D Link CS8600LHA1 User Manual
FCC: DC
S-8600LH
IC: DCS-8600LHA1
Full HD Outdoor Wi-Fi Camera
User Manual
08/29/2018
Hardware: A1
Manual Version: 1.00
Manual Overview
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any
person or organization of such revisions or changes. Information in this document may become obsolete as our services and
websites develop and change. Please refer to the www.mydlink.com website for the most current information.
Manual Revisions
Revision Date Description
1.00 July 24, 2018 Initial release
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries.
All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Copyright © 2018 by D-Link Corporation, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation, Inc.
iD-Link DCS-8600LH User Manual
Table of Contents
Table of Contents
Product Overview ..............................................................1
Package Contents .........................................................................1
Introduction ................................................................................... 2
System Requirements ................................................................. 2
Hardware Overview .....................................................................3
Front .......................................................................................... 3
Side ............................................................................................ 4
Bottom ......................................................................................5
Back............................................................................................6
Power Adapter ....................................................................... 7
Safety ................................................................................................ 8
Before you Begin ...........................................................................8
Wireless Installation Considerations ......................................9
Getting Started ................................................................ 10
Mounting the Camera...............................................................10
Mounting the Power Supply ..................................................12
Setting up the Canera Through mydlink App ..................14
Using the mydlink App ....................................................16
Controlling Your Device ...........................................................16
Troubleshooting .............................................................. 21
Regulatory Information ..................................................24
iiD-Link DCS-8600LH User Manual
Section 1 - Product Overview
DCS-8600LH
Full HD Outdoor Wi-Fi Camera
Product Overview
Package Contents
Power adapter
Quick Installation Guide
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage rating than the one included with your produce will cause damage and void the warranty
for this product.
1D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Introduction
The D-Link DCS-8600LH Full HD Outdoor Wi-Fi Camera boasts a wide-angle lens that easily captures your entire room, wall-to-wall, in high-quality
1080p. You will know what is happening day or night with built in night vision, motion and sound detection sending notications to the mydlink™
app. The rotatable head makes discrete installations easy even on ceilings.
System Requirements
Network Requirements • Activated SIM card with cellular data or Wi-Fi
Smartphone with the following:
• iOS or Android-based operating system
App-based Conguration
Utility Requirements
OS Requirements:
• iOS 9.0 or higher
• Android 4.3 or higher
1
For iPhone, iPad, or Android, smartphones or tablets (please refer
to the mobile app's store page to check whether your device is
compatible)
1
1
2D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Hardware Overview
Front
Microphone
Status LED
Camera Lens
Light Sensor
1 Microphone Records audio of the surrounding area.
2 Status LED
1
2
3
4
Solid Green: Camera has successfully bounded to a Wi-Fi network. Setup is complete.
Flashing Green: Live view active.
Solid Red: Powered on.
Flashing Red: Upgrading rmware. Recovery mode.
Solid Orange: Bluetooth activated.
Flashing Orange: Bluetooth pairing.
3 Camera Lens Records video of the surrounding area. An IR LED encircles it.
4 Light Sensor
The IR-Cut Removable sensor monitors lighting conditions and switches between
color and infrared accordingly.
3D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Side
Speaker
1 Speaker Provides audio playback for the two-way audio feature.
2 Power Cord Supplies power to the camera.
1
2
Power Cord
4D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Bottom
1
Reset Button
2
microSD Card Slot
Mounting Thread
1 Reset Button Holding this recessed button down for at least 10 seconds resets the camera to factory default settings.
2 microSD Card Slot Where a microSD card can be inserted.
3 Mounting Thread 1/4x20 UNF mounting thread
3
5D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Back
1
Snap Mount Indentation
1
Snap Mount
Indentation
Where the snap mount is attached.
6D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Power Adapter
1
2
3
7D-Link DCS-8600LH User Manual
Section 2 - Installation
Safety
Please read all of the safety and operating instructions before using your device:
1. Do not open the device or attempt to repair or service it.
2. Make sure the the SD card slot cover is securely fastened before placing the camera outside.
3. Do not submerge the device in liquid or attempt to clean it with liquids or solvents. To clean the device, disconnect from
the power outlet and use a damp towel.
Before you Begin
Plan the location of your camera:
1. Verify that your camera is electrically rated to operate with the power available in your location.
2. Connect the camera's power adapter into electrical outlets that are not controlled by a wall switch. This will help you to avoid
accidentally turning o power to the device.
3. Be sure to plug the power cables into properly grounded electrical outlets in order to help prevent against electrical shock.
8D-Link DCS-8600LH User Manual
Section 2 - Installation
Wireless Installation Considerations
The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the operating range of your
wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass
through may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or
business. The key to maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling
can reduce your adapter’s range from 1 to 30 meters (3 to 90 feet). Position your devices so that the number of walls or ceilings is
minimized.
2. Be aware of the direct line between network devices. A wall that is 0.5 meters (1.5 feet) thick, at a 45-degree angle appears to be
almost 1 meter (3 feet) thick. At a 2-degree angle it looks over 14 meters (42 feet) thick! Position devices so that the signal will
travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try to position
access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects
such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your
wireless signal.
4. Keep your product away at least 1 to 2 meters (3 to 6 feet) from electrical devices or appliances that generate RF noise.
5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your
wireless connection may degrade dramatically or drop completely. Make sure your 2.4 GHz phone base is as far away from your
wireless devices as possible. The base transmits a signal even if the phone is not in use.
9D-Link DCS-8600LH User Manual
Section 2 - Installation
Getting Started
Mounting the Camera
Step 1
Place the baseplate at the desired location, assuring that it is at least 20cm from the ceiling. Make
sure the screw is facing up and the holes are level. Use a pencil to mark the holes.
Step 2
Using a 6.35 mm drill bit, drill two 25 mm deep holes over the pencil marks. For a plaster, drywall,
or concrete wall, insert the plastic anchors to support the screws rst.
1
2
Step 3
Place the baseplate over the holes. Use the supplied screws to attach the baseplate to the wall.
3
10D-Link DCS-8600LH User Manual
Section 2 - Installation
Step 4
Align the large top screw with the largest hole on the snap mount. Slide the mount down to lock
into place.
Step 5
Attach the back of the camera to the mount. Adjust the angle as desired.
4
5
11D-Link DCS-8600LH User Manual
