DWL-700AP User’s Manual
Package Contents
Package Contents
Contents of Package:
D-Link Air® DWL-700AP
2.4GHz Wireless Access Point
Power Supply - 5V DC, 2.0A
Manual on CD
Quick Installation Guide
Ethernet Cable
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a different voltage rating than the one included with
the DWL-700AP will cause damage and void the warranty for this product.
System Requirements:
Computer with Windows, Macintosh, or Linux-based operating
system with an installed Ethernet adapter
Internet Explorer or Netscape Navigator version 6.0 or above,
with JavaScript enabled
3D-Link Systems, Inc.
DWL-700AP User’s Manual
The versatile D-Link Air DWL-700AP Wireless Access Point is an 802.11b high-performance
wireless device that can be used in one of three modes: as an access point, a repeater, or
a wireless client. It is an ideal way to extend the reach and number of computers connected
to your wireless network.
The DWL-700AP is compatible with existing 802.11b devices such as the D-Link Air and
AirPlus family of products including the DWL-650 and DWL-650+ Wireless Cardbus Adapters,
the DI-614+ Wireless Router, and the DWL-120 Wireless USB Adapter.
After completing the steps outlined in the Quick Installation Guide (included in your package)
you will have the ability to share information and resources, such as files and printers, and
enjoy the freedom that wireless networking brings.
The DWL-700AP is compatible with most popular operating systems, including Macintosh,
Linux and Windows, and can be integrated into a larger network. This manual is designed
to help you connect the Access Point and the D-Link Wireless Adapters into a network in
Infrastructure mode. Please take a look at the Getting Started section in this manual to see
an example of an Infrastructure network using the DWL-700AP.
Introduction
Introduction
The IEEE 802.11b Ethernet standard allows you to connect computers and 802.11b
compatible devices at speeds up to 11Mbps*, dependent upon the distance between wireless
adapters, the configuration of your working environment, or the capabilities or limitations of
your computer systems.
* Maximum wireless signal rate based on IEEE Standard 802.11b specifications. Actual data
throughput will vary. Network conditions and environmental factors, including volume of network
traffic, building materials and construction, and network overhead lower actual data throughput
rate.
4D-Link Systems, Inc.
DWL-700AP User’s Manual
3 Operational Modes – Use the DWL-700AP as an access point, a repeater, or a wireless client.
Fully 802.11b Compatible – Fully compatible with the IEEE 802.11b standard and interoperable
with all existing 802.11b compliant devices.
Provides a level of security with up to 128-bit WEP Encryption – Supports 64 and 128-bit WEP
encryption for a level of security for your data and wireless communication.
Built-in DHCP Server – If enabled, it will automatically assign IP addresses to wireless clients on
the local network.
Web-based interface for managing and configuring – Easy-to-use interface independent of the
operating system.
LEDs
Features and Benefits
Features and Benefits
LED stands for Light-Emitting Diode. The DWL-700AP Wireless Access Point has 3 LEDs as shown below:
Power: solid green light indicates
connection to a power source
LAN: blinking green light indicates
activity; solid green light indicates
connection
WLAN: blinking green light indicates
wireless activity; solid green light
indicates connection
5D-Link Systems, Inc.
DWL-700AP User’s Manual
D-Link wireless products are based on industry standards to provide easy-to-use and
compatible high-speed wireless connectivity within your home, business or public access
wireless networks. D-Link wireless products will allow you access to the data you want,
when and where you want it. You will be able to enjoy the freedom that wireless networking
brings.
A Wireless Local Area Network (WLAN) is a cellular computer network that transmits and
receives data with radio signals instead of wires. WLANs are used increasingly in both home
and office environments, and public areas such as airports, coffee shops and universities.
Innovative ways to utilize WLAN technology are helping people to work and communicate
more efficiently. Increased mobility and the absence of cabling and other fixed infrastructure
have proven to be beneficial for many users.
Wireless users can use the same applications they use on a wired network. Wireless adapter
cards used on laptop and desktop systems support the same protocols as Ethernet adapter
cards.
People use WLAN technology for many different purposes:
Wireless Basics
Wireless Basics
Mobility - Productivity increases when people have access to data in any location within the
operating range of the WLAN. Management decisions based on real-time information can
significantly improve worker efficiency.
Low Implementation Costs – WLANs are easy to set up, manage, change and relocate.
Networks that frequently change can benefit from WLANs ease of implementation. WLANs
can operate in locations where installation of wiring may be impractical.
Installation and Network Expansion - Installing a WLAN system can be fast and easy and
can eliminate the need to pull cable through walls and ceilings. Wireless technology allows
the network to go where wires cannot go - even outside the home or office.
Scalability – WLANs can be configured in a variety of ways to meet the needs of specific
applications and installations. Configurations are easily changed and range from Peer-to-Peer
networks suitable for a small number of users to larger infrastructure networks to accommodate
hundreds or thousands of users, depending on the number of wireless devices deployed.
Inexpensive Solution - Wireless network devices are as competitively priced as conventional
Ethernet network devices.
6D-Link Systems, Inc.
DWL-700AP User’s Manual
Installation Considerations
The number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass
through, may limit the range. Typical ranges vary depending on the types of materials and background RF
(radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these
basic guidelines:
Wireless Basics
Wireless Basics (continued)
1
2
3
4
Keep the number of walls and ceilings between the DWL-700AP and other network
devices to a minimum - each wall or ceiling can reduce your D-Link Air Wireless
product’s range from 3-90 feet (1-30 meters). Position your devices so that the number
of walls or ceilings is minimized.
Be aware of the direct line between network devices. A wall that is 1.5 feet thick
(.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a
2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the
signal will travel straight through a wall or ceiling (instead of at an angle) for better
reception.
Building Materials can impede the wireless signal - a solid metal door or aluminum
studs may have a negative effect on range. Try to position wireless devices and
computers with wireless adapters so that the signal passes through drywall or open
doorways and not other materials.
Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices
or appliances that generate RF noise.
7D-Link Systems, Inc.
DWL-700AP User’s Manual
Setting up a Wireless Infrastructure Network
Getting Started
Getting Started
2
1
3
4
5
Please remember that D-Link Air wireless devices are pre-configured to connect
together, right out of the box, with their default settings.
6
For a typical wireless setup at home (as shown above), please do the following:
You will need broadband Internet access (a Cable or DSL-subscriber line into
your home or office).
Consult with your Cable or DSL provider for proper installation of the modem.
Connect the Cable or DSL modem to your broadband router (see the Quick
Installation Guide included with your router.)
Connect the router to the D-Link Air DWL-700AP.
(See the Quick Installation Guide included with the DWL-700).
If you are connecting a desktop computer in your network, you can install the
D-Link Air DWL-520 Wireless PCI Adapter into an available PCI slot on your
desktop computer.
(See the Quick Installation Guide included with the DWL-520).
Install the D-Link Air DWL-650 Wireless Cardbus Adapter into a laptop computer.
(See the Quick Installation Guide included with the DWL-650).
8D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility
If you wish to change the default settings or optimize the performance of the DWL-700AP, D-Link has
included a configuration utility for this purpose.
Whenever you want to configure your network or the DWL-700AP, you can access the Configuration Utility
by opening the web-browser and typing in the IP address of the DWL-700AP. The DWL-700AP’s default IP
address is shown below:
Open the web browser
Type in the IP address of
the access point
Using the Configuration Utility
(The IP address shown in the example above is the default setting. Use this IP address when connecting to
a network consisting of other D-Link devices set to their default settings. If you have changed the IP address
of the DWL-700AP to conform to a network other than one with D-Link devices, then input that IP address in
the web browser, instead of the default IP address shown.)
Type admin in the
User name field
Leave the Password
blank
Click OK
9D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
After logging in, the screen below will appear. Click on the tabs in the screen to access different segments
of the Configuration Utility. If you choose to use the web-based configuration menu, please configure the
DWL-700AP from a computer with an ethernet connection to the DWL-700AP.
Home > Wizard
Using the Configuration Utility
Apply
Cancel
Help
Restart
Clicking Apply will save changes made to the page.
Clicking Cancel will clear changes made to the page.
Clicking Help will bring up helpful information regarding the page.
Clicking Restart will restart the router..(Necessary for some changes.)
10D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Home > Wireless
Using the Configuration Utility
AP Name: You may choose to rename your access point, especially if you have more
than one access point on your network.
SSID: The SSID is a unique name that identifies a network. All devices on a network
must share the same SSID name in order to communicate on the network. If you choose
to change the SSID from the default setting, input your new SSID name in this field.
The SSID can be up to 32 characters in length.
Channel: Channel 6 is the default channel. Input a new number if you want to change
the default setting. All devices on the network must be set to the same channel to
communicate on the network.
WEP Encryption: Select Enable Encryption to use WEP (Wired Equivalent Privacy)
on the network. All devices on the network, and the access point, must share the same
WEP selection – either Enable or Disable, and they must share the same WEP key.
The WEP key is generated from ASCII or Hexadecimal entries that are either 64-,
128-or 256- bit in length.
When enabling encryption, select the Key Type (ASCII or Hexadecimal) and then input
the appropriate digits or letters. You can create up to 4 keys. Select the key you wish
to use.
Hexadecimal digits consist of the numbers 0-9 and the letters A-F
ASCII (American Standard Code for Information Interchange) is a code
for representing English letters as numbers from 0-127
11D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Home > LAN
Using the Configuration Utility
Dynamic IP Address: Select this option if you would like to have an IP address
automatically assigned to the DWL-700AP by a DHCP server in your network.
DHCP stands for Dynamic Host Configuration Protocol. It is a protocol for assigning dynamic IP addresses “automatically.” With a DHCP Server there is no need
to manually assign an IP address.
Static IP Address: Select this option if you are manually assigning an IP address.
IP Address: 192.168.0.50 is the default IP address of the access point.
Subnet Mask: 255.255.255.0 is the default subnet mask. All devices on the
network must have the same subnet mask to communicate on the network.
Gateway: Enter the IP address of the gateway in your network.
IP Address
If you need to assign static IP addresses to the devices in your network, please
remember that the IP address for each computer or device must be in the same
IP address range as all the devices in the network. Each device must also have
the same subnet mask. For example: Assign the first computer an IP address of
192.168.0.2 and a subnet mask of 255.255.255.0, the second device an IP address of 192.168.0.3 and a subnet mask of 255.255.255.0, and so on. Devices
that are assigned the same IP address may not be visible on the network.
12D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Home > DHCP
Using the Configuration Utility
DHCP Server: Select Enabled or Disabled. Disabled is the default setting. If you
want to use the access point as a DHCP server to automatically assign dynamic IP
addresses on the network, you will select Enabled.
Starting IP Address: If you have enabled the DHCP server function, enter the
starting point of the IP address range for your network.
Ending IP Address: Enter the ending IP address of your IP address range, if you
have enabled the DHCP function of the access point.
Lease Time: Choose the length of time during which the DHCP function of the
DWL-700AP automatically regenerates the IP addresses to the devices in your
network.
DHCP Client Table: Lists the devices on your network that are receiving dynamic
IP addresses from the access point.
13D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Advanced > Mode
Access Point: Select this option to use the DWL-700 AP as an access point in your
network.
Using the Configuration Utility
Wireless Client: Select this option to use the DWL-700AP as a wireless client in your
network. A wireless client is a device that connects to the network through a router or
an access point.
Remote AP MAC: Input the MAC Address of the remote AP to which the
DWL-700AP will connect when it is in wireless client mode.
Site Survey: Click the Site Survey button to select a remote AP to which you
wish to connect.
Repeater: Select this option to use the DWL-700AP to extend the reach of a remote
AP by repeating the signal.
Remote AP MAC: Input the MAC Address of the remote AP that will have its
range extended by the DWL-700AP.
Site Survey: Click the Site Survey button to select a remote AP that you wish
to repeat.
14D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
The default Performance settings are shown here.
Beacon Interval: Beacons are
packets sent by an access point
to synchronize a wireless network.
Specify a beacon interval value.
Default (100) is recommended.
RTS Threshold: This value
should remain at its default setting of 2,437. If you encounter
inconsistent data flow, only minor
modifications to the value range
between 256 and 2,437 are recommended.
Fragmentatio n: This val ue
should remain at its default setting of 2,347. If you experience a high packet error rate,
you may slightly increase your fragmentation threshold within the value range of 256 to
2,346. Setting the fragmentation threshold too low may result in poor performance.
DTIM Interval (Beacon Rate): (Delivery Traffic Indication Message) Enter a value
between 1 and 255 (default is 3) for the Delivery Traffic Indication Message. A DTIM
is a countdown informing clients of the next window for listening to broadcast and
multicast messages.
Basic Rates: Default is 2Mbps. We recommend that you keep the setting at default. If
you lose connection at the TX rate, you will regain connection at the basic rate. A lower
basic rate will make reconnection easier.
TX Rates: Select the transmission rate for the network. The default rate is 11Mbps.
Preamble: Long Preamble is the default setting. (High traffic networks should use
the shorter preamble type.) The preamble defines the length of the CRC block (Cyclic
Redundancy Check is a common technique for detecting data transmission errors)
used in communication between the access point and the roaming wireless network
adapters.
Authentication:
Open System - communicates the key across the network.
Shared Key - devices must have identical WEP settings to communicate.
Auto - automatically adjusts to the Authentication mode of the wireless client.
SSID Broadcast: (Service Set Identifier) Enable or Disable (default) the broadcast of
the SSID name across the network. SSID is a name that identifies a wireless network.
All devices on a network must use the same SSID to establish communication.
Using the Configuration Utility
Advanced > Performance
15D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Advanced > Filters
Using the Configuration Utility
Use MAC Filters to allow or deny computers by their MAC Addresses from accessing the DWL-700AP. You can either manually add a MAC Address or select the MAC
Address from the list of clients that are currently connected to the broadband router
(Connected PCs). The default setting is Disabled MAC Filters.
MAC Filter List: This list will display the MAC Addresses that are in the selected
filter.
16D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Tools > Admin
New Password: Enter the new password.
Confirm Password: Re-enter the password to confirm it.
Using the Configuration Utility
Tools > System
Restore: You may also restore the factory settings by clicking on Restore. Make sure to
save the unit’s settings before clicking on Restore.
Save Settings: The current system settings can be saved as a file onto the local hard
drive.
Load Settings: The saved file or any other saved setting file can be loaded back on the
access point. To reload a system settings file, click on Browse to browse the local hard drive
and locate the system file to be used. Click Load when you have selected the file to be loaded
back onto the access point.
Reset: To complete the reset, click Reset.
17D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Tools > Firmware
Click on Click here to check for the latest firmware.... Download the latest firmware
to your hard drive. Then click Browse on this page to find the firmware upgrade on
your hard drive.
Click Apply to start the firmware upgrade.
Using the Configuration Utility
Status > Device Info
This screen displays the current wireless and Ethernet settings of the DWL-700AP.
18D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Status > Log
Using the Configuration Utility
View Log
The access point keeps a running log of events and activities occurring on the AP. If
the device is rebooted, the logs are automatically cleared.
First Page - The first page of the log.
Last Page - The last page of the log.
Previous - Moves back one log page.
Next - Moves forward one log page.
Clear - Clears the logs completely.
19D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Configuration Utility (continued)
Traffic Statistics
The access point keeps traffic
statistics. You are able to view the
statistics of the router on both the
Ethernet portion of the network
and the wireless portion of the
network. The traffic counter will
reset if the device is rebooted.
Connected
Wireless PCs LIst
This list displa y s t he M AC
Addresses of connected PC’s and
the length of time that they have
been connected.
Using the Configuration Utility
Status> Stats
Status > Wireless
Menu
Select from this menu for extra
help.
Help
20D-Link Systems, Inc.
DWL-700AP User’s Manual
Using the Network Setup Wizard in Windows XP
In this section you will learn how to establish a network at home or work, using
Microsoft Windows XP.
Note: Please refer to websites such as http://www.homenethelp.com and http://www.
microsoft.com/windows2000 for information about networkingcomputers using
Windows 2000, ME or 98SE.
Go to Start>Control Panel>Network Connections
Select Set up a home or small office network
Networking Basics
Networking Basics
When this screen appears, click Next.
21D-Link Systems, Inc.
DWL-700AP User’s Manual
Please follow all the instructions in this window:
Networking Basics
Networking Basics (continued)
Click Next.
In the following window, select the best description of your computer. If your
computer connects to the internet through a gateway/router, select the second option
as shown.
Click Next.
22D-Link Systems, Inc.
DWL-700AP User’s Manual
Enter a Computer description and a Computer name (optional.)
Networking Basics
Networking Basics (continued)
Click Next.
Enter a Workgroup name. All computers on your network should have the same
Workgroup name.
Click Next.
23D-Link Systems, Inc.
DWL-700AP User’s Manual
Please wait while the Network Setup Wizard applies the changes.
Networking Basics
Networking Basics (continued)
When the changes are complete, click Next.
Please wait while the Network Setup Wizard configures the computer.
This may take a few minutes.
24D-Link Systems, Inc.
DWL-700AP User’s Manual
In the window below, select the option that fits your needs. In this example, Create
a Network Setup Disk has been selected. You will run this disk on each of the
computers on your network. Click Next.
Networking Basics
Networking Basics (continued)
Insert a disk into the Floppy Disk Drive, in this case drive A.
25D-Link Systems, Inc.
DWL-700AP User’s Manual
Please read the information under Here’s how in the screen below. After you complete the
Network Setup Wizard you will use the Network Setup Disk to run the Network Setup
Wizard once on each of the computers on your network. To continue click Next.
Networking Basics
Networking Basics (continued)
26D-Link Systems, Inc.
DWL-700AP User’s Manual
Please read the information on this screen, then click Finish to complete the
Network Setup Wizard.
Networking Basics
Networking Basics (continued)
The new settings will take effect when you restart the computer. Click Yes to restart
the computer.
You have completed configuring this computer. Next, you will need to run the Network
Setup Disk on all the other computers on your network. After running the Network
Setup Disk on all your computers, your new wireless network will be ready to use.
27D-Link Systems, Inc.
DWL-700AP User’s Manual
Naming your Computer
To name your computer in Windows XP, please follow these directions:
Networking Basics (continued)
Click Start (in the lower left corner of the screen).
Right-click on My Computer.
Select Properties and click.
Networking Basics
Select the Computer
Name Tab in the System
Properties window.
You may enter a Computer Description if you wish;
this field is optional.
To rename the computer
and join a domain, Click
Change.
28D-Link Systems, Inc.
DWL-700AP User’s Manual
Naming your Computer
In this window, enter the
Computer name.
Select Workgroup and enter
the name of the Workgroup.
All computers on your network
must have the same Workgroup
name.
Click OK.
Networking Basics
Networking Basics (continued)
Checking the IP Address in Windows XP
The wireless adapter-equipped computers in your network must be in the same IP address range (see Getting Started in this manual for a definition of IP address range.)
To check on the IP address of the adapter, please do the following:
Right-click on
the Local Area
Connection icon
in the task bar.
Click on Status.
29D-Link Systems, Inc.
DWL-700AP User’s Manual
Checking the IP Address in Windows XP
This window will appear.
Click the
Support tab.
Networking Basics
Networking Basics (continued)
Click Close.
Assigning a Static IP Address in Windows XP/2000
Note: Some gateways/broadband routers will automatically assign IP addresses
to the computers on the network, using DHCP (Dynamic Host Configuration
Protocol) technology. If you are using a DHCP-capable gateway/router you will
not need to assign static IP addresses.
If you are not using a DHCP capable gateway/router, or you need to assign a static IP
address, please follow these instructions:
Go to Start.
Double-click on
Control Panel.
30D-Link Systems, Inc.
DWL-700AP User’s Manual
Assigning a Static IP Address in Windows XP/2000
Double-click on Network
Connections.
Networking Basics
Networking Basics (continued)
Right-click on Local Area
Connections.
Double-click on
Properties.
31D-Link Systems, Inc.
DWL-700AP User’s Manual
Assigning a Static IP Address in Windows XP/2000
Click on Internet Protocol
Click Properties.
Networking Basics
Networking Basics (continued)
(TCP/IP).
In the window below, select Use the following IP address. Input your IP
address and subnet mask. (The IP addresses on your network must be
within the same range. For example, if one computer has an IP address
of 192.168.0.2, the other computers should have IP addresses that are
sequential, like 192.168.0.3 and 192.168.0.4. The subnet mask must be
the same for all the computers on the network.)
IP Address:
e.g., 192.168.0.2
Subnet Mask:
255.255.255.0
Default Gateway:
Enter the LAN IP address of
the wireless router. (D-Link
wireless routers have a LAN
IP address of 192.168.0.1)
Select Use the following
DNS server address. Enter
the LAN IP address of the
wireless router. (D-Link
wireless routers have a LAN
IP address of 192.168.0.1)
Click OK.
You have completed the assignment of a static IP address. (You do not need to assign
a static IP address if you have a DHCP-capable gateway/router.)
32D-Link Systems, Inc.
DWL-700AP User’s Manual
Checking the Wireless Connection by Pinging in Windows XP/2000
Go to Start > Run >
type cmd. A window
similar to this one
will appear. Type
ping xxx.xxx.xxx.
xxx, where xxx is
the IP address of
the wireless router or
access point. A good
wireless connection
will show four replies
from the wireless
router or access
point, as shown.
Networking Basics
Networking Basics (continued)
Checking the Wireless Connection by Pinging in Windows Me/98
Go to Start > Run
> type command.
A window similar
to this will appear.
Type ping xxx.xxx.
xxx.xxx where xxx
is the IP address
of the wireless
router or access
point. A good
wireless connection
will show four
replies from the
wireless router or
access point, as
shown.
33D-Link Systems, Inc.
DWL-700AP User’s Manual
This chapter provides solutions to problems that can occur during the installation
and operation of the DWL-700AP. We cover various aspects of the network including
network adapters. (The examples below are illustrated in Windows XP. If you have
another operating system, these solutions will still apply although the appearance on
your computer screen may differ.)
Note: It is recommended that you use an Ethernet connection to configure the
DWL-700AP Access Point.
1. The computer used to configure the DWL-700AP cannot access the
Troubleshooting
Troubleshooting
configuration menu.
Check that the Ethernet LED on the DWL-700AP is ON. If the LED is
not ON, check that the cable for the Ethernet connection is securely
inserted.
Check that the Ethernet Adapter is working properly. Please see item
3 (Check that the drivers for the network adapters are installed
properly) in this Troubleshooting section to check that the drivers are
loaded properly.
Check that the IP address is in the same range and subnet as the
DWL-700AP. Please see Checking the IP Address in Windows XP
in the Networking Basics section of this manual.
Note: The IP address of the DWL-700AP is 192.168.0.50. All the computers on the
network must have a unique IP address in the same range, e.g., 192.168.0.x. Any
computers that have identical IP addresses will not be visible on the network.
They must all have the same subnet mask, e.g., 255.255.255.0
Do a Ping test to make sure that the DWL-700AP is responding. Go
to Start>Run>Type Command>Type ping 192.168.0.50. A successful
ping will show four replies.
34D-Link Systems, Inc.
DWL-700AP User’s Manual
2. The wireless client cannot access the Internet in the Infrastructure
mode.
Make sure the wireless client is associated and joined with the correct access
point. To check this connection: Right-click on the Local Area Connection
icon in the taskbar> select View Available Wireless Networks. The Connect
to Wireless Network screen will appear. Please make sure you have selected
the correct available network, as shown in the illustrations below.
Note: Screen shots were
taken using Windows XP. Your
screens may look similar.
Troubleshooting (continued)
default
default
Troubleshooting
Check that the IP address assigned to the wireless adapter is within the same
IP address range as the access point and gateway. Since the DWL-700AP has
an IP address of 192.168.0.50, wireless adapters must have an IP address in
the same range, e.g., 192.168.0.x. Each device must have a unique IP address;
no two devices may have the same IP address. The subnet mask must be the
same for all the computers on the network. To check the IP address assigned
to the wireless adapter, double-click on the Local Area Connection icon in
the taskbar > select the Support tab and the IP address will be displayed.
(Please refer to Checking the IP Address in the Networking Basics section
of this manual.)
If it is necessary to assign a static IP address to the wireless adapter, please
refer to the appropriate section in Networking Basics. If you are entering
a DNS server address you must also enter the default gateway address.
(Remember that if you have a DHCP-capable router, you will not need to
assign a static IP address. See Networking Basics: Assigning a Static IP
Address.)
35D-Link Systems, Inc.
DWL-700AP User’s Manual
3. Check that the drivers for the network adapters are installed properly.
You may be using different network adapters than those illustrated here, but this
procedure will remain the same, regardless of the type of network adapters you are
using.
Go to Start.
Right-click on My Computer.
Click Properties.
Troubleshooting
Troubleshooting (continued)
Select the Hardware Tab.
Click Device Manager.
36D-Link Systems, Inc.
DWL-700AP User’s Manual
Double-click on Network
adapters.
Right-click on D-Link Air
DWL-650 Wireless Cardbus
Adapter
(or whatever network adapter
you are using).
Troubleshooting
Troubleshooting (continued)
Select Properties to check
that the drivers are installed
properly.
Look under Device Status
to check that the device is
working properly.
D-Link Air DWL-650 Wireless Cardbus Adapter
D-Link Air DWL-650 Wireless Cardbus Adapter
D-Link Air DWL-650 Wireless Cardbus Adapter
Cardbus
Click OK.
37D-Link Systems, Inc.
DWL-700AP User’s Manual
4. Resetting the DWL-700AP to Factory Default Settings
After you have tried other methods for troubleshooting your network, you may
choose to reset the DWL-700AP to the factory default settings. Remember that
D-Link Air products network together, out of the box, at the factory default settings.
Troubleshooting
Troubleshooting (continued)
To hard-reset the D-Link Air DWL-700AP to the factory default settings, please do
the following:
Locate the reset button on the back of the DWL-700AP
Use a paper clip to press the reset button
Hold for about 5 seconds and then release
After the DWL-700AP reboots (this may take a few minutes) it will be reset
to the factory default settings.
38D-Link Systems, Inc.
DWL-700AP User’s Manual
Standards
Port:
Data Rates*:
Encryption:
Technical Specifications
Technical Specifications
IEEE 802.11
IEEE 802.11b
IEEE 802.3
IEEE 802.3u
10/100 Mbps Fast Ethernet
1, 2, 5.5, 11Mbps (with Automatic Fallback)
Supports 64 and 128-bit WEP
Media Access Controll:
CSMA/CA with ACK
Frequency Range:
2.4 – 2.462GHz
Operating Range:
Indoors - up to 328 feet (100 meters)
Modulation Technology:
DSSS - Direct Sequence Spread Spectrum
11-chip Barker sequence
* Maximum wireless signal rate based on IEEE Standard 802.11b specifications. Actual data
throughput will vary. Network conditions and environmental factors, including volume of network
traffic, building materials and construction, and network overhead lower actual data throughput
rate.
39D-Link Systems, Inc.
DWL-700AP User’s Manual
Technical Specifications (continued)
Technical Specifications
Modulation Techniques
Barker (1Mbps/0db)
Barker (2Mbps/3db)
Transmitter Output Power:
External Antenna Type:
Over-Driving Levels:
Device Management
CCK (5.5Mbps/5.5db)
CCK (11Mbps/8.5db)
15dBm +/- 2dB
2.5dB gain with reverse
SMA connector
Tolerates up to +17dBm at
the Antenna
Web-Based - Internet
Explorer v5 or later;
Netscape Navigator v4 or
later; or other Java-enabled
browsers.
Operating Temperature:
Physical Dimensions:
L = 5.5 inches
(140mm)
W = 4.5 inches
(114mm)
H = 1 inches
(25.4mm)
LEDs:
Power (Green)
Link (Green)
TX/RX (Green)
Power Input:
External Power
Supply: DC 5V, 2.4A
Weight:
.44 lbs. (200g)
Warranty:
1 Year
32ºF to 131ºF (0ºC to 55ºC)
Humidity:
5% - 95%, non-condensing
Safety & Emissions
FCC
UL
40D-Link Systems, Inc.
DWL-700AP User’s Manual
You can find software updates and user documentation on the D-Link website.
D-Link provides free technical support for customers within the United States and
within Canada for the duration of the warranty period on this product.
U.S. and Canadian customers can contact D-Link technical support through our
website, or by phone.
Tech Support for customers within the United States:
D-Link Technical Support over the Telephone:
(877) 453-5465
24 hours a day, seven days a week.
Technical Support
Technical Support
Technical Support
D-Link Technical Support over the Internet:
http://support.dlink.com
email:support@dlink.com
Tech Support for customers within Canada:
D-Link Technical Support over the Telephone:
(800) 361-5265
Monday to Friday 8:30am to 9:00pm EST
D-Link Technical Support over the Internet:
http://support.dlink.ca
email:support@dlink.ca
41D-Link Systems, Inc.
DWL-700AP User’s Manual
Subject to the terms and conditions set forth herein, D-Link Systems, Inc. (“D-Link”) provides this Limited
warranty for its product only to the person or entity that originally purchased the product from:
• D-Link or its authorized reseller or distributor and
• Products purchased and delivered within the fifty states of the United States, the District of Columbia,
U.S. Possessions or Protectorates, U.S. Military Installations, addresses with an APO or FPO.
Limited Warranty: D-Link warrants that the hardware portion of the D-Link products described below will
be free from material defects in workmanship and materials from the date of original retail purchase of the
product, for the period set forth below applicable to the product type (“Warranty Period”), except as otherwise
stated herein.
1-Year Limited Warranty for the Product(s) is defined as follows:
• Hardware (excluding power supplies and fans) One (1) Year
• Power Supplies and Fans One (1) Year
• Spare parts and spare kits Ninety (90) days
Warranty
Warranty
(USA only)
D-Link’s sole obligation shall be to repair or replace the defective Hardware during the Warranty Period at
no charge to the original owner or to refund at D-Link’s sole discretion. Such repair or replacement will be
rendered by D-Link at an Authorized D-Link Service Office. The replacement Hardware need not be new or
have an identical make, model or part. D-Link may in its sole discretion replace the defective Hardware (or
any part thereof) with any reconditioned product that D-Link reasonably determines is substantially equivalent
(or superior) in all material respects to the defective Hardware. Repaired or replacement Hardware will be
warranted for the remainder of the original Warranty Period from the date of original retail purchase. If a
material defect is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to
repair or replace the defective Hardware, the price paid by the original purchaser for the defective Hardware
will be refunded by D-Link upon return to D-Link of the defective Hardware. All Hardware (or part thereof) that
is replaced by D-Link, or for which the purchase price is refunded, shall become the property of D-Link upon
replacement or refund.
Limited Software Warranty: D-Link warrants that the software portion of the product (“Software”) will substantially
conform to D-Link’s then current functional specifications for the Software, as set forth in the applicable
documentation, from the date of original retail purchase of the Software for a period of ninety (90) days (“Warranty
Period”), provided that the Software is properly installed on approved hardware and operated as contemplated
in its documentation. D-Link further warrants that, during the Warranty Period, the magnetic media on which
D-Link delivers the Software will be free of physical defects. D-Link’s sole obligation shall be to replace the
non-conforming Software (or defective media) with software that substantially conforms to D-Link’s functional
specifications for the Software or to refund at D-Link’s sole discretion. Except as otherwise agreed by D-Link
in writing, the replacement Software is provided only to the original licensee, and is subject to the terms and
conditions of the license granted by D-Link for the Software. Software will be warranted for the remainder of the
original Warranty Period from the date or original retail purchase. If a material non-conformance is incapable
of correction, or if D-Link determines in its sole discretion that it is not practical to replace the non-conforming
Software, the price paid by the original licensee for the non-conforming Software will be refunded by D-Link;
provided that the non-conforming Software (and all copies thereof) is first returned to D-Link. The license
granted respecting any Software for which a refund is given automatically terminates.
Non-Applicability of Warranty: The Limited Warranty provided hereunder for hardware and software of DLink’s products will not be applied to and does not cover any refurbished product and any product purchased
through the inventory clearance or liquidation sale or other sales in which D-Link, the sellers, or the liquidators
expressly disclaim their warranty obligation pertaining to the product and in that case, the product is being
sold “As-Is” without any warranty whatsoever including, without limitation, the Limited Warranty as described
herein, notwithstanding anything stated herein to the contrary.
42D-Link Systems, Inc.
DWL-700AP User’s Manual
Warranty
Submitting A Claim: The customer shall return the product to the original purchase point based on its return
policy. In case the return policy period has expired and the product is within warranty, the customer shall
submit a claim to D-Link as outlined below:
• The customer must submit with the product as part of the claim a written description of the Hardware
defect or Software nonconformance in sufficient detail to allow D-Link to confirm the same.
• The original product owner must obtain a Return Material Authorization (“RMA”) number from the
Authorized D-Link Service Office and, if requested, provide written proof of purchase of the product (such
as a copy of the dated purchase invoice for the product) before the warranty service is provided.
• After an RMA number is issued, the defective product must be packaged securely in the original or
other suitable shipping package to ensure that it will not be damaged in transit, and the RMA number
must be prominently marked on the outside of the package. Do not include any manuals or accessories
in the shipping package. D-Link will only replace the defective portion of the Product and will not ship
back any accessories.
• The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”)
is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link.
Products shall be fully insured by the customer. D-Link will not be held responsible for any packages
that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer
via UPS Ground or any common carrier selected by D-Link, with shipping charges prepaid. Expedited
shipping is available if shipping charges are prepaid by the customer and upon request.
Warranty (Continued)
• Return Merchandise Ship-To Address
USA: 17595 Mt. Herrmann St. Fountain Valley, CA 92708
D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing
requirements, or for which an RMA number is not visible from the outside of the package. The product owner
agrees to pay D-Link’s reasonable handling and return shipping charges for any product that is not packaged
and shipped in accordance with the foregoing requirements, or that is determined by D-Link not to be defective
or non-conforming.
What Is Not Covered: This limited warranty provided by D-Link does not cover: Products, if in D-Link’s judgment,
have been subjected to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty
installation, lack of reasonable care, repair or service in any way that is not contemplated in the documentation
for the product, or if the model or serial number has been altered, tampered with, defaced or removed; Initial
installation, installation and removal of the product for repair, and shipping costs; Operational adjustments
covered in the operating manual for the product, and normal maintenance; Damage that occurs in shipment,
due to act of God, failures due to power surge, and cosmetic damage; Any hardware, software, firmware or
other products or services provided by anyone other than D-Link; Products that have been purchased from
inventory clearance or liquidation sales or other sales in which D-Link, the sellers, or the liquidators expressly
disclaim their warranty obligation pertaining to the product. Repair by anyone other than D-Link or an Authorized
D-Link Service Office will void this Warranty.
Disclaimer of Other Warranties: EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN, THE
PRODUCT IS PROVIDED “AS-IS” WITHOUT ANY WARRANTY OF ANY KIND WHATSOEVER INCLUDING,
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
AND NON-INFRINGEMENT. IF ANY IMPLIED WARRANTY CANNOT BE DISCLAIMED IN ANY TERRITORY
WHERE A PRODUCT IS SOLD, THE DURATION OF SUCH IMPLIED WARRANTY SHALL BE LIMITED TO
NINETY (90) DAYS. EXCEPT AS EXPRESSLY COVERED UNDER THE LIMITED WARRANTY PROVIDED
HEREIN, THE ENTIRE RISK AS TO THE QUALITY, SELECTION AND PERFORMANCE OF THE PRODUCT
IS WITH THE PURCHASER OF THE PRODUCT.
43D-Link Systems, Inc.
DWL-700AP User’s Manual
Limitation of Liability: TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS NOT LIABLE UNDER
ANY CONTRACT, NEGLIGENCE, STRICT LIABILITY OR OTHER LEGAL OR EQUITABLE THEORY FOR ANY
LOSS OF USE OF THE PRODUCT, INCONVENIENCE OR DAMAGES OF ANY CHARACTER, WHETHER
DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT NOT LIMITED TO, DAMAGES
FOR LOSS OF GOODWILL, LOSS OF REVENUE OR PROFIT, WORK STOPPAGE, COMPUTER FAILURE
OR MALFUNCTION, FAILURE OF OTHER EQUIPMENT OR COMPUTER PROGRAMS TO WHICH D-LINK’S
PRODUCT IS CONNECTED WITH, LOSS OF INFORMATION OR DATA CONTAINED IN, STORED ON, OR
INTEGRATED WITH ANY PRODUCT RETURNED TO D-LINK FOR WARRANTY SERVICE) RESULTING
FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY
BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS
REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NON-CONFORMING PRODUCT. THE
MAXIMUM LIABILITY OF D-LINK UNDER THIS WARRANTY IS LIMITED TO THE PURCHASE PRICE OF
THE PRODUCT COVERED BY THE WARRANTY. THE FOREGOING EXPRESS WRITTEN WARRANTIES
AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ANY OTHER WARRANTIES OR REMEDIES,
EXPRESS, IMPLIED OR STATUTORY.
Governing Law: This Limited Warranty shall be governed by the laws of the State of California. Some states do
not allow exclusion or limitation of incidental or consequential damages, or limitations on how long an implied
warranty lasts, so the foregoing limitations and exclusions may not apply. This limited warranty provides specific
legal rights and the product owner may also have other rights which vary from state to state.
Warranty
Warranty (Continued)
Trademarks: D-Link is a registered trademark of D-Link Systems, Inc. Other trademarks or registered trademarks
are the property of their respective manufacturers or owners.
Copyright Statement: No part of this publication or documentation accompanying this Product may be
reproduced in any form or by any means or used to make any derivative such as translation, transformation,
or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United
States Copyright Act of 1976. Contents are subject to change without prior notice. Copyright© 2002 by DLink Corporation/D-Link Systems, Inc. All rights reserved.
CE Mark Warning: This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communication. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
For detailed warranty outside the United States, please contact corresponding local D-Link office.
44D-Link Systems, Inc.
DWL-700AP User’s Manual
FCC Caution:
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications
to this equipment; such modifications could void the user’s authority to operate the equipment.
(1) The devices are restricted to indoor operations within the 5.15 to 5.25GHz range. (2) For this device
to operate in the 5.15 to 5.25GHz range, the devices must use integral antennas.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
The antenna(s) used for this equipment must be installed to provide a separation distance of at least
eight inches (20 cm) from all persons.
This equipment must not be operated in conjunction with any other antenna.
Warranty
Warranty (Continued)
45D-Link Systems, Inc.
DWL-700AP User’s Manual
Registration
Product registration is entirely voluntary and failure to complete or return this form will not
diminish your warranty rights.
Version 1.3
06/02/05
46D-Link Systems, Inc.
Loading...
