EdgeStar DEP650EW, DEP400EW, DEP740EW User Manual
Dehumidifier
Models:
DEP400EW, DEP650EW, DEP740EW
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
Important Safety Information
Improper handling can cause serious damage to the EdgeStar dehumidifier and/or to the user. This dehumidifier is
designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may
invalidate the warranty. Please review the ratings label located on the rear panel of the unit for electrical and other
technical data related to this unit. The unit must be used in a properly grounded wall outlet. Please read and follow the
safety information listed below.
Electrical Safety
This dehumidifier is designed for indoor use only.
Do not use the unit near bath tubs, swimming
pools or other bodies of water.
Do not wet the housing or control panel.
Do not exceed the power outlet ratings.
Do not pull the unit by the cord.
Always turn the unit off and unplug it from the
outlet when cleaning.
Unplug the unit if it is not going to be used for an
extended time period.
Do not operate the unit with a power plug missing
the ground plug, a damaged cord or a loose
socket.
Be sure the dehumidifier is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut or remove the grounding plug.
Do not use extension cords or power strips with
this unit. You may need to contact your electrician
if it is necessary to use a longer cord or do not
have a grounded outlet. Do not modify the power
cord’s length or share the outlet with other
appliances. It is recommended the unit be
connected on its own circuit.
Do not start or stop the unit by switching the
circuit’s power on and off.
If the power cord is damaged, it must be replaced
by the manufacturer or a qualified technician.
Never open the unit while it is plugged in.
Immediately unplug the unit if it makes strange
sounds, emits smells or smoke comes out of it,
and contact customer service.
Do not remove any part of the casing unless
instructed by an authorized technician.
You should never attempt to repair the unit
yourself.
General Safety
This unit is not intended to be used by children.
Children should be supervised to ensure that they
do not play with this product.
Do not allow children to play with the controls or
drop any objects into the air outlets or vents.
Care should be taken when using the unit in a room
with infants, elderly persons, and children.
Do not place flower vases, containers, or any
objects on top of the unit.
Do not allow anyone to sit on the unit.
Do not climb on or use the unit as a step.
Do not cover the air intake or exhaust vents with
towels, clothes or materials that prevent air flow.
When using in closets or confined spaces, be sure
to keep doors open to allow proper ventilation.
Do not use this appliance near flammable gas or
combustibles, such as gasoline, benzene, thinner,
etc.
Do not use in areas where chemicals are handled.
Do not place the unit near a heat source as doing so
may cause the plastic parts to melt.
Only use in an upright position on a flat, level
surface and provide at least 10 inches of clearance
from any walls or objects.
Route the power cord carefully to avoid creating a
tripping hazard.
When using in closets or confined spaces, be sure
to keep doors open to allow proper ventilation.
Clean the filters every two weeks or as needed.
Inspect the filters regularly.
Always insert the filters securely.
Never run the unit without filters.
The water produced by the dehumidifier
is not potable or suitable for drinking.
Do not drink or use condensate or water
drained from the unit as it contains
contaminates and could make you sick.
Electrical products should not be disposed of
with household waste. Please contact your
local recycling center for more information on
how to recycle electronic waste.
i
Table of Contents
IMPORTANT SAFETY INFORMATION ................................................................. I
INTRODUCTION ................................................................................................... 1
PARTS IDENTIFICATION ..................................................................................... 2
BACK VIEW .......................................................................................................... 2
FRONT VIEW ........................................................................................................ 2
INSTALLATION INSTRUCTIONS ........................................................................ 3
CONTROL PANEL OVERVIEW ............................................................................ 4
OPERATING THE CONTROL PANEL ................................................................. 5
POWER ............................................................................................................... 5
Auto-Restart: ................................................................................................. 5
Auto-Shut Off: ................................................................................................ 5
CONTINUOUS MODE ............................................................................................. 5
FAN SPEEDS ........................................................................................................ 5
SETTING THE HUMIDITY LEVEL .............................................................................. 5
LCD DISPLAY ...................................................................................................... 6
Error Codes ................................................................................................... 6
WATER FULL LIGHT .............................................................................................. 6
ADDITIONAL NOTES ABOUT THE DEHUMIDIFIER’S BEHAVIOR: .................................... 6
DRAINING THE UNIT ............................................................................................ 7
MANUAL DRAIN .................................................................................................... 7
CONTINUOUS DRAIN ............................................................................................. 7
MAINTENANCE .................................................................................................... 8
CLEANING THE UNIT ............................................................................................. 8
CLEANING THE PRE-FILTER ................................................................................... 8
CLEANING THE WATER BUCKET ............................................................................. 8
PREPARATION FOR STORAGE ............................................................................... 9
ENERGY SAVING GUIDE ..................................................................................... 9
TROUBLESHOOTING .......................................................................................... 9
TROUBLESHOOTING CONTINUED ......................................................................... 10
SPECIFICATIONS ............................................................................................... 11
EDGESTAR LIMITED WARRANTY ................................................................... 12
EdgeStar Portable Dehumidifier ii
Introduction
Thank you for purchasing this EdgeStar portable dehumidifier. We are glad you
chose us. We believe that your purchase of this product opens a relationship
between you and EdgeStar. We will provide the customer support needed to
nurture that relationship.
This manual contains important information regarding the proper installation, use
and maintenance of your portable dehumidifier. Following this manual will ensure
that your product will work at its peak performance and efficiency.
Your dehumidifier is designed to remove moisture in the air by condensation
removal and collecting the water in a removable bucket, or draining into a drain
hose that can be routed to a drain hole on the floor or condensate pump.
Please save the original product packaging in case you need to safely transport
your portable dehumidifier.
For Your Records:
Please write down the model number and serial number
below for future reference. Both numbers are located on the
ratings label on the back of your unit and are needed to
obtain warranty service. You may also want to staple your
receipt to this manual as it is the proof of your purchase, and
is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer service:
If you received a damaged product, immediately contact the dealer that
sold you the product.
Read and follow this instruction manual carefully to help you install, use
and maintain your portable dehumidifier.
Read the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
Register your product at http://www.edgestar.com and download
product guides, owner’s manuals, and access additional troubleshooting
resources.
If you need warranty service, our friendly customer service
representatives are available via email at service@edgestar.com or by
telephone at 1 (866) 319-5473.
1
Parts Identification
Front View
*Note: Some models
may not come with side
handles.
Control Panel
Handle*
Air Intake
Pre-filter
Water Bucket
Water Level Indicator
All the pictures in this manual are for reference only. Your unit may be
slightly different than the images depicted.
Back View
Exhaust
Drain hose outlet
Caster wheels
Power plug
EdgeStar Portable Dehumidifier 2
