Dynex DX-60D260A13 User Manual

60” LED TV

DX-60D260A13

USER GUIDE

Before using your new product, please read these instructions to prevent any damage.

Dynex DX-60D260A13

60” LED TV

Contents

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

120Hz screen refresh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a home theater system with multiple devices . . . . . . . . . . . . . . . . . 18

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using the on-screen menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

System Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

iii

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Turning INlink on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Turning Device Auto Power Off on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Turning TV Auto Power On on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Displaying a list of INlink-compatible (HDMI-CEC) devices . . . . . . . . . . . . . . . . . 36

Restoring settings to default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Viewing your favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . . 43

Programming a different universal remote control . . . . . . . . . . . . . . . . . . . . . . . . 43

For additional help and information… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

One-year limited warranty - Dynex Televisions . . . . . . . . . . . . . . . . . . . 45

Definitions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

How long does the coverage last? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

What does this warranty cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

How to obtain warranty service? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Where is the warranty valid? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

What does the warranty not cover? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

The issue

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

The home theater entertainment experience is a growing trend, and larger TVs are popular purchases. However, TVs are not always supported on the proper stands or installed according to the manufacturer’s recommendations. We and the consumer electronics industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause injury.

As you enjoy your new product, keep these

safety tips in mind

Tune into safety

• One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

• Carefully read and understand all enclosed instructions for

proper use of this product.

• Don’t let children climb on or play with entertainment system

furniture and TVs.

• Don’t place TVs on furniture that can easily be used as

steps, such as a crate or chest of drawers.

• Remember that children can become excited while watching

a program, especially on a “larger-than-life” TV. Make sure that you place or install the TV where it cannot be pushed, pulled over, or knocked down.

• Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

• One size of wall mount does not fit all. Use only a wall mount rated for the weight of your

TV and that has been recommended by this TV manufacturer, listed in this manual, or otherwise listed by an independent laboratory as suitable for your TV.

• Follow all instructions supplied by the TV and wall mount manufacturers.

• If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

• Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be mounted to walls backed with steel studs or cinder blocks. If you are unsure, ask a professional installer.

• TVs can be heavy. At least two people are required for safe wall mount installation.

Important Safety InstructionsDX-60D260A13

Important Safety Instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your TV. This label is located on the back of your TV.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your TV.

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with dry cloth. 7 Do not block any ventilation openings. Install in accordance

with the manufacturer's instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when

unused for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15 The wall plug is the disconnecting device. The plug must

remain readily operable.

16 An apparatus with a three-prong, grounding-type plug is a

Class I apparatus which needs to be grounded to prevent possible electric shock. Make sure that you connect the Class I apparatus to a grounding-type, three-prong outlet.

17 Remote control batteries should not be exposed to

excessive heat such as sunshine, fire, or the like.

18 The apparatus should not be exposed to dripping or

splashing and no objects filled with liquids, such as vases, should be placed on the apparatus.

Warning

Electric shock hazard

To reduce the risk of fire or electric shock, do not remove any cover or expose the device to rain or moisture. No user-serviceable parts are inside. Refer servicing to qualified service technicians.

Lightning

For added protection for your device receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the power outlet and disconnect any antenna or cable system. This helps prevent property damage and personal injury from lightning and power line surges.

Power lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop your TV or hit, jolt, or press hard against the LCD panel. If the screen breaks, be careful of broken glass.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation.

• If the liquid gets in your mouth, immediately gargle, rinse, and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure that the service technician uses replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, personal injury, or other hazards.

Safety check

After completing any service or repair to this device, ask the service technician to perform routine safety checks to determine that your TV is in correct operating condition.

Power source

Operate your TV only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult an electrician or your local power company.

Servicing

These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.

Important Safety Instructions

1234567

DX-60D260A13

Caution

Damage requiring service

Unplug this TV from the power outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions because incorrect adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore your TV to its normal operation.

• If your TV has been dropped or damaged in any way.

• When your TV exhibits a distinct change in performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected to your TV, make sure that the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to correct grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of the antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Condensation

Moisture will form on the TV if the TV is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, the TV's performance may be impaired. To prevent this, let the TV stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the TV is exposed to the breeze from an air conditioner. In such cases, change the location of the TV.

Mobile telephone warning

To avoid interference with your TV picture and sound, operating problems, or even damage, keep your cordless and cellular telephones away from the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated for environmental reasons. Your TV also contains material that can be recycled and reused. For disposal or recycling information, contact your local authorities to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film transistors, which provide exceptionally sharp video quality. Occasionally, a few non-active pixels may appear on the screen as a fixed blue, green, or red point. These non-active pixels do not adversely affect the performance of your TV, and are not considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

Note to CATV system installer

Article 820 of the National Electrical Code, ANSI/NFPA No. 40 provides guidance for correct grounding. Specifically, it states that the cable ground must be connected to the grounding system of the building as close to the point of cable entry as practical.

IntroductionDX-60D260A13

Introduction

Congratulations on your purchase of a high-quality Dynex product. Your DX-60D260A13 represents the state of the art in LED TV design and is designed for reliable and trouble-free performance.

INlink

Enjoy the benefit of having HDMI CEC compatible products plug and play! No setup is needed! CEC technology lets different components discover and communicate with each other. (See page 34 instructions on how to use INlink.)

for

120Hz screen refresh

With a 120 Hz screen refresh rate twice the rate of a 60 Hz screen, a screen with 1,080 lines of resolution (up from 720 lines in the last generation of HDTVs), and special motion-detection technology, you will experience a picture with clearer detail and brightness, smoother transitions, and reduced motion blurring, particularly when watching fast-motion sports and action scenes. (See page 22 adjust the TV picture.)

for instructions on how to

Installing the stand or wall-mount bracket

15.75 in. (400 mm)

Wall-mount brackets

DX-60D260A13

Installing the stand or wall-mount bracket

Notes

• If you plan to wall-mount your TV, do not install the stand.

• Store the stand and stand screws in case you decide to use the stand in the future.

Installing the stand

To install the stand:

1 Carefully place your TV face-down on a cushioned,

clean surface to protect the screen from damages and scratches.

2 Secure the stand column to the stand with the four

M4 (20 mm) screws provided.

Screw type Screw length # of screws

M4 20 mm 4

3 Attach the stand assembly to the TV using the six M4

(16 mm) screws provided.

Screw type Screw length # of screws

M4 16 mm 6

Installing a wall-mount bracket

Warnin g

This TV is intended to be supported by a UL Listed wall mount bracket with suitable weight/load. (See “Miscellaneous

To attach your TV to a wall-mount bracket:

1 Carefully place your TV face-down on a cushioned,

clean surface to protect the screen from damages and scratches.

2 Attach the wall-mount bracket to your TV using the

mounting holes on the back of your TV. See the instructions that came with the wall-mount bracket for information about how to correctly hang your TV.

Note

• The length of the wall-mount screws vary depending on the wall-mount bracket you purchased. See the instructions that came with the wall-mount bracket for screw lengths.

• The mounting holes on the back of your TV take type M6 screws.

” on page 42.)

TV components

Package contents

• Remote control and batteries (2 AAA)

•TV stand

• M4 type (20 mm length) (4 pcs) to connect the stand column to the stand base.

• M4 type (16 mm length) (6 pcs) to connect the stand column to the TV.

•Stand column

• QUICK SETUP GUIDE

•IMPORTANT INFORMATION

12345

123

456

Front Side

TV componentsDX-60D260A13

# Item Description

Turns off when your TV is on.

Power indicator

Remote control sensor

INPUT

VOL+/VOL–

/CH

(power)

Lights red when your TV is off (standby mode).

Receives signals from the remote control. Do not block.

Press to open the on-screen menu. For more information, see “Selecting a channel page 21.

Press to open the INPUT SOURCE list, press

or to select the video input source, then press INPUT again. For more information, see “Selecting the video input

source” on page 20.

In menu mode, press to confirm selections.

Press to increase or decrease the volume.

Press to go to the next or previous channel in the channel list. For more information, see “Selecting a channel” on page 21.

Press to turn your TV on or off (standby mode). Warn ing: When your TV is off, power still flows through it. To completely disconnect power, unplug the power cord.

” on

# Item Description

ANT CABLE IN

DIGITAL OUTPUT (optical)

AV IN AUDIO L/R

COMPONENT IN VIDEO/Y, P OR AV IN V IDE O/Y

AUDIO OUT

PC IN VGA

PC IN PC/DVI AUDIO IN

B, PR

Connect an antenna or cable TV to this jack. For more information, see “Using

coaxial cable (good)” on page 11.

Connect a digital audio amplifier or home theater system to this jack to listen to TV audio through the amplifier speakers. For more information, see “Using digital

audio” on page 17.

Connect the audio for a component video device to these jacks. For more information, see “Using component video

(better)” on page 10.

OR Connect the audio for a composite video

device to these jacks. For more information, see “Using composite video

(good)” on page 11.

The COMPONENT IN VIDEO/Y jack works as the component video jack or as a composite video jack.

Connect the video for a component video device to these jacks. For more information, see “Using component video

(better)” on page 10.

OR Connect the video for a composite video

device to the VIDEO/Y jack. For more information, “see “Using composite video

(good)” on page 11.

Connect headphones, an analog audio amplifier, a home theater system, or a sound bar to this jack. For more information, see “Using analog audio page 18.

Connect the video (VGA) for a computer to this jack. For more information, see “Using VGA” on page 15.

Connect the audio for a computer to this jack. For more information see “Using

VGA” on page 15.

OR Connect the audio for a DVI device to this

jack. For more information see, “Using DVI

(same as HDMI but requires an audio connection)” on pages 10.

” on

TV components

891

34567891011121314151617181920212223

DX-60D260A13

# Item Description

Connect HDMI devices to these jacks. For more information, see “Using HDMI

(best)” on page 9.

HDMI1/DVI HDMI2/ARC HDMI3

USB

If you are connecting a DVI device, connect the video for a DVI device to the HDMI1/DVI. For more information, see “Using DVI (same as HDMI but requires an

audio connection)” on pages 10.

If you are connecting a home theater system, we recommend that you connect it to the HDMI2/ARC jack.

Connect a USB flash drive to this jack to view compatible JPEG picture files. For more information, see “Connecting a USB

flash drive” on page 16 and “Using a USB flash drive” on page 36.

Remote control

# Button Description

Press to turn your TV on or off (Standby

(Power)

Video Input

mode). WAR NIN G: When your TV is off, power still flows into it. To disconnect power, unplug the power cord.

Press to select the input source.

•Press TV to select TV.

•Press HDMI one or more times to select the device connected to the HDMI1/DVI, HDMI2/ARC, or HDMI3 jack.

•Press VIDEO to select the device connected to the AV or Component IN jacks.

• ACC has no function.

# Button Description

Numbers

. (Dot)

ENTER Press to confirm selections or changes.

MENU Press to open the on-screen menu.

EXIT Press to close the on-screen menu.

INPUT

CH-LIST Press to open the channel list. Hidden

VOL+/VOL– Press to increase or decrease the volume.

SLEEP

ZOOM

Media control

(recall)

   

Home Press to open the on-screen menu.

INFO

CCD

FAV OR I TE

MUTE

CH /CH


MTS/SAP

AUDIO

Press to enter channel numbers and the parental control password.

Press to enter a digital sub-channel number. For more information, see “Selecting a

channel” on page 21.

Press to open the INPUT SOURCE list, then press

 or  to select a video input source.

For more information, see “Selecting the

video input source” on page 20.

channels are grayed and cannot be selected. See “Hiding channels” on page 25.

Press to set the sleep timer. For more information, see “Setting the sleep timer page 33.

Press to select the aspect ratio. For more information, see “Adjusting the TV picture on page 22.

Press these buttons to control playback from an HDMI-CEC compatible device. For more information, see “Displaying a list of

INlink-compatible (HDMI-CEC) devices” on

page 36.

Press to go to the last viewed channel. In USB mode, press to return to a higher level folder.

Press to navigate through the on-screen menus and adjust settings.

Press to display TV status information, such as the channel number, channel name (if available), or signal source. For more information, see “Viewing channel

information” on page 21.

Press to turn closed captioning on or off. You can select CC On, CC Off, or CC On When Mute. For more information, see “Tur ning

closed captioning on or off” on page 30.

Press to open the Favo rite s channel list. For more information, see “Setting up a favorite

channel list” on page 25 and “Viewing a favorite channel” on page 26.

Press to mute the sound. Press again to restore the sound.

Press to go to the next or previous channel in the channel list. For more information, see “Selecting a channel

Press to select the picture mode. You can select Vivid, Standard, Energy Savings, or Custom. For more information, see “Adjusting the TV picture

In analog TV mode, press to select Stereo, Mono, or SAP. In digital TV mode , press to select an alternate audio language, if available. For more information, see “Adjusting sound settings

Press to select the sound mode. for more information, see “Adjusting the sound” on page 23.

” on page 21.

” on page 22.

” on page 23.

” on

”

Making connectionsDX-60D260A13

Making connections

What connection should I use?

Your TV has several connection types for connecting devices to your TV. For the best video quality, you should connect a device to the best available connection.

Use the following tables to identify cables:

Connection

type and jack

HDMI

video/audio

Component

video (requires

an audio

connection)

Video

quality

Best (use this

if your

devices have

HDMI)

Better than composite,

or coaxial

Cable connector

Connection

type and jack

Digital optical

audio

Analog audio

VGA

(computer)

video and

audio

Cable connectors

Composite

video (requires

an audio

connection)

Coaxial

video/audio

Better than

coaxial

Good

You c an use the HDMI1/DVI jack on your TV to connect a DVI device to your TV. You need to attach an HDMI-to-DVI adapter to the end of the HDMI cable that connects to the DVI device.

Cautions

• Check the jacks for position and type before making any connections.

• Loose connections can result in image or color problems. Make sure that all connections are tight and secure.

• The external audio/video equipment shown may be different from your equipment. If you have questions, refer to the documentation that came with your equipment.

• Always unplug the power cord when connecting external equipment.

Making connections

Side of TV

HDMI cable

Cable or satellite box

DX-60D260A13

Connecting power

To connect the power:

• Plug the AC power cord into an AC power outlet.

Notes

• Your TV should only be operated from the power source indicated on the label.

• Always unplug the AC power cord from the power outlet when you will not be using your TV for an extended period of time.

Connecting a cable or satellite box

Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available. For more information, see “What connection should I use?

Notes

• If the signal level for a channel is weak, the picture may be distorted. Adjust the antenna or use a highly directional outdoor or set-top antenna with a built-in amplifier.

• If the picture quality is good on some channels and poor on others, the problem may be caused by a poor or weak signal from the broadcaster or cable TV provider.

• If you connect to cable or satellite TV without a set-top box and experience poor picture quality, you may need to install a set-top box to improve signal reception and picture quality. Contact your cable or satellite TV provider about upgrading to a set-top box.

• Many high-definition (HD) channels upscale standard-definition (SD) content. The picture displayed on your TV is still displayed as SD, thus the picture quality will not be as clear or crisp as it would be if the content was originally recorded in HD.

Using HDMI (best)

To connect a cable or satellite box using HDMI:

1 Make sure that your TV’s power cord is unplugged,

and all connected equipment is turned off.

2 Connect the incoming cable from the cable wall jack

to the cable-in jack on the cable or satellite box.

3 Connect an HDMI cable (not provided) to the HDMI

jack on the side of your TV and to the HDMI OUT jack on the cable or satellite box.

” on page 8.

4 Plug your TV’s power cord into a power outlet, turn

on your TV, then turn on the cable or satellite box.

5 Press INPUT to open the INPUT SOURCE list. 6 Press  or  to highlight HDMI 1, HDMI 2, or

HDMI 3 then press ENTER.

Note

An HDMI cable carries both audio and video. You do not need to use any audio cables.

HDMI cable with HDMI-DVI adapter

3.5 mm audio cable

Cable or satellite box

Side of TV

Compon ent vide o cable

Audio cable

Cable or satellite box

Cables are often color-coded to match color-coded jacks.

Making connectionsDX-60D260A13

Using DVI (same as HDMI but requires an audio connection)

Note

You must use the HDMI1/DVI jack to connect a cable or satellite box using DVI. If you use another HDMI jack, you will not hear sound from the TV speakers.

To connect a cable or satellite box using DVI:

1 Make sure that your TV’s power cord is unplugged,

and all connected equipment is turned off.

2 Connect the incoming cable from the cable wall jack

to the cable-in jack on the cable or satellite box.

3 Connect an HDMI-DVI adapter (not provided) to one

end of an HDMI cable (not provided), then connect the adapter to the DVI OUT jack on the cable or satellite box.

4 Connect the other end of the cable to the

HDMI1/DVI jack on the side of your TV.

Using component video (better)

To connect a cable or satellite box using component video:

1 Make sure that your TV’s power cord is unplugged,

and all connected equipment is turned off.

2 Connect the incoming cable from the cable wall jack

to the cable-in jack on the cable or satellite box.

3 Connect a component video cable (not provided) to

the VIDEO/Y, P your TV and the component video out jacks on the cable or satellite box.

B, and PR video jacks on the side of

5 Connect a 3.5mm audio cable (not provided) to the

PC/DVI AUDIO IN jack on the side of your TV and to the AUDIO OUT jacks on the cable or satellite box.

Note

When you connect the audio using the PC/DVI AUDIO IN jack, the audio output is analog.

6 Plug your TV’s power cord into a power outlet, turn

on your TV, then turn on the cable or satellite box.

7 Press INPUT to open the INPUT SOURCE list. 8 Press  or  to highlight HDMI 1, then press ENTER.

4 Connect an audio cable (not provided) to the

AV I N A UDI O L/R jacks on the side of your TV and to

the audio out jacks on the cable or satellite TV box.

Note

•The VIDEO/Y, PB, and PR video jacks (used to connect a component device) share the AV I N AU DI O L /R jacks with the VIDEO/Y jack (used to connect a composite device).

• When you connect the audio using the AV I N AU DI O L /R jacks, the audio output is analog.

5 Plug your TV’s power cord into a power outlet, turn

on your TV, then turn on the cable or satellite box.

6 Press INPUT to open the INPUT SOURCE list. 7 Press  or  to highlight COMPONENT/AV then

press ENTER.

Making connections

Side of TV

Cable or satellite box

Compos ite cable

Cables are often color- coded to match color-coded jacks.

Side of TV

Coaxia l cable

Cable or satellite box

DX-60D260A13

Using composite video (good)

To connect a cable or satellite box using composite video:

1 Make sure that your TV’s power cord is unplugged,

and all connected equipment is turned off.

2 Connect the incoming cable from the cable wall jack

to the cable-in jack on the cable or satellite box.

3 Connect an AV cable (not provided) to the VIDEO/Y

jack and AV IN AUDIO L/R jacks on the side of your TV and to the composite video and audio out jacks on the cable or satellite box.

Note

•The VIDEO/Y, PB, and PR video jacks (used to connect a component device) share AV I N A UDI O L/R jacks with the VIDEO/Y jack (used to connect a composite device).

• When you connect the audio using the AV I N A UDI O L /R jacks, the audio output is analog.

Using coaxial cable (good)

To connect a cable or satellite box using coaxial cable:

1 Make sure that your TV’s power cord is unplugged,

and all connected equipment is turned off.

2 Connect a coaxial cable (not provided) to the

TV IN ANT/CABLE IN jack on the side of your TV and

to the antenna or cable TV wall jack.

4 Plug your TV’s power cord into a power outlet, turn

on your TV, then turn on the cable or satellite box.

5 Press INPUT to open the INPUT SOURCE list. 6 Press  or  to highlight COMPONENT/AV then

press ENTER.

3 Plug your TV’s power cord into a power outlet, then

turn on your TV.

4 Press INPUT to open the INPUT SOURCE list. 5 Press  or  to highlight TV then press ENTER. 6 If you cannot tune to channels you know exist, scan

for channels. See “Automatically scanning for

channels” on page 24.

Notes

• Use a coaxial cable to eliminate interference and noise from radio waves.

• Do not bundle the coaxial cable with the power cord or other cables.

• If the antenna is not installed correctly, contact qualified service personnel to correct the problem.

• If the signal level for a channel is weak, the picture may be distorted. Adjust the antenna or use a highly directional outdoor or set-top antenna with a built-in amplifier.

• If the picture quality is good on some channels and poor on others, the problem may be caused by a poor or weak signal from the broadcaster or cable TV provider.

+ 35 hidden pages
