Edimax Technology IC-9000 User Manual

Notice according to GNU/GPL

-

Version 2

Copyright by Edimax Technology Co, LTD. all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or
by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of this Company.

This company makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties, merchantability or fitness for any particular purpose. Any software
described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not this company, its
distributor, or its dealer) assumes the entire cost of all necessary servicing,
repair, and any incidental or consequential damages resulting from any defect
in the software. Further, this company reserves the right to revise this
publication and to make changes from time to time in the contents hereof
without obligation to notify any person of such revision or changes.

The product you have purchased and the setup screen ma y appear slightly
different from those shown in this QIG. For more detailed information about
this product, please refer to the User's Manual on the CD-ROM. The software
and specifications could be subjected to change without notice. Please visit
our web site www.edimax.com for the update. All right reserved including all
brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.

This product includes software that is subject to the GNU/GPL-Version 2.
You find the text of the license on the product cd/dvd. The program is free
software and distributed without any warranty of the author. We offer, valid
for at least three years, to give you, for a charge no more than the costs of
physically performing source distribution, a complete machine-readable
copy of the corresponding source code.
Please contact Edimax at: Edimax Technology co., Ltd, NO. 3, Wu-Chuan
3rd RD Wu-Ku-Industrial Park, Taipei Hsien, Taiwan. R.O.C., TEL :
[phone], FAX : [phone], [e-mail]

1. Product Information

Thank you for purchasing this IC-9000! The IC-9000 is designed
with the “user-friendly” concept. You can install the IP Camera easily
on your home network and then access the IP Camera anywhere in
the world with the video management utility. No need to set
complicated DNS name or change the router’s configuration. It’s
just a plug & play.

Before you start to use the IC-9000, please check the package
contents. If anything is missing, please contact the dealer of
purchase and return the package to claim for missing contents.

2. Check Your Package Contents



One IC-9000 DDNS-Free Outdoor IP Camera



One Power Adapter



One Ethernet Cable



One Bracket



One Installation Guide



One CD ROM (User Guide & Utility)



One Account Card



One Accessory Bag (Including Anchors & Screws)

If any of the above items are missing, please contact your
supplier.

3. System Requirement



CPU: Pentium 4 (or equivalent AMD) 1.0 GHz or above, 1 GB
RAM



OS: Windows XP/Vista/Win 7



Browser: IE 7 or above

4. Interface Information

Ethernet Indication LED

Status Indication LED

Item

No.

1

2

3 Lens

4 IR LEDs

5 Light Sensor

6

7 Digital Input This is for alarm detection, an open circuit is

Name Description

Indicates if the Ethernet link is ok and

Ethernet

Indication

LED (blue)

Status
Indication
LED (red)

Ethernet

Jack

packet traffic is sending/receiving. When the
Ethernet cable is connected, the LED is
constant blue light. When there is packet
sending/receiving, the LED is blinking blue
light.
Indicates the Internet connection status.
When the Internet connection is connected,
the LED will be constant red light. If there is
any Internet connection problem, the LED
will be blinking red light.
The focus of the lens is fixed. The effective
focus range is from 30cm to infinity.
Totally 36 IR LEDs which can provide
approximately 30m distance night vision
The light detector can detect when the light
is becoming dark and turn on the IR LEDs
automatically
10/100Mbps fast Ethernet port (Connects to
your local area network)
