Dometic TEC29 EV, TEC29 EV LPG Operating Manual
TEC29 EV, TEC29 EV LPG
Generator
Operating manual . . . . . . . . . . . . . . . . . . . . 10
Generator
Bedienungsanleitung . . . . . . . . . . . . . . . . .33
Générateur
Notice d’utilisation . . . . . . . . . . . . . . . . . . .58
Generador
Instrucciones de uso . . . . . . . . . . . . . . . . . .84
Gerador
Manual de instruções . . . . . . . . . . . . . . . . 110
IGeneratore
Istruzioni per l’uso . . . . . . . . . . . . . . . . . . . 135
Generator
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .159
Generator
Betjeningsvejledning . . . . . . . . . . . . . . . . 183
Generator
Bruksanvisning. . . . . . . . . . . . . . . . . . . . . 206
Generator
Bruksanvisning . . . . . . . . . . . . . . . . . . . . . 229
Generaattori
Käyttöohje . . . . . . . . . . . . . . . . . . . . . . . . . 252
Ƚɟɧɟɪɚɬɨɪ
Инструкция по эксплуатации . . . . . . . . . 275
Generator
Instrukcja obsługi . . . . . . . . . . . . . . . . . . . 301
Generàtor
Návod na obsluhu. . . . . . . . . . . . . . . . . . . 326
Generàtor
Návod k obsluze . . . . . . . . . . . . . . . . . . . . 350
Generátor
Használati utasítás. . . . . . . . . . . . . . . . . . . 373
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
ENERGY & LIGHTING
GENERATORS
TEC29 EV, TEC29 EV LPG
3
TEC29 EV
TEC29 EV LPG
1
3
4
5
2
1
3
4
5
2
1
TEC29 EV, TEC29 EV LPG
4
TEC29 EV TEC29 EV LPG
1
3
4
1
2
2
6 7 8
9
1
2
3
4
5
10
3
TEC29 EV, TEC29 EV LPG
5
1
4
2 3
4
1
2
1
3
5
TEC29 EV, TEC29 EV LPG
6
1
6
4 3 2 1
7
TEC29 EV, TEC29 EV LPG
7
0,7 – 0,8 mm
1
8
360 480
548100160
290
580387
9
TEC29 EV, TEC29 EV LPG
8
0
TEC29 EV, TEC29 EV LPG
9
a
EN
TEC29 EV, TEC29 EV LPG
10
Please read this instruction manual carefully before first use, and store it in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Table of contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
7 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Operating the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
9 Cleaning the generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10 Servicing the generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
12 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
13 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
EN
TEC29 EV, TEC29 EV LPG Explanation of symbols
11
1 Explanation of symbols
!
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Damage to the product resulting from mechanical influences and excess voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
In particular, the manufacturer will not be liable for any consequential damage,
especially consequential damage caused by failure of the generator.
Note the following basic safety information when using electrical devices to protect
against:
• Electric shock
• Fire hazards
• Injury
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
EN
Safety instructions TEC29 EV, TEC29 EV LPG
12
2.1 General safety
!
WARNING!
• Electrical devices are not toys
Keep electrical devices out of reach of children or infirm persons. Do
not allow them to use electrical devices without supervision.
• People (including children) whose physical, sensory or mental
capacities prevent them from using this device safely may not be
allowed to operate it without the supervision of a responsible adult.
• Only use the device as intended.
• Do not make any alterations or conversions to the device.
• Installation, maintenance and repairs of the generator may only be
carried out by qualified personnel who are familiar with the risks
involved when handling generators as well as the relevant regulations.
Inadequate repairs may cause serious hazards. For repair service,
please contact the manufacturer's branch office in your country
(addresses on the back page).
• Exhaust fumes contain carbon monoxide which is a highly toxic,
odourless and colourless gas. Do not inhale any exhaust fumes. Do
not leave the generator motor running in a closed garage or in a room
without windows.
!
CAUTION!
• The generator may only be used with the front door closed.
• Remove all flammable materials such as petrol, paints, solvents, etc.,
from the vicinity of the generator.
• Ensure that hot parts of the generator do not come in contact with any
flammable materials.
• Only refuel the generator when it is switched off and in a well-ventilated area. Petrol and liquid gas are highly flammable and can
explode.
• Do not refuel the generator when the vehicle engine is running if the
tank is in the vicinity of the generator.
• TEC29 EV only: If petrol is spilled, wipe it up properly and wait until
the fumes have cleared before turning on the engine.
• TEC29 EV LPG only: Compare the pressure information on the type
plate with the pressure information on the liquid gas cylinder.
• TEC29 EV LPG only: Never store liquid gas cylinders in unventi-
lated areas or below ground level (funnel shaped holes in the ground).
EN
TEC29 EV, TEC29 EV LPG Target group for this manual
13
• TEC29 EV LPG only: Keep liquid gas cylinders away from direct
sunlight. The temperature may not exceed 50 °C.
• Do not touch the generator and the cables with wet hands.
• Replace the fuses or thermo switch using only those with the same
technical data.
• Do not switch the generator to automatic mode near any ignition
sources (such as petrol stations, dry areas with risk of forest fires).
A
NOTICE!
• TEC29 EV only: Do not fill up the tank too full. Petrol must not be
allowed to fill up to the neck of the tank. Check the lid is on properly.
• If a welding operation has be done on the vehicle disconnect all
generator cables, otherwise the electronics may be damaged.
2.2 Operating the device safely
!
WARNING!
• Always disconnect the power supply when working on the device.
A
NOTICE!
• Only operate the device if you are certain that the housing and the
cables are undamaged.
3 Target group for this manual
This operating manual is for the user of the generator.
EN
Scope of delivery TEC29 EV, TEC29 EV LPG
14
4 Scope of delivery
TEC29 EV
TEC29 EV LPG
5 Accessories
Available as accessories (not included in the scope of delivery):
Designation
Reference
number
TEC29 EV generator 9102900299
AG 102, changeover relay for making priority circuits 9102900013
AG 128, seal for TEC29EV 9102900040
Installation manual
Operating manual
Designation
Reference
number
TEC29 EV LPG generator 9102900302
AG 102, changeover relay for making priority circuits 9102900013
Installation manual
Operating manual
Part designation Item number
AG 101, tank 15 l, plastic 9102900009
AG 100, tank 20 l, stainless steel 9102900011
AG 117, tank 15 l, plastic, with brackets and integrated mouth and cap 9102900010
AG 150, pipe set for AG 100 / AG 101 9102900003
AG 125, flexible metal pipe for extending exhaust pipe, 5 m 9102900138
AG 113, change over switch for parallel connection 9102900015
Parallel cable 9102900296
EN
TEC29 EV, TEC29 EV LPG Intended use
15
6 Intended use
The TEC29 EV (reference no. 9102900299) and TEC 29 EV LPG (reference no.
9102900302) generators are designed for use in motor homes, camper vans and
vehicles for commercial use.
The generator is not suitable for installation in water vessels.
The generator produces a pure sine wave voltage of 230 V/50 Hz which can be
connected to the consumer with a total continuous load of 2600 W. The power
quality is also suitable for sensitive consumers (such as PCs).
The generator can charge a 12 V battery.
7 Technical description
The TEC29 EV and TEC29 EV LPG generators consist of the following main parts
(fig. 1, page 3):
• Combustion engine (1)
• Alternator (2) with permanent magnets
• Inverter (3)
• Internal control panel (4)
• Remote control (5)
The combustion engine (1) drives the alternator (2) connected to it, which in turn
generates AC voltage.
The inverter (3) transforms this AC voltage into a stable voltage of 230 V and 50 Hz.
The terminals, the socket for the connection cable to the remote control (5) and the
main switch are installed in the internal control panel (4).
Overview of the components:
• TEC29 EV: fig. 0, page 8.
• TEC29 EV LPG: fig. a, page 9
The generator has the following features:
• Integrated battery charger for charging the connected battery
• Automatic mode for charging the connected battery automatically (must be
configured accordingly when installed)
EN
Technical description TEC29 EV, TEC29 EV LPG
16
Control elements in the control panel
The control panel is located on the generator behind the cover.
Control elements in the remote control
The remote control is installed in the vehicle interior.
No. in
fig. 2,
page 4
Description
1 Main switch Switches the generator to standby or no
function.
2 TEC29 EV only: Cut-out
switch
Electromechanical protection against overload.
3 TEC29 EV LPG only:
Main fuse
Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
4 TEC29 EV LPG only:
Battery charger fuse
Triggers if the AC voltage overloads. Fuse
needs to be replaced if it has triggered.
No. in
fig. 3,
page 4
Description
1 Display Shows the status reports.
2 On/Off switch P Switches the remote control on and off if the
main switch is at “I” or “1”.
Stops the generator.
3 START button Starts the generator if the remote control is
switched on and the main switch is at “I” or
“1”.
4 TEC29 EV only:
Petrol gauge
Lights up if the petrol goes into reserve.
5 Oil gauge Lights up if the oil level is too low in the
engine.
EN
TEC29 EV, TEC29 EV LPG Operating the generator
17
Displays
8 Operating the generator
A
I
8.1 Basic notes on operation
!
Please note the following basic information:
• Always check the oil level before use (chapter “Checking the oil level” on
page 21).
• TEC29 EV LPG only: Check there are no leaks from the gas supply using a leak
detection spray before every use.
• Even small overloads in the long-run will cause the cut-out switch (TEC29 EV) or
the fuses (TEC29 EV LPG) to trigger.
No. in
fig. 3,
page 4
Description
6 AC supply Actual voltage output
7 Constant output Current capacity of connected consumer
8 Operating hours Time the generator is in operation
9 DC voltage Battery voltage
10 Messages Status reports of the generator (see chapter
“Display messages” on page 19)
NOTICE!
Do not run the generator over 70 % of the maximum constant output for
the first 50 operating hours (run-in phase).
NOTE
Run the generator at a maximum of approx. 75 % of the maximum
continuous load after the run-in phase.
By doing this you can prolong the service life of the generator and
maximise its efficiency.
CAUTION! Beware of injury
Do not insert your fingers or objects into the air nozzles or the intake
grille.
Loading...
