D-link AC3200 DIR-890L User Manual

DIR-890L

AC3200 Ultra Wi-Fi Router

Quick Install Guide

Package Contents

DIR-890L AC3200 Ultra Wi-Fi Router

Power Adapter

Ethernet Cable

Wi-Fi Conguration Card

Quick Install Guide

If any of the above items are missing, please contact your reseller.

Minimum Requirements

Network Requirements:

• An Ethernet-based broadband modem

Web-based Conguration Requirements

Computer with the following:

• Windows® or Mac OS® X operating system

• An installed Ethernet adapter or wireless adapter

Supported Browsers:

• Internet Explorer® 8 or higher, Safari® 5.1 or higher*, Firefox® or Chrome™
Make sure you have the latest version of Java installed. Visit www.java.com

to download the latest version.

*Note: We recommend Internet Explorer® 11 and Safari® 7 for best performance.

mydlink Requirements

• For mydlink and mydlink app requirements refer to:

http://www.mydlink.com

3

Hardware Overview

1 65432

8

9

7

1 SS USB LED A solid white light indicates a USB 3.0 device is connected.

2 USB LED A solid white light indicates a USB 2.0 device is connected.

3 5G LED

4 2.4G LED

5 Internet LED

6 Power LED

7 USB 3.0 Port

8 USB 2.0 Port

9 Reset Button

10 WPS Button Press to start the WPS process. The 2.4G or 5G LED will blink fast.

LAN Ports

11

12 Internet Port Connect a broadband modem to this port using an Ethernet cable.

13 Power Button Press to power the router on and o.

14 Power Port Connect the supplied power adapter.

(1-4)

A solid white light indicates the 5GHz wireless function is working properly.
During the WPS process, this light will blink quickly.

A solid white light indicates the 2.4GHz wireless function is working properly.
During the WPS process, this light will blink quickly.

A solid white light indicates a connection to the Internet port. If the LED is
orange, the connection is good but the router cannot connect to the Internet.

A solid white light indicates a proper connection to the power supply. The light
will be solid orange during boot-up.

Connect a USB ash drive to share content throughout your network. Port
supports USB 3.0 and USB 2.0 devices.

Connect a USB ash drive to share content throughout your network. Port
supports USB 2.0 devices.

Press and hold the reset button with a paper clip for ten seconds to reset the
router to the factory default settings.

Connect Ethernet devices such as computers, switches, and game consoles.

11

12

10

14

13

4

Before you Start

• Users with DSL providers - If you are using a PPPoE connection, you will need

your PPPoE user name and password. If you do not have this information, contact
your Internet provider. Do not proceed until you have this information.

• Users with Cable providers - Make sure you unplug the power to your modem.

In some cases, you may need to turn it o for up to 5 minutes.

• Advanced Users - If your ISP provided you with a modem/router combo, you will

need to set it to “bridge” mode so the DIR-890L router can work properly. Please
contact your ISP or refer to the user manual for your modem/router device.

Connect your Router

Unplug the power to your DSL or Cable modem.

1

Modem

Connect an Ethernet cable from the Internet port of the router to the

2

Ethernet port on your DSL or Cable modem.

Ethernet Port

DCN IN

INTERNET

POWER

...

-

12V

SA

Internet Port (yellow)

Modem

WSP

RESET

1 2 3 4

USB 2.0USB 3.0

Ethernet Cable

DIR-890L

5

Connect another Ethernet cable from the Ethernet port on your

3

computer to one of the LAN ports on the router.

WSP

RESET

1 2 3 4

USB 2.0USB 3.0

DCN IN

INTERNET

POWER

...

-

12V

SA

DIR-890L

Computer

Ethernet Cable

Plug the power back into your DSL or cable modem. Please wait about

4

one minute before continuing.

INTERNET

POWER

DCN IN

...

-

12V

SA

DIR-890L

Modem

WSP

RESET

1 2 3 4

USB 2.0USB 3.0

Computer

6

Plug the power adapter into your router and connect to an available

5

power outlet or surge protector. If the Power LED does not light up, press
the Power button on the back of the router.

1 2 3 4

DCN IN

INTERNET

POWER

...

-

12V

SA

WSP

RESET

USB 2.0USB 3.0

DIR-890L

Modem

After the router has powered up, verify that the Power (white) and Internet

6

(white or orange) LEDs are both lit. Proceed with router conguration.

Conguration

There are two ways to congure your router:

A. Web Browser - Use a web browser from your computer.
B. QRS Mobile app - Use a mobile device with the D-Link QRS Mobile app.

Refer to the QRS Mobile Setup section for more information.

A. Web Browser Conguration

Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari)

1

and enter http://dlinkrouter.local./ or the IP address of the router
(http://192.168.0.1).

7

When the Welcome screen appears, click Next to continue.

2

The router will automatically detect your Internet connection type. If not, then

3

select your Internet connection and click Next to continue.

DSL (PPPoE) users enter your PPPoE user name and password supplied by

4

your ISP. Click Next to continue.

8

Create a name for your Wi-Fi Network and a password. Your wireless devices

5

(i.e., tablets, smartphones, and laptops) will need to have this information
entered to be able to connect to your wireless network. Click Next to
continue.

Continue with the Setup Wizard to nish conguring your DIR-890L router.

6

Once completed, the Internet LED will turn white indicating that your router
is connected to the Internet.

Note: Setting up “mydlink” is optional and not required for the router
to function.

Congratulations! You have completed the router installation.

Antenna Orientation

The DIR­connection possible. In order to maximize performance, orient the antennas
at an angle, pointing outward and away from the base unit.

890L is designed to give you the fastest, most stable network

45°

9

B. QRS Mobile Setup

85

Scan the code below or search “QRS Mobile” (App Store or Google Play) to

1

download the QRS Mobile App to your iPhone, iPad, or Android device.

iOS

Once your app is installed, you may now congure your router. Connect to

2

the router wirelessly by going to your wireless utility on your device. Scan

Android QRS Mobile App

for the wireless network name as listed on the supplied Wi-Fi Conguration
card/sticker. Select the network and then enter the Wi-Fi Password.

D-Link Wi-Fi Conguration Card

Default Conguration

Username: ”Admin”
Password: ” ”(leave the eld blank)

Once connected, click on the QRS Mobile icon from your mobile device,

3

then click Start to continue. Please follow the on-screen instructions to

Wi-Fi Name(SSID)

Wi-Fi Password:

Your conguration

Username: ”Admin”
Password:

DCCAROWIFI0020

complete the setup.

Once the Setup Complete screen appears, click Save and write down the

4

new Wi-Fi Network name and password on your companion card for future
reference.

10

Note: To reconnect to your router, launch your wireless utility, select the new
Wi-Fi Network you created, and then enter your new Wi-Fi password.

Troubleshooting

How do I connect my wireless devices to the DIR-890L router?

1. Open your wireless network utility that displays available wireless networks.

2. Select the Wi-Fi Network name you assigned in the wizard and connect.
Note: If you did not run the setup wizard or you reset the router to its default

settings, refer to the Wi-Fi Conguration Card included for the default Wi-Fi
Network Name and Wi-Fi Password.

You can also connect wireless devices to the DIR-890L router using WPS:

1. Press the WPS button on the DIR-890L for three seconds.

2. Within one minute press the WPS button on your wireless device.

3. Allow up to two minutes to connect.

Note: Some devices may require you to log in to a utility to start the WPS process.

Refer to the user manual of the device you want to connect to the router if you do
not know how to start the WPS process.

How do I change the wireless settings on the DIR-890L router?

1. Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari) and

enter http://dlinkrouter.local./ You can also enter the IP address of the
router (http://192.168.0.1).

2. At the login screen, enter the router password you created in the wizard (no

password by default).

3. Go to Setup > Wireless Settings > Manual Wireless Network Setup to

create a new Wi-Fi network name (SSID) and Wi-Fi password.

*Documentation available at http://www.dlink.com/DIR-890L.
