DCS-8000LHV2
Mini Full HD Wi-Fi Camera
User Manual
10/01/2019
Hardware: A1
Manual Version: 1.00
Manual Overview
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify
any person or organization of such revisions or changes. Information in this document may become obsolete as our services
and websites develop and change. Please refer to the www.mydlink.com website for the most current information.
Manual Revisions
Revision Date Description
1.00 October 1, 2019 Initial release
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United
States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks
of their respective companies.
Copyright © 2017 by D-Link Corporation, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from
D-Link Corporation, Inc.
iD-Link DCS-8000LHV2 User Manual
Table of Contents
Table of Contents
Product Overview ..............................................................1
Package Contents .........................................................................1
Introduction ................................................................................... 2
System Requirements ................................................................. 2
Hardware Overview .....................................................................3
Front .......................................................................................... 3
Back............................................................................................4
LED Behavior .......................................................................... 5
Installation ......................................................................... 6
Safety ................................................................................................ 6
Before you Begin ...........................................................................6
Wireless Installation Considerations ......................................7
mydlink App Camera Setup ...................................................... 8
Mounting the Camera...............................................................10
Using the mydlink App ....................................................12
Controlling Your Device ...........................................................12
Camera Options ..........................................................................13
Device .............................................................................................14
Troubleshooting .............................................................. 16
Technical Specications .................................................. 17
Regulatory Information ..................................................19
iiD-Link DCS-8000LHV2 User Manual
Section 1 - Product Overview
Product Overview
Package Contents
DCS-8000LHV2 ||
Mini Full HD Wi-Fi Camera
Baseplate
Power Adapter
2 x Screws
2 x Wall Anchors
Camera Mount
Quick Installation Guide
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage rating than the one included with your product will cause damage and void
the warranty for this product.
1D-Link DCS-8000LHV2 User Manual
Section 1 - Product Overview
Introduction
The DCS-8000LHV2 Mini Full HD Wi-Fi Camera is a compact wireless network camera suitable for day and night time
environments. It features built-in night vision, motion and sound detection, and a free mobile app — so you can feel at ease
when you’re away from home. Despite its small size, the DCS-8000LHV2 has all the features you need for monitoring your
home. Person detection allows you to be notied of human motion as it can distinguish people from other moving objects.
Unlike other cameras that bog you down with a never-ending stream of irrelevant motion-detection alerts, this camera is
smart enough to send you an alert only when it really matters. Built-in motion and sound detection will automatically send
alert notications to your mobile device. Night-time monitoring is possible with the built-in infrared LED which allows for
night-time viewing of up to 16 feet, so you can relax knowing you have 24/7 monitoring of your home or small oce.
System Requirements
• 802.11n/g wireless network
Network Requirements
• An Internet connection
• A router connected to your broadband modem
mydlink™ App Requirements
• iPhone, iPad, Android smartphone or tablet (please refer to the mobile
app's store page to check whether your device is compatible)
• Email account (for mydlink™ service registration)
2D-Link DCS-8000LHV2 User Manual
Section 1 - Product Overview
Hardware Overview
Front
1
2
3
4
5
1 Infrared LEDs Illuminate the camera’s eld of view in low light environments.
2 Microphone Picks up sound near your camera.
3 Camera Lens Records video of the surrounding area.
The IR-Cut removable sensor monitors lighting conditions and switches between
4 Light Sensor
color and infrared accordingly.
5 Status LED Refer to LED Behavior on page 5 for more information.
3D-Link DCS-8000LHV2 User Manual
Section 1 - Product Overview
Back
1
2
1 microUSB Power Port Attach your microUSB power adapter to this port to supply power to the device.
2 Reset Button Hold the recessed button down to reset the camera to factory default settings.
4D-Link DCS-8000LHV2 User Manual
Section 1 - Product Overview
LED Behavior
Status LED
Status LED
Connected to Wi-Fi and mydlink
Powering on
Ready for set up
Upgrading rmware - do not power o
5D-Link DCS-8000LHV2 User Manual
Section 2 - Installation
Installation
Safety
Please read all of the safety and operating instructions before using device:
• Do not open the device or attempt to repair it.
• Do not submerge the device in liquid or attempt to clean it with liquids or solvents. To clean the device, disconnect it
from the power outlet and use a damp towel to gently wipe it down.
Before you Begin
Plan the location of your camera:
• Verify that your camera is electrically rated to operate with the power available in your location.
• Connect the camera's power adapter into an electrical outlet that is not controlled by a wall switch. This will help avoid
accidentally turning o power to the device.
• Be sure to plug the device into a properly grounded electrical outlet in order to help prevent against electrical shock.
• Make sure that the device is rmly mounted.
6D-Link DCS-8000LHV2 User Manual
Section 2 - Installation
Wireless Installation Considerations
The DCS-8000LHV2 Mini Full HD Wi-Fi Camera lets you view video footage from virtually anywhere within the operating
range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that
the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of materials and
background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these
basic guidelines:
1. Keep the number of walls and ceilings between the camera and wireless access point to a minimum - each wall or ceiling
can reduce your camera’s range from 1 to 30 meters (3 to 90 feet). Position your devices so that the number of walls or
ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 0.5 meters (1.5 feet) thick, at a 45-degree angle
appears to be almost 1 meter (3 feet) thick. At a 2-degree angle it looks over 14 meters (42 feet) thick! Position devices so
that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try
to position access points, wireless routers, and cameras so that the signal passes through drywall or open doorways.
Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and
concrete will degrade your wireless signal.
4. Keep your product away at least 1 to 2 meters (3 to 6 feet) from electrical devices or appliances that generate RF noise.
7D-Link DCS-8000LHV2 User Manual
Section 2 - Installation
mydlink App Camera Setup
1/
2/
Download the mydlink app from the App Store (iOS) or Google Play
(Android) by scanning the QR code.
Note: Ensure that your device is wirelessly connected to the network that the
DCS-8000LHV2 will be in.
Launch the mydlink app and create a new account or sign in to your
existing account.
Note: If you are asked about allowing the app to access your location or to send
notications, select Allow. Make sure location services and Bluetooth are turned
on in your phone’s settings.
8D-Link DCS-8000LHV2 User Manual
Section 2 - Installation
3/
4/
After logging in, tap the Menu button in the top-left corner.
Select Add a Device.
Follow the onscreen instructions to complete the device setup.
