PPPoE (DSL)

Choose PPPoE (Point to Point Protocol over Ethernet) if your ISP uses a PPPoE connection. Your ISP will provide
you with a username and password. This option is typically used for DSL services. Make sure to remove your PPPoE
software from your computer. The software is no longer needed and will not work through a router.

My Internet

Connection:

Address Mode:

IP Address:

User Name:

Password:

Service Name:

Reconnection Mode:

Select
the drop-down menu.

Select Static if your ISP assigned you the IP
address, subnet mask, gateway, and DNS
server addresses. In most cases, select
Dynamic.

Enter the IP address (Static PPPoE only).
Enter your PPPoE user name.
Enter your PPPoE password and then retype

the password in the next box.
Enter the ISP Service Name (optional).
Select either Always-on, On-Demand, or

Manual.

PPPoE.(Username/Password) from

Maximum Idle Time:

DNS Addresses:

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature,
enable Auto-reconnect.

Enter the Primary and Secondary DNS Server Addresses (Static PPPoE only).

21D-Link DIR-615 User Manual

Section 3 - Configuration

MTU:

MAC Address:

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1492 is
the default MTU.

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not
recommended that you change the default MAC address unless required by your ISP. You can use the

MAC.Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

Clone.Your.PC’s.

22D-Link DIR-615 User Manual

Section 3 - Configuration

PPTP

Choose PPTP (Point-to-Point-Tunneling Protocol ) if your ISP uses a PPTP connection. Your ISP will provide you with
a username and password. This option is typically used for DSL services.

Address Mode:

PPTP IP Address:

PPTP Subnet

Mask:

PPTP Gateway:

PPTP Server IP:

Username:

Password:

Reconnect Mode:

Select Static if your ISP assigned you the IP
address, subnet mask, gateway, and DNS server
addresses. In most cases, select Dynamic.

Enter the IP address (Static PPTP only).
Enter the Primary and Secondary DNS Server

Addresses (Static PPTP only).
Enter the Gateway IP Address provided by your

ISP.
Enter the Server IP provided by your ISP

(optional).

Enter your PPTP username.
Enter your PPTP password and then retype the

password in the next box.
Select either Always-on, On-Demand, or

Manual.

Maximum Idle

Time:

DNS Servers:

MTU:

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature, enable
Auto-reconnect.

The DNS server information will be supplied by your ISP (Internet Service Provider.)
Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1400 is the

default MTU.

23D-Link DIR-615 User Manual

Section 3 - Configuration

MAC Address:

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not
recommended that you change the default MAC address unless required by your ISP. You can use the

MAC.Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

Clone.Your.PC’s.

24D-Link DIR-615 User Manual

Section 3 - Configuration

L2TP

Choose L2TP (Layer 2 Tunneling Protocol) if your ISP uses a L2TP connection. Your ISP will provide you with a username
and password. This option is typically used for DSL services.

Address Mode:

L2TP IP Address:

L2TP Subnet Mask:

L2TP Gateway:

L2TP Server IP:

Username:

Password:

Select Static if your ISP assigned you the IP
address, subnet mask, gateway, and DNS
server addresses. In most cases, select
Dynamic.

Enter the L2TP IP address supplied by your
ISP (Static only).

Enter the Subnet Mask supplied by your ISP
(Static only).

Enter the Gateway IP Address provided by
your ISP.

Enter the Server IP provided by your ISP
(optional).

Enter your L2TP username.
Enter your L2TP password and then retype

the password in the next box.

Reconnect Mode:

Maximum Idle Time:

DNS Servers:

Select either Always-on, On-Demand, or
Manual.

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature,
enable Auto-reconnect.

Enter the Primary and Secondary DNS Server Addresses (Static L2TP only).

25D-Link DIR-615 User Manual

Section 3 - Configuration

MTU:

Clone MAC

Address:

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specific ISP. 1400 is the
default MTU.

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not
recommended that you change the default MAC address unless required by your ISP. You can use the

MAC.Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

Clone.Your.PC’s.

26D-Link DIR-615 User Manual

Section 3 - Configuration

Static IP Address

Select Static IP Address if all the Internet port’s IP information is provided to you by your ISP. You will need to enter in the IP address,
subnet mask, gateway address, and DNS address(es) provided to you by your ISP. Each IP address entered in the fields must be in the
appropriate IP form, which are four octets separated by a dot (x.x.x.x). The Router will not accept the IP address if it is not in this format.

IP Address:

Subnet Mask:

Default Gateway:

DNS Servers:

MTU:

MAC Address:

Enter the IP address assigned by your ISP.
Enter the Subnet Mask assigned by your ISP.
Enter the Gateway assigned by your ISP.
The DNS server information will be supplied by

your ISP (Internet Service Provider.)
Maximum Transmission Unit - you may need to

change the MTU for optimal performance with
your specific ISP. 1500 is the default MTU.

The default MAC Address is set to the Internet
port’s physical interface MAC address on the
Broadband Router. It is not recommended that
you change the default MAC address unless
required by your ISP. You can use the
Your.PC’s.MAC.Address button to replace
the Internet port’s MAC address with the MAC
address of your Ethernet card.

Clone.

27D-Link DIR-615 User Manual

Section 3 - Configuration

Wireless Settings

If you want to configure the wireless settings on your
router using the wizard, click Wireless.Network.Setup.
Wizard.and refer to page 79.

Click Add.Wireless.Device.with.WPS if you want to add
a wireless device using Wi-Fi Protected Setup (WPS)
and refer to page 82.

If you want to manually configure the wireless settings
on your router click Manual Wireless.Network.Setup.
and refer to the next page.

28D-Link DIR-615 User Manual

Section 3 - Configuration

Manual Wireless Network Setup

Enable Wireless:

Wireless Network

Name:

802.11 Mode:

Check the box to enable the wireless function. If
you do not want to use wireless, uncheck the box
to disable all the wireless functions. Click Add.New
to create your own time schedule to enable the
wireless function.

Service Set Identifier (SSID) is the name of your
wireless network. Create a name using up to 32
characters. The SSID is case-sensitive.

Select one of the following:

802.11g.Only - Select if all of your wireless clients
are 802.11g.
Mixed.802.11g.and.802.11b - Select if you
are using both 802.11b and 802.11g wireless
clients.

802.11b.Only - Select if all of your wireless clients
are 802.11b.

802.11n.Only - Select only if all of your wireless
clients are 802.11n.
Mixed.802.11n,.802.11b,.and.802.11g - Select
if you are using a mix of 802.11n, 11g, and 11b
wireless clients.
Mixed.802.11n.and.802.11g - Select if you are
using a mix of 802.11n and 802.11g wireless
clients.

Enable Auto

Channel Scan:

Wireless Channel:

The Auto.Channel.Scan setting can be selected to
allow the DIR-615 to choose the channel with the least amount of interference.

Indicates the channel setting for the DIR-615. By default the channel is set to 6. The Channel can be changed to fit the
channel setting for an existing wireless network or to customize the wireless network. If you enable Auto.Channel.Scan,
this option will be greyed out.

29D-Link DIR-615 User Manual

Section 3 - Configuration

Transmission Rate:

Channel Width:

Visibility Status:

Wireless Security:

Select the transmit rate. It is strongly suggested to select
Select the Channel Width:

Auto.20/40 - Select if you are using both 802.11n and non-802.11n wireless devices.
20MHz - Select if you are not using any 802.11n wireless clients. This is the default setting.

Select Invisible if you do not want the SSID of your wireless network to be broadcasted by the DIR-615. If Invisible is selected,
the SSID of the DIR-615 will not be seen by Site Survey utilities so your wireless clients will have to know the SSID of your
DIR-615 in order to connect to it.

Refer to page 79 for more information regarding wireless security.

Best.(Auto) for best performance.

30D-Link DIR-615 User Manual

Section 3 - Configuration

Network Settings

This section will allow you to change the local network settings of the router and to configure the DHCP settings.

IP Address:

Subnet Mask:

Local Domain:

Enable DNS Relay:

Enter the IP address of the router. The default IP
address is 192.168.0.1.

If you change the IP address, once you click Apply, you
will need to enter the new IP address in your browser
to get back into the configuration utility.

Enter the Subnet Mask. The default subnet mask is

255.255.255.0.
Enter the Domain name (Optional).
Uncheck the box to transfer the DNS server information

from your ISP to your computers. If checked, your
computers will use the router for a DNS server.

31D-Link DIR-615 User Manual

Section 3 - Configuration

DHCP Server Settings

DHCP stands for Dynamic Host Control Protocol. The DIR-615 has a built-in DHCP server. The DHCP Server will
automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be
DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.” When you turn your computers
on, they will automatically load the proper TCP/IP settings provided by the DIR-615. The DHCP Server will automatically
allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting and
ending address of the IP address pool.

Enable DHCP

Server:

DHCP IP Address

Range:

Lease Time:

Always

Broadcast:

Learn NetBIOS

WAN:

Net BIOS scope:

Check this box to enable the DHCP server on your router.
Uncheck to disable this function.

Enter the starting and ending IP addresses for the DHCP
server’s IP assignment.

Note: If you statically (manually) assign IP addresses to your
computers or devices, make sure the IP addresses are outside
of this range or you may have an IP conflict.

The length of time for the IP address lease. Enter the Lease
time in minutes.

Enable this function to ensure compatibility with some DHCP
clients.

If NetBIOS advertisement is switched on, switching this setting
on causes WINS information to be learned from the WAN side, if available. Turn this setting off to configure manually.

This is an advance setting and is normally left blank. This allows the configuration of NetBIOS domain name under which
network hosts operate. This setting has no effect if the “ Learn NetBIOS information form WAN is activated.
