Drive Osprey Quick Start Manual

Remove the two knobs on the rear cover and

unscrew the knob on the end of the freewheel
mode lever. Lift up carefully on the rear cover to
remove. The rear cover will still be connected to the
scooter by the white taillight connector cable.

Install the seat post. Ensure that the seat post

is aligned so that the two flanges with holes are

facing the rear of the product. Having these flanges
rotated into any other position will result in instability
in the seat.

Attach the two battery connectors to the

batteries (red to red and black to black).

Remove your scooter from its packaging. Raise

the tiller by pushing down on the tiller lever, lifting
the tiller into place, then releasing the lever.

Replace the rear cover, making sure the tabs

on the bottom of the rear cover fit into the slots
in the scooter’s floorboard. Replace and tighten the
two knobs and the freewheel mode knob removed
in Step 2.

From behind the product, looking forward, insert

the seat bolt into hole on the left side of the seat
post. This bolt is also used to adjust the seat height.
Insert the bolt as far into the hole as it will go, making
sure that the bolt passes all the way through to the
hole on the opposite side. Install the washer and nut
and tighten them using the included flat wrench.

Lift the seat and pull the swivel lever up at the

same time. Lower the bottom of the seat onto
the seat post. Release the lever, swivel the seat
and push down on the seat until it locks in place.

1NOTE: Get help when placing the seat onto the

post to avoid scratching the cover shroud.

1. 2. 3. 4.

5. 6. 7. 8.

Insert the armrests into the attachment points

in the seat frame so that the armrests face
forward.

Please Read Before Operating!

For technical assistance, call toll free [phone] or [phone].

Quick Start Guide

Osprey

Affix the front basket to the bracket on the front
of the scooter’s tiller

Screw the rearview mirrors directly into the
receptors at the top of the product’s control

panel.

Affix the headrest to the top of the seat by

inserting the headrest posts into the holes in
the top of the seat.

Insert and tighten the included star knobs to lock

the armrests into place at the desired width.

9. 10.

11. 12.

Fully charge the scooter’s batteries by inserting the round charger connector into the battery charging
terminal on the scooter’s control panel and inserting the 3-pronged plug into a standard electrical outlet.

Ensure that the 115V/230V switch on the product’s battery charger is set to 1 15V . If the switch is set to 230V , the
scooter will not charge properly.Fu ll charging normally takes 6-8 hours, but can take as many as 10 hours
depending on the batteries’ charge level when starting and the ambient temperature.

13.

Osprey Quick Start Guide

READ BEFORE UNPACKING

This Quick Start Guide offers basic information on initial product
setup only. Read the owner’s manual and all supplemental
information thoroughly before operating the product for
information on safety, battery charging, basic operation, comfort
adjustments, disassembly and care and maintenance.

NOTE: The illustrations provided may not reflect your actual unit.

READ

THIS

FIRST!
