DIGIWEIGH DWP-11K User Manual

DWP-10000R

DWP-1000R

DWP-11KR

Floor / Pallet Scale

DWP-5500R (Floor Scale)

DWP-102E (Indicator)

User Manual

A12-51007 V1.0

Content

CHAPTER 1 MAIN SPECIFICATION

CHAPTER 2 INSTALLATION

2.0 SCALE BASE SET UP

2.1 FRONT AND BACK VIEW OF INDICATOR

2.2 KEY FUNCTIONS

2.3 CONNECTING LOAD CELL TO INDICATOR

CHAPTER 3 OPERATION

3.1 POWER ON & ZERO SETTING

3.2 MANUAL ZERO SETTING

3.3 TARE

3.4 ACCUMULATING

3.5 COUNTING

3.6 USER FUNCTION STEETING

3.7 CONNECT SCOREBOARD TO INDICATOR

3.8 SERIAL COMMUNICATION AND INDICATOR COMMECTION

CHAPTER 4 SETTING PARAMETERS

CHAPTER 5 CALIBRATION

CHAPTER 6 ERROR INDICATION

Floor / Pallet Scale - 1 -

Chapter 1 Main Specification

1. Model: DWP-5500R Floor / Pallet scale

2. Accuracy: Grade Ⅲ, n=5000

3. Sample Rate: 10 times / second

4. Load cell sensitivity 1.5～3mV / V

5. Scale interval: 1/2/5/10/20/50 for option

6. Display: 6 bits LED，6 state indicating signals

7. Power supply: Battery DC6V/4AH

8. Operating temperature/humidity: 0～40℃; ≤90%RH

9. Transporting temperature: -20～50℃

Floor / Pallet Scale - 2 -
