Echo Smartpen Quick Manual

INK TIP

ANTI-ROLL DESIGN MICROPHONE

BUILT-IN SPEAKER OLED DISPLAY MICRO USB CONNECTOR

AUDIO JACKPOWER BUTTONREPLACEABLE

SMARTPEN HARDWARE

Processor ARM 9
Screen 96 x18 OLED display
Camera High speed infrared camera (>70 images/sec)
Storage 2GB NAND
(over 200 hours recording time)

1

Battery Rechargeable lithium (non-removable)
Record Smartpen embedded microphone ­ mono recording
Playback Embedded speaker
Standard 3.5 mm audio jack
PC Connectivity Micro USB cable (charging & data transfer)
Size & Weight Length: 158 mm (6.22 in.)
Width: 19.7 mm (0.78 in.) at top

11.5 mm (0.45 in.) at tip
Weight: 36 grams (1.3 oz.) no cap

BUNDLED SMARTPEN SOFTWARE

Paper Replay Record and replay synchronized

ink and audio

Paper Replay Password Prevent access to your recorded

audio
Notes Ink capture (without audio)
Quick Record Quick-access audio recording
Printed Calc Scientific calculator
Quick Calc Simple calculator that can be

used on any Livescribe dot paper
Other Utilities Multi-language support, Time,

Date, Storage, and Battery

LIVESCRIBE™ DESKTOP SOFTWARE

• Search, view and replay notes

• Export your notes and audio file

• Open and play back pencasts shared with you

• Print your own notebooks on qualified printers

• Available as free software download

MAC SYSTEM REQUIREMENTS

• Mac OS® X version 10.8 or later

• 300 MB of available disk space

• An available USB 2.0 port

• An internet connection

WINDOWS® SYSTEM REQUIREMENTS

• Windows 7, Windows 8, or later

• 300 MB of available disk space

• An available USB 2.0 port

• An internet connection

2

1
