Echo CLM-58V Operator's Manual
Operator’s Manual
Manuel d’utilisation
Manual del operador
58 Volt 21 in. Lawn Mower
Tondeuse de 21 po, 58 V
Podadora de 21 pulg., 58 V
CLM-58V
Batteries and Chargers Sold Separately
Piles et chargeur vendus séparément
Baterías y el cargador se venden por separado
Your lawn mower has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING
using this product.
Thank you for your purchase.
To reduce the risk of injury, the user must read and understand the operator’s manual before
SAVE THIS MANUAL FOR FUTURE REFERENCE
Ce tondeuse a été conçue et fabriquée conformément à nos strictes
normes de fiabilité, simplicité d’emploi et sécurité d’utilisation.
Correctement entretenue, elle vous donnera des années de
fonctionnement robuste et sans problème.
AVERTISSEMENT
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Merci de votre achat.
Pour réduire les risques de
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
Su podadora ha sido diseñada y fabricada de conformidad con las
estrictas normas para brindar fiabilidad, facilidad de uso y seguridad
para el operador. Con el debido cuidado, le brindará muchos años
de sólido y eficiente funcionamiento.
ADVERTENCIA
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
Para reducir el riesgo de lesiones,
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
See this fold-out section for all of the figures
referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes
les figures mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas
las figuras a las que se hace referencia en el manual del operador.
Fig. 1
C
D
B
F
L
I
H
A
I
E
G
I
A - Battery cover (couvercle des piles, tapa de las baterías)
B - Grass bag (collecteur d’herbe, receptor de hierba)
C - Start button (bouton « Start » [démarrer], botón de arranque)
D - Upper handle (poignée supérieure, mango superior)
E - Blade control lever (levier de commande de la lame, palanca de control
de la hoja)
F - Upper handle knob (bouton de la poignée supérieure, perilla del
mango superior)
J
K
G - Lower handle (poignée inférieure, mango inferior)
H - Handle adjustment knobs (boutons de réglage de la poignée, perillas
de ajuste del mango)
I - Height adjustment levers (leviers de réglage de la hauteur, palancas de
ajuste de altura)
J - Mulching plug (insert broyeur, tapón para trituración)
K - Start key (clé de démarrage, llave de arranque)
L - Handle adjustment holes (poignée trous de réglage, maneje orificios
de ajuste
ii
Fig. 2
A
B
A
A - Upper handle knob (bouton de la poignée supérieure, perilla del
mango superior)
A
B
A - Handle adjustment knob (bouton de réglage de la poignée, perilla de
ajuste del mango)
B - Angle holes (trou d’inclinaison, orificios angulados)
B - Starter cable (câble de démarreur, cable del arrancador)
Fig. 4Fig. 3
A
C
B
A - Rear discharge door (couvercle d’éjection arrière, puerta de descarga
posterior)
B - Rear discharge opening (ouverture d’éjection arrière, abertura de
descarga posterio)
C - Mulching plug (insert broyeur, tapón para trituración)
iii
Fig. 5
C
B
E
A
A - Grass bag handle (poignée de collecteur
d’herbe, mango del receptor de hierba)
B - Slots (fentes, ranuras)
C - Rear discharge door (couvercle d’éjection
arrière, puerta de descarga posterior)
D - Rear discharge opening (ouverture
d’éjection latérale, abertura de descarga
lateral)
E - Door rod (barre de couvercle, barra de la
puerta)
F - Hook (crochet, gancho)
Fig. 6
A
B
A - Slots (fentes, ranuras)
B - Hooks (crochets, ganchos)
Fig. 7
C
B
D
F
Fig. 8
Fig. 9
A
B
D
B
A
C
C
A - Start key (clé de démarrage, llave de
arranque)
B - Battery cover (couvercle des piles, tapa de
las baterías)
C - Start key slot (fente de la clé de démarrage,
ranura de la llave de arranque)
A
A - Height adjustment lever (levier de réglage
de la hauteur, palanca de ajuste de altura)
B - Lowest blade setting (le plus bas réglage
de la lame, ajuste más bajo de la hoja)
C - Highest blade setting (le plus haut réglage
de la lame, ajustes de cuchilla más alto)
A - Battery pack (bloc-piles, paquete de
baterías)
B - Battery cover (couvercle des piles, tapa de
las baterías)
C - Battery port (compartimiento de pile,
compartimiento de la batería)
D - Latch (loquet, pestillo)
iv
Fig. 10
C
B
A
A - Blade control lever (levier de commande
de la lame, palanca de control de la hoja)
B - Start button (bouton « Start » [démarrer],
botón de arranque)
C - Upper handle (poignée supérieure, mango
superior)
Fig. 11
Fig. 13
A
Fig. 15
Fig. 12
15° MAXIMUM
15° MAXIMAL
15° MÁXIMA
B
C
A - Blade (lame, hoja)
B - Wrench (clé, llave)
C - Block of wood (pièce de bois, bloque de
madera)
Fig. 14
A
G
A
F
H
F
B
Fig. 16
TO STORE THE MACHINE
POUR REMISER L’ÉQUIPEMENT
PARA GUARDAR LA MÁQUINA
Fig. 17
STORING THE MOWER
IN THE VERTICAL POSITION
RANGEMENT DU MOTEUR
EN POSITION VERTICALE
C
B
D
E
A - Shaft (arbre, eje)
B - Blade (lame, hoja)
C - Blade insulator (isolant de lame, aislante de
hoja)
D - Spacer (entretoise, separador)
E - Blade nut (écrou de lame, tuerca de la hoja)
F - Blade posts (tiges pour lame, montantes
de cuchilla)
G - Blade holder (porte-lame, porta hojas)
H - Motor shaft bushing (coussinet de l’arbre
moteur, buje del eje impulsor)
v
ALMACENAMIENTO DE LA PODADORA
EN POSICIÓN VERTICAL
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
Introduction ......................................................................................................................................................................2
Introduction / Introducción
Important Safety Instructions ........................................................................................................................................ 3-4
Instructions importantes concernant la securite / Instrucciones de seguidad importantes
Symbols .........................................................................................................................................................................5-6
Symboles / Símbolos
Features ............................................................................................................................................................................6
Caractéristiques / Características
Assembly .......................................................................................................................................................................7-8
Assemblage / Armado
Operation .......................................................................................................................................................................8-9
Utilisation / Funcionamiento
Maintenance ..............................................................................................................................................................10-11
Entretien / Mantenimiento
Troubleshooting .............................................................................................................................................................. 11
Dépannage / Corrección de problemas
Accessories .................................................................................................................................................................... 11
Accessoires / Accesorios
Warranty .........................................................................................................................................................................12
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
2 English
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS. Failure
to follow all instructions listed below and on the machine
may result in electric shock, fire, and/or serious personal
injury.
Read All Instructions
This cutting machine is capable of amputating hands and
feet and throwing objects. Failure to observe all safety
instructions could result in serious injury or death.
Avoid dangerous environment — Do not use the lawn
mower in damp or wet conditions or operate in the rain.
Keep children away — Keep all bystanders, children, and
pets at least 100 ft. away. Stop machine if anyone enters
the area.
Tragic accidents can occur if the operator is not alert to
the presence of children. Children are often attracted to
the machine and the mowing activity. Never assume that
children will remain where you last saw them.
• Keep children out of the mowing area and under the
watchful care of a responsible adult other than the
operator.
• Be alert and turn mower off if a child enters the area.
• Never allow children to operate the machine.
• Use extra care when approaching blind corners, shrubs,
trees, or other objects that may block your view of a
child.
Dress properly — Wear heavy, long pants, long sleeves,
gloves, and protective footwear that will protect your feet
and improve your footing on slippery surfaces. Do not
wear loose fitting clothing, short pants, sandals, or go
barefoot. Do not wear jewelry of any kind. They can be
caught in moving parts.
Don’t overreach — Keep proper footing and balance at
all times. Overreaching can result in loss of balance.
Do not leave the mower unattended while running or with
the start key installed.
Keep hands and feet away from cutting area. Keep clear
of the discharge opening at all times.
Operate the lawn mower only in daylight or good artificial
light.
Use safety glasses — Always wear eye protection with
side shields marked to comply with ANSI Z87.1. Use face
mask if operation is dusty.
Use the right appliance — Do not use the lawn mower
for any job except that for which it is intended.
Do not force the lawn mower — It will do the job better
and safer at the rate for which it was designed.
Do not charge lawn mower in rain, or in wet locations.
Stay alert — Watch what you are doing and use common
sense when operating the lawn mower. Do not operate
the mower while tired, upset or under the influence of
drugs, alcohol, or medication. A moment of inattention
while operating the lawn mower may result in serious
personal injury.
Maintain lawn mower with care — Keep machine in good
working condition. Keep handles dry, clean and free from
oil and grease. Keep blades sharp and guards in place
and in working order. Replace damaged or unevenly worn
blades before using mower for best performance.
Check all nuts, bolts, and screws at frequent intervals
for proper tightness to be sure the equipment is in safe
working condition. Mower blades are sharp. Wrap the
blade or wear gloves, and use extra caution when servicing
them.
Do not dispose of the battery in a fire. The cell may
explode. Check with local codes for possible special
disposal instructions.
Stop the motor, wait until the blade comes to a complete
stop, and remove the start key and battery pack before
cleaning the lawn mower, removing the grass bag, or
removing the mulching plug.
Replace blade if it is bent or cracked. An unbalanced
blade causes vibration that could damage the motor
drive unit or cause personal injury. Sharpen a dull blade
equally at each end to maintain the balance. Clean the
blade thoroughly and check its balance by supporting
it horizontally on a thin nail through its center hole. The
nail should be in a horizontal position. If either end of
the blade rotates downward, remove some metal from
the heavy or lower end until the blade is balanced. It is
balanced when neither end drops.
Always use safety protective devices. Do not operate the
mower without the entire grass bag, mulching plug and
rear discharge door in place and working properly.
Do not open or mutilate the battery. Released electrolyte
is corrosive and may cause damage to the eyes or skin.
It may be toxic if swallowed.
Follow manufacturer’s instructions for proper operation
and installation of accessories. Only use accessories
approved by the manufacturer.
Exercise care in handling batteries in order not to short the
battery with conducting materials such as rings, bracelets,
and keys. The battery or conductor may overheat and
cause burns.
Clear the work area before each use. Remove all objects
such as rocks, sticks, metal, wire, bones, toys, or other
objects which can be thrown by the blade. Stay behind
the handle when the motor is running.
Avoid holes, ruts, bumps, rocks, property stakes, or other
hidden objects. Uneven terrain could cause a slip and fall
accident.
English 3
IMPORTANT SAFETY INSTRUCTIONS
Do not mow near drop-offs, ditches, or embankments.
Mow across the face of slopes, never up and down.
Exercise extreme caution when changing direction on
slopes.
Plan your mowing pattern to avoid discharge of material
toward roads, sidewalks, bystanders and the like. Also,
avoid discharging material against a wall or obstruction,
which may cause the material to ricochet back toward
the operator.
Do not mow on wet grass or excessively steep slopes.
Poor footing could cause a slip and fall accident. Walk,
never run.
Use extra care when approaching blind corners, shrubs,
trees, or other objects that may block your view.
Do not pull the mower backward unless absolutely
necessary. If you must back the mower away from a
wall or obstruction, first look down and behind to avoid
tripping or pulling the mower over your feet.
Never direct discharged material toward anyone. Avoid
discharging material against a wall or obstruction. Material
may ricochet back toward the operator. Stop the blade
when crossing gravel surfaces.
Objects struck by the lawn mower blade can cause severe
injuries to persons. The lawn should always be carefully
examined and cleared of all objects prior to each mowing.
If the lawn mower strikes a foreign object, follow these
steps:
• Stop the lawn mower by releasing the blade control
lever, wait until the blade comes to a complete stop,
and then remove start key and battery.
• Thoroughly inspect the mower for any damage.
• Replace the blade if it is damaged in any way. Repair
any damage before restarting and continuing to operate
the mower.
Stop the motor, wait until the blade comes to a complete
stop, and remove start key and battery before unclogging
the chute. The cutting blade continues to rotate for a few
seconds after the motor is shut off. Never place any part
of the body in the blade area until you are sure the blade
has stopped rotating.
If the mower should start to vibrate abnormally, stop the
motor and check immediately for the cause. Replace
the blade if it is unevenly worn or damaged in any way.
Vibration is generally a warning of trouble.
Service on the product must be performed by qualified
repair personnel only. Service or maintenance performed
by unqualified personnel could result in injury to the user
or damage to the product.
The grass bag assembly is subject to deterioration and
wear and should be checked each time the mower is
used. If replacement is needed, make sure the new grass
bag meets original manufacturer’s recommendations and
specifications.
Use only authorized replacement parts when servicing
the product. Use identical replacement blades only. Use
of unauthorized parts may create a risk of serious injury
to the user, or damage to the product.
Maintain or replace safety instructions labels, as necessary.
Disconnect battery — Disconnect battery pack from
the appliance before storing, servicing, transporting, or
changing accessories such as blades. Such preventive
safety measures reduce the risk of starting the tool
accidentally.
Stop the unit and disconnect battery pack and start key
when not in use. Carry or push the unit with the motor
stopped and the start key and battery pack removed from
the mower.
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery
tool or when changing accessories. Following this rule will
reduce the risk of electric shock, fire, or serious personal
injury.
Do not use battery-operated appliance in rain.
Remove or disconnect battery before servicing, cleaning
or removing material from the gardening appliance.
For use with ECHO 58 V lithium-ion battery packs. See Tool/
Appliance/Battery Pack/Charger Correlation Supplement
991000233.
Store idle lawn mower indoors — When not in use, mower
should be stored indoors in a dry, locked place out of the
reach of children. The start key should also be removed
and stored in a separate location out of the reach of
children.
Follow instructions for lubricating and changing
accessories.
Only allow responsible adults, who are familiar with the
instructions, to operate this machine.
Never operate machine in a closed area.
Never tamper with safety devices. Check for proper
operation regularly.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this product. If
you loan someone this tool, loan them these instructions
also.
4 English
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
Symbol Signal Meaning
DANGER:
WARNING:
CAUTION:
NOTICE:
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
(Without Safety Alert Symbol) Indicates important information not related to an
injury hazard, such as a situation that may result in property damage.
Symbol Name Designation/Explanation
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s
Manual
Eye Protection
To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Electric Shock
Keep Hands and Feet
Away
No Reach Do not reach hands or feet under mower deck.
No Slope
Keep Children and
Bystanders Away
Ricochet
Failure to use in dry conditions and to observe safe practices can
result in electric shock.
Keep hands and feet away from blade and cutting area.
Do not operate on inclines greater than 15º. Mow across the face of
slopes, never up and down.
Keep all children and bystanders at least 100 ft. away.
Thrown objects can ricochet and result in personal injury or property
damage.
English 5
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Symbol Name Designation/Explanation
This product uses lithium-ion (Li-ion) batteries. Local, state, or federal
Recycle Symbol
Direct Current Type or a characteristic of current
n
o
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
V Volts Voltage
Hz Hertz Frequency (cycles per second)
min Minutes Time
No Load Speed Rotational speed, at no load
laws may prohibit disposal of batteries in ordinary trash. Consult your
local waste authority for information regarding available recycling and/
or disposal options.
FEATURES
Product Specifications
Motor ...................................................................................................................................................................... 58 Volt DC
Cutting Path ....................................................................................................................................................................21 in.
Height Adjustments ............................................................................................................................................3/4 in. to 4 in.
Wheel Size .........................................................................................................................................................................9 in.
Know Your Lawn Mower
See Figure 1.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
Battery Cover
The battery cover protects the battery port from moisture
and debris.
Grass Bag
The grass bag collects grass clippings and prevents them
from being discharged across your lawn as you mow.
Height Adjustment Levers
Use the wheel height adjustment levers to adjust the cutting
height.
Mulching Plug
Your mower is equipped with a mulching plug that covers
the rear discharge opening, which allows the mower blade
to cut and recut for finer clippings.
Brushless Motor
This product features a brushless motor that maximizes
power and performance as well as battery run time.
Start Button and Blade Control Lever
The start button and blade control lever, located on the upper
handle, are used to start the mower.
Dual Battery Ports
This product features dual battery ports to minimize down
time during operation. To switch from one battery to the
other, simply reverse the arrow direction on the selector key.
Start Key
The start key must be inserted before the mower can be
started.
6 English
ASSEMBLY
Unpacking
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-877-396-3036 for assistance.
Packing List
Lawn Mower
Start Key
Mulching Plug
Grass Bag
Safety Glasses
Operator’s Manual
WARNING
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
WARNING
Do not insert start key or battery pack until assembly is
complete and you are ready to mow. Failure to comply
could result in accidental starting and possible serious
personal injury.
WARNING
To prevent accidental starting, do not make any
adjustments or installations with the start key or battery
pack inserted. Accidental starting of the mower during
assembly could result in serious personal injury.
WARNING
Never operate the mower without the proper safety
devices in place and working. Never operate the mower
with damaged safety devices. Operating the mower with
missing or damaged parts can result in serious personal
injury.
Unfolding and Adjusting Handle Assembly
See Figures 2 - 3.
Fully loosen the upper handle knobs on both sides of the
handle.
Pull up and back on the upper handle to raise the handle
into operating position.
NOTICE
Do not allow the starter cable to become pinched or
trapped when raising the handles.
Tighten the handle knobs on both sides of the handle to
secure.
Pull the handle adjustment knobs out and rotate 90
degrees.
Rotate the handle to the desired position.
Rotate the knob 90 degrees again to secure handle in
place.
NOTE: The handle must be in one of the three handle angle
hole positions or the unit will not operate.
Installing the Mulching Plug
(For Mulching Operation)
See Figure 4.
NOTE: When using the mulching plug, do not install the
grass bag.
Remove start key and battery pack.
Lift and hold the rear discharge door.
Grasp the mulching plug by its handle and insert it at a
slight angle, as shown.
Push the mulching plug securely into place.
Lower the rear discharge door.
Reinstall start key and battery pack when you are ready
to mow.
English 7
ASSEMBLY
Installing the Grass Bag
(For Rear Bagging Operation)
See Figures 5 - 6.
NOTE: When using the grass bag, do not install the mulching
plug.
Remove start key and battery pack.
Lift the rear discharge door.
Lift the grass bag by its handle and place under the rear
discharge door so that the hooks on the grass bag are
seated onto the slots on the mower housing.
Release the rear discharge door.
Reinstall start key and battery pack when you are ready
to mow.
OPERATION
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING
Setting Blade Height
See Figure 7.
When shipped, the wheels on the mower are set to a
low- cutting position. Before using the mower for the first
time, raise the cutting position to the height best suited for
your lawn. The average lawn should be between 1-1/2 in.
to 2 in. during cool months and between 2 in. and 3-1/4 in.
during hot months.
To adjust the blade height:
Remove start key and battery pack.
Adjust each wheel to achieve the desired blade height.
NOTE: Moving the height adjustment levers toward the
inside of the cutting deck lowers the blade height, and
moving the levers toward the outside raises the blade
height.
Reinstall start key and battery pack when you are ready
to mow.
NOTE: This product features dual battery ports to help
minimize down time during operation. The mower may
be operated with one 58 V battery pack installed in either
battery port, or you can install a battery in each port and
simply reverse the direction of the arrow on the start key to
switch to the second battery when the first battery’s charge
is depleted.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING
Always inspect mower for missing or damaged parts
and blade for damage, uneven, or excessive wear prior
to use. Use of the mower with damaged or missing parts
can result in serious personal injury.
This product will accept ECHO 58 V lithium-ion battery
packs only.
For complete charging instructions, refer to the Operator’s
Manuals for your ECHO battery pack and charger models.
Applications
You may use this product for the purpose listed below:
Mowing your lawn
WARNING
Always remove battery pack and remove the start key
from the tool when you are assembling parts, making
adjustments, cleaning, or when not in use. This will
prevent accidental starting that could cause serious
personal injury.
Installing/Removing Battery Pack
See Figure 8.
To install battery pack:
Raise the battery cover.
Align grooves on battery pack with raised ribs in the tool’s
battery port and place the battery pack in the tool.
WARNING
Make sure the latch on the tool snaps in place and the
battery pack is fully seated and secure in the battery port
before beginning operation. Failure to securely seat the
battery pack could cause the battery pack to fall out,
resulting in serious personal injury.
Lower the battery cover.
8 English
Loading...
