Drive Nitro Rollator User Manual

Nitro Rollator

www.ActiveForever.com | 1-800-377-8033

Parts List

1

3

4

5

12

10

11

1. Handgrip

2. Adjustable tubing handgrip

3. Rear reflector on handgrip

4. Brake lever

5. Interlock button for handgrips

6. Back Rest

2

6

7

8

9

7. Seat

8. Bag

9. Front wheel

10. Brake adjust screw

11. Rear wheel

12. Safety bow

Introduction

The Walking aid is suitable for a single user with limited mobility. The nitro is ideal for
indoor and outdoor use.

Nitro Includes:

1. Bag

2. Back Rest

3. Operating Instructions

Unfolding the Nitro

Position the Nitro on its
wheels. Open the red
safety bow and lift up
(figure 1). Press both pipes
from the seat downwards
until they interlock (figure

2).

1

Height Adjustment

Press the red release buttons for handgrips below,
as shown in figure 3, and pull the handgrip upwards
at the same time. As the handle moves, release the
button. This automatically locks in the next possible
height. Repeat this process until the desired height
is reached.

2

3
