Dynex DX-CR112 User Manual

6-in-1 Memory Card Reader

DX-CR112

USER GUIDE

2

Dynex 6-in-1 Memory Card Reader

DX-CR112

Contents

Introduction.............................................................. 2

Features.................................................................... 2

Important safety instructions ................................... 3

Card reader components........................................... 3

Card slots.................................................................. 4

Using your card reader.............................................. 5

Troubleshooting........................................................ 7

Specifications............................................................ 8

Legal notices............................................................. 8

One-year limited warranty ....................................... 9

DX-CR112

Introduction

This Card Reader directly accepts standard media memory cards, such as Secure Digital (SD,
SDHC, and SDCX) and Multi Media Card (MMC and MMCplus). It also accepts microSDHC and
microSD cards without the need for adapters.

This Card Reader also provides incredibly fast read/write speeds when paired with Secure
Digital High Capacity (SDHC) cards, letting you minimize the time you spend transferring files
from and writing files to memory cards.

Features

• Provides two media card slots supporting most popular memory cards including SDHC
high speed memory cards

• USB 2.0 compliant

• USB mass storage device class compliant

• Supports MMC, SDHC (SD 2.0), microSDHC, and microSD cards

• Hot swappable and Plug & Play capability

6-in-1 Memory Card Reader

Important safety instructions

Before getting started, read these instructions and save them for later reference.

• Before you plug your card reader into your computer, read this user guide. In some
operating systems, the driver must be installed before you install your card reader.

• Do not drop or hit your card reader.

• Do not install your card reader in a location that is subject to strong vibrations.

• Do not disassemble or try to modify your card reader. Disassembly or modification may
void your warranty and could damage your card reader leading to a fire or electric
shock.

• Do not store your card reader in a damp location. Do not allow moisture or liquids to
drip into your card reader. Liquids can damage your card reader leading to a fire or
electric shock.

• Do not insert metal objects, such as coins or paper clips, into your card reader.

• Do not remove a card when the LED indicator shows data activity is in progress. You
may damage the card or lose data stored on the card.

Card reader components

Package contents

3

•6-in-1 Memory Card Reader

•Quick Setup Guide*

*Note: For further assistance, go to www.dynexproducts.com.

Minimum system requirements

• IBM-compatible PC or a Macintosh computer

•USB port

• Pentium 133 MHz or higher processor

• 2 MB of hard drive space

• Windows® XP, Windows® Vista, Windows® 7, or Mac OS 10.4.x or higher

Note: Some memory cards, such as the SDXC, are not compatible with Windows XP. Refer to

your card manufacturer to see if your card is compatible with your OS.

4

Card slots

This diagram shows the correct slots for the different types of media cards supported. Refer
to the following section for additional details.

Note: Cards must be inserted
into the microSD slot must be
inserted with the label facing
DOWN.

SD/SDHC/
SDXC/MMC

(Insert with
label facing
UP)

DX-CR112

Media

#

Card Slot

1microSD/

microSDHC

2SD/SDHC/

SDXC/MMC

microSD,
microSDHC

Card Image Details

Data LED

Insert a microSDHC or microSD card into this slot.
No adapter is required.
Note: Insert cards into this slot with the label
facing DOWN.

Inser t a Secure Digital card (SD, SDHC, SDXC, and
mini SD) or a MultiMediaCard (MMC, MMCplus,
and RS-MMC) into this slot.
Notes:

• A memory card adapter is required for
mini SD and RS-MMC cards.

• Insert cards into this slot with the label facing
UP.
