Dynalco SW-100 User Manual

3690 NW 53rd Street • Fort Lauderdale, FL 33309 • Ph 954-739-4300 • Fax 954-486-4968 • www.dynalco.com
DYNALCO
SW-100
Speed Switch / Transmitter
Operating Manual
SW-100
DIN-RAIL SPEED SWITCH
zz
Simple on-line trip frequency setting (using actual input signal or frequency generator)
zz
User settable trip frquency from 0.1 Hz to 25 KHz
zz
Over-speed, under-speed, and zero-speed detection
zz
Relay latching, alarm override, and alarm reset functions
zz
Programmable input circuit accepts outputs from a variety of sensors
zz
Hysteresis and offset functions available
zz
9 to 32 VDC input power
zz
Input and relay status indication LED’s
UL Recognized Component, File # E137808
DESCRIPTION
The SW-100 accepts a frequency input, and controls a single relay (SPDT) based on the value of the input frequency. The Trip frequency can be set to any value from 0.1 Hz to 25 KHz. The SW-100 can be set to trip on overspeed, or underspeed (including zero speed). Offset and hysteresis values can be incorporated into the trip setting to eliminate output chatter. LED indicators for both the Input signal and the Relay status are provided. Two separate input connections for external push-buttons are also provided. One external input overrides the trip detection function, and holds the relay in the release state as long as the input is pulled to common. The other external input clears a latched trip condition when pulled to common.
The SW-100 utilizes a seven position DIP switch, a rotary switch, a push­button and two indication LEDs to accomplish input circuit configuration, operational parameter set-up, input signal, and relay status indication. The input circuitry is DIP switch selectable for a variety of sources.
The indication LEDs are used during normal operation to display the input signal and relay status of the SW-100. These LEDs are also used to provide visual feedback to the user of the current parameter settings during parameter set-up.
DIMENSIONS In inches (mm)
The SW-100 operates in one of six output modes, as selected by the user. The programmable Minimum Response Time provides optimum response vs. input filtering for any input frequency. The offset and hysteresis settings provide flexible adjustment of the relay trip and release points.
The unit is equipped with a universal mounting foot for attachment to standard DIN style mounting rails, including top hat profile rail according to EN 50 022 - 35 x 7.5 and 35 x 15, and G profile rail according to EN 50 035 - G32.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the manual or on equipment must be observed to ensure personal safety and to prevent damage to either the instrument or equipment connected to it. If equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
WARNING: SPEED SWITCHES MUST NEVER BE USED AS
PRIMARY PROTECTION AGAINST HAZARDOUS OPERATING
CONDITIONS. Machinery must first be made safe by inherent design, or the installation of guards, shields, or other devices to protect personnel in the event of a hazardous machine speed condition. The speed switch may be installed to help prevent the machine from entering the unsafe speed.
SPECIFICATIONS
1. POWER: DC Power: 9 to 32 VDC; 2.0 W
Power Up Current: Ip = 600 mA for 50 msec max.
2. OPERATINGFREQUENCYRANGE: 0 Hz to 25 KHz
3. SIGNAL INPUT: DIP switch selectable to accept signals from a variety of sources, including switch contacts, outputs from CMOS or TTL circuits, and magnetic pickups. Current Sourcing: Internal 1 KΩ pull-down resistor for sensors with current
sourcing output. (Max. sensor output current = 24 mA @ 24 V output.)
Current Sinking: Internal 3.9 KΩ pull-up resistor for sensors with current
sinking output. (Max. sensor current = 3 mA.)
Low Bias: Input trigger levers V
sensitivity when used with magnetic pickups.
Hi Bias: Input trigger levels V Max. Input Signal: ±90 V; 2.75 mA max. (with both Current Sourcing and
Current Sinking resistors switched off).
= 0.25 V, VIH= 0.75 V; for increased
IL
= 2.5 V, VIH= 3.0 V; for logic level signals.
IL
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
CAUTION: Risk of electric shock. P/N #: 145F-12810.R2.072309
1
SPECIFICATIONS (Cont’d)
5. CONTROLINPUTS: Active low (V
VDC through a 100 KΩ resistor (I Alarm Reset: Unlatches the relay when pulled to common while the input
frequency is in the release region.
Alarm Override: Causes the SW-100 to unconditionally release the relay
when pulled to common.
6. RELAYCONTACTOUTPUT: FORM “C” (SPDT) contacts max. rating.
5 A @ 120/240 VAC or 28 VDC (resistive load), 1/8 H.P. @ 120 VAC (inductive load). The operate time is 5 msec nominal and the release time is 3 msec nominal.
7. RELAY LIFE EXPECTANCY: 100,000 cycles at max. rating. (As load
level decreases, life expectancy increases.)
8. ACCURACY: ±0.1% of the trip frequency setting.
9. INPUT IMPEDANCE: 33 KΩ min. with the sink and source DIP switches
in the OFF positions.
10. MINIMUM RESPONSE TIME: From 5 msec. +1 period to 10 sec. +1
period in ten steps (excluding relay operate time).
11. HYSTERESIS AND OFFSET: From 0.25% to 33.33% of Trip Frequency
in nine steps. Hysteresis and/or Offset can also be set to 0 (Disabled).
12. INPUT AND POWER CONNECTIONS: Screw in terminal blocks
13. ISOLATION BREAKDOWN VOLTAGE (Dielectric Withstand):
2200 V between power & input, and power & output; 500 V between input & output for 1 minute.
14. CERTIFICA TIONS AND COMPLIANCES:
SAFETY
UL Recognized Component, File #E137808, UL508, CSA 22.2 No. 14
Recognized to U.S. and Canadian requirements under the Component Recognition Program of Underwriters Laboratories, Inc.
IECEE CB Scheme Test Certificate # UL1683A-176645/USA,
CB Scheme Test Report # 97ME50135-042297
Issued by Underwriters Laboratories, Inc.
IEC 61010-1, EN 61010-1: Safety requirements for electrical
equipment for measurement, control, and laboratory use, Part 1.
= 0.5 V max.) internally pulled up to 5
IL
= 50 μA). Response Time = 1 msec.
SNK
ELECTROMAGNETIC COMPATIBILITY
Immunity to EN 50082-2
Electrostatic discharge EN 61000-4-2
Level 2; 4 Kv contact Level 3; 8 Kv air
Electromagnetic RF fields EN 61000-4-3
Level 3; 10 V/m
2
80 MHz - 1 GHz
Fast transients (burst) EN 61000-4-4 Level 4; 2 Kv I/O
Level 3; 2 Kv power
RF conducted interference EN 61000-4-6 Level 3; 10 V/rms
150 KHz - 80 MHz
Power frequency magnetic fields
EN 61000-4-8 Level 4; 30 A/m
Emissions to EN 50081-2
RF interference EN 55011 Enclosure class A
Power mains class A
Notes:
1. This device was designed for installation in an enclosure. To avoid electrostatic discharge, precautions should be taken when the device is mounted outside an enclosure. When working in an enclosure (ex. making adjustments, setting switches, etc.) typical anti-static precautions should be observed before touching the unit.
2. For operation without loss of performance: Unit is mounted on a rail in a metal enclosure (Buckeye SM7013-0 or
equivalent) and I/O cables are routed in metal conduit connected to earth ground.
Refer to the EMC Installation Guidelines section of this bulletin for
additional information.
15. ENVIRONMENTALCONDITIONS: Operating Temperature: 0 to 50°C Storage Temperature: -40 to 80°C Operating and Storage Humidity: 85% max. (non-condensing) from 0°C to
50°C.
Altitude: Up to 2000 meters
16. CONSTRUCTION: Case body is black, high impact plastic. Installation Category II, Pollution Degree 2
17. WEIGHT: 6 oz. (0.17 Kg)
1
ALARM
ALARM RESET
SENSOR SUPPLY
INPUT
SIGNAL
INPUT
COMMON
4
6
7
8
OVERRIDE
(AC VERSION ONLY)
12 VDC (60 mA)
100K
+12V
S3 SINK
3.9K
1K
S1 SRC
+5V+5V
100K
+5V +5V
10K
10K
0.1µf 0.1µf
+12V +12V
54.9K
S2 LOGIC
8.06K
33.2K
0.1µf
10.0K 470pf
392K
BLOCK DIAGRAM
DC
SWITCHING
CIRCUIT
RELAY (RED)
PUSH
BUTTON
DC VERSION
POWER
SUPPLY
+5V
+12V
N.O.
1
COMM.
2
N.C.
3
+
10
9 to 32 VDC
-
12
INPUT
ALARM
OVERRIDE
ALARM
RESET
PROCESS CIRCUITRY
10K
INPUT SIGNAL
INPUT LED
RELAY LED
RELAY
PUSH
BUTTON
INPUT
DIP SWITCH INPUTS
(GREEN)
MODE
CFG2
CFG1
CFG0
S4
S5
S6
S7
2
