TEC30D EV
Generator
Operating manual . . . . . . . . . . . . . . . . . . . . 10
Generator
Bedienungsanleitung . . . . . . . . . . . . . . . . .30
Générateur
Notice d’utilisation . . . . . . . . . . . . . . . . . . .53
Generador
Instrucciones de uso . . . . . . . . . . . . . . . . . .75
Gerador
Manual de instruções . . . . . . . . . . . . . . . . .97
Generatore
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . .120
Generator
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .143
Generator
Betjeningsvejledning . . . . . . . . . . . . . . . .165
Generator
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 186
Generator
Bruksanvisning . . . . . . . . . . . . . . . . . . . . .206
Generaattori
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . .227
Генератор
Инструкция по эксплуатации . . . . . . . . . 248
Generator
Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 271
Generàtor
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 294
Generàtor
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 316
Generátor
Használati utasítás. . . . . . . . . . . . . . . . . . .338
Autogoods “130”
130.com.ua
2
1
6
5
4
3
1
Autogoods “130”
130.com.ua
TEC30D EV
3
TEC30D EV
2
3
1
2
5
3
2
1
6
4
7 8
109
3
Autogoods “130”
130.com.ua
4
4
3
1
2
4
Autogoods “130”
130.com.ua
TEC30D EV
5
2
1
A
CD
B
3
4
5
2
1
5
Autogoods “130”
130.com.ua
O
TEC30D EV
L
I
6
TEC30D EV
2
11
6
234
1
7
Autogoods “130”
130.com.ua
7
TEC30D EV
572 466
500
8
Autogoods “130”
130.com.ua
8
9
Autogoods “130”
130.com.ua
TEC30D EV
9
EN
TEC30D EV
Autogoods “130”
130.com.ua
Please read this instruction manual carefully before first use, and store it in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
8 Operating the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
9 Cleaning the generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10 Servicing the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
12 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
10
EN
TEC30D EV Explanation of symbols
Autogoods “130”
130.com.ua
1 Explanation of symbols
DANGER!
D
!
!
A
I
Safety instruction: Failure to observe this instruction will cause fatal or
serious injury.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Damage to the product resulting from mechanical influences and excess voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
In particular, the manufacturer will not be liable for any consequential damage,
especially consequential damage caused by failure of the generator.
Note the following basic safety information when using electrical devices to protect
against:
• Electric shock
• Fire hazards
• Injury
11
EN
Safety instructions TEC30D EV
Autogoods “130”
130.com.ua
2.1 General safety
DANGER!
D
!
• Do not operate the device in spaces where danger of explosion is
present.
WARNING!
• Electrical devices are not toys
Keep electrical devices out of reach of children or infirm persons. Do
not allow them to use electrical devices without supervision.
• People (including children) whose physical, sensory or mental
capacities prevent them from using this device safely may not be
allowed to operate it without the supervision of a responsible adult.
• Only use the device as intended.
• Do not make any alterations or conversions to the device.
• Installation, maintenance and repairs of the generator may only be
_carried out by qualified personnel who are familiar with the risks
involved when handling generators as well as the relevant regulations.
Inadequate repairs may cause serious hazards. For repair service,
please contact the manufacturer's branch office in your country
(addresses on the back page).
• Mark the area surrounding the device during maintenance work and
prevent access to areas where activation can cause perils.
• Exhaust fumes contain carbon monoxide which is a highly toxic,
odourless and colourless gas. Do not inhale any exhaust fumes. Do
not leave the generator motor running in a closed garage or in a room
without windows.
!
12
CAUTION!
• The generator may only be used with the inspection cover closed.
• Remove all flammable materials such as petrol, paints, solvents, etc.,
from the vicinity of the generator.
• Ensure that hot parts of the generator do not come in contact with any
flammable materials.
• Only refuel the generator when it is switched off and in a well
ventilated area. Diesel oil is highly flammable and can explode.
• Do not refuel the generator when the vehicle engine is running if the
tank is in the vicinity of the vehicle engine.
• Wipe up spilled diesel oil properly and wait until the fumes have
cleared before turning on the engine.
EN
TEC30D EV Target group for this manual
Autogoods “130”
130.com.ua
• Do not touch the generator and the cables with wet hands.
• Replace the fuses using only those with the same technical data.
• Do not switch the generator to automatic mode near any ignition
sources (such as petrol stations, dry areas with risk of forest fires).
NOTICE!
A
2.2 Operating the device safely
!
A
• Do not fill up the tank too full. Diesel oil must not be allowed to fill up
to the neck of the tank. Check the lid is on properly.
WARNING!
• Always disconnect the power supply when working on the device.
NOTICE!
• Only operate the device if you are certain that the housing and the
cables are undamaged.
3 Target group for this manual
This operating manual is for the user of the generator.
4Scope of delivery
Designation Reference no.
TEC30D EV Generator 9102900033
Remote control
Silencer
Exhaust pipe, 2 m
Set mounting brackets for silencer
AG 102, changeover relay for making priority circuits
Extension cable for remote control
Installation manual
Operating manual
13
EN
Accessories TEC30D EV
Autogoods “130”
130.com.ua
5Accessories
Available as accessories (not included in the scope of delivery):
Part designation Reference no.
Damper 9102900028
AG 101, tank 15 l, plastic 9102900009
AG 100, tank 20 l, stainless steel 9102900011
AG 150, pipe set for AG 100/AG 101 9102900003
AG 125, flexible metal pipe for extending exhaust pipe, 5 m 9102900138
AG 171, installation brackets (hanging installation) 9102900150
AG 163, exhaust pipe fixing kit 9102900028
Parallel cable 9102900296
6 Intended use
The TEC30D EV (ref. no. 9102900033) generator is designed for use in motor homes,
camper vans and vehicles for commercial use.
The generator is not suitable for installation in water vessels.
The generator produces a pure sine wave voltage of 230 V/50 Hz which can be
connected to the consumer with a total continuous load of 2500 W. The power
quality is also suitable for sensitive consumers (such as PCs).
The generator can charge a 12 V battery.
7 Technical description
The TEC30D EV generator consists of the following main parts (fig. 1, page 3):
• Fuel pump (1)
• Endothermic engine (2)
• Alternating current generator (3)
• Inverter (4)
• Internal control panel (5)
• Remote control (6)
14
EN
TEC30D EV Technical description
Autogoods “130”
130.com.ua
The fuel pump (1) pumps the fuel from the tank and supplies the endothermic
engine (2).
The endothermic engine (2) drives the alternating current generator connected to
it (3), which in turn generates AC voltage.
The inverter (4) transforms this AC voltage into a stable voltage of 230 V and 50 Hz.
The terminals, the socket for the connection cable to the remote control (6) and the
main switch are installed on the internal control panel (5).
Overview of the components: fig. 9, page 9.
The generator has the following features:
• Integrated battery charger for charging the connected battery
Control elements in the control panel
The control panel is located in the generator behind the cover.
No. in
fig. 2,
page 4
1 Main switch Switches the generator to standby or no
Description
function.
0: The generator is shut off from the supply
battery.
1: The generator is powered by the supply
battery and ready for start up.
2 Battery charger fuse Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
3 Main fuse Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
15
EN
Technical description TEC30D EV
Autogoods “130”
130.com.ua
Control elements in the remote control
The remote control is installed in the vehicle interior.
No. in
fig. 3,
page 4
1 Display Shows the status reports.
2 On/Off switch Switches the remote control on and off if the
3 START button Starts the generator if the remote control is
4 Diesel oil gauge Lights up if the diesel oil goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
Displays
No. in
fig. 3,
page 4
Description
main switch is at “1”.
Stops the generator.
switched on and the main switch is at “1”.
engine.
Description
16
6 AC supply Actual voltage output
7 Constant output Current capacity of connected consumer
8 Operating hours Time the generator is in operation
9 DC voltage Battery voltage
10 Messages Status reports of the generator (see chapter
“Display messages” on page 19)
EN
TEC30D EV Operating the generator
Autogoods “130”
130.com.ua
8 Operating the generator
NOTICE!
A
I
8.1 Basic notes on operation
!
Please note the following basic information:
• When operating the generator at low temperatures (< 0 °C) you have to use
winter diesel fuel or you have to add a percentage of petrol to the diesel oil
according to the following table:
Do not run the generator over 70 % of the maximum constant output for
the first 50 operating hours (run-in phase).
NOTE
Run the generator at a maximum of approx. 75 % of the maximum
continuous load after the run-in phase.
By doing this you can prolong the service life of the generator and
maximise its efficiency.
CAUTION! Beware of injury
Do not insert your fingers or objects into the ventilation openings.
Ambient Temperature Summer diesel Winter diesel
• Always check the oil level before use (chapter “Checking the oil level” on
• Check the oil level in the oil sump.
• Check if the air inlet ducts for combustion and cooling are intact and free from
• Even small overloads in the long-run will cause the fuses to blow.
• Leave the generator running for a few minutes after use without any consumers
–10 to 0 °C 20 % –
–15 to –10°C 30% –
–20 to –15 °C 30 % 20 %
page 21).
residues.
before stopping it.
17
EN
Operating the generator TEC30D EV
Autogoods “130”
130.com.ua
• Abrupt braking, accelerating and driving round bends in the vehicle can cause
problems in the generator's pump system and lead to unwanted shutdown.
• If you are not using your generator for a longer period of time, start it up at least
every 10 days and leave it running for 15 minutes or more.
• Before you restart the generator after a longer period of inactivity proceed as
follows:
– Change the engine oil (chapter “Changing the oil” on page 24).
– Change the fuel filter (chapter “Changing the fuel filter” on page 25).
8.2 Switching the generator to standby or no function
The generator can be switched to standby or no function with the main switch
(fig. 2 1, page 4) in the control panel.
8.3 Switching the remote control on and off
This switch on the remote control (fig. 3 2, page 4) is for switching the remote
control on and off.
➤ Switch the remote control on with the on/off switch.
✓ The display shows:
✓ The generator can now be started.
8.4 Starting the generator
Th e g ene ra tor ca n on ly be s tart ed if it is in st an dby an d th e r emo te co nt rol is sw itch ed
on.
I
➤ Start up the generator with the start button (fig. 3 3, page 4).
18
GEN OFF.
The display switches off automatically after 5 minutes if the start button is not
touched within this time.
Press the start button to switch on the display again.
NOTE
If the generator is still warm, press the start button briefly to start it; press
longer for a cold generator.
EN
TEC30D EV Operating the generator
Autogoods “130”
130.com.ua
8.5 Stopping the generator
➤ Stop the generator with the on/off switch (fig. 3 2, page 4).
If the generator does not stop: switch it off with the main switch (fig. 2 1,
page 4).
Stopping the generator for a prolonged time
➤ Switch it off with the main switch (fig. 2 1, page 4).
➤ Disconnect the battery.
8.6 Display messages
Display message
Description
LOW BATTERY
The battery voltage has fallen
below the minimum value for
starting up (9V).
OIL CHANGE
The number of prescribed
operating hours has been
reached for changing the
engine oil.
NO FUEL
The fuel in the tank is in
reserve.
CHECK OIL LEVEL
Insufficient engine oil.
OIL TEMP PRESS
Insufficient engine oil.
Generator behaviour Measures
The generator does not start. Charge the battery.
The generator continues to
run.
The generator continues to
run.
The generator stops. Fill up with oil (see chapter
The generator stops. Fill up with oil (see chapter
Change the oil (see chapter
“Changing the oil” on
page 24), then restart the
generator by pressing and
holding down the start button.
Refuel.
“Checking the oil level” on
page 21).
“Checking the oil level” on
page 21).
19
EN
Operating the generator TEC30D EV
Autogoods “130”
130.com.ua
Display message
Description
OIL TEMP PRESS
Engine temperature too
high.
GENERATOR ALERT!
General alarm message
OVERLOAD!
The consumers generate an
overload at the output.
Generator behaviour Measures
The generator stops. Switch off the generator and
leave it to cool down. Check
that the ventilation openings
are not obstructed.
If the problem persists,
contact the manufacturer's
branch office in your country
(addresses on the manual‘s
back page).
The generator stops. Check the system by refer-
ring to the troubleshooting
table (page 27).
If the problem persists,
contact the manufacturer's
branch office in your country
(addresses on the manual‘s
back page).
The inverter switches off,
therefore no voltage is
supplied but the engine
carries on running until it
goes off.
Reduce the connected load.
Stop the generator and
restart it.
SHORT CIRCUIT
The consumers cause a short
circuit at the output.
OVER TEMPERATURE
Overheating
LOW POWER ENGINE
The inverter supply voltage
has dropped.
RESTART GEN?
Message appears after the
generator has stopped due
to overheating.
20
The inverter switches off,
therefore no voltage is supplied but the engine carries
on running until it goes off.
The inverter switches off so
no voltage is supplied to
cool the generator, but the
engine carries on running.
The generator stops. Reduce the connected load
The generator is switched
off.
Check the connected
consumers. Stop the
generator and restart it.
Leave the engine to cool
down for a few minutes. Stop
the generator and restart it.
and start the generator
again.
Press the start button to
restart the generator.
EN
TEC30D EV Operating the generator
Autogoods “130”
130.com.ua
Display message
Description
GEN CAL
Message appears when the
generator is started up; it
shows the calibration phase
which takes place before
each start-up. The generator
does not supply any voltage.
GEN WAIT
Message appears while you
are waiting for the generator
to start again.
GEN ON
The generator is operating
normally.
GEN OFF
Generator behaviour Measures
The generator is running but
does not supply any voltage.
The generator is switched
off.
Normal mode –
The generator is in stand-by
and can be started.
8.7 Checking the oil level
CAUTION!
!
Hot oil can cause burns.
Only check the oil level when the generator is switched off.
Wait a moment.
Wait until the message has
disappeared then attempt
ignition again.
–
I
Always check the oil level before use. To do this, proceed as follows (fig. 4,
page 5):
➤ Open the generator cover (2).
➤ Switch the generator to no function with the main switch (1).
➤ Take the dipstick (3) out of the filler neck (4).
➤ Clean the dipstick (3) with a cloth.
➤ Put the dipstick (3) back into the filler neck (4).
➤ Take the dipstick (3) out of the filler neck.
NOTE
The generator must be level.
21
EN
Cleaning the generator TEC30D EV
Autogoods “130”
130.com.ua
➤ Check that the oil level is between the maximum and the minimum notches of the
dipstick (2).
If not, top up with some oil. The maximum amount of oil is 0.9 l.
➤ Put the dipstick (3) back into the filler neck (4).
➤ Switch the generator to standby with the main switch (1).
➤ Close the generator cover (2).
9Cleaning the generator
NOTICE! Beware of damage
A
➤ Clean the generator with a damp cloth from time to time.
➤ Remove any dirt from the air vents in the generator at regular intervals. Make sure
you do not damage the grilles of the generator in the process.
• Do not clean the generator with a high-pressure cleaner. Exposure
to water can damage the generator.
• Do not use sharp or hard objects or cleaning agents for cleaning as
these may damage the generator.
• To clean the generator, use water with a gentle cleaning agent.
Never use petrol, diesel or solvents.
10 Servicing the generator
10.1 Maintenance table
!
I
22
WARNING!
Only have maintenance work carried out by specialist personnel who
are familiar with the relevant regulations. Inadequate maintenance may
cause serious hazards.
NOTE
Have the following maintenance work performed at regular intervals or
after the specified number of operating hours, whichever is sooner.
EN
TEC30D EV Servicing the generator
Autogoods “130”
130.com.ua
Interval Inspection/maintenance
In the first month
or after 50 hours
Every 3 months or
every 50 hours
Every 250 hours ➤ Change the oil (chapter “Changing the oil” on page 24).
Every 500 hours ➤ Replace the fuel filter (chapter “Changing the fuel filter” on
Once a year
or every
1000 hours
➤ Change the oil (chapter “Changing the oil” on page 24).
➤ Check and clean the air filter (chapter “Servicing the air filter” on
page 25).
➤ Clean the motor‘s cooling devices.
➤ Check the valves.
➤ Check if the screws are intact and firmly tightened.
page 25).
➤ Replace the air filter (chapter “Servicing the air filter” on page 25).
➤ Clean the oil filter.
➤ Check the diesel oil supply lines.
The following must be carried out by a HATZ authorised retailer or
Dometic skilled personnel:
➤ Check the fuel injection pump.
➤ Check the vibration damper.
10.2 Preparing maintenance work
CAUTION!
!
Note the following for all maintenance work:
• The generator must not be running.
• All the parts must be cooled down.
➤ Open the generator cover (fig. 4 2, page 5).
➤ Switch the generator to no function with the main switch (fig. 4 1, page 5).
10.3 Finishing maintenance work
➤ Switch the generator to standby with the main switch (fig. 4 1, page 5).
➤ Close the generator cover (fig. 4 2, page 5).
23
EN
Servicing the generator TEC30D EV
Autogoods “130”
130.com.ua
10.4 Changing the oil
CAUTION!
!
A
You may use the following oil:
• Oil with the specifications:
– CCMC D4, D5, PD
– API CD, CE, CF, CG
–SHPD
• SAE grade oils:
–5W-30
–5W-40
–100W
– 100W-30 (recommended)
–10W-30
–15W-30
–30
–40
• Oil with single grade oil viscosity:
Select the appropriate viscosity according to the average temperature on-site.
Hot oil can cause burns. Use protective gloves.
NOTICE!
• Only dispose of used oil at a specialist recycling station and observe
the local laws for environmental protection.
• Do not mix oils with different characteristics or from different manufacturers.
Change the oil as follows (fig. 5, page 6):
➤ Allow the generator to run warm for three to five minutes so that the oil can drain
➤ Take the dipstick (1) out of the filler neck (2).
➤ Place a suitable receptacle (4) near the oil hose (5).
➤ Loosen the clamp (3).
➤ Take off the oil hose (5) and let the oil drain off into the receptacle (4).
➤ Put the oil hose (5) onto the hose-end fitting.
➤ Fasten the oil hose (5) with the clamp (3).
24
off faster and completely.
EN
TEC30D EV Servicing the generator
Autogoods “130”
130.com.ua
➤ Pour fresh oil into the filler neck (2).
The maximum amount of oil is 0.9 l.
The oil level must be between the maximum and the minimum notches of the
dipstick (1).
➤ Put the dipstick (1) back into the filler neck (2).
10.5 Changing the fuel filter
NOTICE!
A
Change the fuel filter as follows (fig. 6, page 7):
➤ Provide a suitable receptacle to catch any fuel leaks.
➤ Loosen the clamps (1).
➤ Remove the fuel filter (2).
➤ Insert the new fuel filter.
➤ Tighten the clamps (1).
Only dispose of pollutants at a specialist recycling station and observe
the local laws for environmental protection.
10.6 Servicing the air filter
!
!
A
WARNING! Danger of explosions
Do not use diesel oil or solvents with low boiling points for cleaning the
air filter. They could ignite or explode.
CAUTION!
Wear an respirator mask and protection glasses.
NOTICE!
Never leave the engine running without an air filter. Otherwise this
quickly wears out the engine.
25
EN
Servicing the generator TEC30D EV
Autogoods “130”
130.com.ua
NOTE
I
Check and change the fuel filter as follows (fig. 7, page 7):
➤ Remove the fixing cap (1) and the filter cover (2).
➤ Remove the knurled nut (3).
➤ Take out the air filter (4).
➤ Check the condition of the air filter (4) carefully:
Shine light into the air filter with a lamp and verify if the paper membrane is
damaged.
Replace the air filter:
–if damaged
– if soiled by humid or oily obstruction
➤ Clean the undamaged air filter of dry obstruction.
Clean the filter cartridge with dry compressed air (do not use jets of compressed
air with a pressure of more than 2 – 2.5 bar): Blow the air from the inside towards
the outside, until all the dust has been completely expelled.
If the air filter is dirty, the air flow to the motor is reduced. Check the
filter regularly so that the motor can function properly. Check this more
frequently if the generator is being used in particularly dusty
environments.
➤ Clean the filter cover (2).
➤ Insert the air filter (4).
➤ Fasten the knurled nut (3).
➤ Mount the filter cover (2).
➤ Fasten the filter cover (2) with the fixing cap (1).
26
EN
TEC30D EV Troubleshooting
Autogoods “130”
130.com.ua
11 Troubleshooting
Fault Cause Remedy
The remote
control does not
come on when
the on/off switch
is pressed.
The starter does
not work when
the start button is
pressed.
The starter turns
but the
generator does
not start.
The generator
tends to go off.
Starter battery is flat. ➤ Charge the starter battery.
Main fuse is blown. ➤ Replace the main fuse.
Power cable is disconnected or the
plug is removed.
Starter battery is flat. ➤ Charge the starter battery.
The main switch is at “0”. ➤ Set the main switch to “1”.
Inverter is damaged. ➤ Contact an authorised
Power cable is disconnected or the
plug is removed.
Starter motor does not start.
Fuel level too low. ➤ Fill up with fuel.
Inverter is damaged. ➤ Contact an authorised
Power cable is disconnected or the
plug is removed.
Injectors are dirty or faulty.
Engine malfunction.
Too much oil in the engine. ➤ Drain the oil.
Load is over 2.5 kW. ➤ Reduce the consumers.
Air filter is dirty. ➤ Clean the air filter (chapter
Inverter is damaged. ➤ Contact an authorised
Malfunction in the pump power
supply.
Injectors are dirty or faulty.
➤ Contact an authorised
workshop.
workshop.
workshop.
“Servicing the air filter” on
page 25).
workshop.
The generator is
running but does
not supply any
voltage.
Inverter is damaged. ➤ Contact an authorised
Power cable is disconnected or
defective.
workshop.
27
EN
Warranty TEC30D EV
Autogoods “130”
130.com.ua
Fault Cause Remedy
The generated
voltage is not
constant.
The battery
charger does not
supply voltage.
Load is over 2.5 kW. ➤ Reduce the consumers.
Air filter is dirty. ➤ Clean the air filter (chapter
“Servicing the air filter” on
page 25).
Inverter is damaged. ➤ Contact an authorised
Power cable is disconnected or
damaged.
Malfunction in the pump power
supply.
Injectors are dirty or faulty.
Battery charger fuse is blown. ➤ Replace the fuse.
workshop.
12 Warranty
The statutory warranty period applies. If the product is defective, please contact the
service partner in your country (addresses on the back on the instruction manual).
Our experts will be happy to help you and will discuss the warranty process with you
in more detail.
13 Disposal
➤ Place the packaging material in the appropriate recycling waste bins wherever
M
B
28
possible.
If you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
Protect the environment!
Do not dispose of any batteries with general household waste.
Return defective or used batteries to your retailer or dispose of them at
collection points.
EN
TEC30D EV Technical data
Autogoods “130”
130.com.ua
14 Technical data
Dometic TEC30D EV
Ref. no.: 9102900033
Rated output voltage: 230 Vw / 50 Hz
Max. constant output
(at 25 °C at sea level):
Battery charger output voltage: 12 Vg
Battery charger max. output current: 10 A
Start battery
Voltage: 12 Vg
Capacity: ≥ 60 Ah
Fuse for system protection: 150 A
Operating temperature range: –15 °C to +50 °C
Fuel: Diesel oil
(acc. EN 590, DIN 51601-DK,
BS 2869 A1/A2, ASTM D975 1D/2D)
Consumption: 0.7 l/h
2500 W
Oil sump capacity: 0.9 l
Motor output: 3.4 kW (4.5 HP)
Engine speed:
Guaranteed sound level: 84 dB(A)
Sound level at distance of 7 m: 59 dB(A)
Insulation class: H
Dimensions: see fig. 8, page 8
Wei ght: 70 kg
Inspection/certification:
3300 min
–1
E
29
Loading...
