ............... 20
●
2-4. Specifying Color Space ............................. 24
2-5. Expanding Signal Output Range .............. 25
To extend the output range ........................... 25
●
To select the range of signals to extend ....... 25
●
2-6. Setting HDMI ................................................ 26
To reduce noise ............................................. 26
●
Chapter 3 Setting Monitor ............................... 27
3-1. Setting Adjustment Menu .......................... 27
Selecting the Language ................................ 27
●
Setting Orientation ........................................ 27
●
To change adjustment menu display position
●
3-2. Skipping Unused Display Modes .............. 28
3-3. Showing and Hiding the EIZO Logo ......... 28
3-4. Locking Operation Buttons ....................... 28
3-5. Changing DUE (Digital Uniformity
Equalizer) Setting ....................................... 29
3-6. Setting Signal Bandwidth .......................... 29
.. 27
3-7. Reset to default ........................................... 30
To reset the color adjustments ...................... 30
●
To reset all adjustments to the default
●
settings .......................................................... 30
Chapter 4 Connecting Multiple External
Devices ............................................ 31
4-1. To switch among input signals ................. 32
4-2. To set input signal selection...................... 32
4-3. Skipping Unused Input Signals ................. 32
4-4. Switching USB Port Automatically ........... 33
Chapter 5 Power Saving Functions ................ 34
5-1. Setting Power Save ..................................... 34
5-2. Adjusting the Brightness of Indicator ...... 35
5-3. Checking the Power Saving Level ............ 35
5-4. Setting DisplayPort Power Save ............... 35
Chapter 6 Troubleshooting .............................. 36
6-1. No picture .................................................... 36
6-2. Imaging problems ........................................37
6-3. Other problems ........................................... 38
Chapter 7 Reference ........................................ 39
7-1. Attaching the Arm ....................................... 39
7-2. Detaching/Attaching Stand Base .............. 40
7-3. Attaching/Detaching Cable Holder ........... 43
7-4. Making Use of USB (Universal Serial
Bus) ............................................................... 44
System Requirement ..................................... 44
●
Connection Procedure .................................. 45
●
7-5. Showing Monitor Information.................... 45
Displaying signal information ........................ 45
●
Displaying Monitor Information ..................... 46
●
7-6. Specications ..............................................47
Accessories ................................................... 49
●
Chapter 8 Glossary .......................................... 50
Appendix .............................................................. 52
Trademark ............................................................... 52
License / Copyright ................................................ 52
FCC Declaration of Conformity ............................ 53
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor ........................... 54
Hinweis zur Ergonomie : ....................................... 54
LIMITED WARRANTY ............................................. 55
Recycling Information ........................................... 64
CONTENTS
5
Chapter 1 Introduction
1-1. Features
• 27.0″ wide format LCD
• Wide color gamut (Adobe®RGB coverage: 99%)
• Supports a resolution of 2560 × 1440.
• IPS panel with 178˚ horizontal and vertical viewing angles
• Frame synchronization mode supported (23.75 - 30.5Hz, 47.5 - 61.0Hz)
• 3 signal input terminals (DVI-D × 1, HDMI × 1, DisplayPort × 1)
- DisplayPort connector (applicable to 8 bit and 10 bit)
- HDMI connector (applicable to 8 bit, 10 bit, and 12 bit)
Can handle PC signals in HDMI input
*1 Not applicable to audio signals.
*2 The maximum screen display is 10 bits.
• Color Mode function
Reproduces a color temperature, gamma, and gamut compliant with the following standard.
- Adobe®RGB / sRGB
• Stand with wide range of movement
The monitor can be adjusted to a position where it provides you with a comfortable and less tiring work environment.
(Tilt: up 35˚/down 5˚, Swivel: 344˚, Adjustable height: 141 mm (Tilt: 35°), 148 mm (Tilt: 0°))
*1
*1,*2
• Supports portrait format
• The “ColorNavigator 6” Color Management Software enables you to calibrate monitor characteristics and
generate color proles
See “1-3. EIZO LCD Utility Disk” (page 9).
• Displays HDCP (High-bandwidth Digital Protection) protected contents.
Note
• This monitor supports portrait format. You can change the orientation of the Setting menu when using the monitor
screen in vertical display position. (see “Setting Orientation” (page 27))
• When using the monitor screen in a portrait position, the graphics board supporting portrait display is required. When
placing the monitor in a por trait position, the settings of your graphics board need to be changed. Refer to the User’s
Manual of the graphics board for details.
Chapter 1 Introduction
6
1-2. Controls and Functions
Front
●
Adjustment
1. button Switches input signals for display (page 32).
2.
3.
4.
5.
6.
7. Power Indicator
button Changes Color Mode (page 17).
button Cancels the setting/adjustment and exits the Adjustment menu.
button
button
button Turns the power on or off.
*1
menu
1
• Provides the menu selection as well as the adjustment and setting of a function.
• Displays the Brightness menu (page 18).
Displays the Adjustment menu, determines an item on the menu screen, and saves
values adjusted (page 10).
Indicates the monitor’s operation status.
Blue: Operating
Orange: Power saving mode
OFF: Main power/Power off
3
4
5 6 72
*1 For details, see “1-4. Basic Operations and Functions” (page 10).
Chapter 1 Introduction
7
Rear
●
15
13
14
8 9
8. Main power switch Turns the main power on or off.
9. Power connector Connects the power cord.
10. Input signal connectors Left: DVI-D connector / Center: HDMI connector / Right: DisplayPort connector
11. USB upstream port
12. USB downstream port Connects a peripheral USB device.
13. Stand
14. Security lock slot Complies with Kensington’s MicroSaver security system.
15. Cable holder Covers the monitor cables.
*2 This monitor can be installed with another compatible arm or stand by removing the standard stand section. (see “7-1.
*2
Attaching the Arm” (page 39)).
Connects the USB cable to use the software that needs USB connection, or to use
USB hub function (page 44).
Used to adjust the height and angle of the monitor screen.
10 11
12
Chapter 1 Introduction
8
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents
and the overview of the software programs.
Disk contents and software overview
●
The disk includes application software programs for adjustment, and User’s Manual. Refer to “Readme.txt” or
the “read me” le on the disk for software startup procedures or le access procedures.
Contents Overview
A “Readme.txt” or “read me” le
ColorNavigator
User’s Manual of this monitor (PDF le)
To use ColorNavigator 6
●
Refer to the corresponding User’s Manual on the CD-ROM disk in order to install and use the software. When
using this software, you will need to connect a PC to the monitor with the supplied USB cable. For details of
the USB cable connection, see “7-4. Making Use of USB (Universal Serial Bus)” (page 44).
6 Software for calibrating monitor characteristics and generating ICC
proles (for Windows) and Apple ColorSync proles (for Macintosh).
(The monitor and PC must be connected using the USB cable.)
Chapter 1 Introduction
9
1-4. Basic Operations and Functions
Basic Adjustment menu operations
●
Displaying Adjustment Menu
1.
1. Press . The Adjustment menu appears.
Item
Menu
Adjusting/Setting
2.
1. Choose a menu to adjust/set with , , and then press .
Current modeMenu title
Setting
2. Choose an item to adjust/set with , , and then press .
3. Adjust/set the selected item with , , and then press .
Exiting
3.
1. Press a few times. The Adjustment menu nishes.
Chapter 1 Introduction
10
Showing Button Guide
●
When you press the front buttons (except the button), the button guide appears next to the button.
Note
• The button guide will continue to appear while the Adjustment menu or Mode menu is showing.
• The button guide is displayed differently depending on the selected menu or status.
• In CAL mode, the brightness cannot be adjusted even though the button guide is displayed above the
and buttons.
Chapter 1 Introduction
11
Functions
●
The following table shows the menus for adjustment and setting items of each menu.
Main Menu Item Reference
Color
Screen
*1
Brightness
Temperature
Gamma
Color Gamut
Advanced
Settings
Color Reset
Screen Size
Color Space
Range Extension Range Extension
HDMI Settings
Hue
Saturation
Clipping
Gain
6 Colors
*2
Super White
Noise Reduction
“2-3. Adjusting Color” (page 18)
“3-7. Reset to default” (page 30)
“To select screen size” (page 15)
“2-4. Specifying Color Space” (page 24)
“2-5. Expanding Signal Output Range”
(page 25)
“2-6. Setting HDMI” (page 26)
Power
Manager
Menu Settings
Tools
*1 Functions available for adjustment and setting in Standard Mode (page 17) are displayed.
*2 This function is available with HDMI signal input.
Power Save
Indicator
EcoView Index
Language
Orientation
Menu Position
Input Selection
Input Skip
Mode Skip
USB Selection
Signal Info
Monitor Info
All Reset
“5-1. Setting Power Save” (page 34)
“5-2. Adjusting the Brightness of Indicator”
(page 35)
“5-3. Checking the Power Saving Level”
(page 35)
“Selecting the Language” (page 27)
“Setting Orientation” (page 27)
“To change adjustment menu display
position” (page 27)
“4-2. To set input signal selection” (page
32)
“4-3. Skipping Unused Input Signals” (page
32)
“3-2. Skipping Unused Display Modes”
(page 28)
“4-4. Switching USB Port Automatically”
(page 33)
“7-5. Showing Monitor Information” (page
45)
“3-7. Reset to default” (page 30)
Chapter 1 Introduction
12
Chapter 2 Adjusting Screens
2-1. Setting Resolution
Compatible Resolutions/Formats
●
The monitor supports the following resolutions and signal format.
Digital Input (DVI-D, DisplayPort, HDMI: PC signal*1)
3
*
Vertical scan
frequency
60 Hz - √ √ -
Resolution
640x480 60 Hz √ √ √ √
720x400 70 Hz √ √ √ √
800x600 60 Hz √ √ √ √
1024x768 60 Hz √ √ √ √
1280x960 60 Hz √ √ √ √
1280x1024 60 Hz √
1600x1200 60 Hz √ √ √ √
1920x1080 60 Hz √ √ √ √
1920x1200 60 Hz √ √ √ √
2560x1440 30 Hz √
2560x1440
DVI-D
(Single Link)
2
*
DVI-D
(Dual Link)
DisplayPort HDMI
√ √ √
- - √
Digital Input (HDMI: video signal*1)
Format
640 x 480 - - - - √
480i - - - - √
480p - - - - √
576i - - - √ 576p - - - √ 720p - - - √ √
1080i - - - √ √
1080p √ √ √ √ √
*1 When displaying PC signals by HDMI signal input, change the monitor’s setting in advance (see “To switch signal
formats” (page 14)).
*2 When displaying in this resolution or vertical scan frequency, change the monitor’s setting in advance (see “ To
switch signal formats” (page 14)).
*3 Recommended resolution
24Hz 25Hz 30Hz 50Hz 60Hz
Vertical scan frequency
Chapter 2 Adjusting Screens
13
To switch signal formats
●
The monitor’s displayable resolution can be changed. Use this function in the following cases.
• DVI: When displaying a dedicated resolution and vertical scan frequency for Single Link.
• HDMI: When displaying PC signals.
Adjustable Range
• DVI: Dual Link / Single Link
• HDMI : Video / PC
Procedure
1. Press
2. Holding
The “Optional Settings” menu appears.
3. Choose “Signal Selection” from “Optional Settings”, and press .
4. Choose the input signal to set with
5. Select “Signal Format” with the selected input signal and press
6. Switch the signal format with
7. Select “Finish” with
8. Press
To set the display resolution for the OS
●
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change
the resolution, follow the procedure below.
to turn off the monitor.
down, press for at least two seconds to turn on the monitor.
or , and press .
.
or .
or .
.
Windows 10
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Display Settings”.
3. On the “Customize your display” dialog box, click “Advanced display settings”.
4. Select a monitor, then choose a resolution from the “Resolution” pull-down menu.
5. Click the “Apply” button.
6. When a conrmation dialog box is displayed, click “Keep changes”.
Windows 8.1 / Windows 7
1. For Windows 8.1, click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except for icons.
3. From the displayed menu, click “Screen resolution”.
4. On the “Screen Resolution” dialog box, select the monitor.
5. Click “Resolution” to select the desired resolution.
6. Click the “OK” button.
7. When a conrmation dialog box is displayed, click “Keep changes”.
Chapter 2 Adjusting Screens
14
OS X Mountain Lion (10.8) and later
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays”. (For Mac OS X Mountain Lion
(10.8), click “Displays” for “Hardware”.)
3. On the displayed dialog box, select the “Display” tab, then choose “Change” for “Resolutions”.
4. The list of selectable resolutions is displayed. Select the desired resolution.
If the desired resolution is not displayed in the list, hold down the Option key and select “Change”.
5. Your selection will be reected immediately. When you are satised with the selected resolution, close the
window.
Mac OS X 10.7
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions” eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close the
window.
To select screen size
●
The image with the resolution other than the recommended resolution is displayed in full screen automatically.
You can change the screen size by using the “Screen Size” function from “Screen”.
DVI, DisplayPort HDMI (PC signal) input
Settings Function
Full Displays an image in full screen. Images are distorted in some cases because the vertical
rate is not equal to the horizontal rate.
Enlarged Displays an image in full screen. In some cases, a blank horizontal or vertical border
appears to equalize the vertical rate and the horizontal rate.
Normal Displays images with the specied resolution.
Example: Image size 1280 × 1024
Full Enlarged Normal
2560 × 1440 1800 × 1440 1280 × 1024
Procedure
1. Choose “Screen” from the Adjustment menu, and press
2. Choose “Screen Size” from “Screen”, and press
3. Select “Full”, “Enlarged”, or “Normal” with
4. Press
to exit.
.
.
or .
Chapter 2 Adjusting Screens
15
HDMI (720p, 1080i, 1080p) input
Settings Function
Enlarged Displays an image in full screen. In some cases, a blank horizontal or vertical border
appears to equalize the vertical rate and the horizontal rate.
Dot by Dot Displays images with the specied resolution.
Example: 720p
Enlarged Dot by Dot
Procedure
1. Choose “Screen” from the Adjustment menu, and press
2. Choose “Screen Size” from “Screen”, and press
3. Select “Enlarged”, or “Dot by Dot” with
4. Press
to exit.
or .
.
.
HDMI (640x480, 480i, 480p, 576i, 576p) input
Settings Function
Auto The monitor automatically changes the screen size according to the aspect ratio sent from
the auto input signal.
4:3 Displays images in a 4:3 format screen.Black bars appear on both sides of the screen.
16:9 images are horizontally compressed.
Letter Box Displays 16:9 letterboxed images in full screen.
Images other than the letterboxed ones are partly cut on top and bottom.
16:9 Displays the entire 16:9 image in full screen. Black bars appear on the top and bottom of
the screen.
4:3 images are horizontally expanded.
Example: 480i/480p (16:9)
Auto 4:3 Letter Box 16:9
Procedure
1. Choose “Screen” from the Adjustment menu, and press
2. Choose “Screen Size” from “Screen”, and press
3. Select “Auto”, “4:3”, “Letter Box”, or “16:9” with
4. Press
to exit.
or .
.
.
Chapter 2 Adjusting Screens
16
2-2. To select the display mode (color mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
Standard Mode Adjust color using the monitor’s Adjustment menu.
1-Custom Available for the color settings according to your preference.
2-Paper Produces a printed paper effect by decreasing contrast and color temperature.
3-Adobe®RGB Suitable for color matching with Adobe®RGB compatible peripherals.
4-sRGB Suitable for color matching with sRGB compatible peripherals.
CAL Mode Adjust the monitor’s color using software.
5 - CAL1
6-CAL2
7-CAL3
Attention
• Avoid operating any function of the monitor while using ColorNavigator 6.
Displays the screen adjusted by the Color Management Software “ColorNavigator 6”.
Example:
The mode menu appears.
1-Custom
↓↑
2-Paper
↓↑
3-Adobe®RGB
↓↑
4-sRGB
↓↑
5- CAL1
↓↑
6-CAL2
↓↑
7-CAL3
Procedure
1. Press
The mode menu appears at the bottom left of the screen.
.
2. The mode among the list is highlighted in turn each time is pressed.
You can switch the mode with or while the mode menu is displayed.
Note
• The Adjustment menu and the Mode menu cannot be displayed at the same time.
• You can disable a specic mode to be selected. For more information, see “3-2. Skipping Unused Display Modes” (page 28).
Chapter 2 Adjusting Screens
17
2-3. Adjusting Color
When displaying in Standard Mode, the “Color” menu of the Adjustment menu allows you to set and save
independent color adjustments for each mode.
Attention
• It takes about 30 minutes (under our measurement conditions) for the performance of electrical parts to stabilize. Please wait
30 minutes or more after the monitor power has been turned on, and then adjust the monitor.
• The same image may be seen in different colors on multiple monitors due to their monitor-specic characteristics. Make ne
color adjustment visually when matching colors on multiple monitors.
Note
• The values shown in “K” or “%” are available only as reference.
To adjust brightness
●
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back
panel).
Setting Range
0 to 100%
Procedure
1. Press
The Brightness menu appears.
2. Use or for adjustment.
3. Press
or .
to exit.
Attention
• If the entered value cannot be set, the value will appear in magenta. In such a case, change the value.
Note
• Alternatively, you can use “Brightness” under “Color” in the Adjustment menu to adjust it.
Chapter 2 Adjusting Screens
18
To adjust the temperature
●
The color temperature can be adjusted.
The color temperature is normally used to express the color of “White” and/or “Black” by a numerical value.
The value is expressed in degrees “K” (Kelvin).
The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the ame
temperature. The gain preset values are set for each color temperature setting value.
Setting Range
Settings Purpose
4000K to 10000K Specify color temperature in units of 100 K
Native The image is displayed in the preset color of the monitor (Gain: 100% for each RGB).
Adobe®RGB Change to color temperature in conformance with Adobe®RGB.
sRGB Change to color temperature in conformance with sRGB.
User Displayed when gain is changed.
Procedure
1. Choose “Color” from the Adjustment menu, and press
2. Choose “Temperature” from “Color”, and press
3. Use
4. Press
Note
• “Gain” allows you to perform more advanced adjustment (see “To adjust gain” (page 23)).
or for adjustment.
to exit.
.
.
To adjust gamma
●
Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the
variation rate is not proportional to the input signal. To keep the balance between the input signal and the
brightness of the monitor is called as “Gamma correction”.
Setting Range
Settings Purpose
1.6 to 2.7 Set the gamma value.
Adobe®RGB Set the gamma curve dened by Adobe®RGB.
sRGB Set the gamma curve dened by sRGB.
Paper Display image look like it is printed on paper.
Procedure
1. Choose “Color” from the Adjustment menu, and press
2. Choose “Gamma” from “Color”, and press
3. Use
4. Press
or for adjustment.
to exit.
.
.
Chapter 2 Adjusting Screens
19
To set color gamut
●
Set the color reproduction area (color gamut). “Color gamut” is the range of colors that devices such as
monitors, digital cameras and printers can express. Various standards are dened.
Settings Purpose
Native Display images in the monitor’s original color gamut.
Adobe®RGB Display images in the color gamut dened by Adobe®RGB.
sRGB Display images in the color gamut dened by sRGB.
Procedure
1. Choose “Color” from the Adjustment menu, and press
2. Choose “Color Gamut” from “Color”, and press
3. Use
4. Press
Note
• The method of displaying the dened color gamut outside the normal gamut of the monitor can be set. For more
information, see “To set clipping” (page 22).
To perform advanced adjustments
●
Make further advanced color adjustments.
or for adjustment.
to exit.
.
.
To adjust hue
This function allows you to adjust the hue.
Setting Range
-100 to 100
Procedure
1. Choose “Color” from the Adjustment menu, and press
2. Choose “Advanced Settings” from “Color”, and press
3. Choose “Hue”, and press
4. Use
5. Press
Attention
• Using this function may make some color gradations unavailable for display.
or for adjustment.
to exit.
.
.
.
Chapter 2 Adjusting Screens
20
To adjust saturation
This function allows you to adjust color saturation.
Setting Range
-100 to 100
Procedure
1. Choose “Color” from the Adjustment menu, and press
2. Choose “Advanced Settings” from “Color”, and press
3. Choose “Saturation”, and press
4. Use
5. Press
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The minimum value (-100) changes the screen to monochrome.
or for adjustment.
to exit.
.
.
.
Chapter 2 Adjusting Screens
21
Loading...
