Edimax Technology ND-233E User Manual

ND-233E

Quick Installation Guide

09-2012 / v1.0

Notice According to GNU General Public License Version 2

This product includes software that is subject to the GNU General Public License version

2. The program is free software and distributed without any warranty of the author. We
offer, valid for at least three years, to give you, for a charge no more than the costs of
physically performing source distribution, a complete machine-readable copy of the
corresponding source code.

Edimax Technology Co., Ltd.

Add: No. 3, Wu-Chuan 3rd Rd., Wu-Ku Industrial Park, New Taipei City, Taiwan (R.O.C.)
Tel: [phone]
Email: [e-mail]

COPYRIGHT

Copyright  Edimax Technology Co., Ltd. all rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any
form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission from Edimax
Technology Co., Ltd.

Edimax Technology Co., Ltd. makes no representations or warranties,
either expressed or implied, with respect to the contents hereof and
specifically disclaims any warranties, merchantability, or fitness for any
particular purpose. Any software described in this manual is sold or licensed
as is. Should the programs prove defective following their purchase, the buyer
(and not this company, its distributor, or its dealer) assumes the entire cost of
all necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Edimax Technology Co., Ltd.
reserves the right to revise this publication and to make changes from time to
time in the contents hereof without the obligation to notify any person of
such revision or changes.

The product you have purchased and the setup screen may appear slightly
different from those shown in this QIG. For more information about this
product, please refer to the user manual on the CD-ROM. The software and
specifications are subject to change without notice. Please visit our website

www.edimax.com for updates. All brand and product names mentioned in

this manual are trademarks and/or registered trademarks of their respective
holders.

1

PACKAGE CONTENTS

Step 1:
Please use a star wrench to remove
the 4 screws (indicated by the arrows
in the diagram), and then remove the
front cover.

Step 2:
Please fix the camera to the ceiling
with the four supplied screws.

Before you start using this product, please check if there is anything missing in
the package, and contact your dealer to claim the missing item(s):

 1 x Network camera

 1 x Power adapter

 1 x Tools package

 1 x CD with utility software and user manual

 1 x Quick installation guide

HARDWARE INSTALLATION

Please follow the instructions to set up your new network camera. If you wish
to place this network camera on a table, please skip steps 1 and 2.

2

Step 3:
Please connect the power and
network cables.

Step 4:
Please loosen the screw identified by
the arrow in the diagram, and then
rotate the mechanism to set the
camera to its desired position.

Step 5:
Please loosen the screw identified by
the arrow in the diagram, and again
turn the mechanism to set the
camera to its desired position.

3

Step 6:
Please rotate the mechanism to set
the camera to a proper position.

Step 7:
Please loosen the screw identified by
the arrow in the diagram, and adjust
the lens.

Step 8:
Please re-attach the front cover and
tighten it appropriately. Please
ensure the front cover is in the
correct position – so that the rubber
around the camera lens is sufficiently
close to the transparent dome
covering.
