D Link IR860LB1 User Manual

Version 2.00| 08/07/2014
User Manual
Wireless AC1200 Dual Band Gigabit Cloud Router
DIR-860L
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes.
Manual Revisions
Revision Date Description
2.00 August 07, 2014 • Initial release for hardware revision B1
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Copyright © 2014 by D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation.
iD-Link DIR-860L User Manual
Table of Contents
Table of Contents
Product Overview .............................................................. 1
Package Contents .........................................................................1
System Requirements .................................................................2
Introduction ...................................................................................3
Features ............................................................................................4
Hardware Overview .....................................................................5
Front View ................................................................................5
Back View .................................................................................6
Installation ......................................................................... 7
Before you Begin ...........................................................................7
Wireless Installation Considerations ......................................8
Manual Setup .................................................................................9
Getting Started ................................................................ 11
Setup Wizard ................................................................................12
QRS Mobile App ..........................................................................17
mydlink™ SharePort ...................................................................22
Using the mydlink™ SharePort app for iPad®,
iPhone®, and iPod touch® ................................................22
Main Menu ............................................................................27
Documents ............................................................................28
Pictures ...................................................................................30
Videos .....................................................................................32
Music .......................................................................................34
Folders ....................................................................................37
Favorites .................................................................................40
Using the mydlink™ SharePort app for Android™ ...41
Main Menu ............................................................................46
Documents ............................................................................47
Pictures ...................................................................................49
Videos .....................................................................................51
Music .......................................................................................53
Folders ....................................................................................56
Favorites .................................................................................60
Using SharePort Web Access ..................................................61
Music .......................................................................................63
Pictures ...................................................................................64
Videos .....................................................................................65
Documents ............................................................................66
Conguration ...................................................................67
Home ..............................................................................................68
Internet ...................................................................................68
DIR-860L .................................................................................69
Connected Clients ..............................................................70
USB Device ............................................................................71
Settings ..........................................................................................72
Wizard .....................................................................................72
Internet ...................................................................................72
IPv6 .....................................................................................81
Wireless ..................................................................................96
Guest Zone .......................................................................98
Network ..................................................................................99
iiD-Link DIR-860L User Manual
Table of Contents
SharePort ............................................................................ 101
Create User .................................................................... 102
mydlink ................................................................................ 103
Features .......................................................................................104
QoS Engine.........................................................................104
Firewall Settings ............................................................... 105
IPv4/IPv6 Rules ............................................................107
Port Forwarding ............................................................... 108
Virtual Server ................................................................ 109
Website Filter ..................................................................... 110
Static Routes ......................................................................111
IPv6 ..................................................................................112
Dynamic DNS .................................................................... 113
IPv6 Host ........................................................................ 114
Management ............................................................................. 115
Time & Schedule ..............................................................115
Time ................................................................................. 115
Schedule ........................................................................116
System Log ......................................................................... 117
Windows® 7 ................................................................................125
WPA/WPA2 ......................................................................... 125
WPS .......................................................................................128
Windows Vista® .........................................................................132
WPA/WPA2 ......................................................................... 133
Windows® XP ............................................................................. 135
WPA/WPA2 ......................................................................... 136
Troubleshooting ............................................................138
Wireless Basics ...............................................................142
What is Wireless? ...................................................................... 143
Tips ................................................................................................145
Wireless Modes .........................................................................146
Networking Basics .........................................................147
Check your IP address ............................................................147
Statically Assign an IP address ............................................148
Wireless Security ......................................................... 149
What is WPA? ................................................................149
Admin ..................................................................................118
System ............................................................................119
Upgrade .............................................................................. 120
Statistics .............................................................................. 121
Connect a Wireless Client to your Router ....................122
WPS Button ................................................................................122
Windows® 8 ................................................................................123
WPA/WPA2 ......................................................................... 123
Technical Specications ................................................150
Warranty .........................................................................151
iiiD-Link DIR-860L User Manual
Section 1 - Product Overview
DIR-860L Wireless AC1200 Dual Band Gigabit Cloud Router
Ethernet Cable
Power Adapter

Product Overview

Package Contents

Wi-Fi Conguration Note
Wi-Fi Conguration Card
CD-ROM
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage rating than the one included with the DIR-860L will cause damage and void the warranty for this product.
1D-Link DIR-860L User Manual
Section 1 - Product Overview

System Requirements

Network Requirements
Web-based Conguration
Utility Requirements
mydlink Requirements
• An Ethernet-based cable or DSL modem
• 802.11ac, n, g, b, or a wireless or Ethernet port
Computer with the following:
• Windows®, Macintosh, or Linux-based operating system
• An installed Ethernet adapter
Browser Requirements:
• Internet Explorer 8 or higher
• Firefox 12 or higher
• Safari 4 or higher
• Chrome 20 or higher
Windows
installed. Visit www.java.com to download the latest version.
• iPhone/iPad/iPod touch (iOS 6.0 or higher)
• Android device (2.3.3 or higher)
• Computer with the following browser requirements:
®
Users: Make sure you have the latest version of Java
• Internet Explorer 8 or higher
• Firefox 12 or higher
• Safari 4 or higher
• Chrome 20 or higher
iPhone, iPad, and iPod touch are registered trademarks of Apple Inc. Android is a trademark of Google, Inc.
2D-Link DIR-860L User Manual
Section 1 - Product Overview

Introduction

The D-Link DIR-860L Wireless AC1200 Dual Band Gigabit Cloud Router shares your Internet connection over a blazing-fast Wireless AC connection. It also comes equipped with four Gigabit ports to provide speeds up to 10x faster than standard 10/100 ports. With the addition of Quality of Service (QoS), you can organize and prioritize separate data streams for your network trac so your video streaming, gaming, and VoIP calls run smoother over both your wired and wireless network.
The DIR-860L supports a host of cloud features including QRS Mobile, which allows you to setup and congure the router using a mobile app. You can set up your router right from your sofa, no PC required.
The Wireless AC1200 Dual Band Gigabit Cloud Router is also mydlink-enabled, which gives you access to your home network no matter where you go. Now you can monitor and manage your home network right from your laptop, iPhone®, iPad®, or Android™ device. mydlink-enabled routers can be congured to send an email to keep you informed anywhere, anytime when new devices are connecting to your network or unwanted access is detected. Monitor in real-time websites that are being visited with recent browser history displayed on the mydlink™ Lite app – which is great for parents.
SharePort technology lets you take advantage of the USB port found on the back of your DIR-860L. Plug in a USB storage drive and you can use the mydlink™ SharePort app for iPad®, iPhone®, iPod touch®, and Android™ device to access les, stream videos, view photos, or listen to music on your laptop or mobile devices.
The DIR-860L Wireless AC1200 Dual Band Gigabit Cloud Router provides incredible wireless speeds, fast Gigabit Ethernet ports, cloud features, and terric security features. Its compact design stays out of your way, and installation is easy and fast.
3D-Link DIR-860L User Manual
Section 1 - Product Overview

Features

• Faster Wireless Networking - The DIR-860L Wireless AC technology provides a wireless connection with speeds
*
of up to 1200 Mbps and 5 GHz bands to allow separation of trac so users can participate in high-bandwidth activities, such as video streaming, online gaming, and real-time audio, without aecting low-priority trac like email and web surng.
• Cloud Features - The DIR-860L supports the QRS Mobile app to setup the router using a mobile device. It is also mydlink-enabled so you can remotely access and manage your DIR-860L from a mobile device. The mydlink™ SharePort app can be used to share les, stream videos, view photos, and play music, and SharePort Plus lets you share a printer.
• Compatible with 802.11n/g/b/a Devices - The DIR-860L is still fully compatible with IEEE 802.11n, 802.11g and
802.11a standards, so it can connect with existing 802.11n, 802.11g, 802.11b, and 802.11a wireless devices.
• Advanced Firewall Features - The web-based user interface displays a number of advanced network management features including:
with concurrent 801.11ac and 802.11n wireless clients . It also operates on both the 2.4 GHz
Content Filtering - Easily applied content ltering based on MAC address, URL, and/or domain name.
Filter Scheduling - These lters can be scheduled to be active on certain days, or for a duration of hours or minutes.
Secure Multiple/Concurrent Sessions - The DIR-860L can pass through VPN sessions. It supports multiple and concurrent IPSec and PPTP sessions, so users behind the DIR-860L can securely access corporate networks.
• User-friendly Setup Wizard - Through its easy-to-use web-based user interface, the DIR-860L lets you control what information is accessible to those on the wireless network, whether from the Internet, or from your company’s server. Congure your router to your specic settings within minutes.
* Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11b, 802.11g, 802.11n, and 802.11ac specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.
4D-Link DIR-860L User Manual
Section 1 - Product Overview

Hardware Overview

Front View

1 Power LED
2 Internet LED
1
2
A solid green light indicates a proper connection to the power supply. The light will be a solid orange during boot up.
A solid green light indicates connection on the Internet port. If the LED is orange, the connection is good but the router cannot connect to the Internet.
5D-Link DIR-860L User Manual
Section 1 - Product Overview

Back View

1
2
3
4
5
6
7
1 WPS Button Press to start the WPS process and automatically create a secure connection to a WPS client.
2 Gigabit LAN Ports (1-4) Connect Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
3 Gigabit Internet Port Using an Ethernet cable, connect your broadband modem to this port. 4 USB 3.0 Port Connect a USB ash drive to share content , or connect it to a USB printer to share it on your network. 5 Power Button Press the power button to power on and o. 6 Power Receptor Receptor for the supplied power adapter. 7 Reset Button Insert a paperclip in the hole and wait several seconds to reset the router to default settings.
6D-Link DIR-860L User Manual
Section 2 - Installation

Installation

This section will walk you through the installation process. Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet, or in the attic or garage.

Before you Begin

• Please congure the router with the computer that was last connected directly to your modem.
• You can only use the Ethernet port on your modem. If you were using the USB connection before using the router, then you must turn o your modem, disconnect the USB cable and connect an Ethernet cable to the Internet port on the router, and then turn the modem back on. In some cases, you may need to call your ISP to change connection types (USB to Ethernet).
• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.
7D-Link DIR-860L User Manual
Section 2 - Installation

Wireless Installation Considerations

The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum ­each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (0.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.
5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4 GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone is not in use.
8D-Link DIR-860L User Manual
Section 2 - Installation

Manual Setup

1. Turn o and unplug your cable or DSL broadband modem. This is required.
Modem
2. Position your router close to your modem and a computer. Place the router in an open area of your intended
work area for better wireless coverage.
3. Unplug the Ethernet cable from your modem (or existing router if upgrading) that is connected to your computer.
Plug it into the LAN port labeled 1 on the back of your router. The router is now connected to your computer.
Computer
4
DIR-860L
9D-Link DIR-860L User Manual
Section 2 - Installation
4. Plug one end of the included Ethernet cable that came with your router into the yellow port labeled INTERNET
on the back of the router. Plug the other end of this cable into the Ethernet port on your modem.
4
Modem
Computer
DIR-860L
INTERNET
5. Reconnect the power adapter to your cable or DSL broadband modem and wait for two minutes.
6. Connect the supplied power adapter into the power receptor on the back of the router and then plug it into a
power outlet or surge protector. Press the power button and verify that the power LED is lit. Allow 1 minute for the router to boot up.
4
Computer
Modem
INTERNET
DIR-860L
7. If you are connecting to a broadband service, you may be online already and further conguration will be optional.
10D-Link DIR-860L User Manual
Section 3 - Getting Started

Getting Started

There are several dierent ways you can congure your router to connect to the Internet and connect to your clients:
D-Link Setup Wizard - This wizard will launch when you log into the router for the rst time. Refer to Setup Wizard on page 12.
QRS Mobile App - Use your iPhone, iPad, or iPod touch to congure your router. Refer to QRS Mobile App on page 17.
Manual Setup - Log into the router and manually congure your router. Refer to Conguration on page 67
11D-Link DIR-860L User Manual
Section 3 - Getting Started

Setup Wizard

If this is your rst time installing the router, open your web browser and enter http://dlinkrouter.local./ in the address bar. Alternatively, enter the IP address of the router (default: http://192.168.0.1). Please refer to Conguration on page 67.
The wizard is designed to guide you through a step-by-step process to congure your new D-Link router and connect to the Internet.
Click Next to continue.
Please wait while your router detects your Internet connection type. If the router detects your Internet connection, you may need to enter your ISP information such as username and password.
12D-Link DIR-860L User Manual
Section 3 - Getting Started
If the router does not detect a valid Internet connection, a list of connection types to choose from will be displayed.
Select your Internet connection type (this information can be obtained from your Internet service provider) and click Next to continue.
If the router detected or you selected PPPoE, enter your PPPoE username and password and click Next to continue.
Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.
If the router detected or you selected Static, enter the IP and DNS settings supplied by your ISP. Click Next to continue.
13D-Link DIR-860L User Manual
Section 3 - Getting Started
For both the 2.4 GHz and 5 GHz segments, create a Wi-Fi network name (SSID) using up to 32 characters.
Create a Wi-Fi password (between 8-63 characters). Your wireless clients will need to have this passphrase or key entered to be able to connect to your wireless network.
Click Next to continue.
In order to secure the router, please enter a new password. You will be prompted for this password every time you want to use the router’s web conguration utility. Click Next to continue.
The Summary window will display your settings. Click Next if you are satised, or click Back to make changes to them.
14D-Link DIR-860L User Manual
Section 3 - Getting Started
To use the mydlink service (www.mydlink.com or the mydlink Lite app), you must have an account. Select Yes if you have a mydlink account already, or No if you want to create one. Click Next to continue.
If you do not want to register at this time, click Skip.
If you clicked Yes, enter your mydlink account name (email address) and password. Click Next to register your mydlink account with the router.
If you clicked No, ll out the requested information and click Next to create your mydlink account.
At the end of the wizard, you will be presented with a nal summary of your settings. Click Finish to close the wizard.
15D-Link DIR-860L User Manual
Section 3 - Getting Started
The mydlink Lite app will allow you to receive notices, browse network users, and congure your router from an iPhone/iPad/iPod touch (iOS
3.0 or higher), or Android device (1.6 or higher).
To download the "mydlink Lite" app, visit the App Store, Google Play or http://www.mydlink.com/apps.
PC and Mac users can use the mydlink portal at http://mydlink.com.
16D-Link DIR-860L User Manual
Section 3 - Getting Started

QRS Mobile App

QRS Mobile app allows you to install and congure your router from your mobile device.
Note: The screenshots may be dierent depending on your mobile device’s OS version.
Step 1 Search for the free QRS Mobile App on the iTunes Store or Google Play.
Step 2
Once your app is installed, you may now congure your router. Connect to the router wirelessly by going to your wireless utility on your device. Scan for the Wi-Fi name (SSID) as listed on the supplied info card. Select and then enter your Wi-Fi password.
Step 3
Once you connect to the router, launch the QRS Mobile app from the Home screen of your device.
Note: The following steps show the Android interface of the QRS Mobile app. If you are using an iPhone, iPad, or iPod touch, the appearance may be dierent to that of the screenshots, but the process is the same.
17D-Link DIR-860L User Manual
Section 3 - Getting Started
Step 4
You will see the welcome screen. Tap Start to proceed, then enter your device password and tap Log In. Tap Next once the Operation Mode screen appears.
Step 5
At this point, please ensure that you the router is connected to a modem. Plug one end of the provided Ethernet cable into your DSL or cable modem, and plug the other end into the port marked INTERNET on the DIR-860L. Tap Next to automatically detect your Internet connection and proceed to the next step.
18D-Link DIR-860L User Manual
Section 3 - Getting Started
Step 6
You will be prompted to set up each wireless frequency band in turn; the 2.4 GHz band followed by the 5 GHz band.
Firstly, enter a network name (SSID) of your choice, or leave it unchanged to accept the default SSID. Each wireless band can be assigned its own SSID.
Secondly, choose a Wi-Fi password of at least 8 characters. Any device trying to connect to the router wirelessly will need to enter this password the rst time it connects.
Finally, tap Next to proceed.
Step 7
Enter the administrator password of your choice. Unlike the Wi-Fi password, this password is only required when you need to congure the router. See Conguration on page 67 for details of when this password is used. Tap Next to proceed.
19D-Link DIR-860L User Manual
Section 3 - Getting Started
Step 8 If you already have a mydlink account, select Yes, I have a mydlink account and enter your mydlink email address and password. Lastly, tap Sign In to set up the router to use your mydlink account.
If you do not have a mydlink account, select No, I want to create a new mydlink account. Enter your E-mail address, choose a mydlink password
and check the I accept the mydlink terms and conditions box. Finally, tap Register account to create your new mydlink account.
If you do not want to congure your router with mydlink at this stage, tap Skip to proceed.
Step 9
If you wish to receive push notications whenever a new rmware update is available, check the Notify me when new rmware is available box and tap Next.
Otherwise, just tap Next to proceed.
20D-Link DIR-860L User Manual
Section 3 - Getting Started
Step 10
You will be presented with a summary of your chosen settings. Tap Save to complete the setup.
Congratulations, your device has been successfully congured! You can share this information by tapping Share By NFC, Share By E-mail, or tap Finish to exit the app.
If you tap Share By NFC, you can now touch the tag with your other device until the conrmation message appears.
Note: NFC is not supported by iPhone, iPad, and iPod touch devices.
21D-Link DIR-860L User Manual
Section 3 - Getting Started

mydlink™ SharePort

Using the mydlink™ SharePort app for iPad®, iPhone®, and iPod touch®

The mydlink SharePort app is a streamlined mobile application that allows you to conveniently stream media and share les stored on a removable storage connected to your router. Once the router is set up, you can start the app and easily connect from a local network or through the Internet to access your photos, videos, music, and documents. It allows you to create your own personal cloud storage; you can upload les and photos from your mobile device to the removable storage via the app from anywhere in the world!
Note: In order to ensure smooth streaming performance, you will need a minimum of 2 Mbit/s upload bandwidth for your router’s Internet connection.
Streaming performance will vary depending on the quality of your Internet connection.
Using mydlink SharePort remotely from the Internet:
1. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.
Note: If you connect a removable storage with many les or a large capacity, it may
take a while for the router to scan and catalog your les.
2. If you are connecting remotely through the mydlink SharePort app from the Internet, you will need a mydlink account. Please refer to mydlink on page 103 for more details.
USB drive
22D-Link DIR-860L User Manual
Section 3 - Getting Started
3. Use your iPhone, iPad or iPod touch to search for and download the free mydlink SharePort app from the App Store.
If you have a QR code reader, you can scan the code for mydlink SharePort to the right.
4. Tap the mydlink SharePort icon, and the app will load.
5. Tap Set up to go to Settings and enter the Admin password and your mydlink Account Login information when the pop-up displays. Tap Done when your information is entered. (The Admin password is only for local access, if you can connect through the Internet, then you can leave the Admin password blank)
23D-Link DIR-860L User Manual
Section 3 - Getting Started
6. You can now use the mydlink SharePort app interface to stream media and access les stored on your removable drive. The wireless icon at the bottom will be lit green to indicate you are connected to the router through Remote Access. If you need to change your settings, tap the gear icon at the top right corner to enter the settings page.
7. If you have more than one device registered to your mydlink account, you can tap Device List (in the top-left corner) and you will be prompted to select the device you wish to use.
Note: If you see a red wireless icon, your router’s network environment may not
be suitable for a direct network connection and you may experience slow network speeds.
24D-Link DIR-860L User Manual
Section 3 - Getting Started
Using mydlink SharePort in a local network:
1. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.
Note: If you connect a removable storage with many les or a large capacity, it may
take a while for the router to scan and catalog your les.
2. Use your iPhone, iPad or iPod touch to search for and download the free mydlink SharePort app from the App Store.
If you have a QR code reader, you can scan the code for mydlink SharePort to the right.
3. On your mobile device, go to your Wi-Fi settings and connect to your router’s wireless network using the default Wi-Fi settings. Locate the Wi-Fi name (SSID) and password for your device as printed on the included Wi-Fi Conguration Card.
4. Tap the mydlink SharePort icon, and the app will load.
25D-Link DIR-860L User Manual
Section 3 - Getting Started
5. Tap Set up to enter the Admin password for your router when the pop-up displays.
6. Enter your Admin Login in the Password eld and tap Done.
7. You can now use the mydlink SharePort app interface to stream media and access les stored on your removable drive. The wireless icon at the bottom will be lit blue to indicate a Local Access connection. If you need to change your settings, tap the gear icon at the top right corner to enter the settings page.
Note: If you see a red wireless icon, your router’s network environment may not
be suitable for a direct network connection and you may experience slow network speeds.
26D-Link DIR-860L User Manual
Section 3 - Getting Started

Main Menu

The mydlink SharePort main menu has dierent sections that let you see all the documents, photos, movies, or music stored on your removable storage. Tap < or >, or swipe left or right to move between the dierent sections. The Wi-Fi icon at the bottom indicates an active local network connection (blue) or remote connection (green/red). Tap the gear icon if it is not lit.
Tap on the document icon to view documents.
Tap the camera icon to view photos.
Tap on the movie icon to play videos.
Tap on the music icon to play audio les.
Tap on the folder icon to browse all les in a folder view.
Tap on the star icon to access your favorite les.
27D-Link DIR-860L User Manual
Section 3 - Getting Started

Documents

The Documents section allows you to share, print, and view documents streamed from your DIR-860L to your mobile device. Tap the document icon on the main menu to browse the documents on your mobile device.
Search Bar:
Enter a lename here to search your storage.
Tap to mark les for deletion.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tapping this icon gives you additional options:
• Open In...: Tap to use a third-party app to open the le.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to update the list of les.
Tap to reorder the les alphabetically.
28D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start the document viewer. In the viewer:
Tap to add/remove the le from your Favorites.
Tap to bring up the same options as >.
Note: Some les may require a third-party app to view them.
29D-Link DIR-860L User Manual
Section 3 - Getting Started

Pictures

The Pictures section allows you to stream images from your DIR-860L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage.
Search Bar:
Enter a lename here to search your storage.
Tap to mark les for deletion.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tapping this icon gives you additional options:
• Open In...: Tap to use a third-party app to open the le.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to start a slideshow of your photos. Tap the screen again to bring up the menu.
Tap to update the list of les.
Tap to reorder the les alphabetically.
30D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start the photo viewer. In the viewer:
Tap to add/remove the current image from your Favorites.
Tap to start the slideshow.
Tap to bring up the same options as >.
31D-Link DIR-860L User Manual
Section 3 - Getting Started

Videos

The Videos section allows you to stream video clips and movies from your DIR-860L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage.
Search Bar:
Enter a lename here to search for a specic le.
Tap to mark les for deletion.
Tap the star icon next to a le to download it to your device and add it into your Favorites section.
Tapping this icon gives you additional options:
• Open In...: Lets you use a third-party app to open the le.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to update the list of les.
Tap to reorder the les alphabetically.
32D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start playing it. In the player:
Tap to play/pause the video. You can scroll to any time on the time line by holding and sliding your nger.
Tap to enter/exit fullscreen mode.
Tap to add/remove the le from your Favorites.
Tapping this icon gives you additional options:
• Open In...: Lets you use a third-party app to open the le.
33D-Link DIR-860L User Manual
Section 3 - Getting Started

Music

The Music section allows you to stream songs from your DIR-860L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage.
Search Bar:
Enter a lename here to search your storage.
Tap to create a playlist and mark les for deletion.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tapping this icon gives you additional options:
• Open In...: Lets you use a third-party app to open the le.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to update the list of les.
Tap to reorder the les alphabetically.
34D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start playing it. In the player:
Tap to repeat all. Tap again to repeat a single song.
Tap to skip to the previous/next song.
Tap to enable/disable shue mode.
To create a playlist:
• Tap Edit > Add Playlist.
• Enter a name for the playlist, then tap Save.
• The name of the playlist will appear in the browser next
to the
icon.
35D-Link DIR-860L User Manual
Section 3 - Getting Started
To add songs to a playlist:
• Tap the playlist in the browser.
• Tap Add Music... to add songs to the current playlist.
• Tick the songs you wish to add and tap Done.
To delete songs from the playlist:
• Tap Edit in the playlist browser and mark the les to be deleted.
• Tap Delete.
36D-Link DIR-860L User Manual
Section 3 - Getting Started

Folders

You can browse your removable storage in a folder view in the folders section. Tapping the lename will open the viewer/player for that le type as described in the previous pages. You can also upload les from your mobile device to the removable storage attached to your router.
Search Bar:
Enter a lename here to search your storage.
Tap to take you to the editing screen where you can add a folder and mark les for deletion or copying.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tapping the > icon gives you additional options depending on the le type.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to upload les from your device to your removable storage.
Tap to update the list of les.
Tap to reorder the les alphabetically.
37D-Link DIR-860L User Manual
Section 3 - Getting Started
To delete les:
• Tap Edit at the top right.
• Tick the circle next to a le to mark it for deletion.
• Tap on Delete at the bottom to delete the le.
To copy les:
• Tap on Copy to bring up a window where you can select the folder to copy to.
• Browse to the directory you want to copy the marked les to and tap Paste.
• You can also tap Add Folder to create a new folder.
To create a new folder:
• Browse to the directory you wish to create a new folder in.
• Tap Edit at the top right.
• Tap Add Folder to add a new folder.
• Enter the name of the new folder, then tap Save.
• Tap OK to conrm folder creation.
38D-Link DIR-860L User Manual
Section 3 - Getting Started
To upload images and videos from your mobile device:
• Browse to the folder you wish to upload to.
• Tap Upload at the bottom.
• Select the photos/videos you wish to upload.
• Tap Done.
During the upload process, the size of the le and the upload progress will be displayed.
To upload more les, tap the + icon at the top right and repeat the steps listed above.
39D-Link DIR-860L User Manual
Section 3 - Getting Started

Favorites

The Favorites section allows you to quickly access your most often used les, no matter what le type, in a special section. Files added to the Favorites section will be copied here for playback in a centralized location.
Tap to mark les for deletion from the local storage in Favorites. The le will still be accessible in other mydlink SharePort sections.
Tapping this icon gives you additional options depending on the le type.
The bottom menu bar includes these options:
Tap to go back to the main menu.
Tap to update the list of les.
Tap to reorder the les alphabetically.
Tap on a le to start the le viewer. In the viewer:
Tap to add/remove the le from your Favorites.
Tap to bring up additional options.
Note: The le options available will vary depending on the le type.
40D-Link DIR-860L User Manual
Section 3 - Getting Started

Using the mydlink™ SharePort app for Android™

The mydlink SharePort app is a streamlined mobile application that allows you to conveniently stream media and share les stored on a removable storage connected to your router. Once the router is set up, you can start the app and easily connect from a local network or through the Internet to access your photos, videos, music, and documents. It allows you to create your own personal cloud storage; you can upload les and photos from your mobile device to the removable storage via the app from anywhere in the world!
Note: In order to ensure smooth streaming performance, you will need a minimum of 2 Mbit/s upload bandwidth for your router’s Internet connection.
Streaming performance will vary depending on the quality of your Internet connection.
Using mydlink SharePort remotely from the Internet:
1. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.
Note: If you connect a removable storage with many les or a large capacity, it may
take a while for the router to scan and catalog your les.
2. If you are connecting remotely through the mydlink SharePort app from the Internet, you will need a mydlink account. Please refer to mydlink on page 103 for more details.
USB drive
41D-Link DIR-860L User Manual
Section 3 - Getting Started
3. Use your Android mobile device to search for and download the free mydlink SharePort app from Google Play™.
If you have a QR code reader, you can scan the code for mydlink
SharePort to the right.
4. Tap the mydlink SharePort icon, and the app will load.
5. Tap Set up to go to Settings and enter the Admin password and your mydlink Account Login information when the pop-up displays. Tap Apply when your information is entered. (The Admin password is only for local access, if you can connect through the Internet, then you can leave the Admin password blank)
42D-Link DIR-860L User Manual
Section 3 - Getting Started
6. You can now use the mydlink SharePort app interface to stream media and access les stored on your removable drive. The wireless icon at the bottom will be lit green to indicate you are connected to the router through Remote Access.
7. If you have more than one device registered to your mydlink account, you can tap Device List (in the top-left corner) and you will be prompted to select the device you wish to use.
Note: If you see a red wireless icon, your router’s network environment may not
be suitable for a direct network connection and you may experience slow network speeds.
43D-Link DIR-860L User Manual
Section 3 - Getting Started
Using mydlink SharePort in a local network:
1. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.
Note: If you connect a removable storage with many les or a large capacity, it may
take a while for the router to scan and catalog your les.
2. Use your Android mobile device to search for and download the free mydlink SharePort app from Google Play™.
If you have a QR code reader, you can scan the code for mydlink
SharePort to the right.
3. On your mobile device, go to your Wi-Fi settings and connect to your router’s wireless network using the default Wi-Fi settings. Locate the Wi-Fi name (SSID) and password for your device as printed on the included Wi-Fi Conguration Card.
DIR-860L
44D-Link DIR-860L User Manual
Section 3 - Getting Started
4. Tap the mydlink SharePort icon, and the app will load.
5. Tap Set up to enter the Admin password for your router when the pop-up displays.
6. Enter your Admin Login in the Password field and tap Apply. You will be taken back to the device list where you can select the device for use with mydlink SharePort.
7. You can now use the mydlink SharePort app interface to stream media and access les stored on your removable drive. The wireless icon at the bottom will be lit blue to indicate a Local Access connection.
Note: If you see a red wireless icon, your router’s network environment may not
be suitable for a direct network connection and you may experience slow network speeds.
45D-Link DIR-860L User Manual
Section 3 - Getting Started

Main Menu

The mydlink SharePort main menu has dierent sections that let you see all the documents, photos, movies, or music stored on your removable storage. Tap < or >, or swipe left or right to move between the dierent sections. The Wi-Fi icon at the bottom indicates an active local network connection (blue) or remote connection (green/red). Tap the gear icon if it is not lit.
Tap on the document icon to view documents.
Tap the camera icon to view pictures.
Tap on the movie icon to play videos.
Tap on the music icon to play audio les.
Tap on the folder icon to browse all les in a folder view.
Tap on the star icon to access your favorite les.
Note: Available features may dier depending on the Android OS version
of your device.
46D-Link DIR-860L User Manual
Section 3 - Getting Started

Documents

The Documents section allows you to share, print, and view documents streamed from your DIR-860L to your mobile device. Tap the document icon on the main menu to browse the les on your mobile device.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to refresh, sort, or mark les for deletion.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tap for additional options:
Tap to return to the main menu.
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Check a le then tap to delete it.
47D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start the document viewer. In the viewer:
• Tap the screen to bring up zoom in/out buttons.
• Drag the screen up or down to scroll between pages.
• Tap
to perform File, Find, Zoom, Reading View, Go To
Page, and Bookmarks actions.
Note: Available actions may dier depending on your Android OS.
48D-Link DIR-860L User Manual
Section 3 - Getting Started

Pictures

The Pictures section allows you to view images streamed from your DIR-860L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to start a slideshow.
Tap to refresh, sort, or mark les for deletion.
Tap the star icon next to each le to download it to your device and add it into your Favorites section.
Tap for additional options:
Tap to return to the main menu.
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Check a le then tap to delete it.
49D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on an image le to start the image viewer. In the viewer:
Tap the star icon to download it to your device and add it into your Favorites section.
Tap to start a slideshow. Tap the image to stop the slideshow.
Tap to delete the current image. Tap OK to conrm.
Tap to bring up additional options using other applications.
Tap to access the image editor.
Note: This function may vary depending on the version of your Android
OS.
50D-Link DIR-860L User Manual
Section 3 - Getting Started

Videos

The Videos section allows you to stream video clips and movies from your DIR-860L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to refresh, sort, or mark les for deletion.
Tap the star icon next to a le to download it to your device and add it into your Favorites section.
Tap for additional options:
Tap to return to the main menu.
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Check a le then tap this icon to delete it.
51D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start playing it. Tap on the screen to bring up the scroll bar, pause button, and play button.
Tap to resume playback.
Tap to pause the video.
Note: Available features may vary depending on the Android OS version installed
on your device.
52D-Link DIR-860L User Manual
Section 3 - Getting Started

Music

The Music section allows you to stream songs from your DIR-860L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to refresh, sort, or mark les for deletion.
Tap to browse your playlists.
Tap the star icon next to a le to download it to your device and add it into your Favorites section.
Tap for additional options:
Tap to return to the main menu.
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Check a le then tap this icon to delete it.
53D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap on a le to start playing it. In the player:
Tap on the up/down arrow to show/hide the player controls.
Tap to repeat all. Tap again to repeat a single song.
Tap to skip to the previous/next song.
Tap to play or pause the song.
Tap to enable/disable shue mode.
To create a playlist:
• Tap
• Tap Add new playlist...
• Enter a name for the playlist, then tap OK. The name of the
• playlist will appear in the browser next to the
icon.
• You can tap
then to refresh the playlist page.
54D-Link DIR-860L User Manual
Section 3 - Getting Started
To add songs to a playlist:
• Tap a playlist to see its contents.
• Tap Add Music... to add songs to the current playlist.
• Tick the songs you wish to add and tap
To delete songs from the playlist:
• Tap Edit in the playlist browser and mark the les to be deleted.
• Tap
then tap OK to conrm.
to save.
55D-Link DIR-860L User Manual
Section 3 - Getting Started

Folders

You can browse your removable storage in a folder view in the folders section. Tapping the lename will open the viewer/player for that le type as described in the previous pages. You can also upload les from your mobile device to the removable storage attached to your router.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to access le options.
In the le browser:
Tap to return to the main menu.
Tap to upload les.
Tap to refresh, sort, create a new folder, or mark les for deletion and copying.
56D-Link DIR-860L User Manual
Section 3 - Getting Started
Tap to select les and perform the following actions:
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Tap to create a new folder.
Mark a le then tap this icon to delete it.
Mark a le then tap this icon to copy it.
To delete les:
• Tap on
• Tap on
and tick the box next to a le for deletion.
to delete your selected files. Tap OK to
conrm.
To copy les:
• Tap on each le for copying.
• Tap on
to select les for copying. Tick the box next to
to browse to the destination.
57D-Link DIR-860L User Manual
Section 3 - Getting Started
• Tap Paste or Cancel.
• You can also tap New Folder if you wish to create a folder in the current directory.
To create a new folder:
• Browse to the directory you wish to create a new folder in.
• Tap
then .
• Enter the name of the folder in the box, then tap OK.
58D-Link DIR-860L User Manual
Section 3 - Getting Started
To upload images and videos from your mobile device:
• Browse to the folder you wish to upload to.
• Tap
and browse to the le or les you wish to upload
from the local device.
• Tick the box next to each of the les you wish to upload.
• Tap Upload.
During the upload process, the size of the le and the upload progress will be displayed under the le name.
• To remove a le from the upload queue, tap the X next to it.
59D-Link DIR-860L User Manual
Section 3 - Getting Started

Favorites

The Favorites section allows you to quickly access your most often used les, no matter what le type, in a special section. Files added to the Favorites section will be copied here for playback in a centralized location.
Search Bar:
Type in the name of a le to search for it.
Tap to return to the main menu.
Tap to refresh, sort, or mark les for deletion.
Tap for additional options:
Tap to return to the main menu.
Tap to update the list of les.
Tap to sort the les by name, size, type, or date.
Check a le then tap to delete it.
60D-Link DIR-860L User Manual
Section 3 - Getting Started

Using SharePort Web Access

SharePort Web Access lets you stream music, photos, and movies from a USB drive attached to your DIR-860L through a Web browser. You can also download and upload les to and from a computer through the Web browser interface.
• Type http://shareport.local. in your browser’s URL to take you to the SharePort Web Access log in page.
• Log in with your admin password or a SharePort Username and Password.
At the main menu, you can browse the les stored on your USB drive by le type.
• Click
to browse by folders.
61D-Link DIR-860L User Manual
Section 3 - Getting Started
The folder browser section will show folder hierarchy at the left and les at the right. You can quickly browse directories and perform operations by using the buttons in the folder browser view.
• Click to return to the main menu.
To create a new folder:
• Click New Folder in the current directory.
• Enter a folder name in the Create Folder pop-up.
• Click OK. The new folder will appear in the left column.
To upload a le:
Click Upload t
the pop-up browse to the file you wish to
• In upload.
• Click OK. The le will appear after the browser refreshes.
To delete a le:
• Tick the checkbox next to the les you wish to delete.
• Click Delete and a dialog box will appear.
• Click OK to conrm.
o upload a le to the current folder.
62D-Link DIR-860L User Manual
Section 3 - Getting Started

Music

You can go to the Music section to browse and play the music les on your storage. Click Back to return to the main menu.
• Click on the audio lename to play it in the browser.
You can pause, seek, mute and adjust the volume in the window.
• Close the window to end playback.
63D-Link DIR-860L User Manual
Section 3 - Getting Started

Pictures

You can go to the Pictures section to browse and view the image les on your storage. Click Back to return to the main menu.
• Click on the image name to view it in the browser.
• Hover your mouse over the left or right side of the image and click < or > to view the previous or next image.
64D-Link DIR-860L User Manual
Section 3 - Getting Started

Videos

You can go to the Videos section to browse and play the video les on your storage. Click Back to return to the main menu.
• Click on the video le to open the le in a window for streaming.
You can pause, seek, mute, adjust the volume, and activate full screen mode in the window controls.
• Close the window to end playback.
Note: Depending on your browser, the video le may be played back using the
default player associated with that le format.
65D-Link DIR-860L User Manual
Section 3 - Usage

Documents

You can go to the Documents section to open and save les from your storage to your computer. Click Back to return to the main menu.
• Click on the lename to open the le.
• Depending on the le type, the default program will be started or a pop-up may ask you to open or save the le.
66D-Link DIR-860L User Manual
Section 4 - Conguration
Conguration
To access the conguration utility, open a web-browser such as Internet Explorer and enter http://dlinkrouter.local./
Windows and Mac users may also connect by typing the IP address of the router (by default this is http://192.168.0.1) in the address bar.
Enter your password. If you previously followed the setup wizard (see Setup Wizard on page 12), please use the admin password you entered during the wizard. Otherwise, leave the password blank. Click Log In to proceed.
Note: If you cannot remember your password and cannot log in, press the reset button (see Back View on page 6) to restore the router to its default settings.
The router’s home page will open displaying its current connection status.
The bar at the top of the page has quick access to Settings and Management functions. You may quickly jump back Home at any time.
Note: The system will automatically log out after a period of inactivity.
67D-Link DIR-860L User Manual
Section 4 - Conguration

Home

The Home page displays the current status of the router in the form of an interactive diagram. You can click each icon to display information about each part of the network at the bottom of the screen. The menu bar at the top of the page will allow you to quickly navigate to other pages.

Internet

The Home page displays whether or not the router is currently connected to the Internet. If it is disconnected, click Click to repair to bring up the setup wizard (see Setup Wizard on page 12).
To bring up more details about your Internet connection, click on the Internet icon. Click IPv4 or IPv6 to see details of the IPv4 connection and IPv6 connection respectively.
Click Release to disconnect from the Internet. If you do this and wish to reconnect, click Renew.
To recongure the Internet settings, refer to Internet on page 72.
68D-Link DIR-860L User Manual
Section 4 - Conguration

DIR-860L

Click on the DIR-860L icon to view details about the router and its wireless settings.
Here you can see the router’s current wireless settings, as well as its MAC address and IPv4/IPv6 addresses.
To recongure the network settings, either click Go to settings on the lower left, or click Settings (at the top of the page) and then Network on the menu that appears. Refer to Network on page 99.
To recongure the wireless settings, either click Go to settings, on the lower right, or click Settings (at the top of the page) and then Wireless on the menu that appears. Refer to Wireless on page 96.
69D-Link DIR-860L User Manual
Section 4 - Conguration

Connected Clients

Click on the Connected Clients icon to view details about the router and its wireless settings.
On this page you can see all the clients currently connected to the router, and their IP addresses.
To edit each client’s settings, click the pencil icon on the client you want to edit.
Name:
Vendor:
IP Address:
Reserve IP:
Parental Control:
Enter a custom name for this client.
Displays the vendor of the device.
Enter a specic IP address for this client.
Enable to reserve this IP address for this client.
If enabled, parental control will completely disable all network activity on the client according to a custom schedule. A drop-down menu will appear; select the time schedule during which parental control will take eect. The schedule may be set to Always OFF to indenitely deny network access to the client, or you can create your own schedules in the Schedules section (refer to Schedule on page 116).
Click Save when you are done.
70D-Link DIR-860L User Manual
Section 4 - Conguration

USB Device

Click on the USB Device icon to view details about the currently connected USB device, the UPnP media server, SharePort, and Windows File Sharing.
If you have a USB device connected, you can see its name and how much free space it has.
To congure your SharePort settings, click Go to settings and refer to SharePort on page 101.
71D-Link DIR-860L User Manual
Section 4 - Conguration

Settings

Wizard

In the Settings menu on the bar on the top of the page, click Wizard to open the setup wizard. This is the same wizard that appears when you start the router for the rst time. Refer to Setup Wizard on page 12 for details.

Internet

In the Settings menu on the bar on the top of the page, click Internet to see the Internet conguration options.
My Internet
Connection Is:
For Dynamic IP (DHCP) refer to Dynamic IP (DCHP) on page 73.
For Static IP refer to Static IP on page 74.
For PPPoE refer to PPPoE on page 75.
For PPTP refer to PPTP on page 76.
For L2TP refer to L2TP on page 78.
For DS-Lite refer to DS-Lite on page 80.
To congure an IPv6 connection, click the IPv6 link. Refer to IPv6 on page 81.
Choose your Internet connection type from the drop-down menu. You will be presented with the appropriate options for your connection type. Click Advanced Settings... to expand the list and see all of the options.
72D-Link DIR-860L User Manual
Section 4 - Conguration
Dynamic IP (DCHP)
Select Dynamic IP (DHCP) to obtain IP address information automatically from your Internet Service Provider (ISP). Select this option if your ISP does not give you an IP address to use.
Host Name:
Primary DNS
Server:
Secondary DNS
Server:
MTU:
MAC Address
Clone:
The host name is optional but may be required by some ISPs. Leave it blank if you are not sure.
Enter the primary DNS server IP address assigned by your ISP. This address is usually obtained automatically from your ISP.
Enter the secondary DNS server IP address assigned by your ISP. This address is usually obtained automatically from your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
The default MAC address is set to the Internet port’s physical interface MAC address on the router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client.
Click Save when you are done.
73D-Link DIR-860L User Manual
Section 4 - Conguration
Static IP
Select Static IP if your IP information is provided by your Internet service provider (ISP).
IP Address:
Subnet Mask:
Default
Gateway:
Primary DNS
Server:
Secondary DNS
Server:
MTU:
MAC Address
Clone:
Enter the IP address provided by your ISP.
Enter the subnet mask provided by your ISP.
Enter the default gateway address provided by your ISP.
Enter the primary DNS server IP address assigned by your ISP.
Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
The default MAC address is set to the Internet port’s physical interface MAC address on the router. You can use drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client.
Click Save when you are done.
74D-Link DIR-860L User Manual
Section 4 - Conguration
PPPoE
Select PPPoE if your Internet connection requires you to enter a username and password. This information is provided by your Internet Service Provider (ISP).
Username:
Password:
Reconnect
Mode:
Maximum Idle
Time:
Address Mode:
IP Address:
Service Name:
Primary DNS
Server:
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select either Always-on, On-Demand, or Manual.
Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto- reconnect.
Select Static IP if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.
Enter the IP address provided by your ISP (Static IP only).
Enter the ISP service name (optional).
Enter the primary DNS server IP address assigned by your ISP.
Secondary DNS
Server:
MTU:
Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
Click Save when you are done.
75D-Link DIR-860L User Manual
Section 4 - Conguration
PPTP
Choose PPTP (Point-to-Point-Tunneling Protocol ) if your Internet Service Provider (ISP) uses a PPTP connection. Your ISP will provide you with a username and password.
PPTP Server IP
Address:
Username:
Password:
Reconnect
Mode:
Maximum Idle
Time:
Address Mode:
PPTP IP
Address:
PPTP Subnet
Mask:
Enter the PPTP server IP address provided by your ISP.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select either Always-on, On-Demand, or Manual.
Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto­reconnect.
Select Static IP if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.
Enter the IP address provided by your ISP (Static IP only).
Enter the subnet mask provided by your ISP (Static IP only).
PPTP Gateway
IP Address:
Primary DNS
Server:
Enter the gateway IP address provided by your ISP (Static IP only).
Enter the primary DNS server IP address assigned by your ISP.
76D-Link DIR-860L User Manual
Section 4 - Conguration
Secondary DNS
Server:
MTU:
Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
Click Save when you are done.
77D-Link DIR-860L User Manual
Section 4 - Conguration
L2TP
Choose L2TP (Layer 2 Tunneling Protocol) if your Internet Service Provider (ISP) uses a L2TP connection. Your ISP will provide you with a username and password.
L2TP Server IP
Address:
Username:
Password:
Reconnect
Mode:
Maximum Idle
Time:
Address Mode:
L2TP IP
Address:
L2TP Subnet
Mask:
Enter the L2TP server IP address provided by your ISP.
Enter the username provided by your ISP.
Enter the password provided by your ISP.
Select either Always-on, On-Demand, or Manual.
Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable Auto­reconnect.
Select Static IP if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.
Enter the IP address provided by your ISP (Static IP only).
Enter the subnet mask provided by your ISP (Static IP only).
L2TP Gateway
IP Address:
Primary DNS
Server:
Enter the gateway IP address provided by your ISP (Static IP only).
Enter the primary DNS server IP address assigned by your ISP.
78D-Link DIR-860L User Manual
Section 4 - Conguration
Secondary DNS
Server:
MTU:
Enter the secondary DNS server IP address assigned by your ISP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
Click Save when you are done.
79D-Link DIR-860L User Manual
Section 4 - Conguration
DS-Lite
DS-Lite is an IPv6 connection type. After selecting DS-Lite, the following parameters will be available for conguration:
DS-Lite
Conguration:
AFTR IPv6
Address:
B4 IPv6
Address:
WAN IPv6
Address:
IPv6 WAN
Default
Gateway:
Select DS-Lite DHCPv6 to let the router allocate the AFTR IPv6 address automatically. Select Manual Conguration to enter the AFTR IPv6 address manually.
If you selected Manual Conguration above, enter the AFTR IPv6 address used here.
Enter the B4 IPv4 address value used here.
Once connected, the WAN IPv6 address will be displayed here.
Once connected, the IPv6 WAN default gateway address will be displayed here.
Click Save when you are done.
80D-Link DIR-860L User Manual
Section 4 - Conguration
IPv6
To congure an IPv6 connection, click the IPv6 link. To return to the IPv4 settings, click IPv4.
My Internet
Connection Is:
For Auto Detection refer to Auto Detection on page 82.
For Static IPv6 refer to Static IPv6 on page 84.
For Auto Conguration (SLAAC/DHCPv6) refer to Auto Conguration (SLAAC/ DHCPv6) on page 86.
For PPPoE refer to PPPoE on page 88.
For IPv6 in IPv4 Tunnel refer to IPv6 in IPv4 Tunnel on page 90.
For 6 to 4 refer to 6 to 4 on page 92.
For 6rd refer to 6rd on page 93.
For Local Connectivity Only refer to Local Connectivity Only on page 95.
Choose your IPv6 connection type from the drop-down menu. You will be presented with the appropriate options for your connection type. Click Advanced Settings... to expand the list and see all of the options.
81D-Link DIR-860L User Manual
Section 4 - Conguration
Auto Detection
Auto Detection mode (not Auto-Conguration mode) automatically detects IPv6 the connection method used by your Internet Service Provider (ISP). If your ISP provides an IPv6 service and Auto Detection failed to detect it, the user must manually select another IPv6 connection type (such as PPPoE, Auto Conguration, 6rd, DS-Lite etc.)
DNS Type:
Primary DNS
Server:
Secondary DNS
Server:
Enable DHCP-
PD:
LAN IPv6
Address:
LAN IPv6 Link­Local Address:
Enable
Automatic
IPv6 Address
Assignment:
Select either Obtain DNS server address automatically or Use the following DNS address.
If you selected Use the following DNS address above, enter the primary DNS server address.
If you selected Use the following DNS address above, enter the secondary DNS server address.
Enable or disable prex delegation services.
If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the router.
Displays the router’s LAN link-local address.
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable
Automatic
DHCP-PD in
LAN:
Enable or disable DHCP-PD for other IPv6 routers connected to the LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information.
82D-Link DIR-860L User Manual
Section 4 - Conguration
Autoconguration
Type:
Router
Advertisement
Lifetime:
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
83D-Link DIR-860L User Manual
Section 4 - Conguration
Static IPv6
Select Static IP if your IPv6 information is provided by your Internet service provider (ISP).
Use Link-Local
Address:
IPv6 Address:
Subnet Prex
Length:
Default
Gateway:
Primary DNS
Server:
Secondary DNS
Server:
LAN IPv6
Address:
Enable or disable a link-local address.
If you disabled Use Link-Local Address, enter the address supplied by your ISP.
If you disabled Use Link-Local Address, enter the subnet prex length supplied by your ISP.
Enter the default gateway for your IPv6 connection.
Enter the primary DNS server address.
Enter the secondary DNS server address.
Enter the LAN (local) IPv6 address for the router.
LAN IPv6 Link­Local Address:
Enable
Automatic
IPv6 Address
Assignment:
Displays the router’s LAN link-local address.
Check to enable the Automatic IPv6 Address Assignment feature.
84D-Link DIR-860L User Manual
Section 4 - Conguration
Autoconguration
Type:
Router
Advertisement
Lifetime:
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
85D-Link DIR-860L User Manual
Section 4 - Conguration
Auto Conguration (SLAAC/DHCPv6)
This is a connection method where the ISP assigns your IPv6 address when your router requests one from the ISP’s server. Some ISPs require you to make some settings on your side before your router can connect to the IPv6 Internet.
DNS Type:
Primary DNS
Server:
Secondary DNS
Server:
Enable DHCP-
PD:
LAN IPv6
Address:
LAN IPv6 Link­Local Address:
Enable
Automatic
IPv6 Address
Assignment:
Select either Obtain DNS server address automatically or Use the following DNS address.
If you selected Use the following DNS address above, enter the primary DNS server address.
If you selected Use the following DNS address above, enter the secondary DNS server address.
Enable or disable prex delegation services.
If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the router.
Displays the router’s LAN link-local address.
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable
Automatic
DHCP-PD in
LAN:
Enable or disable DHCP-PD for other IPv6 routers connected to the LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information.
86D-Link DIR-860L User Manual
Section 4 - Conguration
Autoconguration
Type:
Router
Advertisement
Lifetime:
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
87D-Link DIR-860L User Manual
Section 4 - Conguration
PPPoE
Select PPPoE if your Internet connection requires you to enter a username and password. This information is provided by your Internet service provider (ISP).
PPPoE Session:
Username:
Password:
Address Mode:
MTU:
DNS Type:
Choose Share with IPv4 to re-use your IPv4 PPPoE username and password, or Create a new session.
If you selected Create a new session above, enter the PPPoE username provided by your ISP here.
If you selected Create a new session above, enter the PPPoE password provided by your ISP here.
Select Static IP if your ISP assigned you the IP address, subnet mask, gateway, and DNS server addresses. In most cases, select Dynamic IP.
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your ISP.
Select either Obtain DNS server address automatically or Use the following DNS address.
88D-Link DIR-860L User Manual
Section 4 - Conguration
Enable DHCP-
PD:
LAN IPv6 Link­Local Address:
Enable
Automatic
IPv6 Address
Assignment:
Enable
Automatic
DHCP-PD in
LAN:
Auto
Conguration
Type:
Enable DHCP-PD for LAN IPv6.
Displays the router’s LAN link-local address.
Enable automatic IPv6 address assignment.
Enable or disable DHCP-PD for other IPv6 routers connected to the LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information.
Select SLAAC + RDNSS or SLAAC + Stateless DHCP, Stateful (DHCPv6).
Router
Advertisement
Lifetime:
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
89D-Link DIR-860L User Manual
Section 4 - Conguration
IPv6 in IPv4 Tunnel
The user can congure the IPv6 connection to run in IPv4 Tunnel mode. IPv6 over IPv4 tunneling encapsulates IPv6 packets in IPv4 packets so that IPv6 packets can be sent over an IPv4 infrastructure.
Remote IPv4
Address:
Remote IPv6
Address:
Local IPv4
Address:
Local IPv6
Address:
Subnet Prex
Length:
DNS Type:
Primary DNS
Server:
Enter the IPv4 remote address you will use.
Enter the IPv6 remote address you will use.
Enter the IPv4 local address you will use.
Enter the IPv6 local address you will use.
Enter the subnet prex length supplied by your ISP.
Select either Obtain DNS server address automatically or Use the following DNS address.
If you selected Use the following DNS address above, enter the primary DNS server address.
Secondary DNS
Server:
Enable DHCP-
PD:
LAN IPv6
Address:
If you selected Use the following DNS address above, enter the secondary DNS server address.
Enable or disable prex delegation services.
If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the router.
90D-Link DIR-860L User Manual
Section 4 - Conguration
LAN IPv6 Link­Local Address:
Enable
Automatic
IPv6 Address
Assignment:
Enable
Automatic
DHCP-PD in
LAN:
Auto
Conguration
Type:
Router
Advertisement
Lifetime:
Displays the router’s LAN link-local address.
Enable or disable the Automatic IPv6 Address Assignment feature.
Enable or disable DHCP-PD for other IPv6 routers connected to the LAN interface.
Note: This feature requires a smaller subnet prex than /64 (i.e. allowing for a larger address allocation), such as /63. Contact your ISP for more information.
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
91D-Link DIR-860L User Manual
Section 4 - Conguration
6 to 4
In this section the user can congure the IPv6 6 to 4 connection settings. 6to4 is an IPv6 address assignment and automatic tunneling technology that is used to provide unicast IPv6 connectivity between IPv6 sites and hosts across the IPv4 Internet.
6 to 4 Address:
6 to 4 Relay:
Primary DNS
Server:
Secondary DNS
Server:
LAN IPv6 Address:
LAN IPv6 Link­Local Address:
Enable Automatic
IPv6 Address
Assignment:
Autoconguration
Type:
Displays the 6 to 4 address.
Enter the 6 to 4 relay supplied by your ISP.
Enter the primary DNS server address.
Enter the secondary DNS server address.
Enter the LAN (local) IPv6 address for the router.
Displays the router’s LAN link-local address.
Check to enable the Automatic IPv6 Address Assignment feature.
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Router
Advertisement
Lifetime:
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
92D-Link DIR-860L User Manual
Section 4 - Conguration
In this section the user can congure the IPv6 6rd connection settings.
6rd
Assign IPv6
Prex:
Primary DNS
Server:
Secondary DNS
Server:
Enable Hub and
Spoke Mode:
6rd
Conguration:
LAN IPv6 Link­Local Address:
Currently unsupported.
Enter the primary DNS server address.
Enter the secondary DNS server address.
Enable if you want to minimize the number of routes to the destination by using a hub and spoke method of networking.
Choose the 6rd DHCPv4 Option to automatically discover and populate the data values, or Manual Conguration to enter the settings yourself.
Displays the router’s LAN link-local address.
93D-Link DIR-860L User Manual
Section 4 - Conguration
Enable
Automatic
IPv6 Address
Assignment:
Auto
Conguration
Type:
Router
Advertisement
Lifetime:
Check to enable the Automatic IPv6 Address Assignment feature.
Select Stateful (DHCPv6), SLAAC + RDNSS or SLAAC + Stateless DHCPv6.
Enter the IPv6 address lifetime (in minutes).
Click Save when you are done.
94D-Link DIR-860L User Manual
Section 4 - Conguration
Local Connectivity Only
Local Connectivity Only allows you to set up an IPv6 connection that will not connect to the Internet.
Enable ULA:
Use Default
ULA Prex:
ULA Prex:
Current IPv6
ULA Settings:
Click here to enable Unique Local IPv6 Unicast Addresses settings.
Checking this box will automatically congure the ULA prex for the default setting.
If you wish to choose your own ULA prex, enter it here.
This section will display the current settings for your IPv6 ULA.
Click Save when you are done.
95D-Link DIR-860L User Manual
Section 4 - Conguration

Wireless

In the Settings menu on the bar on the top of the page, click Wireless to see the wireless conguration options. To congure the router’s guest zone, click the Guest Zone link. Refer to Guest Zone on page 98 for details. Click Advanced Settings... to expand the list and see all of the options. The following options apply to both the
2.4 GHz and the 5 GHz wireless frequency bands:
Status:
Wi-Fi Name
(SSID):
Password:
Security Mode:
802.11 Mode:
Wi-Fi Channel:
Transmission
Power:
Channel Width:
Enable or disable the wireless frequency band.
Create a name for your wireless network using up to 32 characters.
Create a password to use for wireless security. Wireless clients will need to enter this password to successfully connect to the network.
Choose None, WEP, or WPA/WPA2-(Personal) (recommended).
Select the desired wireless networking standards to use. The available options will depend on the wireless frequency band, as well as the currently selected security mode.
Select the desired channel. The default is Auto (recommended).
Select the desired wireless transmission power.
A higher channel width allows for faster data transmission, at the possible expense of wireless coverage and compatibility with older wireless clients. Select the optimum channel width for your wireless network from the drop-down menu.
Visibility Status:
The default setting is Visible. Select Invisible if you do not want to broadcast the SSID of your wireless network.
96D-Link DIR-860L User Manual
Loading...
