D Link SL2740RA1 Users Manual

FCC Notices

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION: Change or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.

RF exposure warning:

The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter.

FCC

Federal Communication Commission Interference Statement

− Reorient or relocate the receiving antenna.

− Increase the separation between the equipment and receiver.

− Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

− Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE: FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.

D-Link DSL-2740R User Manual

Table of Contents

PACKAGE CONTENTS .......................................................................................... 1

SYSTEM REQUIREMENTS ..................................................................................... 1

FEATURES .......................................................................................................... 2

HARDWARE OVERVIEW........................................................................................ 3

Connections ................................................................................................. 3

LEDs............................................................................................................. 4

INSTALLATION .................................................................................................... 6

BEFORE YOU BEGIN............................................................................................ 6

INSTALLATION NOTES .......................................................................................... 6

DEVICE INSTALLATION ....................................................................................... 10

Power on Router .........................................................................................11

Factory Reset Button...................................................................................11

Network Connections ................................................................................. 12

SETUP ................................................................................................................ 13

Web-based Configuration Utility................................................................. 13

QUICK SETUP ................................................................................................... 14

ADSL SETUP ................................................................................................... 21

PPPoE/PPPoA ........................................................................................... 22

Dynamic IP Address ................................................................................... 23

Static IP Address ........................................................................................ 24

Bridge Mode ............................................................................................... 25

WIRELESS SETUP ............................................................................................. 26

WEP ........................................................................................................... 27

WPA-Personal ............................................................................................ 28

LAN SETUP...................................................................................................... 29

Use the Router for DHCP........................................................................... 30

Disable the DHCP Server........................................................................... 30

TIME AND DAT E ................................................................................................. 31

ADVANCED ........................................................................................................ 32

PORT FORWARDING .......................................................................................... 32

QOS SETUP ..................................................................................................... 33

Wireless QoS ............................................................................................. 34

LAN QoS .................................................................................................... 35

OUTBOUND FILTER............................................................................................ 36

INBOUND FILTER................................................................................................ 37

DNS SETUP ..................................................................................................... 38

VLAN............................................................................................................... 40

FIREWALL & DMZ ............................................................................................. 41

ADVANCED ADSL.............................................................................................. 42

ADVANCED WIRELESS ....................................................................................... 43

ADVANCED LAN................................................................................................ 44

REMOTE MANAGEMENT .....................................................................................45

NETWORK TOOLS.............................................................................................. 46

MAINTENANCE.................................................................................................. 47

PASSWORD ....................................................................................................... 47

SAVE /RESTORE SETTINGS................................................................................. 48

FIRMWARE UPDATE ........................................................................................... 49

DIAGNOSTICS .................................................................................................... 50

SYSTEM LOG..................................................................................................... 51

STATUS............................................................................................................... 52

DEVICE INFO ..................................................................................................... 52

CONNECTED CLIENTS ........................................................................................ 53

STATI STIC S ....................................................................................................... 54

HELP ................................................................................................................... 55

TROUBLESHOOTING........................................................................................ 56

NETWORKING BASICS..................................................................................... 58

CHECK YOUR IP ADDRESS................................................................................. 58

STATI CALLY ASSIGN AN IP ADDRESS .................................................................. 59

TECHNICAL SPECIFICATIONS......................................................................... 60

D-Link DSL-2740R User Manual

Section 1 - Product Overview

Package Contents

• DSL-2740R Wireless N ADSL2+ Modem Router

• Power Adapter

• CD-ROM with User Manual

• One twisted-pair telephone cable used for ADSL connection

• One straight-through Ethernet cable

• One Quick Installation Guide

Warning: The Router must be used with the power adapter included with the device.

System Requirements

• ADSL Internet service

• Computer with:

• 200MHz Processor

• 64MB Memory

• CD-ROM Drive

• Ethernet Adapter with TCP/IP Protocol Installed

• Internet Explorer v6 or later, FireFox v1.5, or Safari 1.3 or above

• Windows 2000/XP/Vista

• D-Link Click'n Connect Utility

D-Link DSL-2740R User Manual

Section 1 - Product Overview

Features

• PPP (Point-to-Point Protocol) Security – The Router supports PAP (Password Authentication Protocol) and CHAP (Challenge Handshake Authentication Protocol) for PPP connections. The Router also supports MSCHAP.

• DHCP Support – Dynamic Host Configuration Protocol automatically and dynamically assigns all LAN IP settings to each host on your network. This eliminates the need to reconfigure every host whenever changes in network topology occur.

• Network Address Translation (NAT) – For small office environments, the Router allows multiple users on the LAN to access the Internet concurrently through a single Internet account. This provides Internet access to everyone in the office for the price of a single user. NAT improves network security in effect by hiding the private network behind one global and visible IP address. NAT address mapping can also be used to link two IP domains via a LAN-to-LAN connection.

• TCP/IP (Transfer Control Protocol/Internet Protocol) – The Router supports TCP/IP protocol, the language used for the Internet. It is compatible with access servers manufactured by major vendors.

• RIP-1/RIP-2 – The Router supports both RIP-1 and RIP-2 exchanges with other routers. Using both versions lets the Router to communicate with all RIP enabled devices.

• Static Routing – This allows you to select a data path to a particular network destination that will remain in the routing table and never “age out”. If you wish to define a specific route that will always be used for data traffic from your LAN to a specific destination within your LAN (for example to another router or a server) or outside your network (to an ISP defined default gateway for instance).

• Default Routing – This allows you to choose a default path for incoming data packets for which the destination address is unknown. This is particularly useful when/if the Router functions as the sole connection to the Internet.

• ATM (Asynchronous Transfer Mode) – The Router supports Bridged Ethernet over ATM (RFC1483), IP over ATM (RFC1577), and PPP over ATM (RFC 2364).

• Precise ATM Traffic Shaping – Traffic shaping is a method of controlling the flow rate of ATM data cells. This function helps to establish the Quality of Service for ATM data transfer.

• High Performance – Very high rates of data transfer are possible with the Router. Up to 8 Mbps downstream bit rate using the G.dmt standard.

• Full Network Management – The Router incorporates SNMP (Simple Network Management Protocol) support for web-based management and text-based network management via an RS-232 or Telnet connection.

• Telnet Connection – The Telnet enables a network manager to access the Router’s management software remotely.

• Easy Installation – The Router uses a web-based graphical user interface program for convenient management access and easy set up.

Any common web browser software can be used to manage the Router.

D-Link DSL-2740R User Manual

Section 1 - Product Overview

Hardware Overview

Connections

Antennas

Ethernet Ports

Use the Ethernet ports to connect the Router to a compute or an Ethernet LAN.

Power Button

Push in to power-on the Router. Push again to power-off the Router.

ADSL Port

Use the ADSL cable to connect to the your telephone line (RJ-11 port).

D-Link DSL-2740R User Manual

Reset Button

To manually reset, depress button with the power on for at least seven seconds.

Power Insert

Use the adapter shipped with the Router to connect to power source.

Section 1 - Product Overview

Hardware Overview

LEDs

LED Description

Power A steady green light indicates the unit is powered on. When the device is powered off this remains dark. Lights steady green during

power on self-test (POST). Once the connection status has been settled, the light will blink green. If the indicator lights steady red after the POST, the system has failed and the device should be rebooted.

LAN A solid green light indicates a valid link on startup. This light will blink when there is activity currently passing through the Ethernet

port.

WLAN A solid green light indicates a valid link on startup. This light will blink when there is activity currently passing through the Wireless

LAN.

DSL A steady green light indicates a valid ADSL connection. This will light after the ADSL negotiation process has been settled. A

blinking green light indicates activity on the WAN (ADSL) interface.

D-Link DSL-2740R User Manual

Section 1 - Product Overview

Internet A solid green light indicates the WAN IP address from IPCP or DHCP and DSL is up or a static IP address is configured and PPP

negotiation has been successfully completed. If the indicator blinks green, this means the Router is active. If the Router power is off, this remains dark. A solid red light indicates there is no DHCP response, no PPPoE response, PPPoE authentication has failed, and/or there is no IP.

D-Link DSL-2740R User Manual

Section 2 – Installation

Installation

This section will walk you through the installation process. Placement of the Router is very important. Do not place the Router in an enclosed area such as a closet, cabinet, or in the attic or garage.

Before You Begin

Please read and make sure you understand all the prerequisites for proper installation of your new Router. Have all the necessary information and equipment on hand before beginning the installation.

Installation Notes

In order to establish a connection to the Internet it will be necessary to provide information to the Router that will be stored in its memory. For some users, only their account information (Username and Password) is required. For others, various parameters that control and define the Internet connection will be required. You can print out the two pages below and use the tables to list this information. This way you have a hard copy of all the information needed to setup the Router. If it is necessary to reconfigure the device, all the necessary information can be easily accessed. Be sure to keep this information safe and private.

Low Pass Filters

Since ADSL and telephone services share the same copper wiring to carry their respective signals, a filtering mechanism may be necessary to avoid mutual interference. A low pass filter device can be installed for each telephone that shares the line with the ADSL line. These filters are easy to install passive devices that connect to the ADSL device and/or telephone using standard telephone cable. Ask your service provider for more information about the use of low pass filters with your installation.

Operating Systems

The DSL-2740R uses an HTML-based web interface for setup and management. The Web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, Windows XP, and Windows Vista.

D-Link DSL-2740R User Manual

Section 2 – Installation

Web Browser

Any common Web browser can be used to configure the Router using the Web configuration management software. The program is designed to work best with more recently released browsers such as Opera, Microsoft Internet Explorer® version 6.0, Netscape Navigator® version 6.2.3, or later versions. The Web browser must have JavaScript enabled. JavaScript is enabled by default on many browsers. Make sure JavaScript has not been disabled by other software (such as virus protection or web user security packages) that may be running on your computer.

Ethernet Port (NIC Adapter)

Any computer that uses the Router must be able to connect to it through the Ethernet port on the Router. This connection is an Ethernet connection and therefore requires that your computer be equipped with an Ethernet port as well. Most notebook computers are now sold with an Ethernet port already installed. Likewise, most fully assembled desktop computers come with an Ethernet NIC adapter as standard equipment. If your computer does not have an Ethernet port, you must install an Ethernet NIC adapter before you can use the Router. If you must install an adapter, follow the installation instructions that come with the Ethernet NIC adapter.

Additional Software

It may be necessary to install software on your computer that enables the computer to access the Internet. Additional software must be installed if you are using the device a simple bridge. For a bridged connection, the information needed to make and maintain the Internet connection is stored on another computer or gateway device, not in the Router itself.

If your ADSL service is delivered through a PPPoE or PPPoA connection, the information needed to establish and maintain the Internet connection can be stored in the Router. In this case, it is not necessary to install software on your computer. It may however be necessary to change some settings in the device, including account information used to identify and verify the connection.

All connections to the Internet require a unique global IP address. For bridged connections, the global IP settings must reside in a TCP/IP enabled device on the LAN side of the bridge, such as a PC, a server, a gateway device such as a router or similar firewall hardware. The IP address can be assigned in a number of ways. Your network service provider will give you instructions about any additional connection software or NIC configuration that may be required.

D-Link DSL-2740R User Manual
