Dual DV516BT User Manual

DV516BT

INSTALLATION/OWNER’S MANUAL

DVD Multimedia Receiver with Bluetooth

featuring a 7" Touch Screen Display

Safety Notes:

The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

®

Copyright Notes

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Namsung is under
license.

SD Logo is a trademark of SD-3C, LLC.

Other trademarks and trade names are those of their respective owners.

DV516BT PREPARATION

Table of Contents

Warning Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safety Information/Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preparation/Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Control Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remote Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AM/FM Tuner Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CD/USB/SD Card Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DVD Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bluetooth Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Auxiliary Inputs/Rear Camera Operation. . . . . . . . . . . . . . . . . . . . . . . . . .

Page

3

4

5

6

7

8

9-11

12-13

14-18

19-20

21-22

23

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

24

25

26

2

DV516BT PREPARATION

WARNING

Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle

must not operate this unit by watching videos or playing video games while driving.
Failure to follow this instruction could lead to driver distraction which could result in
serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or
property damage.

Several states prohibit the installation of monitors/DVD players if the screen is visible from

the driver’s seat. If you reside in a jurisdiction which has enacted such a law, this unit
must not be installed so that the screen is visible from the driver’s seat. When installing
this unit in the front console/dashboard, the unit must be positioned so that it is facing the
front passenger seat only. Failure to follow this instruction could lead to driver distraction
which could result in serious injury or death to the vehicle’s occupants or persons outside
the vehicle and/or property damage.

This unit is designed so that it may be operated only when the vehicle is in “Park” and the

parking brake is fully engaged. To this end, this unit includes a parking brake lock-out
feature which prohibits the unit from operating if the vehicle is not in “Park” and/or the
parking brake is not fully engaged. When installing this unit, the installer must connect
the parking brake detect wire to the parking brake mechanism in order to make the
parking brake lock-out feature operable. DO NOT simply ground the parking brake detect
wire to a metal portion of the vehicle. Failure to properly install the parking brake lock­out feature could lead to driver distraction which could result in serious injury or death to
the driver’s occupants or persons outside the vehicle and/or property damage.

Once the parking brake lock-out feature is installed, the owner/user must not attempt to

disrupt/neutralize the parking brake lock-out feature by (a) partially engaging the parking
brake and/or (b) purchasing/using any device or unit designed to send necessary brake
signals to the unit. Failure to follow these instructions could lead to driver distraction
which could result in serious injury or death to the driver’s occupants or persons outside
the vehicle and/or property damage.

When operating this unit, keep the unit’s volume level low enough so that the vehicle’s

occupants can hear traffic-related sounds such as police and emergency vehicles.
Failure to follow this instruction could lead to driver distraction which could result in
serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or
property damage.

3

DV516BT OPERATION

Safety Information

Please read all instructions carefully before attempting to install or operate.

Due to its technical nature, it is highly recommended that your DUAL DV516BT is installed by a professional
installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.

To prevent damage or injury:

• Make sure to ground the unit securely to the vehicle chassis ground.

• Do not remove the top or bottom covers of the unit.

• Do not install the unit in a spot exposed to direct sunlight or excessive heat or the possibility of water splashing.

• Do not subject the unit to excessive shock.

• When replacing a fuse, only use a new one with the prescribed rating. Using a fuse with the wrong rating may
cause the unit to malfunction.

• To prevent short circuits when replacing a fuse, disconnect the wiring harness first.

• Use only the provided hardware and wire harness.

• You cannot view video while the vehicle is moving. Find a safe place to park and engage the parking brake.

• If you experience problems during installation, consult your nearest DUAL dealer.

• If the unit malfunctions, reset the unit as described on page 10 first. If the problem still persists, consult your
nearest DUAL dealer or call tech assistance @ 1-866-382-5476.

• To clean the monitor, wipe only with a dry silicone cloth or soft cloth. Do not use a stiff cloth, or volatile solvents
such as paint thinner and alcohol. They can scratch the surface of the panel and/or remove the printing.

• When the temperature of the unit falls (as in winter), the liquid crystal inside the screen will become darker than
usual. Normal brightness will return after using the monitor for a while.

• When extending the ignition, battery or ground cables, make sure to use automotive-grade cables or other cables
with an area of 0.75mm (AWG 18) or more to prevent voltage drops.

• Do not touch the liquid crystal fluid if the LCD is damaged or broken. The liquid crystal fluid may be hazardous
to your health or fatal. If the liquid crystal fluid from the LCD contacts your body or clothing, wash it off with soap
immediately.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

4

DV516BT INSTALLATION

Preparation

Before You Start

• Disconnect negative battery terminal. Consult a qualified technician for instructions.

• Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it
would be subject to dust, dirt or excessive vibration.

Getting Started

• Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve.

• Install mounting sleeve into opening, bending tabs to secure.

• Connect wiring harness as shown on page 6. Consult a qualified technician if you are unsure.

• Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately).

• Reconnect negative battery terminal, and test for correct operation.

• Snap trim ring into place (if required).

• Slide unit into mounting sleeve to secure.

Mounting sleeve opening dimensions

7-3/16” x 2-1/16” (183 mm x 53 mm)

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

5

DV516BT INSTALLATION

Wiring Diagram - Inputs/Outputs

1

2

ACC (B+)

Note:

When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause
damage. The unit uses (1) 15 amp ATM mini style fuse located inside the in-line filter box.

Wiring Notes:

Subwoofer output
The Subwoofer preamp audio output (black jacket with green RCA) is active in all audio modes.

Rear camera input

A rear view camera (not included) can be used with the Camera input.

6

DV516BT OPERATION

Control Locations

12

11

10

9

27

26

25

24

23

22

21

20

19

18

Eject

1

Auxiliary Input

2

USB Port

3

Microphone

4

Tune/Track Down

5

Volume

6

1 2 3 4

1

2

3

45678

Mute / End Call

7

Band

8

Open / Power

9

Release

10

Mode

11

Tune/Track Up / Bluetooth Talk

12

Power

1

Mode

2

Play / Pause

5

6

7

8

9

10

11

12

13

14

15

16

17

3

Mute

4

Title

5

Subtitle

6

Setup

7

Angle

8

Slow

9

Volume Up

10

Zoom

11

Select / Bluetooth Talk

12

Seek Up / Next Track

13

Volume Down

14

15

Audio

Go To

16

EQ / Loudness / End Call

17

Number Keys

18

Root

19

On Screen Display

20

Local / Random

21

Seek Down

22

AS/PS / Repeat

23

Stereo/Mono / Program

24

Stop

25

Enter

26

Band

27

7

DV516BT OPERATION

Remote Control Preparation

Remove battery insulation tape .

To insert or replace the battery,

remove the battery holder.

Remove the battery from the

battery holder.

Install the new battery.

Make sure to keep the (+) side up.

Notes:

• The remote control uses one 3 volt Lithium
CR2025 battery. Remove the battery if the
remote will not be used for a month or
longer.

• Remove and dispose of battery properly.

• Do not store battery with metallic objects
or materials.

Insert the battery holder .

8

DV516BT OPERATION

General Operation

Installing the Faceplate

Power On/Off

Volume

Mute

Mode

Auxiliary Input

USB Port

SD Card

Opening the LCD

Screen Angle

Main Menu

Align the faceplate with the front of the unit, then snap in place
beginning with the left side.

Momentarily press

Rotate the volume knob to increase or decrease the volume level.

Momentarily press MUTE to silence the audio. Momentarily press MUTE
again to return to the previously selected volume. Rotating the volume

knob while the volume is muted will also cancel the mute function.

Press MODE to step through all available input modes: Radio, Disc
(which includes DVD and CD playback), USB, MicroSD, Bluetooth
Phone, Bluetooth Music, Rear Camera, Auxiliary Input, AV Input and
Setup. Modes of operation are indicated on the display and/or the
monitor. Optional USB device and SD card must be connected/inserted
to appear in the mode selection string.

Connect external audio/video devices to the 3.5mm auxiliary input on
the front panel.

Connect a USB device to play MP3/WMA files or view AVI, MP4 video
files or JPG photos.

Insert an SD card into the SD slot (located behind the faceplate) to play
MP3/WMA files or view view AVI, MP4 video files or JPG photos.

Press OPEN to open or close the LCD screen.

Press UPp or DOWN q to adjust the screen angle up or down.

When the monitor is open, press the house icon in the top left corner to
access the Main Menu screen.

to turn the unit on or off.

1 2 53 4

1. Put the monitor into standby mode.

2. Close the LCD screen.

3. Tilt screen up.

4. Tilt screen down.

5. Eject the disc.

9

DV516BT OPERATION

General Operation

Setup Menu

From the Main Menu screen, press SETUP in the bottom right corner
to access the Setup menu and select from six categories across the
bottom: General, Time, Video, Language, Calibration and SWC.

General:

• Animation - Select Off, 10 second, 30 second, 1 minute, 90
second, 2 minute, 3 minute or 4 minute to set animation length.

• Key Beep - Select a OFF or ON to select whether or not the unit

beeps each time a key is pressed.

• Disc - Adjust the following disc options:

- Format - Select NTSC, PAL or AUTO.

- TV Type - Select 4:3PS, 4:3 LB or 16:9.

- Rating - Select desired rating.

• Radio - Adjust the following radio options:

- Select between STEREO or MONO operation.

- Select between LOCAL or DX (distance) tuning.

- Select between the following region settings: EU R OPE ,
AMERICAN1, AMERICAN2 JAPAN and RUSSIAN.

• Bluetooth - Adjust the following Bluetooth options:

- Turn Bluetooth On or OFF.

- Turn Auto Answer feature On or OFF to determine whether

or not the unit will automatically answer incoming calls.

- Turn Auto Connect feature On or OFF to determine whether or
not the unit will automatically connect to available devices.

• Wallpaper - Select from three different wallpaper options.

• Demo - Turn Demo mode OFF or ON.

• Demo 2 - Turn Demo 2 mode OFF or ON.

• Dimmer - Adjust the dimmer levels between 1 and 6.

• Camera Icon - Select between NORMAL or MIRROR for the

camera display.

• About - Select to view information about the unit.

10

DV516BT OPERATION

General Operation

Setup Menu

Reset

Audio

Time:

• Hour - Press < or > to adjust the hour down or up.

• Minute - Press < or > to adjust the minutes down or up.

• Format - Select between a 12HR or 24HR clock display.

• Year - Press < or > to adjust the year.

• Month - Press < or > to adjust the month.

• Day - Press < or > to adjust the day.

Video:

• Brightness - Drag to adjust between 0 and 14.

• Contrast - Drag to adjust between 0 and 14.

• Color - Drag to adjust between 0 and 14.

• Tint - Drag to adjust between 0 and 14.

• Reset - Press to restore factory video settings.

Language:

• English - Set the unit language to English.

Steering Wheel Controls (SWC):

• See insert for SWS programming information.

To resolve abnormal operation or if the unit is inoperable, use the tip
of a pen to press the RESET button (located behind the faceplate). The
unit will reset the main processor to the default settings.

From any mode of operation, press Audio to adjust the following
Audio options:

• EQ - Select from the preset EQ options: JAZZ, CLASSIC, POP,

ROCK, BEAT OR FLAT, or select USER to manually adjust Bass
and Treble options between -7 and 7.

• Fader/Balance - Drag to adjust Fader options between 10F

(front) and 10R (rear) and Balance options between 10L (left) and
10R (right).

• Subwoofer/Loudness

- Adjust subwoofer volume from 1-12, or turn subwoofer OFF.

- Select between OFF, LOW or HIGH loudness levels.

• ASP

- Subwoofer Center Frequency: FLAT, 80Hz, 120Hz, 160Hz.

11

DV516BT OPERATION

AM/FM Tuner Operation

1

2

3

5

6 7

Radio Operation

Main Menu

Current Mode Indicator

Tune Frequency Down

Tune Frequency Up

Phone

Previous Options

Mute

Audio

AS/PS

Band

Next Options

4

8

9 10 11

Select the Radio icon from the Main Menu screen.

Press to return to Main Menu screen.

1

Displays current mode of operation.

2

Press << to tune radio to a lower frequency. Press < to tune the unit

3

down one step at a time.

Press >> to tune radio to a higher frequency. Press > to tune the unit

4

up one step at a time.

Press to access the Phone when Bluetooth is enabled. If Bluetooth is

5

turned off, pressing this button will turn it on.

Press to see the previous screen of options.

6

Press to mute the unit's sound. Press again to unmute, or sound can

7

be restored by adjusting the volume knob of the front panel.

Refer to instructions on page 11 to adjust audio options.

8

Press to scan presets and listen to the first 10 seconds of each. Press

9

again to stop scanning and listen to the station. Press and hold to
automatically find and store the strongest stations as presets.

10

Press between 2 AM and 3 FM bands.

11

Press to see the next screen of options.

12

DV516BT OPERATION

AM/FM Tuner Operation

16

Local / Distance

Loudness

Tilt Screen Up

Tilt Screen Down

Preset Stations

Stereo

14

12

17

Press to toggle between Local (LOC) and Distance (DX) tuning.

12

Press to adjust the Loudness setting between Low, High and Off.

13

Press to adjust the screen angle up.

14

Press to adjust the screen angle down.

15

Press to display the six preset stations stored in memory in the

16

current band. To store a preset station, tune unit to desired station,
then press and hold the desired preset button to store the current
station in that preset spot. Momentarily press any preset station to play
it instantly.

Press to toggle between Stereo (ST) and Mono operation.

17

13

15

13

DV516BT OPERATION

CD/USB/SD Card Operation

3

4

5

CD/USB

or SD Operation

Main Menu

Current Mode Indicator

Repeat

Random

Phone

Direct File Access

1

2

6

To play audio files from a disc or MP3 files from a disc, USB device or SD
card, insert disc or device and playback will begin automatically. To return
to disc, USB or SD card playback from another mode of operation, select
the corresponding icon from the Main Menu.

• Disc Playback -

Insert disc into the slot, and playback will begin

automatically.

• USB Playback - Insert a USB device into the USB slot on the side of

the unit.

• SD Card Playback - Insert SD card into the SD slot on the top of the

unit. When inserting an SD card, the label should face up.

Press to return to Main Menu screen.

1

Displays current mode of operation.

2

3

Press to select a repeat option: Repeat 1, Repeat Folder or Repeat Off.

Press to enable or disable random playback.

4

Press to access the Phone when Bluetooth is enabled. If Bluetooth is

5

turned off, pressing this button will turn it on.

Press to access the directory of folders and files. Use the up/down

6

arrows to scroll through the folder list, then press on the name of the
desired folder to access it. Use the up/down arrows to scroll through
the file list, then press on the name of the desired file to access it.

The default display will show Music files. Select the Photo or Video
icons at the bottom of the screen to display those files instead.

14

DV516BT OPERATION

CD/USB/SD Card Operation

Previous Options

Mute

Previous File/Track

Audio

Play / Pause

Backward

Next File/Track

Forward

Next Options

Tilt Screen Up

Tilt Screen Down

Stop

119 1387 10

7

8

9

10

11

12

13

14

15

16

17

18

1412 15

Press to see the previous screen of options.

Press to mute the unit's sound. Press again to unmute, or sound can be
restored by adjusting the volume knob of the front panel.

Press to go back to the previous file or track.

Press to adjust Audio options.

Press to pause or resume playback.

Press to fast reverse the current track at various speeds: FRx2, FRx4,
FRx8 or FRx20.

Press to advance to the next file or track.

Press to fast forward the current track at various speeds: FRx2, FRx4,
FRx8 or FRx20.

Press to see the next screen of options.

Press to adjust the screen angle up.

Press to adjust the screen angle down.

Press to stop playback.

16 17

18

15

File System

File

Extension

MPEG

Format

Sampling

Frequency

Bitrate

Other

Information

DV516BT OPERATION

Media Compatibility - CD/DVD

File Type MP3

ISO9660

ISO9660

Extension

Other

Extensions

.mp 3/.MP 3/. Mp3/.mP3

Directory Depth Unlimited

File Name Length 32 bytes

Total File Number 2000 files

Total Folder Number 200 folders

File Number via Folder 2000 files

MP3 ID3 TAG

Level 1, Level 2

Level 3 X

JOLIET

ROMEO

Apple ISO X

.rm p/.m4 a X

MPEG 1

MPEG 2

MPEG 2.5

MPEG 1 32/44.1/48kHz

MPEG 2 12/16/22.05/24kHz

MPEG 2.5 8/11.025/12kHz

MPEG 1 32 ~ 320 kbps

MPEG 2 8 ~ 160kbps

MPEG 2.5 8 ~ 160 kbps

Title, Artist, Album

Playback

Filename 32 bytes

Playback X

Filename X

ver.1.x

ver.2.x



















Notes:

• It is not possible to view JPG files on the in-dash monitor while the vehicle is moving. This is a safety feature to
prevent driver distraction.

• The JPG image viewer function will only operate when vehicle is in park and the parking brake is engaged as

described on page 26.

16

DV516BT OPERATION

Media Compatibility - USB/SD Card

File Type MP 3

File System

File

Extension

MPEG

Format

Sampling

Frequency

Bitrate

Other

Information

FAT

.mp 3/.MP 3/. Mp3/.mP3

.rm p/.m4 a X

MPEG 1

MPEG 2

MPEG 2.5

MPEG 1 32/44.1/48kHz

MPEG 2 12/16/22.05/24kHz

MPEG 2.5 8/11.025/12kHz

MPEG 1 32 ~ 320 kbps

MPEG 2 8 ~ 160kbps

MPEG 2.5 8 ~ 160 kbps

Directory Depth Unlimited

File Name Length 32 bytes

Total File Number 2000 files

Total Folder Number 200 folders

File Number via Folder 2000 files

MP3 ID3 TAG

FAT 12 X

FAT 16/ FAT 3 2

ver.1.x

ver.2.x

Title, Artist, Album

















Notes:

• For USB mode, it is not possible to view JPG files on the in-dash monitor while the vehicle is moving. This is a safety
feature to prevent driver distraction.

• The JPG image viewer function will only operate when vehicle is in park and the parking brake is engaged.

• Due to ongoing technological advancement, some USB flash drives and/or SD cards may be incompatible with
this unit.

17

DV516BT OPERATION

Media Compatibility

Media Compatibility

Playback Order

Compatible Recording Formats

Notes

The following types of discs/files are compatible:

• CD-DA, CD-ROM (ISO), CD-R, CD-RW

• DVD Video, DVD+R/RW, DVD-R/RW

• AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps

• Mpeg2: Max video resolution: 720x480, Max video bit rate: 5000 kbps

• Mpeg4: Max video resolution: 720x480, Max video bit rate: 5000 kbps

• DivX/Xvid: Max video resolution: 720x480, Max video bit rate: 5000 kbps

• SD/USB format type: FAT32/FAT

The following types of discs/files are not compatible:

• WMA files that are protected by DRM (Digital Rights Management)

• WMA lossless format

• Discs recorded with Track At Once or packet writing

• MP3 PRO format, MP3 playlists

• RMP format

• WAV format

• WMV format

• AAC, protected AAC, M4A format

Some recordable DVD's and CD's may be incompatible with this unit,
depending on media type and recording method.

MP3 playback sequence begins in the root folder of the disc, USB flash drive
or SD card. Any empty folders or folders that do not include MP3/JPG files
are skipped.

ISO9660 standards:

• Maximum nested folder depth is 8 (including the root folder).

• Valid characters for folder/file names are letters A-Z (all caps), numbers
0-9, and “_” (underscore). Some characters may not be displayed correctly,
depending on the character type.

• This device can play back discs in Joliet and other standards that conform
to ISO9660. MP3 written in the formats other than the above may not play
and/or their file names or folder names may not be displayed properly.

Some files may not play or be displayed correctly, depending on sampling
rates and bit rates.

For best results, use the following settings when ripping MP3 files:
128kbps or higher constant bit rate

44.1kHz or higher sampling frequency

18

DV516BT OPERATION

DVD Operation

1

2

Touchscreen Controls

Elapsed Time

Previous Chapter

19

Inserting a Disc

Ejecting the Disc

Main Menu

Mute

Play / Pause

Next Chapter

Backward

Forward

Next Options

43 5 9

76 8

Insert disc into the slot, and playback will begin automatically. Sub­menus may have to be pressed to access the DVD content. Read the
directions of your specific DVD disc for other features.

Press to eject the disc.

Press anywhere on the LCD to display touch screen controls.

Press to return to Main Menu screen.

1

Displays elapsed time and time remaining on the DVD.

2

Press to mute the unit's sound. Press again to unmute, or sound can

3

be restored by adjusting the volume knob of the front panel.

Press to return to the previous chapter on the DVD.

4

Press to play or pause DVD playback.

5

Press to advance to the next chapter.

6

Press to fast reverse playback at various speeds: FRx2, FRx4, FRx8

7

or FRx20.

Press to fast forward playback at various speeds: FRx2, FRx4, FRx8

8

or FRx20.

Press to display additional menu options.

9

DV516BT OPERATION

DVD Operation

10 11

Invalid Key

Previous Options

Random

Circulate

Audio

Dial

Menu

Goto

Subtitle

Title

Tilt Up

Tilt Down

14

1312

10

11

12

13

14

15

16

17

18

19

20

21

15

Press Random to play chapters in random order or Random Off to play
disc in order.

Press to select from the following repeat options: Repeat Chapter, Repeat
Title, Repeat All or Repeat Off.

Press to adjust Audio options.

Press to access the Phone when Bluetooth is enabled. If Bluetooth is
turned off, pressing this button will turn it on.

Press to access the main menu.

Invalid key.

Press to directly access a specific chapter.

Press to access subtitle options.

Press to access the title menu.

Press to adjust the screen angle up.

Press to adjust the screen angle down.

Press to view the previous option screen.

16

1817

212019

20

DV516BT OPERATION

Bluetooth Operation

1

2

3

Pairing a New Device

Connecting a

Paired Device

Bluetooth Phone

Main Menu

Current Mode Indicator

Phone Keypad

Backspace

21

4

5

Preparation

Redial

Talk

End Call

6

7

Before you can use a Bluetooth device, it must be paired and
connected. Make sure that Bluetooth is activated on your device
before you begin the pairing process.

The unit broadcasts the pairing signal constantly when no
devices are currently connected. Complete the pairing sequence
from your Bluetooth device. Refer to the owner's manual for
your device for more details. The device name is "Dual BT".

The Bluetooth passcode "0000". The unit can be in any mode of

operation when pairing is performed.

Note: On certain phones, pairing may need to be done more than
once if there are connectivity issues.

Most Bluetooth devices support the auto-connect feature and will
connect automatically if the device is in range when the unit is
powered-on. If your device was previously paired but does not
connect, enter the Bluetooth setup menu and ensure that Auto
Connect is On.

To access the phone, select Bluetooth Phone from the Main Menu
or press the phone icon from any operational mode.

Press to return to the Main Menu screen.

1

Displays current mode of operation.

2

Use the phone keypad to dial the desired phone number.

3

Alternately, numbers can be dialed directly from the phone.

Press to redial the last number called.

4

Press to connect a call.

5

Press to backspace when typing a number with the keypad.

6

Press to end a call.

7

DV516BT OPERATION

Bluetooth Operation

Dial

History

Connect

Bluetooth Music

Audio

Previous File / Track

Mute

Play / Pause

Tilt Screen Up

Next File/Track

Tilt Screen Down

98

10

Press to display the keypad and make a call.

8

Press to display a list of recently Received, Missed and Dialed calls.

9

Press to view active and available Bluetooth connections.

10

1412 1611 13

Select this option from the Main Menu to access Bluetooth Music
features.

11

Press to adjust Audio options.

12

Press to go back to the previous file or track.

13

Press to mute the unit's sound. Press again to unmute, or sound can
be restored by adjusting the volume knob of the front panel.

14

Press to pause or resume playback.

15

Press to adjust the screen angle up.

16

Press to advance to the next file or track.

17

Press to adjust the screen angle down.

1715

22

DV516BT OPERATION

Front 3.5mm Aux Input & Rear RCA A/V Input

Auxiliary Input

Using AV Input

Connect an optional audio source into the 3.5mm (front panel) input.

Select auxiliary input from the Main Menu to listen to audio.

Adjust volume on the external audio source as needed (if connected to the
headphone output of the device).

Connect an optional audio/video source to the rear auxiliary input (Red/White/
Yellow RCA connectors). Refer to page 6 for details.

Select AV Input from the Main Menu to listen to audio.

Engage parking brake to watch video.

Rear Camera Operation - (Optional)

Using Rear Camera

Auto Selection

Connect an optional rear camera to the Camera Input (Black RCA connector).

Refer to the wiring diagram for details.

Manual selection - Touch CAMERA icon from the Main Menu or from any
operational mode (when enabled) to select camera mode. Touch the top left area

on the screen to exit camera mode.

Note: The manual mode is for dedicated cameras that are ALWAYS on while
driving, it is not meant for cameras that are connected to the vehicle's reverse
light.

The unit will automatically select camera mode when connected to the reverse
lamp circuitry.

Note: The external video output is not active when using the rear camera input.

23

DV516BT OPERATION

Limited One Year Warranty

This warranty gives you specific legal rights. You may
also have other rights which vary from state to state.

Dual Electronics Corp. warrants this product to the
original purchaser to be free from defects in material
and workmanship for a period of one year from the
date of the original purchase.

Dual Electronics Corp. agrees, at our option, during
the warranty period, to repair any defect in material
or workmanship or to furnish an equal new, renewed
or comparable product (whichever is deemed
necessary) in exchange without charges, subject to
verification of the defect or malfunction and proof
of the date of purchase. Subsequent replacement
products are warranted for the balance of the original
warranty period.

Who is covered? This warranty is extended to the
original retail purchaser for products purchased from
an authorized Dual dealer and used in the U.S.A.

What is covered? This warranty covers all defects
in material and workmanship in this product. The
following are not covered: software, installation/
removal costs, damage resulting from accident,
misuse, abuse, neglect, product modification,
improper installation, incorrect line voltage,
unauthorized repair or failure to follow instructions
supplied with the product, or damage occurring
during return shipment of the product. Specific
license conditions and copyright notices for the
software can be found via www.dualav.com.

What to do?

1. Before you call for service, check the

2. If you require service during the warranty period,

3. Please describe your problem in writing and

4. For more information and for the location of the

Exclusion of Certain Damages: This warranty is
exclusive and in lieu of any and all other warranties,
expressed or implied, including without limitation
the implied warranties of merchantability and fitness
for a particular purpose and any obligation, liability,
right, claim or remedy in contract or tort, whether or
not arising from the company’s negligence, actual or
imputed. No person or representative is authorized
to assume for the company any other liability in
connection with the sale of this product. In no event
shall the company be liable for indirect, incidental or
consequential damages.

troubleshooting guide in your owner’s manual.
A slight adjustment of any custom controls may
save you a service call.

you must carefully pack the product (preferably
in the original package) and ship it by prepaid
transportation with a copy of the original receipt
from the retailer to an
authorized service center.

include your name, a return UPS shipping address
(P.O. Box not acceptable), and a daytime phone
number with your shipment.

nearest authorized service center please contact
us by one of the following methods:

• Call us toll-free at 1-866-382-5476

• E-mail us at [e-mail]

24

DV516BT OPERATION

Specifications

Disc

Frequency response: 20Hz-20kHz
Channel separation @ 1kHz: >80dB
D/A converter: 24 Bit

FM Tuner

AM Tuner

Front USB

SD

Monitor

General

Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 10dBf
50dB quieting sensitivity: 20dBf
Stereo separation @ 1kHz: 38dB
Frequency response: 30Hz-13kHz

Tuning range: 530kHz-1710kHz
Usable sensitivity: 24uV
Frequency response: 30Hz-2.3kHz

Compatibility: High Speed USB 2.0
USB Class: Mass storage class

Compatibility: Micro SD memory card & Micro SDHC memory card

Panel size: 7” diagonal measurement
View angle (up/down/left/right): 50/70/70/70
Resolution: 800 (H) x 480 (V)
Brightness (cd/m2): 250
Contrast ratio: 500:1
Pixels: 1,152,000

Speaker output impedance: 4 ohms
Line output voltage: 4 volt RMS
Line output impedance: 200 ohms
Chassis dimensions: 7" x 7" x 2" (W x D x H)

Design and specifications subject to change without notice.

CEA-2006 Power Standard Specifications

(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)

Power Output: 16 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms)

25

DV516BT OPERATION

Troubleshooting

General

Problem Cause Action

Unit will not turn on

(no power)

Unit has power

(but no sound)

Unit blows fuse(s)

Unit has audio

(but no video)

No video display

(when in reverse)

DVD does not start

playback

IR remote does not work

Excessive skipping

Disc Region Incorrect

appears on display

Yellow wire not connected or incorrect voltage
Red wire not connected or incorrect voltage

Black wire not connected Check connection to ground

Fuse blown Replace fuse(s)

Speaker wires not connected Check connections at speakers

One or more speaker wires touching each
other or touching chassis ground

Yellow or red wire touching chassis ground Check for pinched wire

Speaker wires touching chassis ground Check for pinched wire

Incorrect fuse rating Use fuses with correct rating

Parking brake safety circuit not connected
Parking brake not applied

Reverse circuit not connected
Vehicle is not in reverse

Physical defect in media
Wrong region

Dead battery Replace battery

Unit is not mounted correctly Check mounting sleeve

Physical defect in media Check media for scratches

Region code error Use discs labeled "Region 1" or "All" only

Check connections for proper voltage (11~16VDC)

Insulate all bare speaker wires from each other and
chassis ground

Check connections at parking brake
Apply parking brake as described on page 26

Check connections at reverse lamp
Select reverse gear

Check media for scratches
Use discs labeled "Region 1" or "All" only

For Your Records

Register Your Product

Please keep your original sales receipt and be prepared to provide this receipt in
the event you require service, as your original receipt is considered the best proof of
purchase and indicates the date you purchased your Dual product.

Dealer Name

Dealer Phone

Purchase Date

Register your product online at www.dualav.com.

26

Dual Electronics Corp.

Toll Free: 1-866-382-5476

Monday-Friday, 9AM-5PM EST

©2016 Dual Electronics Corp. All rights reserved.

www.dualav.com

NSA0616-V01

Printed in China
