User Manual of SADP Software
Search Active Device Protocol
V2.0
User Manual of SADP Software
Table of Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Description ............................................................................................................................... 1
1.2 System Requirements .............................................................................................................. 1
Chapter 2 Running SADP Software ............................................................................................. 2
2.1 Running SADP with Administrator Account ............................................................................. 2
2.2 Running SADP with other Admin Accounts .............................................................................. 2
2.3 Running SADP with Non-admin Accounts ................................................................................ 3
Chapter 3 Operating SADP Software ........................................................................................... 6
3.1 Searching Active Devices Online .............................................................................................. 6
3.2 Modifying Network Parameters ............................................................................................... 7
3.3 Restoring Default Password ..................................................................................................... 7
User Manual of SADP Software

Chapter 1 Overview

1.1 Description

Search Active Devices Protocol software is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices. You can also modify the basic network information of the devices using this software.
Note: Online intelligent devices search is not supported by SADP v2.0.

1.2 System Requirements

Operating System: Microsoft Windows XP/ Server 2003 32bits, Windows 7 / Server 2008 32/64 bits; CPU: Intel Pentium4 3.0 @3.00GHz or higher; RAM: 1GB or higher; Display: RADEON X700 series; Minimum Resolution: 1024*768.
User Manual of SADP Software

Chapter 2 Running SADP Software

2.1 Running SADP with Administrator Account

Log in the computer as the administrator, and double-click to enter
the SADP software main interface as shown in Figure 2-1.
Figure 2-1 SADP Interface

2.2 Running SADP with other Admin Accounts

You can also run the SADP software with other accounts of the admin group.
For Windows XP/2003
Refer to Section 2.1 Running SADP with Administrator Account.
For Windows Vista/Win7/2008
Steps:
1. Right-click and click Run as administrator.
User Manual of SADP Software
Figure 2-2 Run as Administrator
2. Click on the pop-up User Account Control dialog box to allow the
program and enter the main interface of SADP software.
Figure 2-3 User Account Control

2.3 Running SADP with Non-admin Accounts

If you log in the operating system with the non-admin accounts (e.g. users or guests), you need to run the software as administrator or as other accounts of the admin group.
For Windows XP/2003
Steps:
User Manual of SADP Software
1. Right-click and click Run as.
Figure 2-4 Run as Administrator
2. Input the username and password of the administrator or other accounts of the
admin group and click to enter the main interface of SADP software.
Figure 2-5 Input Username and Password
For Windows Vista/Win7/2008
1. Right-click and click Run as administrator.
User Manual of SADP Software
Figure 2-6 Run as Administrator
2. Input the password of administrator and click to enter SADP.
Figure 2-7 Enter Administrator Password
User Manual of SADP Software

Chapter 3 Operating SADP Software

3.1 Searching Active Devices Online

Search online devices automatically
After launch the SADP software, it automatically searches the online devices every 15 seconds from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. will be displayed.
Figure 3-1 Searching Online Devices
Note: Device can be searched and displayed in the list in 15 seconds after it went
online; it will be removed from the list in 45 seconds after it went offline.
Search online devices manually
You can also click to refresh the online device list manually. The newly
searched devices will be added to the list.
Note: You can click or on each column heading to order the information;
User Manual of SADP Software
you can click to expand the device table and hide the network parameter panel
on the right side, or click to show the network parameter panel.

3.2 Modifying Network Parameters

Steps:
1. Select the device to be modified in the device list and the network parameters of
the device will be displayed in the Modify Network Parameters panel on the right side.
2. Edit the modifiable network parameters, e.g. IP address and port number.
3. Enter the password of the admin account of the device in the Password field and
click to save the changes.
Figure 3-2 Modify Network Parameters

3.3 Restoring Default Password

Steps:
1. Contact our technical engineers to get the serial code.
Note: Serial code is a series of characters combined by the start time and the serial
User Manual of SADP Software
number of the device.
2. Input the code in the Serial code field and click to restore the
default password.
