Dometic CC32, CC40 Operating Manual
ENFRES
PORTABLE REFRIGERATION
POWERED BOXES
CC32, CC 40
Compressor Cooler
Operating manual . . . . . . . . . . . . . . . . . . . . . 5
Glacière à compression
Notice d’utilisation . . . . . . . . . . . . . . . . . . .20
Nevera por compresor
Instrucciones de uso . . . . . . . . . . . . . . . . . .36
CC32, CC40 AC/DC
1
2
ON
OFF
DOWNUP
SET
POWER
+
–
ERROR
°
1 3 4 5 6 72
3
100-240V~AC 12/24V DC
1 2 43 5
1
3
CC32, CC40 AC/DC
2.
1.
A B
C
1.
1.
2.
2.
4
4
EN
CC32, CC40 AC/DC
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1 General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2 Operating the device safely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 Function description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5.1 Scope of functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5.2 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1 Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.2 Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.3 Connecting the cooling device . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6.4 Using the battery monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.5 Using the cooling device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
6.6 Latching the cooling device lid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6.7 Setting the temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6.8 Switching off the cooling device . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6.9 Defrosting the cooling device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6.10 Replacing the fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8Guarantee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
9Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5
EN
Explanation of symbols CC32, CC40 AC/DC
1 Explanation of symbols
WARNING!
!
!
A
I
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
2 Safety instructions
2.1 General safety
!
6
WARNING!
• Do not operate the device if it is visibly damaged.
• If this device's power cable is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
• This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
• This device can be used by children aged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
• Cleaning and user maintenance must not be carried out by children
without supervision.
• Children must not play with the device.
EN
CC32, CC40 AC/DC Safety instructions
• Children must be supervised to ensure that they do not play with the
device.
• Always keep and use the device out of the reach of children under the
age of 8 years.
• Do not store any explosive substances such as spray cans with a flammable propellant in the device.
CAUTION!
!
A
• Disconnect the device from the power supply
– before each cleaning and maintenance
– after every use
• Food may only be stored in its original packaging or in suitable containers.
• Do not use an extension cord.
NOTICE!
• Check that the voltage specification on the type plate corresponds to
that of the energy supply.
• Only connect the device as follows:
– With the DC cable to a DC plug socket in the vehicle (e. g. ciga-
rette lighter)
– Or with the 120 V connection cable to the 120 V AC mains supply
• Never pull the plug out of the socket by the cable.
• If the cooler is connected to the DC socket: Disconnect the cooler and
other power consuming devices from the battery before connecting
the quick charging device.
• If the cooler is connected to the DC socket: Disconnect the cooler or
switch it off when you turn off the engine. Otherwise you may discharge the battery.
• The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
• The cooling device contains inflammable cyclopentane in the insulation. The gases in the insulation material require special disposal procedures. Deliver the device at the end of its life-cycle to an appropriate
recycling.
7
EN
Scope of delivery CC32, CC40 AC/DC
2.2 Operating the device safely
CAUTION!
!
A
• Before starting the device, ensure that the power supply line and the
plug are dry.
NOTICE!
• Do not use electrical devices inside the cooler unless they are recommended by the manufacturer for the purpose.
• Do not place the device near open flames or other heat sources (heaters, direct sunlight, gas ovens etc.).
• Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat that
arises during operation does not build up. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
• Ensure that the ventilation openings are not covered.
• Do not fill the inner container with ice or fluid.
• Never immerse the device in water.
• Protect the device and the cable against heat and moisture.
3Scope of delivery
Quantity Description
1 Compressor cooler
1 DC connection cable
1 AC connection cable
1 Operating manual
8
EN
CC32, CC40 AC/DC Intended use
4 Intended use
The compressor cooler is suitable for cooling and freezing foods. The compressor
cooler is also suitable for use on boats.
The compressor cooler is designed to be operated from a DC power supply socket
of a vehicle, boat or RV or from an AC mains.
CAUTION! Health hazard!
!
Please check if the cooling capacity of the cooling device is suitable for
storing the food or medicine you wish to cool.
5 Function description
The cooling device can chill products, keep them cool as well as freeze them.
A low maintenance refrigerant circuit with compressor provides the cooling. The
foamed in place insulation and compact compressor ensure optimum cooling.
The cooling device is portable.
When used on boats, the cooling device can withstand a constant incline of 30°.
5.1 Scope of functions
• Three-level battery monitor to protect the vehicle battery
• Display with temperature gauge switches off automatically at low battery voltage
• Temperature setting: With two buttons in steps of 1 °C (2 °F)
9
EN
Function description CC32, CC40 AC/DC
5.2 Operating and display elements
Latch for lid: fig. 1 1, page 2
Operating panel (fig. 2, page 2)
Item Description Explanation
1ON
OFF
2 POWER Status indication
3 ERROR LED flashes red: Cooling device is switched on but
4 SET Selects the input mode
5 – Display, shows the information
6 “+” Press once to increase the value
7 “–” Press once to decrease the value
Switches the cooling device on or off when the button is
pressed for between one and two seconds
LED lights up green: Compressor is on
LED lights up orange: Compressor is off
LED flashes orange: Display switched off automatically
due to low battery voltage
not ready for operation
– Temperature setting
– Celsius or Fahrenheit display
– Set battery monitor
Connectors (fig. 3, page 2)
Item Description
1 AC socket
2Fuse holder
3 Cover AC socket
4 Cover DC socket
5 DC socket
10
EN
CC32, CC40 AC/DC Operation
6Operation
6.1 Before initial use
NOTE
I
Selecting the temperature units
You can switch the temperature display between Celsius and Fahrenheit. Proceed as
follows:
➤ Switch on the cooling device.
➤ Press the “SET” button twice.
➤ Use the “+” and “–” buttons to select Celsius or Fahrenheit.
✓ The selected temperature units then appear in the display for a few seconds. The
display flashes several times before it returns to the current temperature.
Before starting your new cooling device for the first time, you should
clean it inside and outside with a damp cloth for hygienic reasons
(please also refer to the chapter “Cleaning and maintenance” on
page 16).
6.2 Energy saving tips
• Choose a well ventilated installation location which is protected against direct
sunlight.
• Allow warm food to cool down first before placing it in the cooling device to
keep cool.
• Do not open the cooling device more often than necessary.
• Do not leave the cooling device open for longer than necessary.
• Defrost the cooling device once a layer of ice forms.
• Avoid unnecessarily low temperatures.
11
EN
Operation CC32, CC40 AC/DC
6.3 Connecting the cooling device
The cooling device can be operated with DC or AC voltage.
NOTICE! Danger of damage!
A
For safety reasons the cooling device is equipped with an electronic system to prevent the polarity reversal. This protects the cooling device against short-circuiting
when connecting to a battery.
➤ Plug the DC connection cable into the DC socket and connect it to a DC power
socket or …
➤ … plug the AC connection cable into the AC voltage socket and connect it to an
AC mains.
➤ Close the covers of the sockets not in use to prevent accidentally touching the
sockets. This also prevents dust, water and dirt from entering the socket.
Disconnect the cooling device and other consumer units from the vehicle battery before you connect the vehicle battery to a quick charging
device.
Overvoltage can damage the electronics of the cooling device.
6.4 Using the battery monitor
The cooling device is equipped with a multi-level battery monitor that protects your
vehicle battery against excessive discharging when the cooling device is connected
to the DC power supply.
If the cooling device is operated when the vehicle ignition is switched off, the cooling device switches off automatically as soon as the supply voltage falls below a set
level. The cooling device will switch back on once the vehicle battery has been
recharged to the restart voltage level.
NOTICE! Danger of damage!
A
When switched off by the battery monitor, the vehicle battery will no
longer be fully charged. Avoid starting repeatedly or operating current
consumers without longer charging phases. Ensure that the vehicle battery is recharged.
12
EN
CC32, CC40 AC/DC Operation
In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and
“MED” (see the following table).
Battery monitor mode LOW MED HIGH
Switch-off voltage at 12 V
Restartvoltage at 12 V
Switch-off voltage at 24 V
Restart voltage at 24 V
Proceed as follows to select the battery monitor mode:
➤ Switch on the cooling device.
➤ Press the “SET” button three times.
➤ Use the “+” and “–” buttons to select the battery monitor mode.
✓ The selected mode then appears in the display for a few seconds. The display
flashes several times before it returns to the current temperature.
NOTE
I
When the cooling device is supplied by the vehicle battery, select the
battery monitor mode “HIGH”. If the cooling device is connected to a
supply battery, the battery monitor mode “LOW” will suffice.
10.1 V 11.4 V 11.8 V
11.1 V 12.2 V 12.6 V
21.5 V 24.1 V 24.6 V
23.0 V 25.3 V 26.2 V
6.5 Using the cooling device
NOTICE! Danger of overheating!
A
➤ Place the cooling device on a firm foundation.
I
➤ Connect the cooling device, see chapter “Connecting the cooling device” on
page 12.
Ensure at all times that there is sufficient ventilation so that the heat that
generated during operation can dissipate. Ensure that the ventilation
slots are not covered. Make sure that the cooling device is sufficiently far
away from walls and other objects so that the air can circulate.
NOTE
Place the cooling device as shown (fig. 1, page 2). If you operate the
cooling device in a different position it can be damaged.
13
EN
Operation CC32, CC40 AC/DC
NOTICE! Danger from excessively low temperature!
A
➤ Press the “ON/OFF” button for between one and two seconds.
✓ The “POWER” LED lights up.
✓ The display switches on and shows the current cooling temperature.
I
✓ The cooling device starts cooling the interior.
I
6.6 Latching the cooling device lid
➤ Lift the latch (fig. 1 1, page 2) and close the lid.
Ensure that only those objects are placed in the cooling device that are
intended to be cooled at the selected temperature.
NOTE
The temperature displayed is that of the middle of the interior.
The temperatures elsewhere can deviate from this temperature.
NOTE
When operating with the battery, the display switches off automatically
if the battery voltage is low. The “POWER” LED flashes orange.
➤ Release the latch.
✓ The latch audibly clicks in place and secures the cooling device lid.
6.7 Setting the temperature
➤ Press the “SET” button once.
➤ Use the “+” and “–” buttons to select the cooling temperature.
✓ The cooling temperature appears in the display for a few seconds. The display
flashes several times and then the current temperature is displayed again.
14
EN
CC32, CC40 AC/DC Operation
6.8 Switching off the cooling device
➤ Empty the cooling device.
➤ Switch the cooling device off.
➤ Pull out the connection cable.
If you do not want to use the cooling device for a longer period of time:
➤ Leave the lid slightly open. This prevents odor build-up.
6.9 Defrosting the cooling device
Humidity can form frost in the interior of the cooling device or on the evaporator. This
reduces the cooling capacity. Defrost the cooling device in good time to avoid this.
NOTICE! Danger of damage!
A
To defrost the cooling device, proceed as follows:
➤ Take out the contents of the cooling device.
Never use hard or pointed tools to remove ice or to loosen objects
which have frozen in place.
➤ If necessary, place them in another cooling device to keep them cool.
➤ Switch off the cooling device.
➤ Leave the lid open.
➤ Wipe off the defrosted water.
6.10 Replacing the fuse
➤ Replace the fuse (8 A 32 V) as shown (fig. 4, page 3).
15
EN
Cleaning and maintenance CC32, CC40 AC/DC
7 Cleaning and maintenance
WARNING!
!
A
➤ Occasionally clean the device interior and exterior with a damp cloth.
➤ Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
Always disconnect the device from the power supply before you clean
and service it.
NOTICE! Risk of damage
• Never clean the cooler under running water or in dish water.
• Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooler.
8Guarantee
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please include the following documents when
you send in the device:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
16
Loading...
