D Link CS4201A1 User Manual
Version 1.00 | 04/24/2015
User Manual
Vigilance HD Wireless Camera
DCS-4201
Preface
D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or
organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and
change. Please refer to the www.mydlink.com website for the most current information.
Manual Revisions
Revision Date Description
1.0 April 24, 2015 DCS-4201 Revision A1 with rmware version 1.00
Trademarks
D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other
countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.
Copyright © 2015 D-Link Corporation.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation.
2D-Link DCS-4201 User Manual
Table of Contents
Product Overview ......................................................................... 4
Package Contents ................................................................. 4
Introduction ............................................................................ 5
System Requirements ......................................................... 5
Features .................................................................................... 6
Hardware Overview ............................................................. 7
Front ...................................................................................... 7
Rear ........................................................................................ 8
Sides ...................................................................................... 9
Wireless Installation Considerations ............................10
Installation ....................................................................................11
Hardware Installation ........................................................11
Mount the Camera .............................................................12
Conguration with Wizard ..............................................13
Viewing Camera via Web Browser ............................17
Setup Wizard SE ...................................................................17
Conguration ...............................................................................19
Audio and Video ..............................................................35
Preset ...................................................................................37
Motion Detection ...........................................................39
Sound Detection .............................................................41
Time and Date ..................................................................42
Event Setup .......................................................................43
SD Card ...............................................................................52
Advanced ...............................................................................53
Digital Input/Output ......................................................53
ICR and IR ...........................................................................54
HTTPS .................................................................................. 55
Access List ..........................................................................56
Maintenance .........................................................................57
Device Management .....................................................57
System ................................................................................58
Firmware Upgrade ..........................................................59
Status ......................................................................................60
Using the Conguration Interface ................................19
Live Video ..............................................................................20
Setup .......................................................................................22
Setup Wizard ....................................................................22
Network Setup .................................................................27
Wireless Setup ..................................................................31
Dynamic DNS ...................................................................32
Image Setup .....................................................................33
Device Info ........................................................................60
Logs .....................................................................................61
Help......................................................................................62
DI/DO Specications .................................................................63
Technical Specications ...........................................................64
3D-Link DCS-4201 User Manual
Section 1: Product Overview
Package Contents
DCS-4201 Vigilance HD Wireless Camera
CAT5 Ethernet cable
Power adapter
CD-ROM with User Manual and software
Product Overview
Quick Installation Guide
If any of the above items are missing, please contact your reseller.
Safety Notice: Installation and servicing should be done by certied technicians so as
to conform to all local codes and prevent voiding your warranty.
4D-Link DCS-4201 User Manual
Section 1: Product Overview
Introduction
Congratulations on your purchase of the DCS-4201 Vigilance HD Wireless Camera. The DCS-4201 is a versatile and unique
solution for your small oce. Unlike a standard webcam, the DCS-4201 is a complete system with a built-in CPU and web
server that transmits high quality video images for security and surveillance. The DCS-4201 can be accessed remotely, and
controlled from any PC/Notebook over your local network or through the Internet via a web browser. The simple installation
and intuitive web-based interface oer easy integration with your Ethernet/Fast Ethernet or 802.11n/g wireless network. The
DCS-4201 also comes with motion and sound detection features for a complete security solution.
System Requirements
• Computer with Microsoft Windows® 7/8/Vista, Mac OS or Linux
• Internet Explorer 7, Firefox 20, Safari 6, or higher version with Java installed and enabled
• Existing 10/100 Ethernet-based network
• A microSD memory card (optional) is required for recording to onboard storage. SDHC Class 6 or above is recommended.
5D-Link DCS-4201 User Manual
Section 1: Product Overview
Features
Simple to Use
The DCS-4201 is a stand-alone system with a built-in CPU, requiring no special hardware or software. The DCS-4201 supports both ActiveX mode
for Internet Explorer and Java mode for other browsers such as Firefox® and Safari®.
Supports a Variety of Platforms
Supporting TCP/IP networking, HTTP, and other Internet related protocols. The DCS-4201 can also be integrated easily into other Internet/Intranet
applications because of its standards-based features.
Advanced Event Management
The DCS-4201 can be set up to send e-mail notications with snapshots when an event occurs, such as when motion is detected. Events can be
triggered from several sources, such as motion detection and time based events.
Broad Range of Applications
With today’s high-speed Internet services, the Network Camera can provide the ideal solution for delivering live video images over the Intranet and
Internet for remote monitoring. The Network Camera allows remote access using a Web browser for live image viewing, and allows the administrator
to manage and control the Network Camera anytime, anywhere in the world. Many applications exist, including industrial and public monitoring
of homes, oces, banks, hospitals, child-care centers, and amusement parks.
IR LED for Day and Night functionality
The built-in infrared LED enables night time viewing of up to 10 meters.
802.11n Wireless or Ethernet/Fast Ethernet Support
The DCS-4201 oers wireless 802.11n and Ethernet/Fast Ethernet connectivity, making the network camera easy to integrate into your existing
network environment. The DCS-4201 works with a 10Mbps Ethernet based network or 100Mbps Fast Ethernet based network for traditional wired
environments, and works with 802.11n routers or access points for added exibility. The Site Survey feature also allows you to view and connect to
any available wireless networks.
6D-Link DCS-4201 User Manual
Section 1: Product Overview
Front
5
Hardware Overview
1
2
4
6
7
3
1 Status LED Indicates the camera's current status
2 Infrared LED Used to illuminate the camera's eld of view at night
3 PIR Sensor Passive infrared sensor for motion detection
4 Camera Lens Records video of the surrounding area
5 Microphone Records audio from the surrounding area
6
7
Light Sensor
Speaker
The light sensor monitors lighting conditions and switches between day and
night vision modes accordingly
Can play audio sent to camera for two-way communication
7D-Link DCS-4201 User Manual
Section 1: Product Overview
Rear
1
3
4
5
2
1 Ethernet Port
2 Reset Button
3 Power Connector
4 DI/DO Connector
5 Adjustment Ring Tighten or loosen the adjustment ring to adjust the camera's position
Connects to your Ethernet network
Press and hold this button for 10 seconds to reset the camera
Connects to the included DC 5 V power adapter
I/O connectors for external devices
8D-Link DCS-4201 User Manual
Section 1: Product Overview
Sides
1
1 microSD Card Slot
Insert a microSD card for storing recorded images and video locally
9D-Link DCS-4201 User Manual
Section 1: Product Overview
Wireless Installation Considerations
This D-Link device can connect to your wireless network from anywhere within the operating range of your wireless network.
However, the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through,
may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in
your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1. Minimize the number of walls and ceilings between your adapter and other network devices (such as your network
camera) - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters).
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears
to be almost 3 feet (1 meter) thick. At a 2-degree angle, it looks over 42 feet (14 meters) thick. Position your devices so
that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may weaken the wireless signal. Try to position
your access points, wireless routers, and other networking devices where the signal passes through drywall or open
doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets,
brick, and concrete will degrade your wireless signal.
4. Keep your product at least 3-6 feet or 1-2 meters away from electrical devices or appliances that generate RF noise.
5. If you are using 2.4GHz cordless phones or other radio frequency sources (such as microwave ovens), your wireless
connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your
wireless devices as possible. The base transmits a signal even if the phone is not in use.
10D-Link DCS-4201 User Manual
Section 2: Installation
Installation
Hardware Installation
If you wish to set up your camera without using the Camera Setup Wizard, please follow these steps.
Connect the Ethernet Cable
Connect the included Ethernet cable to the network cable connector located on
the panel at the rear of the DCS-4201 and attach it to the network.
Attach the External Power Supply
Attach the external power supply to the DC Power receptor located on the rear
panel of the DCS-4201 and connect it to your wall outlet or power strip.
Note: If you choose to take advantage of the Power over Ethernet feature you
may unplug the power cable.
11D-Link DCS-4201 User Manual
Section 2: Installation
We suggest that you congure the camera before mounting.
Mount the Camera
Please refer to the steps below to assist you with mounting the camera.
1. Place the mounting base where you want to position the camera and use a pencil
to mark the holes.
2. Depending on the material of the wall or ceiling, use proper tools to drill two
holes or screws where you marked. If the wall is made out of concrete, drill the
holes rst, insert the plastic anchors and then the screws.
The space between the camera and the screwheads should be 3 mm.
3. Place the mounting base over the screw that is mounted on the wall. Make sure
to t the screw-heads over the big holes and slide it downward to lock rmly.
Lightly pull the base forward to make sure that it is locked.
4. Place the base cover on the base and screw the camera stem clockwise into the
mounting base.
1
2
3
4
5. Adjust the angle of the camera as desired, then tighten the collar on the camera
stem to lock it in place.
5
12D-Link DCS-4201 User Manual
Section 2: Installation
Conguration with Wizard
Insert the DCS-4201 CD into your computer's CD-ROM drive to begin the installation. If the Autorun function on your
computer is disabled, or if the D-Link Launcher fails to start automatically, click Start > Run. Type D:\autorun.exe,
where D: represents the drive letter of your CD-ROM drive.
Click Setup Wizard to begin the installation.
After clicking Setup Wizard, the following window will open.
Click Next to continue.
13D-Link DCS-4201 User Manual
Section 2: Installation
Click Yes to accept the License Agreement.
Click Next to start the installation process.
Note: The installation may take several minutes to
nish.
Click Finish to complete the installation.
14D-Link DCS-4201 User Manual
Section 2: Installation
Click on the D-Link Setup Wizard SE icon that was created in your
Windows Start menu.
Start > D-Link > Setup Wizard SE
The Setup Wizard will appear and display the MAC address and
IP address of your camera(s). If you have a DHCP server on your
network, a valid IP Address will be displayed. If your network does
not use a DHCP server, the network camera's default static IP
192.168.0.20 will be displayed.
Click the Wizard button to continue.
Enter the Admin ID and password. When logging in for the rst time,
the default Admin ID is admin with the password left blank.
Click Next to continue.
15D-Link DCS-4201 User Manual
Section 2: Installation
Select DHCP if your camera obtains an IP address
automatically from a DHCP server (e.g., router). Select Static
IP if you want to manually enter the IP settings for the camera.
Click Next to continue.
Take a moment to conrm your settings and click Restart.
16D-Link DCS-4201 User Manual
Section 2: Installation
Setup Wizard SE
Viewing Camera via Web Browser
Click on the D-Link Setup Wizard SE icon that was created in your
Windows Start menu.
Start > D-Link > Setup Wizard SE
Select the camera and click Link to access the web
conguration.
The Setup Wizard will automatically open your web browser
to the IP address of the camera.
17D-Link DCS-4201 User Manual
Section 2: Installation
Enter admin as the default username and leave
the password blank. Click OK to continue.
This section displays your camera’s live video. You can select
your video prole and view or operate the camera. For additional
information about web conguration, please refer to the user
manual included on the CD-ROM or the D-Link website.
18D-Link DCS-4201 User Manual
Section 3: Conguration
Conguration
Using the Conguration Interface
After completing the Camera Installation Wizard, you are ready to use your camera. The camera’s built-in Web conguration utility is designed to
allow you to easily access and congure your DCS-4201. At the end of the wizard, enter the IP address of your camera into a web browser, such as
Mozilla Firefox. To log in, use the User name admin and the password you created in the Installation Wizard. If you did not create a password, the
default password is blank. After entering your password, click OK.
19D-Link DCS-4201 User Manual
Section 3: Conguration
Live Video
This section shows your camera’s live video. You may select any of the available icons listed below to operate the camera. You may also select your
language using the drop-down menu on the left side of the screen.
You can zoom in and out on the live video image using your mouse. Right-click to zoom out or left-click to zoom in on the image.
SD Status:
IO Status:
Digital Input Indicator This indicator will change color when a digital input
Motion Trigger
Indicator
Recording Indicator When a recording is in progress, this indicator will
Control Pad
Auto Pan Starts the automatic panning function.
This option displays the status of the microSD card. If no
microSD card has been inserted, this screen will display
the message "Card Invalid."
This option displays the status of your I/O device if a
device has been connected.
signal is detected.
This indicator will change color when a trigger event
occurs.
Note: The video motion feature for your camera must
be enabled.
change color.
This control pad can be used to electronically pan, tilt,
and zoom (ePTZ) within the camera's predened view
area, if one has been dened.
Stop Stops automatic panning.
Preset Path Starts the camera's motion along the predened path.
ePTZ Speed:
You may select a value between 0 and 64. 0 is the slowest
and 64 is the fastest.
20D-Link DCS-4201 User Manual
Section 3: Conguration
Global View:
Language:
Video Prole 1
Video Prole 2
Video Prole 3
Full screen mode
Taking a Snapshot
Go To (Preset List):
This window indicates the total eld of view (FOV) of
the camera. The red box indicates the visible region of
interest (ROI).
You may select the interface language using this menu.
Record a Video Clip
Set a Storage Folder
Listen/Stop Audio In (from microphone)
Start/Stop Audio Out (to speaker)
Start/Stop Digital Output
If any presets have been dened, you can select them
here to move the camera to the selected preset.
21D-Link DCS-4201 User Manual
Loading...
