Dyson DC15 User Manual

The Ball

Owner’s Manual

Please read this manual carefully before using your DC15

Owners manual

Please read this manual carefully before using your DC15.

Important safety instructions

1 Assembling 2 Using your DC15 3 Using your DC15 (continued) 4 Using your DC15 tools

5 Washing your filter 6 Emptying the clear bin

7 Cleaning the clear bin

8 Clearing blockages 9 Using and maintaining optional accessories

10 Using and maintaining optional accessories (continued)

11 Troubleshooting tips

Warranty and customer care

Power On/Off

Carry handle

Shroud

Wand cap

Wand release button

Wand

Hose release button

Clear bin

Airway inspection valve

Brushbar On/Off

Cyclone

Stabilizer

Hose

1 Assembling

Slide wand down inside hose until it clicks.

Slot wand into top of machine and click into place.

Wind cord counter-clockwise and secure with clip.

Click tools into place.

IMPORTANT

• Ensure hose is straight when inserting wand.

• Please see section 9 for usage and maintenance instructions for accessories included with some vacuums.

• If you have any questions, please call the Dyson Helpline toll free at 1-877-397-6622 or log onto www.dyson.com

Brush tool

Crevice tool

Stair tool

tip To quickly release cord,

twist upper cord winder downwards. Twist back up before re-winding cord.

Carrying your DC15

Ensure machine is upright before carrying.

Use the carry handle at the top of the cyclone to lift.

Using your DC15

Plug in and press transparent yellow ON/OFF switch.

Press stabilizer firmly to release cleaner head and pull handle towards you.

Use stabilizer only – do not stand directly on cleaner head to release vacuum.

tip Do not apply weight to handle

while pressing stabilizer.

Ensure stabilizer wheels are fully retracted and click in place or brushbar will not operate.

CAUTION

• Please note: this machine is intended for domestic use only. Fine dust such as plaster dust or flour should only be vacuumed in very small amounts.

• The brushbar will automatically stop if it becomes obstructed.

• Do not press the cyclone release button while carrying the machine or it could fall and cause injury.

• Ensure the cyclone is secured to the machine.

• Do not shake the machine while carrying or it could fall and cause injury.

2 Using your DC15

3 Using your DC15

(continued)

Brush control

To turn the brushbar OFF for bare or delicate flooring, rugs, and carpets, put the machine in the cleaning position, and press the red button. Press it again to restart brushbar.

tip Ensure the stabilizer clicks into

place before vacuuming.

Small movements of the wrist will create a zigzag motion in the cleaner head for easier cleaning around furniture.

tip Twist and turn your wrist like you are turning a doorknob to make the

most of DC15’s maneuverability.

When finished, push the handle firmly beyond the upright position to drop the stabilizing wheels.

Ensure stabilizer wheels are fully locked in place before releasing the machine.

IMPORTANT

• The brushbar will reset to “ON” each time you start the machine and put it in the cleaning position.

• If the brushbar stops during use, please refer to the clearing blockages section.

• Ensure stabilizer wheels are fully locked in place before releasing the machine.

• Consult your flooring manufacturer’s recommended instructions before vacuuming your flooring, rugs, and carpets. Some carpets will fuzz if a rotating brushbar is used when vacuuming. If this happens we recommend vacuuming in bare floors mode and consulting with your flooring manufacturer.
